Composing Classes

Roles Vs Traits

Fernando Barbosa

and Ademar Aguiar

Escola Superior de Tecnologia, Instituto Politécnico de Castelo Branco, Av. do Empresário, Castelo Branco, Portugal

INESC TEC and Faculdade de Engenharia da Universidade do Porto, Rua Dr. Roberto Frias, Porto, Portugal

Keywords: Roles, Traits, Code Reuse, Modularity, Composition, Inheritance.

Abstract: Code replication has significant drawbacks in system maintenance. Code replication can have its origins in

the composition limitations of the language. Several proposals have tried to overcome these limitations. A

popular one is traits. However, traits do not support state or visibility control. Static roles are also a way of

composing classes that has the benefits of traits and offers state, visibility control and other advantages as

block renaming. We compare both approaches on how they are used to compose classes, and how they can

be used to reduce code replication caused by composition limitations. As a case study we will compare how

both approaches can reduce code replication by detecting and removing code clones within the JHotDraw

framework. Results show that roles are capable of reducing a larger amount of replicated code than traits.

1 INTRODUCTION

Code clones, identical blocks of code, are a hint that

the system needs to be refactored (Fowler, 1999).

However code clones appear in most systems,

specially in large ones (Mayrand et al., 1996)

(Baxter et al., 1998). Code clones impair

maintenance and evolution of a system (Baxter et

al., 1998). One problem is the inconsistence in

updating, where a bug in a code block is propagated

to all its clones, and is fixed in most but not all

occurrences. Code clones also have negative effects

in program evolution, comprehensibility and cost

(Roy and Cordy, 2007).

One origin of clones is the lack of composition

mechanisms (Mayrand et al., 1996; Baxter et al.,

1998; Roy and Cordy, 2007). This makes it harder to

deal with crosscutting concerns - concerns that a

class must deal with but are not its main concern.

When dealing with the same concern classes tend to

use similar code. This is more frequent in languages

without multiple inheritance, but multiple

inheritance has so many practical problems that it

has been left out of recent languages, like Java and

C#.

Some clones could be avoided if a language had

other composition mechanisms. Several proposals

are available, like multiple inheritance, mixins

(Bracha and Cook, 1990), traits (Ducasse et al.,

2004; Scharli et al., 2003), features (Apel and

Kästner, 2009) and aspects (Kiczales et al., 2001).

Traits can be seen as a set of methods that

provide common behaviour. When a class uses a

trait its methods are added to the class. The class

also provides glue code to compose the several

traits. Traits cannot store state. State is maintained

by the class that uses the trait.

When a class plays a role the role methods are

added to the class interface. Thus an object’s

behaviour is defined by the composition of all roles

its class declares to play. A class can configure the

role to its needs by configuring types and methods

names. Roles support state and visibility control.

Composing classes using traits or roles can

minimize the code replication due to limitations of

the composition mechanism. To assess this we

conducted an experiment to account how both

approaches could be used to remove the replicated

code found in the JHotDraw Framework. We briefly

present the two approaches then compare them

showing how they deal with conflict resolution,

composition order, etc.

We identified code clones using a clone

detecting tool, and grouped them according to their

concerns. We then tried to develop a role and a trait

for each concern, thus removing the clones. We

developed roles for nearly all detected concerns, but

couldn’t do the same for traits.

Barbosa F. and Aguiar A..

Composing Classes - Roles Vs Traits.

DOI: 10.5220/0004424000630073

In Proceedings of the 8th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE-2013), pages 63-73

ISBN: 978-989-8565-62-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

We can summarize our paper contributions as: a

comparison of roles and traits features, ways of

reducing replicated code using traits and roles; a

comparison of how roles and traits tackle the

problem of reducing duplicated code and identifying

which clones they can eliminate; a case study

showing how each approach reduces replicated code

in an open source system.

This paper is organized as follows. Section 2

presents Traits and Section 3 presents roles. In

Section 4 we compare the two approaches. Section 5

shows how to remove clones using roles and using

traits and section 6 presents the JHotDraw

framework case study. Related work is presented in

section 7 and section 8 concludes the paper.

2 TRAITS IN A NUTSHELL

Traits are units of code reuse and a class can be

constructed using several traits (Ducasse et al., 2004;

Scharli et al., 2003). Traits have a flattening

property: a class can be seen indifferently as a

collection of methods or as composed by traits. The

fact that the class can be seen as a whole promotes

understanding and the fact that it can be composed

promotes reuse.

In Traits a class can be constructed by using

inheritance and by adding traits. The class must

supply all state variables and glue code. The glue

code is the set of methods that the trait requires the

class to provide (for example, accessor methods for

the state variables). Thus a class can be decomposed

into a set of coherent features and the glue code

connects the various features together.

According to (Ducasse et al., 2004), Traits have

the following properties:

– A trait provides methods that implement behaviour

– A trait requires a set of methods that serve as

parameters for the provided behaviour.

– Traits do not specify state variables, and methods

provided by traits never access state variables.

– Classes and traits can be composed from traits.

– The composition order of traits is irrelevant.

– Conflicting methods must be explicitly resolved.

– Trait composition does not affect the semantics of

a class: the meaning of the class is the same as it

would be if all of the methods obtained from the

trait(s) were defined directly in the class.

– Similarly, trait composition does not affect the

semantics of a trait.

A class can redefine its superclass’s and its trait’s

methods. Conflicts arise when unrelated traits have

methods with the same signature. The conflict must

be solved explicitly by redefining the conflicting

method in the class. The conflict is thus resolved

locally. To access the conflicting methods Traits

support aliases. It works by giving an alias to a

method so it can be used in the class without trouble.

To prevent conflicts from occurring in the first place

traits also support the exclusion of methods.

Some attempts to bring traits into Java-like

languages have been made (Quitslund and Black,

2004; Smith and Drossopoulou, 2005). To compare

the Trait approach to the Role approach we used

Chai (Smith and Drossopoulou, 2005). Since Chai is

an extension to the Java language and we intend to

use our JavaStage language, that is also an Java

extension, we can argue that the differences between

the final code is due integrally to each approach and

not to the underlying language. The traits examples

in this paper are presented using the Chai syntax and

derive from the example shown in (Smith and

Drossopoulou, 2005).

Figure 1 shows trait declaration in Chai and its

use by classes. We can see requirement of methods

class Circle {

int radius;

int getRadius() { ... }

}

trait TEmptyCircle {

requires { void drawPoint(int x, int y);

int getRadius(); }

void draw() { ... }

}

trait TFilledCircle {

requires { void drawPoint(int x, int y);

int getRadius(); }

void draw() { ... }

}

trait TScreenShape {

void drawPoint(int x, int y) {...}

}

trait TPrintedShape {

void printPoint(int x, int y){...}

}

class ScreenEmptyCircle extends Circle

uses TEmptyCircle,TScreenShape { }

class PrintedFilledCircle extends Circle

uses TFilledCircle,TPrintedShape {

alias { void printPoint(int x, int y)

from TPrintedShape as

void drawPoint(int x, int y) }

}

Figure 1: Trait example (adapted from (Smith and Drossopoulou, 2005).

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

in the TEmptyCircle: it offers a draw method and

requires the class to provide the drawPoint and

getRadius, with the specified signature. The same

methods are also required by TFilledCircle. The

code also shows a Circle class, representing a circle,

and two subclasses composed by traits and that

inherit from Circle. The ScreenEmptyCircle class is

an empty circle that can be drawn in the Screen, so it

uses TEmptyCircle and TScreenShape. The methods

required by TEmptyCircle are supplied by Circle

and TScreenShape, so ScreenEmptyCircle does not

need to provide them itself. PrintedFilledCircle is a

filled circle than can be printed in a printer, so it

inherits from Circle and uses TFilledCircle and

TPrintedShape. TFilledCircle required methods are

supplied by Circle and TPrintedShape. In the

TPrintedShaped case the class needed to alias the

trait method for the required name.

For more information on Traits we refer to

(Ducasse et al., 2004; Scharli et al., 2003) and for

the Chai language syntax we refer to (Smith and

Drossopoulou, 2005).

3 ROLES IN A NUTSHELL

We use roles as a basic construct from which we can

compose classes. Roles provide the basic behaviour

for concerns that the classes must deal with but are

not their main concern. Thus we can better

modularize the construction of classes. We must

mention that we use roles statically as defined by

Riehle in (Riehle, 2000) where he uses them as static

entities for modelling purposes. We do not use roles

as dynamic entities that can be attached or detached

from an object at runtime. Since there is much work

on the use of dynamic roles (Steimann, 2000; Tamai

et al., 2007; Herrmann, 2005) this must be

mentioned to avoid confusion.

To program with roles we use JavaStage, an

extension to Java (Barbosa and Aguiar, 2013).

Examples in this paper use the JavaStage syntax.

Figure 2 shows the role version of the trait example

of Figure 1.

A role may define methods and fields including

access levels. A class can play any number of roles,

and can even play the same role more than once. A

class playing a role is a player of that role. When a

class plays a role all the non private methods of the

role are added to the class. To play a role the class

uses a plays directive and gives the role an identity.

To refer to the role the class uses its identity. Roles

can inherit from roles and can also play other roles.

A role may require the player to have specific

methods. Those methods are stated in a requirement

list, which indicates who must supply the method

and the method signature. The Performer keyword

indicates that the supplier is the player. Performer is

used within a role as a place-holder for the player’s

type. This enables roles to declare fields and

parameters of the type of the player.

JavaStage has a method renaming mechanism

that allows the renaming of methods with a simple

configuration. Each name may have three parts: a

configurable one and two fixed. Both fixed parts are

optional. The configurable part is bounded by #, like

in the example: fixed#configurable#fixed

The name configuration is done by the class

playing the role in the plays clause. To play the role

the class must define all configurable methods.

It’s possible to declare several versions of a method

using multiple definitions of the configurable name.

This way, methods with the same structure are

defined once.

class Circle {

int radius;

int getRadius() { ... }

}

role EmptyCircle {

requires Performer implements

void #draw#(int x, int y);

requires Performer implements int getRadius();

void draw() { ... }

}

role FilledCircle {

requires Performer implements

void #draw#(int x, int y);

requires Performer implements int getRadius();

void draw() { ... }

}

role ScreenShape {

void drawPoint(int x,int y){ ... }

}

role PrintedShape {

void printPoint(int x,int y){ ...}

}

class ScreenEmptyCircle extends Circle {

plays EmptyCircle(

draw = drawPoint ) emptyCircle;

plays ScreenShape screenShp:

}

class PrintedFilledCircle extends Circle {

plays FilledCircle(

draw = printPoint ) fillCircle;

plays PrintedShape;

}

Figure 2: Role example, equivalent to the traits’ example in Figure 1.

ComposingClasses-RolesVsTraits

Role members have all the visibility control

available to classes and a protected role member is

accessible to its players and subroles. A protected

class member is also accessible to roles. A class can

reduce the visibility of the role members. If a class

uses protected in the plays clause then all the public

role methods are imported to the class as protected.

Class defined methods always take precedence

over role methods and role methods take precedence

over inherited methods. Conflicts may arise when a

class plays roles that have methods with the same

signature. When conflicts arise the compiler issues a

warning. Developers can handle the conflict by

redefining that method and calling the intended

method. This is not mandatory because the compiler

uses, by default, the method of the first role in the

plays clause order.

JavaStage supports role constructors but does not

allow direct role instantiation. For more information

on roles and JavaStage we refer to (Barbosa and

Aguiar, 2013)

4 A COMPARISON BETWEEN

ROLES AND TRAITS

For comparing roles and traits we follow a few key

points that both approaches must deal with and

describe how each handled the situation.

Unit of Composition. In roles the unit of

composition is the role while in traits it is the trait.

Inheritance. Roles and traits are targeted for

single inheritance languages so there is no multiple

inheritance support. Roles can play other roles and

traits can use other traits. Both approaches also

support a class using the same unit several times. In

a class, to access the features of the superclass both

approaches use the super keyword. In a role,

however, the super keyword refers to the super role,

as roles can inherit from other roles. In a trait it

refers to the superclass of the composing class.

State Support. Roles can have state and it does

not cause any conflict because to access role state

the class must use the role identity thus no conflicts

arise. Traits do not support state. Proposals to solve

this introduced a significant complexity to the trait

model and encapsulation problems (Cutsem et al.,

2009). When modelling a concept we, often, need to

express state. For example, to model a container we

need a structure for storage. Forcing the composing

class to supply that structure is rather breaking the

container’s encapsulation.

Conflict Resolution. Both approaches follow

the same rules for method overriding. The class

overrides methods from roles/traits and roles/traits

override the class inherited methods. Conflicts may

arise when methods with the same signature are

provided by more than one unit. In traits the conflict

must be resolved explicitly while in roles the method

of the first played role is used (there is a compiler

warning). In both cases it is the class composer that

decides which method to use. In traits he can choose

to exclude some methods so there is no conflict or

he can redefine the method and use aliases to refer to

each of the conflicting methods. In roles there is no

exclusion and the class composer must redefine the

conflicting method if he wishes to override the rule

of using the method of the first role.

Composition Order. The order in which traits

are composed is symmetric so order of composition

is irrelevant. The same applies for the roles when

there are no conflicting methods. When there are

conflicting methods the order of the plays will

dictate which method is used. This, however, is not

mandatory as discussed in the previous topic.

Method Renaming vs Aliases. There is a

fundamental difference between aliases in traits and

method renaming in the roles. The traits aliases are

used only by the class for distinguishing conflicting

methods, the class interface is not affected. In roles

the renaming affects the class interface. This means

that a class may be able to tailor its interface to suit

its needs and not be limited by the role interface.

The renaming mechanism of the roles also allows

renaming several methods in one go, while aliases in

traits are made one by one. Roles renaming scheme

can provide multiple versions of a method. Traits

aliases can be applied to any method, while on roles

only the configurable methods can be configured.

Flat and Composite View. Both approaches

support a flat view of the class as well as a

composite view. Thus a class can be seen as a set of

methods, the flat view, or as being composed by

several units of composition, the composite view.

The class interface in both views is exactly the same.

The main difference between the two is that a trait

method is seen just like a class method, and a role

method is always a role method and each reference

to other methods will always refer to role methods.

For example, suppose a trait that defines the

methods foo and bar, where bar calls foo. If the class

overrides the foo method then the trait bar method

will call the foo method on the class not on the trait.

The same situation is handled differently by roles. If

the method bar of the role is called then it will call

the foo method on the role and not on the class. For

a role method to call a class method it must do it

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

explicitly using the perfomer keyword.

Visibility control. Traits have no visibility control.

Freezable traits (Ducasse et al., 2007) compensate

this by allowing classes to freeze/unfreeze methods,

i.e., declare a method as private (freeze) or making it

public (defrost). But there is no way to express

access constraints between class and trait. For

example, fields should be accessed directly only by

the owner’s code. Traits do no support this. Roles on

the other hand support all Java access levels, so a

specific interface between role and class is possible.

Stating Requirements. The use of generic types

is a useful feature in most languages, especially for

dealing with object collections. Traits can require

methods from the class that uses them, but cannot

impose restriction on generic types it interacts with.

The requires statement of roles indicates the method

signature and which type it is required from. This

allows roles not only to require methods from the

class but also from other collaborators types.

5 REMOVING CLONES

We want to assess if the extra units of composition

roles and traits provide are capable of reducing code

clones. To remove code clones refactorings (Fowler,

1999) are normally used. The ones most used for

removing code clones are: Extract Method; Pull Up

Method, Pull Up Field, Extract Superclass, Extract

class and Form Template Method (Fanta and

Rajlich, 1999; Komondoor and Horwitz, 2000)

(Higo et al., 2004).

We identified three clone types where roles or

traits can be applied to remove code clones that fall

outside the scope of these refactorings or produce

better results. The clone types all have method

granularity, so if actual clones do not have method

granularity other refactorings must be used. Clone

types are: Clones with identical code; Clones with

similar code but using different types; Clones with

similar code but using different method names with

or without different types

Clones with Identical Code. These clones have

identical methods and/or fields. This could be

handled by the Extract Class refactory, but we argue

that this is one situation where roles/traits produce

better results. Extract Class forces the original class

to provide delegate methods to the newly created

class. With roles and traits those methods are not

required. We put the code in the role/trait and then

compose the class using it.

The application of roles and traits is shown in

Figure 3. The figure represents two classes with

replicated code. Both classes have different,

unrelated, superclasses so Pull Up Method and

Extract Superclass cannot be used. The replicated

code was placed in a trait and a role.

Both solutions are similar, the difference is that

roles support state so they do not require the getX

and setX methods and can even provide them. Traits

require the class to supply those methods.

Clones with Similar Code but using Different

Types. These could be handled by Extract Class,

using type parameters. For example we can build a

Company class that manages workers and we can

build a PolyLine that stores points. Both classes will

have code for adding and removing workers/points,

so there will be replicated code between them, only

class A extends SuperA {

private int x;

int getX() { return x; }

void setX(int x){this.x=x;}

void foo( ) { // more code

x += 14;

}

void bar() { ... }

}

class B extends SuperB {

private int x;

int getX() { return x; }

void setX(int x){this.x=x;}

void foo( ) { // more code

x += 14;

}

void bar() { ... }

}

trait TOne {

requires{ int getX();

void setX( int x );}

void foo( ) { // more code

setX( getX() + 14 );

}

void bar() { ... }

}

class A extends SuperA uses TOne{

private int x;

int getX() { return x; }

void setX( int x){this.x = x;}

}

class B extends SuperB uses TOne{

private int x;

int getX() { return x; }

void setX( int x){this.x = x;}

}

role ROne {

private int x;

int getX() { return x; }

void setX(int x){this.x=x;}

void foo( ){ // more code

x += 14;

}

void bar() { ... }

}

class A extends SuperA {

plays ROne r1;

}

class B extends SuperB {

plays ROne r1;

}

Figure 3: Removing identical clones using roles and traits.

ComposingClasses-RolesVsTraits

the stored type is different. We can create a unit

responsible for this management. We show this

example in Figure 4. For simplicity and space we

used arrays and do not show the management code.

There is a limitation in traits that may render a

solution impossible: traits cannot require methods

from other sources other than the class that uses

them. A possible example is the Observer pattern

(Gamma et al., 1995), where subjects maintain a list

of observers and notify them when changes occur

using an update method. The observer management

is similar to the container problem just described, so

the same solution can be applied. The problem lies

in calling the update method. For calling this method

the Trait must specify the type of the observer

otherwise it cannot call a method on it. Roles can

solve this by requiring the Observer type to

implement an update method, as shown in Figure 5,

where a Figure class notifies FigureObservers

whenever it is changed. The solution reuses the

container role and just adds the notify method.

Clones with Similar Code but Using Different

Method Names with or without different Types.

These clones have identical code but the names of

the methods are not identical. The used types may

also be different. For example we could change the

Company and Polyline example and change them so

that each had different names. The company would

have addWorker and removeWorker methods while

PolyLine would have addPoint and removePoint.

Traits aliases do not cope with these changes as

they only affect the methods internally. With traits

we would have to uniform the methods names and

then apply the previous topic solution. We show

how this situation is handled by roles in Figure 6.

The Company class also shows how we can use the

multiple method version to produce an addWorker

and an addEmployee method.

6 CASE STUDY

To compare how roles and traits are capable of

reducing code replication we applied both to the

JHotDraw framework. The framework defines the

basic structure for a GUI based editor with tools,

different views, user-defined graphical figures, etc.

6.1 Case Study Setup

We searched for replicated code with CCFinderX

(Kamiya et al., 2002), an established clone detection

tool used in aspect mining works (Ceccato et al.,

2005).

We filtered clones inside the same file (same

class), thus eliminating clones that could use Extract

trait TContainer<T>{

requires {

T[] getAll();

}

void add(T t){...}

void remove( T t){

...

}

class Company uses

TContainer<Worker>{

Worker arr[];

Worker[] getAll(){

return arr;

}

class PolyLine uses

TContainer<Point>{

Point arr[];

Point[] getAll() {

return arr;

}

role Container<T> {

private T arr[];

void add( T t ){...}

void remove( T t){...}

T[] getAll() {

return arr;

}

class Company {

plays Container<Worker>

cWorker;

}

class PolyLine {

lays Container<Point>

cPoint;

}

Figure 4: Removing identical clones with different types

using roles and traits.

role Subject<T> extends Container<T>{

requires T implements void update();

void notify( ) {

for( T t : getAll() )

t.update();

}

class Figure {

plays Subject<FigureObserver> figSubject;

}

Figure 5: Defining requirements on collaborators types.

role Container<T> {

private T arr[];

void add#Thing#( T t ) { ... }

void remove#Thing#( T t ) {...}

}

class Company {

plays Container<Worker>( Thing = Worker,

Thing = Employee ) cWorker;

}

class PolyLine {

plays Container<Point>( Thing = Point

) cPoint;

}

Figure 6: Removing identical clones with different

methods and types using roles.

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

Method or similar. We want to assess traits and roles

capability to reduce the code clones derived from

compositional limitations, so we only want clones

that are not removable with traditional refactorings.

The first result included 271 clones, reduced to

146 after filtering. These were manually inspected.

41 false clones were removed leaving a final 105

sets. Some clones only had similar structures, but as

they focused on the same concern we did consider

them. This will explain some unresolved concerns.

We grouped clones according to their concerns.

This helped us decide which role/trait to develop.

We identified 42 concerns, but 5 were removed (2

could be easily refactored, 1 was deprecated code

and 2 were classes pending substitution).

We’ve decided not to change any class interface

or any concern implementation, so the framework is

unchanged. This can restrict roles/traits development

but we want to assess how we can reduce code

replication, not redesign the framework. Roles were

developed and compiled with JavaStage (Barbosa

and Aguiar, 2013) and traits developed with Chai

(Smith and Drossopoulou, 2005).

Results are shown on table 1. For each concern it

shows how many clones were associated and how

many classes were affected. It also shows the

number of lines of code (LOC) that the clone had,

the lines of code that were used by Roles and Traits,

and the ratio between the various solutions.

LOC are a good measure on the effort that each

approach requires, because both use Java as the

underlying language, the syntax of both solutions is

analogous and we made an effort to uniform the

LOC count. We counted as LOC the requirements

statements that traits and roles use. We also counted

as LOC the roles’ plays directive and the traits’ uses

directive. This overhead can lead a small clone to

have more LOC in the solution than in the original

form but the fact that there is no clone gives the

system a great modularity advantage.

In the cases where roles removed clones and

traits did not, the table shows the roles features that

allowed them to remove the clone. For the concerns

that neither technique worked it states the reason

why they failed.

6.2 Results Analysis

Table 1 shows that from the 38 concerns only 8

(21%) concerns were not resolved with roles. Traits

failed to resolve 15 (39%) concerns. It also shows

that traits were not able to resolve the clones that

roles could not. The final outcome is better than

these numbers indicate as we will discuss.

We can see from table 1 that roles never had worst

results than traits, succeeding in 7 concerns where

traits failed and fared better in 13 more concerns.

This indicates that roles are, at least, as good as traits

in reducing replicated code.

Concerns resolved with Roles and Traits.

Comparing the LOC ratio of both approaches, in

those concerns both resolved, one finds that in

average roles only have 83% of the traits code and

68% of the original code, so the effort of developing

the role system seems smaller.

In 6 concerns we were able to reuse roles from

the role library developed in (Barbosa and Aguiar,

2012). From those, 3 are solvable with traits but we

had to develop a special trait for each concern and

could not reuse them from a library. This explains

the great difference in LOC in these concerns.

Supporting state is the role feature responsible

for the fewer code used in roles. The class instead of

having to declare each field and provide getters and

setters would have the field and methods defined in

the role. This is no small advantage not only in LOC

but also in terms of abstraction and encapsulation.

The multiple method version also enabled roles

to have less code, because a single method definition

can provide several methods.

Concerns resolved by Roles Only. Roles were

able to resolve 7 concerns that traits did not. From

these, 3 used roles from the library. Requiring and

renaming methods from other participants is the

feature that enables roles to solve more clones.

From all the concerns roles resolved, two exhibit

a higher LOC than the original implementation:

“Handle creation” and the “Polygon locator”.

The “Handle creation” concern deals with the

creation of handles for each figure. We placed the

creation of the handles in a handle creator class that

has a method for the handle creation for each class.

That and the role overhead lead to more lines of

code than the original implementation. But the role

has an advantage over the original code: it can

dynamically change the handle creator.

The “Polygon Locator” uses an anonymous

class. In JavaStage roles cannot be applied to

anonymous classes so we had to develop an inner

class to play that role and then use it.

Unresolved concerns. A surprising result is that

for the 2 concerns with the most clone sets and class

involved neither technique works. This is because

they are clones in the structure and not on the code

itself. The ”Creating undo activity” creates an

UndoActivity object for each tool and command.

Each has an UndoActivity inner class. Because inner

class constructors have different parameters in

ComposingClasses-RolesVsTraits

Table 1: Identified concerns with the number of associated clones and affected classes. It also shows the LOC for each

approach and respective ratios.

*= reused role from library, br= block renaming, g= generics, mv= multiple versions, rp= requires from participant, s= state

clone class

Original Roles Roles/ Traits Roles/ Traits/

LOC LOC Original LOC Traits Original

Drawing Handles

815

64 40 63% 40 100% 63%

Setting up the undo activity before

executing a Command

2856 44 79% 44 100% 79%

BringToFront/SendToBack Commands

20 12 60% 12 100% 60%

Handle creation

11 20

70 87 124% 87 100% 124%

Drawing polygons

12 11 92% 11 100% 92%

Palette Listener

20 17 85% 17 100% 85%

DisplayBox persistence

35 12 34% 12 100% 34%

DisplayBox handling

58 29 50% 60 48% 103%

DesktopListener Subject

63 45 71% 55 82% 87%

Changing connections

98 53 54% 65 82% 66%

Finding connectable figure

98 53 54% 65 82% 66%

Testing command executability

14 14 100% 15 93% 107%

Floating text holder

47 36 77% 47 77% 100%

DrawingViewListener Subject

63 26* 41% 47 55% 75%

Setting text in a text Figure

36 22 61% 32 69% 89%

Enumerator

33 11* 33% 37 30% 112%

Figure Listener that resends notifications

35 23* 66% 37 62% 106%

Menu enabling

20 14 70% 14 100% 70%

Version control

12 9 75% 9 100% 75%

Selected button manager

18 12 67% 16 75% 89%

Text attributes management

206 120 58% 149 81% 72%

Updating DrawingView Strategy

29 26 90% 32 81% 110%

Connection insets computing

10 7 70% 7 100% 70%

Undo/Redo Commands

32 31 97%

Changing connection handles

20 19 95%

Polygon and PolyLine Handles

32 28 88%

Tools and Commands Dispatchers

89 32* 36%

Figure/Handle and Enumerator

33 2* 6%

Polygon locator

13 20 154%

Drawing editor

54 28* 52%

Reason

Desktop initial configurations

required too much configuration

Persistence (read/write)

similar but not quite identical code

UndoActivity

13 24

Undoactivity inner classes constructors

Creating UndoActivity

14 18

after other roles was just a line of code

Handle manipulation starting action

required too much configuration

Point is inside Figure

code too small

DrawingView Listener

perfomance issues

Mouse motion handling

code too small

br rp g

Resolved by Roles and Traits

Concern

Unresolved

br rp g

br rp

mv br rp

Resolved only by Roles

Roles features

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

number and types, roles and traits could not resolve

this concern. Another example is the “Handle

manipulation starting action”: code is similar but not

identical: methods have different parameters.

Another example is “Persistence”: because

figures must be streamed they have a write and read

methods with similar, but not identical, structures.

Another unresolved concern is “DrawingView

listener”. The replicated code is redefining the

original method for performance issues.

The unresolved “Desktop Initial configuration”

deals with a Desktop’s panel initialization. Each

initialization is similar so we could configure a

role/trait for each. But it would be easier to know

how to configure the scroll pane.

Other unresolved concern was a single line like

getSomeObject().doSomething(). The first method

returns different objects that call different methods,

so role configuration would take more LOC.

We would count only 4 unresolved concerns if

we had not considered some concerns as clones.

6.3 Threats to Validity

We only considered a single system. However, the

discussion in section 5 hints that results from other

systems would also have roles performing better

than traits. We need to do the same test with more

systems to fully assess this.

The clone detection settings can affect the clones

detected which would lead to different concerns. But

we needed to reduce the amount of clone sets to a

manageable number or there would be a greater

number of false clones. We even used less than the

limit of 30 tokens recommended in (Kamiya et al.,

2002) to limit false clones. So we believe that our

settings provided a good number of clones/concerns

that make this case study results valid.

There could be biased results from having the

same developers doing the role and traits approach.

After all the authors are more experienced in roles

than in traits. This could bias the results towards

roles. To prevent this, we opted to base the study on

clone detection and not on developing an alternate

system from scratch.

The effort used to develop each approach was

not taken into account. For that we would need to

assess how teams of developers, each using a

different approach, tackled the same problem. While

the LOC number gives a hint on the effort required,

and here roles have an advantage, it does not tell the

entire story as already mentioned. However it does

give some insights. One insight is that the use of

state reduces the effort to develop roles by reducing

the amount of glue code one must write to use traits.

This also gives roles a better modelling capability

because a role can model a concept that has state and

behaviour as opposed to the traits’ behaviour only

modelling. We also reused roles from our role

library, but traits equivalent could not be placed in a

traits library, which means that the effort of

developing roles was less than that of traits.

7 RELATED WORK

There are a number of dynamic role approaches like

Object Teams (Herrmann, 2005), EpsilonJ (Tamai et

al., 2007) and PowerJava (Baldoni et al., 2007).

These are known for their capability to attach and

detach roles from objects at runtime, something that

(Cutsem et al., 2009) also supports for traits.

ObjectTeams introduces the notion of team. A team

represents a context in which several classes

collaborate to achieve a common goal. Even though

roles are first class entities they are implemented as

inner classes of a team and are not reusable outside

that team. Roles are also limited to be played by a

specific type. PowerJava has a similar concept – the

institution. When an object wants to interact with an

institution it must assume one of the roles the

institution offers. In EpsilonJ roles are also defined

as inner classes of a context. Roles are assigned to

an object via a bind directive. It uses a requires

directive similar to roles and traits. It also offers a

replacing directive to rename methods names.

Feature Oriented Programming (FOP) (Apel and

Kästner, 2009) decomposes the system into features.

FOP relies on a step-wise refinement of applications

by adding new features or refining existing ones. To

compose a system we just state which features it has.

The composition is made automatically with tool

support, like AHEAD (Batory et al., 2004). This is a

more powerful technique than roles or traits.

AHEAD uses several tools for composing the code

and extra files for configuring the composition step.

Roles/Traits are programming languages that

statically compose classes using only source code.

AHEAD can be used to compose classes. For

example, we can develop a class that defines the

basic behaviour of a class, undistinguishable from a

normal Java class, except that it has a feature

keyword indicating to which feature it is associated

to. We can then construct several refinements to that

class. Each refinement indicates the added feature

and the class it refines.

Package Templates (PT) (Krogdahl et al., 2005)

use traditional java packages with a twist. Classes

ComposingClasses-RolesVsTraits

defined in these packages are only directly available

when the package is instantiated. When instantiated

the classes can be tailored to the context of use by:

getting additions; elements can be renamed; type

parameters are given actual types. This tailoring is

similar to roles as roles also support renaming and

type parameters. PT may also impose restrictions on

the various types via a constraints declaration that

resembles roles requirement list. Classes in a PT can

be merged with classes from other PT and can be

used more than once in the same merging (like

roles/traits can be used multiple times). The main

difference between PT and roles is that PT, like

traits, rely on inheritance to do the merging and roles

rely on inner classes. Name clashes are resolved via

renaming, which can be applied to fields and

methods. The renaming cannot be used on the

constraints. JavaStage on the other hand allows the

renaming of required methods

Aspect-Oriented Programming is an approach

that tries to modularize crosscutting concerns

(Kiczales et al., 2001). AOP defines pointcuts to

identify points in the executing program that may

trigger a different execution path and advices that

indicate the new execution path. While the

modularization of crosscutting concerns is the

flagship of AOP several authors disagree (Steimann,

2000; Przybyłek,v2011). The effects of pointcuts

and advices, especially when several aspects have

similar pointcuts, may be unpredictable. Thus simple

changes in the class code can have unsought effects

(Kästner et al., 2007).

The obliviousness feature of AOP means that a

class is aspect unaware so aspects can be plugged or

unplugged as needed. But it introduces problems in

comprehensibility (Griswold et al., 2006). To

understand the system we must know the classes and

which aspects affect each class. This is a major

drawback when maintaining a system, since the

dependencies aren’t always explicit and there isn’t

an explicit interface between both parts.

With roles/traits all dependencies are explicit and

the system comprehensibility is increased (Riehle,

2000). Roles do not have the obliviousness of AOP

because the class is aware of the roles it plays.

Caesar (Mezini and Ostermann, 2003) uses

aspect technology to modularize crosscutting

concerns and enhance reuse of aspects leading to a

greater reduction of repeated code. Caesar uses an

Aspect Collaboration Interface that decouples

aspects binding and implementations by defining

them in a separated module. Caesar does not allow

method renaming.

Jiazzi (McDirmid et al., 2001) is based on Units

(Flatt, 1998) and aims at building systems out of

reusable components integrated with the language.

Jiazzi has two types of units: Atoms (composed by

java classes) and Compounds (composed by atoms

or other compounds). Jiazzi supports the addition of

features to classes without editing their source code.

Roles/Traits could be used within Jiazzi to specify

these new features. A trait/role could be used to add

the same behaviour for different classes in the same

unit, or for the same class but in different units.

8 CONCLUSIONS

We compared how the role and traits approaches

deal with the composition problems that they aim to

diminish by doing a study on how each can reduce

replicated code, especially the replicated code that

derives from lack of compositional mechanisms in

single inheritance languages.

The outcome of the study showed that roles are

more reusable than traits, because roles support

state, have a renaming mechanism that tunes them to

the class purpose and can even provide several

versions of a method in a simple way. We validated

our approach developing roles for the JHotDraw

framework and eliminated nearly all duplicated

code. Doing the same test for traits showed that they

cannot eliminate all the clones roles were capable of.

We even reused some roles from our role library

showing that they are really reusable.

REFERENCES

Apel, S., Kästner, C. (2009): An Overview of Feature-

Oriented Software Development, in Journal of Object

Technology, vol. 8, no. 5, July–August 2009.

Baldoni, M., Boella, G. van der Torre, L., (2007):

Interaction between Objects in powerJava, journal of

Object Technologies 6, 7 - 12.

Barbosa, F. and Aguiar, A. (2012). Roles as Modular

Units of Composition. In 7th International Conference

on Evaluation of Novel Approaches to Software

Engineering, June, 29-30, Wroclaw, Poland.

Barbosa, F. and Aguiar, A. (2013). Using Roles to Model

Crosscutting Concerns. In Aspect Oriented Software

Devlopment (AOSD3), March 24–29, Fukuoka, Japan.

Batory, D., Sarvela, J. N. and Rauschmayer, A., Scaling

Step-Wise Refinement. IEEE TSE, 30(6), 2004.

Baxter, I., Yahin, A. Moura, L., Sant’Anna, M. and Bier.

L. (1998). Clone Detection Using Abstract Syntax

Trees. In Proc. of Int. Conf. on Software Maintenance.

ENASE2013-8thInternationalConferenceonEvaluationofNovelSoftwareApproachestoSoftwareEngineering

Bracha, G. and Cook, W. (1990): Mixin-Based

Inheritance. In Proceedings of the OOPSLA/ECOOP,

pages 303–311, Ottawa, Canada. ACM Press.

Ceccato, M., Marin, M., Mens, K., Moonen, L, Tonella, P.

and Tourwe, T (2005). A qualitative comparison of

three aspect mining techniques, Proc. of the Inter.

Workshop on Program Comprehension, Washington.

Cutsem, T., Bergel, A., Ducasse, S. and Meuter, W.

(2009): Adding State and Visibility Control to Traits

Using Lexical Nesting, Proc. of ECOOP 2009, Italy.

Ducasse, S., Schaerli, N., Nierstrasz, O., Wuyts, R. and

Black, A. (2004): Traits: A mechanism for fine-

grained reuse. In Transactions on Programming

Languages and Systems.

Ducasse, S., Wuyts, R., Bergel, A., and Nierstrasz, O.

(2007): User-changeable visibility: Resolving

unanticipated name clashes in traits. In Proceedings

OOPSLA, New York, NY.

Fanta, R., Rajlich, V. (1999): Removing Clones from the

Code. Journal of Software Maintenance: Research and

Practice, Volume 11(4):223-243.

Flatt, M. and Felleisen, M. (1998) Units: Cool modules for

HOT languages. In Proc. of PLDI, May 1998.

Fowler, M., (1999), Refactoring: Improving the design of

existing code, Addison-Wesley, Boston, MA, USA.

Gamma, E., Helm, R., Johnson, R. and Vlissides, J.,

(1995): Design Patterns: Elements of Reusable Object-

Oriented Software, Addison-Wesley.

Griswold, W.G., Sullivan, K., Song, Y., Shonle, M.,

Tewari, N., Cai, Y., Rajan, H., 2006: Modular

Software Design with Crosscutting Interfaces. IEEE

Software 23(1), 51–60 (2006).

Herrmann, S., (2005): Programming with Roles in

ObjectTeams/Java. AAAI Fall Symposium: "Roles, An

Interdisciplinary Perspective".

Higo, Y., Kamiya, T., Kusumoto, S., Inoue. K. (2004):

Refactoring Support Based on Code Clone Analysis.

In Proceedings of the 5th International Conference on

Product Focused Software Process Improvement

(PROFES'04), Kansai Science City, Japan.

Kamiya, T., Kusumoto, S. and Inoue, K. (2002), Ccfinder:

a multilinguistic tokenbased code clone detection

system for large scale source code, IEEE Trans. Softw.

Eng. 28, no. 7.

Kästner, C., Apel, S., Batory, D., 2007: A Case Study

Implementing Features using AspectJ. In: 11th Inter.

Conference of Software Product Line, Kyoto, Japan.

Kiczales, G., Hilsdale, E., Hugunin, J., Kersten, M., Palm,

J., Griswold. W. G., (2001): An overview of AspectJ.

In proceedings of ECOOP 2001, Budapest, Hungary.

Komondoor, R. and Horwitz SS. (2000): Semantics-

Preserving Procedure Extraction. In Proceedings of

the 27th ACM SIGPLAN-SIGACT Symposium on

Principles of Programming Languages (POPL'00), pp.

155-169, Boston, MA, USA.

Krogdahl, S., Møller-Pedersen, B., Sørensen, F. (2005):

Exploring the use of Package Templates for flexible

reuse of Collections of related Classes, in Journal of

Object Technology, vol. 8, no. 7.

Mayrand, J., Leblanc, C. and Merlo, E. Experiment on the

Automatic Detection of Function Clones in a Software

System Using Metrics. In Proc. of the International

Conference on Software Maintenance, 1996.

McDirmid, S., Flatt, M. and Hsieh, W.C. Jiazzi: new-Age

Components for Old-Fashioned Java”, OOPSLA 2001.

Mezini, M. and Ostermann, K. 2003. Conquering Aspects

with Caesar. In Proc. of AOSD 2003, pages 90 – 99.

Przybyłek, A. /2011). Systems Evolution and Software

Reuse in Object-Oriented Programming and Aspect-

Oriented Programming , TOOLS 2011, LNCS 6705.

Quitslund, P. and Black, A. (2004): Java with traits -

improving opportunities for reuse. In Proceedings of

the 3rd International Workshop on Mechanisms for

Specialization, Generalization and inheritance.

Riehle, D. 2000. Framework Design: A Role Modeling

Approach, Ph. D. Thesis, Swiss Federal Institute of

technology, Zurich.

Roy, C. and Cordy, J. (2007) A Survey on Software Clone

Detection Research. Tech. Report 2007-451, School of

Computing, Queen’s University at Kingston.

Scharli, N., Ducasse, S., Nierstrasz, O. and Black, A.

(2003): Traits: Composable units of behavior. In

Proceedings of ECOOP 2003, volume 2743 of Lecture

Notes in Computer Science. Springer.

Smith, C. and Drossopoulou, S. (2005): Chai: Traits for

Java-like languages. In Proceedings of ECOOP 2005.

Steimann, F., (2000): On the representation of roles in

object-oriented and conceptual modeling. Data &

Knowledge Engineering 35(1):83–106.

Tamai, T., Ubayashi, N., and Ichiyama, R., (2007):

Objects as Actors Assuming Roles in the

Environment, in Software Engineering For Multi-

Agent Systems V, Lecture Notes In Computer

Science, vol. 4408. Springer-Verlag, Berlin.

ComposingClasses-RolesVsTraits
