Towards Automatic Direct Observation of Procedure and Skill (DOPS) in

Colonoscopy

Mirko Arnold

, Anarta Ghosh

, Glen Doherty

, Hugh Mulcahy

, Christopher Steele

, Stephen

Patchett

and Gerard Lacey

School of Computer Science and Statistics, Trinity College Dublin, Dublin, Ireland

Centre for Colorectal Disease, St. Vincent’s University Hospital, University College Dublin, Dublin, Ireland

FRCP, Letterkenny General Hospital Donegal, Letterkenny, Ireland

Beaumont Hospital, Royal College of Surgeons in Ireland, Dublin, Ireland

Keywords:

Medical Computer Vision, Medical Image Applications, Endoscopic Imaging, Vision-based Quality Assess-

ment, Colonoscopy, Machine Learning.

Abstract:

The quality of individual colonoscopy procedures is currently assessed by the performing endoscopist. In

light of the recently reported quality issues in colonoscopy screening, there may be signiﬁcant beneﬁts in

augmenting this form of self-assessment by automatic assistance systems. In this paper, we propose a system

for the assessment of individual colonoscopy procedures, based on image analysis and machine learning. The

system rates the procedures according to criteria of the validated Direct Observation of Procedure and Skill

(DOPS) assessment, developed by the Joint Advisory Group on GI Endoscopy (JAG) in the UK, a system

involving expert assessment of procedures based on an assessment form.

1 INTRODUCTION

Colonoscopy is considered the gold standard for colo-

rectal cancer screening. In addition to a thorough

visualisation of the large intestine, it is possible to

directly take tissue samples or remove polyps. De-

tection and removal of such polyps can prevent them

from developing into cancer, which is why many or-

ganisations recommend regular colorectal screening

for people over a certain age (U.S. Preventive Ser-

vices Task Force, 2008; WGO, 2007). With the com-

mencement of screening programs for asymptomatic

patients in more and more countries (Benson et al.,

2008), the number of colonoscopy procedures is con-

stantly growing.

While colonoscopy can reduce the incidence of

colorectal cancer, it does not eliminate the risk com-

pletely. In fact, studies have shown that in prac-

tice, the percentage of patients developing colorec-

tal cancer shortly after having undergone colonoscopy

screening is between 2 % and 6 % (Bressler et al.,

2007). Since the development of small polyps into

cancer is known to be a gradual process that evolves

slowly over years, this means that a signiﬁcant num-

ber of polyps remain undetected despite colonoscopy

screening.

The cause for these miss rates is not yet well un-

derstood. It is likely to be a combination of a number

of factors. Screening technique and bowel preparation

play an important role, as they determine the amount

of colonic mucosa that is visualised. Perceptual and

cognitive aspects have to be taken into account where

visualised polyps are not correctly identiﬁed by the

endoscopist.

In practice, the quality of colonoscopy procedures

is self-assessed by the performing endoscopist. Addi-

tionally, a number of measures are recorded for sta-

tistical evaluation. Examples of such a measures are

the average withdrawal time or the adenoma detec-

tion rate. These measures, however, can only assess

the average performance of the endoscopist.

For individual procedures there exist subjective

quality measures such as the direct observation and

assessment of the procedures by one or more experts.

Due to the cost of trained experts it is impractica-

ble to use this form of quality assessment more than

for occasional audits or as part of the examination of

trainees. The routine assessment of individual proce-

dures is the task of the performing endoscopist alone.

In this paper, we propose an image analysis and

machine learning based system for automatic assess-

ment of individual procedures according to criteria

Arnold M., Ghosh A., Doherty G., Mulcahy H., Steele C., Patchett S. and Lacey G..

Towards Automatic Direct Observation of Procedure and Skill (DOPS) in Colonoscopy.

DOI: 10.5220/0004300800480053

In Proceedings of the International Conference on Computer Vision Theory and Applications (VISAPP-2013), pages 48-53

ISBN: 978-989-8565-48-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

of the Direct Observation of Procedure and Skill

(DOPS) assessment method developed by the Joint

Advisory Group on GI Endoscopy (JAG) in the UK.

We consider JAG DOPS to be particularly relevant,

as it is the most mature among the available assess-

ment systems and in active use within the NHS Bowel

Cancer Screening Programme in the UK, while others

have yet to be implemented. A standard JAG DOPS

assessment involves the observation of colonoscopy

procedures by two trained experts, who rate the pro-

cedures independent of each other by ﬁlling out a pre-

deﬁned assessment form.

This assessment form is divided into four groups

of criteria: 1) Assessment, Consent, Communication,

2) Safety and Sedation, 3) Endoscopic Skills During

Insertion and Procedure and 4) Diagnostic and Ther-

apeutic Ability. We concentrate on the criteria in the

third group with the objective to measure automati-

cally, to what degree the technical prerequisites are in

place for a high quality colonoscopy screening.

2 BACKGROUND

Automatic computation of quality indicators from

colonoscopy video data has only been marginally ad-

dressed in the literature, despite the interest of the

medical research community.

Hwang, et. al (Hwang et al., 2005), combined

indistinct frame detection, camera motion estimation

and lumen recognition to obtain a number of qual-

ity measures that are mostly related to durations of

semantic segments of the video. Examples are the

duration of the insertion phase and the withdrawal

phase, or the duration of the withdrawal phase dis-

regarding all indistinct frames (the clear withdrawal

time). An interesting measure is also the ratio of wall

views and lumen views, which should be properly bal-

anced, according to the authors. In a more recent ar-

ticle (Oh et al., 2009), the same authors included also

their intervention detection method to determine the

clear and intervention-free withdrawal time.

Liu, et al. (Liu et al., 2007), addressed a differ-

ent aspect of procedure quality by evaluating, whether

the camera was pointed at all sides of a colon seg-

ment. They deﬁned the location of the lumen as the

centre, subdivided the view deviations from the lu-

men direction into four quadrants and computed a his-

togram of the number of images, in which the camera

was pointed in the direction of the different quadrants.

The authors argued that examination of all four quad-

rants is desirable. This can be seen as a ﬁrst attempt

to measure the amount of mucosal surface that was

visualised during a procedure. Liu, et al., recently

proposed an amended version of their approach (Liu

et al., 2010), mainly with an improved method for de-

tecting the lumen position. Apart from this, the his-

togram measure was replaced by counting the number

of spirals (the coverage of all 4 quadrants) in a proce-

dure. Both approaches do not take into account the

forward and backward motion of the camera. A fast

movement through a 20 cm long segment of the colon

would get a similar score as a careful slow inspection

of a very short segment.

In summary, the literature offers only few sugges-

tions for quality measures, that can be determined au-

tomatically. Measuring the insertion and withdrawal

time is only valid when looking at an average over

many procedures. Measures for individual cases, such

as the wall-view/lumen-view ratio or the quadrant

coverage histogram, have yet to be evaluated for va-

lidity. We consider it beneﬁcial to look into measures

that represent generally accepted insertion and exam-

ination techniques and best practices, which we do in

this paper.

3 APPROACH

There are two different types of data we consider in

our approach. One is video data from the endoscopic

camera. The other are measurements of the longi-

tudinal and circular motion of the shaft of the endo-

scope outside the anus using a sensor device. We use

a number of algorithms to measure patterns of image

features and endoscope motion for modelling the un-

derlying characteristics of the JAG DOPS assessment

criteria.

The individual measures are organised into two

levels. The ﬁrst contains all measures characteris-

ing single images, while the second level of measures

describes characteristics of the complete procedures.

The measures of single images are included in the

second level by summarising their behaviour over the

course of the procedure.

For the procedure measures and their mapping

to DOPS criteria we use data obtained from an ex-

periment we conducted, in which endoscopists per-

formed screening procedures on a colonoscopy train-

ing model. The data comprises videos from the endo-

scope camera together with motion sensor readings,

proﬁle data of the endoscopists and ratings of the

procedures by two trained experts according to JAG

DOPS criteria. The motion sensor readings are com-

bined with the image based characteristics to measure

a number of endoscope handling patterns. Further-

more, we use the recorded longitudinal motion of the

shaft of the endoscope to estimate the depth of inser-

TowardsAutomaticDirectObservationofProcedureandSkill(DOPS)inColonoscopy

Orifice

Sensor

Readings

Video

Data

Image Measures

Clarity of Endoscopic

Field of View

Lumen Position

Lumen Presence

Luminal View Quality

Distance to Next Bend

Featu re

Extraction

Machine Learning

Framework

Procedure Measures

Depth of Insertion

Insertion and

Withdrawal Time

Measures of Time and

Velo c i ty

Summarised Image

Measures

Blind Pushing

Stationary Periods

Loop Resolution

Attempts

Featu re

Selection

Support Vector

Regression

Summary Criteria

DOPS Criteria

Luminal View

Handling

Loop Resolution

Procedure Time

Visualisation

Insertion Performance

Withdrawal

Performance

Overall Performance

Figure 1: Layout of the complete quality assessment sys-

tem.

tion of the endoscope. All image based characteris-

tics can therefore be analysed for their behaviour over

time and depth of insertion.

This combination of image and endoscope motion

characteristics results in a large set of measures, de-

scribing colonoscopy procedures in great detail. We

use subsets of these measures as features for the train-

ing of regression models for each of the chosen JAG

DOPS criteria. We evaluate the proposed method by

comparing the model predictions to the ratings of the

trained experts. The complete system is shown in Fig-

ure 1.

For brevity, we keep the description of the individ-

ual building blocks to a minimum, concentrating on

the system as a whole. Future publications will con-

tain details on each of the novel algorithms involved

in the system.

3.1 Image Measures and Machine

Learning Framework

All the involved measures of characteristics of sin-

gle endoscopic images are based on image features,

which are used to train predictive models in a uni-

versal machine learning framework. This framework

involves automatic forward feature selection, parame-

ter optimisation (grid search with iterative reﬁnement)

and training of support vector machines. Depending

on the properties of the particular measure, we use

different kinds of error measures for optimisation and

different types of support vector machines.

Among the image measures, we use a novel mea-

sure for the clarity of the ﬁeld of view, extending the

current state of the art by introducing multiple grades

of clarity as opposed to the previously proposed bi-

nary classiﬁcation into informative and indistinct im-

ages (see, e.g., (Arnold et al., 2009; Oh et al., 2007)).

The clarity measure is based on different representa-

tions of the amount of structure in the image. These

structure features are obtained from a wavelet decom-

position of the image and differences between inten-

sity histograms of horizontal, vertical and diagonal

lines in the image. For regression, we use a ν sup-

port vector regression model.

By introducing measures for different character-

istics of luminal views in single images, i.e., lumi-

nal view quality, lumen presence, position of the lu-

men and distance to the closest bend, we achieve

a detailed description of colonoscopic images with

direct implications to visualisation quality and en-

doscope handling skills. The lumen characteristics

are inferred from intensity, shape and colour fea-

tures obtained from maximally stable extremal re-

gions (MSER, (Matas et al., 2004)) in the image, to-

gether with intensity and colour features of the whole

image. In a ﬁrst step, one of the MSER is chosen

as the most likely representation of the lumen region.

Given this region and the associated features, we use

a C support vector machine for classifying the lumen

as either present or absent. If the lumen is present, its

position is computed as the centroid of the lumen re-

gion. ν support vector regression models are used for

measuring luminal view quality and distance to the

closest bend.

All image based measures beneﬁt from the meth-

ods for detecting and inpainting specular highlights

in endoscopic images that we have proposed earlier

in (Arnold et al., 2010). By either omitting or inpaint-

ing specular pixels in the image we reduce the inﬂu-

ence of the strong gradients and intensity saturation in

these areas.

3.2 Endoscope Motion and Measures of

Procedure Characteristics

For the characterisation of complete procedures we

incorporate measurements of a motion sensor, located

outside the anus, which measures longitudinal and

circular displacement of the endoscope. Due to the

motion sensor being optimised for a speciﬁc colono-

scopy training model, it was necessary to design an

experiment for data collection, in which video and

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

sensor data could be recorded simultaneously. The

obtained data was complemented by information on

the experience of the participating endoscopists and

assessments of the procedures by two trained experts

according to JAG DOPS criteria. This way we were

able to collect video and motion sensor data, for the

development of measures for procedure characteris-

tics, and associated DOPS ratings to train and evalu-

ate models for automatic DOPS assessment.

Given the obtained motion sensor data, we use a

moving average ﬁlter to estimate the depth of inser-

tion of the endoscope. The speed of the endoscope

can be directly obtained. We use these measurements

in methods to automatically infer the insertion and

withdrawal times of procedures and to detect station-

ary periods during insertion, attempts of loop resolu-

tion and occurrences of pushing without a clear view.

All these measures are based on handling patterns de-

tected in the motion sensor data and, in the case of

pushing without clear view, combining these with the

measure for the clarity of the ﬁeld of view in images.

The estimated depth of insertion also allows us to

divide the colon into a number of segments, opening

up new possibilities for summarising the behaviour

of certain characteristics over the course of a proce-

dure. The proposed image measures can therefore

be mapped to meaningful procedure characteristics

by applying various statistics for their summarisation.

Previously it was only possible to analyse the be-

haviour over time, lacking any form of spatial infor-

mation. Combining the spatial segmentation with the

time scale, handling patterns and the set of proposed

image measures, we obtain a set of 92 procedure mea-

sures.

3.3 Mapping Procedure Measures to

DOPS Criteria

We consider the following criteria from the JAG

DOPS assessment (we use the short terms in paren-

theses in the following):

• Maintains luminal view / inserts in luminal direc-

tion. (Lumen)

• Uses torque steering and control knobs appropri-

ately. (Handling)

• Recognises and logically resolves loop formation.

(Looping)

• Completes procedure in reasonable time. (Time)

• Adequate mucosal visualisation. (Visualisation)

In addition, we included criteria summarising the per-

formance during the insertion phase (Insertion), the

Table 1: Groups of features and their relevance for the dif-

ferent DOPS criteria.

Lumen

Handling

Looping

Time

Visualisation

Insertion

Withdrawal

Overall

INSERTION

Backward Speed - × - × - × - ×

Forward speed - × - × - × - ×

Circular Speed - × - - - × - ×

Blind Pushing - × × - - × - ×

Clarity × × - - - × - ×

Loop Resolution - × × - - × - ×

Lumen Dist. To Centre × × - - - × - ×

Dist. To Bend × - - - - × - ×

Lumen Pos. X × × - - - × - ×

Lumen Pos. X Stdev × × - - - × - ×

Lumen Pos. Y × × - - - × - ×

Lumen Pos. Y Stdev × × - - - × - ×

Lumen Presence × × - - - × - ×

Lumen View Quality × × - - - × - ×

Stationary Time - × × - - × - ×

Time - × × × - × - ×

WITHDRAWAL

Backward Speed - - - × × - × ×

Forward speed - - - × × - × ×

Circular Speed - × - - × - × ×

Blind Pushing - × × - - - × ×

Clarity × × - - × - × ×

Lumen Dist. To Centre × × - - × - × ×

Dist. To Bend × - - - × - × ×

Lumen Pos. X × × - - × - × ×

Lumen Pos. X Stdev × × - - × - × ×

Lumen Pos. Y × × - - × - × ×

Lumen Pos. Y Stdev × × - - × - × ×

Lumen Presence × × - - × - × ×

Lumen View Quality × × - - × - × ×

Time - - - × × - × ×

withdrawal phase (Withdrawal) and the whole proce-

dure (Overall).

The major challenge in training models for map-

ping procedure measures to DOPS criteria is the size

of the data set. It consists of 25 procedure videos with

associated motion sensor measurements and DOPS

ratings produced by two trained experts. The JAG

DOPS assessment system is a subjective method of

assessment, which means that full agreement is un-

likely, even between trained assessors. In such a small

data set, these deviations can have a strong impact

on measures of agreement between assessors. We

therefore report results separately, taking each asses-

sor on its own as a reference for our method. 25 ex-

amples are also insufﬁcient for performing automatic

feature selection, as we did earlier within the machine

learning framework to measure image characteristics.

Having 92 features available this method would in-

TowardsAutomaticDirectObservationofProcedureandSkill(DOPS)inColonoscopy

Table 2: Agreement between predictions of the automatic system and the ratings of assessor 1, measured using Kendall’s τ,

Pearson’s r and Krippendorff’s α. For τ and r the values in parentheses are the corresponding p-values. For α the table shows

the lower and upper limits of the 95% conﬁdence intervals in parentheses.

τ (p-value) α (95% CI lower lim., upper lim.) r (p-value)

Lumen 0.442 (0.006) 0.169 (-0.111, 0.426) 0.648 (<0.001)

Handling 0.516 (0.001) 0.642 (0.412, 0.815) 0.705 (<0.001)

Looping 0.294 (0.077) 0.276 (-0.056, 0.564) 0.465 (0.019)

Time 0.290 (0.088) 0.229 (-0.154, 0.538) 0.344 (0.092)

Visualisation 0.460 (0.005) 0.607 (0.499, 0.711) 0.541 (0.005)

Insertion 0.404 (0.011) 0.434 (0.239, 0.618) 0.525 (0.007)

Withdrawal 0.488 (0.003) 0.566 (0.325, 0.756) 0.490 (0.013)

Overall 0.586 (<0.001) 0.400 (0.208, 0.575) 0.783 (<0.001)

Table 3: Agreement between predictions of the automatic system and the ratings of assessor 2, measured using Kendall’s τ,

Pearson’s r and Krippendorff’s α.

τ (p-value) α (95% CI lower lim., upper lim.) r (p-value)

Lumen -0.459 (0.007) -0.530 (-1.000, -0.052) -0.573 (0.003)

Handling 0.241 (0.138) 0.213 (-0.054, 0.445) 0.335 (0.102)

Looping -0.016 (0.940) 0.024 (-0.316, 0.328) 0.093 (0.660)

Time -0.005 (1.000) -0.202 (-0.660, 0.209) -0.491 (0.013)

Visualisation 0.081 (0.639) 0.131 (-0.333, 0.525) 0.120 (0.567)

Insertion -0.263 (0.109) -0.216 (-0.664, 0.137) -0.431 (0.031)

Withdrawal -0.041 (0.818) 0.026 (-0.309, 0.322) -0.171 (0.414)

Overall 0.081 (0.629) 0.095 (-0.239, 0.377) -0.105 (0.618)

evitably lead to overﬁtting and, therefore, poor perfor-

mance on unseen data. Choosing the relevant features

manually based on domain knowledge is not trivial,

since there is seldom an intuitive advantage of any

summarisation operation over the others for the dif-

ferent features.

We therefore take a hybrid approach to feature se-

lection. We organise the features into groups, each

of which is made up of a set of features represent-

ing the same underlying procedure characteristic. We

then use our domain knowledge to select the relevant

groups (characteristics) for each of the target DOPS

measures. Within each group we perform correla-

tion analysis to chose the most relevant feature of the

group. Only the feature with the highest correlation

with the measure in the training examples is retained

in each group. This approach allows us to reduce

the dimensionality of the feature space signiﬁcantly.

This, in turn, reduces the tendency of overﬁtting. Ta-

ble 1 lists the target measures and feature groups we

identiﬁed and shows which group we consider rele-

vant for each of the target measures. By using this

method, depending on the DOPS criterion in question,

the number of features is reduced from 92 to between

5 and 30.

We use ν support vector regression models for pre-

diction of the DOPS criteria. To make best use of the

small data set, the SVMs are trained in a nested cross-

validation scheme. In the outer loop, in each cross-

validation fold, we leave out a single example for test-

ing and hand the rest to the inner loop. In the inner

loop, parameters are optimised with a grid search ap-

proach, again using leave-one-out cross-validation.

4 EVALUATION

For the performance evaluation of the proposed sys-

tem, we compute the strength of association between

the trained SVMs and each of the two assessors. We

are using Kendall’s τ coefﬁcient for this analysis, pro-

viding Pearson correlation r for comparison. The re-

sults are shown in Tables 2 and 3. For comparison,

Table 4 shows the agreement between the two asses-

sors.

We can see a moderate association for most of

the measures when comparing to assessor 1. Inter-

estingly, the method fails to achieve any signiﬁcant

agreement with assessor 2. This may be due to rating

outliers, which can have a strong effect given such

a small sample size. There appears to be a stronger

association between our method and assessor 1 than

between the ratings of the two assessors in all except

the looping criterion. Association between the pre-

dictions of our method and the ratings of assessor 1 is

always statistically signiﬁcant at the 0.1 signiﬁcance

VISAPP2013-InternationalConferenceonComputerVisionTheoryandApplications

Table 4: Agreement between the ratings of assessor 1 and the ratings of assessor 2, measured using Kendall’s τ, Pearson’s r

and Krippendorff’s α.

τ (p-value) α (95% CI lower lim., upper lim.) r (p-value)

Lumen 0.217 (0.262) 0.230 (-0.360, 0.680) 0.314 (0.126)

Handling 0.311 (0.084) 0.310 (-0.070, 0.640) 0.366 (0.072)

Looping 0.494 (0.008) 0.470 (0.180, 0.720) 0.571 (0.003)

Time 0.041 (0.864) 0.050 (-0.390, 0.450) 0.051 (0.810)

Visualisation 0.185 (0.342) 0.210 (-0.360, 0.640) 0.181 (0.387)

Insertion 0.347 (0.055) 0.370 (0.070, 0.610) 0.462 (0.020)

Withdrawal 0.323 (0.082) 0.340 (-0.130, 0.730) 0.381 (0.060)

Overall 0.402 (0.025) 0.410 (0.070, 0.710) 0.518 (0.008)

level, whereas between the two assessors, the associ-

ation is insigniﬁcant for 3 criteria.

4.1 Discussion

The results our method achieves when compared to

assessor 1 are promising. A signiﬁcant degree of as-

sociation for all criteria indicates that certain crite-

ria can indeed be measured automatically from video

and motion sensor data. The poor performance when

compared to assessor 2, however, suggests that the

data we collected may contain outliers. Given the size

of the data set and the resulting uncertainty of the re-

sults, the problem will have to be addressed with a

larger scale experiment. However, the ﬁndings of this

preliminary study suggest that the proposed system

has potential to accurately assess JAG DOPS quality

criteria.

REFERENCES

Arnold, M., Ghosh, A., Ameling, S., and Lacey, G. (2010).

Automatic segmentation and inpainting of specular

highlights for endoscopic imaging. EURASIP Journal

on Image and Video Processing, 2010:12.

Arnold, M., Ghosh, A., Lacey, G., Patchett, S., and Mulc-

ahy, H. (2009). Indistinct frame detection in colono-

scopy videos. In Proc. 13th Int. Machine Vision and

Image Processing Conf. IMVIP ’09, pages 47–52.

Benson, V. S., Patnick, J., Davies, A. K., Nadel, M. R.,

Smith, R. A., and Atkin, W. S. (2008). Colorec-

tal cancer screening: A comparison of 35 initiatives

in 17 countries. International Journal of Cancer,

122(6):1357–1367.

Bressler, B., Paszat, L., Chen, Z., Rothwell, D., Vinden,

C., and Rabeneck, L. (2007). Rates of new or missed

colorectal cancers after colonoscopy and their risk fac-

tors: a population-based analysis. Gastroenterology,

132(1):96–102.

Hwang, S., Oh, J., Lee, J., Cao, Y., Tavanapong, W., Liu, D.,

Wong, J., and de Groen, P. (2005). Automatic mea-

surement of quality metrics for colonoscopy videos.

In Proc. 13th annual ACM international conference

on Multimedia, pages 912–921. ACM New York, NY,

USA.

Liu, D., Cao, Y., Tavanapong, W., Wong, J., Oh, J., and

de Groen, P. (2007). Quadrant coverage histogram:

a new method for measuring quality of colonoscopic

procedures. In Proc. 29th Annual International Con-

ference of the IEEE Engineering in Medicine and Bi-

ology Society, pages 3470–3473.

Liu, X., Tavanapong, W., Wong, J., Oh, J., and de Groen,

P. C. (2010). Automated measurement of quality of

mucosa inspection for colonoscopy. Procedia Com-

puter Science, 1(1):951 – 960. ICCS 2010.

Matas, J., Chum, O., Urban, M., and Pajdla, T. (2004).

Robust wide-baseline stereo from maximally stable

extremal regions. Image and Vision Computing,

22(10):761 – 767. British Machine Vision Comput-

ing 2002.

Oh, J., Hwang, S., Cao, Y., Tavanapong, W., Liu, D., Wong,

J., and de Groen, P. (2009). Measuring objective qual-

ity of colonoscopy. IEEE Transactions on Biomedical

Engineering, 56(9):2190–2196.

Oh, J., Hwang, S., Lee, J., Tavanapong, W., Wong, J., and

de Groen, P. (2007). Informative frame classiﬁca-

tion for endoscopy video. Medical Image Analysis,

11(2):110–127.

U.S. Preventive Services Task Force (2008). Screening

for colorectal cancer: U.S. Preventive Services Task

Force recommendation statement. Annals of Internal

Medicine, 149(9):627–637.

WGO (2007). World gastroenterology organisation

/ international digestive cancer alliance practice

guidelines: Colorectal cancer screening. http://

www.worldgastroenterology.org/colorectal-cancer-

screening.html: [Last accessed: 6 Dec 2012].

TowardsAutomaticDirectObservationofProcedureandSkill(DOPS)inColonoscopy
