From Relational Databases to Ontology-Based Databases

Hamaz Kamal

and Benchikha Fouzia

1,2

LIRE Laboratory, University Mentouri of Constantine 2, Constantine, Algeria

Computer Science Department, University of 20, Aout 1955, Skikda, Algeria

Keywords: Relational Databases, Reverse Engineering, Semantic Discovery, Ontology-Based Databases.

Abstract: Nowadays, the volume of data used in an information system grows rapidly. Additionally, enterprise

information systems are more open to distributed environments and platforms. Thus, the need for

interoperability between the different underlying data sources increases considerably. Therefore, data

storage should consider storing data as well as the semantic of it in a single database. To overcome this

problem, Ontology-Based Databases seem to be a good choice to replace legacy databases. In this sense,

this paper proposes a reverse engineering approach which transforms a relational database to an ontology.

The extracted ontology is enriched with more semantics by mean of external domain ontology. Finally the

ontology and data are stored in one of the existing specific architectures for Ontology-Based Databases.

1 INTRODUCTION

The success of enterprises clearly depends on how

services are being improved and upgraded with time.

From this perspective many enterprises are faced

with the problem of having to optimize their

information systems. This would lead to high quality

services and better interactions. For every

information system, databases play an important role

for data storage, retrieval and manipulation.

Therefore, the development of databases leads also

to the development of any enterprise information

system. Despite the fact that the relational model is

the most used model for data storage, other database

models have appeared. In particular, XML and

object-oriented databases have appeared with the

aim to give additional capabilities, which doesn’t

exist in relational databases. More specifically, the

semantic representation of the stored data is the most

required capability. This capability is essential

especially for enterprises that deal with

heterogeneous environments, in which it is needed

to handle interoperability between different

underlying data sources.

In order to maintain semantics of the stored data,

the use of a conceptual model within a database is

seen to be necessary. Many conceptual models give

the ability to represent semantics of any given

domain. As an example, UML model or ontologies

are able to represent semantics of any domain.

Nowadays the use of ontologies increases in many

fields. Ontologies provide a rigorous and a formal

manner for the formulation of conceptual schemes.

Therefore works to combine ontologies and

databases have emerged (Pierra, 2005); (Alexaki,

2001); (Broekstra, 2002). Once the ontology is

stored with data in a single database, it is possible to

retrieve the definition or the meaning of the

requested elements. Hence providing semantics of

the stored data is considered. Such databases are

called Ontology-Based Databases (OBDB).

In this paper we propose a reverse engineering

approach that transforms a relational database into

an Ontology-Based Database. The literature shows

how a reverse engineering process could provide

abundant benefits in discovering semantics in legacy

databases (Hainaut, 2002). Therefore, in this paper

we propose a set of rules to extract an ontology from

a relational database. The resulted ontology is

enriched with more semantics by mean of external

domain ontology. In the last step the ontology and

data are stored in an OBDB architecture. Here

OntoDB (Dehainsala, 2007) is the architecture that

is being used for storage. The motivation behind

choosing OntoDB is shown in section five.

The rest of the paper is organized as following:

section two and three talk about database

development and reverse engineering respectively.

In section four our proposed approach for reverse

engineering relational databases to ontologies is

289

Kamal H. and Fouzia B..

From Relational Databases to Ontology-Based Databases.

DOI: 10.5220/0004454802890297

In Proceedings of the 15th International Conference on Enterprise Information Systems (ICEIS-2013), pages 289-297

ISBN: 978-989-8565-59-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

detailed. Section five gives some aspects of the

OntoDB architecture. A case study is conducted in

section six followed by conclusion and future work.

2 DATABASE DEVELOPMENT

The development of database models and DBMS

had been always an interesting area of research. The

progress of information systems regards directly and

indirectly the progress of databases. Researchers

have employed different models and techniques to

improve databases. In the last years, a significant

attention is dedicated to reuse existing information

resources, and provide access to them at the

semantic level. In the following we define two of the

major database models that were for big influence in

database development.

2.1 Object-oriented Databases

Object-oriented databases are databases that store

data as objects. Also, objects can be interpreted by

methods defined in their related classes.

Additionally, interesting relationships between

objects such as inheritance are preserved. However,

object-oriented database systems are closely

dependent to a specific language such as C++. They

have been seen for a while as a rival to replace

relational databases (Ramanathan, 1997). Though

the relational model has continued being broadly

used, due of its maturity acquired over the years. In

the other side, the inconveniences of the object-

oriented model (lack of standard, complex

databases…) have long persisted. Meanwhile,

ontologies appeared and didn’t stop to be

increasingly interesting.

2.2 Ontology-Based Databases

2.2.1 Ontologies

An ontology is defined as a specification of a

conceptualization (Thomas 1993). Ontologies define

hierarchies based on structured vocabularies,

grouping together concepts/classes and their

relationships and instances of classes.

2.2.2 Advantages of Ontologies

Ontologies provide many advantages in comparison

with the relational and object models. They provide

rigorous formulation of the conceptual schemas.

They make it possible for systems to use data

semantics. And other advantages as inferences and

use of online vocabularies like WordNet. As a

consequence, many works on using ontologies

within databases have started to appear (Pierra,

2004); (Broekstra, 2002) assuming that using

ontologies will give born to more semantically

efficient databases.

2.2.3 Approaches for Ontology Storage

The concept of OBDB is widely defined and

explained in (Pierra, 2005). Such databases use

ontologies as one of the database layers. They store

in a same database data and semantics that define

data by the mean of an ontology.

There exist different approaches with different

ways to store ontologies.

 Vertical Representation Approach: In this

approach the storage is simple where classes and

relationships/properties are stored as triples:

‘Subject, Predicate, Object’. Jena (Wilkinson,

2003) is an example of such an approach.

 Specific Representation Approach: In this

approach, the storage is different from an

implementation to another. However the most

general strategy stores separately the ontology

and data, where each data should have a

reference to its conceptual element in the

ontology. IBM SOR (Jing, 2007) follows this

approach for storing ontology and data. There

exist other approaches that add a new part called

‘Meta-Schema’ as with the OntoDB architecture

(Dehainsala, 2007) (See Figure1).

Different languages for exploiting and querying

OBDB exist as SPARQL (Seaborne,), OntoQL

(Jean, 2006), etc.

Figure1: Ontology-Based Database architecture.

The advantage of OBDB approaches is the fact

that it is possible to query either the stored data, the

ontology that defines the data or both. According to

the diverse advantages of such approaches and of

ontologies in general, works on relational database

reverse engineering to ontologies have appeared. In

the following we define the reverse engineering

process and its early and late targeted models.

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

290

3 RELATIONAL DATABASE

REVERSE ENGINEERING

The reverse engineering process is a process that

analyses a given model or a system in order to

discover information concerning its components and

their relationships. Therefore it is possible to

discover semantics, especially for legacy/relational

databases. Also the main motivation behind applying

a reverse engineering process over legacy databases

is that these last contain an important mass of data,

as well as useful information to reuse. Many models

were defined to be the result of this process. First

ones were toward the conceptual schema, as the

work in (Johansson) which extracts a conceptual

schema from a relational database. Some other

works considered extracting semantics under an

object oriented model as the work in (Ramanathan,

1997). Hence, this would provide better semantics

under an object-based representation of the relevant

entities. Lately ontologies are being the most used

model to be the source-to-target of relational

database reverse engineering. The related work can

be classified as follows.

3.1 Exploiting Relational Schemes

Although some works on relational database reverse

engineering consider using external sources to end

up with a better ontology, most of the existing

approaches exploit only the relational

schema/database. As an example the work in

(Astrova, 2004) proposes an approach that analyses

the SQL-DDL code of the database and the

correlations between keys, attributes and data in

order to discover semantics. The process divides the

relational schemes into base relations, composite

relations and dependant relations. An extension of

this work has succeeded in (Astrova, 2006) and

represents the resulted ontology in OWL. It takes

also into account the representation with OWL of

some database constraints as the constraint CHECK.

Another recent work in (Zdenka, 2010) focuses on

conversion of constructs from relational database to

OWL constructs, in addition of transferring the

relational data to ontology instances by application

of their rules.

3.2 Exploiting an External Source

In this category of approaches an ontology is

extracted from a relational schema/database and then

enriched by help of an external source. Some

approaches exploit the semantics that could be found

in the related HTML pages/forms used to interact

with the database. Such as the work in (Astrova,

2005) and (Benslimane, 2008). This last uses HTML

forms to analyze them in order to discover more

semantics. The discovered new entities and

organized in a way that permits to discover relevant

constraints and dependencies between data. Another

work in (Kashyap, 1999) exploits user queries to add

additional semantics to the ontology extracted from

the database. This last shows that user queries can

indeed reveal semantics which could be translated to

new classes or properties.

In the next section we present our approach for

ontology extraction from a relational database and

its enrichment.

4 THE PROPOSED APPROACH

The proposed approach supposes that the relational

database is in the 3NF, and do not use surrogate

keys. Three main steps constitute our approach that

fulfils respectively the following tasks:

 Ontology extraction from a relational database

by application of a set of rules.

 Enrichment of the extracted ontology by help of

external domain ontology.

 Ontology and data storage in OntoDB.

4.1 Preliminaries

 Basic Relational Concepts: A relational schema

can be seen as a finite set of attributes that we

denote ∂. Attributes are denoted using the capital

letters of the alphabet from beginning A, B, C, A

…, a set of attributes is denoted by the last

capital letters of the alphabet X, Y, Z. We use R

to represent a relation schema, where R is a

subset of ∂ and (R

∪ R

∪…R

) = ∂. If we assume

that R(X) represents a relation schema with n

attributes, we write X

, A

. Also each

attribute has a set of values D. Tuples are

denoted by t such that for a given relation R

, … A

) we have t

(R⊂D

)

…

)

where t

of R represents values of a

specific tuple.

 Keys and Dependencies: A primary key PK is a

candidate key CK chosen to identify attributes of

R, we write PK(R) to denote a PK of a relation,

and PK(X) to denote X as the attributes used for

the PK. A foreign Key FK in a relation R

is a PK

in another relation R

(sometimes in the same

FromRelationalDatabasestoOntology-BasedDatabases

291

relation), where values of the FK reference

values of the PK. We use S to denote the set of

all attributes that represent foreign keys in ∂.

Inclusion dependencies IncD exist between two

relation schemes if the following form holds:

(Y)⊆ R



Z

 | Y = Z (same sequence of

attributes), IncD takes the following form R

(Y)

→ R

(Y).

 Ontologies: We describe an ontology by a 4-

tuple O=(C

, A

, R

, H

), Where:

• C

is a finite set of classes (C

... C

• A

is a collection that represents the sets of

attributes belonging to the classes. A(c) denote

attributes that belong to one class.

• R

is a finite set of roles/relationships which

exist between classes. C

R

denotes a role

between two concepts | C

(Domain), C

(Range).

• H

represents the hierarchy or taxonomy

between concepts. We write H

⊆ C

denote that C

is the subclass of C

In the following, our transformation process

based on rules is presented and explained.

4.2 Transformation Process

The transformation process is composed of a set of

rules to create ontological classes and hierarchies

between classes. Then it creates roles/relationships

between classes and finally the attributes of classes.

Rule#1:

For ever

: PK(R) ⋂ S = ∅ (When such a case

holds we call R an atomic relation)

Do:

reate

Rule#2:

For every: Two atomic relations R

with:

PK(R

) ⊆ PK{/CK} (R

)

Do: Create

⊆

correspond

respectively to

Rule#3:

For every: Atomic relation R

with:

FK(R

)

⊆

PK(R

)

Do: Create C | C Class created for attribute FK

Create H

⊆

| C

Class created for R

Rule#4:

For every: Two atomic relations R

with:

IncD: R

(Y) → R

(Z) exists such as:

FK(Y) ⊆ PK(Z)

Do: Create C

| C

(domain)

(range)

Rule#5:

For every: PK(R

)

such tha PK(W,Y) represent

the attributes used for the PK, with:

IncD: R

(Y) → R

(Y)

PK(R

) ⋂ PK(R

)



Do: Create C

| C

(domain)

(range)

Rule#6:

For every: R

(Z) where:

Z ∈

Znnumbero

attribute

with n⩾2.

Do: ∀i,j

⩽

∧ i ≠ j ∧i < j

Create C

R C

| C

(domain)

(range)

Create Inverse Role C

R C

The values of i and j represent the relations that are

being referenced by the FK’s of R(Z).

Rule#7:

For every: R

(Z,W) such that Z ∈

S.

W ⋂



∅

Do: Create C

Create roles the same way as in Rule#6

Rule#8:

For every: R having X a set of its attributes, such

that foreign keys are not considered.

Do: A(c) = {(X

.. X

)}

We studied these rules to cover the different possible

relational forms to capture as much semantics as

possible. After the creation of classes in Rule1

hierarchies between classes are created in rule2.

Rule3 treats reflexive cases when a relation

references itself, thus a new class is interesting to be

created to represent an additional semantic link. In

the other hand, roles are created in Rule4, Rule5 and

Rule6. More specifically Rule 5 treats the case of

weak entities translated to relations, and Rule6 treats

binary and n-ary relationships where we used

variables i, j to treat the different possible cases.

Rule7 is a special case of Rule6, when an additional

attribute(s) exist and not referencing any other

relation. A class is created for this case to not lose

the semantics of the possible additional attributes

(See attribute grade in table 2). And last, Rule8

creates attributes of classes.

Once the ontological model is extracted it will be

enriched under the enrichment process.

4.3 Enrichment Process

The enrichment process is an effective way to add

more semantics to the extracted ontology. More

often the ontology extracted from a relational

database is closer to an object model. However, by

adding more semantics, the ontology will be more

adequate. The enrichment is based on an algorithm

and some additional cases for adding more roles.

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

292

Table 1: Algorithm of enrichment.

Main Function

Description: The main function supposes that we

already have two ontologies (our extracted ontology

RO and the domain ontology DO).

Prior Step.Organize classes of RO from top to down

in the array r1. Organize classes of DO from bottom to

top in the array r2

c1 and c2 represent respectively each class from r1 and

foreach c1 in r1

{ k= Stemming (c1); //receiving the root word in variable k

r3= WordNet(k); //get possible synonyms in the array r3

foreach c2 in r2

foreach q in r3

{b=StringCompare(q,c2); //b is boolean false by default

if (b); //if b=true

//once there’s similarities we call these two functions.

DegreeOfSimilarities (c1,c2);

Enrichment(c1,c2);

}

Degree of Similarities

Description: Degree of similarities is calculated

between each two classes. With help of the degree

calculations done between classes, an expert can decide

which classes to keep or to deleted

P1= an array that will have all properties of c1;

P2= an array that will have all properties of c2;

x1= max (P1.length,P2.length);

x2= number of similar properties between c1 and c2;

Degree= (x1/x2); // Degree is a float variable

Enrichment

Description: The enrichment function adds

subclasses/superclasses and their properties once two

classes show similarities. Also, it makes sure not to add

existing classes. Once all enrichment finished roles that

point only to one class will be deleted.

co1Sub= classes subsumed by c1;

co1Sup= the super class of c1;

co2Sub= classes subsumed by c2 (if they exist);

if co1Sup = null

//no super classes

// Case 1 {Write in an output file the class c1 with all the

chain of the super classes found in DO, and their properties; }

foreach s in co1Sub

for each f in co2Sub

{

if ((s && WordNet(s)) are all different of f) // test

to not add classes that already exist

// Case 2 {Write always in the output file the class s with f as

its new subclass with its properties

;}

if (f.subclass = = (any other s in co1 || Wordnet (s)) //

we call d any s that satisfies this condition

// Case 3 ‘Once a class added to c1’ {Write on the same output

file that d is now subsumed by f and not anymore by c1 (delete

subsumption between (c1, d));

}

4.3.1 Algorithm of Enrichment

This proposed algorithm attempts to add new

classes/properties. We inspired some points for our

algorithm from the work in (Rene, 2010). The main

steps of the algorithm are shown in table 1.

The fact that domain ontologies exist lately for a

very large number of fields motivates their use in

our algorithm of enrichment. In addition they could

cover interesting semantic aspects. In this sense,

they could bring many benefits to an extracted

ontology from a relational database of the same

domain of application.

4.3.2 Adding More Roles

Additional roles can be discovered between classes

if the following conditions hold: Relations related to

the classes are atomic relations. One or more of

these atomic relations contain (⩾2) foreign keys. In

other words let’s suppose we have three atomic

relation schemes R

and R

. And R

has two

foreign keys R

(X, FK

) such as:

)⊆PK

) and FK

)⊆PK

If such a condition holds it is possible to derive a

new role between R

and R

. However, the nature of

the role can be only decided by an expert that knows

the semantics of the database.

5 PROCESS OF STORAGE

The last step in our approach consists on storing the

enriched ontology and data which existed in the

relational database. As we mentioned we use the

OntoDB architecture for storage. This last offers

many advantages: it stores ontology and data

separately, it has a meta-schema part, which is

flexible and stores different ontology models. And

facilitates updates, since the ontology is stored as an

instance of the meta-schema, in addition, it enables

to store semantic definitions in other languages.

Figure 2: Meta schema part.

OntoDB architecture covers similarities with the

FromRelationalDatabasestoOntology-BasedDatabases

293

relational model as when using foreign keys to link

different parts together. It was implemented under a

PostgreSQL environment. OntoDB has a query

language called OntoQL, which is very close to

SQL. According to these features, an enterprise that

uses a relational database would prefer to have a

better storage environment, but yet not a totally

different from the one existing. Thus we opted for

OntoDB because it covers most today’s desired

features in a database.

The creation of a database based on OntoDB

architecture is carried out using OntoQL statements

for ontology and data definition. Also it is possible

to alter and update the database once it is created.

The general syntax for ontology definition is

shown as follows. More details of OntoQL can be

found in (Jean (thesis), 2006).

Once the ontology is defined we proceed by the

migration of data from the relational database. These

data will be stored in the content part of OntoDB. To

populate the content part, data can be directly

transferred from each table/relation in the relational

database to its related table in OntoDB. Obviously,

each class in the ontological part of OntoDB can

have a table for storing its instances in the content

part. Hence, if a relation R in ∂ has a created class C

in OntoDB and C has been assigned a table T in the

content part. Data from R will be transferred to T

with the same sequence of tuples. This applies only

for attributes that are common for both R and C.

Let’s suppose that the following form represents a

specific tuple in the relation Person:

(Person⊂D

(Id-Person

(name

)

(address

)

In the content part we use the same values of tuple

for populating a tuple in the extent of Person’s class,

if we suppose that it has the same defined attributes.

Tuples in the relation Person will be mapped in the

same order to the table Person of the content part. In

the other hand, the link between the ontology part

and content part is kept (Jean, 2006), because every

class is related to the table(s) that define its data.

More of the storage details are represented in the

next section of the case study.

6 CASE STUDY

In this section an example of simple relational

database is given to illustrate the application of our

approach (See table 2). After this, we present details

of the storage process with OntoQL clauses. By the

same way, we show the advantages of OntoDB

when querying data semantics. We write

attribute{number} to distinguish foreign keys, primary

keys are underlined.

Table 2: Relational schema.

1) Person (Id-Person, name, address, marriedwith{1})

2) Professor(Id-Prof{1}, salary, CourseID{6})

3) Student(Id-Stud{1}, year, DepId{4})

4)Department(DepId, name, devided-In{9}, located-

In{8})

5) Laboratories(IdLab, interests, budget, DepId{4})

6) Course(CourseId, title, section)

7) CourseTime(CT, CourseId{6}, starttime)

8) City(CityId, name, population)

9) Division(NumDiv, description)

10) Enrolled(Id-Stud{3}, CourseId{6}, grade)

11) Teaches(Id-Prof{2}, Id-Stud{3})

Since the enrichment is based on a domain

ontology, we use the one found in (Domain-

Ontology), a part of it is shown in figure 3.

Figure 3: A part of the domain ontology.

The result of the application of our

transformation and enrichment processes is

represented in figure 4. Each class labelled with

either C or R or both means respectively that it was

enriched with more class(es) or role(s).

For the enriched classes they were benefited with

more semantics. The class project was added

‘

SoftwareProject’ and ‘ResearchProject’ as new

subclasses. The class Person was added ‘Employee’

and the class Student ‘

Graduate’ and ‘Undergraduate’.

In the other hand, roles have been added to

Department, Student and Person. Finally a new role

(Laboratories ‘located-in’ Division) is added with

the case of adding more roles of section 4.3.2. Next

step consists on ontology and data storage.

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

294

Figure 4: Result after applying our approach.

6.1 OntoQL Statements

In order to execute OntoQL statements tools as

OntoQL-Plus and PLIB-Editor exist. The clause

CREATE CLASS is used to create a new class. The

one called DESCRIPTION is used to describe the

class and provide it with more semantics. The

PROPERTIES clause represents attributes of the

class. In the following a part of OntoQL statements

is shown for ontology definition in OntoDB.

CREATE Class Person

DESCRIPTOR(

#name[fr]='une personne',

#definition='human being‘)

PROPERTIES (Id-Person INT, name String,

address String)

CREATE Class Professor UNDER Person

DESCRIPTOR(

#name[fr]='Professeur',

#definition='Teacher or supervisor‘)

PROPERTIES (Id-Prof INT, Salary Float)

CREATE Class Student UNDER Person

DESCRIPTOR(

#name[fr]='Etudiant',

#definition='Person studying‘)

PROPERTIES (Id-Stud INT, year DATE)

CREATE Class Department

DESCRIPTOR(

#name[fr]='Département',

#definition=’Academic buildings‘)

PROPERTIES (DepId INT, name String)

We proceed the same way with the rest of classes. In

order to store roles we extend the meta-schema part,

the entity Role is created under the existing entity

‘Property’ in the meta-schema.

CREATE #Entity Role UNDER #Property

(#Rolename String,

#InverseRole String,

#Domain REF(#Class),

)

The classes related to the roles will be linked to

them with internal identifiers. For the content part an

extent is created for each class issued of the

transformation process.

CREATE EXTENT OF Person (Id-Person, name,

address, marriedwith);

Such a clause creates a table in the content part.

The clause used to insert values is:

INSERT INTO (attributes) VALUE (values);

It is possible also to create views as an extent of

other tables of the content part. For example, we

represented ‘MarriedWith’ as a subclass of Person.

We could then create a view for it based on the

attributes of person and its data.

CREATE VIEW OF MarriedWith AS

(SELECT Id-Person, name, Marriedwith)

FROM Person

WHERE (Marriedwith IS NOT NULL)

This clause creates a new table with the attributes of

the selection and will eventually represent only

married persons.

6.2 Querying OntoDB

The OntoQL query language provides different

abilities that could be used to exploit the semantics

of the stored ontology and data. Here are some

examples:

The first query retrieves the code of classes

which define a property called ‘located-in’.

SELECT c.#code

FROM c in #class, p in #properties

WHERE p.#name = ‘located-in’

It is possible to retrieve the names of classes with

the provided other language.

SELECT #name[FR] FROM #class

The following query returns classes that have

‘Etudiant’ as their French name.

SELECT c.#oid

FROM c in #Class

WHERE c.#name[fr] like ‘Etudiant’

We could query also on roles

SELECT p.#role, p.#inverserole FROM

#PROPERTY AS p WHERE p.#oid=101

FromRelationalDatabasestoOntology-BasedDatabases

295

Furthermore, we could select from ranges of

super/sub classes and also properties by using:

#superclasses #directsuperclasses #subclasses

#scopeProperties #properties #usedproperties. All

these are very useful to exploit better the ontological

semantics stored in OntoDB. This sub-section

highlighted only few of OntoQL abilities, which are

more interesting (Jean (thesis), 2006). We show on a

future work how we could retrieve more from

OntoQL abilities, and from using OntoDB for

ontology and data storage.

7 CONCLUSIONS

In this paper, we presented a reverse engineering

approach that aims to migrate relational databases to

OBDB. We proposed first a set of transformation

rules to extract an ontology from a relational

database. And to optimize the extracted ontology we

proposed an enrichment process. This last uses

external domain ontology and attempts to add more

classes or properties to make the ontology

semantically more complete. Then we stored the

enriched ontology and data in OntoDB. In a future

work we will focus on running more experiments,

tests and evaluations on larger databases, and prove

how OBDB could bring many benefits for an

enterprise. Equally important, we prove the

efficiency of our transformation process by testing

several transformation criteria. Such criteria are

useful to prove that there’s no information loss in the

transformation process.

REFERENCES

Alexaki, S. Christophides, V. Karvounarakis, G.

Plexousakis, D. Tolle, K., 2001. The ics-forth rdfsuite:

Managing voluminous rdf description bases. In

SemWeb. Hong Kong, pp. 1-13.

Astrova, I., 2004. Reverse Engineering of Relational

Databases to Ontologies. In Proceedings of the 1st

European Semantic Web Symposium (ESWS),

Heraklion, Greece, pp 327-341.

Astrova, I., Kalja, A., 2006. Mapping of SQL Relational

Schemata to OWL Ontologies. In Proceedings of the

6th WSEAS International Conference on Applied

Informatics and Communications, Elounda, Greece.

pp375-380.

Astrova, I., Stantic, B., 2005. An HTML Forms Driven

Approach to Reverse Engineering of Relational

Databases to Ontologies. In Proceedings of the 23rd

IASTED International Conference on Databases and

Applications (DBA), Innsbruck, Austria.pp 246 - 251.

Benslimane, S., Malki, M., Rahmouni, M., Rahmoun, A.,

2008. Towards Ontology Extraction from Data-

IntensiveWeb Sites: An HTML Forms-Based Reverse

Engineering Approach. The International Arab

Journal of Information Technology. pp 34-44.

Broekstra, J., Kampman, A., Van Harmelen, F., 2002.

Sesame : A generic architecture for storing and

querying rdf and rdf schema. Proceedings of the First

Internation Semantic WebConference, number 2342 in

Lecture Notes in Computer Science. pp 54–68.

Dehainsala, H., Pierra, G., Bellatreche, L., 2007. Ontodb:

An ontology-based database for data intensive

applications. In DASFAA. pp 497-508.

Domain-Ontology http://ontoware.org/swrc/swrc_v0.3.owl

Hainaut, J., 2002. Introduction to database reverse

engineering. Book, 160 pages.

Thomas R, Gruber., 1993. Formal ontology in conceptual

analysis and knowledge representation. Chapter:

“Towards principles for the design of ontologies used

for knowledge sharing”. Kluwer Academic Publishers.

Jean,. S., Aït Ameur, Y., Pierra, G., 2006. Querying

ontology based databases the ontoql proposal. In

Proceedings of the 18th International Conference on

Software Engineering & Knowledge Engineering, pp

166—171.

Jean, S (thesis).2006., OntoQL, un langage d’exploitation

des bases de données à base ontologique. Mémoire de

doctorat.

Jing, L., Li, M.,Lei, Z., Jean-Sébastien, B., Chen, W., Yue,

P., Yong, Y., 2007. SOR: A Practical System for

Ontology Storage, Reasoning. In VLDB 2007, 33rd

Very Large Data Bases Conference ,pp 1402-1405.

Johannesson, P., 1994. A Method for Transforming

Relational Schemas into Conceptual Schemas. In

Proceedings of the Tenth International Conference on

Data Engineering IEEE Computer Society

Washington, DC, USA, pp 190-201.

Kashyap, V., 1999. Design and creation of ontologies for

environmental information retrieval. In Proceedings of

the 12th Workshop on Knowledge Acquisition,

Modeling and Management. Alberta, Canada. pp. 3–

21.

Pierra, G. Dehainsala, H. Aït-Ameur, Y. Bellatreche, L.

2005. Base de données à base ontologique: principes

et mise en œuvre. Ingénierie des Systèmes

d’Information, 10(2):91-115.

Pierra, G., Dehainsala, H. Aït-Ameur, Y., Bellatreche, L.

Chochon, J and Mimoune, M. (2004). Base de

Données à Base Ontologique: le modèle OntoDB.

Proceedings of Base de Données Avancées 20èmes

Journées (BDA’04), 263–286.

Ramanathan, S., Hodges, J., 1997. Extraction of object-

oriented structures from existing relational databases.

SIGMOD Jounral Vol 26 number 1, pp 59-64.

Rene Robin, C.R., 2010. A Novel Algorithm for Fully

Automated Ontology Merging Using Hybrid Strategy.

European Journal of Scientific Research. Vol.47 No.1,

PP. 074-081.

Seaborne, A., Prud’hommeaux, E. Sparql query language

for rdf. http: // www. w3. org/ TR/ rdf-sparql-query/

ICEIS2013-15thInternationalConferenceonEnterpriseInformationSystems

296

Wilkinson, K., Sayers C., Kuno, H., Reynolds, D. 2003.

Efficient RDF storage and Retrtieval in Jena2.

Proceedings of the 1st International Workshop on

Semantic Web Database (SWDB’03). pp. 131–150.

Zdenka, T., 2010. Relational Database as a Source of

Ontology Creation. Proc, of the International

Multiconference on Computer Science and

Information Technology. 135.139.

FromRelationalDatabasestoOntology-BasedDatabases

297
