Exploring the Gender Effect on Cognitive Processes in Program

Debugging based on Eye-movement Analysis

Ting-Yun Hou

, Yu-Tzu Lin

, Yu-Chih Lin

, Chia-Hu Chang

and Miao-Hsuan Yen

Graduate Institute of Information and Computer Education, National Taiwan Normal University,

No.162, Sec. 1, Heping E. Rd., Da-an Dist., Taipei City 10610, Taiwan

Department of Biomedical Engineering, Yuanpei University, No.306, Yuanpei St., HsinChu, Taiwan 30015, Taiwan

Graduate Institute of Networking and Multimedia, National Taiwan University, Taipei City, Taiwan

Graduate Institute of Science Education, National Taiwan Normal University, Taipei City, Taiwan

Keywords: Computer Programming, Eye Tracking, Cognition Process, Program Debugging, Sequential Analysis.

Abstract: This study addresses the gender differences of cognitive processes involved in program debugging. In the

experiment, twenty-five participants were asked to find bugs in the test programs. Eye-movement analysis

was employed to track the students’ gaze paths while they traced and tried to debug the programs. Cognitive

processes were then obtained by employing sequential analysis of gaze data to investigate the significant

sequences of attention areas. Cognitive processes of different genders were investigated by comparing the

tracing sequences of program debugging. The experimental results show that both genders had limited

working memory capacities for debugging the iterative program with complex computation. But females

needed more manual calculation for the recursive program in this study. For the iterative structure, females

tended to grasp the program requirements and then trace into the major part of the program, while males

traced the change of output value according to the logic of the iterative statements. For the recursive

problem, females traced the flow of recursive induction and the stop condition to execute the program and

find bugs, while males traced the recursive function in a more leaping way. This study leaks the gender

differences of cognitive processes in program debugging, based on which instructors/researchers can

develop adaptive computer programming instruction for students of different genders.

1 INTRODUCTION

Many instructors/researchers investigated how to

effectively and efficiently develop students

programming skills. However, it is still challenging

in the field of computer science education (Costelloe,

2004). The most challenging thing for novice

programmers is to locate and resolve bugs (Lahtinen

et al., 2005). Novices usually felt frustrated when

they had to find bugs because their knowledge about

programming was fragile (Perkins and Martin, 1986).

Some research discussed programmers’ debugging

behaviors and found that novice programmers debug

programs in a trial-and-error manner without

comprehending programs so that they usually cannot

resolve errors successfully (Fitzgerald, et al., 2008).

Thus, investigating factors of students’ cognitive

processes in debugging programs is one of critical

keys to improve their programming skills. However,

cognition is a very complex process. Traditional

research on cognition often conducted interviews

and paper tests (Chen et al., 2010), but the results of

these methods might be affected by missing memory,

the exactitude of introspection, and unconscious

social desirability. More than 80% of cognitive

processes are obtained through vision (Sanders and

McCormick, 1987). Eye movements are not smooth

and individuals do not gaze on just one point of a

visual field; they switch between fixation and

saccadic eye movements in a very short space of

time. Such complex brain activities underlie the

concept of cognition. Through the process of

eye-tracking, it is possible to obtain data regarding

the amount and moment of eye fixation, saccade,

gaze duration, regression, skipping, and refixation in

an area of interest (AOI), which in turn can help us

understand the cognitive processes occurring

simultaneously. Eye movements detected by

eye-trackers can provide much information

regarding visual cognitive processes (Just and

469

Hou T., Lin Y., Lin Y., Chang C. and Yen M..

Exploring the Gender Effect on Cognitive Processes in Program Debugging based on Eye-movement Analysis.

DOI: 10.5220/0004415104690473

In Proceedings of the 5th International Conference on Computer Supported Education (CSEDU-2013), pages 469-473

ISBN: 978-989-8565-53-2

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Carpenter, 1984) and has been used to investigate

creativity, learning, reading, teaching, affection, and

problem solving. In a previous study, researchers

applied eye-tracking to capture visual attention

strategies and to conduct a detailed account of visual

attention during a debugging task (Bednarik, 2011).

Another study by Bednarik et. al. (Bednarik, Myller,

Sutinen, and Tukiainen, 2006) reported that gaze can

reflect the thinking mode of a subject, represent their

interest level, and the importance of each visualized

area. However, they did not find any correspondence

between program debugging and the mental model

used.

In this study, we investigated the gender effects

on the cognitive processes of program debugging,

which can give suggestions to instructors for design

adaptive instructional strategies for different

genders.

2 METHODOLOGY

2.1 Participants

The participants were twenty-five subjects (13 males,

12 females) of the Department of Computer Science

in a university in North Taiwan. They studied

programming in C for at least one year. None of the

subjects had major psychological or psychiatric

disorders that may affect the experimental results.

2.2 Procedure

The C language was utilized in this study.

Participants were provided with 2 100-lines C

programs (one was the iterative structure and the

other was the recursive structure), each had three

semantic or syntactic bugs. The time limit for each

problem was 10 min. The subjects had to try to find

all bugs by watching the source codes without using

program development software. After they finished

debugging the codes, they then had to explain the

logic and the purpose of the programs in an

interview in order to assess whether they understood

the programs successfully had to try to find all bugs

by watching the source codes without using program

development software. After they finished

debugging the codes, they then had to explain the

logic and the purpose of the programs in an

interview in order to assess whether they understood

the programs successfully.

2.3 Data Collected

The Eyelink 1000 eye-tracker was employed to

record participants’ program debugging paths. The

viewing distance was approximately 86 cm and the

screen resolution was 1024 × 768. The gaze data

was at first down sampled to obtain quantized gaze

sequences. Sequential analysis (Bakeman, 1986) was

then further employed for data interpretation and

simplification. This algorithm can analyze how a set

of complex probabilities behaved when it is applied

repeatedly over time based on Maximum likelihood

estimation. After sequential analysis, students’

cognitive processes could be extracted.

Figure 1: System overview.

The whole experimental procedure, including the

interview was recorded with a video camera to avoid

loss of information. We also provided the subjects

with the function of free drawing on the screen so

that they could write down their thoughts or

computational processes. The Region of Interest

(ROI) was decided according to the logic of the

program, e.g., variable definitions, I/O statements,

conditional statements, function calls, computations

in the function, and the note area. Figure 2 presents

an example of a test program and the corresponding

ROIs (each ROI was labeled with a block).

Figure 2: One example of ROIs.

CSEDU2013-5thInternationalConferenceonComputerSupportedEducation

470

3 RESULTS AND DISCUSSION

3.1 The Iterative Problem

The experiment results for the iterative program, as

illustrated in Tables 1, show that when debugging

the iterative program, both males and females had

the significant sequence of

 Note area→Note area

This implies that both genders could not manipulate

computations completely mentally while tracing the

program and needed the note area to assist program

tracing. The reason might be that their working

memory capacities were not enough to trace the

program because mental arithmetic is constrained by

working memory (Adams and Hitch, 1997;

Mackintosh and Bennett, 2003). Female students

had the following additional sequences:

 Variable definition→I/O statement

 I/O statement→I/O statement

 I/O statement→Inner loop condition

That is, females paid much attention to the basic

definitions and program requirements, which are the

major step to comprehend the program (Chen, 2007).

Males had the additional sequences:

 Computation in the conditional statement →

Variable definition→Conditional statements for

the output value

 Output→Output

They spend more time tracing the value changes

according to the logic of the iterative statements of

the loop. Previous research (Marzieh, Dave, & Colin,

2007) argued that the most common mistakes made

by novice programmers occur in the loop statements.

Therefore, male participants in this experiment also

considered the bugs might occur in the loop.

3.2 The Recursive Problem

In the experiment of the recursive program, females

had the significant sequences (as presented in Table

2):

 Recursive function name→Variable definition

in the recursive function → Conditional

statements in the recursive function

 Conditional statements in the recursive function

→ Conditional statements in the recursive

function

 Computation in the recursive function →

Computation in the recursive function →

Recursive call

 Note area→Note area

The results show that females often found bugs in

recursive statements and followed the recursive

logic, which compiles with Sabah’s research (2012)

indicating that students have to trace the flow of

recursive induction and the stop condition to execute

the program and find bugs. However, males tended

to confirm the program requirements at first by

seeing the I/O statements. Their significant

sequences were:

 I/O statement→I/O statement

 Return value of the recursive function →

Computation in the recursive function

 Recursive function name→Variable definition

in the recursive function

Table 1: Results of the sequential analysis for the iterative program debugging.

Va ri able

definition

I/O statement

Outer loop

condition

Inner loop

Condition

Computation in

the conditional

statement

Conditional

statements for

the output

value

Output Note area

F M F M F M F M F M F M F M F M

Va ri able

definition

1.84 -0.59

2.54*

-0.5 -0.6 0.54 0.99 1.56 0.07 -1.35 0.11

2.88*

-0.68 -0.3 -0.84 0.17

I/O statement 0.52 0.28

2.57*

1.87 0.17 -1.79

3.13*

1.37 1.29 -0.24 -1.36 -0.65 0.02 -0.17 -2.73 -0.52

Outer loop

condition

0.15 -1.17 -0.35 -1 0.6 1.51 1.96 1.66 1.03 0.64 -0.4 0.84 -0.11 -1.47 -0.39 -0.21

Inner loop

Condition

-0.29 -0.64 1.33 0.7 1.96 -0.18 1.89 1.82 0.98 0.34 -0.73 -0.32 -0.18 0.24 -1.81 -1.22

Computation in

the conditional

statement

-0.52

2.36*

-1.2 -0.24 0.11 0.64 0.19 -0.3 0.13 -0.87 -0.9 -0.81 1.71 -0.43 -0.17 0.24

Conditional

statements for

the output

value

-0.95 -0.81 0.12 -0.65 -0.4 -0.4 -0.73 -0.85 -0.25 -0.27 0.3 3.32 1.9 1.5 0.6 -0.49

Output 1.48 -0.3 0.52 -0.57 -1.24 -1.03 -1.14 -1.25 -1.39 1.08 1.11 1.5 0.83 2.5* -0.96 -0.72

Note area -1.37 -0.92 -1.99 0.49 -1.21 -0.21 -1.81 -0.29 -0.83 -0.23

2.35*

-1.28 0.24 -0.72

3.56* 2.03*

*p < 0.05.

ExploringtheGenderEffectonCognitiveProcessesinProgramDebuggingbasedonEye-movementAnalysis

471

Table 2: Results of the sequential analysis for the recursive program debugging.

I/O statement

Recursive

function name

Va ri a ble

definition in the

recursive

function

Conditional

statements in

the recursive

function

Computation in

the recursive

function

Recursive call

Return value of

the recursive

Note area

F M F M F M F M F M F M F M F M

I/O statement

-0.75 2.2* -0.66 1.19 0 -1.39 0.85 -1.88 0.31 -0.27 -0.15 -1.26 0.66 0.46 -0.42 -0.59

Recursive

function name

-0.66 -0.43 -0.59 -0.52 2.5* 2.72* 0.46 -0.94 -0.23 -0.42 -0.96 0.2 -0.64 -0.83 -1.1 -1.4

Va ri a ble

definition in the

recursive

function

1 -0.66 0.24 -0.06 -0.59 -1 2.06* 1.03 0.68 1.03 -1.45 1.25 -0.97 -0.93 -1.05 -1.57

Conditional

statements in

the recursive

function

-1.36 -0.27 0.46 -0.42 0.39 2.41* 2.85* 0.43 0.32 0.43 0.61 0.51 -1.31 1.12 -1.8 -1.17

Computation in

the recursive

function

-1.27 -1.88 -1.12 -0.42 1.86 0.56 -1.43 1.45 2.08* 0.77 2.58* 0.51 -0.4 1.12 -0.17 -1.17

Recursive call

1.71 -1.26 1.14 -1.32 -0.75 -0.8 -0.94 1.02 0.93 1.02 1.68 -0.6 -0.08 0.33 -1.78 -0.02

Return value of

the recursive

function

-0.72 0.46 -0.64 -0.83 -0.97 -0.93 -1.31 1.12 -1.22 2.71* 1.85 -0.85 -0.7 -0.54 2.18* -0.9

Note area

`0.39 1.67 -1.1 -0.68 -1.05 -1.57 -1.35 -0.22 -1.62 -1.17 -0.65 -0.02 3.87* 0.21 2.91* 0.49

*p < 0.05.

 Conditional statements in the recursive function

→Variable definition in the recursive function

Males seemed to trace the recursive function in a

leaping manner and did not pay equivalent attention

to all recursive components. They traced the value

changes according to the conditional statements and

variable definitions in the recursive function. In

addition, they did not use the note area as often as

females did. It seems that males did not feel the

limitation of their working memory for solving this

recursive program.

4 CONCLUSIONS

This study addresses the gender effects on cognitive

processes involved in computer program debugging

based on eye-movement analysis. The naïve gaze

data was analyzed by sequential analysis to find the

sequences of cognition. The findings show that both

genders had limited working memory capacities for

debugging the iterative program with complex

computation. But females needed more manual

calculation for the recursive program in this study.

For the iterative structure, females tended to grasp

the program requirements and then trace into the

major part of the program, while males traced the

change of output value according to the logic of the

iterative statements. For the recursive problem,

females traced the program based on the recursive

logic to find bugs, while males traced the recursive

function in a more leaping way. The evidence of

gender differences in cognitive processes of program

debugging

can help understand more about cognition

of programming and design suitable programming

instruction for different genders.

ACKNOWLEDGEMENTS

This work was partially supported by the National

Science Council and the Ministry of Education of

China under contact no. NSC 101-2511-S-003 -037.

REFERENCES

Adams J. W. and Hitch G. J., Working memory and

children’s mental addition. Journal of experimental

child psychology, 1997;67(1): 21–38.

Bakeman R. Observing interaction : an introduction to

sequential analysis. New York: Cambridge University

Press, 1986.

Bednarik, R. (2011). Expertise-dependent visual attention

strategies develop over time during debugging with

multiple code representations. International Journal

of Human-Computer Studies, 70(2), 143-155.

Bednarik, R., Myller, N., Sutinen, E., & Tukiainen, M.

(2006). Program visualization: Comparing

eye-tracking patterns with comprehension summaries

and performance. In ACM Proceedings of the 18th

Workshop of the Psychology of Programming Interest

Group, 68-82.

Chen, H. C., Lai, H. D., & Chiu, F.C. (2010). Eye tracking

technology for learning and education. Research in

Education Sciences, 4, 39-68.

Costelloe, E. (2004). Teaching programming: The state of

the art. CRITE Technical Report, Centre for Research

in I.T. in Education.

Fitzgerald, S. (2008). Debugging: Finding, Fixing and

Flailing, a Multi-Institutional Study of Novice

CSEDU2013-5thInternationalConferenceonComputerSupportedEducation

472

Debuggers. Computer Science Education, vol. 18,

93-116.

Just, M.A., Carpenter, P.A. (1984). Using eye fixations to

study reading comprehension. New Methods in

Reading Comprehension Research. Hillsdale, NJ:

Lawrence Erlbaum Associates, 151-182.

Lahtinen E. (2005). A study of the difficulties of novice

programmers. SIGCSE Bull., 37, 14-18.

Mackintosh N. J. and .Bennett E. S, The fractionation of

working memory maps on to different components of

intelligence. Intelligence, 2003;31:519-531.

Marzieh, A. Dave, E., & Colin, H. (2005). An analysis of

patterns of debugging among novice computer science

students. ITiCSE, 84-88.

Perkins, D. & Martin, F. (1986). Fragile knowledge and

neglected strategies in novice programmers.

Proceedings of the first workshop on empirical studies

of programmers on Empirical studies of programmers,

213-229.

Sabah AL-Fedaghi. (2012). Conceptual framework for

recursion in computer programming. Journal of

Theoretical and Applied Information Technology,

46(2), 983-990.

Sanders, M.S., & McCormick, E.J. (1987). Human factors

in engineering and design. New York: McGraw-Hill.

ExploringtheGenderEffectonCognitiveProcessesinProgramDebuggingbasedonEye-movementAnalysis

473
