Using Skin Segmentation to Improve Similar Product

Recommendations in Online Clothing Stores

Noran Hasan, Ahmed Hamouda, Tamer Deif , Motaz El-Sabban and Ramy Shahin

Microsoft Research Advanced Technology Labls in Cairo, 306 Cornish El Maadi, Basatin District, Cairo, Egypt

Keywords: Skin Segmentation, Image Matching and Retrieval.

Abstract: Image matching and retrieval in the domain of clothing, as used in online shopping for recommending

similar products, is often distracted by the existence of a mannequin/model wearing the product. The

existence of a model adds clutter to both the shape and color features of the product. In this paper, we

propose a novel image pre-processing pipeline that minimizes skin and background segments generated

from generic GraphCut segmentation. Experiments judged by human subjects show very promising gains of

around 23% in retrieval precision of the top 25 similar products compared to the baseline system.

1 INTRODUCTION

Online shopping allows consumers to browse and

purchase products online. Online stores often rely on

images, some textual descriptions, and sometimes

videos, to represent and showcase products. To help

consumers find products that better match their

needs, or merely to expose to them other options,

online stores try to recommend to consumers

products that are similar to the ones they are

browsing.

Recommending similar products requires a

metric that would capture product similarity. For

some products, such as clothing, how the product

looks is an integral factor in the consumer’s decision

to purchase, therefore the visual similarity between

products is an important dimension of product

similarity. It is reasonable to assume that consumers

would be interested in clothing items that are similar

in form and/or color to the items they are browsing.

That is in contrast to other products, such as books,

where the visual similarity of products is

insignificant.

There are a number of challenges in image

retrieval such as complex backgrounds, viewpoint

variation, etc. A challenge in the domain of clothing

that we focus on in this paper is that the items are

sometimes worn by a model in the product’s image.

Therefore, the visual representation of the product,

including shape and color, would be cluttered by the

model’s shape and skin color. Consequently, the

recommended products will be affected by whether

or not these products are worn by a model in their

images.

There is little work done on retrieval of clothing

images. Recently, Grana et al, 2012, have presented

a color-based technique for fashion-retrieval. They

have a pre-processing step to remove skin or

mannequin parts but they do not provide details of

their skin removal technique or an analysis of the

effect of skin removal on retrieval. Our contributions

include:

 Proposing a novel skin region removal pipeline

tailored to enhancing visual product search quality

 conducting experiments and reporting very

promising evaluation results on a large image dataset

of 1 million product images from a commercial

search engine

To motivate the work in this paper, we illustrate

in Table 1 how the top results of image matching are

different for the exact same product with and

without a human model. With a model, most of the

results returned also include a model. When the

model was manually removed from the image, the

results returned were mostly images that do not

contain a model. This supports the assumption that

the existence/absence of a model influnces the image

matching system’s decision that should ultimately

measure similarity based on the products’ visual

features independent of a possibly existing model.

In this paper, we present a technique that

uses skin detection to identify body parts and

693

Hasan N., Hamouda A., Deif T., El-Sabban M. and Shahin R..

Using Skin Segmentation to Improve Similar Product Recommendations in Online Clothing Stores.

DOI: 10.5220/0004299906930700

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 693-700

ISBN: 978-989-8565-47-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Table 1: Bias of results to existence/absence of a model.

With a model Without a model

Query Image

Top Results

automatically remove those before the visual

descriptors are extracted.

In Section 2, we refer to some related work in the

fields of image retreival, image indexing, fashion

retrieval, and skin detection. In Section 3, we

describe the system into which we apply skin

removal and in Section 4, we describe our skin

removal technique. In Section 5, we present our

judging methodology and results. Finally in Section

6, we conclude the paper and discuss future work.

2 RELATED WORK

Although there is a lot of work being done on image

retrieval in general, there is little work done on the

specific domain of clothing retrieval. Recently,

Grana et al, 2012, presented their work on fashion

retrieval based solely on color using a color bag of

words signature. They describe garments by a single

dominant color and therefore focus only on images

with a unique color classification. Arguing that

uniform color space division and color space

clustering don’t reflect fashion color jargon, they use

color classes that label garments in their training set

to split the color space in a way that minimizes error

between these color classes. They use automatic pre-

processing to remove skin and mannequin parts and

then use GrabCut (Rother et al., 2004) to remove

clothing items that are not the main garment

depicted in an image. However, they don’t provide a

description of their skin removal approach in this

pre-processing step and its impact on retrieval.

Skin detection has been approached by

researchers with different methodologies including

explicit color space thresholding and histogram

models with naïve Bayes classifiers which we

discuss later (Kakumanu et al., 2007). However, we

noticed that the precision of most of the proposed

techniques is not high. That is mainly because those

techniques depend on analysing the images in the

visible color spectrum without any attention to the

context. This is not optimal because many factors

(like illumination, camera characteristics, shadows,

makeup, etc…) affect the skin color significantly. A

workaround is to move the problem to the non-

visible color spectrum (Infra-red range), in which

the skin color seems to be more consistent across

different conditions. However, the equipment

needed is more expensive and usually not available

in consumer devices.

3 EXISTING SYSTEM

We integrate our skin removal component in an

existing clothing retrieval system (running on a

commercial search engine) which we briefly

describe in this section. Figure 3 shows a high-level

overview of the system. In the coming subsections,

we briefly describe the features extracted. In the

following section, we describe our skin removal

component and how it fits in this system.

The features generated for each image are

contours to capture shape, and a single RGB value

that captures the most dominant color. The image

indexing and retrieval system is based upon the

Edgel index by Cao et. Al, 2011.

3.1 Visual Representation

When a query image is submitted, a list of candidate

similar edges is retrieved from an inverted index

(Sivic and Zisserman, 2003). This list is ranked

based on a composite score of the edge similarity,

salient color similarity, and textual description

similarity. Our interest is in improving the edge

similarity score by removing unwanted edges and

therefore improving this metric’s semantic quality.

By removing such edges, we also potentially impact

the salient color extracted as motivated in figure 2.

3.1.1 Image Pre-processing

To reduce computation and storage costs while

preserving information, the image is first downsized

to a maximum dimension of 200 pixels (Cao et. Al,

2011). The downsized image is then segmented

using GraphCut (Felzenszwalb and Huttenlocher,

2004). The output is a segmented image where each

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

694

segment is colored by the mean color of its pixels

(see figure 1). It is then passed on to the salient color

extractor. It is also converted to grayscale and

passed on to the edge detection component.

3.1.2 Edge Detection

The grayscale segmented image is fed to a Canny

detector to find contours. Contours are broken up at

inflection points and very short edges are discarded.

These edges are then used to create an inverted-

index for the images. This inverted-index is used to

retrieve the most similar images in terms of shape.

The salient color is then used to rank the returned

results.

3.1.3 Salient Color Extraction

When the image is segmented, the output image of

segmentation is colored by the mean color of the

pixels inside this segment. After edge detection, and

based on the assumption that the background is a

simple and homogeneous, the foreground bounding

box is determined by the minimum box that

encompasses all detected edges. Once this bounding

box is found, an RGB histogram is created for this

area of the segmented RGB image. The top color in

the histogram is considered the salient color. To

further avoid the background color, that is usually

white in this domain, if the top color is white, the

next color is considered the salient color.

3.2 Index Generation

An inverted-index based on edges is used for fast

retrieval of similar images. It is out of the scope of

this paper to delve into the details of this component,

but what we like to stress is the importance of the

edges and their direct impact on the quality of

similar images retrieved. Therefore, our work

explained in the next section attempts to remove

unwanted edges before they are fed to the index

generation component.

4 SKIN REMOVAL

METHODOLOGY

The purpose of our work is to eliminate from

products’ images edges that define the model’s body

rather than the product itself. Since edge detection is

performed on the segmented image as explained in

Section 3, we need to blend the skin segments with

background segments so that the edge detector

doesn’t detect these unwanted edges. Figure 3 shows

where our contribution is integrated to the system.

Figure 5 shows an overview of our skin removal

technique. Figure 4 shows an examples on how the

edges changed with skin removal.

In the following sub-sections, we explain why

we chose this point of integration, how we do the

skin to background blending, issues that we faced,

and how we handled them.

Figure 1: Stages leading to edge extraction. Top-left: The

input image. Top-right: The segmented image with each

segment colored by the average color of its pixels.

Bottom-left: Grayscale of segmented image. Bottom-right:

Edges detected by the Canny detector.

Figure 2: Two examples of salient colors extracted. The

example on the left shows an accurate salient color, and

the example on the right shows how the model’s skin

dominated the salient color, and a better salient color was

produced after skin removal.

4.1 Skin Detection

The majority of state-of-the-art techniques rely on

color for skin detection. Leading approaches either

use explicit color space thresholding or model skin

color within the color space. Therefore, we

investigated two skin detection techniques that

where suggested in the excellent survey by

Kakumanu et al, 2007; explicit thresholding in the

YCbCr color space, and histogram modelling with a

naïve Bayes classifier. In the first technique, the

image is converted into the YCbCr color space, and

then a threshold is used to classify skin vs. non-skin

pixels. The ranges we used were applied on the Cb

and Cr components (Cb=[77,127], and

Cr=[133,173]).

UsingSkinSegmentationtoImproveSimilarProductRecommendationsinOnlineClothingStores

695

Figure 3: Overview of the system after skin removal

integration.

As described in (Kakumanu et al, 2007) and (Jones

and Rehg, 2002), we developed a histogram model

with naïve Bayes classifiers. The idea is to

approximate the probability distributions of color for

skin pixels and for non-skin pixels. Training images

are first converted to the Lab color space and then a

3D bin model is built by clustering the pixels

according to their L, A, and B values into 64

clusters. The centroid of each cluster is chosen as its

representative. The next step is creating a histogram

model by counting the pixels that fall in each bin.

This was done by measuring the Euclidean distance

between each training pixel and the 64 clusters and

then assigning it to the closest cluster. Once the

model is ready, it is used to classify pixels in the test

images. For each pixel, the probabilities of it being

a skin vs. a non-skin pixel are compared and it is

classified accordingly.

To evaluate the different skin detection

techniques, we manually labelled 265 images,

trained the histogram model on 185 images and used

80 for evaluation. The dataset includes challenging

samples where the product color is similar to skin

colors (e.g. beige, brown). Figure 7 shows samples

of the data and how they were labelled.

To blend skin with the background, skin pixels

need to be identified. When skin classification is

done on the pixel-level on the original image before

segmentation, misses can lead to non-homogenous

areas (see middle of figure 6) that would result in

more unwanted edges being detected. However,

classifying all pixels in a segment collectively

ensures that no new unwanted edges are introduced

by skin removal (see right of figure 6).

Figure 4: Effect of skin removal on detected edges (colors

denote different contour segments). Top left: Input image.

Bottom left: Segmented colored image. Middle top:

Grayscale of segmented image. Middle bottom: Edges

detected without skin removal. Right top: Segmented

image after removing skin segments. Right bottom: Edges

detected after removing skin segments.

Figure 5: Overview of skin removal technique.

Moreover, segment-level classification is much

faster since all pixels in a segment only need a single

classification, rather than once for each pixel (or for

each possible RGB value in the image). Therefore,

we found that it makes more sense to perform skin

detection and removal on the segmented image

rather than the raw image.

Conversion to

Gra

scale

Skin Removal

Edge Detection

Index Generation

Salient Color

Extraction

Image Segmentation

Skin

Detectio

Background

Detection

Thin

ments

Do the skin detected

ratio to foreground,

andtotal coloring

ratio to entire image

exceed thresholds?

Color skin, background

segments, skin segments and

thin segments white

nothing

Yes

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

696

Table 2: Comparison of explicit thresholding and training

our own histogram model for skin detection.

Explicit

Threshold

Trained Histogram Model,

threshold at:

0.5 1.5 2.5

Precision 24% 29% 39% 60%

Recall 99% 65% 36% 6%

Accuracy 79% 87% 92% 93%

False

Positive

Rate

76% 71% 61% 40%

Figure 6: Left: Input image. Middle: White areas show

per-pixel positive skin classifications. Right: White areas

show per-segment positive skin classifications.

Figure 7: Examples of images labelled for skin.

Figure 8: Blue areas mark segments classified as

background.

4.2 Skin Segment Coloring

To prevent skin edges from being detected, we need

to blend skin segments with the background.

Intuitively, we considered coloring skin segments

with the same color as the closest background

segment. The measure of proximity can be done in a

number of ways. We tried using the distance

between segments’ centroid as the measure of

proximity but that sometimes resulted in that the

nearest segment selected is not adjacent to the skin

segment. Therefore, the segment edges are still

visible. Even when that problem doesn’t occur, the

background that appears homogenous may include

slightly different colors, and therefore when each

segment is colored by the color of its nearest

background segment, some edges are desirably lost

but other edges persist (see figure 9). Therefore,

even if the proximity measure ensures that the

segments are adjacent, the results would still be

unsatisfactory.

4.2.1 Background Detection

Due to the nature of online clothing images, the vast

majority of images have simple backgrounds.

Taking advantage of that and to avoid more complex

background detection algorithms, such as GrabCut

(Rother et al, 2004), we devised a simple algorithm

to detect the background. Since, the image is already

segmented, we classify a segment as background if it

intersects with the image border. This approach has

demonstrated satisfactory results (see figure 8).

Consequently, we decided to color all the skin

and background segments by the same color.

However, this approach surfaced a problem with

thin segments that we discuss next.

Figure 9: The effect of coloring a skin segment by the

color of the nearest background segment in terms of

distance between segment centroids.

4.2.2 Thin segments

We noticed that in some images, there are thin

spurious segments that exist between skin and

background segments that have been missed by both

skin and background detectors. Although they are

initially not very visible, they become very visible

when the skin and background segments are colored

white (see figure 10). To classify a segment as thin

or not, we first need to identify its bounding box as

the minimum and maximum values it reaches in the

x and y dimensions. We then calculate the area of

the segment’s bounding box as well as the actual

area of the segment which is the count of pixels that

belong to this segment. We then define the area ratio

which aims to capture curved or diagonal thin

segments as:

UsingSkinSegmentationtoImproveSimilarProductRecommendationsinOnlineClothingStores

697

Arearatio 

Actualarea

Boundingboxarea

(1)

We also calculate the segments’ elongation which

aims to capture thin, fairly straight thin segments

that are vertical or horizontal. We define it as the

ratio between the horizontal and vertical dimensions:

Elongation 

maximumwidth, height

minimumwidth, height

(2)

A segment is classified as thin if its elongation is

greater than 10 or its area ratio is less than 20%.

Figure 10: Left: Segmented colored image image. Middle:

After skin removal and without handling thin segments.

Right: After removing thin segments.

Figure 11: Two examples of products that are very similar

in color to skin. The red areas mark those erroneously

classified as skin.

4.3 False-positive Handling

Some products have a color that is very close to skin

color and are therefore erroneously classified as skin

(see Figure 11). To overcome this issue, we make

sure that skin removal is only performed if the

percentage of the foreground detected as skin is less

than a certain threshold. With some experimentation

we found that 70% is a reasonable threshold.

To combat cases of where background and thin

segments may have been falsely detected parts of the

garment, we also check that the total coloring does

not exceed 90% of the entire image. If this threshold

is exceeded, skin removal is skipped for that image.

5 RESULTS

5.1 Data Selection

To evaluate the effectiveness of our skin removal

approach in improving the visual relevance of the

retrieved product matches, three product categories

are selected: jackets, dresses and skirts. For each

category, a representative sample of twenty images

is selected to be used as queries, for which the

visually-similar matches from the same category are

retrieved. The query is issued against a database of

around 24,000 dresses, 49,500 jackets and 32,500

skirts. For each of the selected queries, the top 25

matches are retrieved. A total number of 1500 (3

categories * 20 queries * 25 matches) pairs are

judged as described later in the following section. To

select the best thresholds, skin coloring techniques,

etc., multiple experiments were run and their results

were evaluated. It is worth noting that the number of

pairs to be judged exceeded the total number above

because of evaluating multiple experiments. Each

experiment results in the generation of a new index

which potentially results in new matches per query.

5.2 Judging Process

In an effort to better simulate the consumer’s online

shopping experience, five human judges were asked

to judge the similarity between each product and its

corresponding top matches. All judges were

assigned exactly the same set of pairwise product-

matches from the three product categories

mentioned above. Each judge is presented with a

pairwise comparison between a product and a

visually-similar candidate match. The pairs are

presented in a random order from all categories. The

judge is asked to rate each pair, based on the visual

similarity, on a scale of 1 to 4 where: (1 = Very

Different, 2 = Somewhat Different, 3 = Somewhat

similar, 4 = Very Similar). Figure 12 illustrates the

description of each rating along with example pairs.

5.3 Evaluation Technique

The goal of the evaluation process is to measure the

amount of improvement achieved due to adopting

the skin removal approach in the index generation

process. As mentioned before, we have tried several

variations of our skin removal technique and for

each, a new index is generated. Once a new index is

ready, each of the selected twenty queries per

category is issued to get the top 25 matches. The

new pairs then go into the judging cycle. Each pair

gets five rates from the judges. We define the

Average Judging Rate (AJR) as the average of all

rates provided by the judges. It is worth noting that

each pair gets exactly a single rate per judge,

regardless of index that resulted in that rate.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

698

The evaluation is done by means of precision

that is defined as:

Precision 

  

(3)

where TP (True Positive) represents the number of

similar products retrieved by the system and got an

AJR between 2 and 4. FP (False Positive) represents

the number of similar products retrieved by the

system and got an AJR less than 2. The preferred

metric is precision because it captures the user

experience in terms of whether the retrieved results

are relevant or not. Recall, however, is not used

because it is unfeasible to comprehensively evaluate

all matches of each query against the entire database.

Using the evaluation scheme above, an initial

version of the system (without adopting any skin

removal method) is evaluated and considered the

baseline. Consequently, each skin removal

experiment conducted is evaluated and compared to

the baseline to measure the amount of improvement.

5.4 Results

Tables 3 and 4 show the top 5 and 25 matches,

respectively, for different skin coloring techniques.

We compare 3 different techniques:

 Nearest Background Segment Color (NBSC):

Coloring skin segments by the color of its nearest

background segment where the proximity measure

is based on the distance between segment centroids

 Dominant Background Color (DBC): Coloring

skin and background segments by the color of

largest background segment.

 Single Color (SC): Color skin and background

segments by a single new color (white).

The results show that the best technique is Single

Color coloring where the average precision

increased from the baseline precision 0.56 to 0.64 on

the top 5 matches, and 0.43 to 0.53 on the top 25

matches. As discussed in section 4.3, coloring a

segment by its nearest background segment does not

remove all skin edges even if skin segments are

correctly classified. That is because backgrounds

that appear homogenous probably include multiple

similar shades, and therefore some edges will persist

(refer to figure 9). Dominant Background Color

performs comparable to Single Color in the top 5

matches but is worse in the top 25 matches. It is

possible that the dominant color negatively

influences the salient color, while white doesn’t

(refer to section 3.2).

To visually demonstrate the impact of skin

removal on retrieval, figure 13 shows an example of

the top 4 matches for a query dress image before and

after using our best skin removal technique using

Single Color coloring. Table 5 shows the AJRs for

both the baseline and post-skin-removal matches.

The precision for the top 4 matches is shown

calculated as explained in section 5.3 where an AJR

of 2 or more is considered a TP, and an AJR below 2

is considered a FP. In this particular example, the

precision went up from 0.25 to 0.75.

Table 3: Comparison of the precision of the top 5 matches

for different skin segment coloring techniques.

Dresses Jackets Skirts Average

Baseline 0.54 0.62 0.51 0.56

NBSC

0.54 0.70 0.58 0.61

DBC

0.62 0.68 0.60 0.63

0.64 0.68 0.60 0.64

Table 4: Comparison of the precision of the top 25

matches for different skin segment coloring techniques.

Dresses Jackets Skirts Average

Baseline 0.37 0.52 0.39 0.43

NBSC

0.44 0.57 0.48 0.49

DBC

0.38 0.38 0.59 0.45

0.50 0.58 0.51 0.53

Table 5: AJR for results in figure 13 and the precision for

the top 4 results.

Rank Baseline AJR After skin removal AJR

11.6 2

21.8 2

32 1.8

41.2 2.8

Precision 0.25 0.75

Figure 12: Left-to-right: An image of a query product, a

very different product (very different form and color), a

somewhat different product (different color and different

form, but both color and form are somewhat similar), a

somewhat similar product (either the form or color is

similar, and the other is different)., a very similar (similar

color and similar form).

UsingSkinSegmentationtoImproveSimilarProductRecommendationsinOnlineClothingStores

699

Figure 13: Example top 4 matches before and after skin

removal. Top row: query image. Left column: baseline

results. Right column: results after skin removal.

6 CONCLUSION & FUTURE

WORK

We used skin removal to improve similar products

retrieval in the domain of clothing. We tried our

technique on 3 types of clothing; dresses, jackets and

skirts. The results show improvement in precision as

measured for up to the top 25 matches. Skin removal

helped remove unwanted edges and improve salient

color extraction, which in turn increased relevance.

Potential future work includes developing the

technique to handle more complex cases such as

complex backgrounds, multiple viewpoints of a

product in the same image, and multiple products

depicted in the same image, e.g. a top and skirt

where the skirt is the product of interest. It is

possible to leverage knowledge of the product

category to better choose representative edges and

better identify the region that has the color of

interest. Also, the product metadata, such as color

description, can be used to better localize the

product region in the image. In addition, a more

complex color descriptor can be devised to better

describe products that consist of multiple colors.

REFERENCES

Canny, J., 1983. A Computational Approach to Edge

Detection. IEEE Transactions on Pattern Analysis and

Machine Intelligence.

Cao, Y., Wang, C., Zhang, L., Zhang, L., 2011. Edgel

Index for Large-Scale Sketch-based Image Search.

IEEE Conference on Computer Vision and Pattern

Recognition.

Datta, R., Joshi, D., Li, J., Wang, J. Z. 2008. Image

retrieval: Ideas, influences, and trends of the new age.

ACM Computing Surveys.

Felzenszwalb, P. F., Huttenlocher, D. P., 2004. Efficient

Graph-Based Image Segmentation . International

Journal of Computer Vision.

Grana, C., Borghesani, D., Cucchiara, R., 2012, Class-

based Color Bag of Words for Fashion Retrieval.

IEEE International Conference on Multimedia and

Expo.

Jones, M. J., Rehg, J. M., 2002. Statistical Color Models

with Application to Skin Detection. International

Journal of Computer Vision.

Kakumanu, P., Makrogiannis, S., Bourbakis, N., 2007. A

survey of skin-color modeling and detection methods.

Pattern Recognition.

Martin, D. R., Fowlkes, C. C., Malik, J., 2004. Learning to

detect natural image boundaries using local brightness,

color, and texture cues. Pattern Analysis and Machine

Intelligence.

Rother, C., Kolmogorov, V., Blake, A., 2004. GrabCut:

interactive foreground extraction using iterated graph

cuts. ACM SIGGRAPH.

Sivic, J., Zisserman, A., 2003. Video Google: a text

retrieval approach to object matching in videos.

Proceesings of the 9

IEEE International Conference

on Computer Vison.

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

700
