UML Class Diagram Simpliﬁcation

A Survey for Improving Reverse Engineered Class Diagram Comprehension

Hafeez Osman

, Arjan van Zadelhoff

and Michel R. V. Chaudron

1,2

Leiden Institute of Advanced Computer Science, Leiden University, Leiden, The Netherlands

Department of Computer Science and Engineering, Chalmers University of Technology, Gothenburg, Sweden

Keywords:

Software Engineering, Reverse Engineering, UML, Class Diagram, Simpliﬁcation.

Abstract:

Class diagrams may include an overwhelming amount of information. For a large and complex class diagrams

there is a possibility that not all information in the class diagram is important for understanding the system.

In this paper, we study how to identify essential and secondary information in class diagrams. To this end, we

performed a survey with professionals, academics and students to enquire information in class diagrams that

is considered important. In total, 25 complete responses were received with 76% of the respondents having

average or above skills with class diagrams. As the results, we discovered that the metric that counts the

number of public operations is the most important metric for indicating importance of a class in a diagram.

Also, we discovered that class names and coupling were inﬂuencing factors when it comes to excluding classes

from a class diagram.

1 INTRODUCTION

UML class diagrams are valuable artefacts in software

development and software maintenance. This dia-

gram is helpful for software developers and software

maintainers in order to understand architecture, de-

sign and implementation of a software system. UML

class diagrams describe the static structure of pro-

grams at a higher level of abstraction than source code

(Gu

eneuc, 2004). UML models, which are usu-

ally created during the design phase, are often poorly

kept up-to-date during the realization and mainte-

nance phase. As the implementation evolves, cor-

respondence between design and implementation de-

grades from its initial design (Nugroho and Chaudron,

2007).

Reverse engineering is the process of analyzing

the source code of a system to identify its compo-

nents and their interrelationships and create design

representations of the system at a higher level of ab-

straction (Chikofsky and Cross, 1990). In particular,

reverse engineered class diagrams are typically a de-

tailed representation of the underlying source code,

which makes it hard for the software engineer to

understand what are the key elements in the soft-

ware structure (Osman and Chaudron, 2011). Al-

though several Computer Aided Software Engineer-

ing (CASE) tools have options to leave out several

properties in a class diagram, they are unable to auto-

matically identify important classes.

Normally, to understand a software system, a pro-

grammer needs both source code and design. A

good representation of a class diagram by showing

the crucial information of a system is needed, es-

pecially when new programmers want to join a de-

velopment group; they need a starting point in or-

der to understand the whole project before they are

able to contribute. Tools that support maintenance,

re-engineering or re-architecting activities have be-

come important to decrease the time software person-

nel spend on manual source code analysis and help

to focus attention on important program understand-

ing issues (Bellay and Gall, 1997). This paper aims

at simplifying UML class diagrams by leaving out

unnecessary information without affecting the devel-

oper’s understanding of the entire system. To this

end, we have conducted a survey to gather informa-

tion from professionals, academics and students about

what type of information they focus on.

The paper is structured as follows : Section 2 dis-

cusses related work. Section 3 describes the examined

properties and tools for this research. Section 4 ex-

plains about the survey methodology while Section 5

presents the results and ﬁndings. We discuss our ﬁnd-

ings in Section 6 and Section 7 suggests future work.

This is followed by our conclusion in Section 8.

291

Osman H., van Zadelhoff A. and R. V. Chaudron M..

UML Class Diagram Simpliﬁcation - A Survey for Improving Reverse Engineered Class Diagram Comprehension.

DOI: 10.5220/0004319902910296

In Proceedings of the 1st International Conference on Model-Driven Engineering and Software Development (MODELSWARD-2013), pages 291-296

ISBN: 978-989-8565-42-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

2 RELATED WORK

In this section, we discuss several studies that are

slightly related to this study. Yusuf et al. (Yusuf

et al., 2007) performed a study about assessing the

comprehension of UML Class diagrams via eye track-

ing. They used eye-tracking equipment to collect a

subject’s activity data in a non-obtrusive way as the

subjects are interacting with the class diagram in per-

forming a given task. They concluded that experts

tend to use such things as stereotype information,

colouring, and layout to facilitate more efﬁcient ex-

ploration and navigation of class diagrams. Also, ex-

perts tend to navigate/explore from the center of the

diagram to the edges whereas novices tend to navi-

gate/explore from top-to-bottom and left-to-right.

Egyed (Egyed, 2002) presents an approach for au-

tomated abstraction that allows designers to zoom out

of class diagrams to investigate and reason about the

bigger picture. This approach was based on a large

number of abstraction rules and, when used together,

it can abstract complex class structures quickly. In to-

tal, the article provides 121 rules to abstract a class di-

agram. They showed that their technique scales, pro-

duces correct results most of the time, and addresses

issues such as model ambiguities that are inherently

part of many (UML) diagrams.

Table 1: The Chosen Software Design Metrics.

Metrics

Category

Description

NumAttr

Size

The number of attributes in a class

NumOps

Size

The number of operations in a class

NumPubOps

Size

The number of public operations in a

class

Setters

Size

The number of operations with a name

starting with ‘set’.

Getters

Size

The number of operations with a name

starting with ‘get’, ‘is’, or ‘has’.

NOC

Inheritance

The number of immediate subclasses

subordinated to a class in the class

hierarchy.

DIT

Inheritance

DIT is calculated as the longest path

from the class to the root of the

inheritance tree.

CLD

Inheritance

The longest path from the class to a

leaf node in the inheritance hierarchy

below the class.

Dep_Out

Coupling

(import)

The number of dependencies where

the class is the client

10.

Dep_In

Coupling

(export)

The number of dependencies where

the class is the supplier

11.

EC_Attr

Coupling

(export)

The number of times the class is

externally used at attribute type

12.

IC_Attr

Coupling

(import)

The number of attributes in the class

having another class or interface as

their type

13.

EC_Par

Coupling

(export)

The number of times the class is

externally used as parameter type

14.

IC_Par

Coupling

(import)

The number of parameters in the class

having another class or interface as

their type

3 EXAMINED PROPERTIES AND

TOOLS

In this section we describe the design metrics and the

tools used for this research.

3.1 Examined Properties

We study 14 metrics from the categories Size, Cou-

pling and Inheritance. The metrics that we use are

listed in Table 1.

3.2 Tools

SDMetrics

is used to measure the structural prop-

erties of object oriented design. SDMetrics version

2.11 (academic license) is used for this purpose. We

chose Enterprise Architect

for design and reverse en-

gineered UML class diagrams in this survey.

4 SURVEY METHODOLOGY

In this section, we explain how the questionnaire was

designed and why.

4.1 Questionnaire Design

The questionnaire consisted out of 3 parts. A print-

able version is available at (van Zadelhoff, 2012).

4.1.1 Part A: Background of the Respondents

Part A consisted of 4 questions. We asked about the

respondent’s background: occupation, location, years

of experience with class diagrams and skills in creat-

ing, modifying and understanding class diagrams.

4.1.2 Part B: Class Diagram Indicators for Class

Inclusion /Exclusion

The ﬁrst 13 questions asked which metrics of a class

diagram based on indicator for including/excluding a

class. In each of these 13 questions, we brieﬂy ex-

plained the metrics and a choise of 5 multiple choises

were offered are shown in Table 2. In the last question

of part B (i.e. question 14), we tried to discover the

reasons of the respondents for including and exclud-

ing a class in a class diagram.

Table 2: Answers Multiple Choice Questions.

Multiple

Choice Letter

Answers

Score

Class(es) Definitely Should Not be Included

-2

Class(es) Probably Should Not be Included

-1

Class(es) Sometimes be Included

Class(es) Probably Should be Included

Class(es) Definitely Should be Included

http://www.sdmetrics.com/

http://www.sparxsystems.com.au

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

292

4.1.3 Part C: Commenting UML Diagrams

In this part, we tried to simulate actual problem by

providing several class diagrams. Participants had to

indicate which class or information of a class to in-

clude/exclude. The following class diagrams were in-

volved in this survey:

1. ATM simulation system: This class diagram

is developed by the Department of Mathematics

and Computer Science, Gordon College (Bjork,

2004).

2. Library System: This system is taken from

(Eriksson et al., 2004). The reverse engineered

design was used for this questionnaire.

3. Pacman Game: This project is found at (Craig

et al., 2009). We used the forward design and the

reverse engineered design of this system

We also tried to simulate the various ﬂavours of

class diagrams from the software industry by provid-

ing different Levels of Detail (LoD) of class diagrams

and the sources of class diagrams. The information

about the class diagrams that we used in question

number 1, 2, 3 and 5 in part C is shown in Table 3.

Other than these 4 questions, we have made 2 more

questions in which we asked the respondents which

ﬂavour of class diagram they prefer.

Table 3: Description of Design Models used in the Ques-

tions.

Question System Source of Diagram

Level of Detail (LoD)

1 ATM Machine Forward Design

Low

2 Library System Reverse Engineered

High

3 Pacman Game Forward Design

High

5 Pacman Game Reverse Engineered

High

4.2 Experiment Description

The questionnaire was published online for two

months. The total respondents that started this ques-

tionnaire were 98. However, only 25 respondents

completed this questionnaire. Most of the incomplete

responses stopped after the questions in Part A.

5 RESULTS AND FINDINGS

In this section we present our results and ﬁndings

from this survey. The responses for this survey are

available at (Osman and van Zadelhoff, 2012).

5.1 Background of the Respondents

In this subsection we present the results of part A of

the questionnaire.

5.1.1 Roles and Locations

For the respondents’ role, 40% of the respon-

dents mentioned that their current status is Re-

searcher/Academic while 32% of the respondents are

IT Professionals. 28% of the respondents answered

Student. For the respondents’ location, 45% of the

respondents stated that they were from in The Nether-

lands. 32% of the respondents are from Malaysia.

5.1.2 Skills and Experience with Class Diagrams

24% of the respondents mentioned that their experi-

ence with class diagrams is between 1 and 3 years

while 16% of the respondents answered this question

with “3 - 7 Years”. 12% of the respondents answered

“7 - 10 Years” and 20% of the respondents mentioned

that they have more than 10 years of experience with

class diagrams. In terms of the respondents skills

on creating, modifying and understanding class dia-

grams. 40% of the respondents stated that their skill

is Average, while 20% answered “Good”. 16% of the

respondents rated their skill Excellent.

5.2 Indicator for Class Inclusion

In this subsection we present our result of part B. For

question B1 to B13, the respondents were provided 5

choises of answers. We analysed these 13 questions

by using a score-system as shown in Table 2.

In the Size category, the highest score is NumPub-

Ops with 25 points. NumOps has 18 points while Nu-

mAttr has 17 points. The Setters/Getters metric has

13 points. From these results we can consider that the

respondents found operations are important in a class

diagram, speciﬁcally operations that are public.

For the Coupling category, Dep Out and Dep In

have 17 and 16 points, respectively. EC Attr has 15

points while IC Attr has 17 points. If we compare

the points between these two metrics and EC Par (11

points) and IC Par (9 points), there is a huge differ-

ence. This indicates that the classes that are declared

and are used as an attribute are more important than

the classes that are declared and are used as a param-

eter in class operations.

For the Inheritance category, the results indicate

that NOC has the most points in this category which

is 20 points. DIT and CLD have 7 points and 5 points,

respectively. With these results we can suggest that

UMLClassDiagramSimplification-ASurveyforImprovingReverseEngineeredClassDiagramComprehension

293

the respondents only need a part of the inheritance

tree.

In term of class inclusion/exclusion, the answers

are analyzed by creating several keywords that are re-

lated to the given answers An answer in this open-

ended question could contain multiple keywords. We

understand that the “Important/Relevant class” is a

very broad term but that is basically what the re-

spondents answered. The answers also show that

there are three keywords that are being related to

the answers the most. These are Important/Relevant

Class (29.6%), Coupling (18.5%), and Domain Re-

lated (25.9%).

5.3 Practical Problems

In this part, we tried to access the information about

the classes that should not be included in a class dia-

gram.

5.3.1 Coupling

In question C1, the ATM System class diagram was

presented without attributes and operations. As a re-

sult, 48% of the respondents chose to exclude the

class Money and 36% of the respondents chose to not

include the OperatorPanel and Status class in a class

diagram. From our observation, those 3 classes have

the number of coupling (e.g. Dep In,Dep Out) <=2.

32% of the respondents chose to exclude the classes

Deposit, EnvelopeAcceptor, ReceiptPrinter, Transfer

and Withdrawal. The coupling for those classes is =2.

This shows that the amount of coupling plays a major

role in selecting the classes that should or should not

be included in a class diagram.

5.3.2 Meaningful Class Names

A reverse engineered class diagram from a Library

System was used for question C2 an all elements were

presented in High Level of Detail (HLoD). We were

expected to discover the elements that inﬂuence in se-

lecting the classes that should not be included.

From the results, it is shown that most of the re-

spondents chose not to include the classes that have

no relationship. In this question, we found that class

names also play a major role in determining whether

a class should be included or excluded. AboutDia-

log, MessageBox and QuitDialog clearly mentioned

the functionality of the classes that are used to display

the information. Borrower, Reservation, Loan, Item

and Title are classes that have a meaningful name that

might indicate the functionality of the classes and also

closely relate to the domain i.e. Library System.

5.3.3 Level of Detail

In Question C4, by referring to the class diagrams in

C1, C2 and C3, the respondents were asked which

ﬂavour of class diagram they preferred.

The results show that almost half of the respon-

dents preferred working with class diagram C3. 48%

of the respondents preferred diagram C3 because they

mentioned that the class diagram is clear, the neces-

sary information is provided e.g. attributes and op-

erations and most of the classes that are presented

are important. 20% of the respondents preferred to

use class diagram C1. Most of the respondents that

chose this diagram were Researchers/Academic and

IT Professionals with the skill in class diagram rang-

ing from Average to Excellent. It seems that most

of the respondents that have a good skill and expe-

rience in class diagrams prefer to use this diagram.

12% of the respondents mentioned that it did not mat-

ter which diagram they get, 8% of the respondents

preferred class diagram C2 and 8% did not prefer any

of the presented class diagrams.

5.3.4 Reverse Engineered Class Diagram which

Conformed to Forward Design

In question C5, the class diagram used was slightly

different from the class diagram presented in question

C3 because this class diagram was constructed by us-

ing a reverse engineering technique. In this question,

we tried to discover if there was any difference of se-

lecting the classes that should not be included in a

class diagram in a reverse engineered class diagram

that is close or almost similar with the forward design

class.

The result shows that the class Direction and Pac-

Shell were selected by 72% of the respondents to be

left out from the class diagram. Compared to the

question C3, the Iterator and Iterable classes were dif-

ferently presented in this reverse engineered diagram.

The interface class is automatically presented in the

class that is connected to the interface class.

5.3.5 Reverse Engineered vs. Forward Engineer

Class Diagram

Question C6 tried to discover which type of class dia-

gram was preferred by the respondents i.e. between

the reverse engineered and the forward engineered

class diagrams. The reverse engineered class diagram

used was different with the reverse engineered class

diagram in question C2 because this class diagram

was derived from a system that was implemented (or

coded) closely with the forward design.

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

294

The results show that most of the respondents

(mainly researcher) preferred to use the reverse engi-

neered class diagram (Class Diagram C5). 40% of the

respondents chose this diagram because it is more de-

tailed, clear, there is no interface class and it is easier

to understand. 20% of the respondents did not choose

any of the two class diagrams because for them it does

not matter which one. On the other hand, 16% of the

respondents preferred forward engineered class dia-

gram (class diagram C3).

6 DISCUSSION

In this section we discuss the results and ﬁndings pre-

sented in the previous section.

6.1 Respondents’ Background

In Part A, the respondent’s status in this questionnaire

was quite evenly distributed and the location of the

respondents showed that most of the respondents are

from The Netherlands and Malaysia.

In terms of the respondent’s skill and experience

with class diagrams, we found that 72% of the respon-

dents have more than 1 year of experience and that

76% of the respondents have rated themselves aver-

age or above if it comes to creating, modifying and

understanding class diagrams. Even though 28% of

the respondents said that they have less than one year

of experience, we can still state that all the respon-

dents have knowledge about class diagrams.

6.2 Software Design Metrics

In the Size category, we found that the higher the

number of public operation, is the more people pre-

fer this class. Public operations are not restricted to

be accessed internally but they also can be accessed

publicly from other classes. This might be the reason

why the respondents found public operations.

In the Coupling category, we have discovered that

classes that have many incoming and outgoing de-

pendencies are important. We found that IC Attr and

EC Attr have higher points than EC Par and IC Par.

The reason might be that the class(that is declared as

an attribute) is more important because it could be

used for every operation in the class. In the Inheri-

tance category, we discovered that for a class that has

a high NOC, the class should be included in a class

diagram. This parent class is helpful to show the ab-

straction of a group of classes. For DIT, the higher

number of DIT does not indicate it is an important

class because it basically means that this particular

class is located very low in the inheritance hierarchy

which means that this class is too detailed and most

of the times not needed. For CLD, if a class has

a high frequency of this metric means this class is

very abstract, meaning that this class alone will not

be enough to understand the whole hierarchy.

As for the complete results, we found that

NumPubOps has the highest points of all the metrics.

Also all the metrics have a positive score. The overall

ranking of the score is shown in Table 4. This result

could be applied for a software designer to simplify a

class diagram during the documentation phase.

Table 4: Overall Score for Software Design Metrics.

No. Software Metrics Score

1 NumPubOps 25

2 NOC 20

3 NumOps 18

4 NumAttr 17

5 Dep_Out 17

6 IC_Attr 17

7 Dep_In 16

8 EC_Attr 15

9 Setters/Getters 13

10 EC_Par 11

11 IC_Par 9

12 DIT 7

13 CLD 5

6.3 Class Names and Coupling

Based on the results in Part C, we discovered that a

highly inﬂuential factor when we are trying to ex-

clude classes from a class diagram is coupling. An-

other inﬂuencing factor is the class name. Many re-

spondents excluded Graphical User Interface (GUI)

related classes in the Library system because of the

class name and coupling. However, sometimes this

element is not an inﬂuencing factor as we have seen in

the ATM system because many respondents excluded

domain related classes, classes that are needed for the

functionality of the ATM system.

6.4 Class Diagram Preferences

In question C4, we discovered that most of the re-

spondents preferred to use HLoD of the forward de-

sign. The reasons the respondents gave was that this

class diagram is clearer and the necessary information

is provided in this class diagram. This result seems to

indicate that the forward design with High Level of

Detail was preferred by the respondents. Meanwhile,

in question C6, most of the respondents had chosen

the reverse engineered design (HLoD). The reason

UMLClassDiagramSimplification-ASurveyforImprovingReverseEngineeredClassDiagramComprehension

295

might be that the reverse engineered design that was

provided has few differences from the forward design.

The respondent stated that they preferred this diagram

because they ﬁnd it more detailed, clear, and it is eas-

ier to understand. Some of the respondents also men-

tioned that the interface classes are removed and is

thus a better class diagram.

6.5 Threats to Validity

Although the respondents of this survey was quite

well distributed between the status roles (Student, Re-

searcher/Academic and IT Professional), we consider

that the amount of full responses were not enough.

The locations of the respondents were biased to The

Netherlands and Malaysia. Most of the questions in

this study require the respondent to choose the best

answers. We needed to do several assumptions on

why the respondents chose these answers and this as-

sumptions may not be accurate.

7 FUTURE WORK

This study was an early experiment on how to sim-

plify class diagrams and we see a number of ways to

extend this work. We propose to validate the result-

ing class diagram by using an industrial case study

and discover the suitability of the simpliﬁed class dia-

gram for the practical usage. It would also be interest-

ing to include other metrics that we have not chosen

and check whether they are important or not and ask

why the respondent chose the answer to get the rea-

son.

From the results, we found that class role and re-

sponsibility are one of the important indicators in a

class diagram. We would like to suggest a study on

names (class, operation and attribute) that the soft-

ware developers ﬁnd important or meaningful in order

to understand a system. We discovered some weak-

ness in the questionnaire and our suggestion is to im-

prove this questionnaire by increasing the amount of

responses. It would be interesting to see what the re-

sults are with a larger group of respondents.

8 CONCLUSIONS

In this survey we have discovered the most important

elements in a class design. We also discovered what

ﬂavour of class diagrams is preferred to work with.

From the results, we discovered that the most impor-

tant software design metric is the Number of Public

Operations. This means that if a class has a high num-

ber of public operations then this indicates that this

class is important and should be included in a class di-

agram. In this survey we also discovered that the class

names and coupling are inﬂuencing factors when se-

lecting a class to be excluded from a class diagram.

With these results we can highlight which classes

should be included or excluded in a reverse engi-

neered class diagrams based on our results and anal-

ysis by looking at the metrics and behaviour the re-

spondents had in Part C. Although the number of re-

sponses of this questionnaire is not that high, we still

managed to ﬁnd some inﬂuencing factors for deciding

a class to be included or excluded in a class diagram.

REFERENCES

Bellay, B. and Gall, H. (1997). A Comparison of Four Re-

verse Engineering Tools, pages 2–11. IEEE Computer

Society Press.

Bjork, R. C. (2004). Atm system. http://www.math-

cs.gordon.edu/courses/cs211/ATMExample/ .

Chikofsky, E. J. and Cross, J. H. (1990). Reverse engineer-

ing and design recovery: A taxonomy. IEEE Software,

7(1):13–17.

Craig, A., Dinardo, A., and Gillespie, R. (2009). Pacman

game. http://code.google.com/p/tb-pacman/ .

Egyed, A. (2002). Automated abstraction of class diagrams.

ACM Trans. Softw. Eng. Methodol, 11(4):449–491.

Eriksson, H.-E., Penker, M., Lyons, B., and Fado, D.

(2004). UML 2 Toolkit. Wiley.

eneuc, Y.-G. (2004). A Systematic Study of UML Class

Diagram Constituents for their Abstract and Precise

Recovery, pages 265–274. IEEE.

Nugroho, A. and Chaudron, M. R. V. (September 20-21,

2007). A Survey of the Practice of Design - Code

Correspondence amongst Professional Software En-

gineers, pages 467–469. Proceedings of the First In-

ternational Symposium on Empirical Software Engi-

neering and Measurement.

Osman, H. and Chaudron, M. R. V. (September 12-13,

2011). An Assessment of Reverse Engineering Capa-

bilities of UML CASE Tools, pages 7–12. 2nd An-

nual International Conference Proceedings on Soft-

ware Engineering Application (SEA 2011).

Osman, H. and van Zadelhoff, A. (2012). Structured ques-

tionnaire responses. http://www.liacs.nl/∼hosman/

Complete Results Structural Survey.rar.

van Zadelhoff, A. (2012). Structured ques-

tionnaire. http://www.liacs.nl/∼hosman/

The Presence of Classes in Class Diagrams.pdf.

Yusuf, S., Kagdi, H., and Maletic, J. I. (2007). Assessing

the Comprehension of UML Class Diagrams via Eye

Tracking. pages 113–122. 15th IEEE International

Conference on Program Comprehension ICPC ’07.

MODELSWARD2013-InternationalConferenceonModel-DrivenEngineeringandSoftwareDevelopment

296
