Classification of Knowledge Representations using an Ontology-based

Approach

Ruben Costa

, Paulo Figueiras

, Pedro Maló

and Celson Lima

CTS, Uninova, Dep.ª de Eng.ª Electrotécnica, Faculdade de Ciências e Tecnologia, FCT, Universidade Nova de Lisboa,

2829-516 Caparica, Portugal

UFOPA / IEG / PSI, Federal University of Western Pará, Santarém, Brazil

Keywords: Ontology Engineering, Unsupervised Document Classification, Vector Space Models, Semantic Vectors.

Abstract: One of the primary research challenges in the knowledge representation domain relates to the process of

formalization of document contents using dependent metadata and in particular how the classifiers are

derived. Most approaches to determining appropriate classifiers are limited and only take account of the

explicit, word-based information in the document. The research described in this paper explores the

potential classifier enrichment through incorporation of implicit information derived from the complex

relationships (Semantic Associations) in domain ontologies with the addition of information presented in

documents for unsupervised document classification. The paper introduces a novel conceptual framework

for representation of knowledge sources, where each knowledge source is semantically represented (within

its domain of use) by a Semantic Vector (SV), which is enriched using the classical vector space model

approach extended with ontological support, employing ontology concepts and their relations in the

enrichment process. The test domain for the assessment of the approach is Building and Construction, using

an appropriate available Ontology. Preliminary results were collected using a clustering algorithm for

document classification, which indicates that the proposed approach does improve the precision and recall

of classifications. Future work and open issues are also discussed.

1 INTRODUCTION

The representation of knowledge has been an

important human endeavor since the dawn of the

human race. The creation of written and spoken

languages is the best known example of the effort to

represent knowledge in such ways as to preserve it

and to guarantee that it will be transmitted to future

generations.

The subject of knowledge representation gained

a new dimension with the advent of the computer

age. Particularly, with the creation of the World

Wide Web, new forms of knowledge representation

were needed in order to transmit data from source to

recipient in common data formats, and to aid

humans to find the information they want in an

easily understandable manner.

With the evolution of the Semantic Web,

knowledge representation techniques got into the

spotlight, aiming at bringing human understanding

of the meaning of data to the world of machines.

Such techniques create knowledge representations of

knowledge sources (KS), whether they are web

pages or documents (Figueiras et al., 2012).

Most existing information retrieval techniques

are based upon indexing keywords extracted from

KS. Regrettably, keywords or index terms alone

often cannot adequately capture the document

contents, resulting in poor retrieval and indexation

performances. Nevertheless, keyword indexing is

widely used in commercial systems because it is still

the most viable way by far to process large amounts

of text.

This paper illustrates the development of a

framework which supports the process of a

representation of knowledge sources, using a vector

space model (VSM) (Salton et al., 1975) approach

and the enrichment of such representation using

background knowledge available in a domain

ontology. The proposed work will be assessed in the

building and construction sector. The major steps of

the work include the analysis of the relations

between ontological concepts, and the KS they are

representing as well as the enhancement of such

184

Costa R., Figueiras P., Maló P. and Lima C..

Classiﬁcation of Knowledge Representations using an Ontology-based Approach.

DOI: 10.5220/0004541701840191

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2013), pages 184-191

ISBN: 978-989-8565-81-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

relations with semantic associations among

concepts. Hence, the main contribution of this work

is consequently not trying to develop new or

improving any of the current classification

algorithms but to affect the document term vectors

in a way that we could and measure the effect of

such semantic enrichment on existing classifiers.

This paper is structured as follows. Section 2

presents the related work. Section 3 illustrates the

domain ontology used under this work. Section 4

describes the process of enrichment of KSs. Section

5 illustrates the empirical evidences of the work

addressed so far. Finally, section 6 concludes the

paper and points out the future work to be carried

out.

2 RELATED WORK

The presented work is the continuation of the work

presented in (Figueiras et al., 2012) and (Costa et al.,

2012). In terms of the issue addressed here, Castells

et al. (Castells et al., 2007) propose an approach

based on an ontology and supported by an

adaptation of the Vector Space Model, similarly to

our approach. It uses the tf-idf (term frequency–

inverse document frequency) algorithm, matches

documents’ keywords with ontology concepts,

creates semantic vectors, and uses the cosine

similarity to compare created vectors. A key

difference between this approach and the presented

work is that Castells’ work does not consider

semantic relations or the hierarchical relations

between concepts (both taxonomic and/or

ontological relations).

Li (Sheng, 2009) presents a way of

mathematically quantifying such hierarchical or

taxonomic relations between ontological concepts,

based on relations’ importance and on the co-

occurrence of hierarchically related concepts, and

reflects this quantification in documents’ semantic

vectors. Li’s work aims at creating an Information

Retrieval (IR) model based on semantic vectors to

apply over personal desktop documents, and it has

no relation to Web IR applications, as is the case of

the presented work.

On the other hand, Nagarajan et al. (Nagarajan

et al., 2007) propose a document indexation system

based on the VSM and supported by Semantic Web

technologies, just as we do here. They also propose

ways of quantifying ontological relations between

concepts, and represent that quantification in

documents’ semantic vectors. There are some

differences between Nagarajan’s work and our

approach. For instance, Nagarajan et al. do not

distinguish between taxonomic and ontological

relations, also our work doesn’t not include terms

from documents within semantic vectors, such terms

previously semantically mapped to ontology

concepts.

Focusing on more recent works, Xia et al. (Xia

and Du, 2011) propose a document classification

mechanisms based on title vector based document

representations, in which is assumed that terms in

documents’ titles represent main topics in those

documents, and therefore the weights for title terms

should be amplified.

Finally, the work of García et al. (García et al.,

2010) aims to propose some new metrics to measure

relationships among classes in an ontology.

Relationships among classes in an OWL ontology

are given by the object properties that are defined as

a binary relation between classes in the domain with

classes in the range. The proposal of García et al. is

based on the coupling metric defined in the software

engineering field, adapting it to the Semantic Web’s

needs.

3 THE ONTOLOGY

The domain-specific ontology used in this work was

entirely developed using Protégé ontology editor

(Stanford Center for Biomedical Informatics

Research, s.d.), and it is written in OWL-DL

language (Sean et al., s.d.). The ontology

comprehends two major pillars, namely, concepts

and relations. The first relates to specific elements

(classes) of building and construction related areas

which cover for example, type of project, project

phase, and similar data. The other specifies how

such concepts are related to each other.

Several levels of specificity are given for all

concept families, as described for the ‘Actor’

concept. These specificity levels represent concepts

hierarchies and, ultimately, taxonomic relations such

as ‘Architect’ <is_a> ‘Design Actor’ and ‘Design

Actor’ <is_a> ‘Actor’. All classes, or concepts, have

an instance, which corresponds to the class, and

comprises the keywords or expressions gathered and

related to each concept, through an ontological

datatype property designated ‘has Keyword’.

All concepts are themselves keywords, because

they are expressions or terms that may occur in a

knowledge source. In addition to themselves,

concepts also possess equivalent terms that are terms

or expressions relevant for capturing different

semantic aspects of such concepts. For instance, the

ClassificationofKnowledgeRepresentationsusinganOntology-basedApproach

185

‘Learning_Facility’ concept has a

‘Higher_Education_Facility’ individual, and this

individual has several keywords designated as

equivalent terms, such as ‘university’, ‘science

college’, and ‘professional college’, meaning that

each equivalent term belongs to some concept, as

shown in Figure 1. Moreover, concepts are

connected by ontological object properties called

ontological relations. Ontological relations relate

concepts among themselves and are described by a

label (property) and the relevance (weight) of such

relation in the context of the B&C domain ontology.

Figure 1: Domain Ontology elements.

4 THE PROCESS

In this section, we describe the justification behind

our hypothesis that background knowledge available

in domain ontologies can be used to enrich statistical

term vectors representations. Our approach mainly

focuses on knowledge representation of knowledge

sources, but there are several steps that need to be

performed before and after the knowledge

representation itself. Figure 2 gives a general

overview of our process, which consists of two main

modules, namely Document Analysis Module and

Semantic Enrichment Module.

Figure 2: The process.

4.1 Document Analysis Module

We start with a state-of-the art indexing tool, called

RapidMiner (RapidMiner, 2012), to generate

document term vectors (statistical vector) where

terms are ordered by their level of importance within

a document using a normalized tf-idf score.

There are two stages in the first module, namely

Term Extraction and Term Selection, for reducing

the dimensionality of the source document set. Both

are described here.

4.1.1 Term Extraction

The whole extraction process is as follows:

a) First of all, each document is broken into

sentences. Then, terms in each sentence are

extracted as tokens (this process is called

tokenization).

b) All tokens found in the document are

transformed to lower case.

c) The terms belonging to a predefined stop word

list are removed.

d) Remained terms are converted to their base

forms by stemming, using the snowball method.

The terms with the same stem are combined for

frequency counting. In this paper, a term is

regarded as the stem of a single word.

e) Tokens whose length is “< 4” or “> 50”

characters are discarded.

f) The n-Grams generation is seen here as a

creation of sequences of 1 to N words. For this

case we are considering the generation of

unigrams, bigrams (e.g. Waste Management)

and trigrams (e.g. Electric Power Product).

4.1.2 Term Selection

We understand that terms of low frequencies are

supposed as noise and useless, thus we apply the tf–

idf (term frequency - inverse document frequency)

method to choose the key terms for the document

set. Equation 1, is used for the measurement of





for the importance of a term 



within a

document 



. The main limitation of tf-idf method is

that long documents tend to have higher weights

than short ones. It considers only the weighted

frequency of the terms in a document, but neglects

the length of the document. In Equation 2, 



is the

frequency of 



in 



, and the total number of

occurrences in 



is the maximum frequency of all

terms in 



used for normalization to prevent bias for

long documents.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

186









∗



(1)



















(2)





log







(3)

After calculating the weight of each term in each

document, those which satisfy the pre-specified

minimum tf–idf threshold γ are retained. For this

work, we consider all terms where its tf-idf score

was greater or equal than 0.001. Subsequently, these

retained terms form a set of key terms for the

document set D.

A document, denoted 



is a logical unit of text,

characterised by a set of key terms 



together with

their corresponding frequency 



, and can be

represented by













,











,





,…,



,



,…,







,





.

Such representation is entitled statistical vector,

meaning that, for each document in D there is a

resultant statistical vector. An example of a

statistical vector is depicted in Table 1.

Table 1: Statistical Vector.

Key Term Weight

sanitari

0,004101

water_suppli_drainag

0,003265

toilet

0,002482

personnel

0,002332

4.2 Semantic Enrichment Module

In this module we construct a new term vector,

named Semantic Vector (SV) for all the documents

in D. This vector comprises of ontology concepts

that are on the domain ontology and whose

equivalent terms semantically match terms which

are present in the statistical vector, (Table 2).

Table 2: Ontological Equivalent Terms.

Ontological Concept Equivalent Terms

Complete_Sanitary_Suite

complete sanitary

suite, complete

bathroom suite,

bathroom,

washroom,…

Plumbing_Fixture_And_

Sanitary_Washing_Unit

bathtub, shower,

service sink,

lavatory,…

Sanitary_Disposal_Unit

water closet, toilet,

urinal,…

A semantic vector is represented by two

columns: the first column contains the concepts that

build up the knowledge representation of the KS,

i.e., the most relevant concepts for contextualizing

the information within the KS; the second column

keeps the degree of relevance, or weight, that each

term has on the knowledge description of the KS

(Costa et al., 2012).

Our approach takes into account three different

but complementary procedures for building up the

semantic vector, where each iteration is expected to

add new semantic enrichment of the KS

representation: keyword-based, taxonomy-based,

and ontology-based semantic vectors. The first step

is related with the definition of a keyword-based

semantic vector.

4.2.1 Keyword-based Semantic Vector

The keyword-based semantic vector takes into

consideration only the relation between terms

existing in the statistical vector and ontology

concepts presented on the domain ontology.

In this module, we use semantic background

knowledge from ontologies as a way to augment

traditional syntactic term vectors. A fundamental

drawback behind Vector Space Model is that it treats

a document as a bag of words and ignores the

dependence between terms, i.e., it assumes that

terms in a document occur independent of each

other. Capturing dependency between key terms

within syntactic term vectors in terms of co-

occurrences has been successfully attempted by the

use of statistical techniques (Nagarajan et al., 2007).

However there are cases when terms do not co-occur

very often and are also not related in a way that such

techniques can help. For example, if terms “bathtub”

and “shower” in Table 2 do not co-occur frequently,

statistical techniques will fail to identify a possible

correlation between them.

The next iteration deals with finding similarities

between the statistical vector’s keywords and

equivalent terms which are linked to ontological

concepts from the domain ontology. The matching

process between equivalent terms presented on the

domain ontology and the keywords within the

statistical vector is done by using a similarity

measure between words (cosine similarity).

The keyword-based semantic vector is then

stored in the database in the

form

∑







;

∑









, where n is the number of

concepts in the vector, x



is the syntactical

representation of the concept and w





is the semantic

weight corresponding to the concept.

Table 3 depicts the weight of every ontology

concept associated to each key term within the

ClassificationofKnowledgeRepresentationsusinganOntology-basedApproach

187

statistical vector, where the first column corresponds

to the ontology concepts that were matched to

describe the most relevant terms extracted from the

statistical vector, the second column indicates the

most relevant terms that were matched to ontology

equivalent terms, and the third column indicates the

semantic weight for each ontology concept matched.

Table 3: Keyword-based semantic vector.

Concept Key Term Weight

Sanitary_Disposal_Unit

toilet, urin,

water_closet

0,149514

Sanitary_Laundry_and_

Cleaning_Equipment_Pr

oduct

sanitari 0,132629

Team

person,

personnel

0,104497

Commitee

subcommitte 0,067880

4.2.2 Taxonomy-based Semantic Vector

Taxonomy-based vectors push one step further in the

representation of KSs by adjusting the weights

between expressions according to the taxonomic

relation among them, i.e., expressions that are

related with each other with the ‘is_a’ type relation.

If two or more concepts that are taxonomically

related appear in a keyword-based vector, the

existing relation can boost the relevance of the

expressions within the KS representation.

Definition 1: In the hierarchical tree structure of

the ontology, concept A and concept B are

homologous concepts if the node of concept A is an

ancestor node of concept B. Hence, A is considered

the nearest root concept of B, R(A,B). The

taxonomical distance between A and B is given by:







,



















|

















|

(4)

In Equation 4, depth (X) is the depth of node X

in the hierarchical tree structure, with the ontological

root concept’s depth being zero (0).

Definition 2: In the hierarchical tree structure of

the ontology, concept A and concept B are non-

homologous concepts if concept A is neither the

ancestor node nor the descendant node of concept B,

even though both concepts are related by kin; If R is

the nearest ancestor of both A and B, then R is

considered the nearest ancestor concept for both A

and B concepts, R(A,B); The taxonomical distance

between A and B is expressed as:







,







,









,



(5)

Figure 3 depicts the difference between

homologous and non-homologous concepts.

Figure 3: Homologous and non-homologous concepts

(Sheng, 2009).

The taxonomy-based semantic vector is

calculated using the keyword-based vector as input,

where taxonomical relations are used to boost the

relevance of the concepts already present within the

vector or to add new concepts. The weight of the

concepts is boosted when two concepts found in the

keyword-based vector are highly relevant, with the

degree of relevance being defined by a given

threshold. If the relevance of the taxonomical

relation between two concepts is higher than the

predefined threshold, then the semantic weight of

such concepts is boosted in the taxonomy-based

vector. If a concept already present in the keyword-

based vector is taxonomically related to a concept

than is not present in the vector, then the related

concept is added into the taxonomy-based vector.

An example of a taxonomy-based semantic

vector is depicted in Table 4. The taxonomical

similarity is calculated differently for both

homologous and non-homologous taxonomical

relations defined previously:





,



1











1





,





(6)

If , 0 and  and  are homologous.





,



1











1





,













(7)

If ,0 and  and  are non-

homologous.







,



1

(8)

If 



,



0.

Table 4: Taxonomy-based semantic vector.

Concept Weight

Sanitary_Disposal_Unit

0,107615

Sanitary_Laundry_and_Cleaning_Equip

ment_Product

0,092500

Team

0,075767

Plumbing_Fixture_and_Sanitary_Washi

ng_Unit

0,057912

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

188

The concept ‘Plumbing_Fixture_and_Sanitary

_Washing_Unit’ weight was boosted within the

Taxonomy-based semantic vector because it is

highly related with the concepts

‘Sanitary_Disposal_Unit’ and

‘Sanitary_Laundry_and_Cleaning_Equipment_prud

ct’.

4.2.3 Ontology-based Semantic Vector

The third iteration in the semantic vector creation

process is the definition of the semantic vector based

on the ontological relations defined in the domain

ontology. Our system uses human input (knowledge

experts in the building and construction domain) to

establish the final numerical weights on each

ontological relationship.

The first step is to analyse the ontological

relations among concepts found in the input

semantic vector. The taxonomy-based semantic

vector is used as input for this analysis. The creation

of the ontological-based semantic vector is a two-

step process: the first step boosts weights of

concepts already present in the taxonomy-based

vector, depending on the relevance of the ontology

associations among them; the second step adds new

concepts that are not present in the input vector,

according to ontological relations they might have

with concepts belonging to the taxonomy-based

vector (Costa et al., 2012).

Analogously to the creation of a taxonomy-based

semantic vector, the new concept is added to the

semantic vector only if the importance of an

ontological relation exceeds a pre-defined threshold,

for the same constraint purposes. The ontological

relation’s significance, or relevance, is not

automatically computed; rather, as explain before, it

is calculated by knowledge experts in the building

and construction domain, and is defined by a vector

comprising a pair of concepts and the weight

associated to the pair relation, as shown in Table 5.

Table 5: Ontological Relations.

Property Subject Object Weight

is_part_of

Complete

_Sanitary

_Suite

Sanitary_Laun

dry_and_Clea

ning_Equipme

nt_Product

0,07

is_part_of

Sanitary_

Disposal_

Unit

Sanitary_Laun

dry_and_Clea

ning_Equipme

nt_Product

0,07

The equation 9 describes the process of boosting

of concepts or addition of new ones. Where 





, is

the new weight of the ontological concept, 





the taxonomy weight of the concept to be boosted, if

the concept is added then 





should be zero. 





is the taxonomical weight of the concept related to





and 









is the weight of the relation between





and 















 









∗











(9)

An example of an ontology-based semantic

vector is depicted in Table 6.

Table 6: Ontology-based semantic Vector.

Concept Weight

Sanitary_Disposal_Unit

0,111718

Sanitary_Laundry_and_Cleaning_Equi

pment_Product

0,099504

Team

0,074115

Plumbing_Fixture_and_Sanitary_Was

hing_Unit

0,056649

In this example, the concepts

‘Sanitary_Disposal_Unit’ and

‘Sanitary_Laundry_and_Cleaning_Equipment_Prod

uct’ where boosted because they are already present

in the taxonomy-based vector and are related by the

ontological relation ‘<is_part_of>’.

5 ASSESSMENT OF THE

PRESENTED WORK

Our dataset for evaluation in this paper is primarily

focused in related products used in building and

construction. Figure 4 shows part of the taxonomy

that we classified the documents into. Although the

taxonomy related with product contains 16 sub-

categories, we chose a small subset (5 categories as

shown in Figure 4).

Figure 4: Categories used for evaluation.

We tested our approach with 20 scientific

publications containing on average 3.500 words

each. The reason for choosing scientific publications

was the significant amount of words in each

document, which makes the scattering of each

ClassificationofKnowledgeRepresentationsusinganOntology-basedApproach

189

document in terms of key terms much higher when

compared to simple webpages or news headlines,

making the precise classification a challenge.

All our test documents were manually pre-

labeled with the support of ICONDA search engine

(IRB, 1986) and a close human evaluation.

The final goal of the assessment is to measure

into what extent, a document altered term vector

using the proposed approach, implies a more

meaningful representation of its contents. In other

words, can we affirm that, adding new concepts,

boosting the important ones and removing the less

important ones from a semantic vector leads to a

truly enrichment of KS representations? In order to

answer such, we must first verify, if classifiers can

perform better clustering analysis, by grouping

documents which are more similar within the same

category, using the semantic vectors

Our system uses the altered term vectors as

inputs to various classification algorithms -

specifically, we used an unsupervised classification

algorithm for the evaluations (K-Means clustering

(MacQueen, 1967)).

In the following sub-section, we present the

results of our approach and give details on the kinds

of classification patterns we have observed.

5.1 Results

Our metrics for evaluation of our approach are based

on the traditional notions of precision and recall.

Nevertheless, the precision of such classification

tends to be a subjective issue. As an example, the

way how ontology relations between concepts were

evaluated will deeply affect such classification. As

stated before, our system uses human input

(knowledge experts in the building and construction

domain) to establish the final numerical weights on

each ontological relationship. The importance of

relationships between ontological concepts is by its

nature, an independent and customizable component

that affects classification.

The figures below present the classification

statistics. According to such results, we will explain

in detail why some documents have been

successfully classified and why others didn’t.

Average recall and precision values for 5 categories

using all four vectors (see Figure 5 and Figure 6).

When analyzing in more detail the categories

into which KSs have been assigned to, it was

interesting to conclude that in some cases the

proposed approach brought an added value and in

other situations such added value was not so evident.

Considering the ‘Sanitary Laundry and Cleaning’

Figure 5: Overall Recall Values for 5 Categories.

Figure 6: Overall Precision Values for 5 Categories.

category, we can conclude that using our approach

there was a substantial improvement in terms of

recall metric, from 25% using the statistical-based

approach to 75% using the ontology-based approach.

In this case, the usage of ontological relations

presented in the domain ontology (as shown in Table

5), improved the recall metric from 50% to 75%.

Our results also have shown that quite a few key

document terms had no direct matching with

ontology equivalent terms instances, the reason for

that is related with the use of an incomplete domain

model (further work in extending the Ontology

knowledge base can help to solve this issue to some

extent) and also related with the lack of a proper

method for performing word sense disambiguation

during the matching process (as explained before).

It is possible for a domain Ontology to have

nothing to do with the classification. The goal is to

do no worse than the statistical-based approach

when the Ontology is relevant or irrelevant.

Our document dataset for evaluation took into

account several categories that had some similarities

among key terms present in such documents. For

example, contents in ‘Climate Control’ and ‘Electric

Power and Lighting’ categories have a lot of similar

terms that make such document classification

between the categories a non-trivial task. Statistical

term vectors that rely solely on document contents

have shown to be poor representations, when

0% 20% 40% 60% 80% 100%

CoveringCladdingand

Finish

WasteManagement

SanitaryLaundryand

Cleaning

ElectricPowerand

Lighting

ClimateControl

Recall
