Instance-based Anomaly Method for Android Malware Detection

Borja Sanz, Igor Santos, Xabier Ugarte-Pedrero, Carlos Laorden, Javier Nieves and Pablo G. Bringas

S3Lab, University of Deusto, Avenida de las Universidades 24, Bilbao, Spain

Keywords:

Security, Malware, Android.

Abstract:

The usage of mobile phones has increased in our lives because they offer nearly the same functionality as

a personal computer. Besides, the number of applications available for Android-based mobile devices has

increased. Android application distribution is based on a centralized market where the developers can upload

and sell their applications. However, as it happens with any popular service, it is prone to misuse and, in

particular, malware writers can use this market to upload their malicious creations. In this paper, we propose a

new method that, based upon several features that are extracted from the AndroidManifest ﬁle of the legitimate

applications, builds an anomaly detection system able to detect malware.

1 INTRODUCTION

Smartphones have become an indispensable gadget in

our daily lives. We check our email, browse the Inter-

net, or play games with our friends, wherever we are.

However, in order to take advantage of every possibil-

ity they may offer, applications have to be previously

installed in the devices. In the past, the installation of

applications was uncomfortable for the users because

the process was complicated: users had to look for the

desired application in the Internet and, after ﬁnding it,

they had to install it in their devices.

Afterwards, new methods for distribution and in-

stallation were developed taking advantage of the In-

ternet connection available in mobile devices. Users

can now install any application without a personal

computer, by using application stores that are already

installed in the devices. Apple’s AppStore was the

ﬁrst online store to bring this new paradigm for users.

Since then, other vendors such as RIM, Microsoft or

Google have adopted the same model and deployed

application stores for their devices. These factors

have contributed to the popularity of smartphones and

thus, the number of applications has increased. In par-

ticular, Apple’s App Store offers more than 800,000

applications to their users

while Google’s Play Store,

Android’s ofﬁcial application store, hosts 675,000

apps

Unfortunately, application markets are also sus-

http://www.apple.com/pr/library/2013/01/

28Apple-Updates-iOS-to-6-1.html

http://ofﬁcialandroid.blogspot.com.es/search?q=675000

ceptible of hosting malware. In order to deal with

these threats, Android and iOS use different ap-

proaches. While Apple applies a very strict review

process for the submitted applications performed by

at least two reviewers, Android relies on its secu-

rity permission system and on the user’s sound judge-

ment. However, users may not have security con-

sciousness and may not read the required permis-

sions before installing an application (Mylonas et al.,

2012). Despite these efforts, both vendors have

hosted malware in their stores (Egele et al., 2011;

Zhou and Jiang, 2012). Therefore, both models are

not sufﬁcient to ensure user’s safety and new models

should be developedand deployed in order to improve

the security of the devices.

With regards to Android malware, Zhou et al.

(Zhou and Jiang, 2012) created a big Android mal-

ware collection between 2010 and 2011. They ob-

tained 23 samples in January 2011 and 1,260 in Oc-

tober 2011 (which represented an increase of over

5,000%). They conducted a thorough study on this

subject and analysed its evolution in recent times.

They concluded that Android malware has shown a

rapid increase in both sophistication and number of

new samples. Besides, they show that more than 80%

of the malware samples repackage legitimate apps

and 93% of them exhibit a botnet-like capability.

Several approaches have been proposed to detect

these malicious software in Android. Shabtai et al.

(Shabtai et al., 2010) trained several machine learn-

ing models using the following features: the count

of elements, attributes and namespaces of the parsed

Android Package File (.apk). To validate their mod-

387

Sanz B., Santos I., Ugarte-Pedrero X., Laorden C., Nieves J. and G. Bringas P..

Instance-based Anomaly Method for Android Malware Detection.

DOI: 10.5220/0004529603870394

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 387-394

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

els, they selected features using three selection meth-

ods: Information Gain, Fisher Score and Chi-Square.

Their approach achieved 89% of accuracy classifying

applications into only 2 categories: tools or games.

Albeit this research was not explicitly focused in mal-

ware detection, their authors suggest the usage of this

technique to detect malware as further work. Be-

sides, other proposals use dynamic analysis for the

detection of malicious applications. Crowdroid (Bur-

guera et al., 2011) is an approach that analyses the

behaviour of the applications through device usage

features. Blasing et al. created AASandbox (Blas-

ing et al., 2010), which is a hybrid dynamic-static

approximation. The approach is based on the anal-

ysis of the logs for the low-level interactions obtained

during execution. Shabtai and Elovici (Shabtai and

Elovici, 2010) also proposed a Host-Based Intrusion

Detection System (HIDS) which used machine learn-

ing methods to determine whether an application is

malware or not. Google itself has also deployed a

framework for the supervision of applications called

Bouncer. Oberheide and Miller 2012

revealed how

the system works: it is based in QEMU and performs

both static and dynamic analysis.

Against this background, we present a new tech-

nique for the detection of malicious Android executa-

bles. This approach uses several features extracted

by analysing the Manifest ﬁle of Android applica-

tions. In particular,we use the

uses-permission

and

the

uses-feature

tags within the manifest ﬁle. Us-

ing these features of several legitimate applications,

we build an instance-based anomaly detection method

able to detect anomalous malicious applications.

The reminder of this paper is organised as follows.

Section 2 details the generation of the dataset. Sec-

tion 3 presents the permissions used in our approach.

Section 4 describes our anomaly detection method.

Section 5 shows the results obtained for the empirical

evaluation. Section 6 details the related work. Finally,

section 7 discusses the results and shows the avenues

of further work.

2 DATASET DESCRIPTION

In this section, we describe the dataset collected to

validate our method. The dataset is composed of both

benign and malicious software. In order to compose

the dataset, the following requirements were consid-

ered: (i) it must be heterogeneous, showing diversity

in the types of applications available in the Android

market, and (ii), it must be proportional to the number

http://jon.oberheide.org/ﬁles/summercon12-bouncer.pdf

of samples of each category in the Android market.

2.1 Benign Software Dataset

We gathered 1,811 Android samples of diverse types

and categorised them using the same scheme that An-

droid market follows. To this end, we used an unof-

ﬁcial library called android-market-api

that retrieves

the category of a given application. From the cate-

gorised samples, we selected a subsample to be part

of the ﬁnal benign software dataset. The methodology

employed was the following:

1. Determine the Number of Total Samples. In order

to facilitate the training of machine-learning mod-

els, it is usually desirable for both categories to be

balanced. Otherwise, the resulting model can be

biased towards one of the classes, and the results

may not be fully representative. Therefore, given

that the number of malware samples is inferior to

the benign ones, we reduced the number of benign

applications to meet the number of the malicious

ones.

2. Determine the Number of Samples for each Be-

nign Category. We decided to balance the dataset

according to the observed distribution in the An-

droid market, and therefore, selected the number

of applications consequently.

3. Types of Application. There are different types

of applications: native ones (developed by means

of the Android SDK), web (developed through

HTML, JavaScript and CSS, which only launch

a Webkit frame) and widgets (simple applications

displayed in the Android desktop). All these ap-

plications have the same core, but different fea-

tures. To represent the heterogeneity of Android,

we included samples of each different type in the

ﬁnal dataset.

4. Selection of the Samples for each Category. Once

the number of applications for each category was

determined, we randomly selected the applica-

tions, avoiding different versions of the same ap-

plication. Table 1 shows the distribution of the

legitimate applications in the categories.

2.2 Malicious Software Dataset

The malicious samples were obtained thanks to the

company VirusTotal

. VirusTotal offers a series of

services called VirusTotal Malware Intelligence Ser-

vices, which allows researchers to obtain samples

from their databases.

https://code.google.com/p/android-market-api/

http://www.virustotal.com/

SECRYPT2013-InternationalConferenceonSecurityandCryptography

388

Table 1: Number of benign software applications.

Category Number Category Number

Action and Arcade 32 Multimedia and video 23

Books 10 Music and audio 12

Business 1 News and magazines 7

Cards Games 2 Personalization 6

Casuals 10 Photography 6

Comics 1 Productivity 27

Communication 20 Puzzles 16

Sports 5 Races 6

Enterprise 4 Sales 3

Entertainment 16 Society 25

Finance 3 Tools 80

Health 3 Transportation 2

Libraries and Demos 2 Travels 2

Lifestyle 4 Weather 8

Medicine 1

Total: 333

Initially, we collected 2,808 samples. Next, we

normalized the different outputs of the different an-

tivirus vendors. The goal of this step was to deter-

mine their reliability detecting malware in Android.

To this end, we assumed that every sample that was

detected as malware by at least one antivirus was, in-

deed, malware. Then, we evaluated the detection rate

of each antivirus engine with respect to the complete

malware dataset:

(1)

where n

is the number of samples detected by the i

antivirus and n is the total number of malware sam-

ples. Then, we evaluated each malware sample taking

into account the weight of each antivirus. For this

evaluation, we applied the next metric:

w =

∑

i=1

∈ A (2)

being A = (a

,...,a

ℓ

) the set of weights of the ℓ

antiviruses that detect that particular sample. There-

fore, w rates the detection taking into account the

antiviruses that detect the sample. We determined

a threshold to discard irrelevant samples from the

dataset that was set empirically to 0.1, which provided

us a total number of 1,202 malware samples. Finally,

we also removed every duplicated sample so the ﬁnal

malware dataset was composed of 333 unique sam-

ples.

3 FEATURE ENGINEERING

In this section, we review the different feature sets

we have considered for the detection of Android

malware. We gathered these features from the

AndroidManifest.xml

ﬁle that is packed with ev-

ery Android application. To this end, we ﬁrst ex-

tracted the permissions used by each application us-

ing the Android Asset Packaging Tool (

aapt

), avail-

able within the set of tools provided by the Android

SDK.

3.1 Permissions of the Application

The structure for declaring a

uses-permission

the

AndroidManifest.xml

ﬁle is shown in Figure 1.

<uses-permission android:name=

"string" />

Figure 1: General template for a

uses-permission

within

the AndroidManifest ﬁle.

In this way, there are several strings that

are used for declaring the permission us-

age of the different Android applications

such as

android.permission.CAMERA

android.permission.SEND SMS

We processed the

AndroidManifest.xml

ﬁle

searching for the

uses-permission

tag and retrieved

the string declaring the type of permission. After

that, we generated an input vector for each of the 130

http://developer.android.com/guide/topics/manifest/

uses-permission-element.html

Instance-basedAnomalyMethodforAndroidMalwareDetection

389

possible permissions, with a binary feature indicat-

ing whether the permission is present or not in the

analysed Android application. For example, Figure 2

shows the permission declaration of an Android ap-

plication.

...

<uses-permission android:name="

android.permission.SEND_SMS" />

<uses-permission android:name="

android.permission.INTERNET" />

<uses-permission android:name="

android.permission.READ_CONTACTS" />

...

Figure 2: Example of permission declaration in an applica-

tion.

The input vector of permissions for this ap-

plication would be composed of 127 zeros, rep-

resenting the permissions not used and 1s for

the 3

uses-permission

tags declared (

SEND SMS,

INTERNET

, and

READ CONTACTS

We selected this feature set for two main reasons:

ﬁrst, the gathering process has a low computing over-

head and, second, these features represent the be-

haviour that an application may implement.

3.2 Uses-features of the Manifest File

The

AndroidManifest.xml

ﬁle shows other features

apart from permissions. Moreover, this information

may be relevant for the task of detecting malware.

The structure for declaring a

uses-feature

in the

AndroidManifest.xml

ﬁle is shown in Figure 3.

...

<uses-feature

android:name="string"

android:required =["true"|"false"]

android:glEsVersion ="integer" />

...

Figure 3: Declaration of features in an application.

The

android:name

attribute determines the fea-

ture (e.g., camera, gps) used by the application,

the

android:required

attribute determines whether

that feature is mandatory for the correct handling of

the application or not, and the

glEsVersion

attribute

determines the version of OpenGL, if used. These at-

tributes are represented in the Manifest ﬁle under the

tag

<uses-feature>

and determine some of the fea-

tures, both software and hardware, that are required

for the correct execution of an application. In this

http://developer.android.com/guide/topics/manifest/

uses-feature-element.html

way, the use of Bluetooth or the camera are deter-

mined by the tags

android.hardware.bluetooth

and

android.hardware.camera

. Besides, these el-

ements of the Manifest ﬁle only inform about the

behaviour of the application and are not mandatory.

Even though this information is not mandatory, it is

used sometimes by other services or applications in

order to improve the interaction between the applica-

tions. Nevertheless, due to the optional character of

these features, many applications lack these ﬁelds.

In our dataset, the features extracted are related

to the use hardware such as localization by means

of the GPS, Wi-Fi, or proximity sensors. In light of

this context, we considered this information relevant

in order to determine whether an application is mal-

ware or not, because it adds some information com-

plementary to permissions and provides us with a be-

havioural view of the inspected application. In order

to use these features as input vectors for machine-

learning, we processed the

AndroidManifest.xml

ﬁle searching for the

uses-features

tag and gath-

ered the string declaring the type of feature. After

that, we generated an input vector for each of the

37 (34 hardware and 3 software) possible features,

with a binary feature indicating whether the feature

is present or not in the analysed Android application.

As an example, Figure 4 shows the declaration of

uses-features

for an Android application.

...

<uses-feature

android:name=

"android.hardware.camera"

android:required ="false" />

<uses-feature

android:name=

"android.hardware.bluetooth" />

...

Figure 4: Example of the declaration of the

uses-features

in an application.

The input vector of features for this applica-

tion will be composed of 35 zeros, representing

the not used

uses-features

and 1s representing

the 2 used features (

android.hardware.camera

and

android.hardware.bluetooth

4 ANOMALY BASED METHOD

Anomaly detection approaches model normality and

try to identify outlier occurrences. In this way, ev-

ery deviation to this model is considered anomalous.

Through the representation described in the previous

section, our method represents Android applications

SECRYPT2013-InternationalConferenceonSecurityandCryptography

390

as points in the feature space. When an application is

being inspected, our method starts by computing the

features to represent the sample as a point in the fea-

ture space. This point is then compared with the pre-

viously calculated points of legitimate applications.

To this end, distance measures are required. In this

study, we have used the following distance measures:

• Manhattan Distance. This distance between two

points v and u is the sum of the lengths of the

projections of the line segment between the points

onto the coordinate axes:

d(x,y) =

∑

i=0

− y

| (3)

where x is the ﬁrst point; y is the second point;

and x

and y

are the i

component of the ﬁrst and

second point, respectively.

• Euclidean Distance. This distance is the length

of the line segment connecting two points. It is

calculated as:

d(x,y) =

∑

i=0

− u

(4)

where x is the ﬁrst point; y is the second point;

and x

and y

are the i

component of the ﬁrst and

second point, respectively.

• Cosine Similarity. It is a measure of similarity

between two vectors by ﬁnding the cosine of the

angle between them (Tata and Patel, 2007). Since

we are measuring distance and not similarity we

have used 1−CosineSimilarity as a distance mea-

sure:

d(x,y) = 1− cos(θ) = 1−

~v·~u

||~v||·||~u||

(5)

where~v is the vector from the origin of the feature

space to the ﬁrst point x, ~u is the vector from the

origin of the feature space to the second point y,

~v ·~u is the inner product of ~v and ~u. ||~v||·||~v|| is

the cross product of~v and~u. This distance ranges

from 0 to 1, where 1 means that the two evidences

are completely different and 0 means that the evi-

dences are the same (i.e., the vectors are orthogo-

nal between them).

By means of these measures, we are able to com-

pute the deviation of an application with respect to

a set of legitimate applications. Other distance mea-

sures, such as Mahalanobis distance were discarded

due to their complexity. One characteristic of our ap-

proach is its simplicity, which allows its deployment

in smartphones with low processing capabilities.

Since we have to compute the distance of any ap-

plication to the points representing valid applications,

a combination metric is required in order to obtain

a ﬁnal distance value which considers every measure

performed. To this end, our system employs 3 sim-

plistic rules: (i) select the mean value, (ii) select the

lowest distance value and (iii) select the highest value

of the computed distances.

In this way, when our method inspects an appli-

cation, a ﬁnal distance value is acquired, which will

depend on both the chosen distance measure and a

combination rule.

5 EMPIRICAL VALIDATION

To evaluate our method, we used the dataset described

in section 2, composed by 666 samples. Speciﬁcally,

we followed the next conﬁguration for the empirical

validation:

1. Cross Validation: We performed a 5-fold cross-

validation over the benign samples to divide them

into 5 different divisions of the data into training

and test sets.

2. Calculating Distances and Combination Rules:

We extracted the

uses-permissions

and

uses-features

of the applications and com-

bined 3 different measures with 3 different

combination rules described in section 4 to

obtain a ﬁnal measure of deviation for each

testing instance. More accurately, we applied the

following distances: (i) the Manhattan Distance,

(ii) the Euclidean Distance, and (iii) the Cosine

Similarity. For the combination rules we tested

the following ones: (i) the mean value, (ii) the

lowest distance and (iii) the highest distance.

3. Deﬁning Thresholds: For each measure and com-

bination rule, we established 10 different thresh-

olds to determine whether a sample is valid or not.

The lowest threshold was conﬁgured to produce

no false negatives, while the highest one was set

to produce no false positives.

4. Testing the Method: We evaluated the method by

measuring these parameters:

• True Positive Ratio (TPR), also known as sen-

sitivity: TPR = TP/(TP+ FN) where TP are

the number of applications correctly classiﬁed

(true positives) and FN is the number of appli-

cations misclassiﬁed as valid ones.

•

False Positive Ratio

(FPR), that is the number

of legitimate applications misclassiﬁed as mal-

ware: FPR = FP/(FP+ TN) where FP is the

number of valid apps incorrectly detected as

malicious while TN is the number of valid apps

correctly classiﬁed.

Instance-basedAnomalyMethodforAndroidMalwareDetection

391

•

Accuracy

, which is the total number of hits di-

vided by the number of the instances in the

dataset: Accuracy = (TP+ TN)/(P+ N).

•

Area Under ROC Curve

(Singh et al., 2009),

establishes the relation between false negatives

and false positives.

Table 2 shows the obtained results. When we ap-

plied Manhattan distance, we obtained the best AUC

value (0.88), using average as the combination rule.

The accuracy obtained was around 85% for this com-

bination. Using euclidean distance, we obtained more

than 0.90 of AUC and 87.57% of accuracy. Finally,

using cosine distance, we obtained the best results:

0.91 of AUC and nearly 90% of accuracy.

In general, the results obtained surpassed 0.8 of

AUC and 80% of accuracy for all distances, consid-

ering the average as a combination rule in the three

cases.

6 RELATED WORK

In order to tackle the problem of growing malware in

Android, researchers have begun to explore this area

using the experience acquired in other platforms. We

can distinguish two different approaches. Dynamic

approaches execute the sample in an isolated environ-

ment and collect data about its execution. These ap-

proaches require high computational efforts and are

not suitable for the deployment on smartphones. Be-

sides, static approaches analyse the samples without

executing them. Some attempts are based on sig-

nature scanning, that is, detecting known patterns

present in malicious applications, while others try to

implement generic approaches to distinguish patterns

in benign or malicious applications.

Shabtai and Elovici (Shabtai et al., 2012) pre-

sented “Andromaly”, a framework for detecting mal-

ware on Android mobile devices. This framework

collected 88 features and events and, then, applied

machine-learning algorithms to detect abnormal be-

haviours. Their dataset was composed of 4 self-

written pieces of malware, as well as goodware sam-

ples, both separated into two different categories

(games and tools). Their approach achieved a 0.99

area under ROC curve and 99% of accuracy.

Despite these results, their framework required the

acquisition of a huge number of features and events,

overloading the device and, consequently, draining

the battery. Our approach, in contrast, extracts the

data from the

AndroidManifest.xml

ﬁle, which is a

trivial process. Although our results are not as sound

as theirs, our approach requires much less computa-

tional efforts. In addition, our dataset is larger and

sparser in malware samples than theirs.

Regarding the signature based approach, Schmidt,

Camtepe, and Albayrak (Schmidt et al., 2010) fo-

cused on a static and light-weight analysis of the sam-

ples. They used system calls as features and simple

classiﬁers to detect malicious behaviours. Both ap-

proaches do not prevent the installation of malware

in the devices. Our system evaluates each application

before its installation, considering several features ex-

tracted from the manifest ﬁle, obtaining similar re-

sults to those obtained in previous work.

Peng et al. (Peng et al., 2012) proposed an ap-

proach to rank the risk of Android applications us-

ing probabilistic generative models. They selected

the permissions of the applications as key feature.

Speciﬁcally, they chose the top 20 most frequently re-

quested permissions in their dataset, composed by 2

benign software collections, obtained from the An-

droid application store Google Play (157,856 and

324,658 samples, respectively) and 378 unique sam-

ples of malware. They obtained a 0.94 AUC as best

result. Nevertheless, the unbalanced nature of their

dataset makes it difﬁcult to directly compare the re-

sults with our approach. In fact, our approach is based

on anomaly detection, as it measures the deviation of

any sample to a set of benign applications. In addi-

tion, we complemented the information provided by

the permissions with the

uses-features

, enhancing

the results and approaching the results to those ob-

tained by previous methods. In summary, our ap-

proach prevents the installation of malware on the de-

vices, instead of monitoring the execution of the ap-

plications, thus saving device resources and prevent-

ing undesirable consequences.

7 CONCLUSIONS AND FUTURE

WORK

Smartphones and tablets are ﬂooding both consumer

and business markets and, therefore, these devices

manage a large amount of information. Thus, mal-

ware writers have found in these devices a new source

of income and therefore the number of malware sam-

ples has grown exponentially in these platforms.

In this paper, we presented a new malicious soft-

ware detection approach that is inspired in anomaly

detection systems. In contrast to other approaches,

this method only needs to previously label goodware

and measures the deviation of a new sample respect to

normality (applications without malicious intentions).

Although anomaly detection systems tend to produce

high error rates (specially, false positives), our exper-

SECRYPT2013-InternationalConferenceonSecurityandCryptography

392

Table 2: Results for different combination measures and distance rules. The results in bold are the best for each combination

rule and distance measure.

(a) Manhattan distance.

Comb. Thres. TPR FPR AUC Acc.

Average

8755.51128 1.00000 1.00000

0.88167

50.00%

17468.67613 0.90991 0.21321 84.83%

26181.84099 0.62042 0.10811 75.62%

34895.00584 0.51952 0.06006 72.97%

43608.17069 0.42042 0.03303 69.37%

52321.33555 0.31471 0.01802 64.83%

61034.50040 0.27387 0.00601 63.39%

69747.66525 0.10751 0.00300 55.23%

78460.83011 0.01862 0.00000 50.93%

87173.99496 0.00000 0.00000 50.00%

Max.

47404.00000 1.00000 1.00000

0.65852

50.00%

54503.66667 0.98498 0.99099 49.70%

61603.33334 0.90811 0.94595 48.11%

68703.00000 0.74595 0.78679 47.96%

75802.66667 0.62943 0.53153 54.89%

82902.33334 0.52853 0.04204 74.32%

90002.00001 0.35796 0.00901 67.45%

97101.66667 0.02643 0.00000 51.32%

104201.33334 0.00480 0.00000 50.24%

111301.00001 0.00000 0.00000 50.00%

Min.

0.00000 1.00000 1.00000

0.72431

50.00%

3470.00000 0.54294 0.13814 70.24%

6940.00000 0.52853 0.09009 71.92%

10410.00000 0.41502 0.06006 67.75%

13880.00000 0.34054 0.02703 65.68%

17350.00001 0.17898 0.00000 58.95%

20820.00001 0.10450 0.00000 55.23%

24290.00001 0.02583 0.00000 51.29%

27760.00001 0.00661 0.00000 50.33%

31230.00001 0.00000 0.00000 50.00%

(b) Euclidean distance.

Comb. Thres. TPR FPR AUC Acc.

Average

70.35688 1.00000 1.00000

0.906084463

50.00%

95.24643 0.97057 0.47147 74.95%

120.13597 0.93814 0.23423 85.20%

145.02552 0.88649 0.13514 87.57%

169.91506 0.54655 0.09309 72.67%

194.80461 0.46066 0.04805 70.63%

219.69415 0.37898 0.03303 67.30%

244.58370 0.27628 0.00601 63.51%

269.47324 0.04444 0.00300 52.07%

294.36279 0.00000 0.00000 50.00%

Max.

217.72460 1.00000 1.00000

0.67797888

50.00%

230.60165 0.98559 0.99399 49.58%

243.47870 0.93393 0.96096 48.65%

256.35575 0.82763 0.88288 47.24%

269.23281 0.68468 0.62462 53.00%

282.10986 0.58799 0.15015 71.89%

294.98691 0.44505 0.01201 71.65%

307.86396 0.05165 0.00000 52.58%

320.74102 0.00721 0.00000 50.36%

333.61807 0.00000 0.00000 50.00%

Min.

0.00000 1.00000 1.00000

0.729316704

50.00%

19.63557 0.64985 0.30030 67.48%

39.27114 0.56336 0.23423 66.46%

58.90671 0.54294 0.13814 70.24%

78.54228 0.53333 0.09610 71.86%

98.17784 0.43063 0.06306 68.38%

117.81341 0.34054 0.02703 65.68%

137.44898 0.13634 0.00000 56.82%

157.08455 0.01562 0.00000 50.78%

176.72012 0.00000 0.00000 50.00%

Comb. Thres. TPR FPR AUC Acc.

Average

0.07126978 1.00 1.00

0.914959103

50.00%

0.17446314 0.89 0.16 86.28%

0.27765650 0.86 0.08 89.04%

0.38084985 0.79 0.04 87.24%

0.48404321 0.33 0.01 66.22%

0.58723657 0.33 0.01 66.22%

0.69042993 0.33 0.01 66.22%

0.79362328 0.33 0.01 66.22%

0.89681664 0.33 0.01 66.22%

1.00001000 0.00 0.00 50.00%

Max.

0.34282500 1.00 1.00

0.529312195

50.00%

0.41584556 0.99 0.98 50.12%

0.48886611 0.96 0.97 49.70%

0.56188667 0.87 0.80 53.18%

0.63490722 0.87 0.80 53.06%

0.70792778 0.87 0.80 53.06%

0.78094833 0.87 0.80 53.06%

0.85396889 0.87 0.80 53.06%

0.92698944 0.87 0.80 53.06%

1.00001000 0.00 0.00 50.00%

Min.

-0.10000000 1.00 1.00

0.803523343

50.00%

0.02222333 0.64 0.04 79.85%

0.14444667 0.33 0.01 66.22%

0.26667000 0.33 0.01 66.22%

0.38889333 0.33 0.01 66.22%

0.51111667 0.33 0.01 66.22%

0.63334000 0.33 0.01 66.22%

0.75556333 0.33 0.01 66.22%

0.87778667 0.33 0.01 66.22%

1.00001000 0.00 0.00 50.00%

imental results show low FPR values. The number

of malicious samples discovered up-to-date is limited:

signature scanning methods are effective and efﬁcient

solutions for current malware. Nevertheless, we con-

sider that malware authors will soon apply obfusca-

tion techniques making difﬁcult the detection process.

This possibility was explored by Rastogi et al. (Ras-

togi et al., 2013). In this way, our approach reduces

the necessity to collect malware samples (i.e., it is

not necessary to update a signature database), as it is

based on anomaly detection. In addition, our method

is based on features that are extracted from the mani-

fest ﬁle, making possible to prevent the installation of

malicious software.

However, this approach presents several limita-

tions. By means of an internet connection, a be-

nign application can download a malicious payload

and change its behaviour. In order to detect this be-

haviour, a dynamic approach is required. Unfortu-

nately, dynamic approaches cannot be deployed in

Instance-basedAnomalyMethodforAndroidMalwareDetection

393

current smartphones due to their computational and

battery limitations.

Future work is oriented in two main directions. On

the one hand, other distance measures and combina-

tion rules could be tested. On the other hand, there

are other static features that could be used to improve

the detection ratio, that could be obtained from the

AndroidManifest.xml

ﬁle or from the binary class

(e.g., strings, API calls). The use of different features

could reduce the risk of incorrectly classifying benign

applications that have permission usage declarations

similar to malicious samples.

ACKNOWLEDGEMENTS

This research was partially supported by the

Basque Government under the research project

‘BRANKA4U: Evoluci´on de los servicios bancarios

hacia el futuro’ granted by the ETORGAI 2011 pro-

gram.

REFERENCES

Blasing, T., Batyuk, L., Schmidt, A.-D., Camtepe, S. A.,

and Albayrak, S. (2010). An android application sand-

box system for suspicious software detection. In Mali-

cious and Unwanted Software (MALWARE), 2010 5th

International Conference on, pages 55–62. IEEE.

Burguera, I., Zurutuza, U., and Nadjm-Tehrani, S. (2011).

Crowdroid: behavior-based malware detection system

for android. In Proceedings of the 1st ACM workshop

on Security and privacy in smartphones and mobile

devices, pages 15–26. ACM.

Egele, M., Kruegel, C., Kirda, E., and Vigna, G. (2011).

Pios: Detecting privacy leaks in ios applications. In

Proceedings of the Network and Distributed System

Security Symposium.

Mylonas, A., Kastania, A., and Gritzalis, D. (2012). Del-

egate the smartphone user? security awareness in

smartphone platforms. Computers & Security.

Peng, H., Gates, C., Sarma, B., Li, N., Qi, Y., Potharaju, R.,

Nita-Rotaru, C., and Molloy, I. (2012). Using proba-

bilistic generative models for ranking risks of android

apps. In Proceedings of the 2012 ACM conference on

Computer and communications security, pages 241–

252. ACM.

Rastogi, V., Chen, Y., and Jiang, X. (2013). Evaluating an-

droid anti-malware against transformation attacks.

Schmidt, A.-D., Camtepe, A., and Albayrak, S. (2010).

Static smartphone malware detection. In proceedings

of the 5th Security Research Conference (Future Se-

curity 2010), ISBN, pages 978–3.

Shabtai, A. and Elovici, Y. (2010). Applying behavioral

detection on android-based devices. Mobile Wire-

less Middleware, Operating Systems, and Applica-

tions, pages 235–249.

Shabtai, A., Fledel, Y., and Elovici, Y. (2010). Automated

static code analysis for classifying android applica-

tions using machine learning. In Computational Intel-

ligence and Security (CIS), 2010 International Con-

ference on, pages 329–333. IEEE.

Shabtai, A., Kanonov, U., Elovici, Y., Glezer, C., and Weiss,

Y. (2012). andromaly: a behavioral malware detection

framework for android devices. Journal of Intelligent

Information Systems, pages 1–30.

Singh, Y., Kaur, A., and Malhotra, R. (2009). Compara-

tive analysis of regression and machine learning meth-

ods for predicting fault proneness models. Interna-

tional Journal of Computer Applications in Technol-

ogy, 35(2):183–193.

Tata, S. and Patel, J. M. (2007). Estimating the selectiv-

ity of tf-idf based cosine similarity predicates. ACM

SIGMOD Record, 36(2):7–12.

Zhou, Y. and Jiang, X. (2012). Dissecting android malware:

Characterization and evolution. In Security and Pri-

vacy (SP), 2012 IEEE Symposium on, pages 95–109.

IEEE.

SECRYPT2013-InternationalConferenceonSecurityandCryptography

394
