Noise Models in Inductive Concept Formation

Marina V. Fomina, Alexander P. Eremeev and Vadim V.Vagin

Moscow Pover Engeneering Institute, Technical University, Krasnokazarmennaja Street, Moscov, Russia

Keywords: Knowledge Acquisition, Information Generalization, Data Mining, Knowledge Discovery, Decision Tree,

Noise Model, Learning Sample.

Abstract: The problem of information generalization with account for the necessity of processing the information

stored in real data arrays which may contain noise is considered. Noise models are presented, and a noise

effect on the operation of generalization algorithms using the methods of building decision trees and

forming production rules is developed. The results of program modeling are brought about.

1 INTRODUCTION

Knowledge discovery in databases (DB) is important

for many technical, social, and economic problems.

Up-to-date DBs contain such a huge quantity of

information that it is practically impossible to

analyze this information manually to acquire

valuable knowledge for decisions making. The

systems for automatic knowledge discovery in DB

are capable of analyzing "raw" data and presenting

the extracted information faster and with more

success than an analyst could find it himself. At first

we consider setting up the generalization problem

and the methods of its decision. Then the noise

models and prediction of unknown values in

accordance with the nearest neighbour method in

learning samples are viewed. And finally modeling

the algorithm of decision tree with the combination

of forming production rules in the presence of noise

and results of program simulation are given.

2 GENERALIZATION PROBLEM

Knowledge discovery in DB is closely connected

with the solution of the inductive concept formation

problem or the generalization problem.

Let us give the formulation of feature-based concept

generalization (Vagin et al., 2008).

Let

},...,,{

21 n

oooO 

be a set of objects that

can be represented in an intelligent decision support

system (IDSS). Each object is characterized by r

attributes: A

, A

, … , A

. Denote by Dom(А

Dom(А

), … , Dom(А

) the sets of admissible values

of features where Dom(А

)={x

, x

, … 





1, and 



is the number of different values

of the feature A

. Thus, each object



1 is represented as a set of feature values,

i.e.,

},...,,{

21 iriii

xxxo



, where

Dom(А

),1



. Such a description of an

object is called a feature description. Quantitative,

qualitative, or scaled features can be used as object

features (Vagin and Eremeev, 2009).

Let O be the set of all objects represented in a

certain IDSS; let V be the set of positive objects

related to some concept and let W be the set of

negative objects. We will consider the case where

WVO 









. Let K be a non-empty

set of objects such that



 KKK

, where

VK 



and

WK 



. We call K a learning sample.

Based on the learning sample, it is necessary to build

a rule separating positive and negative objects of a

learning sample.

Thus, the concept is formed if one manages to

build a decision rule which, for any example from a

learning sample, indicates whether this example

belongs to the concept or not. The algorithms that

we study form a decision in the form of rules of the

type "IF condition, THEN the desired concept." The

condition is represented in the form of a logical

function in which the boolean variables reflecting

the feature values are connected by logical

connectives. Further, instead of the notion "feature"

we will use the notion "attribute". The decision rule

is correct if, in further operation, it successfully

recognizes the objects which originally did not

444

V. Fomina M., P. Eremeev A. and V. Vagin V..

Noise Models in Inductive Concept Formation.

DOI: 10.5220/0004420104440450

In Proceedings of the 15th International Conference on Enterprise Information Systems (ICEIS-2013), pages 444-450

ISBN: 978-989-8565-59-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

belong to the learning sample.

The presence of noise in data changes the above

setting up of the generalization problem both at the

stage of building decision rules and at the stage of

the object classification. First of all, the original

learning sample K is replaced by the sample K' in

which distorted values or missing values of features

occur with a certain probability. We consider the

solution of the concept generalization problem using

the methods of decision trees (Quinlan, 1986, 1996)

including binary decision trees (Breiman et al.,

1984).

3 GENERALIZATION

ALGORITHMS BASED

ON DECISION TREES

The purpose of the given paper is to study a noise

influence on the work of generalization algorithms

that build decision trees.

The decision tree T is a tree in which each non-

final node accomplishes checking of some condition,

and in case a node is finite, it gives out a decision for

the element being considered. In order to perform

the classification of the given example, it is

necessary to start with the root node. Then, we go

along the decision tree from the root to the leaves

until the final node (or a leaf) is reached. In each

non-final node one of the conditions is verified.

Depending on the result of verification, the

corresponding branch is chosen for further

movement along the tree. The solution is obtained if

we reach a final node. Decision tree may be

transformed into a set of production rules.

Research of noise effect on the operation of

generalization algorithms has been performed on the

basis of comparative analyses of two known

algorithms C 4.5 and CART.

The algorithm C4.5 as its predecessor ID3

suggested by J.R.Quinlan (Quinlan, 1986, 1996)

refers to an algorithm type building the classifying

rules in the form of decision trees. However, C4.5

works better than ID3 and has a number of

advantages:

- numerical (continuous) attributes are introduced;

- nominal (discrete) values of a single attribute may

be grouped to perform more effective checking;

- subsequent shortening after inductive tree building

based on using a test set for increasing a

classification accuracy.

The algorithm C 4.5 is based on the following

recursive procedure:

An attribute for the root edge of a tree T is

selected, and branches for each possible values of

this attribute are formed.

The tree is used for classification of learning set

examples. If all examples of some leaf belong to the

same class, then this leaf is marked by a name of this

class.

If all leafs are marked by class names, the

algorithm ends. Otherwise, an edge is marked by a

name of a next attribute, and branches for each of

possible values of these attribute are created, go to

step 2.

The criterion for choosing a next attribute is the

gain ratio based on the concept of entropy (Quinlan,

1996).

In the algorithm CART (Breiman et al., 1984),

building a binary decision tree is performed. Each

node of such decision tree has two descendant. At

each step of building a tree, the rule that shares a set

of examples from a learning sample into two subsets

is assigned to a current node. In the first subset,

examples are entered where a rule is performed, and

the second subset includes examples where a rule

does not performed. Accordingly for the current

node, two descendant nodes are formed and the

procedure is recursively repeated until a tree will be

obtained. In this tree the examples of a single class

are assigned to each final node (tree leaf).

The most difficult problem of the algorithm

CART is a selection of best checking rules in tree

nodes. To choose the optimal rule, there is used the

assessment function of partition quality for a

learning set introduced in (Breiman et al., 1984).

The important distinction of the algorithm CART

from other algorithms of building the decision trees

is the use the mechanism of tree cutting. The cutting

procedure is necessary to obtain the tree of an

optimal size with a small probability of erroneous

classification.

4 NOISE MODELS

Assume that examples in a learning sample contain

noise, i.e., attribute values may be missed or

distorted. Noise arises due to following causes:

incorrect measurement of the input parameters;

wrong description of parameter values by an expert;

the use of damaged measurement devices; and data

lost in transmitting and storing the information

(Mookerjee et al., 1995). Our purpose is to study

noise effect on the functioning C 4.5 and CART

algorithms.

One of basic parameters of research is a noise

NoiseModelsinInductiveConceptFormation

445

level. Let a learning sample K (|K| = m) be

represented in the table with m rows and r columns,

such table has N=m



r of cells. Each table row

corresponds to one example and each column – to

certain informative attribute. A noise level is a

magnitude p

, showing that an attribute value in a

learning or test set will be distorted. So, among all N

cells, Np

of cells at the average will be distorted.

Modeling a noise includes noise models and ways of

their entering as well.

For research, two noise models were chosen:

“absent values” and “distorted ones”. In the first

case for the given noise level with probability p

known attribute value is removed from a table. The

second variant of entering a noise is linked with

substitution of a known attribute value for another

one that may be wrong for the given example.

Values for replacement are chosen from domains

Dom(А

rk 1

, where p

sets up a

probability of such substitution.

At entering a noise of the type “absent values”, it

is necessary also to select a way of treating absent

values. In the paper two ways are considered:

omission of such example and restoring absent

values on the “nearest neighbours” method (Vagin

and Fomina, 2011).

There are several ways of entering a noise in

learning sets (Quinlan, 1986). Let us consider three

ways of entering a noise into a table.

1. Noise is entered evenly in the whole table with

the same noise level for all attributes.

2. Noise of the given level is entered evenly in one

or several explicitly indicated attributes. Entering

a noise into the single table column, the content

of which is the most important attribute (root

node), is an extreme case here.

3. The new way of irregular noise entering in a

table was offered. Here a noise level for each

column (informative attribute) depends on a

probability of passing an accidentally selected

example through a tree node marked by this

attribute.

We have:

- a sum noise entered into a table corresponds to the

given noise level;

- all informative attributes, values of which are

checked in nodes of a decision tree, are put on

distortions;

- the more “important” an attribute the higher a

distortion level of its values.

Principles of noise level account for the third

irregular model are proposed. Let the decision tree T

have been built on the basis of the learning sample

K. Evidently, an accidentally selected example will

passes far from through all nodes. Hence, our

problem is to efficiently distribute this noise

between table columns (attributes) in

correspondence with statistical analysis of DBs

having a given average noise level p

For each attribute A

, find a factor of the noise

distribution S

according to a probability of passing

some example through the node marked A

. Clearly,

each selected example from K will pass through the

root node of a decision tree. Therefore the value 1 is

assigned to the factor S

of the root attribute.

All other tree nodes which are not leafs have one

ancestor and some descendants. Let one such node

be marked by attribute A

and have the ancestor

marked by A

. The edge between that nodes is

marked by the attribute value x

where x



Dom(А

Let m be the example quantity in K and m

be the

example quantity in K satisfying to the condition:

attribute value for A

is equal to x

Then the factor of noise distribution



















The value 0 is assigned to all factors for

attributes not using in a decision tree. Introduce the

norm











Thus, each attribute A

, will be undergone to

influence of a noise where a noise level is

















∙



∙

Here 



is a given noise level, r is an attribute

quantity.

It is easy to see that 

∑









⁄





, i. e. the

average noise level is the same as the given one.

Further, we consider the work of the

generalization algorithm in the presence of noise in

original data. Our purpose is to assess the

classification accuracy of examples in a test sample

by increasing a noise level in this sample.

5 RESTORING ABSENT VALUES

IN A LEARNING SAMPLE

Let a sample with noise, K', be given; moreover, let

the attributes taking both discrete and continuous

values be subject to distortions. Consider the

problem of using the objects of a learning sample K'

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

446

in building a decision tree T and in conducting the

examination using this tree.

Let o

K' be an object of the sample;

=<x

, … , x

>. Among all the values of its

attributes, there are attributes with the value Not

known. These attributes may be both discrete and

continuous.

Building a decision tree while having examples

with absent values leads to multivariant decisions.

Therefore, we try to find the possibility for restoring

these absent values. One of the simplest approaches

is a replacement of an unknown attribute value on

the average (mean or the mode, MORM). Another

possible approach is the nearest neighbours method

which was proposed for the classification of the

unknown object o on the basis of consideration of

several objects with the known classification nearest

to it. The decision on the assignment of the object o

to one or another class is made by information

analysis on whether these nearest neighbours belong

to one or another class. We can use even a simple

count of votes to do this. The given method is

implemented in the algorithm of restoring

RECOVERY that was considered in detail in (Vagin

and Fomina, 2010), (Vagin et al., 2008). Since the

solution in this method explicitly depends on the

object quantity, we shall call this method as the

search method of k nearest neighbours (kNN).

6 MODELING THE

ALGORITHMS OF FORMING

GENERALIZED NOTIONS

IN THE PRESENCE OF NOISE

The above mentioned algorithms C 4.5 and CART

have been used to research the effect of a noise on

forming generalized rules and on classification

accuracy of test examples. To restore unknown

values the methods of nearest neighbours (kNN) and

choice of average (MORM) are used. We propose

the combined algorithm "Induction of Decision Tree

with restoring Unknown Values" (IDTUV3)

including C4.5, CART and RECOVERY algorithms.

The RECOVERY algorithm is used at the presence

of examples containing a noise of the type “absent

values”. When absent values of attributes are

restored, one of algorithms of notion generalization

is used.

Below, we present the pseudocode of the

IDTUV3 algorithm.

Algorithm IDUTV3

Given: K= K



Obtain: decision rules: decision

tree T, binary decision tree T

Beginning

Obtaining K= K



Select noise model (absent values or

distorted values ), noise level,

one of three noise entering types

(uniform, in root column, irregular)

If noise model is “absent values “

then use RECOVERY

Perform: introduce noise in K

Select generalization algorithm

C4.5 or CART

If Select C4.5

then obtain decision tree T

else Select CART and obtain

decision tree T

end if

Output decision tree T or T

end

End of IDTUV3.

To develop the generalization system, the

instrumental environment MS Visual Studio 2008,

program language C# has been used. The given

environment is a shortened version MS Visual

Studio. DBMS MS Access was used to store data

sets.

The program IDTUV3 performs the following

main functions:

- loads the original data from DB;

- enters different variants of noise in learning and

test sets;

- builds the classification model (a decision tree, or

binary decision tree) on the basis of the learning

sample;

- forms production rules in accordance with the

constructed tree;

- recognizes (classifies) objects using a classification

model;

- statistics on classification quality is formed.

We present experiment results fulfilled on the

following three data groups from the known

collection of the test data sets of California

University of Informatics and Computer Engineering

"UCI Machine Learning Repository" (Merz and

Murphy, 1998):

1. Data of Monk's problems;

2. Repository of data of the StatLog project:

- Australian credit (Austr.credit);

3. Other data sets (from the field of biology and

juridical-investigation practice).

Below the results of experiments for the problem

of Monk-1 are produced. The learning sample was

made up of 124 examples (62 positive and 62

negative examples), the size of which composes

30% from the whole example space (432 objects).

NoiseModelsinInductiveConceptFormation

447

The set of test examples includes all examples (216

positive and 216 negative examples). Each object is

characterized by 6 informative attributes. The class

attribute has two different values.

In tables 1, 2 classification accuracy, obtained

under the given noise level, is represented for the

given generalization algorithm and the particular

way of entering noise.

Table 1: Classification results for examples with noise

(“distorted values”) by entering a noise to a learning

sample.

Algorithm

and way of

entering a

noise

Classification accuracy of “noisy”

examples, %

noise

Noise

10%

Noise

20%

Noise

30%

С4.5,

uniform

85,13 83,98 75,15 79,48

С4.5,

irregular

85,13 83,24 77,33 73,31

СART,

uniform

81,24 78,34 74,19 72,24

СART,

irregular

81,24 77,05 70,73 70,63

Table 2: Classification results for examples with noise

(“distorted values”) by entering a noise to a test sample.

Algorithm

and way of

entering a

noise

Classification accuracy of “noisy”

examples, %

noise

Noise

10%

Noise

20%

Noise

30%

С4.5,

uniform

85,13 84,41 76,72 76,96

С4.5,

irregular

85,13 81,63 71,97 67,53

СART,

uniform

81,24 79,91 75,19 73,68

СART,

irregular

81,24 78,59 73,25 72,04

In the case of using the model “absent values”

(Tables 3, 4) in each cell there are allocated 2

values: upper – by restoring unknown values on the

method of “nearest neighbor” (neighbor number –

3), down - omission of examples with unknown

values.

Let us consider the influence problem of a noise

entering method on the work of generalization

algorithms. Below the experiments are presented in

which the model “distorted values” was used and the

algorithm C4.5 was chosen. A noise was entered in

test samples by each from three ways of entering a

noise: uniform, in a root attribute, irregular. Results

are given in Table 5 for problems of Monks 1, 2 and

3 and for data collections Glass and Australian

Credit.

Table 3: Classification results for examples with noise

(“absent values”) by entering a noise to a learning sample.

Algorithm

and way of

entering a

noise

Classification accuracy of “noisy”

examples, %

noise

Noise

10%

Noise

20%

Noise

30%

С4.5,

uniform

85,13 85,35 84,39 79,95

85,13 82,49 82,71 71,41

С4.5,

irregular

85,13 85,12 78,50 77,32

85,13 79,32 69,91 68,09

СART,

uniform

81,24 82,17 76,83 73,14

81,24 78,28 73,51 70,09

СART,

irregular

81,24 82,93 75,68 71,43

81,24 77,77 68,48 66,54

Table 4: Classification results for examples with noise

(“absent values”) by entering a noise to a test sample.

Algorithm

and way of

entering a

noise

Classification accuracy of “noisy”

examples, %

noise

Noise

10%

Noise

20%

Noise

30%

С4.5,

uniform

85,13 82,39 74,54 77,72

85,13 84,38 71,29 73,85

С4.5,

irregular

85,13 78,94 71,76 74,42

85,13 78,06 65,78 66,71

СART,

uniform

81,24 77,37 70,33 74,76

81,24 76,51 64,47 64,81

СART,

irregular

81,24 79,70 72,45 75,13

81,24 78,81 66,41 66,24

Let’s define in the Table 5 the methods of entering a

noise as follows: u – uniform, r – in root attribute, i

– irregular.

We can make the following conclusions. A noise

in DBs influences essentially on the classification

accuracy and on generalization algorithms as a

whole.

The noise entered into a test set has essentially

larger influence on the classification accuracy than a

noise entered in a learning set (on the average up to

5 – 6% at entering a noise up to 30%).

With increasing a noise level, the irregular way

of entering a noise has essentially larger influence

on the classification accuracy than the uniform way

of entering a noise (on the average up to 3 – 4% at

entering a noise up to 30%).

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

448

Table 5: Classification results for examples with noise

(“distorted values”) by entering a noise to a test sample.

Data set

and method

of entering

a noise

Classification accuracy of “noisy”

examples, %

noise

Noise

10%

Noise

15%

Noise

20%

MONKS

82,3 83,53 82,74 83,06 78,14

81,63 81,12 79,73 76,71

83,49 81,89 82,01 76,98

MONKS

88,54 84,43 82,15 79,35 73,5

83,15 79,36 75,28 65,98

82,71 80,82 74,68 68,12

MONKS

85,44 82,35 83,78 79,2 75,89

82,24 80,46 79,81 70,52

82,13 81,59 81,37 71,77

GLASS

70,35 68,93 67,03 62,93 59,15

65,34 63,71 61,26 55,74

64,48 64,52 63,68 56,61

AUSTR.

CREDIT

83,31 82,73 80,57 73,19 69,41

79,34 75,61 73,33 62,01

82,14 77,49 74,07 63,71

Under growth of a noise level, “distortion model”

sometimes is able to increase the classification

accuracy.

The method of “nearest neighbours” gives a

better classification accuracy in comparison with

exclusion from a sample of examples with unknown

values (on the average up to 8% under a noise level

up to 30%).

The dependence of classification accuracy on a

noise level at different variants of entering a noise is

close to linear.

From three ways of entering a noise, the most

influence on the classification accuracy has entering

a noise in the root node.

7 CONCLUSIONS

In the paper the problem of inductive concept

formation was considered and means of its solution

in the presence of noise in original data were

researched.

The new noise model in DB tables was offered,

in consequence of which there is provided irregular

entering a noise into informative attributes of

learning and test samples. Machine experiments on

researching the noise influence on work of

generalization algorithms C4.5 and CART are

produced. The joint algorithm IDTUV3 allowing to

process learning samples containing examples with

noisy values, have been suggested.

The obtained results of modeling have shown

that the algorithms С4.5 и CART in the combination

with the restoring algorithm allow to handle data

efficiency in the presence of noise of a different

type.

The system of building generalized concepts

using the obtained results has been developed and

the program complex has been implemented.

The paper has been written with the financial

support of RFBR (No. 11-07-00038a, 12-01-

00589a).

REFERENCES

Vagin V., Golovina E., Zagoryanskaya A., Fomina M.,

2008. Exact and Plausible Inference in Intelligent

Systems. 2-nd Edition. (in Russian)

Vagin V., Eremeev A., 2009. Methods and Tools for

Modelling Reasoning in Diagnostic Systems. ISEIS

2009, Proceedings of the 11th International

Conference on Enterprise Information Systems, Milan,

Italy.

Quinlan J., 1986. Induction of Decision Trees. In Machine

Learning, 1.

Quinlan J., 1996. Improved Use of Continuous Attributes

in C 4.5. In Journal of Artificial Intelligence Research,

Vol.4.

Breiman L., Friedman J., Olshen R., Stone C., 1984.

Classification and Regression Trees. Wadsworth,

Belmont, California.

Mookerjee V., Mannino M., Gilson R., 1995. Improving

the Performance Stability of Inductive Expert Systems

under Input Noise. In Information Systems Research

Vol.6 (4).

Vagin V., Fomina M., 2011. Problem of Knowledge

Discovery in Noisy Databases. In Int. J. Mach. Learn.

& Cyber. Vol.2. Springer Ferlag, Berlin.

Quinlan J., 1986. The effect of noise on concept learning.

In Machine Learning Vol. II , Chapter 6. Palo Alto,

CA: Tioga.

NoiseModelsinInductiveConceptFormation

449

Vagin V., Fomina M., 2010. Methods and Algorithms of

Information Generalization in Noisy Databases. In

Advances in Soft Computing. 9th Mexican Intern.

Conference on AI, MICAI 2010, Pachuca, Mexico,

Proceedings, Part II. / Springer Verlag, Berlin.

Vagin V., Fomina M., Kulikov A., 2008. The Problem of

Object Recognition in the Presence of Noise in

Original Data. In 10th Scandinavian Conference on

Artificial Intelligence SCAI 2008.

Merz C, Murphy P., 1998. UCI Repository of Machine

Learning Datasets. Information and Computer Science

University of California, Irvine, CA 92697-3425

http://archive.ics.uci.edu/ml/.

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

450
