HTML5 Agents – Mobile Agents for the Web

Kari Systä, Tommi Mikkonen and Laura Järvenpää

Department of Pervasive Computing, Tampere University of Technology, BOX 553, 33101 Tampere, Finland

Keywords: HTML5, Mobile Agents.

Abstract: The emergence of HTML5 allows more applications to be run in browsers. Although most of these

applications are often network connected, they can also run in off-line mode and especially after

deployment they are not necessarily dependent on any server. We argue that the modern Web infrastructure

with HTML5 as such can be an agent platform and mobile agents could be developed in similar way as Web

applications. For us the agents can also be end-user applications that the user can send to a server so that the

state is preserved and the execution can continue. The user can later fetch the agent to the same client device

or to another device. In addition to the mobile agent use cases, the concept also allows users to continue

their work later on another device or even allows other users to continue execution in their own devices. The

paper presents the overall concept and architecture of HTML5 agents, a number of use cases, the proof-of-

concept implementation, and a list of example applications.

1 INTRODUCTION

HTML5, the latest version of standards in the

HTML family, extends the applicability of the

technology towards client-side applications.

Traditionally, Web applications have more or less

been acting as user interfaces for applications

running in a server, but the goal of HTML5 is to

allow the development of complete client-side

applications. Consequently the emergence of

HTML5 allows more applications to be run in

browser, and these applications can be deployed

over network by using the standard Web

technologies. Moreover, although most of these

applications are often network connected, they can

also run in off-line mode and especially after

deployment they are not necessarily dependent on

any server. For us the overall goal of HTML5 to

support rich applications is important, and in this

paper we do not refer to any specific new technology

introduced by HTML5.

The capabilities of HTML5 described above,

together with other recent developments, such as

increasing pervasiveness of the Web and improving

performance of JavaScript virtual machines inside

browsers, enable the introduction of Web-based

application platforms and operating systems –

something that can be called Web operating systems.

In these systems applications can be stored in a

cache so that downloading is not necessary at the

subsequent invocations of the application. For the

user this means that the applications do not differ

from using traditional installed applications.

Examples of such systems include Cloudberry

(Taivalsaari and Systä, 2012), Google Chromium

OS (http://www.chromium.org/chromium-os) and

Firefox OS of Mozilla (http://www.mozilla.org/en-

US/firefoxos). Of these systems, Chromium OS is

almost a generic operating system for web-enabled

devices, whereas Firefox OS and Cloudberry are

systems where all user-visible functionality of a

smart phone is implemented as HTML5

applications. The listed systems also prove the above

claim that HTML5 technology can be used to build

complete and advanced applications which in many

ways are indistinguishable from traditional,

installable binary applications.

From the technological perspective, however,

Web operating systems differ from traditional

application platforms, because they build on

principles of the Web instead of more traditional

concepts associated with operating systems and

binary applications. Although applications are often

cached, they are not necessarily explicitly “installed”

and updates can be delivered automatically and

without bothering the end user.

The development of Web operating systems and

especially Cloudberry (Taivalsaari and Systä, 2012)

Systä K., Mikkonen T. and Järvenpää L..

HTML5 Agents – Mobile Agents for the Web.

DOI: 10.5220/0004368800370044

In Proceedings of the 9th International Conference on Web Information Systems and Technologies (WEBIST-2013), pages 37-44

ISBN: 978-989-8565-54-9

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

have inspired an idea of Cloud browser (Taivalsaari

et al., 2013). In Cloud browser the browser session –

in essence a set of active “pages” and HTML5

applications, both of which are identified by

associated URLs – constitutes the user session. This

user session – the URLs of applications and

information on the state of the applications – is

stored in the Web.

The Web is based on mobile code. Four para-

digms of mobile code have been presented in

(Carzaniga et al., 1997):

 Client-Server where client uses code that is located

in another node.

 Remote Evaluation where client sends execution

instructions, for example SQL queries, to another

node.

 Code On Demand where code is downloaded to

the client for execution. HTML5 applications are

widely used examples of code-on-demand.

 Mobile Agent where code together with internal

state of the application is moved to other node for

execution.

The first three paradigms are regularly used in

Web applications and (Taivalsaari et al., 2013)

presented a concept where the internal state of

HTML5 applications were stored in server in the

cloud.

This paper builds on the above ideas, where the

browser is increasingly acting as the application

platform, and where applications can store their

internal state in the server for future use. In addition,

we propose moving the executable code with the

internal state of the application. As a concrete

contribution, we propose a system where the

applications can also continue their execution while

being stored in the server, and the running

applications can later be retrieved back to a browser.

We consider these applications as mobile agents

since they comply with commonly used definitions

of mobile agents, like the ones presented in (Kotz

and Gray, 1999) and (Yu et al., 2006). Although our

current applications do not include autonomous

migration, the proposed approach supports it at the

conceptual level. Our agents are implemented as

HTML5 applications and thus we call them HTML5

agents in this paper.

We claim that HTML5 technology provides

important benefits in implementation and use of

mobile agent for two main reasons:

1. HTML5 technologies are widely used and have a

strong ecosystem. This means that platforms are

widely available and there are de-facto standards and

tools.

2. A new class of use cases for mobile agents

becomes available since the users can run the same

application as a normal application and transfer it to

an agent server, and pull it back in another context.

This puts the users in control and makes the agent

platform more user-oriented.

Many applications can also be implemented with

other paradigms presented in (Carzaniga et al.,

1997). Especially, some of our use cases could be

implemented with Client-Server paradigm so that

most of the logic is moved to server and only the

user interface is in browser. We believe that our

approach is more suitable for cases where:

 local execution gives additional value because of

access to local resources, responsiveness

requirements or cost or quality issues in network

quality, and

 the original source location of application cannot

be used as a host for execution, e.g., for

commercial or privacy reasons.

In addition, the agents can visit several servers

and browser clients during its execution. This

enables the use cases that typically require

specialized agent platform.

The rest of this paper has been organized as

follows. Section 2 describes the proposed archi-

tecture, and a number of use cases that can be

associated with our approach. Section 3 introduces

our proof-of-concept implementation of the frame-

work, and Section 4 discusses some example

applications. Section 5 discusses related work, and

pinpoints unique features of our approach. Section 6

provides a discussion on the lessons we have learned

in the development process and potential ideas for

future work. Towards the end of the paper, Section 7

draws some final conclusions.

2 ARCHITECTURE AND USE

CASES

In the following, we address two principal elements

of our work. First, we discuss how we have realized

the system at the level of principal design, and then,

we provide some use cases that can be implemented

with our system. We place the focus on conceptual

level, and do not yet go to concrete technical details

of the system, which will be addressed later on in the

paper.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

2.1 Architecture

In the proposed system, an HTML5 agent can run in

two modes:

1. With a user interface inside a client runtime

engine, i.e. the browser.

2. In a headless mode, i.e. without a user interface,

in an application server that we call agent server

in this paper.

The agent can move between these modes and

locations when the browser pulls the agent from a

server and when the browser pushes the agent back

to a server. Furthermore, we support multi-device

usage – the browser instance that pulls an executing

agent can be different from the browser instance that

had originally pushed the agent to the server.

Therefore, during its life-cycle the agent may visit

several browsers and several agent servers. An

example life cycle is presented in Figure 1.

Figure 1: Life-cycle of HTML5 agent.

In Figure 1, agent is started by Browser1, when the

agent is downloaded from its origin server (Step 1).

In this phase the agent is initialized and the

execution begins. Since the agent executes in a

browser it has a user interface. In Step 2, the agent is

pushed to an agent server. This means that the agent

server gets the internal execution state of the agent

and the application code (actually a URL to the

code). The agent can continue the execution in the

server. In Steps 3-5, the agent moves from one

environment to other but preserves its internal state

and continues execution. Finally, the execution is

terminated in Step 6. Note that in life cycle shown in

Figure 1, as well as in our experimental

implementation, too, the agent always moves

between server and client. However, it would be

trivial to make the agent to move at least between

servers.

It should also be noted that not all applications

need to execute in the server, but execution resumes

when the agent migrates to (some) browser again.

For example, in the media player scenario presented

in (Yu et al., 2006) playing should be resumed when

agent is in the browser again. However, for some

systems, headless mode may provide important

functions that are essential for satisfying certain

types of requirements. In case of monitoring

applications, for instance, certain events might

trigger moving the application back to the client so

that the user can take appropriate actions. Naturally,

this would require presence of some push

notification technology.

Internal state of the application is an important

part of a mobile agent. The state needs to be

serialized, transferred and de-serialized in the new

location. It is obvious that without modifying the

implementations of the browser the complete state of

the application cannot be serialized, and the agent

needs to be written so that serialization of the

relevant components of the state is possible. Our

design provides support for such serialization of the

important parts of the state.

In our current implementation a single agent

instance moves from host to host, but it would be

trivial to change the behaviour so that a new copy is

created when needed. For instance when a browser

fetches the agent from the agent server, a new copy

could be created and the original application could

also continue its execution in the agent server. We

believe that this can be performed with configuration

options included in the framework, but this remains

a piece of future work as discussed towards the end

of the paper.

Since the agent can run both with and without

UI, the architecture has to be designed to separate UI

from execution. HTML5 provides a good ground for

this separation. Similarly to most HTML5

applications, HTML5 agents are composed of two

major parts:

1. Declarative description of the user interface in a

form of HTML, CSS and image files.

2. JavaScript-files describing the executable code.

As is common in today’s web applications, the

HTML-file includes references to Cascading Style

Sheets (CSS), images and other resources, and

JavaScript files.

When the HTML5 agent is running in the agent

server, it runs in the headless mode and the HTML

and CSS files are not needed. Only the virtual

machine executing JavaScript is needed for the

execution of the agent. Naturally, whenever the

agent moves to a browser HTML and CSS files need

to be available again. Therefore, the agents need to

preserve at least URLs of the UI components of the

agent. Also the JavaScript code of the agents has to

HTML5Agents-MobileAgentsfortheWeb

be written in such a way that it can be executed

without presence of the Document Object Model

(DOM) tree, the data structure that is used as an

internal presentation of a web page inside the

browser. (W3C, 2005) We provide a simple browser

emulation system that supports running of browser-

based applications in a server, but still certain coding

rules need to be followed.

The execution model of the application also

needs to be suitable for our approach. First of all it

needs to be suitable for running in the browser, for

instance it should not block the event loop of the

browser run-time. On the other hand it needs to

execute without UI events delivered by the browser.

Furthermore, the agent needs to have safe points in

execution in which the internal state can be

serialized in consistent state. In practice this means

that all the application logic has to be embedded in

the event handlers and in addition to handlers for UI

events there is a handler for timer events that are

generated by our framework.

If the only requirement is that the application and

its internal state are stored to an agent server but the

application does not need to execute there, there are

fewer constraints for the design. The application

state must be serialized, but support for the agent

execution model – timer-based events – is not

needed.

2.2 Use Cases

Our system targets two kinds of use cases:

traditional use cases of mobile agents and long-

lasting sessions in web applications that are used in

multi-device environment.

We fundamentally agree with (Lange and

Oshima, 1999) and assume no single killer

application for mobile agents, but several

applications can benefit from mobile agent

technology. From the example application areas

presented in (Lange and Oshima, 1999) the

following would at least benefit from our solution:

 e-Commerce. If the product a user wants is not

immediately available, or if the pricing is not

satisfactory, the user can set her constraints and then

send the e-commerce application to the agent server

for execution.

 Personal Assistance. The example given in (Lange

and Oshima, 1999) ”to schedule a meeting with

several other people, a user can send a mobile

agent to interact with the agents representing each of

the people invited to the meeting. The agents

negotiate and establish a meeting time.” would be

good use case for us, too.

 Secure Brokering. The agent server could be a

mutually trusted host that enables collaboration

between the agents.

 Workflow Applications. The workflow application

can be a web application that is executed both in a

server and in browsers of several users.

Among web applications all applications that

should execute continuously but the user would still

like to have a break or just switch to another device

are potential use cases of our HTML5 agents. With

normal web applications the application state is lost

when user switches from one device to another.

Our solution allows users to continue their work

in another device. The novel idea presented in this

paper is that the execution of the application can also

continue while user is not using it through any

device. This is beneficial for instance, in the

following cases:

 monitoring applications that collect data about

events or values of various sensors,

 strategy games that should continue execution of

users instructions as robots when user is not

present, and

 applications whose execution takes a lot of time or

need to access big server-side resources are better

executed in the agent server.

Many of these applications can also be

implemented as server-side applications that users

access with a browser. However, the server-side

applications are typically bound to a specific service

and configurability for individual users is limited.

Some applications would also like to access

resources in the client device and thus the execution

should take place in the client device. Finally, the

ability to move computational agents between

clients and servers adds an extra layer of flexibility.

3 PROOF-OF-CONCEPT

IMPLEMENTATION

To test and validate our idea we have created an

experimental implementation of the agent

architecture. The server side of the implementation

is based on Node.js technology (Nodejs, n.d.), which

is a platform for the development of scalable

network applications using JavaScript (Taivalsaari

and Systä, 2012). Thanks to Node.js we can execute

the same JavaScript code both in server and in

browser.

The implementation consists of three main

components: 1) agent framework that acts as a

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

superclass for the agent applications, 2) execution

context in the server-side including an emulation of

the browser environment, 3) serialization format and

transfer protocol for application state and

information. More detailed explanations of these

components are given in the following.

3.1 The Agent Framework

The execution model is event-based which is normal

in browsers and Node.js server. To support

execution of possible computing tasks of the agent, a

periodic timer calls an application-specific work-

function on regular intervals.

As explained earlier, the complete internal state

cannot be stored and migrated by the system and

also in this experimental system the application need

to explicitly define state information that should be

serialized and delivered when the agent moves from

a location to another. In practice, the agents have

variable list that contains the state that has been

saved and transferred.

The superclass Agent is implemented by using

the functional inheritance pattern presented in

(Crockford, 2008). In this inheritance pattern the

super class defines the set of methods as follows:

function Agent(src,html) {

var that = {};

that.method1 = function(args) {…}

that.method2 = function(args) {…}

return that;

}

This Agent class is not to be instantiated, but each

concrete agent application inherits from Agent as

follows:

function MyAgent(src,html) {

var that = Agent(src,html);

/* new and overridden methods */

}

In our design, the class Agent offers the following

utility methods:

 createVar(name,value) creates a new variable

to the variable list, i.e. extends the state of the

agent.



setVal (name,value) sets a value of a

variable in the state of the agent.



getVal(name) – gets value of a variable in the

state of the agent.



setWork(function, interval) – sets the

function that is periodically executed with the

given interval.



setRunInterval(interval) – changes the

interval between executions.



start() and stop() – starts/resumes and stops

execution of the agent. In practice, the timer is

started and stopped.



serialize() – returns a JSON-string that

includes all necessary information to preserve the

state and continue execution of the agent in a new

location. This method is for the framework and is

not usually called from application code.

The application-specific sub-class of the Agent can

override the following methods:

 Method getRunningStatus() – should return a

string that the management interface of the agent

server context can show.

 Function

continueWork() – re-initializes the

execution when the agent has arrived and de-

serialized in a new location and the execution

should be resumed. This function initializes the

state of the agent by recreating the variables.

In addition, the agent has to provide a function

that creates and initializes the agent object.

3.2 Managing Execution Context

in the Server Side

As hinted earlier we have implemented a simple

HTTP server with Node.js. This server receives

description of the agent, i.e., the location of

executable JavaScript file(s) and state information,

in an HTTP-POST request. Then, the following

steps are performed:

 The executable JavaScript file is downloaded from

the origin server.

 The required run-time structures are created.

 The function

continueWork() of the down-

loaded agent is called.

 A timer to periodically fire the work-function is

initialized.

The application code of web applications

typically assumes existence of a DOM tree created

from the HTML. For the headless mode we have a

minimal browser emulation layer for applications

that refer to HTML document. The design principle

is to provide as minimal emulation as possible and

require applications to adapt, too. For example,

some of our example applications draw graphics

through Canvas API (W3C, 2004). The application

code should check if Canvas API is available, in

HTML5Agents-MobileAgentsfortheWeb

accordance to the following snippet of code:

var ctx = comp.getContext("2d");

if (ctx != null) {

that.draw(…);

}

This would actually be a good coding practice

for all web applications since

getContext() could

return null in browsers, too. Our emulation

implementation of

getContext() is simply the

following:

this.getContext = function () {

return null;

}

In addition, our browser emulation framework

includes implementation of standard JavaScript

function

getElementById(id) that always returns

a new object that carries the given id and

implements our emulation interface. We also have

toString() that is mainly used for debugging

purposes.

In order to use the same API for network

configuration, we have installed an implementation

of XMLHttpRequest (W3C, 2013) module to our

Node.js server.

3.3 Serialization Format and Transfer

Protocol

In our design, the browser can receive the agent in

two alternative ways:

1. by fetching the HTML-files of the application

from the origin server, or

2. by fetching an agent description from agent

server.

In contrast, the agent server gets the agent by

3. receiving an agent description in a HTTP

POST message.

In cases 2 and 3 information about the agent and

its internal state is encapsulated in an agent

description that is a JSON document containing the

following information:

 auri: a URL that points to the JavaScript file of the

application. The agent runtime, in the new

execution location, needs to download the JavaScript

file from this URL.

 huri: a URL pointing to HTML file, i.e., UI of the

application. The HTML file then refers to required

CSS and image files.

 id: unique ID of the agent instance.

 variables: local state in terms of names and values

of local variables.

The utility method serialize() of class Agent

creates this agent description. When the agent server

receives a request to pull an agent (Step 3 in Figure

1) the agent server calls method

serialize() of

running agent and includes the result in the response.

When client browser wants to push agent to the

agent server, it also calls this method and embeds

the result to the HTTP POST request that send the

agent to the server.

For optimization reasons, when the application is

fetched from agent server, the content of the HTML

file is attached to the agent description.

The implementation of our agent system requires

the browser to fetch content from several origins. To

enable this we have used the Cross-Origin Resource

Sharing (CORS) (W3C, 2013) technology to allow

use of several origins.

4 EXAMPLE APPLICATIONS

We have experimented and tested the framework

with some test applications. The example

applications have been used to further develop and

validate different aspects of our agent framework.

Monitoring. Our first example application was a

simple monitoring application that tracks the CPU

load of a server machine. While implementing this

application we also made most of our current design

decisions. When this agent is run in a browser, the

application shows current load level, minimum and

maximum values, and latest history graphically.

When this application is run in a server, the

information is still collected so that a non-

interrupted sequence of data can be shown when the

agent has migrated back to a browser. This

application was tested both on PC browsers and on a

smartphone.

Image Analysis. We also wanted to test the

framework with an application that contains long-

lasting computation and user would like to push the

computation to the server after seeing that it has

been started correctly. As a concrete example we

selected an image analysis application that can

compute characteristics of images both in browser

and server. With this application we investigated

issues with large amounts of data, and the main

learning is that the future agents should have

pointers in the resources in the Internet instead of

carrying the data in the state of the agent.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies

On-line query applications. We assume that

many applications of our HTML5 agents collect

information for the user. The motivation could be e-

commerce or just to get information when it

becomes available. To experiment with this

application area we have implemented an agent that

lets users to follow an on-line artist community - in

our case DeviantArt (Deviant art, n.d) for new

content from favourite artists or by selected

keywords. With this application we also

experimented with a computation that had behave

slightly differently in browser and server because the

source of RSS feed provides different format and

content for different clients.

While the above applications demonstrate the

main capabilities of the present implementation, we

will continue development of new applications when

new and improved capabilities are introduced. Some

of these ideas are discussed in Section 6 of this

paper.

5 RELATED WORK

As already pointed out, our agents comply with

commonly used definitions such as “Mobile agents

are programs that can migrate from host to host in a

network, at times and to places of their own

choosing. The state of the running program is saved,

transported to the new host, and re stored, allowing

the program to continue where it left off”

(Kotz and Gray, 1999) or “Mobile agents are self-

contained and identifiable computer programs that

can move autonomously within the network and act

on behalf of the user or other entities. A mobile

agent can execute at a host for a while, halt

execution, dispatch itself to another host, and

resume execution there”. (Yu et al., 2006)

A survey of mobile agent technologies has been

given in (Gupta and Kansal, 2011), but the

discussion is limited to traditional mobile agents. In

this paper we propose a new approach in which

HTML5 - a standard feature of a browser - and the

emulation in application server constitute the agent

platform.

Benefits and application areas of mobile agents

have been discussed in (Lange and Oshima, 1999).

From the motivations presented in (Lange and

Oshima, 1999), at least reduction of network load

and latency, asynchronous and anonymous

execution are valid for HTML5 agents, too. Also

many of the presented application areas are common

to HTML5 agents.

An agent platform hosted in browsers has been

presented in (Feldman, 2007). This work has

common targets with ours; it allows agents to be

executed both in server and browser. In (Feldman,

2007) mobile agent platform is based on concepts of

Pneuna that is relatively close to our agent

description and Soma that is the execution

environment. In the approach proposed in (Feldman,

2007) Soma hides the differences of browser and

server environment and creates a completely new

application platform for mobile agents. In our

approach standard and well-known HTML5 is the

agent/application platform. In addition the approach

presented in (Feldman, 2007) has not been designed

for pushing agents to agent server when user or

browser is not active or when the agent should find a

new browser to run on.

The basic idea presented in (Yu et al., 2006) is

somewhat similar to our approach, but they do not

use HTML5 as the application platform. For

example, their media player example would fit

nicely to our approach, too, especially if HTML5

media API would be used to implement the player.

A particularly interesting aspect in (Yu et al., 2006)

is self-adaptation and context awareness – in

practice different UI to different devices. It would be

interesting to implement similar behaviour using

web technologies.

The relation between trends in the Internet and in

mobile agents has also been discussed in (Kotz and

Gray, 1999). The paper discusses these trends and

forecasts that “within a few years, nearly all major

Internet sites will be capable of hosting and willing

to host some form of mobile code or mobile agents.”

This paper has also interesting discussions about

technical and non-technical hurdles of mobile

agents. From the presented technical hurdles using

HTML5 overcomes “standardization and

portability” and to limited extent also “security”.

From the non-technical hurdles our approach solves

“Getting ahead of the evolutionary path” because we

use the de-facto HTML5 technology, and “Revenue

and image” has effectively been eliminated by the

evolution of the Internet and its business models.

6 FUTURE WORK

We are still in initial phase of our work and have

only tested our approach with a limited number of

applications. Although we have proven that the

approach works with these applications, we

anticipate a need to improve the architecture so that

development of new agents becomes easier. We

need to develop new applications and collect

HTML5Agents-MobileAgentsfortheWeb

feedback from other developers. For example, our

browser emulation interface for the server side is

still incomplete, and it has only been tested with

very a limited set of test applications. Therefore new

features must and have been added to the system as

new applications are implemented.

Context awareness, as in (Yu et al., 2006) should

also be added, and we should work more with

different types of devices. In particular context

awareness should be complemented with

mechanisms for self-adaptation, which would

provide extra flexibility in some use cases.

Security is an obvious concern for all

dynamically moving code. In the current system we

rely on standard security mechanisms of HTML5

applications in browser. However, if the agents need

to execute sensitive tasks in the server or agents of

several users should collaborate in the server, we

need to develop additional security mechanisms that

are missing from today’s Web.

In our current example a single instance of an

agent migrates between hosts. Extensions to

multiplying agents should be experimented with and

we should develop configuration techniques for

when to move applications and when to multiply

them.

Finally, exploring agents that are able to

autonomously extend their behaviour in accordance

to the needs of the application is one of the

directions we have been considering. Building on

the immense flexibility of the Web and web

applications, this would be a step towards mashware

where components offered as a service form the

basis for constructing applications (Mikkonen and

Salminen, 2012).

7 CONCLUSIONS

Recent development of web technologies is rapidly

gearing the Web towards a role where it offers more

and more facilities that have been commonly

associated with traditional operating systems and

binary applications.

In this paper, we have shown that HTML5

technology can be used to implement mobile agents

and that use of agent approach can improve the user

experience especially in multi-device scenario. In

addition, we introduced a proof-of-concept

implementation that is able to run simple

applications. While as future work, we list a number

of ideas that will improve the capabilities of the

system; we believe that the present implementation

validates the feasibility of the fundamental design.

REFERENCES

Carzaniga, A., Picco, G., P., Vigna, G., 1997. Designing

distributed applications with mobile code paradigms.

In Proceeding of the 19th international conference on

Software engineering (ICSE’97), May 17-23, 1997,

Boston, Massachusetts, USA pp 22-32.

Crockford, D., 2008. JavaScript: the Good Parts, O'Reilly

Media, Inc. May 8, 2008.

DeviantArt n.d., home page. http://www.deviantart.com/,

Last viewed 3.2.2013.

Feldman, M., 2007. An approach for using the Web as a

Mobile Agent infrastructure, In proceedings of the

International Multiconference on Computer Science

and Information Technology, pp. 39 – 45, 2007.

Gupta, R., Kansal, G., 2011. A Survey on Comparative

Study of Mobile Agent Platforms. In International

Journal of Engineering Science and Technology

(IJEST), 3(3): 1943 – 1948.

Kotz K., and Gray, R., S., 1999. Mobile Agents and the

Future of the Internet, In SIGOPS Oper. Syst. Rev.,

33(3):7–13, pp 7-13.

Lange, D., B., Oshima, M., 1999. Seven good reasons for

mobile agents, In Communications of the ACM,

Volume 42 Issue 3, March 1999, pp 88 – 89.

Mikkonen, T., Salminen, A., 2012. Implementing Mobile

Mashware Architecture: Downloadable Components

as On-Demand Services. Procedia Computer Science.

10, 2012, pp 553-560.

Nodejs, n.d., Web page for document and download of

nodejs technology, http://nodejs.org/. Last viewed

03.02.2013.

Taivalsaari, A., Mikkonen, T., Systä, K., 2013. Cloud

Browser: Enhancing the Web Browser with Cloud

Sessions and Downloadable User Interface", To

appear in the Proceedings of GPC 2013, Soul Korea,

9-11.5.2013, will be published as LNCS (Lecture

Notes in Computer Science).

Taivalsaari, A., Systä, K., 2012. Cloudberry: HTML5

Cloud Phone Platform for Mobile Devices. In IEEE

Software, July/August 2012, pp.30-35.

W3C, 2004. The Canvas 2D API 1.0 Specification. W3C

Editor's Draft. http://dev.w3.org/2006/canvas-

api/canvas-2d-api.html. Last viewed 04.02.2013.

W3C, 2005. Document Object Model (DOM).

http://www.w3.org/DOM/. Last viewed 04.02.2013.

W3C, 2013. Cross-Origin Resource Sharing. W3C

Candidate Recommendation 29 January 2013.

http://www.w3.org/TR/cors/. Last viewed 03.02.2013.

Yu, P. Cao, J., Wen W., Lu, J., 2006. Mobile Agent

Enabled Application Mobility for Pervasive

Computing, In Lecture Notes in Computer Science

Volume 4159, 2006, pp 648-657.

WEBIST2013-9thInternationalConferenceonWebInformationSystemsandTechnologies
