Using Conditional Random Fields with Constraints to Train Support

Vector Machines

Locating and Parsing Bibliographic References

Sebastian Lindner

Institute of Computer Science, University of W¨urzburg, W¨urzburg, Germany

Keywords:

Bibliography, Classiﬁcation, Conditional Random Fields (CRFs), Constraint-based Learning, Information

Extraction, Information Retrieval, Machine Learning, References Parsing, Semi-supervised Learning, Support

Vector Machines (SVMs).

Abstract:

This paper shows how bibliographic references can be located in HTML and then be separated into ﬁelds.

First it is demonstrated, how Conditional Random Fields (CRFs) with constraints and prior knowledge about

the bibliographic domain can be used to split bibliographic references into ﬁelds e.g. authors and title, when

only a few labeled training instances are available. For this purpose an algorithm for automatic keyword

extraction and a unique set of features and constraints is introduced. Features and the output of this Conditional

Random Field (CRF) for tagging bibliographic references, Part Of Speech (POS) analysis and Named Entity

Recognition (NER) are then used to ﬁnd the bibliographic reference section in an article. First, a separation

of the HTML document into blocks of consecutive inline elements is done. Then we compare one machine

learning approach using a Support Vector Machines (SVM) with another one using a CRF for the reference

locating process. In contrast to other reference locating approches, our method can even cope with single

reference entries in a document or with multiple reference sections. We show that our reference location

process achieves very good results, while the reference tagging approach is able to compete with other state-

of-the-art approaches and sometimes even outperforms them.

1 INTRODUCTION

Due to the increasing number of scientiﬁc publica-

tions, there is a growing demand to search for similar

works and compare new results with previous ones.

There already are certain online publishing sys-

tems and special search engines like Google Scholar

or CiteSeerX

that allow this kind of research. To

support searches e.g. for speciﬁc authors, ﬁrst of all

the reference section has to be located within all in-

dexed documents. After that, each reference has to be

divided into a set of ﬁelds e.g. author or journal title.

In the remaining part of this paper, we will therefore

use the terms labeling, tagging and splitting into ﬁelds

as synonyms. Because of the diversity of the content

and the corresponding reference sections this process

is not easy to automate.

Initial approaches to cope with this kind of data

mining task e.g. the previous version of CiteSeer used

http://scholar.google.com

http://citeseerx.ist.psu.edu/index

rule based algorithms. CiteSeer therefore applied

heuristic rules to big sets of data and became a well-

known search engine for references (Bollacker et al.,

1998). But the sets of rules were difﬁcult to maintain

and to adjust to other domains. In contrast to that,

machine learning techniques are much more adapt-

able to other reference locating and labeling domains

(Zou et al., 2010). Generally speaking, supervised

machine learning algorithms use labeled training ma-

terial to build a statistical model, which is then used

to tag or label further data. First machine learning ap-

proaches used Hidden Markov Models (HMMs) for

this task (Hetzner, 2008). Nowadays CRFs are most

popular, because they allow the use of dependend fea-

tures and joint inference over the whole reference and

so achieve better results (Gao et al., 2012).

In cooperation with Springer Science+Business

Media we develop the web platforms SpringerMa-

terials

and SpringerReference

for online document

http://www.springermaterials.com

http://www.springerreference.com

Lindner S..

Using Conditional Random Fields with Constraints to Train Support Vector Machines - Locating and Parsing Bibliographic References.

DOI: 10.5220/0004546100280036

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval and the International Conference on Knowledge

Management and Information Sharing (KDIR-2013), pages 28-36

ISBN: 978-989-8565-75-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

publishing. Those platforms have a great amount of

bibliographic data with a variety of citation styles.

Because of these different citation styles, using some

random part of the available references for training

to label some other part of the references would not

lead to a good labeling performance. However, since

the content is organized in books and subject areas,

training of separate models can be done with regard

to this segmentation. Because the generation of la-

beled training data for each of this content partitions

is a time consuming job, the focus of this paper lies

on cases where only a few training instances are avail-

able.

Due to the limited amount of training instances,

a Conditional Random Field and additional prior

knowledge in form of constraints about the bibliog-

raphy domain in addition to a few labeled instances

are used for training. This CRF can then easily be

adapted to other domains (citation styles) by gener-

ating a few new labeled instances for training and

changing the constraints. That way, a new CRF model

can be trained for each book or subject area. This re-

sults in a signiﬁcant improvement in overall labeling

accuracy.

Afterwards, we explain how the results of this ref-

erence labeling process can then be used to locate the

reference section in the ﬁrst place. Normally, the

locating of the reference section would be the ﬁrst

step in extracting bibliographic references from doc-

uments. But we demonstrate how results of the refer-

ence tagging can even be of value for the reference

locating process. Therefore, we reuse the features

and the output of the reference labeling process in ad-

dition to the results of a Named Entity Recognition

(NER) analysis, a Part Of Speech (POS) tagging step

and the generation of some additional features to lo-

cate the reference section in a document with a ma-

chine learning algorithm. We compare the use of a

Conditional Random Field (CRF) and a Support Vec-

tor Machine (SVM) for this task.

The results in this paper proof that the mentioned

reference locating process has a very good accu-

racy, while the reference tagging can compete with

other state-of-the-art approaches and even outperform

them. Since the features and the output of the refer-

ence parsing step are used to locate the reference sec-

tion in an article this step is introduced ﬁrst.

So in the ﬁrst part of this paper, we demonstrate

how references can be parsed. Therefore, ﬁrst of all

an extended constraint model for CRFs is introduced.

Next, all used features and constraints needed for this

task are described. In addition to that, it is shown

how automatically extrated constraints can be used to

construct new features for learning.

In the second part of the paper, we propose a new

method for the classiﬁcation of HTML blocks into

those containing a reference and those which do not

contain a reference. Therefore, a novel feature set

for two machine learning algorithms to classify these

blocks is introduced. Next, the results for the refer-

ence parsing and location step are shown and com-

pared to other previous approaches. Last but not least,

we draw conclusions and propose several topics for

further research.

2 REFERENCE PARSING

First of all, we formally introduce the task of ref-

erence parsing. It is to assign the correct labels

y = {y

, y

, . . . y

} to tokens of an input sequence

x = {x

, x

, . . . x

}. Tokens are thereby generated by

splitting a reference string on whitespace. For exam-

ple, the token Meier in an input sequence should re-

ceive the label AUTHOR. For examples of tagged ref-

erences see Table 1.

This also is a common task in other research areas

like Part Of Speech tagging and semantic role labeling

(Park et al., 2012). So all techniques shown in this

paper can similarly be used in other ﬁelds of research

as well.

2.1 CRFs with extended Generalized

Expectation Criteria

Linear-chain Conditional Random Fields (CRFs) are

a probabilistic framework that uses a discriminative

probabilistic model over an input sequence x and an

output label sequence y as shown in equation 1.

(y|x) =

Z(x)

exp

∑

(x, y)

(1)

In case of a linear chain CRF F

(x, y) are a number of

feature functions and Z(x) is a normalization factor as

described in (Sutton and McCallum, 2006).

Since the goal is to train a model with as few la-

beled training instances as possible, constraints are

used to improve labeling results. An existing concept

of Conditional Random Fields (Mann and McCallum,

2010) is therefore extended to allow more complex

constraints.

Given a set of training data T =

n

(1)

, y

(1)



, . . . ,



(m)

, y

(m)

o

and an additional set

of unlabeled references U, the goal of training a Con-

ditional Random Field with extended constraints is

to learn the parameters λ

by maximizing equation 2.

While training, these additional unlabeled references

UsingConditionalRandomFieldswithConstraintstoTrainSupportVectorMachines-LocatingandParsingBibliographic

References

Table 1: Examples of tagged references.

(a) <author>N. Benvenuto and F. Piazza.</author><title>On the Complex Backpropagation Algorithm.</title>

<journal>IEEE Transactions on Signal Processing,</journal><volume>40(4)</volume>

(b) <author>C. Jay, M. Cole, M. Sekanina, and P. Steckler.</author>

<title>A monadic calculus for parallel costing of a functional language of arrays.</title> In

<editor>C. Lengauer, M. Griebl, and S. Gorlatch, editors,</editor>

<booktitle>Euro-Par’97 Parallel Processing,</booktitle><volume>volume 1300</volume> of LNCS,

<pages>pages 650-661.</pages><publisher>Springer-Verlag,</publisher><date>1997.</date>

are used to calculate a distance between the current

labeling results on these unlabeled references and the

provided constraints.

Θ(λ, T,U) =

∑

logp



(i)



−

∑

2σ

−δD(q|| ˆp

(2)

where q is a given target distribution and

ˆp

= p

| f

(x, k) = 1, . . . , f

(x, k) = 1) (3)

with all f

(x, k) being feature functions that only de-

pend on the input sequence. The ﬁrst term in equation

2 is the log-likelihood used by most CRF implemen-

tations for training and the second term is a Gaussian

prior for regularization. D(q|| ˆp

) is a function to cal-

culate a distance between the provided target proba-

bility distribution and the distribution calculated with

the help of the unlabeled training data. To penalize

differences in these distributions, δ is thereby used as

a weighting factor (Lafferty et al., 2001). This is the

part of the equation that takes the constraints into ac-

count during training.

In this paper we compare three different distance

metrics against each other. The ﬁrst one is the

Kullback-Leibler (KL), the second the L

distance

and the third one is a range-based version of the L

distance. In the last case, target probability ranges

can be speciﬁed instead of one speciﬁc value. If the

calculated probability then falls within this range, the

calculated distance is 0.

As implementation we used MALLET (McCal-

lum, 2002), which implements CRFs with General-

ized Expectations (GE) as described in (Mann and

McCallum, 2010). Instead of restricting the target

probability distribution to the use of only one fea-

ture (see equation 4), we extended this functionality

to support multiple features as well (see equation 3).

This way more complex constraints can be deﬁned,

which in return improved our labeling results.

ˆp

= p

| f

(x, k) = 1) (4)

An example of such a constraint could be that if

a name appears at the beginning of a document, it

should be labeled AUTHOR.

2.2 CRF Features for Reference Parsing

The following enumeration brieﬂy lists the different

categories of features used by the reference tagging

process. We therefore use a set of binary feature func-

tions similar to the ones used by ParsCit (Councill

et al., 2008).

1. Word based Features. Indicate the presence of

some signiﬁcant predeﬁned words like ’No.’,’et

al’, ’etal’, ’ed.’ and ’eds.’.

2. Dictionary based Features. Indicate whether a

dictionary contains a certain word in the reference

string like for author ﬁrst- and lastnames, months,

locations, stop words, conjunctions and publish-

ers.

3. Regular Expression based Features. Indicate

whether a word in the reference string matches

a regular expression like ordinals (e.g. 1st,

2nd...), years, paginations (e.g. 200-215), ini-

tials (e.g. J.F.) and patterns that indicate whether

a word contains a hyphen, ends with punctuation,

contains only digits, digits or letters, has lead-

ing/trailing quotes or brackets or if the ﬁrst char

is upper case.

4. Keyword Extraction based Features. Indicate

whether a word is in a list of previously extracted

keywords for a certain label.

For the keyword extraction process the GSS measure

(Sebastiani, 2002) was used. GSS is thereby deﬁned

GSS(t

, c

) = p(t

, c

) · p(

, c

) − p(t

, c

) · p(t

, c

(5)

where p(

, c

) for example is the probability that

given a label c

, the word t

does not occur under this

label.

Table 2 shows a brief excerpt of the extracted key-

words. As one can see, many useful keywords could

be automatically extracted for the labels.

In addition to the already mentioned features, a

window feature with size 1 and a feature that indi-

cates the position of each word in the reference string

was used for training the CRF. Window feature in

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

Table 2: Automatically extracted keywords with their cor-

responding label.

Keyword

Label

Proceedings BOOKTITLE

Conference BOOKTITLE

PAGES

Press PUBLISHER

ACM

JOURNAL

Journal JOURNAL

University

INSTITUTION

Proc BOOKTITLE

Vol

VOLUME

this case means that features of one token (word) are

transferred to its neighbors.

2.3 CRF Constraints for Reference

Parsing

In order to use Conditional Random Fields with ex-

tended Generalized Expectations as shown in equa-

tion 2, constraints must be deﬁned for the reference

labeling task. The following enumeration shows the

types of constraints used and names a few examples

of them:

1. Constraints that depend on a single feature

function e.g. extracted keywords for a label

should be tagged with that exact label or words

that match a year pattern should deﬁnitely be la-

beled YEAR

2. Constraints that depend on multiple feature

functions e.g. words at the beginning of the ref-

erence string and are contained in the dictionary

of names should be labeled AUTHOR. At the end

of the reference string they should be labeled ED-

ITOR. Also a number right to word ’No.’ should

recieve the label VOLUME.

An extensive list of all used constraints, their as-

signed probability distributions and other extracted

keywordscan be found in our previouspaper (Lindner

and H¨ohn, 2012).

3 REFERENCE LOCATING

Existing algorithms for extracting information from

HTML usually depend on the Document Object

Model (DOM) structure of the document. A related

ﬁeld of work that has recently been studied by several

researches is the automatic extraction of records from

web pages. Such records could for example be the

items in an online shopping cart. Most of them are

based on identifying similar DOM tree structures in

the web page. Using visual information, tree match-

ing and tree alignment, Zhai and Liu were able to

successfully extract such structured records (Zhai and

Liu, 2006). Fontn et al. even extended these ap-

proaches to extract sub-records (Fontan et al., 2012).

On the other hand, data mining algorithms on

scanned documents mostly analyze geometric fea-

tures and layout. Either a top-down approach to re-

cursively divide the whole document into smaller sec-

tions e.g. using X-Y cut (Ha et al., 1995), or a bottom-

up approach to cluster more and more small compo-

nents together (Jain and Yu, 1998) is used. Both of

these processes terminate when some criteria is met.

In this part of the paper, two machine learning

techniques for the identiﬁcation of a reference section

in an HTML document are introduced. Therefore, the

performances of a Conditional Random Field (CRF)

and a Support Vector Machine (SVM) are compared

against each other. First of all the HTML is parti-

tioned into units belonging together (blocks) based on

the HTML DOM (Document Object Model) and vi-

sual layout information. After that, features for each

of these blocks are extracted and used for classiﬁca-

tion into reference and non-reference blocks.

Zou et al. followed a similar approach by ﬁrst ex-

tracting zones from HTML and then training a SVM

with features from these zones (Zou et al., 2010).

Since we used our own dataset from SpringerRefer-

ence, there are some different preconditions in com-

parison to the approach of Zou et al. They used the

MEDLINE 2006 database for reference section locat-

ing experiments. In their approach the output of the

SVM and the corresponding conﬁdence values for the

classiﬁcation results are used in an equation to deter-

mine the best candidates for the ﬁrst and last reference

entry (see equation 6).

∗

] = argmax

∏

≤i≤t

P(c

= R)

∏

0≤ j<t

< j≤N

(1− P(c

= R)),

(6)

where t

and t

are the locations of the ﬁrst and last

reference, respectively. N ist the total number of child

zones and P(c

= R) is the probability of the k

child

being a reference zone (Zou et al., 2010).

Because not all of our documents even have a ref-

erence section or have multiple reference sections in

one single document, their approach is not directly ap-

plicable. Their ‘repair step‘ can also not be usefully

applied if a document only contains one reference en-

try. In addition to that, their approach uses features

like the left and top position of extracted zones for

training. Since some of our articles have multiple ref-

erence sections these features can not be transferred

to our domain. If we had a further reading section

UsingConditionalRandomFieldswithConstraintstoTrainSupportVectorMachines-LocatingandParsingBibliographic

References

Table 3: (a) Example of a reference section, (b) HTML source code of the reference section, (c) Named Entity Recognition

results for a reference entry, (d) Part Of Speech tagging results for a reference entry (e) Part Of Speech tagging results for a

random paragraph, (f) CRF tagging results for a random paragraph

(a) 1. McDufﬁe, H. H., Dosman, J. A., Semchuk, K. M., Olenchock, S. A., & Sentihilselvan, A. (1995).

Agricultural health and safety: Workplace, environment and sustainability. Boca Raton, FL: Lewis.

2. Messing, K. (1998). One-eyed science: Occupational health and women workers. Philadelphia: Temple

University Press.

(b)

<ul>

<li>1. McDuffie, H. H., Dosman, J. A., Semchuk, K. M., Olenchock, S. A., &

Sentihilselvan, A. (1995). Agricultural health and safety: Workplace,

environment and sustainability. Boca Raton, FL: Lewis.</li>

<li>2. Messing, K. (1998). One-eyed science: Occupational health

and women workers. Philadelphia: Temple University Press.</li>

</ul>

Sentihilselvan, A. (1995)

DATE. Agricultural health and safety: Workplace, environment and sustainability

Boca Raton

LOCATION, FL LOCATION: Lewis. PERSON

(d) McDufﬁe

NNP, H. NNP H. NNP, Dosman NNP, J. NNP A. NNP, Semchuk NNP, K. NNP M. NNP, Olenchock NNP,

NNP A. NNP, & CC Sentihilselvan NNP, A. NN (1995) CD. Agricultural NNP health NN and CC safety NN:

Workplace

NNP, environment NN and CC sustainability NN. Boca NNP Raton NNP, FL NN: Lewis NNP.

(e) The DT appearance NN of IN any DT coast NN, the DT Arctic NNP included VBD, depends VBZ on IN the DT

alterations

NNS that WDT have VBP occurred VBN to TO the DT geologic JJ base NN it PRP inherited VBD.

(f) The

TITLE appearance TITLE of TITLE any TITLE coast TITLE, the TITLE Arctic TITLE included TITLE,

depends

NOTE on NOTE the NOTE alterations NOTE that NOTE have NOTE occurred NOTE to NOTE

the

NOTE geologic NOTE base NOTE it NOTE inherited NOTE.

after the ﬁrst paragraph in a long document, the loca-

tion information of this block would not be different

in comparison to other normal blocks. So the posi-

tion of a block with a reference in the document is not

signiﬁcant for the learning process.

3.1 Extraction of Blocks

Table 3 shows an example of two references (a) and

their corresponding source code (b). As one can see

in this case an unordered list is used to arrange the two

references. But there are many other ways to structure

the same information, for example by using a table

<table>

, a new paragraph

for each entry or just

line breaks

between text.

In order to get blocks of content belonging to-

gether, one can not just use the DOM and extract all

elements that have no child elements. For example

in Table 3 (b) the title of the two citations is italic.

Extracting elements without children as blocks would

lead to very small blocks, which have too few relevant

information for a correct classiﬁcation.

To cope with that, a bottom-up approach is used

to successively merge inline DOM nodes. These are

nodes that do not introduce line breaks. For this we

use the HTML parser jsoup

. This parser has a prede-

ﬁned lists of tags that introduce line-breaks like

<div>

and those, which are inline elements like

or simple text. In the example of Table 3 (b)

http://jsoup.org/

the italic titles would be merged with the surrounding

rest of the reference string, because the text and the

italic HTML node are inline elements. The

<li>

el-

ement however, introduces a line-break. So each of

these two references would end up in an own block.

Figure 1 shows examples of extracted blocks. If the

whole document basically only contains text and is

structured by

and inline elements that use Cas-

cading Style Sheet (CSS) information, the extraction

of the blocks can be quite difﬁcult.

Figure 1: Examples for extracted blocks.

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

3.2 Reference Block Classiﬁcation

First of all, the features for the classiﬁcation process

are introduced. Afterwards it is shown, how two dif-

ferent machine learning techniques can be used to

classify blocks into those, which contain a reference

and those which do not contain a reference. There-

fore, a SVM approachis presented and then compared

to a CRF for classiﬁcation.

Initially, a set of features is generated by other ma-

chine learning modules. The Stanford Named Entity

Recognizer (Finkel, 2007) is used to extract persons,

dates, locations and organizations. This software in

turn utilizes a Conditional Random Field to extract

these entities. An example output for a reference

block is given in Table 3 (c). In this table the cor-

responding label to a word is appended by LABEL.

In comparison to blocks that do not belong to a refer-

ence section, the number of extracted entities is much

higher. So the number of entities is a clear indicator

for a reference entry.

Next the Stanford Log-linear Part-Of-Speech Tag-

ger (Toutanova et al., 2003) is applied to each block.

This uses a Cyclic Dependency Network for its label-

ing process. Table 3 (d) and (e) show the output of

this tagging process for a reference block and a ran-

dom other block from our corpus. Almost all words

in the reference string are tagged as NN (Noun, sin-

gular or mass) or NNP (Proper noun, singular). In the

case of a random non-reference paragraph however,

the number of conjunctions or verbs is much higher

like VBD (Verb, past tense), VBZ (Verb, 3rd person

singular present), VBP (Verb, non-3rd person singular

present), VBN (Verb, past participle) or VBG (Verb,

gerund or present participle). So the number of verb

forms in a block is another indicator for classiﬁcation.

Other labels that appear in this table are: CC (Coor-

dinating conjunction), DT (Determiner), IN (Preposi-

tion or subordinating conjunction), JJ (Adjective).

In addition to these, we use the output of our own

reference parser as input for classiﬁcation. While it

is able to correctly label most reference sections, its

output is very different for a non-reference section as

shown in Table 3 (f). All words are labeled as titles or

notes. Not even one author is found in the string. So

the output of the CRF reference tagger can also be of

value to tell a reference and a non-reference section

apart.

On top of the machine learning outputs, a number

of other features are used for classiﬁcation. All fea-

tures generated by the reference parsing process are

reused in this reference locating step as well. Mean-

ing features for dictionaries, important keywords, reg-

ular expressions and so on.

Furthermore, we used the following features for

each block:

• text length

• number of words

• average word length

• number of punctuation characters

• average number of punctuation character (normal-

ized by the number of words)

The number of occurrences of each of the previously

mentioned features is then used for training. To take

the position of these features in the block into ac-

count, each of the features is also combined with a

position number (from 1 to 6) that indicates where

the feature appeared. It is for example expected to

ﬁnd many author names at the beginning of a refer-

ence entry and only a few at the end.

Next we use the Selenium web browser automa-

tion framework

to determine the y-coordinate of

each block. This framework is able to render an

HTML page in a browser and provides an interface

to get all visual and DOM based information for this

page. The blocks are then ordered according to their

vertical position and the features of block neighbors

are added to the current block. Because it is ex-

pected that reference blocks are found in groups, the

classiﬁcation results can be increased this way. The

same is true for blocks that are not reference entries.

We could retrieve additional layout information about

each block from rendering it in a browser, but since

we have multiple reference sections in some docu-

ments, additional visual information were not useful.

As Support Vector Machine implementation we

used the Weka Data Mining software (Hall et al.,

2009). It implements a SVM with Sequential Mini-

mal Optimization and some additional improvements

to increase training speed (Keerthi et al., 2001). The

SVM is then used to classify each block into the cate-

gories reference or non-reference. Since a CRF’s pur-

pose is to label an input sequence and not a single

block, a whole document and all blocks in it are used

as an input sequence for training. Unfortunately the

Mallet CRF does not support continuous values for

training, so ﬁrst all features have to be discretized.

This is done with the help of an algorithm by Fayyad

and Irani (Fayyad and Irani, 1993), which is also im-

plemented by the Weka framework.

seleniumhq.org

UsingConditionalRandomFieldswithConstraintstoTrainSupportVectorMachines-LocatingandParsingBibliographic

References

4 EVALUATION OF REFERENCE

LOCATING

To evaluate the reference locating, we collected a

random set of 1,000 articles from our SpringerRef-

erence corpus that had a reference section. These

were then split into 500 articles for training and

500 for testing. The 500 testing articles contained

42,023 blocks of which 8,983 were reference blocks.

From these 41,764 could be correctly classiﬁed by the

SVM approach and 259 got mislabeled. This means

99.3837% of the blocks got the correct classiﬁcation,

while only 0.6163% blocks were classiﬁed wrong.

The CRF however did not perform this well. It

only achieved 91.3% accuracy. Perhaps the CRF is

not able to extract the most important features out of

such a variety of features. Additionally, since the CRF

uses each document as only one training instance and

treats all the blocks as an input sequence, 500 training

instances might just not be enough training material.

Another problem might be that the algorithm used for

discretizing did not split the value ranges into usefull

segments.

The results are slightly worse in comparison to

those of Zou et al. (Zou et al., 2010). Only 8 blocks

out of 22,147 got misclassiﬁed by their approach us-

ing the MEDLINE 2006 database. As already men-

tioned before, their approach would not be as success-

ful on our data. In contrast to the MEDLINE docu-

ments, many of our documents have zero or only one

reference. Despite that, there are articles that have

more than one reference section e.g. a further read-

ing section. Using a ’repair step’ to ﬁnd the ﬁrst and

last entry of a reference section would not be possible

here. Either because there is only one entry or all en-

tries between two different reference section would be

classiﬁed as a reference section through this step. So

we concentrated our effort on generating better fea-

tures for learning, instead of trying to increase results

through an additional ’repair step’ at the end.

5 EVALUATION OF REFERENCE

PARSING

As a reference parsing test domain we used the

Cora reference extraction task (McCallum et al.,

2000) to compare our approach to previous ones.

This set contains 500 labeled reference with 13 dif-

ferent labels like AUTHOR, BOOKTITLE, DATE,

EDITOR, INSTITUTION, JOURNAL, LOCATION,

NOTE, PAGES, PUBLISHER, TECH, TITLE, VOL-

UME .

5.1 Labeling Results

Generally the same test approach as described in

(Chang et al., 2007) was used. 500 reference in-

stances were split into 300 for training, 100 for de-

velopment and 100 for testing in the evaluation pro-

cess. From this training set we take a varying num-

ber of samples from 5 to 300 for training. For semi-

supervised learning we also use 1000 instances of un-

labeled data, we took from the FLUX-CiM and Cite-

SeerX databases. These can be obtained from the

ParsCit

website.

The labeling results are shown in Table 4. The re-

sults report the token based accuracy i.e. the percent-

age of correct labels and are calculated as averages

over 5 runs. Column Sup contains the results for a

CRF with the same features as previously described

but with no constraints. Column GE-KL shows the

results for our Generalized Expectation with Multi-

ple Feature approach using the KL-divergenceand the

last column those for the L

-Range distance metric

GE-L

-Range.

Table 4: Comparison of token based accuracy for different

supervised / semi-supervised training models for a varying

number of labeled training examples N. Results are an av-

erage over 5 runs in percent.

Sup PR CODL GE-KL GE-

-Range

5 69.0 75.6 76.0 74.6 75.4

73.8 - 83.4 81.2 83.3

80.1 85.4 86.1 85.1 86.1

84.2 - 87.4 87.2 88.4

87.5 - - 89.0 90.5

100

90.2 - - 90.4 91.2

300

93.3 94.8 93.6 93.9 94.1

In this paragraph, our method is compared to other

state-of-the-art semi-supervised approaches. Column

CODL shows the results for the constraint-driven

learning framework (Chang et al., 2007). Here the

top-k-inference results are iteratively used in a next

learning step. In Posterior Regularization (column

PR) the E-Step in the expectation maximization al-

gorithm is modiﬁed to take constraints into account

(Ganchev et al., 2010). Dashes indicate that the refer-

enced papers did not contain values for a comparison.

As one can see, our approaches can compete

with other leading semi-supervised training methods.

While our approaches perform slightly worse than the

others with a very limited amount of training data, one

of our approaches outperforms the other techniques

with N = 25 and N = 50 training instances. One rec-

ognizes that the introductionof constraints greatly im-

proves labeling results. For N = 20 the improvement

http://aye.comp.nus.edu.sg/parsCit/

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

of GE-L

-Range in comparison to (column Sup) is

6 percentage points. In our experiments a CRF us-

ing GE constraints with multiple feature functions and

−Range as distance metric has the best labeling re-

sults.

The results also suggest that the positive inﬂuence

of constraints decreases with an increasing number of

training instances N. The traditional CRF (column

Sup) is then able to determine proper weights for fea-

tures without user provided constraints. In the case

of relatively many training instances N = 300 com-

plex constraints even seem to have slightly negative

effects in comparison to use of simpler constraints in

other approaches (column PR).

Table 5 shows precision, recall and the F

measure

for each separate label with 15 training instances us-

ing GE with multiple feature functions and L

-Range

as distance metric.

Table 5: Precision, recall and F1 measure for label accuracy

with N = 15 for a CRF with GE-L

-Range.

Label

Precision Recall F

AUTHOR 98.5 98.6 98.6

DATE

95.0 82.5 88.3

EDITOR

92.3 52.8 67.2

TITLE

85.5 98.2 91.4

BOOKTITLE

84.3 84.1 84.2

PAGES

82.6 90.0 86.1

VOLUME

75.8 73.5 74.6

PUBLISHER

73.7 35.0 47.5

JOURNAL

71.9 66.6 69.1

TECH

67.5 25.7 37.2

INSTITUTION

62.4 43.4 51.2

LOCATION

51.4 60.0 55.4

NOTE

15.6 10.0 12.2

As Table 5 indicates, there is a big difference in

the F

value for all labels. Because some labels like

AUTHOR occur much more often in the training set

and we set up more constraints for these labels, the

performances in these cases are better. In contrast to

that, labels like NOTE achieve a rather poor accuracy.

However it is important to have a good performance

for more common labels to achieve a good overall la-

beling performance.

It also has to be mentioned that in cases with only

few reference instances the results can have a high

standard deviation. The diversity of strings in this

small portion of training material might simply be to

high for proper training.

6 CONCLUSIONS AND FUTURE

WORK

We proposed a new method for locating and parsing

bibliographic references in HTML documents. We

pointed out how HTML content can be grouped into

blocks based on the Document Object Model. After-

wards, we have shown how these then can be used for

classiﬁcation into the categories ’is a reference’ or ’is

not a reference’. Therefore, the features and output of

the reference parsing step are used to locate the bibli-

ographic reference section.

In addition to that, we used other machine learning

techniques like Part Of Speech tagging and Named

Entity Recognition to obtain further input for our ref-

erence location process and so improvedclassiﬁcation

results. Next, a Conditional Random Field and a Sup-

port Random Machine for the classiﬁcation task were

compared against each other. In our setup the SVM

approach achieved much better results than a similar

approach using a CRF. Even though the reference lo-

cation process by Zou et al. achieves slightly better

results, we have shown that their approaches can not

be transferred to our documents from the Springer-

Reference corpus. Their ’repair step’ can not be ap-

plied to our document domain, because it assumes

many references in one section and only one reference

section per document. Despite the difﬁculties of our

test domain, our approach yields very good locating

results.

Furthermore, we introduced a new method of

parsing references with constraints. The labeling re-

sults proof that the proposed semi-supervised ma-

chine learning algorithm can compete with other

state-of-the-art approaches. It even outperforms other

approaches with a certain amount of training in-

stances.

Both the reference locating and the reference pars-

ing approach can easily be adapted to other do-

mains of data. For example, the CRF with con-

straints approach could also be used to build a custom

Named Entity Recognizer for historical texts. Since

many NER approaches already use CRFs in the back-

ground, constraints could improve results while only

needing a few training instances. The proposed clas-

siﬁcation algorithms could for example be used to de-

termine if a page contains a shopping cart and so used

for data mining purposes.

In future we would like to evaluate how biblio-

graphic databases can be used to correct citations and

even augment them with missing information as pro-

posed by Gao et al. (Gao et al., 2012). The reference

information can then even be used to calculate a relat-

edness for documents. This information could for ex-

ample be used in an automatic link generation process

for disambiguation. Since a method for the automatic

extraction of keywords was proposed for feature ex-

traction, we would like to concentrate future effort in

UsingConditionalRandomFieldswithConstraintstoTrainSupportVectorMachines-LocatingandParsingBibliographic

References

the automatic extraction of further features. On top of

that, we are trying to not only include constraints in

the learning phase of a Conditional Random Field, but

also in the inference step. We believe that this could

even improve labeling results.

REFERENCES

Bollacker, K. D., Lawrence, S., and Giles, C. L. (1998).

CiteSeer: An autonomous web agent for automatic re-

trieval and identiﬁcation of interesting publications. In

Proceedings of the second international conference on

Autonomous agents, pages 116–123. ACM.

Chang, M.-W., Ratinov, L., and Roth, D. (2007). Guid-

ing semi-supervision with constraint-driven learning.

Proceedings of the 45th Annual Meeting of the Asso-

ciation of Computational Linguistics, pages 280–287.

Councill, I. G., Giles, C. L., and Kan, M.-Y. (2008). ParsCit:

An open-source CRF reference string parsing pack-

age. In International Language Resources and Evalu-

ation. European Language Resources Association.

Fayyad, U. M. and Irani, K. B. (1993). Multi-interval dis-

cretization of continuous-valued attributes for classi-

ﬁcation learning. In Thirteenth International Joint

Conference on Articial Intelligence, volume 2, pages

1022–1027. Morgan Kaufmann Publishers.

Finkel, J. R. (2007). Named entity recognition and the stan-

ford NER software.

Fontan, L., Lopez-Garcia, R., Alvarez, M., and Pan,

A. (2012). Automatically extracting complex data

structures from the web. International Conference

on Knowledge Discovery and Information Retrieval

(KDIR 2012).

Ganchev, K., Graa, J., Gillenwater, J., and Taskar, B.

(2010). Posterior regularization for structured latent

variable models. Journal of Machine Learning Re-

search, 11:2001–2049.

Gao, L., Qi, X., Tang, Z., Lin, X., and Liu, Y. (2012). Web-

based citation parsing, correction and augmentation.

In Proceedings of the 12th ACM/IEEE-CS joint con-

ference on Digital Libraries, pages 295–304. ACM.

Ha, J., Haralick, R. M., and Phillips, I. T. (1995). Recursive

XY cut using bounding boxes of connected compo-

nents. In Document Analysis and Recognition, 1995.,

Proceedings of the Third International Conference on,

volume 2, pages 952–955. IEEE.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The WEKA data min-

ing software: an update. ACM SIGKDD Explorations

Newsletter, 11(1):10–18.

Hetzner, E. (2008). A simple method for citation meta-

data extraction using hidden markov models. In Pro-

ceedings of the 8th ACM/IEEE-CS joint conference on

Digital libraries, pages 280–284. ACM.

Jain, A. K. and Yu, B. (1998). Document representation and

its application to page decomposition. Pattern Anal-

ysis and Machine Intelligence, IEEE Transactions on,

20(3):294–308.

Keerthi, S. S., Shevade, S. K., Bhattacharyya, C., and

Murthy, K. R. K. (2001). Improvements to platt’s

SMO algorithm for SVM classiﬁer design. Neural

Computation, 13(3):637–649.

Lafferty, J., McCallum, A., and Pereira, F. (2001). Con-

ditional random ﬁelds: Probablistic models for seg-

menting and labeling sequence data. In Proceedings of

the Eighteenth International Conference on Machine

Learning (ICML-2001), pages 282–289.

Lindner, S. and H¨ohn, W. (2012). Parsing and Maintaining

Bibliographic References. International Conference

on Knowledge Discovery and Information Retrieval

(KDIR 2012).

Mann, G. S. and McCallum, A. (2010). Generalized ex-

pectation criteria for semi-supervised learning with

weakly labeled data. Journal of Machine Learning

Research, 11:955–984.

McCallum, A. (2002). Mallet: A machine learning for lan-

guage toolkit. http://mallet.cs.umass.edu.

McCallum, A., Nigam, K., Rennie, J., and Seymore, K.

(2000). Automating the contruction of internet portals

with machine learning. Information Retrieval Journal,

3:127–163.

Park, S. H., Ehrich, R. W., and Fox, E. A. (2012). A hybrid

two-stage approach for discipline-independent canon-

ical representation extraction from references. In Pro-

ceedings of the 12th ACM/IEEE-CS joint conference

on Digital Libraries, JCDL ’12, pages 285–294, New

York, NY, USA. ACM.

Sebastiani, F. (2002). Machine learning in automated text

categorization. ACM Computing Surveys, 34(1):1–47.

Sutton, C. and McCallum, A. (2006). Introduction to Con-

ditional Random Fields for Relational Learning. MIT

Press.

Toutanova, K., Klein, D., Manning, C. D., and Singer, Y.

(2003). Feature-rich part-of-speech tagging with a

cyclic dependency network. In Proceedings of the

2003 Conference of the North American Chapter of

the Association for Computational Linguistics on Hu-

man Language Technology-Volume 1, pages 173–180.

Association for Computational Linguistics.

Zhai, Y. and Liu, B. (2006). Structured data extraction

from the web based on partial tree alignment. Knowl-

edge and Data Engineering, IEEE Transactions on,

18(12):1614–1628.

Zou, J., Le, D., and Thoma, G. R. (2010). Locating and

parsing bibliographic references in HTML medical ar-

ticles. International Journal on Document Analysis

and Recognition, 2:107–119.

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval
