Solving Planning Problems with LRTA*

Raulcezar M. F. Alves and Carlos R. Lopes

Faculty of Computing, Federal University of Uberlˆandia, Uberlˆandia, Minas Gerais, Brazil

Keywords:

Planning Systems, EHC, BFS, LRTA*, FF Planner.

Abstract:

A number of new heuristic search methods have been employed in the development of planning systems

over the last years. Enforced Hill Climbing (EHC) combined with a complete search strategy, such as Best

First Search (BFS), is a method that has been frequently used in several AI planning systems. Although

this method presents an enhanced performance when compared to alternative methods used in many of the

other planning domains, it does all the same show some weaknesses. In this paper the authors propose to

replace the use of EHC and BFS with LRTA*, which is a search algorithm guided by heuristics like EHC and

is as complete as BFS. Moreover, the authors implemented some optimizations on LRTA*, such as a heap

with a maximum capacity to store the states during the search, along with pruning of successors after state

expansion. Experiments show signiﬁcant improvements compared to the standard form of the FF planner,

which is a representative planning system based on EHC and BFS.

1 INTRODUCTION

Planning is a ﬁeld of Artiﬁcial Intelligence that tries

to control complex systems autonomously. It has be-

come very useful for solving practical problems such

as design, logistics, games, space exploration, etc.

Planning systems or planners aim to generate a se-

quence of actions, called a plan, required to reach a

goal (a solution of a problem) from a given initial con-

ﬁguration of the problem.

Many planners use search techniques to select ac-

tions for building their plans such as the FF (Fast

Forward) planner that combines the execution of two

search algorithms: EHC (Enforced Hill Climbing)

and BFS (Best First Search). After performing sev-

eral experiments on problems of common planning

domains using FF, it was possible to identify some sit-

uations that could hamper the performance of search

algorithms. One situation happens when the search

process goes into a local maximum and gets stuck

at dead ends, which cause local search algorithms

as EHC to fail. Another situation refers to the lack

of memory space to store all the states generated by

complete search algorithms like BFS.

This paper presents a planning algorithm based on

a search algorithm known as LRTA* (Learning Real

Time A*). In order to overcome the difﬁculties de-

scribed above, we propose some modiﬁcations to the

standard LRTA* algorithm. A priority queue is used

to store generated states. States with high heuristic

values are placed near to the root, so they can be eas-

ily removed in case there is no memory space left.

Also we have introduced a policy for pruning succes-

sors rather than saving all of them after expanding a

state. An advantage of LRTA*, is that it can easily es-

cape from a local maximum, which is a problem for

local search techniques. The planning algorithm was

built upon JavaFF, a Java implementation of FF. Ex-

periments show signiﬁcant improvements compared

to the standard form of the FF planner.

The remainder of the paper is organized as fol-

lows. Section 2 describes related work and motiva-

tion for our proposal. Deﬁnition and characteristics

of the problem to be solved are provided in section

3. Background knowledge is described in Section 4.

In section 5 we propose the HPS-LTRA* algorithm

to improve the planning process. A description of the

experiments and their results is provided in section 6.

The conclusion is presented in section 7.

2 RELATED WORK

In the last decade there was a signiﬁcant increase in

the efﬁciency of planning systems. The FF planner is

the evolution of these systems. FF incorporated tech-

niques proposed by previous planners like HSP (Bon-

net and Geffner, 1998) which brought along some fur-

ther improvements.

475

M. F. Alves R. and R. Lopes C..

Solving Planning Problems with LRTA*.

DOI: 10.5220/0004449404750481

In Proceedings of the 15th International Conference on Enterprise Information Systems (ICEIS-2013), pages 475-481

ISBN: 978-989-8565-59-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

Just as HSP, the FF planner (Hoffmann and Nebel,

2001) carries out a forward state space search, using

a heuristic that estimates the goal distance by ignor-

ing the delete list of all actions. It is a very common

strategy used to relax the model and ﬁnd a solution

with lower cost and fewer restrictions. Unlike HSP

that assumes subgoals to be independent, FF takes

into account positive interactions that might happen

among subgoals. Also, FF accepts the selection of

more than one action at a time by building a graph of

a relaxed plan, a technique based on the Graphplan

system (Blum and Furst, 1995).

Another difference between FF and HSP is the in-

troduction of a novel kind of local search strategy to

avoid local maximum, employing a systematic search

and HC (Hill Climbing) algorithm, called EHC (En-

forced Hill Climbing). The EHC was developed to use

the concept of helpful actions during the expansion of

a state. The employment of helpful actions works like

a ﬁlter to return a set with just promising successors

of a state.

FF was the most successful automatic planner

in the “2nd International Planning Competition”.

Metric-FF a descendant of FF, was a top performer in

STRIPS and simple numeric tracks of the next com-

petition. Recent planners such as Conformant-FF,

Contingent-FF, Probabilistc-FF, MACRO-FF, MAR-

VIN, POND, JavaFF, DiFF and Ffha have employed

strategies introduced by FF (Akramifar and Ghassem-

Sani, 2010).

In the same line of FF, other recent planners com-

bine several search techniques. For instance, FD

(Fast Downward) (Helmert, 2006) computes plans by

heuristic search in the state space reachable from the

initial state. However, FD uses a very differentheuris-

tic evaluation function called the causal graph heuris-

tic that does not ignore the delete list unlike HSP and

FF. FD also uses some optimizations in search algo-

rithms within its strategy, as described below:

• Greedy best-ﬁrst search: a modiﬁed version

of (Russell and Norvig, 2009) greedy best-ﬁrst

search, with a technique called deferred heuris-

tic evaluation to mitigate the negative inﬂuence of

wide branching. It also deals with preferred op-

erators introduced by FD, similar to FF’s helpful

actions.

• Multi-heuristic best-ﬁrst search: a variation of

greedy best-ﬁrst search which evaluates search

states using multiple heuristic estimators, main-

taining separate open lists for each, and support-

ing the use of preferred operators too.

• Focused iterative-broadening search: a new sim-

ple search algorithm that does not use heuristic es-

timators, and instead reduces the vast set of search

possibilities by focusing on a limited operator set

derived from the causal graph.

The LAMA planner (Richter and Westphal, 2010)

follows the same idea offered by the other systems

cited above, that being the heuristic forward search.

It presented the best performance among all plan-

ners in the sequential satisﬁcing track of the “Inter-

national Planning Competition 2008”. LAMA uses

a variant of the FF heuristic and heuristic estimates

derived from landmarks, propositional formulas that

must be true in every solution of a planning task.

Two algorithms for heuristic search are implemented

in LAMA: a greedy best-ﬁrst search, aimed at ﬁnd-

ing a solution as quickly as possible; and a Weighted

A* search that allows balancing speed against solution

quality. Both algorithms are variations of the standard

methods, using open and closed lists.

The improvementmade to planning systems is not

only due to the advanceof heuristic functions, but also

to the creation and modiﬁcation of search algorithms.

In (Akramifar and Ghassem-Sani, 2010), a new

form of enforced hill climbing, called GEHC (Guided

Enforced Hill Climbing) was proposed to avoid dead

ends during the search by adapting an ordering func-

tion to expands the successors. It is faster and ex-

amines fewer states than EHC, even though in some

domains its plan quality was slightly inferior.

An approach of action planning based on SA (Sim-

ulated Annealing) is described at (Rames Basilio Ju-

nior and Lopes, 2012), which shows signiﬁcant re-

sults compared to algorithms based on enforced hill

climbing. One of the difﬁculties is to choose the val-

ues of the parameters used in SA.

(Xie et al., 2012) presents a method that use a

greedy best-ﬁrst search driven by a combination of

random walks and direct state evaluation, which bal-

ances between exploration and exploitation. This

technique was implemented in the Arvand planner of

IPC-2011, which improved coverage and quality of

its standard form. The algorithm scales better than

other planners especially in domains in which many

paths are generated between the initial state and the

goal. However, it does not have a good performance

in problems that require exhaustive search of large re-

gions of the state space.

A variation of a best-ﬁrst search algorithm is in-

troduced by (Stern et al., 2011), called PTS (Poten-

tial search), which is designed to solve a cost-bound

search problem. It orders the states in the open list

according to their potential that is generated by the

relation between a given heuristic and the optimal so-

lution cost. This algorithm showed good results in

relation to others that have a similar purpose, such as

those algorithms based on Weighted A*. But until the

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

476

desired solution is found, a state that has a slightly

higher potential but is farther from the goal is prefer-

able to a state that is very close to the goal.

In most of these works even with some modiﬁca-

tions, the algorithms are not capable of ﬁnding the so-

lution for all problems by using only one search tech-

nique. In general, it is necessary to use a combination

of search techniques. When the main techniques fail

in achieving a solution, the planners make use of a

complete search to reach the goal in order to guaran-

tee completeness. As a result, much time and effort

are wasted in a preliminary phase of those planning

algorithms.

3 CHARACTERIZATION OF THE

PROBLEM

A planning problem is deﬁned by a tuple of three el-

ements (A, I, G), where A is a set of actions, I refers

to the initial state, and G corresponds to a goal to be

achieved. Let P be the set of all propositions that rep-

resents facts in the world. The current state, or world,

is assigned to w and represents the subset of satis-

ﬁed propositions in P so that w ⊆ P in the world. In

STRIPS (Fikes and Nilsson, 1971), an action is repre-

sented by a triple (pre(a), add(a), del(a)) whose elements

belong to the set of propositions P and corresponds

respectively to its preconditions and effects - this last

through the add and delete lists. Action a is applica-

ble in w if w ⊇ pre(a) holds. To apply a in w, replace

w with w’ so that w’ = w - del(a) + add(a). It is assumed

that del(a) ∩ add(a) = {}. A planner should be capable

of ﬁnding a sequence of actions that change I into a

state that satisﬁes G.

Our work was developed based on the FF plan-

ner, more speciﬁcally on JavaFF. JavaFF (Coles et al.,

2008b) is a planner and also a planning framework. It

is implemented in Java, based on the source code of

CRIKEY (Coles et al., 2008a), which contains the ba-

sic structure of FF planner. JavaFF is not a full recon-

struction of FF planner, but it preserves the essence of

FF. It has several features necessary in a planner:

• functions and planning heuristics based on FF

planner;

• parser functions for domains and problems de-

scribed in PDDL (Planning Domain Deﬁnition

Language) (Fox and Long, 2003);

• implementation of EHC and BFS, which together

form the basis of FF planner;

• examples of domains and planning problems in

PDDL format.

After performing several tests in domains of plan-

ning problems offered by JavaFF by using the default

combination of EHC and BFS, it was possible to iden-

tify some general situations that could hamperthe per-

formance of any search algorithm, such as:

• planning problems with many states that generate

the same successors, demanding a large memory

space;

• states generating many successors, which also re-

quire too much memory space;

• states that generate themselves as successor. If the

planner does not treat repeated states the search

might go into a loop. Therefore, it is necessary

that these states be removed;

• states where the heuristic evaluation demands a

lot of time, usually because they are very far from

the goal. So, if these heuristics need to be re-

calculated every time that a state reappears in the

search, the process tends to be very slow;

• situations in which the search process goes into a

local maximum and gets stuck at dead ends, mak-

ing local search algorithms as EHC fail. In this

case, the strategy of FF and JavaFF is to invoke a

complete algorithm, called BFS, to solve the task

from scratch, thus losing all the previous process-

ing data, which expends more time and memory.

EHC and BFS can be affected by the difﬁculties

described above. In this work we propose to replace

the use of EHC and BFS with LRTA*, which is a

search algorithm guided by heuristics like EHC and

is as complete as BFS. Moreover, we made some op-

timizations on LRTA*, such as a heap with capacity

to store the states during the search, along with the

pruning of some successors after the expansion of a

state.

4 BACKGROUND

A search tries to determine a sequence of steps to

reach the goal from the initial state of a problem.

Search process can be compared with the process of

building a search tree whose root is the initial state.

The leaf nodes correspond to states waiting to be ex-

panded or states that possess an empty set of succes-

sors. For each step, the search algorithm chooses a

leaf node to expand until it reaches the goal. Search

algorithms generate multiple choices of paths, where

the decision of what path to follow is deﬁned by the

search strategy.

Some algorithms use uninformed search strate-

gies, also called blind search, where there is no infor-

mation about the distance between the current state

SolvingPlanningProblemswithLRTA*

477

and the goal. The most popular uninformed search

algorithms are: breadth-ﬁrst search, uniform-cost

search, depth-ﬁrst search, depth-limited search, iter-

ative deepening depth-ﬁrst search and bidirectional

search.

Informed search strategy, or heuristic search, uses

speciﬁc knowledge of the problem to choose the next

state to be expanded. This knowledge can be repre-

sented by a heuristic function that estimates the cost

of the current state to the goal. This estimate indicates

how promising the state is in terms of achieving the

objective. Under this approach, there are two types

of algorithms: off-line and on-line (Furcy, 2004). In

off-line algorithms, the deliberativephase, or planning

phase, is carried out completely before the execution

phase. Therefore, it needs all the time and space nec-

essary to ﬁnd a solution, and then move onto the exe-

cution. On the other hand, on-line algorithms, known

as real time search algorithms, alternate the deliber-

ative phase and execution during the search process.

They have constraints related to time and information,

i.e., they do not have enough information about the

search space, and after some time they need to return

a solution. In general, on-line algorithms can ﬁnd so-

lutions faster than off-line algorithms.

A* is an off-line algorithm which combines

uniform-cost search with heuristic search, using the

following evaluation function to determine how good

a state is: f(n) = g(n) + h(n), where g(n) is the amount

spent until reaching the state n and f(n) is the esti-

mated cost to reach the goal from n. This algorithm

had been described ﬁrstly by (Hart et al., 1968) and

became known as A. When used with an admissi-

ble heuristic, it reaches the optimal solution, and is

known as A*. However, it is impractical on a large

scale because it keeps in memory all possible paths

during the search process.

LRTA* (Learning Real Time A*) (Korf, 1990)

could be seen as an on-line version of A*. During

the search for a solution, it updates the heuristic val-

ues of the states, forcing it to “learn” whether a path

is good or not. When the solution coming from the

search is executed, more information is obtained from

the environment. In this way, better paths can be ob-

tained later. A basic description of the LRTA* fol-

lows. It begins in the initial state s

initial

and then

transfers to the next step where it moves to the most

promising successor according to its evaluation func-

tion. The search ends when the goal s

goal

is found. At

each iteration, the algorithm updates the estimative of

the distance between the current state s

current

and the

goal, giving more information about the environment

to help the search process.

Algorithm 1: LRTA*(s

initial

goal

1: s

current

← s

initial

2: loop

3: s

′

← arg min

′′

∈succ(s

current

)

(c(s

current

′′

) + h(s

′′

))

4: if s

current

= s

goal

then

5: h(s

current

) ← h

current

)

6: else

7: h(s

current

) ← max(h(s

current

),min

′′

∈succ(s

current

)

(c(s

current

′′

) +

h(s

′′

)))

8: end if

9: if s

current

= s

goal

then

10: return

success

11: end if

12: s

current

← s

′

13: end loop

As shown in Algorithm 1, its executioncan be de-

scribed in the following manner: a h value is associ-

ated to each state. The h

(s) corresponds to the initial

value of h for a state s. First, the initial state s

initial

is deﬁned as current state s

current

. LRTA* selects a

successor to be the new current state; it is made by

evaluating the minimum sum c(s

current

′′

) + h(s

′′

) of

all adjacent states of s

current

, where ties are broken at

random (line 3). Then, the heuristic value of the cur-

rent state h(s

corrente

) is updated (line 4-8). After that,

it moves to the selected successor (line 12) and a new

iteration starts. This process is repeated until the goal

is reached.

5 HPS-LRTA*

LRTA * is guided by a heuristic evaluation in the

same way as EHC and is as complete as BFS. In

this section we present the algorithm HPS-LRTA*

(Heap&PruningSuccessors-LRTA*), an adaptation of

LRTA*, for generating plans more efﬁciently and re-

ducing execution time. HPS-LRTA* also allows for

the balancing and storage of states in memory, which

handles the lack of space during the search. Details

concerning these improvements are described below.

• states generated by the algorithm will be stored

in a heap that work as a priority queue, which is

ordered by heuristic values at each state. Thus,

states with higher values will be closer to the root

facilitating their removal if there is not enough

memory. The chance of using states with higher

values of priority again during the search is very

low;

• keeping the states with some structure prevents

the reevaluation of its heuristic value every time

it reappears in the search. In cases where the goal

is far away, this calculation is very slow. Further-

more, storing states ensures that when a heuristic

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

478

of a saved state is updated, it will never be reset.

This is the way LRTA* learns;

• the learning process is one of the greatest ad-

vantages of the algorithm, which is particular to

LRTA*. This is realized by updating the heuristic

value of the current state using the result obtained

from the evaluation function of the best succes-

sor, which allows a more accurate evaluation of

this state if it reappears in the search;

• if a state is generated several times in the search,

just one instance of it remains in the heap, which

saves space;

• when a state generates itself as successor, that suc-

cessor will be pruned, which avoids loops;

• HPS-LRTA* uses the same heuristic function ex-

istent in FF. By considering that such heuristic is

a good function for estimating the number of ac-

tions necessary for achieving the goal, it believes

that states with high heuristic values will not be

promising for the search. Based on this aspect,

and by the fact that there are problems that gener-

ate many successors with the same heuristic val-

ues during the expansion of a state, pruning suc-

cessors with higher heuristics could be a good op-

tion to save space. For this reason, only some of

the successors with lower heuristics will be stored,

while the others will be pruned. Based on experi-

ments, it was observed that a rate of pruning cor-

responding to 0.7 provided the best results;

• another important parameter is the heap capacity

that determines how many states can be stored.

If the search exceeds the heap capacity, its root

(which contains the state with the worst heuristic)

will be removed repeatedly until the capacity re-

turns to normal;

• every state needs to keep a reference to its par-

ent state. This is necessary for the occurrence of

backtracking. The use of backtracking allows the

search process to escape from local maximums

and dead ends, which is something that cannot be

avoided in EHC. Without backtracking, execution

could stop and lose all existing processing data.

Algorithm 2 shows the pseudo-code of the algo-

rithm HPS-LRTA*. The algorithm starts by initial-

izing the heap Q (line 1). The s

current

variable (cur-

rent state) is instantiated to the initial state (line 2)

and added to the heap (line 3). Next, the main loop

starts. Firstly, a balance of the heap is made if neces-

sary. It consists of removing its root repeatedly until

its capacity becomes less than c (maximum capacity

of the heap). This is necessary for allowing enough

memory space during the search (lines 5-7). A test is

Algorithm 2: HPS-LRTA*(s

initial

goal

,r,c).

1: Q ← {}

2: s

current

← s

initial

3: Q.add(s

current

)

4: loop

5: while Q.length() > c do

6: Q.remove()

7: end while

8: if s

current

= s

goal

then

9: return

success

10: end if

11: S ← {arg min

′′

∈succ(s

current

)

(c(s

current

′′

) + h(s

′′

))}

12: s

′

← S[random(S.length())]

13: h(s

current

) ← max(h(s

current

),min

′′

∈succ(s

current

)

(c(s

current

′′

) +

h(s

′′

)))

14: Q.increaseKey(s

current

,h(s

current

))

15: if s

′

/∈ Q then

16: Q.add(s

′

)

17: end if

18: for i ← 0 to (S.length() × r) do

19: if S[i] /∈ Q then

20: Q.add(S[i])

21: end if

22: end for

23: s

current

← s

′

24: end loop

carried out, which veriﬁes if s

current

reaches the spec-

iﬁed goal. When the goal is achieved, the algorithm

stops the execution and returns success (lines 8-10).

In the next step the expansion phase begins. It

starts by evaluating the minimum sum c(s

current

′′

h(s

′′

) for all successors. These successors make

current

their parent, and a set S keeps all successors

that have the lowest h value in this expansion. If a

successor state is exactly the same of scurrent it will

be pruned (line 11). From all the successors at S, one

of them is chosen randomly (line 12).

The heuristic value h(s

current

) of the current state

current

is updated with the lowest evaluation of its

successors (line 13). With this new value, the state

must be updated in the heap. This updating might

take this state close to the root if its heuristic gets

worse (line 14). The selected successor is added to

the heap if it is not already there (lines 15-17). The

same happens with a percentage of the successors in

the set S, and the rest are pruned to save space (lines

18-22). The rate of pruning is given by parameter r.

Finally, the move to the selected successor is made

(line 23), and the algorithm realizes another iteration.

6 EXPERIMENTS AND RESULTS

As already mentioned above, our planning system

was built upon JavaFF, a Java implementation of FF.

Essentially, the calls of EHC and BFS were replaced

SolvingPlanningProblemswithLRTA*

479

by a call to HPS-LRTA*. In order to make a compar-

ative analysis between FF and the proposed planner,

both approaches solved planning problems from the

following domains:

• driverlog: warehouse management domain, from

where trucks transport crates and then the crates

must be stacked on pallets at their destinations;

• depots: this domain involves driving trucks,

which deliver packages between locations. The

complication is that the trucks require drivers who

must walk between trucks in order to drive them.

The paths for walking and the roads for driving

form different maps on the locations;

• pipesworld: pipeline domains, where pipes are

used to connect areas.

Usually, each domain has 20 associated problem

instances of increasing size, measured in terms of the

numbers of constants and related goals in each in-

stance (Long and Fox, 2006). In our tests, the driver-

log domain has 20 problems where 01-08 are simple

problems, 09-13 add more location and 14-20 apply

more resources. Depots contains 22 problems which

01-06 are small problems, 07-09 increase the num-

ber of surfaces, 10-12 augment the locations, 13-15

have more surfaces and locations, 16-18 add more

general resources such as trucks and hoists, and 19-

22 increase the problem scale. Pipesworld is a com-

plex domain that contains 50 problems, where even

the ﬁrst 10 problems are very hard to solve.

Software and hardware conﬁgurations include op-

erating system Linux OpenSuse 12.1, processor Intel

Centrino (dual core of 1.4GHz each one), 1.9GiB of

memory and hard disk SATA-82801 of 160GB.

The experiments were carried out by running

JavaFF which combines EHC and BFS, and the al-

gorithm proposed in this paper, HPS-LRTA*. For

each one of these approaches, ﬁfty executions were

realized for each problem of the domains mentioned

above. In order to allow comparative analysis, we

chose only those problems that ﬁnished their execu-

tion in at most 30 minutes in both approaches.

Figure 1 depicts the average runtime for the prob-

lems solved by both approaches.

Table 1 shows the rate of failed executions due to

lack of memory space and their average runtime.

Note that for more difﬁcult problems, the pro-

posed algorithm has a better runtime in most cases.

Moreover, it manages to avoid the lack of memory

space, which might cause the failure of the search.

This failure might happen when FF is employed. For

instance problem 08 in the depots domain and prob-

lem 02 in the pipesworld domain had respectively

86% and 100% of failed executions in the experi-

Figure 1: Average time to successful executions.

Table 1: Rate of failed executions and average time.

Problem Failed Time

EHC + BFS HPS - LRTA* EHC + BFS HPS - LRTA*

Depots 01 0% 0% 0,20 sec. 0,20 sec.

Depots 02 0% 0% 0,50 sec. 1,30 sec.

Depots 03 0% 0% 65,36 sec. 14,93 sec.

Depots 07 8% 0% 202,68 sec. 86,90 sec.

Depots 08 86% 0% 18,41 sec. 940,66 sec.

Depots 13 0% 0% 29,63 sec. 162,81 sec.

Driverlog 01 0% 0% 0,07 sec. 0,25 sec.

Driverlog 02 0% 0% 0,82 sec. 0,69 sec.

Driverlog 03 0% 0% 0,17 sec. 0,54 sec.

Driverlog 04 0% 0% 0,95 sec. 0,83 sec.

Driverlog 05 0% 0% 0,53 sec. 1,07 sec.

Driverlog 06 0% 0% 1,03 sec. 1,23 sec.

Driverlog 07 0% 0% 0,40 sec. 1,24 sec.

Driverlog 08 0% 0% 2,98 sec. 2,67 sec.

Driverlog 09 0% 0% 4,84 sec. 5,25 sec.

Driverlog 10 0% 0% 0,88 sec. 2,55 sec.

Driverlog 11 0% 0% 5,77 sec. 15,31 sec.

Driverlog 12 0% 0% 158,20 sec. 221,46 sec.

Driverlog 13 5% 0% 52,33 sec. 37,02 sec.

Driverlog 14 16% 0% 204,02 sec. 145,39 sec.

Pipesworld 01 0% 0% 0,44 sec. 0,75 sec.

Pipesworld 02 100% 0% ................... 41,96 sec.

Pipesworld 03 0% 0% 136,44 sec. 79,69 sec.

Pipesworld 04 4% 0% 83,52 sec. 50,56 sec.

Pipesworld 05 0% 0% 38,35 sec. 44,25 sec.

Pipesworld 06 4% 0% 49,46 sec. 54,25 sec.

ments. This occurs when EHC reaches a dead end,

and BFS is launched. BFS makes a complete search

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

480

that keeps all the states in memory, which might cause

lack of memory space if the search runs for a long

time.

7 CONCLUSIONS

When concerning simple problems where the initial

state is closer to the goal and few states are generated,

the heuristic proposed by the FF is a useful guide for

search algorithms. Therefore, an agile algorithm such

as EHC can solve problems faster.

However, for more difﬁcult problems in which

many states should be generated and many actions are

required to produce the goal, EHC is inclined to fail

by getting stuck at dead ends. In this case the EHC

execution stops and all the time spent and processing

realized thus far is lost. When this happens, FF starts

a new search from the scratch by using BFS, which

is characterized by a low response time. Also, BFS

needs more space to store the states, which cause it

fail sometimes. In these situations the algorithm HPS-

LRTA* is more efﬁcient, due to the fact that it can es-

cape from a local maximum, avoiding dead ends, and

it also balances the memory space. An improvement

that could be put into practice is to use the concept

of helpful actions in the algorithm, as it is the case

with EHC. Helpful actions ﬁlter the most promising

states before the expansion phase, which accelerates

the search process. Also, the authors are planning

to change HPS-LRTA* with respect to the expansion

state. The idea is to generate successors until one

that is better evaluated than the current state, is found.

In doing this we believe that HPS-LRTA* can solve

small problems as fast as EHC.

ACKNOWLEDGEMENTS

This research is supported in part by the Coordination

for the Improvement of Higher Education Personnel

(CAPES), Research Foundation of the State of Minas

Gerais (FAPEMIG) and Faculty of Computing (FA-

COM) from Federal University of Uberlˆandia (UFU).

REFERENCES

Akramifar, S. A. and Ghassem-Sani, G. (2010). Fast for-

ward planning by guided enforced hill climbing. Eng.

Appl. Artif. Intell., 23(8):1327–1339.

Blum, A. and Furst, M. L. (1995). Fast planning through

planning graph analysis. In Proceedings of the 14th in-

ternational joint conference on Artiﬁcial intelligence

- Volume 2, IJCAI’95, pages 1636–1642, San Fran-

cisco, CA, USA. Morgan Kaufmann Publishers Inc.

Bonnet, B. and Geffner, H. (1998). Hsp: Heuristic search

planner. Entry at the AIPS-98 Planning Competition,

Pittsburgh.

Coles, A. I., Fox, M., Long, D., and Smith, A. J. (2008a).

Planning with problems requiring temporal coordina-

tion. In Proceedings of the Twenty-Third AAAI Con-

ference on Artiﬁcial Intelligence (AAAI 08).

Coles, A. I., Fox, M., Long, D., and Smith, A. J. (2008b).

Teaching forward-chaining planning with javaff. In

Colloquium on AI Education, Twenty-Third AAAI

Conference on Artiﬁcial Intelligence.

Fikes, R. and Nilsson, N. J. (1971). Strips: A new approach

to the application of theorem proving to problem solv-

ing. In Cooper, D. C., editor, IJCAI, pages 608–620.

William Kaufmann.

Fox, M. and Long, D. (2003). Pddl2.1: An extension to pddl

for expressing temporal planning domains. Journal of

Artiﬁcial Intelligence Research, 20:2003.

Furcy, D. A. (2004). Speeding up the convergence of on-

line heuristic search and scaling up ofﬂine heuristic

search. PhD thesis.

Hart, P., Nilsson, N., and Raphael, B. (1968). A Formal Ba-

sis for the Heuristic Determination of Minimum Cost

Paths. IEEE Transactions on Systems Science and Cy-

bernetics, 4:100–107.

Helmert, M. (2006). The fast downward planning system.

Journal of Artiﬁcial Intelligence Research, 26:191–

246.

Hoffmann, J. and Nebel, B. (2001). The ff planning system:

Fast plan generation through heuristic search. Journal

of Artiﬁcial Intelligence Research, 14:2001.

Korf, R. E. (1990). Real-time heuristic search. Artif. Intell.,

42(2-3):189–211.

Long, D. and Fox, M. (2006). The international planning

competition series and empirical evaluation of ai plan-

ning systems. In Paquete, L., Chiarandini, M., and

Basso, D., editors, Proceedings of Workshop on Em-

pirical Methods for the Analysis of Algorithm.

Rames Basilio Junior, R. and Lopes, C. (2012). An ap-

proach to action planning based on simulated anneal-

ing. In Systems, Man, and Cybernetics (SMC), 2012

IEEE International Conference on, pages 2085 –2090.

Richter, S. and Westphal, M. (2010). The lama planner:

Guiding cost-based anytime planning with landmarks.

Russell, S. J. and Norvig, P. (2009). Artiﬁcial Intelligence:

A Modern Approach. Prentice Hall, 3rd edition.

Stern, R., Puzis, R., and Felner, A. (2011). Potential search:

A bounded-cost search algorithm. In ICAPS.

Xie, F., Nakhost, H., and M¨uller, M. (2012). Planning via

random walk-driven local search. In ICAPS.

SolvingPlanningProblemswithLRTA*

481
