Video Segmentation by Event Detection: A Novel

One-class Classiﬁcation Approach

Mahesh Venkata Krishna, Paul Bodesheim and Joachim Denzler

Computer Vision Group, Friedrich Schiller University Jena, 07743 Jena, Germany

Abstract. Segmenting videos into meaningful image sequences of some partic-

ular activities is an interesting problem in computer vision. In this paper, a novel

algorithm is presented to achieve this semantic video segmentation. The goal is to

make the system work unsupervised and generic in terms of application scenar-

ios. The segmentation task is accomplished through event detection in a frame-

by-frame processing setup. For event detection, we use a one-class classiﬁcation

approach based on Gaussian processes, which has been proved to be successful

in object classiﬁcation. The algorithm is tested on videos from a publicly avail-

able change detection database and the results clearly show the suitability of our

approach for the task of video segmentation.

1 Introduction

A major goal of computer vision is to make computers do at least some of the vision-

based tasks that are currently tedious or difﬁcult for humans to perform. In many real-

world applications it is often the case that there is a large corpus/stream of videos with

interesting events sparsely spread over it. It then becomes an exhausting task to extract

interesting events from the huge amount of data. The aim of this work is to achieve this

interesting event extraction by segmenting the input video into various semantic phases.

Applications of this vary widely, e.g. in surveillance, most of the time nothing abnormal

happens but suddenly there is an important activity like breach of rules. In microscopic

videos recording microbial activities, interesting events happen sparsely over time and

it is a huge waste of manpower to keep it under constant observation. In such situations,

automated event extraction is a very important tool.

In addition, video segmentation gets us into important theoretical issues such as

what deﬁnes an interesting event and how can a machine guess by itself what an inter-

esting event may be. As deﬁnitions of events are application dependent, a generic def-

inition of an event can only be stated as : “Something that is not normal in the video”,

i.e. something novel. This leads us to the main contribution of this work: the application

of one-class classiﬁcation (OCC) algorithms to generic unsupervised video segmenta-

tion. In our approach, detecting temporal novelties in a video is a big step towards

video segmentation. To perform one-class classiﬁcation, we look among the various

approaches that have been proposed in the ﬁeld of object classiﬁcation. There exist var-

ious approaches based on one-class classiﬁcation techniques, such as Gaussian process

Venkata Krishna M., Bodesheim P. and Denzler J..

Video Segmentation by Event Detection: A Novel One-class Classiﬁcation Approach.

DOI: 10.5220/0004394100730081

In Proceedings of the 4th International Workshop on Image Mining. Theory and Applications (IMTA-4-2013), pages 73-81

ISBN: 978-989-8565-50-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

regression (GPR) [3], support vector data description (SVDD) [9], one-class SVM [8],

or Parzen density estimation [6]. One can clearly see that the OCC setup matches our

problem scenario: a model of normality (or known patterns) has to be built by clustering

in the feature space and novelty is declared in case an outlier is met in the testing phase.

We show in the following sections how one-class classiﬁcation techniques can be used

for video segmentation.

The remainder of this paper is organized as follows. First, in section 2, we review

related work in the ﬁeld of video segmentation. A brief discussion of their relative ad-

vantages and shortcomings is provided. In section 3, we review one of the most promi-

nent OCC techniques, namely Gaussian process regression. We then present our video

segmentation approach in section 4 together with the explanation how to use OCC tech-

niques for event detection in videos. The results on the thermal videos of the CVPR

change detection dataset [2] are presented in section 5 highlighting the suitability of

our approach. A summary of our ﬁndings and suggestions for future research directions

conclude the paper.

2 Previous Work

The work by Koprinksa and Carrato [4] provides a good survey of video segmentation

techniques based on a very diverse range of theoretical concepts and for various ap-

plications. Most of the algorithms presented there concentrate on directly ﬁnding the

differences between frames through some distance measure between feature vectors of

consecutive frames. A threshold is then applied to this distance to achieve a segmenta-

tion. This approach yields reasonable results but is based on directly ﬁnding inter-frame

differences without modeling the underlying scenario. Thus, they can not detect seman-

tic changes, e.g. approaches based on global color histograms may not detect events

such as a person bending or falling as it is not likely that there is a signiﬁcant change in

the color histogram.

Liu et al. [5] have presented an approach based on the perceived motion energy

feature, where optical ﬂow vectors in each frame are averaged and multiplied with a

factor arising out of the dominant direction of motion. These features are then clustered

to form segments of the video corpus. This method is very useful for videos containing

a lot of motion, but when events happen that do not alter the motion proﬁle of the frames

(e.g. color changes), it is likely to fail.

Therefore, we need a generic framework for video segmentation without assump-

tions of a speciﬁc application. The next section provides the theoretical aspects of our

proposed approach based on OCC.

3 One-class Classiﬁcation Techniques

In this section, we brieﬂy describe the idea behind OCC as well as one of the most

prominent techniques, i.e. the Gaussian process regression framework presented by [3].

3.1 The Task of One-class Classiﬁcation

In an OCC scenario, there are only training samples X =



(1)

, . . . , x

(N )



of a sin-

gle class available. Thus, all of them have the same constant label, e.g. y = 1 =

(1, 1, . . . , 1)

. This class is often referred to as target class and the corresponding sam-

ples as target data or target set [9]. The aim is to ﬁnd an appropriate description of the

class distribution to distinguish this single class from every other possible and currently

unknown class. Therefore, a novelty score should be inferred for each test sample x

∗

such that a large score indicates strong membership to the target class. If this score is

below a certain threshold, the test sample will be treated as an outlier not belonging to

the estimated distribution. The following methods allow for a suitable modeling with

samples that only stem from a single class.

3.2 Gaussian Process Regression

The Gaussian process framework is a well-known probabilistic methodology that is suc-

cessfully used for tasks such as regression and classiﬁcation [7]. In the case of Gaussian

process regression (GPR), outputs y(x) are assumed to be generated according to a la-

tent function f and a noise term ε:

y(x) = f (x) + ε . (1)

Following a Bayesian framework, output values of unknown samples x

∗

are predicted

probabilistically by marginalizing over both latent function values and noise. While

this is in most cases infeasible to realize exactly, a few assumptions make the prediction

tractable:

1. Latent functions f are drawn from a Gaussian process prior with zero mean, and

covariance function κ.

2. The noise term is assumed to be normally distributed: ε ∼ N (0, σ

Using these assumptions, the predictive distribution over output values is normally

distributed, i.e. y

∗

|X, y, x

∗

∼ N (µ

∗

, σ

∗

), where moments µ

∗

and σ

∗

can be computed

in closed form. The work of [3] shows how GPR can be used to solve OCC problems.

The authors propose using either the predictive mean µ

∗

(GPR-Mean) or negative vari-

ance −σ

∗

(GPR-Var) as novelty scores:

∗

= k

∗



K + σ



−1

1 and (2)

−σ

∗

= −



∗∗

− k

∗



K + σ



−1

∗

+ σ



, (3)

where K = κ (X, X) , k

∗

= κ (X, x

∗

) , k

∗∗

= κ (x

∗

, x

∗

), and I the unit matrix.

We have decided to choose the GPR approach, because it is shown by [3] that Gaus-

sian processes are superior to the SVDD approach of [9] in visual object categorization.

Since one-class SVM leads to equivalent results compared to SVDD [8], the GPR ap-

proach is our method of choice. Having this OCC technique on hand, we explain how

to use it for video segmentation in the next section.

4 Video Segmentation by Event Detection

In this section, we ﬁrst focus on our idea of using OCC methods for video segmentation.

Afterwards, we present the algorithm of our OCC approach. The last part of this section

is about the features we use to obtain proper video segmentation.

4.1 The Idea of our Approach

The goal of this work is to semantically segment videos into meaningful image se-

quences. To achieve such a partition, an approach similar to work ﬂow segmentation

can be used, where different phases of the video are marked based on their semantic

content. In each time step, we model the current situation with a OCC model and then

look for special events (novelties) in the consecutive frames.

Thus, in our approach we want to detect events that lead to a change of the current

phase. This is carried out by using OCC methods as explained in the following section.

In the end, we are able to evaluate the resulting segmentation of the whole sequence

which comes from the detected events.

4.2 Our One-class Classiﬁcation Approach

Let us assume that there are features available for each frame stored in a speciﬁc fea-

ture vector. The feature extraction methods will be explained in section 4.3. We start

with learning a one-class model (Sec. 3) using the features of the ﬁrst F frames of the

video. Here, we assume that there is no event within these ﬁrst frames and assign them

with phase count 1. In most real-life situations, a few frames in the order of 30 to 60

correspond to 2-3 seconds, where it is reasonable to assume that no interesting event

happens. For every consecutive frame, we evaluate the learned model to obtain its nov-

elty score. This is done until the score of a frame drops below a speciﬁed threshold T .

If this is the case, we have detected an event leading to a phase change.

Assuming that such events, which indicate a phase change, are sparsely spread over

time (i.e. do not happen closely, with a gap of at least F frames between them), we learn

a new one-class model with the features of the next F frames. The unlabeled previous

frames are assigned with the phase count of the old model and we update the phase

count of the current model. The video sequence is segmented this way, completely

unsupervised. An overview of our approach can be seen in Figure 1.

Note that our approach does not need a training step using manually labeled se-

quences to learn a suitable model. Moreover, it can be directly applied to any video

sequence since the model is learned on-the-ﬂy within the sequence that should be seg-

mented. We may only have to adjust the parameters F and T as well as method speciﬁc

parameters of the OCC model.

4.3 Features for each Frame

Due to the fact that we want to build a generic framework for video segmentation with-

out using speciﬁc knowledge about the target application scenarios and deﬁnition of

Fig. 1. Overview of our one-class classiﬁcation

approach for video segmentation.

Fig. 2. Example frames of the ﬁve se-

quences within the CVPR change de-

tection dataset: (a) corridor, (b) lake-

Side, (c) diningRoom, (d) library,

(e) park.

events, it is extremely challenging to choose a suitable feature set for the algorithm. For

the present implementation evaluated on the thermal surveillance videos, we use pyra-

midal histogram of oriented gradients (PHOG) as proposed in [1]. This is a very suit-

able feature because in surveillance sequences, events are deﬁned by entry of a person,

change in the normal movements of the people in the scene, etc., and PHOG features

are very efﬁcient at representing object shapes in the frame. In this feature representa-

tion, local features are represented as histograms of edge orientations. The number of

bins is a parameter of the feature descriptor. Each histogram bin represents the number

of edges orientated in a speciﬁc direction. To represent shapes of various sizes within a

frame, an image pyramid is built for the frame and histograms from each pyramid level

are concatenated. For more details, the reader is referred to [1].

5 Experiments

As generic semantic segmentation of video sequences is a new challenge in computer

vision, we are not aware of any existing dataset speciﬁcally intended for this purpose.

For this reason, the change detection dataset for the CVPR 2012 change detection work-

shop [2] is used to test our approach and to demonstrate its suitability. The thermal

images from this dataset have been used because they contain sequences with large

variance in object size and intensity contrast. Example frames of the dataset are shown

in Figure 2. The ground truth data provided with the dataset is oriented towards motion

detection and hence, we created our own ground truth for our application.

The data is in

the form of grayscale frames of size 320x240 pixels. There are ﬁve sequences, namely

corridor, diningRoom, lakeSide, library, and park. Each sequence contains different

kind of motion and different zoom levels such that the object sizes are very different.

5.1 Experimental Setup

The parameter F , i.e., the number of frames used for training the model, was ﬁxed at

50. Thus, the ﬁrst 50 frames are assumed not to have any special event. At the normal

rate of 25 frames per second, this means we are assuming constancy for only 2 seconds,

which is a very realistic and reasonable assumption. The threshold T was set to 0.175,

which was determined empirically on the dataset. Future work will include automatic

determination of even these two system parameters. Furthermore, 30 bins are used in

the PHOG descriptor for each histogram calculated over three levels.

5.2 Results on the CVPR Change Detection Dataset

In most of the published works including [5], the performance measures used are sub-

jective and do not lend themselves to comparison. The reason is that in problems like

video segmentation, it is very difﬁcult to deﬁne a good performance measure for the al-

gorithms. Hence, we concentrated on the fact that our algorithm works on the principle

of detecting events and use performance measures for event detection. To evaluate the

results of the algorithm qualitatively, we used the detection rate η:

η =

number of correct detections

number of events in ground truth

. (4)

It is often the case that the detection of the algorithm and the ground truth vary by

about 20-25 frames, because the algorithm makes hard decisions using a threshold and

ground truth is marked by human observers. This is not a serious problem, since in

real-life videos 25 frames corresponds to a time span of 1 second, in which generally

not many events happen. For most applications, this difference is not a major problem.

Additionally, over-segmentation is expected, because our algorithm works com-

pletely unsupervised. As the threshold is set without any prior knowledge about the

video and is thus completely independent of it, often very small and insigniﬁcant changes

in the video result in a new segment being reported. However, this is also not a cause

for alarm as this stage is usually intended to be followed by a higher processing stage

or a human observer in most applications. Thus, at the higher level, we can choose to

ignore these particular extra segments in a post-processing step. We represent the effect

of over-segmentation with the over-segmentation ratio γ:

γ =

number of false detections

number of events in ground truth

. (5)

Readers interested in obtaining the ground truth for their own further research or veriﬁcation

of our methods can contact the authors.

Table 1. Results on the thermal video subset of the CVPR Change Detection Dataset for F = 50

and T = 0.175 using detection rate η (4) and over-segmentation ratio γ (5)

Video η γ

corridor 0.68 0.31

diningRoom 0.81 0.45

lakeSide 0.17 0

library 1 2.78

park 0.83 0.5

This represents the average number of extra segments for every segment in the ground

truth. However, it should be noted that under-segmentation could be more costly and

hence needs to be reduced. Table 1 shows the results for each video in the dataset.

The results for the lakeSide video are evidently poor compared to other videos. It is

heavily under-segmented. This is due to the fact that the video has extremely low con-

trast and even for a human observer, it is very challenging to locate events. In addition,

the events and objects in the video are of very small dimensions. To detect events in

this scenario, one has to set the threshold extremely low, which would increase the false

detection rate in other generic cases. On the other hand, we see that the library video is

over-segmented. This can be solved by increasing the threshold (experiments revealed

that increasing the threshold to 0.25 in this case reduces false detection rate to 0.35,

while retaining the excellent detection rate).

Often, it is even desirable to have over-segmented videos, e.g. in the library video,

the detected extra events are basically the person under observation turning pages.

These are not labeled in the ground truth because they are minor events but could be

interesting for the application. In the diningRoom video, the extra events detected are

basically the person turning, which is an interesting change but again not labeled in the

ground truth.

Figures 3 and 4 show a timeline and an example frame segmentation on the library

video, and Figure 5 shows segmentation example frames for corridor video. To analyze

the effect of the parameter T on the overall performance, the η vs. γ curve is plotted for

the library and corridor videos in Figures 6 and 7. We have varied T from 0.15 to 0.20.

Larger values of the threshold result in an over-segmented video, i.e., high γ, whereas

smaller values result in under-segmented videos. An interesting point to note is that for

over-segmented videos, we obtain detection rates η often less than those with lower γ.

This is due to the training time F . Often, an event is detected when there is none (i.e.,

over-segmentation) and during the following training time, an event is missed.

The results are promising and there are strong indications that a video dependent

threshold determination will solve most of these existing issues.

6 Conclusions and Future Work

The work was aimed at segmenting the video sequences into activity phases, enabling us

to further process the smaller units and extract the interesting parts. We used a one-class

classiﬁcation approach based on Gaussian processes to do this with success as seen in

Fig. 3. Segmentation timeline for the library video (with T = 0.175 and F = 50), with the

ground truth (the shadings indicate the matched detections).

Fig. 4. Example segmentation on the library

video.

Fig. 5. Example segmentation on the corridor

video.

Fig. 6. Detection rate η vs. over-segmentation

ratio γ for the library video.

Fig. 7. Detection rate η vs. over-segmentation

ratio γ for the corridor video.

the previous section. The accuracy in event detection is quite impressive even with the

simple PHOG features used in this implementation. This demonstrates the possibility

of using one-class classiﬁcation schemes, such as the ones based on GPR, for the task

of video segmentation.

As noted earlier, the accuracy of the system can be further enhanced by intelligent

selection of parameters. Automated parameter optimization is one topic of future work.

This may yield better results because then the parameters will be dependent on the video

instead of being universal and it may avoid situations as the one encountered in the case

of the lakeSide video.

Furthermore, feature selection will be part of further research. The authors believe

that feature selection is of critical importance in this case and the use of more sophis-

ticated features could drastically improve the performance of the approach. To exploit

features representing shape and motion in a combined descriptor is a promising idea for

future work.

Acknowledgements

Mahesh Venkata Krishna is funded by a grant from the Carl Zeiss AG, through the

“Pro-Excellence” scholarship of the federal state of Thuringia, Germany. We thank Dr.

Stefan Saur and Dr. Christian Wojek for useful discussions and suggestions.

References

1. Bosch, A., Zisserman, A., and Munoz, X. (2007). Representing shape with a spatial pyramid

kernel. In Proceedings of the 6th ACM international conference on Image and video retrieval

(CIVR’07), pages 401–408, New York, NY, USA. ACM.

2. Goyette, N., Jodoin, P.-M., Porikli, F., Konrad, J., and Ishwar, P. (2012). changedetection.net:

A new change detection benchmark dataset. In Proceedings of the IEEE Workshop on Change

Detection (CDW’12) at CVPR’12.

3. Kemmler, M., Rodner, E., and Denzler, J. (2010). One-class classiﬁcation with gaussian

processes. In Proceedings of the Asian Conference on Computer Vision (ACCV’10), pages

489–500.

4. Koprinska, I. and Carrato, S. (2001). Temporal video segmentation: A survey. Signal Pro-

cessing: Image Communication, 16(5):477 – 500.

5. Liu, T., Zhang, H.-J., and Qi, F. (2003). A novel video key-frame-extraction algorithm based

on perceived motion energy model. IEEE Transactions on Circuits and Systems for Video

Technology, 13(10):1006 – 1013.

6. Parzen, E. (1962). On estimation of a probability density function and mode. The Annals of

Mathematical Statistics, 33(3):1065–1076.

7. Rasmussen, C. E. and Williams, C. K. I. (2006). Gaussian Processes for Machine Learning.

The MIT Press.

8. Sch

olkopf, B., Platt, J. C., Shawe-Taylor, J., Smola, A. J., and Williamson, R. C. (2001).

Estimating the support of a high-dimensional distribution. Neural Computation, 13(7):1443–

1471.

9. Tax, D. M. J. and Duin, R. P. W. (2004). Support vector data description. Machine Learning,

54(1):45–66.
