Automatic Face Corpus Creation

Ladislav Lenc and Pavel Kr´al

Department of Computer Science and Engineering, University of West Bohemia, Plzeˇn, Czech Republic

Keywords:

Automatic Face Recognition, Czech News Agency, Scale Invariant Feature Transform, Corpus Creation.

Abstract:

This paper deals with the automatic real-world face corpus creation. The main contribution consists in propo-

sition and evaluation of the automatic face corpus creation algorithm. Next, we statistically analysed the

structure of the created face corpus when the automatic algorithm is used. We further compared the face

recognition accuracy of our previously developed face recognition approach on this corpus while using differ-

ent size/quality datasets. We have shown that the manual veriﬁcation of the corpus is not necessary. Therefore,

we concluded that our proposed algorithm is suitable for the further use by the Czech News Agency, our com-

mercial partner.

1 INTRODUCTION

In this paper, we are focusing on the automatic la-

beling of people in the database with a huge number

of the real-world photographs. Certain portion of the

pictures is labeled (informationabout the person iden-

tity available). The rest is unlabeled. In this case, the

recognition is tightly connected with the face detec-

tion and extraction steps because the pictures do not

contain only the faces.

Automatic corpus creation methods have been de-

veloped and evaluated particularly in the speech pro-

cessing domain (Chen and Nie, 2000; Tom´as et al.,

2001). Unfortunately, to the best of our knowledge

there is only little work on the automatic corpus cre-

ation in the face recognition ﬁeld. All the well known

face databases have been created manually. However,

manual labeling is a very time-consuming and expen-

sive task.

The main goal of this paper thus consists in cre-

ation of a huge real-world face database. The creation

process must be as automatic as possible. The labeled

examples will be used for this task. The main con-

tribution of this work is proposition and evaluation

of the automatic face corpus creation algorithm. An-

other contribution of this paper is the statistical anal-

ysis of the results of the face corpus creation process

when the automatic creation algorithm is used. The

newly created face corpus will be used to evaluate

some face recognition approaches, which represents

the next contribution of this paper. We also compare

the face recognition accuracy while using different

size/quality datasets. The results of this work will be

used by the Czech News Agency (

CTK).

For the face recognition, we use the adapted Scale

Invariant Feature Transform (SIFT)-based Kepenekci

method (Lenc and Kr´al, 2012), which has shown very

good recognition accuracy on standard datasets (e.g.

ORL). It is based on the SIFT algorithm proposed by

David Lowe in (Lowe, 2004). The SIFT algorithm is

used for feature extraction and the matching scheme

proposed by Kepenekci (Kepenekci, 2001) is used for

face comparison.

The following section describes the proposed cor-

pus creation algorithm and the structure of the created

face corpus. The next section contains the face recog-

nition results on the created corpus. Finally, the Sec-

tion 4 summarizes the results and givessome ideas for

the future research.

2 AUTOMATIC CORPUS

CREATION

We used the

CTK photo-database for all experiments.

Every picture contains one face of a known person

(with the label). Unfortunately, the photos contain not

only the face itself. They may be composed of more

people, some background objects, etc.

2.1 Proposed Algorithm

Therefore, we propose an algorithm in order to detect

and extract the faces from the pictures and to create

582

Lenc L. and Král P..

Automatic Face Corpus Creation.

DOI: 10.5220/0004333305820586

In Proceedings of the 5th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2013), pages 582-586

ISBN: 978-989-8565-39-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 1: Example of one correctly detected face (left) and

one incorrectly detected face by the Viola-Jones face detec-

tor.

a face corpus as most automatically as possible:

1. face detection,

2. identiﬁcation and deletion of the incorrectly de-

tected faces,

3. eyes detection and head rotation according to the

eyes

2.1.1 Face Detection

We use the OpenCV library http://opencv.

willowgarage.com/wiki/ for the face detection

task. It implements the Viola-Jones algorithm (Viola

and Jones, 2001) which is one of the most successful

face detection algorithms. Figure 1 shows one

example of the correctly and one example of the

incorrectly detected face.

2.1.2 Incorrectly Detected Faces Identiﬁcation

and Deletion

Unfortunately, a certain number of the incorrectly de-

tected faces occurs in the output. Therefore, a ver-

iﬁcation of the detected faces is indispensable. In

order to avoid the manual processing, we propose a

classiﬁer for this task. It is used to classify the pic-

tures into two classes: F (faces) and NF (non faces).

We assume that the color distribution of these two

classes differ signiﬁcantly. Therefore, we compute

a histogram for every picture and we use histogram

values as a feature vector.

We utilize a neural network of the type Multi-

Layer Perceptron (MLP) as an implementation of the

classiﬁer due to its simplicity and our know-how in

this ﬁeld. It is trained on manually selected sub-set

of faces (50 examples) and non-faces (50 examples).

The MLP topology has 3 layers: 256 input nodes

(each input corresponds to one intensity value in the

grayscale picture), 10 neurons in the hidden layer and

two output nodes: F × NF classes. In order to eval-

uate the accuracy of this classiﬁer, we chosen ran-

domly 100 examples from each class and we verify

them manually. The face × non-face classiﬁer’s ac-

curacy is about 87% which is enough for our further

experiments.

Figure 2: Examples of the faces with 2, 1 and 0 detected

eyes (from left to right).

Figure 3: Example of the face detection (left), eyes detec-

tion (middle) and the face rotation according to the eyes

(right).

2.1.3 Eyes Detection and Head Rotation

According to the Eyes

As concluded in many previous studies, the face qual-

ity inﬂuence signiﬁcantly the face recognition accu-

racy. Our databaseis composed of the real-world pho-

tograph where the faces are usually not taken from the

front, but from the different angles. It is thus beneﬁ-

cial to transform the faces in order to be as similar as

possible, i.e. front-view faces. We simplify this trans-

formation by the face rotation according to the eyes.

The eyes are detected using a Viola-Jones algo-

rithm (as for the face detection task). If both eyes

are detected successfully the face is rotated and po-

sitioned so that the eyes are in the horizontal line for

all images. Finally, we perform a brief manual control

(on 100 examples) in order to evaluate the accuracy of

our eyes detection task. The resulting eyes detection

accuracy is thus about 94%. Figure 2 shows one ex-

ample of the eyes detection task where two, one and

no eye was detected by the algorithm.

Figure 3 shows the above described tasks of the

face and eyes detection and the face rotation accord-

ing to the eyes.

2.2 Resulting Corpus

Figure 4 shows the structure of the automatically cre-

ated face corpus by the above described algorithm.

We can summarize the important information as fol-

lows:

• in 1478 pictures no face was detected by the Viola

Jones method,

• another 3158 images was marked as no faces by

the MLP face × non-face classiﬁer,

AutomaticFaceCorpusCreation

583

Figure 4: Structure of the created

CTK face corpus.

• another 6623 face-pictures was not rotated ac-

cording to the eyes because no eye or one eye de-

tected,

• in the 4562 faces two eyes were detected and these

faces were rotated according to the eyes,

Note, that the whole corpus contains 15821 la-

beled images.

3 FACE RECOGNITION

The experiments have been motivated by the fact, that

our previously proposed face recognition approaches

work very well (recognition accuracy close to 100%

as already shown in (Lenc and Kr´al, 2012)) on the

standard ORL dataset and we would like to evaluate

our best approach on the real-world data (i.e. previ-

ously created corpus).

In all following experiments, an adapted SIFT-

based Kepenekci face recognitionapproach (Lenc and

Kr´al, 2012) and a cross-validation procedure will be

used.

3.1 Face Datasets

The face recognition accuracy is signiﬁcantly inﬂu-

enced by the three parameters:

1. quality of the face corpus,

2. number of the recognized faces,

3. number of the training face examples per person.

Therefore, we create some different face sub-sets

(see Table 1) in order to show the accuracy of the face

recognition when these parameters differ.

The ﬁrst part of this table shows the number of in-

dividuals when the face detection step is not veriﬁed,

while the second part reports the number of individ-

uals when the veriﬁcation of the face detection was

used. The second column represents the number of

individuals with a successful eyes detection, while the

number of individuals with incorrectly detected eyes

is reported in the third column.

Table 1: Face dataset sizes in relation to: a) the number

of the face examples per person; b) veriﬁcation of the face

detection; c) result of the eye detection.

Example no.

per person

Correctly

detected eyes

Incorrectly de-

tected eyes

1. Face detection without any veriﬁcation

Number of individuals

10 121 101

8 229 238

6 395 458

4 594 781

2. Face detection with the MLP veriﬁcation

Number of individuals

10 34 25

8 91 106

6 244 262

4 468 568

3.2 Face Recognition Results

Table 2 shows the face recognition accuracy on the

different datasets. We can conclude some interesting

knowledge from this table:

• eyes detection is very important for the face

recognition (poor face recognition accuracies of

the sub-sets with the incorrect eyes detection),

• the face detection using the Viola Jones method

is good enough and the further veriﬁcation by the

MLP classiﬁer is not necessary (better recognition

accuracy of the MLP veriﬁed set could be caused

by the smaller number of recognized examples,

only 34 individuals in the smallest set),

• face recognition accuracy is signiﬁcantly lower

when the number of the recognized individuals in-

creases and the number of training examples de-

creases,

• the best recognition accuracy (about 71%) is ob-

tained on the sub-set with the smallest number of

recognized individuals and with the highest num-

ber of training examples.

In our previous experiments (Lenc and Kr´al,

2012) we show that the number of training examples

is very important for the face recognition. Unfortu-

nately, we do not know, whether the second parameter

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

584

Table 2: Face recognition accuracy on the different datasets

in [%].

Example no.

per person

Correctly

detected eyes

Incorrectly de-

tected eyes

1. Face detection without any veriﬁcation

Face recognition accuracy in [%]

10 56.94 19.01

8 44.60 14.45

6 34.89 12.23

4 24.28 7.74

2. Face detection with the MLP veriﬁcation

Face recognition accuracy in [%]

10 71.18 47.20

8 52.75 22.76

6 35.79 16.17

4 24.84 9.99

inﬂuences the face recognition in the same manner or

it is less important. Therefore, we realized the follow-

ing experiment that shows the face recognition accu-

racy for constant number of training examples (equal

to 3). In this experiment, only the cases with the cor-

rectly detected eyes and the rotated faces are consid-

ered.

Table 3 shows the face recognition accuracy of

this experiment. We can conclude that the number of

the training examples inﬂuences our face recognition

method much more than the number of the recognized

individuals. In all cases, the recognition accuracy was

comparable except the case with the lowest count of

individuals (slightly higher recognition accuracy).

Table 3: Face recognition accuracy on the different datasets

with 4 face examples per person in [%].

Number of

individuals

Face recognition

accuracy in [%]

1. Face detection without any

veriﬁcation

121 24.79

229 25.67

395 26.27

594 24.28

2. Face detection with the

MLP veriﬁcation

34 32.35

91 27.75

244 23.77

468 24.84

In the previously described experiments, only part

of the results of the proposed face detection algorithm

was manually controlled. Therefore, the face recog-

nition errors occur due to two reasons:

1. error of the face classiﬁcation method,

2. error of the corpus creation algorithm (face detec-

tion and extraction).

In the last experiment, we would like to identify

the corpus creation errors in orderto evaluate our clas-

siﬁer as accurate as possible. Table 4 reports the re-

sults of this experiment. This experiment shows that

manual veriﬁcation improve the recognition accuracy

only slightly, improvement about 3% and 5% for 34

and 91 individuals, respectively.

Table 4: Comparison of the face recognition accuracy of the

automatic and manual veriﬁed face datasets.

Number of

individuals

Number

of exam-

ples/individual

Face recogni-

tion accuracy

in [%]

1. Face detection and extraction without

manual veriﬁcation

34 10 71.18

91 8 52.75

2. Face detection and extraction with

manual veriﬁcation

34 10 74.12

91 8 57.28

4 CONCLUSIONS AND

PERSPECTIVES

In this work, we proposed and evaluated a new face

corpus creation algorithm with the objective to create

a real-world face corpus for testing of our previously

developed face recognition approaches. We also sta-

tistically analysed the results of the face corpus cre-

ation process when the proposed algorithm was used.

This analysis shows that 4562 images was processed

successfully by the proposed algorithm. We further

compared the face recognition accuracy while using

different size/quality datasets. We demonstrated that

the eyes detection is very important step in the face

corpus creation process. We also proved, that the

number of the training examples inﬂuences the face

recognition much more than the number of the recog-

nized individuals. In the last experiment, we showed

that manual veriﬁcation of the corpus improve the

recognition accuracy only slightly. Therefore, we

conclude that our proposed algorithm is suitable for

the further use by the Czech News Agency, our com-

mercial partner.

As mentioned previously, the face recognition ac-

curacy is inﬂuenced signiﬁcantly by the quality of

the face database. Therefore, the ﬁrst perspective

consists in harmonization of the faces by using bet-

ter face transformations than the simple rotation ac-

cording to the eyes. Another perspective consists in

the use of conﬁdence measures as the post-processing

AutomaticFaceCorpusCreation

585

step (Lenc and Kr´al, 2011). The conﬁdence measure

technique will be used to detect and remove incor-

rectly detected (and rotated) face examples from the

resulting corpus. The conﬁdence measure will be also

used after the face recognition task.

ACKNOWLEDGEMENTS

This work has been partly supported by the UWB

grant SGS-2010-028 Advanced Computer and Infor-

mation Systems and by the European Regional De-

velopment Fund (ERDF), project NTIS - New Tech-

nologies for Information Society, European Centre of

Excellence, CZ.1.05/1.1.00/02.0090. We also would

like to thank Czech New Agency (

CTK) for support

and for providing the photographic data.

REFERENCES

Chen, J. and Nie, J.-Y. (2000). Automatic construction

of parallel English-Chinese corpus for cross-language

information retrieval. In The sixth conference on Ap-

plied natural language processing. Association for

Computational Linguistics.

Kepenekci, B. (2001). Face Recognition Using Gabor

Wavelet Transform. PhD thesis, The Middle East

Technical University.

Lenc, L. and Kr´al, P. (2011). Conﬁdence measure for au-

tomatic face recognition. In International Conference

on Knowledge Discovery and Information Retrieval,

Paris, France.

Lenc, L. and Kr´al, P. (2012). Novel matching methods for

automatic face recognition using SIFT. In 8th AIAI

(Artiﬁcial Intelligence Applications and Innovations)

Confence, Halkidiki, Greece.

Lowe, D. G. (2004). Distinctive image features from scale-

invariant keypoints. International Journal of Com-

puter Vision, 2.

Tom´as, J., Fabregat, M. del Val, J., Casacuberta, F., Pic´o, D.,

Sanch´ıs, A., and Vidal, E. (2001). Automatic devel-

opment of spanish-catalan corpora for machine trans-

lation. In Second International Workshop on Span-

ish Language Processing and Language Technologies,

Ja´en, Spain.

Viola, P. and Jones, M. (2001). Rapid object detection using

a boosted cascade of simple features. In Conference

on Computer Vision and Pattern Recognition.

ICAART2013-InternationalConferenceonAgentsandArtificialIntelligence

586
