Negotiating and Brokering Cloud Resources based on Security Level

Agreements

Jesus Luna

, Tsvetoslava Vateva-Gurova

, Neeraj Suri

, Massimiliano Rak

and Loredana Liccardo

Department of Computer Science, Technische Universit¨at Darmstadt, Darmstadt, Germany

Dipartimento di Ingegneria dell’Informazione, Seconda Universita’ di Napoli, Aversa (CE), Italy

Keywords:

Cloud Security, Security Level Agreements, Security Metrics, Security Negotiation, Resource Brokering.

Abstract:

Cloud users often motivate their choice of Cloud Service Provider (CSP) based on requirements related with

the offered Service Level Agreements (SLA) and costs. Unfortunately, while security has started to play

an important role in the decision of using the Cloud, it is quite uncommon for CSPs to specify the security

levels associated with their services. This often results in users without the means (i.e., tools and semantics)

to negotiate their security requirements with CSPs, in order to choose the one that best suits their needs.

However, the recent industrial efforts on speciﬁcation of Cloud security parameters in SLAs, also known

as “Security Level Agreements” or SecLAs is a positive development. In this paper we propose a practical

approach to enable the user-centric negotiation and brokering of Cloud resources, based on both the common

semantic established by the use of SecLAs and, its quantitative evaluation. The contributed techniques and

architecture are the result of jointly applying the security metrology-related techniques being developed by

the EU FP7 project ABC4Trust and, the framework for SLA-based negotiation and Cloud resource brokering

proposed by the EU FP7 mOSAIC project. The proposed negotiation approach is both feasible and well-suited

for Cloud Federations, as demonstrated in this paper with a real-world case study. The presented scenario

shows the negotiation of a user’s security requirements with respect to a set of CSPs SecLAs, using both the

information available in the Cloud Security Alliance’s “Security, Trust & Assurance Registry” (CSA STAR)

and the WS-Agreement standard.

1 INTRODUCTION

While the many economic and technological advan-

tages of Cloud computing are apparent, the migration

of key security relevant applications onto it has been

limited, in part, due to the lack of accountablesecurity

assurance speciﬁcation provided by the Cloud Ser-

vice Provider. Furthermore, the typical Cloud user is

not a security expert, though nevertheless has speciﬁc

security requirements to fulﬁll (e.g., due to regulatory

compliance) that are usually expressed at an infor-

mal level, thus making them difﬁcult and expensiveto

align and negotiate with respect to the CSP’s security

offer. Unfortunately, at the state of practice (e.g., as

discussed by the Cloud Security Alliance’s SLA WG

(Cloud Security Alliance, 2012)), many Cloud users

ﬁnd themselves without the means to match and fur-

ther negotiate their security requirements with avail-

able CSPs. Contrary to Cloud resource negotiation

based on non-security indicators (e.g., using perfor-

mance metrics as presented in (Rak et al., 2011b)),

the ﬁeld of security-based negotiation presents sev-

eral challenges mainly due to both the lack of security

assurance/quantiﬁers, and the semantic gap among

users and CSPs with respect to security.

Fortunately, security negotiation in Cloud com-

puting has recently taken some initial and promising

steps. Early academic works like (Kandukuri et al.,

2009) and, the Cloud community (e.g., workgroups

at the European Network and Information Security

Agency (ENISA) (Dekker and Hogben, 2011)) have

identiﬁed that specifying security parameters in Ser-

vice Level Agreements (termed as “Security Level

Agreements” or SecLA over this paper) actually en-

ables the establishment of a common semantic in or-

der to model security among users and CSPs. How-

ever, despite the state of the art efforts aiming at build-

ing and representing Cloud SecLAs (e.g., the CSA’s

SLA and PLA working groups (Cloud Security Al-

liance, 2012)), there is still a gap on the techniques

to reason about them. In particular we refer to the

techniques aimed to quantitatively evaluate the secu-

533

Luna Garcia J., Vateva-Gurova T., Suri N., Rak M. and Liccardo L..

Negotiating and Brokering Cloud Resources based on Security Level Agreements.

DOI: 10.5220/0004500505330541

In Proceedings of the 3rd International Conference on Cloud Computing and Services Science (CloudSecGov-2013), pages 533-541

ISBN: 978-989-8565-52-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

rity level provided by the SecLA, this being a core

requirement to enable the proposed negotiation of

Cloud resources based on security parameters (just

as presented in our previous research (Luna et al.,

2012b) and (Luna et al., 2012a)).

This paper proposes a novel methodology and ar-

chitecture to systematically broker Cloud resources

based on (i) a technique to quantitatively evaluate

and rank SecLAs and, (ii) a set of building blocks

to enable the user-centric negotiation of Cloud secu-

rity parameters. Our joint research contributes with

a practical approach that extends the Cloud SecLA

evaluation technique contributed by Luna (Luna et

al., 2012a), to enable the negotiation and brokerage

of Cloud resources presented in (Rak et al., 2011b)

using the well-known WS-Agreement protocol (An-

drieux et al., 2007).

The overall vision of this paper is represented in

Figure 1, where an iterative Negotiation process (Step

1) quantiﬁes and ranks the user security requirements

(i.e., represented as a User SecLA), with respect to

one or more CSP SecLAs (Step 1b). Once an exist-

ing CSP SecLA offer matches the User SecLA, then

an Enforcement stage takes place i.e., the broker ac-

quires and delivers CSP resources to user (Step 2).

This paper is focused on developing the details related

with the underlying negotiation stage, whereas the re-

source brokering is out of scope. Notice that both the

Negotiation (Step 1) and Evaluation (Step 1b) stages

are not completely independent: security negotiation

needs the quantitative evaluation of SecLA in order to

rank the available CSP with respect to a user require-

ment, whereas the evaluation stage applies a user-

deﬁned negotiation criteria in order to classify the

CSPs’ security features.













 !

"#$

%



Figure 1: Overview of the proposed security negotiation

and brokerage of Cloud resources.

This paper also proposes an architecture to im-

plement the presented SecLA negotiation methodol-

ogy in the context of a Cloud Federation, using the

framework being developed by the EU FP7 mOSAIC

project (mOSAIC, 2011). This frameworkenables the

creation of distributed Cloud applications through a

set of components based on the management and ne-

gotiation of Service Level Agreements.

Finally, to demonstrate the feasibility of our pro-

posal we present the case study of a real system that

implements the negotiation of a User SecLA with re-

spect to a set of CSPs SecLAs, based on the infor-

mation available in STAR (Cloud Security Alliance,

2011b) and the WS-Agreement standard (Andrieux et

al., 2007).

The paper is organized as follows: Section 2 in-

troduces the basic concepts behind the proposed se-

curity negotiation approach, Section 3 describes how

Cloud SecLAs can be speciﬁed using WS-Agreement

in order to enable its negotiation via the architecture

presented in Section 4. A real case study that applies

the proposed approach is discussed in Section 5, Sec-

tion 6 analyzes related works and, ﬁnally Section 7

presents our conclusions.

2 QUANTITATIVELY

EVALUATING AND RANKING

CLOUD SecLAs

Two base concepts driving our proposal are presented

in this section. First, we discuss in further detail the

notion of Cloud SecLAs (cf. Section 2.1). Second, in

Section 2.2 are presented the basics of a technique to

reason about SecLA, in particular to enable its quan-

titative evaluation as required by the negotiation pro-

cess presented in this paper.

2.1 Cloud Security Level Agreements

The concept of SecLAs currently exists in varied

dimensions and the Cloud is not an exception. The

use of Cloud SecLAs has the potential to provide

tangible beneﬁts to CSPs especially associated with

improved security administration and management

practices, thus allowing for transparency to end users.

The end users can also beneﬁt from SecLAs by

understanding the costs and beneﬁts associated with

this new service model. The importance of Cloud

SecLAs has also been recognized in a recent study

by ENISA (Dekker and Hogben, 2011), showing that

while SLAs are often used, and availability is often

addressed in these SLAs, other security parameters

(e.g., related with the conﬁdentiality and integrity

properties) are less well covered. As introduced by

Bernsmed (Bernsmed et al., 2011), a Cloud SecLA

usually models the CSP security at the service level

and in practice, the content of these Cloud SecLAs

Templates is designed by multi-disciplinary working

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

534

groups (e.g., the Cloud Security Alliance’s SLA

and PLA work groups (Cloud Security Alliance,

2012)). The result is an organized collection of

security statements (also called “security pro-

visions”) in the form {security attribute, value}

(e.g., {Backup Frequency, Daily} and

{Encryption Key Size, 512 bits}), as also proposed in

different industrial and academic works (Casola V., et

al., 2006), (Casola et al., 2005), (Samani et al., 2011)

and (Luna et al., 2011). In order to be manageable,

these security provisions are usually organized into

“hierarchical categories” derived from a taxonomy

e.g., Savola (Savola et al., 2010) or the CSA’s Con-

sensus Assessment Initiative Questionnaire (CAIQ)

(Cloud Security Alliance, 2011a). Cloud SecLAs

are usually stored in publicly available – and trusted

– repositories like e.g., the CSA’s “Security, Trust

& Assurance Registry” (Cloud Security Alliance,

2011b). Apart from the challenges related with the

creation of SecLAs in real Cloud deployments, the

current paucity of techniques to quantitatively reason

about them has proven to be part of the obstacles

in using SecLAs, just as mentioned by Almorsy

(Almorsy et.al., 2011) and (Luna et al., 2012b). In

order to contribute towards bridging this gap, the

next section presents the basics of a Cloud SecLA

evaluation technique which will be used by the

negotiation mechanism proposed later in this paper.

2.2 Quantitative SecLA Evaluation at a

Glance

For the contributed negotiation process (cf., Step 1 in

Figure 1) it is helpful to have a user-centric mecha-

nism to quantitatively evaluate and objectively rank

SecLAs with respect to a predeﬁned user require-

ment (Step 1b). Our approach extends the notion of

Cloud SecLA benchmarking proposed in (Luna et al.,

2012a), through the use of quantitative rankings, as

an enabler of the proposed negotiation process. The

overall intent is to (a) systematically quantify the se-

curity level associated with each SecLA involved in

the negotiation process (i.e., User SecLA and CSPs

SecLA) and (b) use the data from (a) to allow the

systematic elicitation of the CSP that is closer to the

user’s security requirements. For the purposes of this

paper, only three basic concepts of the SecLA evalu-

ation are presented and the interested readers are re-

ferred to (Luna et al., 2012a) for further details.

SecLAs have a twofold use: on one hand, the

authors make the realistic assumption (cf., Section

2.1) that each CSP is associated with a CSP SecLA,

on the other hand, they also advocate for the use of

SecLAs to represent security requirements of Cloud

users thus establishing a common semantic with CSPs

for reasoning about security. User-deﬁned require-

ments (termed as User SecLA) are a distinctive el-

ement of Cloud SecLA, where all the security pro-

visions are weighted in order to represent their rel-

ative importance from user’s perspective (e.g., for

some users “Encryption Key Size” might be more im-

portant than “Backup Frequency”). Furthermore, for

the sake of usability the technique proposed in (Luna

et al., 2012a) also considers that either quantitative

weights (e.g., from 0 to 1) or qualitative weights (e.g.,

low/medium/high) can be assigned at different levels

of the User SecLA.

The second concept is a mapping process that al-

lows representing any Cloud SecLA (usually these

documents are informally formatted) as a data struc-

ture that can be systematically processed. These data

structures (called “Quantitative Policy Trees” or QPT

in (Luna et al., 2012a)), are an extended version of

classical “AND-OR” trees used to integrate both se-

curity requirements and associated quantiﬁers needed

by the quantitative evaluation process. For the pur-

poses of this paper and due to space restrictions, only

a high-level view of the process to map SecLAs to

QPT is presented in Figure 2. The outcomes of the

mapping process are (i) a User QPT populated with

the weights and security provisions’ values speciﬁed

in the User SecLA and, (ii) one or more CSP QPTs

mapped from its respective CSP SecLAs and also

populated with the correspondingsecurity provisions’

values.

Cloud SecLA

Top-level category

Level-1

Category-1

Level-1

Category-n

Extraction

Iterative

Extraction

Security

Provision-1

Security

Provision-n

Mapping

AND/OR

Figure 2: SecLA-to-QPT: mapping a Cloud SecLA into a

QPT (Luna et al., 2012a).

The third and ﬁnal concept required from (Luna

et al., 2012a) is a set of rules to quantitatively ag-

gregate and propagate the weights and security provi-

sion’s values to the whole QPT (i.e., from leaf nodes

up to the root node). Once the User QPT and the

NegotiatingandBrokeringCloudResourcesbasedonSecurityLevelAgreements

535

CSP QPTs have been populated with the aggregated

values, it is possible to apply a ranking algorithm to

determine how different CSPs under-/over-provision

user’s requirements. In (Luna et al., 2012a) are pro-

posed two different ranking techniques: a quantitative

ranking (e.g., a real number on the interval {0. . . 1})

that due to its nature is more suitable for automated

systems than for humans and, a qualitative ranking

that aims to be more “human-friendly” by using a

set of qualitative labels (e.g., {“Copper”, “Silver”,

“Gold”}) to represent the QPT evaluation’s results.

In the rest of this paper, we will show that the pre-

viously presented notion of quantitative ranks can be

extended to actually negotiate Cloud resources using

a broker-based architecture.

3 CREATING AND SPECIFYING

SecLAs USING

WS-AGREEMENT

As introduced in Section 1, the goal of the proposed

approach is to offer the systematic negotiation of se-

curity using Cloud SecLAs. In order to fulﬁll this goal

our proposal (i) creates a set of CSP SecLA based on

the security information derived from the the CSA

STAR repository (Cloud Security Alliance, 2011b)

and, (ii) represents both CSP/User SecLA using the

WS-Agreement standard (Andrieux et al., 2007). In

this section we discuss in further detail these two

phases.

Listing 1: SDT element in WS-Agreement.

<ws ag: Ser vic eDe scr iption Te rm wsag:Name

=” CustomerAccessRequirements ”

wsag:ServiceName =” S e c u ri t y A r c hi t e c t u r e

”>

< / wsa g:S erv iceDes cripti onT er m>

First, given CSA STAR’s broad adoption by ma-

jor CSP our research proposes the creation of SecLA

derived from the information stored there. Currently,

STAR contains entries in the form of “Consensus

Assessments Initiative Questionnaire” reports (CAIQ

(Cloud Security Alliance, 2011a)), which provide

industry-accepted ways to document what security

controls exist in Cloud offerings. The current CAIQ

report contains a set of 171 security parameters (all

of these with a qualitative “YES/NO” answer) dis-

tributed in the following controls: Compliance (CO)

– 14, Data Governance (DG) – 15, Facility Security

(FS) – 9, Human Resources Security (HR) – 4, In-

formation Security (IS) – 71, Legal (LG) – 2, Opera-

tions Management (OP) – 5, Risk Management (RI) –

12, Release Management (RM) – 5, Resilience (RS) –

11 and Security Architecture (SA) – 23. Given these

CAIQ’s properties, it is possible to create SecLAs

with the features required by the evaluation and rank-

ing methodology presented in Section 2.

Second, to allow the automated negotiation of

Cloud SecLA (derived from the CAIQ as mentioned

in the previous paragraph), we adopted the SLA-

oriented language proposed by WS-Agreement which

was created with the goal to standardize the termi-

nology/protocol used when two parties are trying to

establish an agreement. It mainly consists of a lan-

guage for specifying the nature of the agreement and,

a SOAP-based protocol for actually establishing the

agreement between two participants. At state of art,

the WS-Agreement language is widely used for SLA

negotiation and has been adopted by projects like EU

FP7 mOSAIC (mOSAIC, 2011).

The main component within the WS-Agreement

standard is the SLA speciﬁcation core, which consists

of three elements: Service Description Terms (SDT),

Service Properties (SP) and, Guarantee Terms (GT).

A SDT is a fundamental element, providing a full or

partial functional description of a service. One or

more SDTs can be related to a service. A SP ele-

ment deﬁnes properties/variables, associated with a

service, and used for expressing guarantees on a ser-

vice. Finally, a GT element deﬁnes an assurance on a

service through an assertion (using the content of the

SP element) expressed over the service described by

the SDTs. In the rest of this section we present the

process required to specify a SecLA using the WS-

Agreement standard, however due to space restric-

tions our explanation will only show relevant excerpts

of the resulting XML document.

Based on the CAIQ’s structure (Cloud Security

Alliance, 2011a), ﬁrst we model each security control

as a SDT. Then, the respective value of the controls

along with the inputs required by the evaluation tech-

nique presented in Section 2 (i.e., the User SecLA’s

AND/OR relationships and weights) are modeled as

GTs on the SDT. CAIQ’s inherent hierarchical struc-

ture (i.e., sub-controls) is represented as security ele-

ments in WS-Agreement (cf., Listing 1).

Once the SDT has been speciﬁed, we have to fo-

cus on the SP element. First, we deﬁne a SP for each

CAIQ sub-control, as required by its respective SDT

(cf., Listing 2). Second, in the SP element we de-

ﬁne the variables (e.g., weights) and related semantics

used for expressing the security requirements through

assertions in the GT element.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

536

Listing 2: SP element in WS-Agreement.

< w s a g :S e r v i ce P r o p er t i e s wsag:Name=”

CustomerAccessRequirements ”

wsag:ServiceName =” S e c u ri t y A r c hi t e c t u r e

”>

<w sag:V ar iabl e wsag:Name=”SA−01.1”

wsag:Metric =” boolean ”>

<wsag:Location>$ t h i s / wsag:Terms /

wsag:All /

ws ag:S er viceDes cr ipt ion Te rm

[@wsag:Name = ’

CustomerAccessRequirements ’ ]</

wsag:Location>

</ w sag :V ari able>

<w sag:V ar iabl e wsag:Name=”SA−01.Q1”

wsag:Metric =” s t r i n g ”>

<wsag:Location>$ t h i s / wsag:Terms /

wsag:All /

ws ag:S er viceDes cr ipt ion Te rm

[@wsag:Name = ’

CustomerAccessRequirements ’ ]</

wsag:Location>

</ w sag :V ari able>

<w sag:V ar iabl e wsag:Name=” Weight ”

wsag:Metric =” f l o a t ”>

<wsag:Location>$ t h i s / wsag:Terms /

wsag:All /

ws ag:S er viceDes cr ipt ion Te rm

[@wsag:Name = ’

CustomerAccessRequirements ’ ]</

wsag:Location>

</ w sag :V ari able>

< / wsa g:V ari ableSet>

< / w s ag: S e r v ic e P r ope r t ie s>

For the GT description, the user can deﬁne a guar-

antee on a security service expressed as an assertion

in the Service Level Objective (SLO). The data re-

quired to model this assertion are: the security level

of the CAIQ control, the AND/OR relationships and

the weights. A more detailed explanation of the GT

element will be presented in Section 5.

Up to this point, we have fully developed the

structure of an empty WS-Agreement template “com-

pliant” with the Cloud SecLA evaluation technique

summarized in Section 2. Both users and CSPs are

now able to populate this template with their own se-

curity controls and values, so the ﬁnal set of SecLA

documents can be used for negotiation purposes just

as presented in the following section.

4 ARCHITECTURAL MODEL

As outlined in Figure 1, our approach takes into con-

sideration three different aspects (negotiation, evalu-





















 !

"

#

Figure 3: Proposed SecLA negotiation architecture.

ation and brokerage) which can be implemented as

independent modules. In Rak (Rak et al., 2011b),

a clear distinction was made among negotiation and

brokerage of Cloud resources in order to propose an

architecture to automatically perform these tasks us-

ing the framework developed by the EU FP7 mO-

SAIC project (mOSAIC, 2011). Despite the negoti-

ation process presented by Rak (Rak et al., 2011b) is

based on performance parameters (described in terms

of measurable metrics), our research extrapolates its

results to demonstrate that a similar architecture can

be also used to negotiate quantiﬁed security parame-

ters in the form of Cloud SecLAs. We propose the

three-tier architecture shown in Figure 3, where the

intermediate layer is comprised of the following mod-

ules: (i) the Negotiation Module which has the role

of managing the interactions with End Users, (ii) the

SecLA Evaluation which implements the technique

presented in Section 2.2 and, (ii) the Service Broker-

ing in charge of brokering the elicited Cloud services.

In this section we will focus on the Negotiation and

SecLA Evaluation modules, but interested readers are

referred to Rak (Rak et al., 2011b) for a full descrip-

tion of the Service Brokering module.

4.1 The User-centric Negotiation

Protocol

The Negotiation Module interacts with users in or-

der to identify their requirements (i.e., create an User

SecLA), and applies the results of the quantitative

SecLA evaluation/ranking (cf., Section 2.2) in order

to orchestrate the overall negotiation process. We as-

sume that users are able to specify their security re-

quirements in the form of a User SecLA (even if they

are not security experts), using as a guidance the CSA

CAIQ reports (Cloud Security Alliance, 2011a). As

mentioned in Section 3, the STAR repository (Cloud

Security Alliance, 2011b) can be used as a trusted

source for creating CSPs SecLAs. The Cloud SecLA

negotiation protocol shown in Figure 4, is the user-

centric mechanism we propose to allow end users and

CSPs arriving to an agreement on the requested/pro-

NegotiatingandBrokeringCloudResourcesbasedonSecurityLevelAgreements

537

























!

!!

!

!!



"

"

"



"

"

"

Figure 4: User-centric Cloud SecLA Negotiation Protocol.

vided security levels.

The proposed protocol works as follows: once the

user has created a User SecLA with her speciﬁc se-

curity requirements, the negotiation process starts by

submitting it to the Negotiation Module. Upon re-

ception, the Negotiation Module forwards the User

SecLA to the SecLA Evaluation module, which imple-

ments the technique described in Section 2.2 to quan-

titatively evaluate and rank the user requirement with

respect to a set of available CSPs SecLAs (previously

fetched from a repository like STAR). As a result, the

SecLA Evaluation module returns to the user this set

of CSPs, but ordered with respect to the requested

User SecLA (e.g., quantitatively ranked from best to

worst). In this case the user is given the chance to

make (either automatically or manually) an informed

decision by choosing a CSP from this resulting set.

The user-selected CSP SecLA is then submitted to

the Broker, so it can be either reserved or refused. If

it is refused, then the user has to submit a new pro-

posal (i.e., another CSP SecLA), and if it is reserved

then a timeout is set for the CSP SecLA. This time-

out is a pre-deﬁned period of time, which will be al-

lowed to elapse before a user ﬁnally agrees on the re-

served CSP. Once the user decides to continue with

the resource reservation, then an agreement will be

signed. Finally, once the reservation ends then the

signed agreement is terminated.

The negotiation protocol presented in this sub-

section can be deployed using both the SLA Frame-

work developed in (Amato et. al., 2012) and, the

WS-Agreement standard. Although those implemen-

tation details are out of the scope of this paper, in the

next section we show the feasibility of the proposed

approach with a real case study.

5 CASE STUDY: NEGOTIATING

CAIQ-BASED SECURITY

In order to demonstrate how the proposed negotia-

tion mechanism can be used with real-world infor-

mation, in this section we present a case study that

uses the CSP data stored in CSA STAR (Cloud Se-

curity Alliance, 2011b), a publicly available reposi-

tory that documents the security controls provided by

CSPs worldwide. We show that our user-centric nego-

tiation mechanism can use STAR data (i) to establish

a common semantic with respect to the security of-

fered by the CSP and, (ii) to enable Cloud customers

automatically choose the CSP that better fulﬁlls their

security requirements. As mentioned in Section 3, the

STAR repository contains only static security controls

(i.e., not updated in real-time by the CSP), however

the proposed negotiation approach can be easily ex-

tended to manage real-time information e.g., gener-

ated by continuous security monitoring systems (cf.,

Section 7).

Listing 3: A Guarantee Term element in WS-Agreement.

<wsag:GuaranteeTerm wsag:Name=”

UserRequirementOnCustomerAccess ”

Obl igated =” Pr ovi der ”>

<ws ag:ServiceScope ServiceName=”

s t ri n g ”> S e c u r i t y A r ch i t e ct u r e< /

wsag:ServiceScope>

SA−01.1 EQ true , Weight EQ 0 . 5 )

AND (SA−01.Q1 EQ SLA, Weight

EQ 0. 5)

< / wsag:Cus tomServiceL evel>

</ wsa g:S erv iceLev elO bje c ti ve>

. . . . .

</ w sag :Bu si nes sV alu eL ist>

< / wsag:GuaranteeTerm>

The main goal of this case study is to show the fea-

sibility of our approach, so it has been simpliﬁed with

respect to the information (i.e., amount of STAR’s se-

curity controls) being used. Nevertheless, the base

negotiation techniques can be applied to more com-

plex case studies (as we will show in future research).

In this section we also assume that an user only wants

to specify in her User SecLA some speciﬁc require-

ments, mostly related to the security mechanisms im-

plemented by the CSP. Using the CAIQ terminology

(Cloud Security Alliance, 2011a), this user require-

ment translates to an User SecLA containing only the

parameters under the Security Architecture (SA) con-

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

538

























































































Figure 5: SecLA tree for the Security Architecture (SA) category of the CAIQ reports (Cloud Security Alliance, 2011a).

trol (cf., Figure 5).

As mentioned in Section 3, the user expresses her

security requirements as a WS-Agreement document

that is, in terms of both a service and guarantee terms

(cf. Section 3). More speciﬁcally, the user can de-

ﬁne a GT over a particular service in the form of an

assertion in the SLO element. This is the basis for

applying the negotiation process described in Section

4. It should be noticed that all three the GT element,

the CAIQ and the QPT (cf., Section 2) have the same

hierarchical structure, therefore the user can specify

her requirements with different levels of granularity.

For example, she can deﬁne a minimum requirement

at the “root” SA control, but also at each one of its

“leaf” sub-controls (e.g., SA-01, SA-01.Q1, ...) just

as shown in Listings 3 and 4. Furthermore, these ex-

cerpts of the WS-Agreement document also show that

numeric weights can be assigned to individual con-

trols, in order to represent its relative importance from

a user perspective.

Listing 4: A Guarantee Term element in WS-Agreement.

<wsag:GuaranteeTerm wsag:Name=”

UserRequirementOnSecurityArch ”

Obl igated =” Prov ider ”>

<ws ag:ServiceScope ServiceName=”

s t r i n g ”> S e c u r i t y A r c h i t e c t u r e< /

wsag:ServiceScope>

<wsag:CustomServiceLevel>

( CustomerAccessRequirements EQ

0. 4 , Weight EQ 0 . 5 )

AND ( Us er IDCredentials EQ 0. 4 ,

Weight EQ 0 . 5 )

AND ( D a t a S e c u r i t y I n t e g r i t y EQ 0 .4 ,

Weight EQ 0 . 5 )

AND ( A p p li c a t i o n S e c u r i t y EQ 0.4 ,

Weight EQ 0 . 5 )

AND ( Da t a I n t e g r i t y EQ 0.4 , Weight

EQ 0. 5 )

AND ( ProductionEnviron ments EQ

0. 4 , Weight EQ 0 . 5 )

AND ( RemoteUserMultifactorAuth EQ

0. 4 , Weight EQ 0 . 5 )

AND ( Segmentation EQ 0 .4 , Weight

EQ 0. 5 )

AND ( Cloc kSy nch ro niz atio n EQ 0. 4 ,

Weight EQ 0 . 5 )

AND ( E q u i p m e nt I n d e nt i f i ca t io n EQ

0. 4 , Weight EQ 0 . 5 )

AND (

Aud itL og gin gI nt r us i o nD e te ct i on

EQ 0.4 , Weight EQ 0 . 5 )

< / wsag:Cus tomServiceL evel>

</ wsa g:S erv iceLev elO bje c ti ve>

. . . . .

</ w sag :Bu si nes sV alu eL ist>

< / wsag:GuaranteeTerm>

Tables 1 and 2 show the quantitative results of

the negotiation process, after applying the evaluation

technique (cf., Section 2.2) to the following set of

Cloud SecLAs:

• Three well-known CSPs (i.e., CSP1 to CSP3)

taken from the CSA STAR repository

• Two different user requirements with the same

relative weights per-SA control. The ﬁrst one

(User

min

) using the minimum allowable security

levels (i.e., LSL = 1), whereas the second one

(User

max

) using the maximum (i.e., LSL = 4). No-

tice that three SA-controls (i.e., SA-08, SA-10,

SA-11) are not shown in the results, because they

did not apply to the evaluated CSPs.

Obtained results in Tables 1 and 2, show that at

the SA Aggregated level the contributed negotiation

methodology allows ranking the available CSPs as

{CSP

, CSP

} forUser

min

, but as {CSP

, CSP

CSP

} for User

max

. As a rule of thumb, the more

appropriate CSP (i.e., the one that best fulﬁlls the

user requirement) will be the one with the quantitative

score closest to zero (i.e., the User SecLA baseline).

Finally, the resulting set of ranked CSPs is returned to

user, so she can either (i) automatically decide the one

to use (i.e., the best ranked) or, (ii) manually apply ad-

ditional criteria for the decision making process (e.g.,

CSP price). Future research will also focus on the

evaluation of non-security related parameters, which

Due to STAR’s usage restrictions, it is not possible to

disclose the real identity of the CSPs under evaluation.

NegotiatingandBrokeringCloudResourcesbasedonSecurityLevelAgreements

539

Table 1: Quantitative evaluation of the User

min

SecLA re-

quirement.

CSP

SA Aggregated 2.86 2.16 2.6

SA-01 1.50 3.00 2.50

SA-02 3.00 1.29 2.14

SA-03 3.00 3.00 3.00

SA-04 3.00 1.50 3.00

SA-05 3.00 3.00 3.00

SA-06 3.00 0 3.00

SA-07 3.00 3.00 0

SA-09 3.00 3.00 3.00

SA-12 3.00 3.00 3.00

SA-13 3.00 0 3.00

SA-14 3.00 3.00 3.00

Table 2: Quantitative evaluation of the User

max

SecLA re-

quirement.

CSP

SA Aggregated -0.14 -0.84 -0.4

SA-01 -1.50 0 -0.50

SA-02 0 -1.71 -0.86

SA-03 0 0 0

SA-04 0 -1.50 0

SA-05 0 0 0

SA-06 0 -3.00 0

SA-07 0 0 -3.00

SA-09 0 0 0

SA-12 0 0 0

SA-13 0 -3.00 0

SA-14 0 0 0

might be taken into account to perform a more com-

prehensive negotiation process.

6 RELATED WORK

To the best of our knowledge, there are only two pre-

vious works related with the idea proposed in this

paper for Cloud ecosystems. The ﬁrst one was con-

tributed by Max (Rak et al., 2011a), where authenti-

cation and authorization mechanisms are negotiated

between users and CSPs via a SLA-based interface

in the context of the EU FP7 mOSAIC project (mO-

SAIC, 2011). Our research improves over the ideas

described in (Rak et al., 2011a), by contributing with

a common semantic (the Cloud SecLA) and an evalu-

ation technique to quantitatively match the user’s se-

curity requirements with respect to a set of available

CSP. In the second related work Hale (Hale and Gam-

ble, 2012) introduced SecAgreements, a framework

for negotiating Cloud security risks via (i) a SLA-

based matchmaking algorithm and, (ii) a set of exten-

sions proposed for the WS-Agreement protocol (An-

drieux et al., 2007). Despite the similarities with our

research, on one hand SecAgreements’ matchmak-

ing algorithm is not user-centric and only can specify

weights at the individual security provision-level,thus

lacking of the usability offered by our evaluation ap-

proach (cf., Section 2.2). On the other hand, as future

work we are planning to research if the risk-based ap-

proach proposed by SecAgreements (Hale and Gam-

ble, 2012) might be used to complement our own ne-

gotiation methodology.

7 CONCLUSIONS

In this paper we have introduced the foundations for

negotiating and brokering Cloud resources based on

the notion of Security Level Agreements. At the core

of the negotiation stage is a user-centric technique

for quantitatively evaluating and ranking SecLAs, be-

ing developed within the EU FP7 ABC4Trust project

(ABC4Trust, 2011). Through the notion of Cloud

SecLAs, our quantitative evaluation technique offers

a common semantic to systematically match a User

SecLA requirement with respect to the most appropri-

ate CSP. Based on our experience within the EU FP7

mOSAIC project (mOSAIC, 2011), this paper also

presented an architecture and protocol to implement

the proposed Cloud negotiation mechanism. The fea-

sibility of the proposed approach was demonstrated

through a real-world case study that used the CSP

information contained in the CSA STAR repository

(Cloud Security Alliance, 2011b).

Despite STAR contains only static/declarative in-

formation about CSPs, our negotiation approach has

the potential to use also “dynamic” security data (e.g,

measured in real-time by network sensors), directly

embedded into the WS-Agreement protocol. We have

also shown that the contributed methodology is suit-

able for Cloud Federations, where the negotiation of

security parameters is a critical factor taking into ac-

count the amount of available CSP.

Once the envisioned architecture is deployed us-

ing the mOSAIC framework (mOSAIC, 2011), fu-

ture work will empirically analyze in detail the tech-

nical trade-offs (e.g., from the performance perspec-

tive) between SLA-based resource negotiation and,

the SecLA-based mechanism presented in this paper.

Finally, future activities will also research “advanced”

negotiation features not considered so far e.g., re-

negotiation and continuous monitoring.

CLOSER2013-3rdInternationalConferenceonCloudComputingandServicesScience

540

ACKNOWLEDGEMENTS

Research supported in part by the Deutsche

Forschungsgemeinschaft (German Research Founda-

tion) Graduiertenkolleg 1362 - DFG GRK 1362, the

EC FP7 project ABC4Trust (Grant Agreement no.

257782), the FP7-ICT-2009-5-256910 (mOSAIC)

and Loewe TUD CASED.

REFERENCES

ABC4Trust (2011). ABC4Trust FP7. Online: http://

www.abc4trust.eu/.

Almorsy et al., (2011). Collaboration-Based Cloud Com-

puting Security Management Framework. In Proc.

of IEEE Intl Conference on Cloud Computing, pages

364–371.

Amato et al., (2012). SLA Negotiation and Brokering for

Sky Computing. In Procs. of the Intl. Conference on

Cloud Computing and Services Science, pages 611–

620. SciTePress.

Andrieux et al., (2007). Web Services Agreement Spec-

iﬁcation (WS-Agreement). Technical Report TR-

WSAgreement-2007, Open Grid Forum.

Bernsmed et al., (2011). Security SLAs for Federated Cloud

Services. In Proc. of IEEE Availability, Reliability and

Security, pages 202–209.

Casola, V., Preziosi, R., Rak, M., and Troiano, L. (2005). A

reference model for security level evaluation: Policy

and fuzzy techniques. J. UCS, 11(1):150–174.

Casola et al., (2006). A SLA evaluation methodology in

Service Oriented Architectures. In Quality of Protec-

tion, volume 23 of Springer Advances in Information

Security, pages 119 – 130.

Cloud Security Alliance (2011a). The Consensus As-

sessments Initiative Questionnaire. Online: https://

cloudsecurityalliance.org/research/cai/.

Cloud Security Alliance (2011b). The Security, Trust

& Assurance Registry (STAR). Online: https://

cloudsecurityalliance.org/star/.

Cloud Security Alliance (2012). Security and Privacy

Level Agreements working groups. Online: https://

cloudsecurityalliance.org/research/pla/.

Dekker and Hogben, (2011). Survey and analysis of se-

curity parameters in cloud SLAs across the European

public sector. Technical Report TR-2011-12-19, Eu-

ropean Network and Information Security Agency.

Hale and Gamble, (2012). SecAgreement: Advancing Se-

curity Risk Calculations in Cloud Services. In Proc.

of the IEEE World Congress on Services, pages 133 –

140.

Kandukuri et al., (2009). Cloud Security Issues. In Procs.

of the IEEE Intl. Conference on Services Computing,

pages 517–520.

Luna et al., (2011). A Security Metrics Framework for the

Cloud. In Proc. of Security and Cryptography, pages

245–250.

Luna et al., (2012a). Benchmarking Cloud Security Level

Agreements Using Quantitative Policy Trees. In Proc.

of the ACM Cloud Computing Security Workshop.

Luna et al., (2012b). Quantitative Assessment of Cloud Se-

curity Level Agreements: A Case Study. In Proc. of

Security and Cryptography.

mOSAIC (2011). mOSAIC FP7. Online: http://

www.mosaic-cloud.eu/.

Rak et al., (2011a). A SLA-based interface for security

management in cloud and GRID integrations. In Proc.

of the IEEE Intl. Conf. on Information Assurance and

Security, pages 378 – 383.

Rak et al., (2011b). User Centric Service Level Manage-

ment in mOSAIC Application. In Procs. of the Eu-

ropar Workshop. Springer.

Samani et al., (2011). Common Assurance Maturity

Model: Scoring Model. Online: http://common-

assurance.com/.

Savola et al., (2010). Towards Wider Cloud Service Appli-

cability by Security, Privacy and Trust Measurements.

In Proc. of IEEE Application of Information and Com-

munication Technologies, pages 1–6.

NegotiatingandBrokeringCloudResourcesbasedonSecurityLevelAgreements

541
