Internet of Things Aware WS-BPEL Business Process

Dulce Domingos, Francisco Martins and Carlos C

andido

LaSIGE - Faculty of Science, Lisbon University, Campo Grande, Lisbon, Portugal

Keywords:

Internet of Things, Business Process, WS-BPEL.

Abstract:

Business process can beneﬁt from the deployment of the Internet of Things, since they can use sensor context

information to optimize their execution and to react to emergent situations in real-time. Nowadays, the WS-

BPEL is the de-facto standard language used to deﬁne processes through the composition of web services.

However, as this language is based on the service orchestration paradigm, it complicates the way process can

use context information. This paper presents a WS-BPEL extension that includes context variables. These vari-

ables maintain sensor values. Their updates are done automatically by using the publish/subscribe paradigm.

In addition, to support more reactive behaviours, this extension also includes the when-then construct. To

realize this extension, we use the language transformation mechanisms, so it can be as much independent as

possible from the process execution engine.

1 INTRODUCTION

The Internet of Things (IoT) aims at bridging the

gap between the physical world and its representation

within information systems. It will deﬁnitely have a

deep impact on business processes, since they can use

the context information IoT provides to optimize their

execution and to adapt to environment changes, in real

time.

The WS-BPEL (OASIS, 2007) is a OASIS stan-

dard used to deﬁne processes as web services compo-

sitions, i.e., orchestrations of web services. To facil-

itate the IoT integration into business processes, re-

cent works provide the information and functionali-

ties of physical objects as web services. These web

services can be implemented directly in sensors or

through middleware (Zeng et al., 2011). The service-

oriented approach has the advantage of facilitating in-

teroperability as well as it also encapsulates hetero-

geneity and speciﬁcities of physical objects. As the

WS-BPEL is based on service orchestration, the sen-

sor information that web services provide can be eas-

ily integrated into processes by using a synchronous

request/reply paradigm.

However, with this paradigm, if a process needs

to have updated information about environment

changes, it has to get sensors information periodically,

overloading the process execution engine and increas-

ing the number of exchanged messages between the

sensor network and the execution engine.

The work we present in this paper aims at simpli-

fying the use of updated sensor context information in

business processes and at deﬁning more reactive pro-

cesses. We deﬁne a WS-BPEL extension to include

context variables, which are update asynchronously

through the publisher/subscriber paradigm, according

to the WS-Notiﬁcation standard. We support context

variable with a language transformation. This option

has the advantage of being independent from the pro-

cess execution engine.

In addition, our WS-BPEL extension also include

the when-then construct. The when condition can in-

clude context variables. We also support this con-

struct with a language transformation. However, our

implementation depends on an auxiliary service that

detects the modiﬁcation of variable values. In our pro-

totype, we use Apache ODE listeners (Apache ODE,

2013).

We present a motivating scenario in the next sec-

tion. Section 3 resumes the standards we use in this

work. We describe related work in section 4 and our

WS-BPEL extension in section 5. The last section in-

cludes conclusions and future work.

2 MOTIVATING SCENARIO

Our motivating scenario is based on a common busi-

ness application: the transportation of goods.

A distribution company receives a container of

505

Domingos D., Martins F. and Cândido C..

Internet of Things Aware WS-BPEL Business Process.

DOI: 10.5220/0004449905050512

In Proceedings of the 15th International Conference on Enterprise Information Systems (ICEIS-2013), pages 505-512

ISBN: 978-989-8565-60-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

strawberries on a pier discharge. After unloading, the

container is placed on a truck and transported to the

distribution center, from where they are distributed to

retail stores. The container has temperature sensors

and they are used to monitor the strawberries state.

During transportation, the temperature inside the con-

tainer raises above the value that guarantees strawber-

ries quality. If the company maintains the destination

of strawberries, they will reach consumers in bad con-

ditions. To avoid this waste, when they get the infor-

mation about the raise of temperature, they change the

container destination and it is forwarded to a closer

distribution center.

In this use case scenario, we illustrate the beneﬁts

of monitoring context information, i.e., the tempera-

ture of the container, and consequently, the possibil-

ity to change the process to react to context modiﬁca-

tions.

To include this behaviour into a WS-BPEL pro-

cess deﬁnition, the modeler has to deﬁne the interac-

tion with sensors, deviating his focus from the main

process logic.

3 CONCEPTS

In this section we present an overview of WS-BPEL.

Before that, we present the other standards we use in

this work.

3.1 Web Services Addressing

Web Services Addressing (WS-Addressing) (Box and

et al., 2004) deﬁnes transport-neutral mechanisms

that allow web services to communicate addressing

information. This speciﬁcation deﬁnes elements to

uniquely identify web services endpoints using Ex-

tensible Markup Language (XML). One of the ele-

ments is the EndPointReference (EPR), whose ﬁeld

address represents the web service address. Be-

yond this ﬁeld, an EPR offers optional ﬁelds (such as

the ReferenceParameters), for instance, to distinguish

EPRs with the same address.

3.2 Web Services Description Language

Web Service Description Language (WSDL) (Chris-

tensen et al., 2001) is a XML-based language used

to describe the functionalities that web services offer.

A WSDL web service description includes its name,

address (EPR), the service binding (deﬁnes the proto-

cols), operations available, exchanged messages, and

possible faults. It contains all the information needed

to contact a web service.

3.3 Web Services Notiﬁcation

Web Services Notiﬁcation (WSN) (OASIS, 2006) de-

ﬁnes a set of speciﬁcations that aim at deﬁning how

web services interact using notiﬁcations or events.

The communication uses the publisher/subscriber

paradigm, where an entity can publish information to

others without having to know them in advance. The

speciﬁcations provide WSDL interfaces. We point out

the interfaces for two services: the publisher service

(NotiﬁcationProducer) and the service that receives

notiﬁcations (NotiﬁcationConsumer). They specify

the minimum operations that each service must pro-

vide: the publisher service has to provide the sub-

scribe and get-CurrentMessage operations, and the

consumer service has to provide the operation to re-

ceive notiﬁcations, the notify operation. When invok-

ing the subscribe operation, the subscriber must de-

ﬁne, among other things, the EPR to where the notiﬁ-

cations should be sent.

3.4 Web Services Business Process

Execution Language

Web Services Business Process Execution Language

(WS-BPEL) (OASIS, 2007) is the OASIS standard

executable language for deﬁning business processes

through web services orchestration. A business pro-

cess deﬁnition includes two elements: a WSDL ﬁle

that describes the business process functionalities

(web services) with their messages data structures,

services addresses, among others, and a WS-BPEL

ﬁle that deﬁnes the business process logic.

The WS-BPEL includes different types of activi-

ties, such as ﬂow control activities (If, While, Scope,

Flow), communication activities (Receive, Reply, In-

voke), assign values activities (Assign), fault handlers

(Throw, Rethrow), to name a few. We can declare vari-

ables of any primitive type, complex type (consisting

of several primitive data types), and messages. Mes-

sage variables are used almost exclusively in commu-

nication activities. Variables can be global or local, if

declared within a Scope.

Processes in WS-BPEL export and import func-

tionalities by using web services. Web services are

modeled as partnerLinks. Every partnerLink is char-

acterized by a partnerLinkType, which is deﬁned in

the WSDL deﬁnition. A partnerLinkType speciﬁes

the role and the type of a partner. An input commu-

nication activity is associated with the MyRole and an

output communication activity is associated with the

PartnerRole.

In order to distinguish process instances, WS-

BPEL provides the Correlation mechanism. A corre-

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

506

lationSet is deﬁned by 1) the primitive data type that

will be used and 2) the rule set (one per message type).

The correlationSet is associated with communication

activities. Each correlationSet can only be initialized

once and, if we use it in an Invoke, we have to deﬁne

when the Correlation is established: in the sending

operation, in response, or in both. The Correlation-

Sets property deﬁnes, through XPATH, the message

elements exchanged by processes that identiﬁes each

conversation (i.e., each process instance).

The WS-BPEL standard supports extensibility, by

allowing namespace-qualiﬁed attributes to appear in

any WS-BPEL element and by allowing elements

from other namespaces to appear within WS-BPEL

deﬁned elements. In addition, WS-BPEL provides

two explicit extension constructs: extensionAssign-

Operation and extensionActivity.

All extensions used in a process must be declared.

This statement is made by inserting into the Exten-

sions construct language the namespaces associated

with the extensions and the MustUnderstand attribute

with the value yes or no, which states whether the pro-

cess execution engine has to support the extension.

There are two different options to realize an ex-

tension (Kopp et al., 2011). With a ”BPEL Language

Transformation”, extension constructs are translated

into standard BPEL constructs. The generated stan-

dard BPEL code can be deployed on a process execu-

tion engine that ignores the extension. With the other

option, the ”BPEL runtime engine”, the extension is

realized by changing the process execution engine in

order to support the additional functionalities.

3.5 XSL Transformations

Extensible Stylesheet Language Transformations

(XSLT) (Clark et al., 2007) is a speciﬁcation that de-

ﬁnes the syntax and semantics of a language to trans-

form and render XML documents. XSLT is designed

for use as part of the Extensible Stylesheet Language

(XSL), which is a style language for XML. XSL in-

cludes an XML vocabulary to specify formatting and

uses XSLT to describe the document transformation.

4 RELATED WORK

In our work, we use context with the same meaning

as George et al. (George and Ward, 2008; George,

2008). These authors deﬁne context as an environ-

ment state, which is external to the process, whose

value can change independently of the process lifecy-

cle, and can inﬂuence process execution.

Traditionally, context information is obtained ac-

cording to a synchronous request/response paradigm,

and business processes use it in predeﬁned points.

They use context information to: (i) determine the ser-

vices that compose processes (Yu and Su, 2009), (ii)

choose between multiple implementations for a spe-

ciﬁc service (Ranganathan and McFaddin, 2004), or

(iii) determine whether a service should participate in

future compositions (Karastoyanova et al., 2005).

In (Wieland et al., 2007), the authors propose an

extension to WS-BPEL, named Context4BPEL, in or-

der to explicitly model how context inﬂuences work-

ﬂows. The Context4BPEL is deﬁned according to the

WS-BPEL extension mechanisms. This extension in-

cludes mechanisms to: (1) manage context events to

allow the asynchronous reception of events; (2) query

context data, and (3) evaluate transition conditions

based on context data. However, Context4BPEL is

realized as a ”BPEL Runtime Extension” and conse-

quently also needs that the process execution engine

supports it. In addition, the context information man-

agement depends on the Nexus platform.

In (Wieland et al., 2009), the authors propose

a WS-BPEL extension that includes reference vari-

ables. With this kind of variables, the services can

exchange pointers to variables instead of their val-

ues. Pointers are represented with EPRs. Accord-

ing to the value of an attribute of the extension, ref-

erences are evaluated (1) upon activation of Scope,

(2) before variables are used, (3) periodically, or (4)

through an event sent from a external service. This ex-

tension is realized as a ”BPEL Language Transforma-

tion”, replacing references with WS-BPEL variables,

inserting links to partners and interaction activities.

The type (4) of references evaluation is similar to our

work: the transformation adds a constructor onEvent

to the process deﬁnition. However, these authors do

not state how the external service addresses the event

to the onEvent web service. Additionally, references

evaluation depends on the RRS Service (Reference

Resolution Service), a speciﬁc service available on

the platform the authors propose.

George et al. (George and Ward, 2008; George,

2008) also propose a solution based on context vari-

ables. These authors extend WS-BPEL by adding

new attributes to variables. However, the process def-

inition must also contain explicitly the Invoke oper-

ation to realize the subscription. To realize the ex-

tension, they use a ”BPEL Runtime Extension” op-

tion, by changing the process execution engine, and

they distinguish process instances through the Muse

Apache platform (Apache Muse, 2013).

InternetofThingsAwareWS-BPELBusinessProcess

507

5 IoT WS-BPEL EXTENSION

In this section we present how we extend the WS-

BPEL with context variables and with the when-then

construct. We also describe how we realize the exten-

sion and we present an overview of our prototype.

5.1 Context Variables - Language

Extension

Our main goal is to simplify the access to context

information within WS-BPEL processes through the

new concept of context variable. This way, each vari-

able represent the current value of a speciﬁc sensor.

As the language already provides a constructor for

variables, we decided to deﬁne context variables by

adding new attributes to the constructor. The new

attributes represent the minimum information neces-

sary to realize the subscribe operation according to

the WS-Notiﬁcations standard, and, consequently, the

minimum information required to identify a sensor

through a web service.

The following example illustrates the deﬁnition of

a context variable named tempVar, which maintains

the value of a sensor. The web service that provides

this value is identiﬁed by the attribute publisherEPR

with the topic Temperature.

Example of a variable context deﬁnition:

...

<variable name="tempVar" Type="xsd:anyURI"

iotx:topic="Temperature"

iotx:publisherEPR="http://192.168.1.43:8081/

pubService"/>

</variables>

In addition, the extension has to be deﬁned in the

process. In the following we present the extension

deﬁnition, and its namespace and preﬁx.

Example of the extension deﬁnition:

<bpel:process name="myProcess"

...

xmlns:iotx="http://iot.extensions">

<extension namespace="http://iot.extensions"

mustUnderstand="yes"/>

</extensions>

...

</bpel:process>

In the next section we describe the realization of

this part of our extension.

5.2 Context Variables: Language

Transformation

As previously mentioned, WS-BPEL extensions can

be realized as a runtime extension or as a model trans-

formation. We realize the context variable part of

our WS-BPEL extension with a model transforma-

tion. This option has the advantage of making it inde-

pendent of the process execution engines. However,

as the model transformation operation adds new ac-

tivities, variables, etc., the process that is executed do

not match exactly the process the modeler deﬁned.

In the following, we detail the transformation we

realize. We use the WS-Notiﬁcation standard in the

communication between processes instances and sen-

sors. This transformation includes editing the WS-

BPEL ﬁle and creating a WSDL ﬁle.

5.2.1 Editing the WS-BPEL File

Firstly, we remove the extension attributes from the

context variables. These variables are now WS-BPEL

standard variables of type xsd: anyURI.

Next, we change the main Sequence of the pro-

cess by inserting a Flow activity after the ﬁrst Receive

activity, named Start. Inside the Flow activity, we de-

ﬁne a Sequence activity to include the original pro-

cess deﬁnition and a Sequence activity for each con-

text variable. This way, Sequence activities that re-

ceive notiﬁcations run in parallel with the Sequence

activity that has the original process deﬁnition.

The Sequence activities of each context variable

include two main operations: the subscription opera-

tion and the reception of notiﬁcations.

Subscription Operation. The subscription operation

is done with an Invoke activity. This Invoke activity

calls the publisher EPR deﬁned in the context vari-

able. As the subscription operation is a two-way op-

eration, we deﬁne two variables: the inputVariable

and the outputVariable. Before the Invoke activity,

we use an Assign activity to initialize the message the

Invoke sends to the publisher. We format this mes-

sage according to the WS-notiﬁcation standard. The

message is initialized with the topic declared in the

context variable and the EPR to where the publisher

sends notiﬁcations. The EPR is generated by concate-

nating the process name with the name of the context

variable. The output variable is initialized in the In-

voke response. As we initialize the Correlation in the

Invoke response, we declare its initialization in the re-

sponse. Below we show the subscription message and

the Invoke activity.

Example of subscription message (Subscribe):

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

508

<wsnt:Subscribe ...>

<wsnt:ConsumerReference>

<wsa:Address ... >

http://192.168.1.71:8080/ode/processes/

myProcesstempVar

</wsa:Address>

</wsnt:ConsumerReference>

<wsnt:Filter>

<wsnt:TopicExpression ... > Temperature

</wsnt:TopicExpression>

</wsnt:Filter>

</wsnt:Subscribe>

Invoke to perform the subscription:

<bpel:invoke name="Invoke"

partnerLink="pubSubPartnerLink"

operation="Subscribe"

portType="wsntw:NotificationProducer"

inputVariable="subscribeRequest"

outputVariable="subscribeResponse">

<bpel:correlations>

<bpel:correlation set="notifyCorrelationSet"

initiate="yes"

pattern="response" />

</bpel:correlations>

</bpel:invoke>

Operation to Receive Notiﬁcations. Processes re-

ceive notiﬁcations through a Receive activity (i.e., an

inbound message activity). This activity uses a vari-

able to save the notiﬁcations and the Correlation. In

the following we illustrate the Receive activity.

Operation to receive notiﬁcations:

<bpel:receive name="Receive"

partnerLink="pubSubPartnerLink"

operation="Notify"

portType="wsntw:NotificationConsumer"

variable="NotificationMsg">

<bpel:correlations>

<bpel:correlation set="notifyCorrelationSet"

initiate="no" />

</bpel:correlations>

</bpel:receive>

Finally, after the Receive activity, we add an As-

sign activity to copy the value of the notiﬁcation mes-

sage to the context variable, as we present in the fol-

lowing.

Assign operation that updates the context variable:

<bpel:assign validate="no" name="updateVar">

<bpel:copy>

<bpel:from part="Notify"

variable="NotificationMsg">

<bpel:query queryLanguage="urn:oasis:

names:tc:wsbpel:2.0:sublang:xpath1.0">

wsnt:NotificationMessage/wsnt:Message

</bpel:query>

</bpel:from>

<bpel:to variable="tempVar" />

</bpel:copy>

</bpel:assign>

All process instances use the same port to receive

notiﬁcations. To distinguish instances, we use the

Correlation. In the following we describe how we

use the Correlation to guarantee that each subscriber

(process instance) receives its notiﬁcations.

As each context variable maps to a different sub-

scription, we deﬁne a correlationSet for each context

variable. We use the Correlation with two messages

(SubscriptionResponse and Notify). Thus we deﬁne

two rules and we use them in all the correlationSets.

The rules states that, for each message, the correla-

tions use the ﬁeld ReferenceParameters of the ele-

ment SubscriptionReference. The data type has to

be the same as the ﬁeld ReferenceParameters, i.e.,

anyURI (any type). We use the Correlation in the In-

voke response, where the correlationSet is initialized,

and in the Receive.

5.2.2 Adding WSDL Files

Each context variable is related with two services:

the subscribe service and the service to where noti-

ﬁcations are sent (the consumer service). We deﬁne

these services in an additional WSDL ﬁle, which the

transformed WS-BPEL process imports. This way,

we avoid modifying the original WSDL ﬁle. We get

the address of the subscribe service directly from the

deﬁnition of the context variable, and we generate the

address of the consumer service by concatenating the

process name with the name of the context variable.

We import the operations of each service from the

WSDL ﬁles of the WS-Notiﬁcation standard. This

WSDL ﬁle also includes the Correlation properties

we use in the WS-BPEL transformation.

5.3 When-then: Language Extension

We deﬁne the when-then as a top level construct. It

is not an activity. As event handlers, when-then con-

structs are installed in parallel with each other. This

construct has a condition and an activity, which is ex-

ecuted once, when the condition becomes true. In

the following we present the when-then syntax and

an example. In this example, we illustrate the use of

a when-then construct that executes a Sequence with

two empty activities when the value of tempVar is

greater than 35.

The when-then syntax:

<iotx: when standard-attributes>

<bpel:condition expressionLanguage="anyURI"?>

InternetofThingsAwareWS-BPELBusinessProcess

509

bool-expr

</bpel:condition>

activity

</iotx:when>

A when-then example:

...

<iotx:when name="testeWhen">

<bpel:condition>$tempVar > 35</bpel:condition>

</sequence>

</iotx:when>

...

</process>

5.4 When-then: Language

Transformation

We also realize this part of the extension with a lan-

guage transformation approach. However, we use an

auxiliary web service to detect the modiﬁcation of

variable values, avoiding busy waiting. In our im-

plementation, these web services use the Listeners of

Apache ODE.

In the following we detail the language transfor-

mation, which includes editing the WS-BPEL ﬁle and

creating a WSDL ﬁle. Before that we describe the

auxiliary web service.

5.4.1 The Auxiliary Web Service

The auxiliary web service monitors the value of when

conditions. It provides the RegisterWhen operation

that clients use to register the conditions they want

that this service monitors. This service uses an ODE

Listener to be informed when the value of a variable

has been modiﬁed. In this situation, it evaluates con-

ditions, and, when they become true, it sends a Un-

lockWhen to the respective process instance.

5.4.2 Editing the WS-BPEL File

Firstly we remove the when-then construct. To ex-

ecute the when-then code in parallel with the main

process logic, we add a Flow activity. We point out

that the ﬁnal WS-BPEL process deﬁnition only has

an additional Flow activity with all the code added to

support context variables and when-then constructs.

For each when-then, we add:

• two message variables used with web service in-

teractions,

• the PartnerLink and its roles,

• the CorrelationSet, and

• the Sequence activity.

The ﬁrst operation of the Sequence activity is the As-

sign. We use the Assign operation to initialize the

message we use to invoke the register operation in the

auxiliary web service. This message has the condi-

tion, the EPR used to receive the message notifying

that the when condition becomes true, and the identi-

ﬁcation of the process instance.

We illustrate this Assign operation in the follow-

ing.

Inicialization of the message used to invoke the web service

that monitors the when condition:

<assign validate="no"

name="testeWhenSubscriptionCreation">

<copy>

<from>

<when:RegisterWhenRequestElement>

<when:WhenProcessReference>

<wsa:Address ...>

http://localhost:8080/ode/processes/

SubscribertesteWhen

</wsa:Address>

</when:WhenProcessReference>

<when:Condition>$tempVar > 35

</when:Condition>

<when:InstanceId> -1 </when:InstanceId>

</when:RegisterWhenRequestElement>

</literal>

</from>

<to variable="testeWhenWhenRequest"

part="registerWhenRequest"/>

</copy>

<copy>

<to variable="testeWhenWhenRequest"

part="registerWhenRequest">

<query ...> when:InstanceId </query>

</to>

</copy>

</assign>

After the Assign operation, we add an Invoke ac-

tivity to call the RegisterWhen operation and a Re-

ceive activity. This activity is associated with the Un-

lockWhen operation, and, as it is a blocking activity,

it will not continue until the process instance receives

a message notifying that the conditions has become

true. Both activities use the CorrelationSet, which

distinguishes processes instances through their iden-

tiﬁcation (InstanceId). Finally, after the Receive, the

Sequence has the original activities of the when-then

construct.

5.4.3 Adding WSDL Files

The WSDL ﬁles include two web services interfaces:

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

510

Figure 1: The prototype and its tools.

• the auxiliary web service

• the web service that corresponds to the Receive

activity used to wait for the message notifying that

the conditions has become true. The EPR of this

web service is generated by concatenating the pro-

cess name with the name of the when-then con-

struct.

In addition, it includes the messages, the PartnerLink-

Type, and the correlation rules.

5.5 Prototype

We develop the prototype with the following tools:

• Eclipse EE + BPEL Designer plugin - modeling

tool (Eclipse IDE, 2013; BPEL Designer Project,

2013),

• Saxon Home Edition - XLST Processor (Saxon

Home Edition, 2013),

• Apache ODE - WS-BPEL execution en-

gine(Apache ODE, 2013), and

• Apache Tomcat (Apache TomCat, 2013).

Figure 1 illustrates our toolchain prototype and

how it performs model transformations.

6 CONCLUSIONS AND FUTURE

WORK

Business processes can beneﬁt signiﬁcantly from the

IoT information. The work we present in this pa-

per aims at simplifying the access to this informa-

tion within WS-BPEL processes. Through a WS-

BPEL extension, processes can include context vari-

ables, whose value is updated transparently and asyn-

chronously: the extension is responsible for the op-

erations required to perform the communication be-

tween process instances and sensors, allowing process

modelers to focus on business logic. We realize the

extension through a language transformation mecha-

nisms, allowing it to be as independent as possible

from the process execution engine.

Future work includes maturing the prototype to

add more validations in the language transformation,

to support context variables deﬁned inside Scopes,

and to provide an extension to the Eclipse WS-BPEL

Designer plugin, the tool we use to model processes.

ACKNOWLEDGEMENTS

This work was partially supported by the FCT through

the PATI project (PTDC/EIAEIA/103751/2008) and

the LaSIGE multi annual funding.

REFERENCES

Apache Muse (2013). URL: http://ws.apache.org/muse/

Page visited on February 10th, 2013.

Apache ODE (2013). URL: http://ode.apache.org/ Page vis-

ited on February 10th, 2013.

Apache TomCat (2013). URL: http://tomcat.apache.org/

Page visited on February 10th, 2013.

Box, D. and et al. (2004). Web services address-

ing (ws-addressing). IBM, W3C. URL: http://

www.w3.org/Submission/ws-addressing/.

BPEL Designer Project (2013). URL:

http://www.eclipse.org/bpel/ Page visited on February

10th, 2013.

Christensen, E., Curbera, F., Meredith, G., and Weer-

awarana, S. (2001). Web service deﬁnition language.

Microsoft, IBM.

Clark, J., Deach, S., and Kay, M. (2007). Xsl transforma-

tions. Saxonica, Adobe.

Eclipse IDE (2013). Eclipse IDE for Java EE Developers.

URL: http://www.eclipse.org/ Page visited on Febru-

ary 10th, 2013.

George, A. (2008). Providing context in ws-bpel processes.

Technical report, Journal of the Electrochemical Soci-

ety.

George, A. A. and Ward, P. A. S. (2008). An architecture for

providing context in ws-bpel processes. In Proceed-

ings of the 2008 conference of the center for advanced

studies on collaborative research: meeting of minds,

CASCON ’08, pages 22:289–22:303, New York, NY,

USA. ACM.

Karastoyanova, D., Houspanossian, A., Cilia, M., Ley-

mann, F., and Buchmann, A. (2005). Extending

bpel for run time adaptability. In Proceedings of the

Ninth IEEE International EDOC Enterprise Comput-

ing Conference, EDOC ’05, pages 15–26, Washing-

ton, DC, USA. IEEE Computer Society.

Kopp, O., Grlach, K., Karastoyanova, D., Leymann, F.,

Reiter, M., Schumm, D., Sonntag, M., Strauch, S.,

InternetofThingsAwareWS-BPELBusinessProcess

511

Unger, T., Wieland, M., and Khalaf, R. (2011). A

classiﬁcation of bpel extensions. Journal of Systems

Integration, 2(4):3–28.

OASIS (2006). Web services notiﬁcation (ws-

notiﬁcation) version 1.3. OASIS. URL: https://

www.oasis-open.org/committees/wsn/.

OASIS (2007). Web services business process execution

language version 2.0. Organization for the Advance-

ment of Structured Information Standards.

Ranganathan, A. and McFaddin, S. (2004). Using work-

ﬂows to coordinate web services in pervasive com-

puting environments. In Proceedings of the IEEE In-

ternational Conference on Web Services, ICWS ’04,

pages 288–, Washington, DC, USA. IEEE Computer

Society.

Saxon Home Edition (2013). URL: http://saxon.

sourceforge.net/ Page visited on February 10th, 2013.

Wieland, M., G

orlach, K., Schumm, D., and Leymann, F.

(2009). Towards reference passing in web service

and workﬂow-based applications. In Proceedings of

the 13th IEEE international conference on Enterprise

Distributed Object Computing, EDOC’09, pages 89–

98, Piscataway, NJ, USA. IEEE Press.

Wieland, M., Kopp, O., Nicklas, D., and Leymann, F.

(2007). Towards context-aware workﬂows. In CAISE´

07 Proceedings of the Workshops and Doctoral Con-

sortium. Citeseer.

Yu, L. and Su, S. (2009). Adopting context awareness in

service composition. In Proceedings of the First Asia-

Paciﬁc Symposium on Internetware, Internetware ’09,

pages 11:1–11:10, New York, NY, USA. ACM.

Zeng, D., Guo, S., and Cheng, Z. (2011). The web of things:

A survey (invited paper). Journal of Communications,

6(6).

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

512
