HoneydV6: A Low-interaction IPv6 Honeypot

Sven Schindler

, Bettina Schnor

, Simon Kiertscher

, Thomas Schefﬂer

and Eldad Zack

Department of Computer Science, University of Potsdam, Potsdam, Germany

Department of Electrical Engineering, Beuth Hochschule, Berlin, Germany

EANTC AG, Berlin, Germany

Keywords:

IPv6, Honeypot, Darknet, IPv6 Trafﬁc Analysis.

Abstract:

This paper starts with the presentation of results from an IPv6-darknet experiment that we conducted during

summer 2012. The experiment indicates that attackers are gaining interest in IPv6 networks and appropriate

security tools need to be readied. Therefore, we propose HoneydV6, a low-interaction IPv6 honeypot that can

simulate entire IPv6 networks and which may be utilized to detect and analyze IPv6 network attacks. Our

implementation extends the well-known low-interaction honeypot Honeyd. To the best of our knowledge, this

is the ﬁrst low-interaction honeypot which is able to simulate entire IPv6 networks on a single host. The huge

IPv6 address spaces requires new approaches and concepts in order to enable attackers to ﬁnd and exploit a

honeypot. We increase the chance for an attacker to ﬁnd a target host in our IPv6 honeypot by reacting to the

attacker’s requests with the dynamic generation of new IPv6 host instances in the honeynet.

1 INTRODUCTION

In June 2012, the Internet Society arranged the World

IPv6 Launch Day, an event where well-known service

providers and web companies like Google or Yahoo!

started to enable IPv6 support for their customers.

With the increasing number of service providers

offering IPv6, the number of attackers aiming for

these networks may increase. In order to get an idea

of the current threat level in IPv6 networks, we started

an IPv6-darknet experiment in March 2012 using a

/48 network. A darknet is an address space that is

advertised and routed but does not provide any ser-

vices (Ford et al., 2006). All trafﬁc entering a darknet

can be considered malicious. This eases classiﬁcation

and subsequent analysis, because we do not have to

separate production trafﬁc from attack trafﬁc.

Due to the huge IPv6 address space, brute-force

network scanning of IPv6 addresses is not attractive

for an attacker and hence the probability to catch at-

tackers in a darknet is low. Nevertheless, the results

of our darknet experiment show that malicious IPv6

trafﬁc is existent and increasing.

There may also arise new threats that are aimed

at speciﬁc weaknesses in the IPv6 design. A well-

known example for this trend is the published THC-

IPv6 Attack Toolkit (Heuse, nd) which exploits sev-

eral protocol-speciﬁc features, such as the IPv6 State-

less Address Autoconﬁguration (Thomson et al.,

2007).

In order to analyse IPv6-related attacks, IPv6-

enabled security tools like Intrusion Detection Sys-

tems or virtual honeypots have to be deployed that

allow a deeper analysis of attack patterns. Virtual

honeypots provide an excellent mechanism to col-

lect information about network attacks and vulner-

abilities, because they provide a level of interactiv-

ity that cannot be achieved by darknets. A virtual

honeypot is a security device that has no production

value (Seifert et al., 2006). This can be something

like a computer or even a mobile phone which only

purpose is to attract attackers, so that their attacks can

be analysed. Low-interaction honeypots like Hon-

eyd (Provos, 2003) may even be used to simulate large

networks with thousands of routers and hosts.

We chose to extend the low-interaction IPv4 hon-

eypot Honeyd to HoneydV6, since it is able to simu-

late entire IPv4 networks on a single computer and

provides a lot of components that could be reused

in our IPv6 implementation. Further, Honeyd is the

fundamental part of a number of honeypot solutions

like Tiny Honeypot or the SCADA HoneyNet Project

and can be used to improve the capabilities of hon-

eypots like Nephentes (CERT Polska, 2012). There-

fore, by implementing IPv6 functionality into Hon-

eyd, the aforementioned honeypots may be adapted so

Schindler S., Schnor B., Kiertscher S., Schefﬂer T. and Zack E..

HoneydV6: A Low-interaction IPv6 Honeypot.

DOI: 10.5220/0004515100860097

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 86-97

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

that they are able to handle IPv6 connections as well.

Honeyd implements a customized network stack

to handle multiple simulated hosts on a single ma-

chine. The large number of available addresses in a

single IPv6 network requires a new honeynet design

approach. The static placement of virtual components

does not work, because an attacker is unlikely to ﬁnd

a deployed honeypot within the large IPv6 address

space by chance. We therefore developed the concept

of random IPv6 request processing to allow attackers

to dynamically ﬁnd and exploit our simulated hosts.

The next section presents the results from our

darknet experiment. Section 3 summarizes related

work. In Section 4 and 5, we present the IPv6 exten-

sion of Honeyd. Section 6 shows the results of per-

formance measurements of HoneydV6 and Section 7

concludes our work.

2 EXAMINING THE THREAT

LEVEL IN IPv6 NETWORKS

A couple of years ago, it was hard to ﬁnd any mali-

cious or even unintentional trafﬁc in IPv6 networks.

In 2006, Matthew Ford et al. published a trafﬁc

statistic of their IPv6 darknet with a /48 preﬁx, which

may have been the world’s ﬁrst IPv6 darknet (Ford

et al., 2006). Within approximately 16 months, they

captured about 12 ICMPv6 packets which were most

probably caused by misconﬁguration and typograph-

ical errors resulting from the long and unwieldy IPv6

addresses. In comparison, Pang et al. observed in

2004 about 30,000 packets of background radiation

per second in a class A IPv4 network (Pang et al.,

2004).

In 2010, Geoff Huston presented the results of

his darknet experiment where he examined the back-

ground radiation in a 2400::/12 network provided by

APNIC for 9 days (Huston, 2010). The darknet re-

ceived about 21,000 packets. However, the used /12

address block was not vacant and about 1.6 percent

of the network addresses had already been allocated.

Therefore, it is hard to compare the results of this ex-

periment to earlier darknet results even though trafﬁc

which was directed to allocated addresses was ﬁltered

before further analysis. It is assumed that the received

trafﬁc is caused by misconﬁguration and probably a

small number of guess probes. Scans that are deﬁ-

nitely produced by bots or viruses could not be de-

tected.

We set up a new /48 IPv6 darknet and monitored

the incoming trafﬁc for 9 months including the time

around the World IPv6 Launch to conﬁrm this as-

sumption. The address space was provided by the

tunnel broker “Hurricane Electric” and the incoming

trafﬁc was tunnelled to our machine using a SIT tun-

nel.

While the probability that an attacker choses an

IPv6 address from our darknet is about 2

−48

, we ob-

served a total number of 1172 packets. The whole

trafﬁc consists of TCP packets, much to our surprise,

we didn’t receive a single UDP or ICMPv6 packet.

Figure 1 shows the temporal distribution of the re-

ceived packets. As predicted, we received most of

the trafﬁc around the World IPv6 Launch day. Even

though the number of received packets has decreased

since the World IPv6 Launch, we are still constantly

receiving packets.

100

120

140

160

180

200

Jan Feb Mar Apr May Jun Jul Aug Sep Oct

Number of received Packets

Date (months)

Darknet activity

Figure 1: Number of received packets per day, increased

number of packets around the World IPv6 Launch day.

2.1 Backscatter

Most of the TCP trafﬁc (1157 packets) seems to be

backscatter. This kind of trafﬁc can be caused by mis-

conﬁguration or by attackers who intentionally use

spoofed source addresses when sending packets to a

destination. The destination under attack creates a re-

spond packet to the spoofed source address. So in our

case, attackers spoofed addresses that belong to our

darknet address space.

In case of TCP it is rather simple to spot backscat-

ter trafﬁc. A TCP handshake is essential to enable the

connection setup. Normally, this handshakecannot be

completed if the initiating client uses a spoofed source

address. If a target receives the initial TCP hand-

shake packet, where the SYN ﬂag is set in the TCP

header, it tries to complete the handshake by answer-

ing with a TCP packet where SYN and ACK ﬂags

are set. Hence, the reception of TCP darknet trafﬁc,

where SYN and ACK ﬂags are set, is a good indica-

tion of backscatter. Of course, it is possible to gen-

erate TCP packets with SYN and ACK ﬂags set and

send it directly to a destination. However, we con-

cluded that the intentional forwarding of such packets

HoneydV6:ALow-interactionIPv6Honeypot

to our darknet is very unlikely, since they would serve

no known purpose.

We continued our attack evaluation with an anal-

ysis of the attacked ports. Table 1 provides a source

port statistic for the received backscatter trafﬁc.

Table 1: Source ports of the received backscatter packets.

Number of packets Source port Description

486 113 auth

327 22 ssh

186 6667 ircd

158 80 http

Port 113 belongs to the most occurring source

ports in our backscatter trafﬁc. It is actually used

by the Ident protocol (Johns, 1993) which is able to

identify an owner of a TCP connection on a remote

multi-user system. The protocol is still used, for ex-

ample by IRC servers which connect back via Ident

to a requesting source in order to ensure a user’s iden-

tity (Oikarinen and Reed, 1993).

The 486 received packets with source port 113

came from 8 different source IPs. They are aimed

for 457 different destination IPs. This indicates that

457 different clients tried to connect to 8 different

servers. A peculiar aspect of all packets received

on port 113 is an unaltered acknowledgment number

for most of the sources with different destination ad-

dresses. Hence, the TCP handshake must have always

been initiated with the same initial sequence num-

ber with different source addresses. In some cases,

even the sequence number as well as acknowledgment

number stay unaltered.

As you can see in Table 1, we received 327 pack-

ets from source port 22 (ssh). The packets came from

8 different sources and were targeted at 295 differ-

ent destinations. Two of the source addresses are

also contained in the set of packets coming from port

113. Similar to the packets coming from port 113,

most packets from the same source share the same

acknowledgment number even though the targets are

different.

Furthermore, we received 186 packets targeted at

port 6667, commonly used by IRC (Kalt, 2000). All

packets came from the same source but had a different

destination addresses. The acknowledgment number

of all packets is equal.

We received further 158 packets coming from one

source IP using source port 80. Like the packets com-

ing from port 6667, the acknowledgment number and

the target port always stays the same, with one excep-

tion. The last packet received contains a different des-

tination port and a different acknowledgment number.

Geoff Huston also reported a huge amount of TCP

backscatter trafﬁc where ACK and SYN ﬂags are set.

He assumes misconﬁguration as one possible expla-

nation for receiving these packets in his darknet. In

our case, almost all packets coming from the same

source, even packets with different target addresses,

share the same target port and acknowledgment num-

ber. This indicates a deliberate use of spoofed source

addresses when connecting to the server. It is possible

that these packets belong to a denial of service attack.

Because we might have seen only a subset of all pack-

ets belonging to an attack, we are not able to provide

a clearer statement about the attack’s purpose.

2.2 ACK Scans

We also received 15 packets where only the ACK ﬂag

of the TCP header is set without any sign of a prior

TCP handshake. All 15 packets are coming from the

same /64 subnet, which belongs to the address space

of the tunnel broker “Hurricane Electric”. The miss-

ing handshake suggests that these packets are part of

an ACK scan, which is usually used to evaluate ﬁlter

rules of ﬁrewalls. The source port of these packets,

however, is Microsoft’s ﬁle sharing port 445, which

belongs to the most attacked ports in the IPv4 dark-

net experiment presented in (Pang et al., 2004). Geoff

Huston also received 141 TCP packets without an ini-

tial handshake and he also concludes that these pack-

ets belong to a network probe and rules out that these

packets may belong to backscatter trafﬁc.

2.3 Summary

Even though our /48 IPv6 darknet recorded only light

trafﬁc, we can say that the IPv6 network is not free

of threats anymore. Almost all received packets were

caused by spoofed source addresses and may belong

to denial of service attacks and we even received

packets that may be network probes. So far, we did

not receive any connection attempts that may be at-

tributed to viruses or bots.

We conclude that, in contrast to earlier darknet re-

ports, the IPv6 internet has become more interesting

for attackers.

Our IPv6 darknet has been an excellent tool to as-

sess the general network threat-level, however, is not

well suited to analyse network-level attacks in more

detail. Therefore, the next section looks at IPv6 hon-

eypots.

3 RELATED WORK

The only IPv6-capable general purpose low-

interaction honeypot is Dionaea (Dionaea, nd), a

SECRYPT2013-InternationalConferenceonSecurityandCryptography

honeypot which emulates well-known services like

SMB or SIP. It is able to detect remote shellcode

attacks using the emulation library libemu (Baecher

and Koetter, nd). In contrast to Honeyd, Dionaea

does not implement a customized network stack and

a single instance of Dionaea is not able to simulate

entire IPv6 networks. Although it is possible to

create honeynets by setting up multiple instances of

Dionaea, it is more challenging to maintain multiple

machines and expenses increase as additional per-

formance is needed. This approach is not usefully

applicable for IPv6 networks if a huge number of

honeypots needs to be deployed.

There already exist different approaches to set up

honeyfarms consisting of thousands of honeypots: In

(Vrable et al., 2005), the authors presented Potemkin,

an architecture to create a honeyfarm with thousands

of virtual machine based honeypots. A gateway dy-

namically creates virtual machines for incoming re-

quests and forwards the trafﬁc to the machines. It is

not clear whether the gateway is able to process IPv6

trafﬁc. The approach needs to ﬁlter network scans

because otherwise, a new machine would have to be

created for each scanned IP address which would lead

to performance problems. Of course, Potemkin faces

the same performance issues as most high-interaction

honeypots do. While Potemkin needs a handful of

servers to simulate 64,000 machines, low-interaction

honeypots like Honeyd are able to simulate the same

number of hosts on a single end user machine.

Recently, HoneyCloud was proposed (Clemente

et al., 2012), a cloud based honeypot that aims to be

able to handle thousands of attackers and to utilize

various log mechanisms and IDS’. HoneyCloud cre-

ates new virtual machine based high-interaction hon-

eypots for each attacker and is deployed in an elastic

compute cloud (EC2) using Eucalyptus. The system

utilizes different log mechanisms and is even able to

capture keystrokes. While the Potemkin honeyfarm

may assign multiple attackers to the same target ma-

chine, HoneyCloud assigns each attacker to a separate

high-interaction honeypot which writes events into

own log ﬁles in order to avoid log ﬁle mixtures. Hon-

eyCloud accepts SSH connections only and is cur-

rently not able to handle other services or even net-

work scans. That is a drawback when trying to gather

valuable information about bots and viruses in IPv6

networks because it is necessary to monitor the whole

range of ports and services. Furthermore, the need for

a cloud infrastructure makes it hard for smaller busi-

nesses or even private researchers to deploy the hon-

eypot without falling back on commercial solutions.

4 EXTENDING Honeyd TO

Honeyd V6

Honeyd is a low-interaction honeypot which has been

developed by Niels Provos in the C programming lan-

guage and is currently available in version 1.5c on the

project website

. We chose Honeyd as base for our

IPv6 honeypot since it is able to simulate entire IPv4

networks on a single host. It provides a framework

that enables users to write service scripts for the sim-

ulated machines, e.g. a script that simulates a telnet

service and captures all log-in attempts of an attacker.

These service scripts can be bound to addresses which

are managed by Honeyd.

The simulation of entire networks in Honeyd is

accomplished by a customized network stack imple-

mentation using the network capture library libpcap

to bypass the host’s network stack. Even though

this approach is very ﬂexible, it impedes the IPv6

extension because the existing IPv6 functionality of

the host’s operating system cannot be reused. The

packet processing has to be modiﬁed and essential

parts of entirely new protocols such as ICMPv6 or

the Neighbor Discovery Protocol (NDP) have to be

implemented.

In this section, we will describe the major IPv6

speciﬁc implementations. A number modiﬁcations

require a deeper understanding of Honeyd’s architec-

ture. We will therefore provide a deeper insight into

the technical background when required.

4.1 Adapting the Conﬁguration

of Virtual Hosts

Honeyd can be conﬁgured by deﬁning all hosts to be

simulated in a conﬁguration ﬁle. The behaviour of

a simulated host can be speciﬁed via so-called sys-

tem templates. A template speciﬁes system properties

such as open ports and their assigned scripts. List-

ing 1 shows a conﬁguration ﬁle for an IPv4 network

containing two system templates called windows and

linux.

c r e a t e windows

s e t windows defa u l t t cp act i o n r e s e t

add windows t c p port 21 ” s c r i p t s / f t p . sh ”

c r e a t e li n ux

s e t l i nux de f a u l t t c p ac ti o n r e s e t

add linux tcp por t 23 ” s c r ip t s / t e l n e t . pl ”

add linux tcp por t 80 ” s c r ip t s / web . sh”

http://www.honeyd.org/

http://www.tcpdump.org/

HoneydV6:ALow-interactionIPv6Honeypot

se t windows e t h e r n e t ” aa : 0 0: 0 4 : 78 : 98 : 7 6 ”

se t linux et he rn e t ”aa : 0 0: 0 4 : 78 : 9 5 :8 2 ”

bind 192.16 8 .1. 5 windows

bind 192.16 8 .1. 6 windows

bind 192.16 8 .1. 7 linux

Listing 1: Honeyd example conﬁguration.

A template is created using the create statement

followed by the template name. In this example, the

FTP port 21 of the windows template is opened and

attached to a script called ftp.sh. The ftp.sh script

contains just enough functionality to capture all log-

in attempts, an actual log-in is not possible. The set

statement assigns a MAC address to the template. By

using the bind statement, the windows template is

bound to the addresses 192.168.1.5 and 192.168.1.6

whereas the linux template is bound to the address

192.168.1.7.

Internally, Honeyd creates a new template for each

IP address binding which are basically copies of the

original deﬁned template. The names of the copied

templates are changed from windows or linux to their

deﬁned IP addresses so that a template belonging to

an incoming connection can easily be found by its

name.

The different templates are maintained in a splay

tree ordered by their names. A splay tree is a self

balancing binary tree where recently accessed ele-

ments are located close to the root (Sleator and Tarjan,

1985). This allows an efﬁcient search for a connection

belonging to an incoming packet.

In HoneydV6, the syntax to deﬁne templates and

to assign scripts to conﬁgured ports in the conﬁgura-

tion ﬁle is left unchanged. Our modiﬁed conﬁgura-

tion parser allows users to bind templates to an IPv6

address in the same way as an IPv4 address. A bind

statement with a given IPv6 address followed by the

template name is sufﬁcient to bind a template to an

IPv6 address.

The fact that the honeypot maintains templates in

a splay tree ordered by their names in a string repre-

sentation allows us to store IPv6 and IPv4 templates

in the same tree. It might be possible to improve the

performance by storing IPv4 and IPv6 templates in

two separate trees. However, our performance tests

show that the current performance is sufﬁcient for

most scenarios (see Section 7).

4.2 Modifying Packet Processing

As soon as Honeyd receives an IPv4 packet, it

searches for the corresponding template based on the

target address. If it cannot ﬁnd a template, the packet

will silently be discarded. If a packet is received for

which Honeyd is responsible, the packet will be for-

warded to a dispatcher. The dispatcher moves the

packet further to a TCP, UDP or ICMP processor, de-

pending on the IP payload. If the packet is a fragment,

then Honeyd will wait for all fragments to arrive and

will assemble the fragment before forwarding it to the

dispatcher.

The service scripts, such as the ftp.sh script of

the previous example, are connected to the matching

connection via socket pairs. Honeyd forwards incom-

ing trafﬁc to the standard input of the assigned script

while the standard output of a script is sent back to the

attacker. In addition, scripts are able to print logging

information using their standard error output.

Similar to the IPv4 approach, HoneydV6 assem-

bles and forwards incoming IPv6 packets to a new

IPv6 packet dispatcher. We had to modify the orig-

inal TCP and UDP processor, so that they are able

to process both kinds of connections, IPv4 as well as

IPv6. The IPv6 dispatcher forwards received packets

to the new ICMPv6 or to the extended TCP and UDP

processor based on the payload type.

Fragmented IPv6 packets get reassembled before

they are forwarded to the IPv6 packet dispatcher.

This function required the implementation of an IPv6

packet assembler which evaluates the fragment exten-

sion header, if available, of each incoming packet.

The offset and length of each incoming fragment is

logged so that attacks which are based on packet frag-

mentation can easily be analysed.

Honeyd provides a number of further settings

and mechanisms such as proxy connections to high-

interaction honeypots, conditional templates and ﬁn-

gerprinting. However, these features are out of the

scope of this document.

4.3 TCP and UDP

Honeyd’s packet dispatcher passes incoming TCP

and UDP packets to the corresponding callbacks.

These callback functions are named tcp

recv cb

and udp recv cb respectively. After our modiﬁca-

tions, these functions wrap around tcp recv cb46 and

udp

recv cb46 which are able to handle IPv4 as well

as IPv6 packets.

Fortunately, these callbacks needed only minor

modiﬁcations. Depending on the address family, an

incoming packet is now mapped to the corresponding

structure as shown in the following code snippet of

the UDP callback:

if (addr

family == AF INET) {

ip = (struct ip

hdr ∗)pkt;

udp = (struct udp

hdr ∗)(pkt + (ip−>ip hl << 2));

}else if (addr

family == AF INET6) {

SECRYPT2013-InternationalConferenceonSecurityandCryptography

ip6 = (struct ip6 hdr ∗)pkt;

get

ip6 next hdr((u char ∗∗)&udp,ip6,IP PROTO UDP);

}

Listing 2: Protocol switches to handle IPv4 and IPv6.

The use of the two different structures in the same

functions had quite an impact on multiple code seg-

ments. However, this way a lot of code fragmentation

could be avoided and the packet processing is easier

to understand.

In quite a few sections of the TCP and UDP code,

the IPv4 functionality could not be reused and a pro-

tocol switch had to be implemented. One example is

the checksum and data length calculation, which had

to be updated in both callbacks.

The IPv6 packet processing needs to be aware of

possible extension headers. As shown in the previous

example, the actual payload cannot be retrieved di-

rectly, we ﬁrst have to parse the chain of possible ex-

tension headers. The function get

ip6 next hdr pro-

vides a pointer to a certain extension header or the

actual payload.

The structures to maintain UDP and TCP connec-

tions (udp

con and tcp con) include a pointer to a tu-

ple structure which holds address details of a connec-

tion:

struct tuple {

...

//currently used to store the ipv4 addresses

addr t ip src;

addr t ip dst;

//currently used to store the ipv6 addresses

struct addr src

addr;

struct addr dst

addr;

uint16

t sport;

uint16

t dport;

...

};

Listing 3: Excerpt of the modiﬁed tuple structure to main-

tain a connection.

Honeyd uses the variables ip

src and ip dst of

type ip addr t to store IPv4 addresses of a connec-

tion. This type is too small to store IPv6 addresses,

so we had to add the ﬁelds src

addr and dst addr to

store IPv6 addresses.

4.4 Fragmentation

IPv6 fragmentation handling differs from IPv4 inso-

far, as only source nodes may fragment packets. We

implemented the functions ip6

send fragments and

ip6

fragment that handle fragmentation of outgoing

IPv6 packets that are larger than the maximum trans-

mission unit (MTU) and reassemble fragmented in-

coming packets. All fragments are maintained in a

splay tree using the following fragment6 structure:

struct fragment6 {

SPLAY

ENTRY(fragment6) node;

TAILQ

ENTRY(fragment6) next;

TAILQ

HEAD(frag6q, frag6ent) fraglist;

struct addr src

addr;

struct addr dst

addr;

uint32

t ip6 id;

uint32

t total len;

uint8

t nxt hdr;

struct event timeout;

};

Listing 4: IPv6 fragment structure.

Besides address, length and ID, the structure con-

tains a queue which stores received fragments be-

longing to a packet. When a packet arrives, the

function ip6

fragment ﬁnd is used to search for al-

ready received fragments in the splay tree. If the

received packet is the ﬁrst received fragment then

ip6

fragment new is used to insert a new entry into

the splay tree. If other fragments have already been

received, then ip6

insert fragment is used to add the

packet to the fragment queue.

Outgoing packets bigger than the Honeyd MTU

are fragmented using ip6

send fragments. Path MTU

discovery has not yet been implemented and a

ﬁxed deﬁned size HONEYD

MTU is used instead.

ip6

send fragments computes the number of frag-

ments needed and prepares the fragments by insert-

ing a fragmentation extension header before using

honey

deliver ethernet6 to send each single fragment.

4.5 Implementation of the Neighbor

Discovery Protocol

While IPv4 uses ARP for address resolution, IPv6 is

based on the new so-called Neighbor Discovery Pro-

tocol (NDP). Therefore, HoneydV6 has to implement

the essential parts of NDP.

For every IPv4 template that is created, Honeyd

creates an ARP entry which contains the Ethernet ad-

dress in a splay tree that can be used later to handle

ARP requests. For IPv6 templates, HoneydV6 creates

a further splay tree representing a neighbor cache. It

contains the Ethernet addresses of all IPv6 templates

needed by the NDP.

We implemented the essential parts of NDP that

are required to properly advertise the simulated ma-

chines in the network:

• Send and Process Neighbor Solicitations - If a

machine needs the Ethernet address of a node in

HoneydV6:ALow-interactionIPv6Honeypot

the local network, it sends a neighbor solicita-

tion message to that node. A host receiving a

neighbor solicitation answers with a neighbor ad-

vertisement containing the corresponding Ether-

net address.

• Send Router Solicitations and Process Router ad-

vertisements - It is very probable that in practice

HoneydV6 will run behind a router. In order to

ﬁnd all routers and their Ethernet addresses, Hon-

eydV6 sends a router solicitation to the all routers

multicast address and afterwards collects incom-

ing router advertisements.

Because NDP goes hand in hand with ICMPv6,

the core functionality to handle NDP packets is con-

tained in icmp6.c. Honeyd’s dispatcher was modiﬁed

to forward ICMPv6 packets to the ICMPv6 dispatcher

function icmp6

recv cb. The function passes the in-

coming packet to the corresponding handler depend-

ing on the ICMPv6/NDP type.

switch(icmp6−>icmp6

type){

case ND

NEIGHBOR SOLICIT:

handle

neighbor solicitation(inter,ip6, icmp6);

break;

case ND

NEIGHBOR ADVERT:

handle

neighbor advertisement(inter,ip6, icmp6);

break;

case ND

ROUTER ADVERT:

handle

router advertisement(inter,ip6 ,icmp6);

break;

case ICMP6

ECHO REQUEST:

handle

echo request(inter,ip6, icmp6,

ntohs(ip6−>ip6

plen)+IP6 HDR LEN+ETH HDR LEN

break;

default:

syslog(LOG

DEBUG,”unhandled icmp6 type: %d”,

icmp6−>icmp6

type);

break;

}

Listing 5: ICMPv6 dispatcher.

4.6 Support for the Monitoring

of Network Scans

One of Honeyd’s advantages is its ability to simulate

entire network topologies containing virtual routers

and virtual low-interaction hosts. This mechanism

allows researchers to analyse the way network scans

are performed and how bots try to ﬁnd new hosts to

infect. RFC 5157 (Chown, 2008) suggests a num-

ber of possible ways to reveal IPv6 hosts more efﬁ-

ciently than brute-force network scanning. Network

scanning tools like scan6 of the SI6 Networks’ IPv6

Toolkit (SI6 Networks, 2012) already started to im-

plement these scanning techniques.

In order to allow researchers to observe new kinds

of scanning methods in IPv6 networks, we adapted

Figure 2: An example IPv6 network that can be simulated

using HoneydV6 and the conﬁguration presented in Listing

the internal routing mechanisms of Honeyd to support

IPv6 packet routing.

Listing 6 shows an example conﬁguration for the

network topology presented in Figure 2. In order

to simplify the conﬁguration, the conﬁguration syn-

tax corresponds with the syntax used to deﬁne IPv4

network topologies. Our example contains four vir-

tual routers and three virtual low-interaction hosts.

Incoming network packets need to traverse an entry

router, which in this example has the IPv6 address

2001:db8::99. An entry router can be deﬁned using

the route entry statement followed by the router ad-

dress and the reachable network which in this case is

2001:db8::0/32.

By using the add net and the link statement,

the entry router is directly connected to Router 2

and Router 3 with the addresses 2001:db8:1::15 and

2001:db8:1::16 respectively. Router 2 covers the

network 2001:db8:3::/48 and has the virtual low-

interaction Host 1 with address 2001:db8:3::10 at-

tached.

Because of the ﬁrst add net statement, Hon-

eydV6 knows that packets targeting the network

2001:d8:3::/48 need to be forwarded to Router 2.

A link statement deﬁnes what addresses are directly

reachable through a router. In case of Router 2, all

addresses within the network 2001:db8:3::/48 are di-

rectly reachable which includes Host 1.

In order to simulate a realistic network packet

routing, the following ICMPv6 types had to be im-

plemented:

• Time Exceeded - Each time an IPv6 packet tra-

verses a router, its hop limit gets decreased. As

soon as the hop limit reaches zero, HoneydV6

sends an ICMPv6 Time Exceeded message back

SECRYPT2013-InternationalConferenceonSecurityandCryptography

to the source.

• Destination Unreachable - If a packet is sent to an

address within Honeyd’s address space to an un-

deﬁned virtual host or to a closed UDP port then

the honeypot replies with an ICMPv6 Destination

Unreachable message.

Both packet types are essential in order to make

network scanning tools like traceroute6 work and to

allow attackers exploring the virtual network.

The simulation of physical network properties, as

provided by the Honeyd IPv4 version, was adapted to

also work with IPv6 packets. This includes the com-

putation of the hop limit of a packet and functions that

ﬁnd and compare IPv6 networks.

It is possible to deﬁne factors like packet loss or

network latency as shown in Listing 6. In this exam-

ple, a packet transfer from Router 1 to Virtual Host

1 takes about 100 milliseconds while a packet from

Router 3 to Virtual Host 3 needs about 800 millisec-

onds. If no latency is set, then a packet is passed to

the next hop without any extra delay except the time

needed for computation.

Of course, the provided example conﬁguration

requires that the covered preﬁxes are advertised

throughout the global IPv6 Internet and attacking traf-

ﬁc is forwarded to the machine HoneydV6 is running

on.

ro u t e e n t r y 2001:db8 :: 9 9 network 2001: db8 : : 0 / 3 2

bind 2001:db8 : : 9 9 rou t er 1

bind 2001:db8 : 1 : : 1 5 ro u t e r2

bind 2001:db8 : 1 : : 1 6 ro u t e r3

bind 2001:db8 : 2 : : 1 6 ro u t e r4

bind 2001:db8 : 3 : : 1 0 host1

bind 2001:db8 : 2 : : 1 0 host2

bind 2001:db8 : 4 : : 1 0 host3

ro u t e 2001:db8 :: 99

add n e t 2001:db8 : 3: : 0 / 48 2001:db8 : 1 : : 1 5

la t en cy 100 ms

ro u t e 2001:db8 :: 99

add n e t 2001:db8 : 2: : 0 / 48 2001:db8 : 1 : : 1 6

ro u t e 2001:db8 :: 99

add n e t 2001:db8 : 4: : 0 / 48 2001:db8 : 1 : : 1 6

ro u t e 2001:db8 : 1 : : 1 6

add n e t 2001:db8 : 4: : 0 / 48 2001:db8 : 2 : : 1 6

la t en cy 800 ms

ro u t e 2001:db8 :: 99 l i n k 2001:db8 : 1: : 0 / 48

ro u t e 2001:db8 : 1 : : 1 5 li n k 2001:db8 : 3 : : 0/ 4 8

ro u t e 2001:db8 : 1 : : 1 6 li n k 2001:db8 : 2 : : 0/ 4 8

ro u t e 2001:db8 : 2 : : 1 6 li n k 2001:db8 :4 : : 0 /4 8

Listing 6: Extract of HoneydV6 conﬁguration to simulate

the network shown in Figure 2.

5 PITFALLS

We faced two major issues when we extended Hon-

eyd to HoneydV6. One problem was that scope IDs,

which were embedded in link-local addresses, com-

plicated address comparisons needed to route packets.

Besides that, we had to deal with memory access vio-

lations caused by dynamic arrays. The following two

subsections explain both issues in more detail.

5.1 Scope IDs Stored in Link-local

Addresses

The link-local interface addresses that we retrieved

using the libdnet network library function intf

get

contained scope IDs directly embedded in the ad-

dress. In order to convert these addresses into

valid link-local addresses, the scope IDs had to

be removed. We wrote a simple function called

addr

remove scope id to remove the scope ID from

link-local addresses.

static void addr

remove scope id(struct addr∗ ip6) {

if (ip6−>addr

data8[0]==0xfe && ip6−>addr data8[1]==0x80) {

/∗ delete scope id ∗/

ip6−>addr

data8[2]=0;

ip6−>addr

data8[3]=0;

}

Listing 7: Function to remove scope IDs.

HoneydV6 retrieves the interface of an incoming

packet by using libpcap. Therefore there is no need to

store a removed scope ID. When HoneydV6 initializes

and inspects an interface, it removes scope IDs of all

it’s IPv6 address aliases directly after acquiring the

interface information with intf

get.

for(i=0;i<inter−>if

ent.intf alias num;i++){

if (inter−>if

ent.intf alias addrs[i].addr type == ADDR TYPE IP6){

/∗ clear the embedded scope id if its a link−local address ∗/

ip6addr = &inter−>if

ent.intf alias addrs[i];

addr

remove scope id(ip6addr);

}

Listing 8: Removing the scope IDs of all link-local alias

addresses.

5.2 Use of Dynamic Arrays

The original Honeyd version maintains information

about an interface in a custom interface structure

shown in Listing 9. This structure has a ﬁeld of type

intf

entry followed by other ﬁelds.

HoneydV6:ALow-interactionIPv6Honeypot

struct interface {

TAILQ

ENTRY(interface) next;

struct intf

entry if ent;

int if

addrbits;

struct event if

recvev;

pcap

t ∗if pcap;

eth

t ∗if eth;

int if

dloff;

char if

ﬁlter[1024];

};

Listing 9: Structure used to store interface information.

The intf

entry structure contains a dynamic array

which may overwrite the following ﬁelds. The func-

tion intf

get, which is used in interface.c to retrieve

interface information, ﬁlls the dynamic array with ad-

dress aliases depending on the amount of reserved

memory. If no further memory is available then no

alias will be returned. This was not a problem in the

IPv4 version because no address aliases needed to be

requested. In the IPv6 version, we need to ﬁnd out the

address aliases to get information about assigned IPv6

addresses too. Therefore, we extended the memory

allocation for the interface and moved the intf entry

structure to the end of the interface structure.

6 COVERING HUGE ADDRESS

SPACES USING RANDOM IPv6

REQUEST PROCESSING

The huge address space of an IPv6 subnet makes it

hard, if not almost impossible, for an attacker to ﬁnd a

single host on the network by pure chance. While this

fact is very welcome in common networks, it impedes

the behavioral analysis of an actual attacker who may

or may not be able to ﬁnd a machine.

We want to observe IPv6 network scan techniques

and analyse the attacker’s actions when he actually

ﬁnds a running host. In order to accomplish this, we

extended HoneydV6 with a mechanism that dynam-

ically creates simulated hosts on-demand and ran-

domly accepts IPv6 connections. Hence, after a cer-

tain number of connection attempts, an attacker will

deﬁnitely ﬁnd a machine to exploit.

Furthermore, all connection attempts are logged,

even to IPv6 addresses that are not deﬁned in the con-

ﬁguration ﬁle. It allows us to analyze IPv6 network

scans and to ﬁnd new scan patterns.

When a packet arrives, HoneydV6 tries to ﬁnd the

matching virtual low-interaction host. If no host can

be found, then a new template will be dynamically

created with a speciﬁed acceptance probability. A

user can enable the so-called IPv6 random mode by

using the randomipv6 statement followed by the ac-

ceptance probability. In order to deﬁne what template

to use for dynamically created machines, the name of

a default template has to be speciﬁed right after the

acceptance probability.

Consider the example conﬁguration in Listing 10

where we deﬁne the template randomdefault to be the

default template. The default template has the web

server and the FTP port open and assigned to the cor-

responding scripts. Besides the conﬁgured open ports

and the matching script assignments, the template has

a deﬁned Ethernet address. HoneydV6 replaces the

last three bytes of this Ethernet address with randomly

generated bytes for each newly created template. This

corresponds to Honeyd’s default behavior in the IPv4

version. Currently, we are supporting only one default

template.

c r e a t e randomdefault

s e t randomdefault d e f a ul t tc p a ct io n r e s e t

add randomdefault tcp po r t 21 ” s cr i p t s / ft p . sh ”

add randomdefault tcp po r t 80 ” s cr i p t s / web . sh ”

s e t randomdefault e t h e r n e t ” aa :0 0 : 04 : 7 8 :9 8 :7 8 ”

randomipv6 0.5 randomdefault 256

randomexclude 2001: db8 : : 1

randomexclude 2001: db8 : : 2

randomexclude 2001: db8 : : 3

Listing 10: Honeyd conﬁguration to randomly accept IPv6

connections.

If the honeypot randomly decides to reject a re-

quest and not to create a machine for it, then the tar-

get address will be blacklisted. Future requests to a

blacklisted address will always be ignored to keep the

system state consistent and to avoid revealingthe hon-

eypot.

In some cases it may be useful to exclude certain

addresses from the automatic template creation, e.g.

if other nodes are in the same network. This can be

done by using the randomexclude statement. An ex-

cluded address is automatically blacklisted and Hon-

eydV6 will ignore requests to this address.

It is possible to deﬁne an upper bound for the num-

ber of dynamically created templates by the honey-

pot. This number can be set after the default template

name. In the example above, the maximum number

of allowed templates is 256. It is important to re-

strict the number of dynamically created virtual low-

interaction hosts in order to avoid memory-exhaustion

attacks. Each created machine and each blacklisted

address causes memory consumption until the maxi-

mum number of allowed machines is reached.

We recommend to restrict the number of dynami-

cally created machines as well as the acceptance prob-

SECRYPT2013-InternationalConferenceonSecurityandCryptography

ability to an appropriate low value depending on the

use case. A large number of uniformly distributed

host may easily reveal the honeypot.

7 PERFORMANCE TESTS

Our modiﬁed version of Honeyd still fully contains

the original IPv4 implementation. Thus it is able to

handle IPv4 and IPv6 packets at the same time. When

we implemented the IPv6 functionality, we tried to

modify the IPv4 code as little as possible in order to

avoid new programming errors and negative impact

on the IPv4 performance. Nevertheless, in some cases

minor modiﬁcations to the IPv4 work ﬂow had to be

done. We conducted some measurements to quantify

the performance of the new IPv4 and IPv6 code in

HoneydV6.

7.1 Comparison: IPv4 and IPv6

Throughput

In order to evaluate the performance impact of our

IPv6 modiﬁcation, we compared the average appli-

cation layer throughput of the original IPv4 Honeyd

1.5c with HoneydV6. We developed a simple Hon-

eyd benchmark service script and a corresponding

client which allow us to measure the time needed to

transfer larger ﬁles over the network to the honeypot.

The original honeypot as well as the IPv6 modiﬁca-

tion were installed on a Fujitsu PRIMERGY TX200

S5 Server with an Intel Xeon processor 5500 series

and 4096 MB of RAM running Ubuntu 12.04. The

benchmark client was installed on a LenovoThinkPad

L520 with an Intel i5-2450M CPU and 4096 MB of

RAM. Both computers were connected via a Brocade

FWS648G FastIron switch using Gigabit Ethernet.

Table 2 shows the results for transferring 50 MB

and 100 MB from the client via IPv4 and IPv6 to the

honeypot benchmark service.

Table 2: Comparison of transmission time in seconds be-

tween the original Honeyd version 1.5c and HoneydV6.

Filesize 1.5c (IPv4) V6 (IPv4) V6 (IPv6)

50 MB 15.98 s 16.19 s 16.33 s

100 MB 31.85 s 31.94 s 32.36 s

For each experiment, Table 2 shows the median

from 5 runs. It takes about 16 seconds to transfer

50 MB to the honeypots and about twice as much

time to transfer 100 MB. In case of transferring 50

MB over IPv4, the original 1.5c version of Honeyd

is approximately 0.2 seconds faster than HoneydV6.

For sending 100 MB, the original Version was about

0.09 seconds faster than our modiﬁed version. This

indicates that the overhead is in the magnitude of

the measurement error and neglectable. The over-

head is most probably caused by a number of newly

added IPv4/IPv6 switches in the source code. Further-

more, the IPv6 transfer is insigniﬁcantly slower than

the IPv4 transfer of both versions. HoneydV6 needed

approximately 0.35 seconds longer than the original

1.5c version to transfer 50 MB and about 0.51 sec-

onds to transfer 100 MB over IPv6.

7.2 Scalability of HoneydV6

While throughput measurements can help to get an

impression of the performance impact caused by the

IPv6 modiﬁcations, throughput is not a very useful

criteria to evaluate a honeypot for its suitability in

a network. A honeypot like Honeyd rather needs to

be able to handle a large number of connections than

transferring huge ﬁles.

Provos and Holz measured for example the num-

ber of TCP requests per second that Honeyd is able to

process (Provos and Holz, 2008). Since we are par-

ticularly interested in the performance impact on the

application layer, we used the web server benchmark

servload (Zinke et al., 2012)

to measure the num-

ber of HTTP GET requests that HoneydV6 is able to

process per second. Servload is capable of replay-

ing a previously captured trafﬁc log ﬁle based on the

timestamps of the contained packets. We generated a

log ﬁle containing 20,000 HTTP GET requests from

different source addresses with 600 requests per sec-

ond. HoneydV6 was conﬁgured to simulate a single

machine which was bound to an IPv4 and an IPv6

address and which delivers the web.sh script that is

shipped with the original Honeyd version 1.5c when

getting requests on port 80. The web.sh script simu-

lates a Microsoft IIS 5.0 and delivers either a direc-

tory listing of the server or a 404 NOT FOUND page.

Our generated requests demanded a non-existing in-

dex.html page so that the web.sh script responses with

an HTTP 404 NOT FOUND error code and a short

explanation.

As with the throughput measurements, we re-

peated the test run for the original Honeyd 1.5c and

compared the results with the IPv6 and IPv4 requests

of HoneydV6.

As shown in Table 3, the original Honeyd version

and HoneydV6 were able to process about 212 IPv4

requests/s. HoneydV6 managed to handle about 205

IPv6 request/s without any packet loss which is cur-

rently more than sufﬁcient in an IPv6 network and

Download avaible from http://www.salbnet.org/

HoneydV6:ALow-interactionIPv6Honeypot

Table 3: Comparison of the number of HTTP GET requests

per second that Honeyd 1.5c and HoneydV6 is able to han-

dle without any packet loss.

1.5c (IPv4) V6 (IPv4) V6 (IPv6)

212.57 214.00 205.75

only slightly less than its IPv4 counterpart is able to

process.

We conﬁgured HoneydV6 to simulate just a sin-

gle target for our test runs. Since Honeyd main-

tains one connection entry for each connection in a

splay tree, regardless of existing connections with

the same target address, the performance difference

between benchmarking a single target compared to

benchmarking multiple targets is insigniﬁcant.

8 CONCLUSIONS AND FUTURE

WORK

While the general threat level in IPv6 networks is still

low compared to IPv4 networks, the results of our

IPv6-darknet experiment show the raising interest of

attackers in IPv6.

The honeypot HoneydV6 presented in this paper

provides an excellent foundation for future IPv6 net-

work security research. It can be used to observe

attacks in IPv6 networks and to reveal new network

scan approaches. HoneydV6 is based on the well-

known honeypot Honeyd which is the fundamental

part of a number of honeypot solutions like Tiny

Honeypot or the SCADA HoneyNet Project. These

projects can easily be extended to IPv6 networks us-

ing HoneydV6.

HoneydV6 is the ﬁrst low-interaction honeypot

which is able to simulate entire IPv6 networks. Be-

sides IPv6 packet processing, HoneydV6 implements

necessary parts of the ICMPv6 and the Neighbor Dis-

covery Protocol. In order to observe new kinds of

scanning methods in IPv6 networks, we adapted the

internal routing mechanisms of Honeyd to support

IPv6 packet routing. In our performance tests Hon-

eydV6 performed comparable to Honeyd for both,

IPv4 and IPv6 networks. Further, we developed a

mechanism that randomly and dynamically generates

low-interaction IPv6 hosts, based on the requests of

an attacker, in order to increase the chances that an

attacker will encounter the honeypot within the huge

IPv6 address space.

We are currently setting up a honeynet based on

HoneydV6 together with research partners to observe

how the threat level in IPv6 networks develops.

Honeyd still contains some features that are sup-

ported in IPv4 networks only. One example is the

operating system ﬁngerprintingmechanism, which al-

lows Honeyd to emulate system-speciﬁc behavior. We

currently investigate how the new nmap IPv6 ﬁnger-

print format (Nmap, nd) can be reused to simulate

the network stack parameters of different operating

systems. HoneydV6 is a useful tool to deceive at-

tackers and to analyse how an attacker interacts with

network services. However, the honeypot is not able

to inspect UDP or TCP payload for malicious con-

tent which makes it hard to extract new exploits from

the received trafﬁc. We are therefore working on a

connection between our IPv6 honeypot and the shell-

code detection library libemu (Baecher and Koetter,

nd) with the aim of simplifying remote exploit detec-

tion.

In order to promote further IPv6 research, we will

make the sources of our HoneydV6 implementation

publicly available at http://www.idsv6.de.

REFERENCES

Baecher, P. and Koetter, M. (nd). libemu x86 Shell-

code Emulation. Available from: http://libemu.

carnivore.it/.

CERT Polska (2012). ENISA Honeypot Study - Proactive

Detection of Security Incidents.

Chown, T. (2008). IPv6 Implications for Network Scan-

ning. RFC 5157 (Informational). Available from:

http://www.ietf.org/rfc/rfc5157.txt.

Clemente, P., Lalande, J.-F., and Rouzaud-Cornabas, J.

(2012). HoneyCloud: Elastic Honeypots - On-attack

Provisioning of High-Interaction Honeypots. In Inter-

national Conference on Security and Cryptography,

pages 434–439, Rome, Italy.

Dionaea (nd). dionaea catches bugs. Available from: http://

dionaea.carnivore.it/.

Ford, M., Stevens, J., and Ronan, J. (2006). Initial Results

from an IPv6 Darknet. In ICISP ’06: Proceedings of

the International Conference on Internet Surveillance

and Protection, page 13, Washington, DC, USA. IEEE

Computer Society.

Heuse, M. (nd). THC IPv6 attack tool kit. Available from:

http://www.thc.org/thc-ipv6/ [cited 09.05.2011].

Huston, G. (2010). Background Radiation in IPv6. Avail-

able from: https://labs.ripe.net/Members/mirjam/

background-radiation-in-ipv6.

Johns, M. S. (1993). Identiﬁcation Protocol. RFC

1413 (Proposed Standard). Available from: http://

www.ietf.org/rfc/rfc1413.txt.

Kalt, C. (2000). Internet Relay Chat: Architec-

ture. RFC 2810 (Informational). Available from:

http://www.ietf.org/rfc/rfc2810.txt.

Nmap (nd). Nmap Network Scanning - IPv6 ﬁnger-

printing. Available from: http://nmap.org/book/

osdetect-ipv6-methods.html.

Oikarinen, J. and Reed, D. (1993). Internet Relay Chat

Protocol. RFC 1459. Updated by RFCs 2810, 2811,

SECRYPT2013-InternationalConferenceonSecurityandCryptography

2812, 2813. Available from: http://www.ietf.org/rfc/

rfc1459.txt.

Pang, R., Yegneswaran, V., Barford, P., Paxson, V., and

Peterson, L. (2004). Characteristics of internet back-

ground radiation. In Proceedings of the 4th ACM SIG-

COMM conference on Internet measurement, IMC

’04, pages 27–40, New York, NY, USA. ACM.

Provos, N. (2003). Honeyd: A Virtual Honeypot Daemon.

Technical report, Center for Information Technology

Integration, University of Michigan.

Provos, N. and Holz, T. (2008). Virtual Honeypots - From

Botnet Tracking to Intrusion Detection. Addison-

Wesley.

Seifert, C., Welch, I., and Komisarczuk, P. (2006). Taxon-

omy of honeypots. Technical report, Victoria Univer-

sity of Wellington, Wellington.

SI6 Networks (2012). SI6 Networks’ IPv6 Toolkit

- A security assessment and troubleshooting tool

for the IPv6 protocols. Available from: http://

www.si6networks.com/tools/ipv6toolkit.

Sleator, D. D. and Tarjan, R. E. (1985). Self-adjusting bi-

nary search trees. J. ACM, 32(3):652–686. Available

from: http://doi.acm.org/10.1145/3828.3835.

Thomson, S., Narten, T., and Jinmei, T. (2007). IPv6

Stateless Address Autoconﬁguration. RFC 4862,

Internet Engineering Task Force. Available from:

http://tools.ietf.org/html/rfc4862.

Vrable, M., Ma, J., Chen, J., Moore, D., Vandekieft, E.,

Snoeren, A. C., Voelker, G. M., and Savage, S. (2005).

Scalability, Fidelity, and Containment in the Potemkin

Virtual Honeyfarm. In Proceedings of the twenti-

eth ACM symposium on Operating systems princi-

ples, SOSP ’05, pages 148–162, New York, NY, USA.

ACM.

Zinke, J., Habenschuß, J., and Schnor, B. (2012). servload:

Generating Representative Workloads for Web Server

Benchmarking. In International Symposium on Per-

formance Evaluation of Computer and Telecommuni-

cation Systems (SPECT), Genoa.

HoneydV6:ALow-interactionIPv6Honeypot
