Toward a Neural Aggregated Search Model for Semi-structured

Documents

F. Z. Bessai-Mechmache

Research Centre on Scientific and Technical Information, CERIST, Ben Aknoun, 16306, Algiers, Algeria

Keywords: Neural Networks, Self-organizing Maps, Aggregated Search, XML Information Retrieval, XML Document,

Aggregate, Classification of XML Elements, Learning.

Abstract: One of the main issues in aggregated search for XML documents is to select the relevant elements for

information need. Our objective is to gather in same aggregate relevant elements that can belong to different

parts of XML document and that are semantically related. To do this, we propose a neural aggregated search

model using Kohonen self-organizing maps. Kohonen self-organizing map lets classification of XML

elements producing density map that form the foundations of our model.

1 INTRODUCTION

XML information retrieval recovers information

from different granularities such as document or

parts of document (Kamps et al., 2003; Fuhr et al.,

2004) and with different types such as images, text,

videos, news…etc. However, assembly or grouping

these elements in a suitable form to provide a

complete view of the information available should

be considered.

An ordered list of elements is the answer

returned by the majority of current XML

information retrieval systems (Sigurbjornsson et al.,

2003; Ogilvie and Callan, 2003; Lalmas and

Vannoorenberghe, 2004; Piwowarski et al., 2002).

The result as an ordered liste requires the user to

browse sequentially and examine the results one by

one to find the appropriate content. The aggregated

search comes to relieve this problem by assembling

and combining elements to construct answers

including all relevant information with respect to

user’s query. To do this, se suggest a neural

aggregated search model using Kohonen self-

organizing maps. Self-organizing map allows an

automatic classification of XML elements producing

density map to which we apply a genetic algorithm

to generate aggregates.

This paper is structured as follows. We initially

introduce related work concerning XML aggregated

search. We describe our model in section 3. In

section 4 we conclude the paper.

2 STATE OF THE ART

Few works in literature deal with aggregate search

for semi structured documents as XML. The

proposed models that cover this issue are limited to

Web documents (Clarke et al., 2008; Agrawal et al.,

2009; Kopliku, 2009; Arguello et al., 2011; Kopliku

et al., 2011). So, Polyzotis and Huang were the first

to have proposed a solution to aggregated search in

XML documents. Indeed, XCLUSTERs (Polyzotis

and Garofalakis, 2006) is a model representing XML

summaries. It regroups some XML elements and

uses a small space to store their abstarcts. eXtract

(Huang et al., 2008) is an information retrieval

system that generates results as XML fragments. An

XML fragment is qualified like result if it is

autonomous (understanding by the user), distinct

(different from the other fragments), representative

(of the themes of the query) and succinct. The

Possibilistic aggregated search model (Bessai-

Mechmache and Alimazighi, 2011; Bessai-

Mechmache and Alimazighi, 2012) is an aggregated

search model based on possibilistic networks that

provide a natural representation of links between a

document, its elements and its content, and allow an

automatic selection of relevant aggregates. The

neural aggregated search model we suggest in this

paper uses Kohonen self-organizing maps

(Kohonen, 1990; Haykin, 1999). These self-

organizing maps allow an automatic classification of

XML elements producing density map that form the

foundations of aggregated search. Indeed, in order to

Bessai-Mechmache F..

Toward a Neural Aggregated Search Model for Semi-structured Documents.

DOI: 10.5220/0004538400910095

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval and the International Conference on Knowledge

Management and Information Sharing (KDIR-2013), pages 91-95

ISBN: 978-989-8565-75-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

identify the relevant aggregate which answers the

query we apply a genetic algorithm (Ahmed et al.,

2008; Bangorn and Quen, 2005) to the density map.

3 AGGREGATED SEARCH

MODEL

3.1 Model Architecture

The architecture of the proposed model is a

Kohonen neural network that consists of a grid

(map) of neurons and an input stimulus, as

illustrated in Figure 1 below.

Figure 1: Model Architecture.

3.1.1 Map Description

Each neuron of the map represents an element of

the XML document. Only leaves elements of the

hierarchical structure of XML document are

classified on the map. The non leaves elements will

be classified by relevance propagation at search

time.

The map is divided into subset of XML elements

(areas or subregions) having the same

characteristics, i.e. they deal with the same thematic.

Therefore, elements belonging to the same subregion

are potential candidates to appear in the same

aggregate answering a given query.

Input stimulus is an N-dimensional vector of

neurons that represents an element to be classified

on the map. Each neuron in the input stimulus is an

indexing term of the element.

Connection that join every neuron (term) of the

stimulus to the map reflect the importance (W

) of

term ‘t

‘ in element ‘e

‘. This importance (or weight)

is calculated by the following equation (Trotman,

2005).

= tf

* ief * idf

(1)

With:

- tf

: term frequency

- ief: inverse frequency of element ‘e

’ for term ‘t

’.

- idf: inverse frequency

3.1.2 Connections between Elements

The Weight S

is used to model the semantic link

between two elements ‘e

’ and ‘e

’ of the map. Sij is

calculated based on the following three factors:

- The Number of Common indexing Terms (nct)

(terms that the two elements have in Common); this

factor determines whether the two elements deal

with the same topic. It belongs to interval ] 0, 1[ and

is calculated as follows.

(, )

Number of common terms between e and e

nct e e

Number of terms of e Number of terms of e





(2)

-The co-occurrence of query terms in the

elements (R

min( ( , ), ( , ))

()

() ()

ekl e kl

ttQ

ek e k

tQ tQ

cooccurrences t t cooccurrences t t

occurrences t occurrences t













(3)

- The Longest Common Prefix (lcp) between the

Hierarchical Identifiers (HI) of the two elements

(HIe

, HIe

). The lcp(HIe

, HIe

)=0 if the two

elements e

and e

don't belong to the same

document. Example: If HIe

=5.2.1.4 and

HIe

= 5.2.4.2 then lcp(HIe

, HIe

)= 2.

The weight S

is calculated as follows:

(, ) ( , ) ()

ij i j e e ij

SncteelcpHIHI RQ





(4)

3.1.3 Learning Algorithm

Let X(t) = { X

( t), X2(t),…, Xn(t)} be a learning

pattern at instant t. Let W

(t) = { W

(t), W

(t) ,…,

(t)} be a neuron at instant t.

Firstly, the map must be initialized randomly.

For each input pattern:

1- Calculate the distance between the pattern and

all neurones (||X(t)-W

(t)||). The chosen distance

measure is the Euclidean distance.

2- Select the nearest neurone as winner W

(||X(t)-W

(t)|| = min

||X(t)-W

(t)||)

3- Update each neurone according to the rule:

(t+1) = W

(t) + α(t).h

, W

)

(t).||X

(t) - W

(t)||

with 1 ≤ i ≤ n.

Let 0 ≤ α ≤ 1 be the learning rate, and h

, W

)

the neighbourhood

function. This function assumes

values in [0, 1] and is high for neurones that are

close in the neighbourhood, and small (or 0) for

neurones far away.

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

4- Repeat the process until a certain stopping

criterion is met. Usually, the stopping criterion is a

fixed number of iterations.

To guarantee convergence and stability of the

map, the learning rate and neighbourhood radius are

decreased in each iteration, thus converging to zero.

3.2 Query Processing

A query consists of a set of terms, Q = (t

, t

,..., t

In our approach, we consider the query as a

vector of terms ready to be classified on the

Kohonen map.

Figure 2: Classification of the query on Kohonen map.

Once the query classified on the map, the

elements of its neighbourship are selected as

illustrated in Figure 2 above. The set of selected

elements is used to generate aggregates in response

to the query. This set, denoted SE(Selected

Element), will serve as initial population for the

genetic algorithm we define in next section.

SE = {le

, le

…, le

} with ‘le’: leaf element.

3.3 Aggregates Generation

The aim of our aggregate serach model is to return a

list of aggregates in response to a user query. Each

aggregate is composed of a set of coherent and non-

redundant elements, conveying relevant information

in relation to user’s need. For this, we propose a

specific genetic algorithm for the generation of these

aggregates from the list of elements selected thanks

to our self-organizing map.

Our genetic algorithm works on two populations,

the population of elements ‘P

’ and the population of

aggregates ‘P

’. Clearly, we define different fitness

functions (or relevance function) to evaluate the two

populations.

3.3.1 Relevance of Leaves Elements

The relevance of a leaf element with respect to the

query (RSV(Q, le)) is equal to the sum of the

weights of query terms with regard to this element.

(,l)

RSV Q e W





(5)

With:

- W

: the weight of term ‘t

’

in leaf element ‘le’.

- M: the number of query terms.

3.3.2 Relevance of Non-Leaf Element

The fitness of a non-leaf element corresponds to the

relevance of this element in relation to the query. It

is calculated by the following relevance propagation

formula (Sauvagnat et al., 2006):

(, )1

(,) * (, )*

dist e le

ele

le F

FRSVQle E RSVQle











(6)

With:

- |E

| is the number of leaves elements that are

also child elements of the element ‘e’.

- le: leaf element.

- α є ]0..1]: is a parameter allowing to quantify the

importance of the distance separating leaves elements

from their ascendant element ‘e’.

- dist (e, le) is the distance between the leaf element ‘le’

and its ascendant element ‘e’ in accordance with the

hierarchical structure of the XML document.

3.3.3 Aggregate Relevance

The fitness of an aggregate ‘ag’, denoted ‘F

‘, is the

relevance of this aggregate in relation to the query.

This relevance is calculated according to the

relevance of elements composing the aggregate and

according to the semantic link connecting these

elements. It is formulated as follows:

(, ) *

(1)!

iag ijag

ag e ij

eE eeE

ag ag

FRSVQag F S



 





(7)

With:

- |E

|: Number of elements of the aggregate.

- E

: Set of elements those constitute the aggregate.

- F

: Relevance of element e

with regard to the query.

- S

: Semantic link degree between two elements e

and e

3.3.4 Genetic Algorithm

To generate the aggregate result we use the

following genetic algorithm:

a. Initialization

The P

population is initialized by the set SE, so

= {le

, le

, …, le

}. The P

Population is

initialized with aggregates formed by considering all

possible combinations of elements of P

population.

= {ag

, ag

,…, ag

TowardaNeuralAggregatedSearchModelforSemi-structuredDocuments

b. Assessment of population of aggregates P

with normalized fitness function F

then selection

of K top individuals and their assignment to P

population: P

 K top aggregates.

c. As long as the stopping criterion is not

reached do:

 Go back up one level in the hierarchical tree

of XML documents (that contain these

elements) by applying the propagation of

relevance.

 Add elements obtained by propagation to P

population. Evaluate the new population of

elements with the normalized fitness

function F

 Selection of L top elements and their

assignment to P

population. The L top

elements are potentially useful elements to

generate relevant aggregates: P

 L top

elements.

 Apply parameters of hybridization and

mutation to P

population. This is to

regenerate new aggregates from the new

population of elements P

taking into

account various cases of overlap that may

exist.

 Add new aggregates to P

population.

Evaluate the new population of aggregates

with the normalized fitness function F

and

select K top aggregates: P

 K top

aggregates.

 Go to step c.

4 CONCLUSIONS

Our neural aggregated search model thanks to

Kohonen self-organizing map assembles elements

from different parts of XML documents to build

aggregates including all relevant information for the

query.

Future work will concern the evaluation of our

approach on a data set.

REFERENCES

Ahmed, A., A., R., Bahgat, A., Abdel Latef, Abdel Mgeid,

A., A., and Osman, A. S., 2008. Using Genetic

Algorithm to Improve Information Retrieval Systems.

World Academy of Science, Engineering and

Technology 17.

Agrawal, R., Gollapudi, S., Halverson, A., 2009.

Diversifying Search Results, ACM Int. Conference on

WSDM.

Arguello, J., Diaz, F., Callan, J., 2011. Learning to

aggregate vertical results into web search results. In

Proceedings of the 20th ACM Conference on

Information and Knowledge Management,CIKM'11,

Glasgow, United Kingdom.

Bangorn, K., and Quen, P., 2005. Applied genetic

algorithms in information retrieval. Proceedings of

International Journal of Production Research (King

Mongnut’s Institute of Technology, Ladkrabang,

Bangkok), 43, p.4083-4101.

Bessai-Mechmache F. Z., and Alimazighi, Z. 2012.

Possibilistic Model for Aggregated Search in XML

Documents. International Journal of Intelligent

Information and Database Systems, IJIIDS, Vol. 6, No

4, pp 381-404

Bessai-Mechmache, F. Z., and Alimazighi, Z. 2011.

Possibilistic Networks for Aggregated Search in XML

Documents. In proceedings of International

Conference on Information & Communication

Systems, ICICS’2011, Irbid, Jordan, pp 67-72.

Clarke, C. L., Kolla, M., Cormack, G. V., Vechtomova,

O., 2008. Novelty and diversity in information

retrieval evaluation. SIGIR’08, p.659-666.

Haykin, S., 1999. Neural Networks: A Comprehensive

Foundation, Prentice Hall, ISBN 0-13-273350-1

Huang, Y., Liu, Z., Chen, y., 2008. Query biased snippet

generation in XML search. ACM SIGMOD, p.315-

326.

Kamps, J., Marx, M., De Rijke, M., Sigurbjörnsson, B.,

2003. XML Retrieval: What to retrieve? ACM SIGIR

Conference on Research and Development in

Information Retrieval, p.409-410.

Kopliku, A., 2009. Aggregated Search: From information

nuggets to aggregated documents. CORIA, p.507-514.

Kopliku, A., BOUGHANEM, M., PINEL-SAUVAGNAT,

K., 2011. Searching within Web pages: Retrieving

attributes from HTML tables in the Web. In

Conference on Information and Knowledge

Management, CIKM’11, Glasgow, United Kingdom.

Lalmas, M., Vannoorenberghe, P., 2004. Indexation et

recherche de documents XML par les fonctions de

croyance. CORIA'2004, p.143-160.

Fuhr, N., Lalmas, M., Malik, S., Szlavik, Z., 2004.

Advances in XML Information Retrieval: INEX 2004.

Dagstuhl Castle, Germany, December 6-8.

Ogilvie, P., Callan, J., 2003. Using language models for

flat text queries in XML retrieval. In Proceedings of

INEX 2003 Workshop, Dagstuhl, Germany, p.12-18.

Piwowarski, B., Faure, G.E., Gallinari, P., 2002. Bayesian

Networks and INEX. In INEX 2002 Workshop

Proceedings, p.149-153, Germany.

Polyzotis, N., Garofalakis, M. N., 2006. XCluster

Synopses for Structured XML Content. ICDE.

Sauvagnat, K., Boughanem, M., Chrisment, C., 2006.

Answering content-and-structure-based queries on

XML documents using relevance propagation.

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

Information Systems, Special Issue SPIRE 2004,

vol. 31, p.621-635, Elsevier.

Sigurbjornsson, B., Kamps, J., de Rijke, M., 2003. An

element-based approach to XML retrieval. INEX 2003

workshop, Dagstuhl, Germany.

Kohonen, T., 1990. Self-organizing map. Proceedings of

the IEEE, Vol. 78, n°9.

Trotman, A., 2005. Choosing document structure

weights. Information Processing and Management,

vol. 41, n°2, p.243-264.

TowardaNeuralAggregatedSearchModelforSemi-structuredDocuments
