Cloud Testing for Mobile Software Systems

Concept and Prototyping

Oleksii Starov

, Sergiy Vilkomir

and Vyacheslav Kharchenko

Department of Computer Science, East Carolina University, Greenville, NC, U.S.A.

Department of Computer Systems & Networks, National Aerospace University KhAI, Kharkiv, Ukraine

Keywords: Cloud Testing, Mobile Systems, Testing Framework, TaaS, Android.

Abstract: This paper describes an approach for increasing the effectiveness of mobile software system testing. A

Cloud Testing of Mobile Systems (CTOMS) framework is presented in the form of a cloud service that

provides the ability to run tests on a variety of remote mobile devices. This framework is based on a

heterogeneous networked system that connects operational computers, mobile devices, and databases with

software applications. Our research focuses on building a concept and a prototype of CTOMS that supports

testing Android mobile applications in the cloud. CTOMS allows multidirectional testing, providing the

opportunities to test an application on different devices and/or operating system (OS) versions and new

device models for their compatibility with the newest OS versions and the most popular applications.

Another new aspect is to embed the test model, specifically the appropriate testing techniques for mobile

development, within the framework. For users, this model will provide suggestions from CTOMS about the

test methods, criteria, coverage, and possible test cases. These suggestions are based on available

configurations, statistics, and resource constraints.

1 INTRODUCTION

Mobile developments are presented nowadays as a

variety of different applications with different

quality requirements. Interest in critical mobile

applications that require high-level reliability and

security is growing rapidly. For instance, mobile

applications have become commonplace for online

banking (Bank of America, 2013), and some

researchers are discussing the use of smartphones

and tablets at nuclear power plants (Moser, 2012). A

new trend is to use smartphones as components for

mobile cyber-physical systems because the powerful

hardware has a variety of sensors (White et al.,

2010). Examples of such systems include mobile

applications for notifications about hurricanes (Carr,

2012), monitoring cardiac patients (Leijdekkers,

2006), and traffic monitoring (Work and Bayen,

2008).

To guarantee the mobile applications’ reliability

and security, sufficient testing is required on a

variety of heterogeneous devices as well as on

different OS. Android development is the most

representative example of how different applications

should function amid a plethora of hardware-

software combinations (uTest, 2013). Adequately

testing all of these platforms is too expensive—

perhaps impossible—especially for small resource-

constrained mobile development companies.

This paper describes a framework that facilitates

the testing of mobile applications. The idea is to

create a cloud service that provides the ability to run

tests on a variety of remote mobile devices (i.e.,

smartphones). The proposed framework is based on

a heterogeneous networked system that connects

operational computers, mobile devices, and

databases with applications. This framework is

presented as a combination of hardware

(smartphones) and software (applications) that

allows for different testing directions. For instance,

it is possible to test a new smartphone model for its

compatibility with mobile applications and to test a

new application on different smartphone models.

This framework—CTOMS—serves as Testing as a

Service (TaaS) for mobile development.

This paper is organized as follows. Section 2

discusses the current state-of-the-art cloud testing

and the testing of mobile systems and applications.

Section 3 presents CTOMS, including its ability for

multidirectional testing, and the use of testing

124

Starov O., Vilkomir S. and Kharchenko V..

Cloud Testing for Mobile Software Systems - Concept and Prototyping.

DOI: 10.5220/0004416101240131

In Proceedings of the 8th International Joint Conference on Software Technologies (ICSOFT-EA-2013), pages 124-131

ISBN: 978-989-8565-68-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

models that allow users to choose specific testing

methods for their systems. The issues of security and

performance testing using CTOMS are also analyzed

and described. A high-level CTOMS architecture is

suggested in Section 4. Elements of prototyping and

feasibility studies of the framework are described in

Section 5. Section 6 concludes the paper and

proposes the directions for future work.

2 RELATED WORKS

A variety of cloud testing services exist to facilitate

software testing (Inçki et al., 2012); (Vilkomir,

2012); (Tilley and Parveen, 2012), including testing

mobile applications (Priyanka et al., 2012). Several

of these services provide remote access to connected

smartphones in order to accomplish their testing

(Perfecto Mobile, 2013); (Keynote Device

Anywhere, 2013). Of these, the Perfecto Mobile

service provides a well-suited example of optimum

core functionality for our proposed CTOMS

framework. Specifically, Perfecto Mobile aids

mobile developers in using remote smartphones for

manual testing, recording of scripts, and automatic

running of tests on a range of models. The CTOMS

framework offers two key enhancements over

existing testing services: multidirectional testing

capabilities and integration of the testing model into

the functionality of the service. Apkudo’s device

analytics (Rowinski, 2012) provide some elements

of multidirectional testing by testing devices on the

top 200 apps from the market. Keynote

DeviceAnywhere Test Planner provides elements of

testing techniques by suggesting a set of devices to

use for testing. While these services do not offer the

total range of desired comprehensive functionalities

compared with CTOMS, they point to the interest in

this testing direction.

A scientific testbed for a cloud solution is

discussed in Konstantinidis et al. (2012). Usage of a

set of plug-ins for different testing methods as a part

of the cloud testing framework is considered in

Jenkins et al. (2011). Cloud testing distributed

systems is analyzed in Tilley and Parveen (2012),

Rhoton and Haukioja (2011), and Coulouris et al.

(2011).

Many testing approaches were investigated

specifically for Android applications, including

automation of testing and GUI testing (Hu and

Neamtiu, 2011); (Ridene and Barbier, 2011), testing

frameworks that use distributed networked solutions

(Ridene and Barbier, 2011); (Mahmood et al., 2012),

security testing (Mahmood et al., 2012), and others.

Many investigations justify Android selection as

a base mobile platform for the CTOMS prototype.

Thus, according to Gartner, Android devices hold

the best part of the market (Haselton, 2012), and

forecasts by Forbes indicate that the Android

platform will advance to meet enterprise

requirements soon (Fidelman, 2012). Previous

research regarding bugs statistics in Android OS

(Maji, 2010) proves that Android has effectively

organized an open-sourced bug-tracking system that

can be helpful in further investigations.

3 THE CTOMS CONCEPT

3.1 Multidirectional Testing

This paper aims to generalize the concept of the

cloud service that provides mobile devices for

testing. The CTOMS framework extends the typical

functionality and provides the ability to test OS

version updates and new hardware devices against

most popular or/and important applications. It is

important to be confident that the legacy mobile

applications will still work properly in a new

environment.

Figure 1: Multidirectional testing.

Figure 1 illustrates the concept of multidirectional

testing. It shows the three main types of objects in

the system: applications (apps), devices (hardware),

and versions of OS. CTOMS provides the ability to

test each side on/against others; in other words, it

provides multidirectional testing from all possible

perspectives. All use cases are in high demand.

Simple lines show existing services. Dashed lines

show partially new use cases; see Rowinski (2012)

for an analogue of testing new devices against

applications. Bold arrows show totally new

functionality.

The current study considers cloud solutions for

the following scenarios:

CloudTestingforMobileSoftwareSystems-ConceptandPrototyping

125

1. Application developers can test a product on

different devices and/or OS versions.

2. OS developers can test new versions of an OS on

a set of modern devices and the most popular

apps to ensure compatibility.

3. Hardware developers can test new device models

for their compatibility with the newest OS

versions and the most popular applications.

The innovative aspect of our approach is that it

provides testing of new OS version against the top

popular applications (and test cases used for their

development). The relevance of such functionality

becomes obvious if we consider how rapidly new

versions of iOS or Android systems are released.

The same acute situation applies to hardware, thus

the device fragmentation testing matrix for Android

development can have nearly 4,000 separate

Android device models (uTest, 2013).

In general, the need to test OS or hardware

against applications is driven by critical systems that

contain mobile applications. In such systems, it is

very important to guarantee the dependability of

crucial applications with a newer version of the OS

or a new device. Critical mobile applications must

still work properly after OS updates and provide the

same reliability, or else the resulting faults can be

very expensive. The presence of all testing

perspectives in the CTOMS framework provides the

ability to comprehensively test mobile systems

because the hardware components are also key ones

for them.

Android development is the most representative

example of the problem of diverse configurations to

be tested. The variety of heterogeneous devices, OS

versions, screen resolutions, and other parameters is

significant. The popularity of the Android operating

system necessarily makes the question of cloud

testing extremely important. As such, this research

focuses first on building a prototype of the CTOMS

that supports Android testing. The following

sections offer solutions from both the architecture

and implementation points of view. The proposed

CTOMS framework also takes into consideration the

possibility of support for different kinds of devices:

from smartphones to mobile robots and from

microcontroller-based embedded systems to field-

programmable hardware (Kharchenko et al., 2009).

3.2 The CTOMS Structure

The conceptual structure of the CTOMS framework

contains several layers of mechanisms and

functionalities. Each should be analyzed,

architected, and implemented in a final

comprehensive system. Figure 2 illustrates these

layers and their connections with possible use cases:

1. The contributor of the device only invests in

hardware by connecting it to the cloud system.

2. The application developer uploads the

application under test (source codes or binary),

specifies test cases (automated scripts or unit

tests), gets results as pass/fail statistics or

screenshots for checkpoints, manually accesses

selected devices for debugging, etc.

Figure 2: The CTOMS structure and use cases.

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

126

3. The application developer uploads the

application under test (source codes or binary),

specifies test cases (automated scripts or unit

tests), gets results as pass/fail statistics or

screenshots for checkpoints, manually accesses

selected devices for debugging, etc.

4. The device producers test new devices against

the base of apps and OS software in CTOMS.

Test scripts available in the system for chosen

apps can be used. Producers can also specify

their own test scenarios.

5. The OS producer connects the devices with new

OS versions to the cloud or uploads update

packages to the database. Then the new OS

versions are tested with apps/scripts/ devices in

the system. OS producers can also specify their

own test scenarios.

Figure 2 shows that each user can provide a “testing

model” while using the framework. For application

developers, this means specifying a test strategy,

namely, what tests need to be performed on what

devices and how. For example, they can specify

their own test scripts; select devices, OS versions,

coverage, methods to check if a test is passed, etc.

For other users, this means not only specification of

test strategy or rules of testing (in case of

contributor), but also how to perform the testing on

connected devices. For example, the settings can be

made for which or how many applications to test.

The technical interface of the system for

contributors, as well as OS and hardware producers,

is almost the same.

The innovative feature of CTOMS is its testing

model that serves as an internal mechanism and

additional service for users (layer inside cloud on the

Figure 2). This aspect is described in more details in

the next section.

The databases in CTOMS store the software

(applications and OS versions), the testing results,

the statistical information about testing, and user

information for granting privileges based on the

billing and for providing multi-tenancy, etc.

This work with devices requires the development

of three additional layers: load balancing of tests

execution, diagnostic facilities, and heterogeneous

device connections. All of these layers (inside the

cloud in Figure 2) should be investigated in

accordance with earlier specified new use cases,

along with the creation of corresponding

methodologies. Load balancing of tests execution

system means algorithms to distribute test cases

between connected smartphones in optimal ways

with respect to time of operation and wait time of

other users. Simultaneously, general scalability

should also be taken into account.

The main high-level architecture solutions for the

challenges above are described in Section 4.

3.3 Testing Model

Another new aspect proposed in this study is to

embed the test model, i.e., appropriate testing

techniques for mobile development within the cloud

framework. Specifically, pair-wise testing (Kuhn et

al., 2009) is considered for this purpose. The pair-

wise testing combinatorial approach aids in dealing

with large amounts of different combinations of

hardware and software parameters that should be

covered by the tests. Coverage evaluation is a crucial

activity within mobile testing. According to the

Android Developers website (Android Developers,

2013), there are nine families of Android OS present

in the market (not counting subversions and builds

without Google APIs), four types of screen

resolution (small, normal, large, extra), and four

levels of screen density. Other parameters, such as

the type of Internet connection (WiFi, 3G), size of

ram, vendor, and processor’s characteristics, should

also be taken into consideration n order to provide

adequate coverage during testing. Some examples of

combinatorial tests based on different configurations

of Android application can be found in Kuhn et al.

(2010). Other techniques, including t-wise testing

(Lei et al., 2007), MC/DC (Chilenski and Miller,

1994), and RC/DC (Vilkomir and Bowen, 2006)

testing criteria, are also considered for integration

with CTOMS.

From a user’s point of view, the embedding of a

testing model operates as suggestions provided by

CTOMS: namely, suggestions relating to what

hardware-software configurations need to be tested,

the testing criterion to choose, the minimal test

coverage required, the risk statistics about particular

device configurations, etc. As a result, a user can

choose an appropriate testing model for a given

situation in terms of desired budget, time,

requirements, etc.

A testing model must also provide the general

organization of testing (i.e., launching tests, storing

results, etc.). This provides an opportunity to collect

statistics in the system, and for instance, to advise a

user that a particular device caused the main part of

defects during other similar applications testing.

CTOMS can also be considered for providing

reliability, performance, and security testing. In the

context of security testing, the following variants of

additional services are proposed:

CloudTestingforMobileSoftwareSystems-ConceptandPrototyping

127

 Implementation of different kinds of static

analysis.

 Whitebox approaches based on decompiling Java

classes (Mahmood et al., 2012).

 Model-driven approaches for security and

language-based security analysis.

 Automated stress security testing.

For performance testing, it is proposed to use

frame rate counters similar to Windows phone

Emulator (Windows Phone Dev Center, 2013).

For reliability testing, detailed usage of statistics

is proposed in conjunction with the long-term

performing of tests.

A detailed design of the CTOMS framework

aims to provide the ability to extend functionality

with such kinds of testing in a way similar to plug-

ins. The global goal is to create a comprehensive

testing environment.

4 ARCHITECTURE OF CTOMS

The architecture of a networked system, such as

CTOMS, can vary significantly in its level of

complexity. For example, the size of the desired

distributed solution is one dependent factor. CTOMS

can be architected as a single PC computer with

connected smartphones, or as a comprehensive cloud

solution that operates hundreds of such PC nodes.

To achieve all of its goals, CTOMS should be

implemented from a large-scale perspective and

must correspond to all cloud computing features,

such as service delivery, scaling, virtualization,

elasticity, multi-tenancy, load balancing, universal

access, etc. The cloud type can also differ from a

public SaaS (Software as a Service) solution to a

private IaaS (Infrastructure as a Service), with the

ability to provide a low-level configuration.

In this paper, trade-off solutions for CTOMS

complexity are suggested. The solutions include

leveraging public cloud providers, such as Google

App Engine (GAE) and Amazon AWS to create a

master application (layer) of the system in PaaS

(Platform as a Service). Computers with connected

mobile devices serve as “leaf nodes” and create a

slave layer of the system. They perform actual

testing on smartphones, collect results, and interact

with a master application through the Internet.

Figure 3 illustrates the high-level architecture of

CTOMS. It shows three layers of the system

interacting with each other. The separation of the

master layer as a public PaaS application gives the

ability to easily achieve both horizontal and vertical

scaling (layer 1 in Figure 3). The master layer does

not depend on the other layers, e.g., leaf nodes.

Besides, it also can leverage the highly scalable

databases and data storage provided by PaaS. The

master application has a comprehensive web

interface.

Communication between subsystems through the

Internet (web services) provides a convenient

scaling of layer 3. Leaf computers with smartphones

can be easily connected to a master application in

the cloud. They could also operate emulators (virtual

Android devices marked with a dashed line). The

interface for working with emulators and devices is

the same.

The middle layer 2 is optional. Its goal is to

leverage embedded Hadoop facilities of chosen

PaaS, particularly, MapReduce functionality. The

Figure 3: A variant of the CTOMS architecture.

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

128

aim is to organize test distribution and results

gathering by the master application. The algorithms

for effective load balancing of tests execution still

are performed by the master application.

5 IMPLEMENTATION

OF THE CTOMS PROTOTYPE

The current study provides a prototyping of the

CTOMS according to a specified distributed

architecture of the desired cloud system. The first

and third layers, according to Figure 3, were

implemented as the first prototype. The resulting

system consists of the two web Java applications:

the master and the leaf node.

The created master application is placed in a

Google App Engine cloud (Google App Engine,

2013), and, from a user’s point of view, looks like a

web interface to upload Android applications’

binaries and test scripts and get testing results.

The MonkeyRunner tool (MonkeyRunner, 2013)

provided with Android SDK (Android SDK, 2013)

is used to perform and automate actual testing on

mobile devices. This was the easiest choice for

acquiring a useful system that reflects all the

required characteristics of similar testing services.

Our aim was not to create a new and better way of

testing automation or manual remote access to

smartphones, but to create a cloud system to

accommodate other improvements. Thus, the current

CTOMS prototype accepts scripts for the

MonkeyRunner tool and provides as testing results a

set of screenshots-checkpoints taken on different

devices to compare by user-tester. Then the user can

specify which screenshot shows a bug.

The following associated issues were elaborated:

scripts parallelization to run on several devices

simultaneously; automation of statistics of fail/pass

checks based on heuristic images comparison; and a

possibility to embed useful supporting frameworks

as AndroidViewClient (AndroidViewClient, 2013)

and ViewServer (ViewServer, 2013).

Users can also run the client application on their

own computers to perform local testing. The

functionalities are the same (except for the absence

of integrated testing techniques). In this case, the

computer plays the role of the leaf node.

Functionality of multidirectional testing is

provided in the CTOMS prototype. It gives an

opportunity to test a connected device against

applications and corresponding tests within the

database of the system. Then a user can compare

screenshots taken on the new device (or device with

installed new OS version) to nominal screenshots

taken on trustworthy old models. This new device

can be connected to the system from a user’s site

and serve in the private (not shared) mode. At the

same time, MonkeyRunner tests do not require

uploading a binary (APK file) and can simulate

common user interactions with Android OS.

The ACTS tool by the National Institute of

Standards and Technology (NIST, 2013) is used to

integrate a combinatorial testing model in CTOMS.

A correspondent interface is provided through the

master application.

All interconnections of the master application

and leaf nodes were implemented through RESTful

web services. This gives the ability to publicly

expose them as Application Programming Interfaces

(Jacobson et al., 2011).

Integration of static code analyzers to provide

quality indicators and reveal security vulnerabilities

was considered, but because such functionality can

serve as a fully separated service, it was moved to

further versions.

6 CONCLUSIONS

The CTOMS cloud framework is presented here as a

way to increase the quality of testing mobile

applications. The main concepts, architecture, and

prototype implementation are described. Integrating

a testing model in CTOMS allows researchers to

apply different testing techniques and provide

performance and security testing of mobile

applications. The current prototype provides ability

of functional testing and detecting user interface

related bugs (e.g., layout or graphic performance

issues).

A variety of extensions to the framework are

possible on conceptual and implementation levels.

The future work will focus on case studies and

experiments using CTOMS. In particular, using

possible crowdsourcing benefits provided by

CTOMS, we are going to investigate dependency

between bugs in mobile applications and updates of

OS, and show testing effectiveness of such a cloud

of devices. Development experience and preliminary

analysis of reviews and bug reports in Google Play

indicate high clustering of defects for a specific OS

version or smartphone model. For instance, based on

the latest reviews of Twitter Android app (Twitter,

2013), we can conclude that users have problems

with notifications on different devices under

Android 4.0.1. Some statistics on causes of mobile

app crashes (including crashes by OS version),

CloudTestingforMobileSoftwareSystems-ConceptandPrototyping

129

provided by Crittercism (Crittercism, 2013), can be

found in Geron (2012).

REFERENCES

Android Developers, 2013. Dashboards. Available at:

http://developer.android.com/about/dashboards/

Android SDK, 2013. Available at: http://developer.

android.com/sdk/

AndroidViewClient, 2013. Extension to MonkeyRunner.

Available at: https://github.com/dtmilano/Android

ViewClient

Bank of America, 2013. Mobile Banking. Available at:

https:// www.bankofamerica.com/online-banking/

mobile.go

Carr, D. F. 2012. Hurricane Sandy: Mobile, Social Tools

Help Emergency Management, Brainyardnews (Oct.

2012). Available at: http://www.informationweek.

com/thebrainyard/news/social_media_monitoring/240

012463/hurricane-sandy-mobile-social-tools-help-

emergency-management

Chilenski, J. J., Miller, S., 1994. Applicability of Modified

Condition/Decision Coverage to Software Testing,

Software Engineering Journal, Sept. 1994, 193-200.

Coulouris, G., Dollimore, J., Kindberg, T., Blair, G.,

2011. Distributed Systems: Concepts and Design,

Addison-Wesley. 5

edition.

Crittercism, 2013. Available at: https://www.

crittercism.com/

Fidelman, M., 2012. The Latest Infographics: Mobile

Business Statistics For 2012. Available at: http://

www.forbes.com/sites/markfidelman/2012/05/02/the-

latest-infographics-mobile-business-statistics-for-2012

Geron, T. 2012. Do iOS Apps Crash More Than Android

Apps? A Data Dive. Available at:

http://www.forbes.com/sites/tomiogeron/2012/02/02/d

oes-ios-crash-more-than-android-a-data-dive/

Google App Engine, 2013. Developers portal. Available

at: https://developers.google.com/appengine

Haselton, T., 2012. Android Has 56.1% Of Global OS

Market Share, Gartner Says. Available at:

http://www.technobuffalo.com/2012/05/16/android-

has-56-1-of-global-os-market-share-gartner-says

Hu, C., Neamtiu, I., 2011. Automating GUI testing for

Android applications. In Proceedings of the AST '11,

6th International Workshop on Automation of

Software Test. ACM New York, NY, USA, 77-83.

Inçki, K., Ari, I., Sozer, H., 2012. A Survey of Software

Testing in the Cloud. In Proceedings of 2012 IEEE

Sixth International Conference on Software Security

and Reliability Companion. 18-23.

Jacobson, D., Brail, G., Woods, D., 2011. APIs: A

Strategy Guide. O’Reilly Media, Inc., 60-70.

Jenkins, W., Vilkomir, S., Sharma, P., Pirocanac, G.,

2011. Framework for Testing Cloud Platforms and

Infrastructures. In Proceedings of the CSC 2011,

International Conference on Cloud and Service

Computing, Hong Kong, China, Dec. 12-14, 2011,

134-140.

Keynote DeviceAnywhere, 2013. The Mobile Testing

Platform. Available at: http://www.keynotedevice

anywhere.com

Kharchenko, V., Siora, O., Sklyar, V., 2009. Design and

testing technique of FPGA-based critical systems. In

Proceedings of CADSM 2009, 10th International

Conference - The Experience of Designing and

Application of CAD Systems in Microelectronics

(Polyana-Svalyava, Ukraine, Feb. 24-28, 2009, 305-

314.

Konstantinidis, A., Costa, C., Larkou, G., Zeinalipour-

Yazti, D., 2012. Demo: a programming cloud of

smartphones. In Proceedings of the MobiSys '12, 10th

international conference on Mobile systems,

applications, and services.. ACM New York, NY,

USA, 465-466.

Kuhn, R., Kacker, R., Lei, Y., Hunter, J., 2009.

Combinatorial Software Testing, IEEE Computer.

Volume 42, Number 8, Aug. 2009, 94-96.

Kuhn, R., Kacker, R. N., Lei, Y., 2010. Practical

Combinatorial Testing, NIST Special Publication,

October, 2010.

Lei, Y., Kacker, R., Kuhn, D. R., Okun, V., Lawrence, J.,

2007. IPOG: A General Strategy for T-Way Software

Testing. In Proceeding of ECBS '07, IEEE

Engineering of Computer Based Systems conference,

March 2007, 549-556.

Leijdekkers, Gay, V. 2006. Personal Heart Monitoring and

Rehabilitation System using Smart Phones. In

Proceedings of the International Conference on

Mobile Business. Citeseer, 29.

Mahmood, R., Esfahani, N., Kacem, T., Mirzaei, N.,

Malek, S., Stavrou, A., 2012. A whitebox approach for

automated security testing of Android applications on

the cloud. In Proceedings of AST 2012, Automation of

Software Test, 7th International Workshop.

Maji, K., 2010. Characterizing Failures in Mobile OSes: A

Case Study with Android and Symbian. In Software

Reliability Engineering (ISSRE) 21st International

Symposium.

MonkeyRunner, 2013, Android SDK tool.

http://developer.android.com/tools/help/monkeyrunner

_concepts.html

Moser K., 2012. Improving Work Processes for Nuclear

Plants (Exelon Nuclear). In American Nuclear Society

Utility Working Conference 2012.

NIST, 2013. ACTS tool. Available at: http://csrc.nist.gov/

groups/SNS/acts/download

Perfecto Mobile, 2013. The MobileCloud Company.

Available at: http://www.perfectomobile.com/

Priyanka, Chana, I., Rana, A., 2012. Empirical evaluation

of cloud-based testing techniques: a systematic review,

ACM SIGSOFT Software Engineering Notes archive.

Volume 37, Issue 3, May 2012, ACM New York, NY,

USA, 1-9.

Rhoton, J., Haukioja, R., 2011. Cloud Computing

Architected: Solution Design Handbook, Publisher:

Recursive, Limited, ISBN: 0956355617.

Ridene, Y., Barbier, F., 2011 A model-driven approach for

automating mobile applications testing. In

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

130

Proceedings of the 5th European Conference on

Software Architecture: Companion Volume Article

No. 9.

Rowinski D., 2012. Mobile Carriers and OEMs Get

Android App Testing Cloud from Apkudo, ReadWrite

(February 7, 2012). Available at: http://

readwrite.com/2012/02/07/mobile-carriers-and-oems-

get-a

Tilley, S., Parveen, T., 2012. Software Testing in the

Cloud: Perspectives on an Emerging Discipline,

Information Science Reference, Nov. 2012.

Twitter, 2013. Application for Android. Available at:

https://play.google.com/store/apps/details?id=com.twit

ter.android&hl=en

uTest, Inc., 2013. The Essential Guide to Mobile App

Testing (free eBook) Available at: http://www.

utest.com/landing-blog/essential-guide-mobile-app-

testing.

ViewServer, 2013. Available at: https://github.

com/romainguy/ViewServer

Vilkomir, S., 2012. Cloud Testing: A State-of-the-Art

Review, Information & Security: An International

Journal. Volume 28, Issue 2, Number 17, 2012, 213-

222.

Vilkomir, S., Bowen, J. P., 2006. From MC/DC to

RC/DC: formalization and analysis of control-flow

testing criteria, Formal aspects of computing, Volume

18, Number 1, 2006, 42-62.

White, J., Clarke, S., Dougherty, B., Thompson, C., and

Schmidt, D. 2010. R&D Challenges and Solutions for

Mobile Cyber-Physical Applications and Supporting

Internet Services. Springer Journal of Internet Services

and Applications. Volume 1, Number 1 (2010), 45-56.

Windows Phone Dev Center, 2013. Testing Apps for

Windows Phone. Available at: http://msdn.microsoft.

com/library/windowsphone/develop/jj247547(v=vs.10

5).aspx

Work, D. B., Bayen, A. M., 2008. Impacts of the Mobile

Internet on Transportation Cyberphysical Systems:

Traffic Monitoring using Smartphones. In

Proceedings of National Workshop for Research on

High-Confidence Transportation Cyber-Physical

Systems: Automotive, Aviation and Rail, Washington,

DC, Nov. 18-20, 2008.

CloudTestingforMobileSoftwareSystems-ConceptandPrototyping

131
