Combining SysML and Modelica to Verify the Wireless Sensor Networks

Energy Consumption

Ahmed Hammad, Hassan Mountassir and Samir Chouali

Femto-ST Institute, University of Franche-Comt´e, Besanc¸on, France

Keywords:

Speciﬁcation, SysML, Modelica, Design, Virtual Veriﬁcation, Model Transformation, MDA, WSN.

Abstract:

Wireless Sensor Networks (WSN) have large industrial applications. However, the modelisation is still a very

complex task in view of the nature of these networks, namely because they are distributed, embedded and

have strong interactions between the hardware and software parts. In addition, industrials use semi-formal

methods to design their systems and validate behaviours by simulation. In this context, in order to improve the

checking of the WSN properties, we propose a Model Driven Architecture (MDA) approach for modeling and

checking of properties like energy consumption. This approach combines the advantages of SysML and Mod-

elica languages. It is described mainly by two steps. At ﬁrst, we offer a model transformation by taking into

account static, dynamic and requirement diagrams of SysML in order to specify their corresponding Modelica

model. In the second step, we carried out the virtual veriﬁcation of WSN energy consumption. This approach

is implemented inside Topcased platform and illustrated through a crossroads monitoring system which aims

the veriﬁcation of energy consumption.

1 CONTEXT AND MOTIVATION

During the last decade, WSN have been a major suc-

cess in the scientiﬁc and the industrial communities

for their broad application ﬁelds. However, this kind

of networks is mainly used in the observation of phys-

ical phenomena in a restricted environment. They

are characterized by a simple deployment and a low

production cost. Furthermore, the WSN industry ac-

tors should develop the modeling methods of these

networks in order to maintain the competitiveness of

their products. In addition, modeling WSN is equiv-

alent to modeling distributed and embedded system

at the same time. Moreover, the formal methods are

generally used in the modeling of critical systems that

require rigorous veriﬁcations. These methods require

good skills in mathematics. As a result, industrials

have widely adopted semi-formal methods to design

WSN applications. These methods are based mainly

on semi-formal language (text or graphic) for which

is deﬁned a precise syntax and a relatively weak se-

mantics. Besides, semi-formal languages are easy

to understand and provide a rich structuring mecha-

nism allowing the reduction of the design time and

cost. However, in order to improve the checking of

the WSN properties which is done generally by sim-

ulation, we propose an MDA approach to design and

to check the WSN properties. Our approach is based

on the SysML language which will be extended to

an executable language namely Modelica (Modelica,

2009). Considering the Modelica characteristics, we

propose a virtual veriﬁcation of properties which are

deduced from the SysML requirement diagram. This

approach includes the beneﬁts of the SysML model-

ing and the possibility to simulate and to verify the

modeled system with Modelica. SysML and Modelica

are two complementary languages, their joint use of-

fers the very expressive, formal language for differen-

tial algebraic equations and discrete events of Model-

ica with the very expressive SysML constructs for re-

quirements, structural decomposition, logical behav-

ior and traceabilty of requirements.

We focused our work on the study the WSN energy

consumption which is heavily dependent on the type

of node. These nodes are designed in the aim to max-

imize their life expectancy. In (Halgamuge et al.,

2009), the authors proposed an energy consumption

model for WSN. The major feature of this model is

the accuracy in estimating the energy consumption.

Therefore, this model aims to estimate the overall life-

time of the WSN accurately. For these reasons, we

adopted this energy consumption model in our study.

This paper is structured as follows: ﬁrst we provide

the existing works relating to the WSN modeling.

198

Hammad A., Mountassir H. and Chouali S..

Combining SysML and Modelica to Verify the Wireless Sensor Networks Energy Consumption.

DOI: 10.5220/0004319601980201

In Proceedings of the 1st International Conference on Model-Driven Engineering and Software Development (MODELSWARD-2013), pages 198-201

ISBN: 978-989-8565-42-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Then, we give brief introductions to WSN, SysML

and Modelica languages. After that, we explain our

approach to design and to verify the WSN energy

consumption property. Finally, we conclude and give

some future works.

2 RELATED WORKS

In the literature, we found several works on the mod-

eling and the veriﬁcation of the WSN properties.

For example, E. Cheong and al. (Cheong et al.,

2006) developed a Framework that provides a graph-

ical environment for the WSN applications modeling

and simulation using mainly TinyOS. Another similar

work done with Simulink was proposed by M. M. R.

Mozumdar and al. (Mozumdar et al., 2008). They de-

veloped a Framework which provides the ability to

make performance analysis of the designed system

through simulation and it also allows the code gener-

ation which is compatible with TinyOS. S. Villa and

al. (S. Villa, 2011) proposed an approach for mod-

eling WSN using UML and SystemC. They deﬁned

two UML proﬁles, namely the UML-SystemC proﬁle

which includes the SystemC speciﬁc concepts and the

UML-Marte proﬁle which allows hardware-software

modeling (co-design). Then they have designed a

Framework that enables the model transformation be-

tween the UML model and the SystemC model. The

veriﬁcation of SoC properties is done by the simula-

tion.

Our WSN modeling approach is based on the MDA

standard. It allows a semi-formal modeling with the

SysML language which will be extended by the Mod-

elica in order to verify WSN properties. In other

words, we offer the possibility to design clear mod-

els, to allow also the simulation and the virtual veriﬁ-

cation of designed system properties.

3 PRELIMINARIES

3.1 Wireless Sensor Networks

The WSN modeling is inﬂuenced by many factors,

which include fault tolerance, scalability, produc-

tion costs, operating environment, sensor network

topology, hardware constraints, transmission media

and power consumption. These factors are important

because they serve to direct the design of the WSN

protocols and algorithms. In addition, they can

be used to compare different WSN architectures.

Moreover, the prospects of the WSN applications

are promising but the challenges that they present

are not less numerous and not less complex, neither.

Among the crucial issues, which represent the WSN

non-functional properties, we can mention the energy

consumption, the automatic conﬁguration, the com-

munication security.

3.2 SysML Language

SysML (SysML1.3, 2012) has been proposed by the

Object Management Group (OMG) , together with the

International Council on Systems Engineering (IN-

COSE) (INCOSE, 2012) and the AP233 consortium

(AP2, 2012) with the aim to deﬁne a general pur-

pose modeling language for systems engineering. It is

based on the actual standard for software engineering,

the Uniﬁed Modeling Language (UML) (UML2.4,

2011) version 2.4, with some extensions. It replaces

the class concept in modeling by blocks for a vocabu-

lary more suited to the Systems Engineering (SE). A

block includes any software, hardware, data and pro-

cesses concepts.

3.3 Modelica Language

The Modelica is an object-oriented modeling lan-

guage that allows the modeling of physical systems

which can be complex and heterogeneous. It can be

considered as a multidisciplinary modeling language

(Fritzson and Bunus, 2002). The Modelica is an open

language which is developed and promoted by the

Modelica Association. The Modelica models are de-

scribed mathematically in acausal way through dif-

ferential equations, algebraic equations and discrete

equations. The Modelica solvers contain very effec-

tive algorithms for solving equation systems which

allow the handling of complex models that are de-

scribed by thousands of equations.

4 OUR APPROACH

We propose to transform the SysML models to an ex-

ecutable models in Modelica. The adopted method-

ology is constituted of following steps. In the ﬁrst

stage, the modeler designs the WSN application with

the SysML language. In the next phase, the designer

is invited to run a check of his model in order to re-

ﬁne it when there are problems reported by the an-

alyzer. Among the problems identiﬁed by the ana-

lyzer, we list, the undeﬁned elements (initialization,

typing, etc.) which are generally due to forgetfulness

and the model elements which are not considered by

CombiningSysMLandModelicatoVerifytheWirelessSensorNetworksEnergyConsumption

199

the model transformation (SysML model to Modelica

model) rules. The objective of this analysis is to en-

sure that the generated code at the end of the trans-

formation process is executable by the OpenModelica

compiler. After this check, we can undertake the third

step that deﬁnes the transformation from the SysML

model to the Modelica model. The ﬁle resulting from

this transformation is in XMI (XML Metadata Inter-

change) format conformed to the proposed Modelica

meta-model. For the last step, we transform the Mod-

elica model to the Modelica code. The input ﬁle of

this transformation (model to text) is the XMI ﬁle re-

sulting from the last transformation (SysML model to

Modelica model) and the output ﬁle is the Modelica

code.

4.1 The Case Study

We present an example for the motorized trafﬁc den-

sity in urban areas. It requires the establishment of

signaling trafﬁc laws to improve the safety and the

ﬂuidity. The toughest trafﬁc problems are at the road

intersection. In fact, the passage priority associated

to eventual changing direction could create bottle-

necks. The solution adopted by trafﬁc operators to

regulate circulation is signalized system(tricolor and

bicolor lights). The trafﬁc lights installed at the in-

tersection are used to adjust the vehicle movements.

They are managed by a system that synchronizes the

color changes of the different junction lights. The

trafﬁc-light colors are managed by a controller which

depends on the number of cars waiting to cross the

junction. The duration of a cycle lights (yellow - red

- green) and the time of each phase is deﬁned by the

trafﬁc center of the city. This center supervizes all

streets intersections.

4.2 Transformation Rules from SysML

to Modelica

In the literature, we found several attempts to deﬁne

correspondences between the SysML (or UML2) and

the Modelica languages (Paredis and Johnson, 2008),

(Paredis et al., 2010). These works are based on the

MDA standard, that describes an approach to make

model transformations. The main work is (SysML-

ToModelica, 2012), there is ongoing work by the

OMG on standardization of the model transforma-

tion SysML to Modelica. Our approach takes into ac-

count the requirement, structural and behavioural dia-

grams. The requirement diagram describes functional

and non-functional requirements as well as the trace-

ability of these with the elements of the model. Struc-

tural diagram allows is used to describe the structure

Table 1: Transformation rules from SysML to Modelica.

Elements of SysML

model

Elements of Modelica

model

package, block, abstract-

block

package, block, partial-

class

ﬂow-speciﬁcation,

value-type

connector, type

ﬂow-property, ﬂow-port property, connector

connector ﬂux(x,y) equation connect(x,y)

constraint property equation

state machine guard ’when’ statement guard

operation without a

value to return

instruction block of

’when’ statement

operation with a value to

return

function

requirement boolean expression (in-

variant or safety con-

straint)

of the target model and the parametric diagram allows

us to consider the mathematical models which repre-

sent the behaviour of the real system. Finally, state

machine diagrams are used to describe the behaviour

of each component of the system under study. The

below table 1 provides a list of correspondences be-

tween the elements of the SysML and the Modelica

metamodels.

5 VERIFICATION WITH Modelica

5.1 Virtual Veriﬁcation

The Modelica language enables simulation and veri-

ﬁcation through the tests. In this context, the seminal

work is presented by W. Schamai and al. (Schamai

et al., 2011) which shows an approach to verify the

properties of Modelica model. This approach relies

on the MBSE (Model Based Systems Engineering).

This model will be executed and checked against the

system requirements in the early stages of the de-

velopment cycle. Furthermore, in the MBSE ap-

proach requirements are connected with model ele-

ments which allows traceability.

5.2 Energy Consumption Veriﬁcation

In our approach, we rely on the SysML requirement

diagrams. The designer selects a checkable require-

ments by linking them with boolean expression (con-

straint) that represents invariant or safety constraint

of system. To ensure traceability, the designer must

connect each checkable requirement with one or more

blocks that will satisfy this requirement. In this way,

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

200

we ensure the reusability and the traceability of re-

quirements. During the simulation of our system, we

adopted a random scenario of execution. The number

of vehicles on each lane will be randomly generated

every ﬁve seconds. After these steps, we speciﬁed a

simulation time which must be greater than the WSN

desired lifetime in the order to analyze all the criti-

cal durations of time (minimal WSN lifetime). Oth-

erwise, after ”19.22” hours of the simulation, the re-

quirement that expresses the WSN desired lifetime is

violated.

6 CONCLUSIONS AND FUTURE

WORKS

This work illustrates an approach to design and to ver-

ify the WSN energy consumption property using the

MDA standard. This approach combines the bene-

ﬁts of the SysML and the Modelica languages. We

proposed a model transformation from the SysML

model to the Modelica model taking into account the

static diagrams, dynamic diagrams and also the re-

quirement diagram of the SysML in order to spec-

ify the matching Modelica model. In addition, we

have done virtual veriﬁcation and requirement trac-

ing. These operations are allowed by the mapping

between the SysML requirements and the Modelica

properties (constraints). We also indicate that our

methodology is implemented in the TopCased envi-

ronment.

The next phase of this work is to introduce sequence

and activity diagrams in the action descriptions of the

state machine. The purpose of this step is to pro-

vide opportunities for designers who do not master

the Modelica programming to work with our Frame-

work. Furthermore, we intend to validate our model

transformation from SysML to Modelica by unit test-

ing and/or formal proofs.

ACKNOWLEDGEMENTS

We would like to acknowledge the support of the Re-

gional Council of Franche-Comt´e with the SyVad

project.

REFERENCES

AP2 (2012). http://ap233.eurostep.com.

(http://syvad.univ-fcomte.fr)

Cheong, E., Lee, E. A., and Zhao, Y. (2006). ‘Joint

Modeling and Design of Wireless Networks and Sen-

sor Node Software. Technical Report UCB/EECS-

2006-150, EECS Department, University of Califor-

nia, Berkeley.

Fritzson, P. and Bunus, P. (2002). ‘Modelica-A Gen-

eral Object-Oriented Language for Continuous and

Discrete-Event System Modeling and Simulation.

Simulation Symposium, Annual, pages 0–365.

Halgamuge, M. N., Zukerman, M., Ramamohanarao, K.,

and Vu, H. L. (2009). ‘An Estimation of Sensor En-

ergy Consumption. Progress In Electromagnetics Re-

search B (PIERB), 12:259–295.

INCOSE (2012). http://www.incose.org.

Modelica (2009). Modelica Standard Library 3.1. http://

www.modelica.org/libraries/Modelica/.

Mozumdar, M. M. R., Gregoretti, F., Lavagno, L., Vanzago,

L., and Olivieri, S. (2008). A Framework for Mod-

eling, Simulation and Automatic Code Generation of

Sensor Network Application. In SECON, pages 515–

522.

Paredis, C. J., Bernard, Y., Burkhart, R. M., de Koning,

H.-P., Friedenthal, S., Fritzson, P., Rouquette, N. F.,

and Schamai, W. (2010). An Overview of the Sysml-

Modelica Transformation Speciﬁcation. In 2010 IN-

COSE International Symposium.

Paredis, C. J. J. and Johnson, T. (2008). Using OMG’s

SysML to support simulation. In Proceedings of the

40th Conference on Winter Simulation, WSC ’08,

pages 2350–2352. Winter Simulation Conference.

S. Villa, D. Serna, J. A. (2011). Systemc Code Generation

from UML for Wireless Sensor Networks Design. In

International conference on modeling, simulation and

visualization methods, MSV ’11, pages 53–60.

Schamai, W., Helle, P., Fritzson, P., and Paredis, C. J. J.

(2011). Virtual Veriﬁcation of System Designs against

system Requirements. In Proceedings of the 2010 in-

ternational conference on Models in software engi-

neering, MODELS’10, pages 75–89, Berlin, Heidel-

berg. Springer-Verlag.

SysML1.3 (2012). http://www.omg.org/spec/SysML/1.3/.

SysMLToModelica (2012). SysML-Modelica transforma-

tion(SyM) speciﬁcation. http://www.omg.org/SyM/

1.0/.

UML2.4 (2011). http://www.omg.org/spec/UML/2.4.1/ In-

frastructure.

CombiningSysMLandModelicatoVerifytheWirelessSensorNetworksEnergyConsumption

201
