counter, 1827.6 for the EKF filter. It therefore works
correctly in a practical scenario.
6 CONCLUSIONS
This paper presents a sensor fusion algorithm for a
wheel mounted accelerometer and gyroscope based
odometry sensor. In contrast to existing approaches
using ad hoc methods to derive wheel angles, the
presented solution uses an Extended Kalman filter as
a principled estimator for locally linear systems ob-
served by noisy sensors. The power of this algo-
rithm is demonstrated by the overall positve results of
a number of experiments using real hardware under
normal as well as extreme conditions, and by simula-
tion experiments to compare the filter output against
a well known true state. The filter adapts dynamically
to saturation of the gyroscope and of the centrifugal
force accelerometer at high speed and continues to
work with even a single accelerometer. Embedded
in a small hardware component, it will provide a very
simple way of belated or temporary installation for
existing vehicles.
