To Frag or to Be Fragged

An Empirical Assessment of Latency in Cloud Gaming

Ulrich Lampe

, Qiong Wu

, Ronny Hans

, Andr

e Miede

and Ralf Steinmetz

Multimedia Communications Lab (KOM), TU Darmstadt, Rundeturmstr. 10, 64283 Darmstadt, Germany

Fakult

at f

ur Ingenieurwissenschaften, HTW des Saarlandes, Goebenstr. 40, 66117 Saarbr

ucken, Germany

Keywords:

Cloud Computing, Cloud Gaming, Quality of Service, Latency, Measurement.

Abstract:

With the emergence of cloud computing, diverse types of Information Technology services are increasingly

provisioned through large data centers via the Internet. A relatively novel service category is cloud gaming,

where video games are executed in the cloud and delivered to a client as audio/video stream. While cloud

gaming substantially reduces the demand of computational power on the client side, thus enabling the use of

thin clients, it may also affect the Quality of Service through the introduction of network latencies. In this

work, we quantitatively examine this effect, using a self-developed measurement tool and a set of actual cloud

gaming providers. For the two providers and three games in our experiment, we ﬁnd absolute increases in

latency between approximately 40 ms and 150 ms, or between 85% and 800% in relative terms.

1 INTRODUCTION

Since its popularization in the mid-2000s, cloud com-

puting has substantially altered the way in which In-

formation Technology (IT) services are delivered and

brought massive changes to the IT sector (Dikaiakos

et al., 2009). Today, the decade-old vision of deliver-

ing IT as a “utility” has come closer to realization than

ever before (Buyya et al., 2009).

A relatively novel business model, within the

greater context of cloud computing, is cloud gaming.

The principal idea of this concept is to execute video

games in a cloud data center and deliver them to a

client as audio/video stream via the Internet. The client

thus serves as a simple playback and input device; the

computationally complex task of executing the actual

game logic and rendering the game images is shifted

to the cloud (Choy et al., 2012; Jarschel et al., 2011;

Ross, 2009; S

uselbeck et al., 2009).

From a formal standpoint, based on the popular

NIST deﬁnition of cloud computing (Mell and Grance,

2011), cloud gaming can most intuitively be inter-

preted as a subclass of the Software as a Service model,

because it constitutes a functionally complex service

that is offered on the basis of low-level infrastructure

services.

From a customer perspective, one main advantage

of cloud gaming exists in the ability to access games

at any place and time, independent of any speciﬁc de-

vice upon which they are installed (Choy et al., 2012).

Furthermore, hardware expenditures are substantially

reduced, because a simplistic thin client is usually sufﬁ-

cient for access (Chen et al., 2011). In addition, games

do not have to be purchased for a ﬁxed (and commonly

quite notable) amount of money, but can be leased on a

pay-per-use basis. From the provider perspective, one

main beneﬁt is the prevention of copyright infringe-

ments (Ross, 2009). In addition, distribution costs

may be substantially reduced, because the need for the

delivery of physical media is alleviated. Furthermore,

the development process may be greatly simpliﬁed if

games are exclusively developed for the cloud, rather

than multiple different platforms.

However, the use of the Internet also introduces

a new component into the delivery chain. Being a

public network, the Internet lies (partially) out of the

control sphere of both the user and the provider, and

follows a “best effort” philosophy, i. e., it does not

make any end-to-end Quality of Service (QoS) assur-

ances (Courcoubetis et al., 2011). Hence, limitations

of the network infrastructure, such as high latency,

small bandwidth, or high packet loss, may potentially

affect the QoS of the overall cloud gaming system for

the user.

In this work, we focus on the QoS parameter of

latency. This parameter plays an important role for the

overall game experience (Dick et al., 2005; S

uselbeck

et al., 2009). As the title of this work indicates, this

Lampe U., Wu Q., Hans R., Miede A. and Steinmetz R..

To Frag or to Be Fragged - An Empirical Assessment of Latency in Cloud Gaming.

DOI: 10.5220/0004345900050012

In Proceedings of the 3rd International Conference on Cloud Computing and Services Science (CLOSER-2013), pages 5-12

ISBN: 978-989-8565-52-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

applies speciﬁcally for action-oriented games such as

ﬁrst-person shooters, where it may determine whether

a player is “fragged”, i.e., her/his character is killed,

or is able to frag her/his opponent (Claypool and Clay-

pool, 2010; Dick et al., 2005).

Hence, the research question we aim to empirically

answer in this work is: “What is the impact of cloud

gaming on the QoS parameter of latency, as compared

to a local execution of a video game?”

In the following Section 2, we introduce the exper-

imental setup and infrastructure. Subsequently, in Sec-

tion 3, we extensively present and discuss the results.

An overview of related work is given in Section 4.

The paper concludes with a summary and outlook in

Section 5.

2 EXPERIMENTAL DESIGN

In this section, we describe the overall design of our

experiment. To begin with, we brieﬂy explain the

dependent and independent variables that were con-

sidered. Subsequently, we introduce our measurement

tool and brieﬂy describe its technical implementation.

2.1 Dependent Variable: Latency

As explained in the previous section, in this work, we

focus on the QoS parameter of latency. It thus consti-

tutes the only dependent variable in our experiments.

More speciﬁcally, we consider user-perceived latency.

By that term, we refer to the timespan that elapses be-

tween a certain action performed by the user, e. g., the

press of a mouse button or a key, and the correspond-

ing game reaction, e. g., the appearance of gunﬁre or

the menu. It is also referred to as “interactive response

time” in related research (Choy et al., 2012).

Based on the combined ﬁndings of Choy et al.,

Wang, and Wilson, latency can be split into the follow-

ing components if a game is locally executed (Choy

et al., 2012; Wang, 2012; Wilson, 2009):

•

Input lag, which corresponds to the timespan be-

tween two subsequent sampling events of the game

controller, e. g., mouse or keyboard.

•

Game Pipeline CPU Time, i. e., the time which is

required for processing the input and realizing the

game logic.

•

Game Pipeline GPU Time, i. e., the time which the

graphic card requires for rendering the next frame

of the game.

•

Frame Transmission, which denotes the time that

is required for transferring the frame from the back-

buffer to the frontbuffer of the graphic card, and

subsequently to the screen.

•

LCD Response Time, which indicates the timespan

that is required to actually display the frame on the

screen.

Once a game is executed in the cloud and delivered

via a network, the following additional components

have to be considered (Choy et al., 2012; Wang, 2012;

Wilson, 2009):

•

Upstream Data Transfer, i. e., the time that it takes

to sent the user input to the cloud gaming provider.

•

Capture and Encoding, which denotes the time

requirements for capturing the current frame and

encoding it as video stream.

•

Downstream Data Transfer, i. e., the timespan for

transferring the stream to the client.

•

Decoding, which indicates the time for converting

the video stream back into a frame.

Intuitively, one might reason that a cloud-based

game will always exhibit a higher latency that a locally

executed game due to the additional latency compo-

nents. However, this is not necessarily true. In fact,

due to the use of potent hardware in the cloud and de-

pending on the geographical distance between the user

and the cloud provider, the reduction of time spent in

the game pipeline may overcompensate the network,

encoding, and decoding latencies (Wang, 2012).

2.2 Independent Variables: Games,

Providers, and Networks

The dependent variable in our experiments, latency,

may potentially be determined by various factors, i. e.,

a set of independent variables. In our work, we fo-

cus on different games, cloud gaming providers, and

network connections as suspected key determinants.

With respect to the main subject of our research,

i. e., the examined games, our focus was on action-

oriented titles. As explained in the previous section,

these games are commonly very sensitive to latency

increases and thus, of elevated interest. We speciﬁcally

chose the following titles, all of which are available

both in the cloud and for local installation:

•

Shadowgrounds

is a 3D ﬁrst-person shooter game

developed by Frozenbyte. It was initially released

in the year 2005.

•

Shadowgrounds Survivor

is a sequel to Shadow-

grounds. It was also developed by Frozenbyte and

released in 2007.

http://www.shadowgroundsgame.com/

http://www.shadowgroundssurvivor.com/

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

•

Trine

is an action-oriented puzzle game. It was

developed by Frozenbyte as well and released in

2009.

The determination of representative cloud gaming

providers is somewhat challenging. Following an ini-

tial hype around cloud gaming, which resulted in a

variety of new suppliers, the market appears to be in

a phase of consolidation today. For example, Gaikai,

one of the pioneers in cloud gaming, was acquired

in August 2012 by the major industry player Sony

(Gaikai, 2012), and has temporally ceased its services.

This work includes measurements for three provision-

ing options:

•

Cloud Gaming Provider A (CGP-A), which is lo-

cated in the Americas and operates a dedicated

infrastructure

•

Cloud Gaming Provider B (CGP-B), with head-

quarters in the Asian-Paciﬁc region, which also

uses a dedicated infrastructure.

•

A Local Personal Computer (Local), which is

equipped with an Intel Core 2 Quad Q6700 CPU,

an NVidia Geforce GTX 560 GPU, and 4 GB of

memory.

As it has been explained before, cloud gaming

employs the Internet as delivery channel. Because

the network as such is out of the control sphere of

both provider and user, we focus on the user’s network

connection in our experiments. Speciﬁcally, we regard

the following techniques:

•

Universal Mobile Telecommunications System

(UMTS), which marks the third generation (3G) of

cellular networks and has been widely deployed in

many industrialized countries since the mid-2000s.

We use a variant with with the High Speed Packet

Access (HSPA) extensions.

•

Long Term Evaluation (LTE), which corresponds

to the fourth generation (4G) of cellular networks.

It has recently been or is currently being introduced

by many mobile network providers.

•

Very High Speed Digital Subscriber Line (VSDL),

which denotes the cutting-edge in traditional ﬁxed-

line, copper cable-based Internet access.

2.3 Measurement Tool:

GALAMETO.KOM

The aim of our approach is to automate the measure-

ment process to the largest possible extent. For that

http://www.trine-thegame.com/

Unfortunately, due to legal considerations, we are

required to anonymize the names of the cloud gaming

providers.

matter, we have devised a GAme LAtency MEasure-

ment TOol, or in brief, GALAMETO.KOM. This tool

autonomously invokes a predeﬁned action in the game

and measures the time interval until the corresponding

reaction can be observed.

As a preparatory step, the tool requires the user to

specify the trigger that invokes a certain action in the

game. Such trigger may consist in pressing a mouse

button or a key. Furthermore, the user has to spec-

ify the screen area that will reﬂect the corresponding

reaction, such as the display of gunﬁre or the main

menu. In order to reliably identify the reaction, the

user further declares a numerical sensitivity value

This sensitivity value reﬂects the change of the aver-

age color within the predeﬁned screen area. Lastly,

in order to start an experiment, the user speciﬁes the

desired number of observations in the sample.

For each measurement iteration,

GALAMETO.KOM ﬁrst invokes the speciﬁed

trigger. That is, it submits the user-deﬁned activity

to the game and stores a timestamp

act

. Then, the

tool scans the frontbuffer of the graphics card and

computes the initial average color value

init

for the

predeﬁned screen area. That procedure is continuously

repeated, each time updating the current average color

curr

and a corresponding timestamp

react

. Once

a change of color, i. e., a reaction with sufﬁcient

magnitude, is detected (i. e., if

curr

−c

init

| ≥ δ

holds),

the latency

lat

= t

react

− t

act

can be computed. The

latency value is stored as new observation, and the

process is repeated until a sample of the desired size

has been collected.

2.4 Measurement Procedure

For our experiment, we followed a so-called full fac-

torial design. That is, we conducted measurements

for each possible value combination of the three in-

dependent variables. Because the local execution of

a single-player game is independent of the network

connection, there are seven possible combinations of

provider and network. For each combination, we exam-

ine the three selected games. Thus, our experimental

setup consists of 21 different test cases.

For each test case, we acquired a sample of 250 ob-

servations. Subsequently, we checked for statistically

signiﬁcant differences between the test cases with re-

spect to the mean latencies using a parametric

-test

(Jain, 1991; Kirk, 2007). For validation purposes, a

non-parametric Mann-Whitney

-test was addition-

ally applied (Kirk, 2007). Both tests were conducted at

the same conﬁdence level of 95% (i. e.,

al pha = 0.05

The mean latencies of a pair of test cases are only

considered signiﬁcantly different if the according indi-

ToFragortoBeFragged-AnEmpiricalAssessmentofLatencyinCloudGaming

cation is given by both tests.

All experiments were executed using the previ-

ously speciﬁed laptop computer in order to avoid mea-

surement inaccuracies due to hardware differences.

The different network connections were provided by

a major German telecommunications provider. No ar-

tiﬁcial network disturbances were introduced into the

measurement process.

3 EXPERIMENTAL RESULTS

AND DISCUSSION

The results of our experiment, i. e., observed mean la-

tencies, along with the corresponding conﬁdence inter-

vals, are illustrated in Figures 1, 2, and 3 for the three

games respectively. In the appendix, we further pro-

vide corresponding box-and-whisker plots (Figures 4

through 6). In addition, Table 1 contains the detailed

results that have been the basis for the ﬁgures.

As can be seen, a local execution of the games

yields the lowest latencies, ranging from 22 ms for

Shadowgrounds to 44 ms for Trine. As it may have

been expected, the latencies signiﬁcantly increase with

the novelty of the game. Because the remaining latency

components can be assumed constant, this indicates a

growth of computational complexity within the game

pipeline, i. e., the overall increase in latency can likely

be traced back to increased CPU and GPU time.

For cloud gaming provider A, we observe mean la-

tencies between approximately 65 ms and 130 ms. The

latencies signiﬁcantly decrease with improved network

connectivity. Speciﬁcally, with respect to the cellular

networks, LTE is able to reduce the mean latency by

up to 35 ms compared to UMTS. A ﬁxed-line connec-

tion, namely VSDL, yields a further reduction of up to

12 ms. In general, the latency increases diminish com-

pared to a local execution with the novelty of the game.

This indicates that the latency of the game pipeline

can, in fact, be reduced through the use of dedicated

hardware in the cloud data center (cf. Section 2.1).

However, the effect does not compensate for the net-

work delay in our test cases. Hence, regardless of the

game and network connection, provider A is not able

to compete with a local execution in terms of latency.

Depending on the network connection, cloud gaming

adds between 40 ms and 90 ms of latency for each

considered game. These differences are statistically

signiﬁcant at the assumed conﬁdence level of 95%.

For cloud gaming provider B, we ﬁnd even higher

mean latencies between about 150 ms and 220 ms.

Once again, there is a signiﬁcant reduction in these ﬁg-

ures with improved network connectivity. Compared

to UMTS, LTE achieves a reduction of up to 29 ms,

which very similar to the results for cloud gaming

provider A. Likewise, VSDL shaves off between 9 ms

and 17 ms in latency in comparison to LTE. In con-

trast to provider A, we do not ﬁnd a decreasing latency

margin with increasing novelty, i. e., computational

complexity, of the game. Thus, provider B is even

less capable than provider A of competing with a local

execution in terms of latency. Speciﬁcally, depending

on the game, provider B adds between 100 ms and

150 ms of latency. As for provider A, these increases

are statistically signiﬁcant.

In summary, with respect to the research question

from Section 1, we conclude that cloud gaming has

a signiﬁcant and negative impact on the QoS param-

eter of latency, compared to the local execution of a

game. Depending on the provider and network con-

nection, cloud gaming results in an latency increases

between 40 ms and 150 ms. In relative terms, the

increases amount to between 85% (Trine at CGP-A

using VDSL) and 828% (Shadowgrounds at CGP-B

using UMTS).

As previously explained, our focus in this work

was on QoS, i. e., objective quality ﬁgures. Thus, the

subjective perception of our results may substantially

differ between various player groups. According to

Dick et al., the mean tolerable latencies for an unim-

paired experience in a multi-player game are in the

range between 50 and 100 ms; maximal tolerable la-

tencies are approximately 50 ms higher, i. e., in the

order of 100 to 150 ms (Dick et al., 2005). User stud-

ies by Jarschel et al. also indicate that the Quality

of Experience (QoE) quickly drops with increasing

latency, speciﬁcally in fast-paced games such as rac-

ing simulations or ﬁrst-person shooters (Jarschel et al.,

2011). Hence, based on the observed numbers, we

believe that cloud gaming is primarily attractive for

slow-paced games, as well as casual players who likely

have moderate QoS expectations compared to experi-

enced and sophisticated gamers.

Given the reliance on the Internet as delivery

medium, cloud gaming would likely proﬁt from a shift

away from the best-effort philosophy towards sophis-

ticated QoS mechanisms. The development of such

mechanisms has been an active ﬁeld of research for

many years, resulting in proposals such as Integrated

Services (IntServ) or Differentiated Services (DiffServ)

(Tanenbaum, 2003). However, past experience – for

example, with the rather sluggish introduction of IPv6

– has shown that many Internet service providers are

rather reluctant to make fundamental infrastructure

changes unless a pressing need arises. In addition,

as the ongoing debate about net neutrality shows, the

introduction of QoS management techniques on the In-

ternet is not merely a technical issue. For a more com-

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

100

150

200

250

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Mean Latency [ms]

Provider, Network

Figure 1: Mean latencies with 95% conﬁdence intervals for

the game Shadowgrounds per test case (sample size

n =

250).

prehensive discussion, we refer the interested reader

to Xiao (Xiao, 2008).

Assuming that the Internet itself will remain to fol-

low a best-effort philosophy in the short and medium

term, two main options remain for cloud providers to

improve the QoS of their systems.

The ﬁrst option consists in moving the data cen-

ters geographically closer to the clients. However,

for a constant client base, such decentralization im-

plies building a larger number of data centers. Due

to the reduced size and thus, smaller economies of

scale of these data centers (Greenberg et al., 2008),

such approach is likely to be cost-intensive. A viable

alternative may consist in the exploitation of servers

in existing content delivery networks, as proposed by

Choy et al. (Choy et al., 2012).

Second, cloud providers may upgrade their servers

to reduce the latency of the game pipeline. Thus, they

could aim to (over-)compensate for the network la-

tency. However, while such an approach may be suc-

cessful for computationally complex games, it will

likely fail for older games where the impact of the

game pipeline is relatively small. In addition, server

upgrades can be costly, speciﬁcally if disproportion-

ately expensive high-end components have to be pur-

chased.

Hence, in our opinion, a key challenge for cloud

providers consists in ﬁnding an economically reason-

able balance between QoS (and thus, the potential

number of customers) and cost.

4 RELATED WORK

With the interest in – not to say hype around – cloud

computing in recent years, this paradigm has been a

very intensive area of research. However, the speciﬁc

100

150

200

250

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Mean Latency [ms]

Provider, Network

Figure 2: Mean latencies with 95% conﬁdence intervals for

the game Shadowgrounds Survivor per test case (sample size

n = 250).

100

150

200

250

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Mean Latency [ms]

Provider, Network

Figure 3: Mean latencies with 95% conﬁdence intervals for

the game Trine per test case (sample size n = 250).

issue of cloud gaming has, according to our percep-

tion, received relatively little attention by the research

community to date.

Chen et al. have, to the best of our knowledge,

been the ﬁrst to conduct empirical latency measure-

ments of actual cloud gaming providers (Chen et al.,

2011). In their experiments, they regarded OnLive, a

commercial provider, as well as, StreamMyGame, a

free software tool that permits to set up a private video

game stream. Chen et al. propose and implement a

measurement tool which is based on similar concep-

tual ideas as GALAMETO.KOM. Most notably, the

authors also trigger a certain action – in their case, the

invocation of the in-game menu – and observe the ap-

pearance of the corresponding reaction based on color

changes. In their experiments, they ﬁnd streaming

delays – which do not include the network latency –

between 135 ms and 240 ms for OnLive and up to

500 ms for StreamMyGame. Thus, their results are in

a similar order of magnitude as the values that have

been observed in our experiments. In contrast to this

work, Chen et al. trigger the comparison process in

ToFragortoBeFragged-AnEmpiricalAssessmentofLatencyinCloudGaming

the measurement tool through a redirected Direct3D

function call and operates on the backbuffer of the

graphics card, not the frontbuffer. Thus, the latency

component that is introduced through the copying of

the backbuffer scene into the frontbuffer has not been

considered in their work. In addition, and more impor-

tantly, the authors do not use a locally executed game

as benchmark in their experiments.

Jarschel et al. have conducted a user-study involv-

ing 58 participants on QoE of cloud gaming depending

on network characteristics (Jarschel et al., 2011). For

that purpose, they generate an audio/video stream us-

ing a PlayStation 3 gaming console. This stream is

subjected to artiﬁcial delay and packet loss, ranging

between 0 and 300 ms and 0 and 1% respectively,

in different test scenarios. Jarschel et al. ﬁnd that

the quality of the downstream, i. e., the link between

provider and user, has a substantially higher impact

on the QoE than the quality of the upstream, i. e., the

link between user and provider. Their results also indi-

cate that packet loss is of higher relevance than latency

for the subjective quality perception. The main dif-

ference compared to our work consists in the focus

on subjective, rather than objective quality aspects. In

addition, Jarschel et al. did not regard commercial

cloud providers in their experiments.

Wang and Dey have proposed a cloud gaming sys-

tem for mobile clients called Cloud Mobile Gaming

(CMG) (Wang and Dey, 2009). As part of their work,

they examine the impact of different factors on the user

experience. The considered factors involve the video

stream conﬁguration and quality, the game conﬁgura-

tion, delay (i. e., latency), and packet loss. Similarly

to Jarschel et al., the authors use a controlled exper-

imental setup, in which they systematically vary the

values of the previously mentioned factors. Using on

a study group of 21 participants, they infer impair-

ment functions for these factors. The ﬁndings are

subsequently validated using a control group of 15

participants. Based on practical measurements, the

authors conclude that their CMG system may provide

a subjectively good or mediocre gaming experience in

Wi-Fi and cellular networks, respectively. In contrast

to our work, which considers public cloud gaming

providers and the local execution of games, Wang and

Dey exclusively examine their own, proprietary cloud

gaming system.

Outside the academic world, West has measured

the latency of various locally executed games on a

PlayStation 3 console (West, 2008). West uses a com-

modity digital camera in order to take high-frequency

photographs of the game controller and the attached

screen during gameplay. Based on a subsequent man-

ual analysis of the resulting picture stream, he deduces

the timespan between a button press and the corre-

sponding action. West ﬁnds latencies between approx-

imately 50 and 300 ms on the PlayStation 3. The main

beneﬁt ob West’s method is the clear separation be-

tween the gaming system and the measurement system.

In addition, the camera-based approach also permits to

capture the LCD response time. However, the accuracy

of the measurement is limited by the maximal fram-

erate of the camera. In addition, GALAMETO.KOM

only requires a brief preparatory manual tuning phase,

whereas West’s method requires substantial manual ef-

fort, which renders the collection of large data samples

difﬁcult.

In summary, to the best of our knowledge, our work

is the ﬁrst to empirically examine and systematically

compare the user-perceived latency for both cloud-

based and locally executed games. Our research results

thus permit us to objectively quantify the QoS impact

of moving games from a local computer to the cloud,

which can be a decisive factor for the acceptance of

cloud gaming among potential customers.

5 SUMMARY AND OUTLOOK

The cloud computing paradigm has substantially trans-

formed the delivery of IT services. A relatively new

service class within this context is cloud gaming. In

cloud gaming, video games are centrally executed in a

cloud data center and delivered to the customer as an

audio/video stream via the Internet. While this model

has many advantages both from a user and provider

perspective, it also introduces the Internet into the de-

livery chain, which may inﬂict the Quality of Service

for the user.

In this work, our focus was on the experimental

evaluation of user-perceived latency in cloud-based

and locally executed video games. For that mat-

ter, we created the semi-automatic measurement tool

GALAMETO.KOM. We conducted latency measure-

ment for two cloud gaming providers, using three dif-

ferent games and network types, respectively.

Our results indicate that cloud gaming exhibits

signiﬁcantly higher latency than a local execution. Ab-

solute increases were in the range between 40 ms and

150 ms, while the the relative increases approximately

amounted to between 85% and 800%. The margin

between cloud providers and the local execution di-

minished with an improved network connection and

an increase in computational complexity of the game.

In our future work, we aim to substantially extend

our experiments through the consideration of addi-

tional games, providers, networks, and devices. In this

process, we will pursue a longitudinal design, which

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

permits to identify time-dependent variations in la-

tency. We additionally strive to analyze the effects of

network disturbances, such as ﬂuctuating bandwidth

or increased packet loss, on the QoS parameter of user-

perceived latency. Furthermore, we aim to examine

how cloud gaming providers can cost-efﬁciently pro-

vide their services under consideration of QoS aspects.

ACKNOWLEDGEMENTS

This work has been sponsored in part by the

E-Finance Lab e.V., Frankfurt am Main, Germany

(http://www.eﬁnancelab.com).

REFERENCES

Buyya, R., Yeo, C., Venugopal, S., Broberg, J., and Brandic,

I. (2009). Cloud Computing and Emerging IT Plat-

forms: Vision, Hype, and Reality for Delivering Com-

puting as the 5th Utility. Future Generation Computer

Systems, 25(6):599–616.

Chen, K., Chang, Y., Tseng, P., Huang, C., and Lei, C. (2011).

Measuring the Latency of Cloud Gaming Systems. In

19th ACM International Conference on Multimedia.

Choy, S., Wong, B., Simon, G., and Rosenberg, C. (2012).

The Brewing Storm in Cloud Gaming: A Measurement

Study on Cloud to End-User Latency. In 11th Annual

Workshop on Network and Systems Support for Games.

Claypool, M. and Claypool, K. (2010). Latency Can Kill:

Precision and Deadline in Online Games. In First An-

nual ACM SIGMM Conference on Multimedia Systems.

Courcoubetis, C., Dramitinos, M., Stamoulis, G., Blocq, G.,

Miron, A., and Orda, A. (2011). Inter-Carrier Inter-

connection Services: QoS, Economics and Business

Issues. In 2011 IEEE Symposium on Computers and

Communications.

Dick, M., Wellnitz, O., and Wolf, L. (2005). Analysis of Fac-

tors Affecting Players’ Performance and Perception in

Multiplayer Games. In 4th ACM SIGCOMM Workshop

on Network and System Support for Games.

Dikaiakos, M., Katsaros, D., Mehra, P., Pallis, G., and Vakali,

A. (2009). Cloud Computing: Distributed Internet

Computing for IT and Scientiﬁc Research. IEEE Inter-

net Computing, 13(5):10–13.

Gaikai (2012). Gaikai.com :: History. http://

www.gaikai.com/history.

Greenberg, A., Hamilton, J., Maltz, D., and Patel, P. (2008).

The Cost of a Cloud: Research Problems in Data Cen-

ter Networks. ACM SIGCOMM Computer Communi-

cation Review, 39(1):68–73.

Jain, R. K. (1991). The Art of Computer Systems Perfor-

mance Analysis: Techniques for Experimental Design,

Measurement, Simulation, and Modeling. Wiley.

Jarschel, M., Schlosser, D., Scheuring, S., and Hossfeld, T.

(2011). An Evaluation of QoE in Cloud Gaming Based

on Subjective Tests. In 5th International Conference on

Innovative Mobile and Internet Services in Ubiquitous

Computing.

Kirk, R. (2007). Statistics: An Introduction. Wadsworth

Publishing, 5th edition.

Mell, P. and Grance, T. (2011). The NIST Deﬁnition of

Cloud Computing – Special Publication 800-145. Tech-

nical report, National Institute of Standards and Tech-

nology.

Ross, P. (2009). Cloud Computing’s Killer App: Gaming.

IEEE Spectrum, 46(3):14.

uselbeck, R., Schiele, G., and Becker, C. (2009). Peer-to-

Peer Support for Low-Latency Massively Multiplayer

Online Games in the Cloud. In 8th Annual Workshop

on Network and Systems Support for Games.

Tanenbaum, A. S. (2003). Computer Networks. Pearson

Education, 4th edition.

Wang, J. (2012). NVIDIA GeForce GRID – A Glimpse

at the Future of Gaming. http://www.geforce.com/

whats-new/articles/geforce-grid.

Wang, S. and Dey, S. (2009). Modeling and Characteriz-

ing User Experience in a Cloud Server Based Mobile

Gaming Approach. In 2009 IEEE Global Telecommu-

nications Conference.

West, M. (2008). Measuring Responsiveness in Video

Games. http://www.gamasutra.com/view/feature/

132122/measuring responsiveness in video .php.

Wilson, D. (2009). Exploring Input Lag Inside and Out.

http://www.anandtech.com/show/2803/7.

Xiao, X. (2008). Technical, Commercial and Regulatory

Challenges of QoS: An Internet Service Model Per-

spective. Morgan Kaufmann.

All online references in this paper were last accessed

and validated in January 2013.

APPENDIX

Please refer to the next page.

ToFragortoBeFragged-AnEmpiricalAssessmentofLatencyinCloudGaming

Table 1: Detailed results for the independent variable latency per test case (in ms). Abbreviations: SG – Shadowgrounds; SGS –

Shadowgrounds Survivor; CI95 – Radius of the 95% conﬁdence interval; Pc. – Percentile.

Game Provider Network Mean CI95 2.5th Pc. 25th Pc. Median 75th Pc. 97.5th Pc.

SG CGP-A UMTS 93.65 6.49 68.98 81.06 87.49 95.00 132.66

SG CGP-A LTE 76.39 1.34 55.04 69.74 76.65 83.19 96.76

SG CGP-A VSDL 64.39 0.98 48.01 59.05 64.52 69.96 79.75

SG CGP-B UMTS 205.34 3.00 167.71 189.81 200.33 216.11 262.00

SG CGP-B LTE 181.47 3.20 145.54 163.79 179.08 193.80 263.31

SG CGP-B VSDL 170.09 3.29 136.85 151.75 166.23 178.13 259.15

SG Local N/A 22.13 0.93 7.91 17.46 22.68 27.80 36.00

SGS CGP-A UMTS 106.19 1.61 83.63 96.21 106.89 115.02 130.41

SGS CGP-A LTE 80.41 1.40 60.26 72.82 79.59 87.32 102.33

SGS CGP-A VSDL 70.43 1.00 56.06 64.66 70.00 76.13 86.90

SGS CGP-B UMTS 217.63 3.27 182.11 200.11 213.73 231.18 285.12

SGS CGP-B LTE 201.58 2.85 161.56 189.64 198.71 210.90 261.06

SGS CGP-B VSDL 184.45 2.73 150.83 167.37 183.18 199.11 224.45

SGS Local N/A 33.79 1.11 16.64 27.69 34.03 39.98 51.08

Trine CGP-A UMTS 128.13 1.91 95.56 117.01 128.43 139.00 153.98

Trine CGP-A LTE 93.06 1.31 76.26 85.96 93.24 99.48 112.61

Trine CGP-A VSDL 82.88 1.25 67.05 75.82 82.03 88.62 106.85

Trine CGP-B UMTS 189.58 2.57 157.01 176.04 187.87 201.02 239.97

Trine CGP-B LTE 160.76 3.11 130.12 145.36 156.74 169.60 219.02

Trine CGP-B VSDL 151.69 2.01 118.01 141.79 152.10 161.56 181.86

Trine Local N/A 44.68 1.83 25.14 35.90 41.01 49.29 84.01

100

150

200

250

300

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Latency [ms]

Provider, Network

Figure 4: Box-and-whisker plot of latencies for the game

Shadowgrounds per test case (sample size

n = 250

). The box

indicates the 25th and 75th percentiles, whereas the whiskers

mark the 2.5th and 97.5th percentiles. The median, i. e., 50th

percentile, is denoted by a horizontal bar within the box.

100

150

200

250

300

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Latency [ms]

Provider, Network

Figure 5: Box-and-whisker plot of latencies for the game

Shadowgrounds Survivor per test case (sample size

n = 250

Same notation as in Figure 4.

100

150

200

250

300

CGP-A

UMTS

CGP-A

LTE

CGP-A

VSDL

CGP-B

UMTS

CGP-B

LTE

CGP-B

VSDL

Local

N/A

Latency [ms]

Provider, Network

Figure 6: Box-and-whisker plot of latencies for the game

Trine per test case (sample size

n = 250

). Same notation as

in Figure 4.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience
