Analysis of Mexican Research Production

Exploring a Scientifical Database

Silvia B. González-Brambila

, Mihaela Juganaru-Mathieu

and Claudia N. González-Brambila

Departamento de Sistemas, Universidad Autónoma Metropolitana, Unidad Azcapotzalco,

Av. San Pablo 180, Col. Reynosa Tamaulipas, México D.F., C.P. 02200, Mexico

Departement ISCOD, Institut Henri Fayol, Ecole Nationale Supérieure des Mines de Saint Etienne,

158, cours Fauriel, 42023-F, Saint Etienne, France

Department of Business Administration, Instituto Tecnológico Autónomo de Mexico,

Río Hondo 1, Col. Atizapan San Angel, México, D.F. C.P. 01080, Mexico

Keywords: Text Mining, Analysis, Clustering, Scientific Field.

Abstract: This paper presents an exploring analysis of the research activity of a country using ISI web of Science

Collection. We decided to focus the work on Mexican research in computer science. The aim of this text

mining work is to extract the main direction in this scientific field. The focal exploring axe is: clustering.

We have done two folds analysis: the first one on frequency representation of the extracted terms, and the

second, much larger and difficult, on mining the document representations with the aim of finding clusters

of documents, using the most used terms in the title. The cluster algorithms applied were hierarchical,

kmeans, DIANA, SOM, SOTA, PAM, AGNES and model. Experiments with different number of terms and

with the complete dataset were realized, but results were not satisfactory. We conclude that the best model

for this type of analysis is model based, because it gives a better classification, but still it needs better

performance algorithms. Results show that very few areas are developed by Mexicans.

1 INTRODUCTION

This paper presents an analysis of a research activity

in the field of computer science. We have chosen to

work with the Mexican production in the field of

computer science during the years 2009-2011 (our

choice of this field was induced by our own

competencies). Naturally, our work is easy

translatable in to other science fields with a weak

condition of a domain expert presence.

Document classification has a lot of different

applications, like sentimental analysis in social

media, e-mail spam, news monitoring, and sorting

out useful documents from documents that are not of

interest. Document classification can be coarsely

divided in supervised and unsupervised (clustering).

One of the disadvantages of the supervised

classification is that it is necessary to assign the

categories in advance. In general, the classification

of research papers is done manually by the authors

or by specialized people.

Computer Sciences have a lot of subareas, and is

one of the disciplines with highest growth. The most

used classifications are from ACM and Microsoft

Research Search. It would be desirable to find

something similar to these classifications.

The Association for Computing Machinery

(ACM) is a U.S. –based international learned society

for computing. Founded in 1947, it´s the world’s

largest and most prestigious scientific and

educational computing society. The 2012 ACM

Computing Classification System (ACM, 2012) was

created by a group of volunteers. It serves as a

standard classification system in the computing

field, and has been developed as a poly-hierarchical

ontology that can be utilized in semantic web

applications. The main areas considered are eleven:

Hardware, Computer Systems Organization,

Networks, Software and its engineering, Theory of

Computation, Mathematics of Computing,

Information Systems, Security and Privacy, Human-

Centered Computing, Computing Methodologies

and Applied Computing.

Microsoft Academic Search (Microsoft, 2012) is

a service developed by Microsoft Research to find

academic content, researchers, institutions and

177

González Brambila S., Juganaru-Mathieu M. and González-Brambila C..

Analysis of Mexican Research Production - Exploring a Scientiﬁcal Database.

DOI: 10.5220/0004548201770182

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval and the International Conference on Knowledge

Management and Information Sharing (KDIR-2013), pages 177-182

ISBN: 978-989-8565-75-4

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

activities. It indexes academic papers and authors.

The main areas considered are: Algorithms,

Artificial Intelligence, Bioinformatics &

Computational Biology, Computer Education,

Computer Vision, Data Mining, Databases,

Distributed & Parallel Computing, Graphics,

Hardware & Architecture, Human-Computer

Interaction, Information Retrieval, Machine

Learning & Pattern Recognition, Multimedia,

Natural Language & Speech, Networks &

Communications, Operating Systems, Programming

Languages, Real-time & Embedded Systems,

Scientific Computing, Security & Privacy,

Simulation, Software Engineering and World Wide

Web.

The main contribution of this paper is that it

shows that some human experience is needed in

order to interpret the results obtained by different

data mining techniques, because they produce

different results when the same database is

considered. Also, that there are only few areas in

which Mexicans are working in. In this paper we

analyzed all titles of ISI research papers written by

Mexican researchers during 2009, 2010 and 2011.

The obtained results are completely no satisfactory,

and we need to improve and refine some of the

existing clustering algorithms.

The ISI database that is used in this analysis

contains all publication in Science and Social

Science Citation Indexes, in which at least one

Mexican researcher participates. The data was

produced by Thomson Reuters in April, 2012.

In the second section of this paper we present the

related work and give more detail about our

exploring directions. Section 3 presents the

collection we used and the pre-processing steps.

Section 4 briefly describes the clustering algorithms

used and the measures for validating results. Section

5 is dedicated to present the results of the

experiments and their interpretation. We finish

presenting some conclusions and future work.

2 RELATED PAPERS

Without any doubt, the development of the web and

the development of the representation of the textual

documents in numerical format have a lot of effects

in the way to publish, organize, ask for, treat and

save information. Scientific information also is

growing in a significant way. According to (Laakso

and Björk, 2012) the study about the open access

publishing, some 340,000 articles were published

during 2011.

Websites have indexes and offer partial access.

Some are organized by domain, like ACM and

BioMed Central, for example, or by publisher like

ScienceDirect or IEEE, and all of these can provide

references and also complete contents; other type of

web sites collect an important part of references of

scientific publications and have enormous directory

of references. That is the case of ISI Web of Science

or DLP. In this case, any reference is associated with

the link of the source on the web site containing the

whole paper.

The references or complete papers collection has

a specific access for institutions like universities,

research departments of companies or governmental

agencies. A user may be a scientist interested in his

own domain, or a connected or a general domain

like statistics; a user may also be a scientist in

human or social sciences interested in detecting

much more knowledge, or also a governmental user

interested in the quality, the volume, the main

domains or sub-domains that need to be encouraged

or strongly supported.

All these websites contain powerful information

retrieval tools, but the last type user is much more

interested in “synthetically” (aggregate) information

and knowledge. Text mining has an important role to

play into detecting potentially interesting

information and knowledge.

On the other hand, the collections of scientific

publications are often used as experimental

collection to illustrate text mining techniques,

measures and algorithms like (Sebastiani, 2005) and

(Hazewinkel, 2002). Also a large amount of specific

text mining algorithms, pre-treatment processes and

techniques were involved like in (Balys et al., 2010),

(Galindo et al, 2010), (Taheriyan, 2011). Balys and

Rudzkis in (Balys et al., 2010) have suggested a

classifier adapted to scientific papers, their classifier

is based on some probabilistic models in the aim to

choose the positions of the terms to take into account

(the same for all document), these positions are

called projection on a set of indices; the

classification was done inside the classes of applied

mathematics and statistics. In (Galindo et al., 2010)

only the punctuation signs are used to classify inside

huge classes of domains like medicine, engineering,

and social science. Taheriyan (Taheriyan, 2011)

have worked on a text mining technique based on a

construction of a directed graph within scientific

documents.

Sometimes, the scientific articles or research

projects mining process use external semantic

resources like WordNet lexical categories (Gharib et

al., 2010) or specific ontologies (Ma et al., 2012).

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

178

Our choice was to treat all the papers in the large

domain of the computer science extracted from ISI

Web of Science. We have analyzed a three year

window of publications using generic techniques of

data and text mining. Our deliberate choice to work

with a fixed in time collection has induced a finite

set of terms, in opposite with (Hazewinkel, 2002)

which considers the evolution of the set of terms

detecting some probabilistic laws of growing. The

aim of our analysis is to detect some potential

interesting information for research governmental

agencies like ConaCyT (National Council for

Science and Technology in Mexico).

3 DATA PREPROCESSING

We originally extract 1,585 papers with 4,183

different terms of the ISI Database. The maximum

and minimum length of a title was 27 and one

words, respectively.

In order to make the analysis we make a

preprocess that consisted in convert all the words in

lower case, remove some punctuation and stop

words, and extract the root of the words. We review

several times by hand the dictionary and made some

adjustments; trying to put together different patterns

that usually refer to the same concept; see Table 1.

After this process, the terms were reduced to 2,765.

We can interpret a term as important according

to a simple counting of frequencies. The root terms

with highest frequency are “system” (203), “model”

(188), “control” (167), “network” (156), “fuzzy”

(132), “algorithm” (118), “neural” (116), “optim”

(108), “design” (96) and “applic” (89) (see Fig. 1).

We can conclude that there is a lot of work in

systems, modeling, control, networks, fuzzy and

algorithms.

Table 1: Some terms replaced by others.

Pattern Replaced with

3-d, three-dimensional 3d

2-d, two-dimensional 2d

ga, genetic-algorithm, genetic algorithm

neural-network, nn neural network

multi-objective, multiobjective multi objective

real-time real time

agent-based agent based

data set, data-base database

Table 2 shows the high correlation between the

most frequency root terms. This gives us

information about “neural networks”, “fuzzy logic”

and “genetic algorithms”. However the correlations

are very small. Fig. 1 and Table 2 give us an idea

that most of the research work doing in Mexico is

about Artificial Intelligence and much of the titles

are about control or optimization, perhaps with

neural networks and genetic algorithms.

Figure 1: Cloud Word with the 100 most frequently root

terms with a frequency minimum of five.

After the cleaning phase we obtained a

1,585*2,765 matrix. An idea was to do a

dimensionality reduction (DR). In (Sebastiani, 2002)

for a problem of classification the author define a

supervised DR using controlled vocabulary as some

parts of terms inside a sub-domain or the whole

subdomain. We couldn’t use this approach because

we didn’t use any external resource. We have

intended some unsupervised DR eliminating terms

based on the frequency inside the collection and

respecting a threshold. The clusters obtained were

(very often) really different for very closed threshold

values and also some document representations

became empty.

Table 2: Correlation between high frequency root terms.

Root term Higher correlations

System

linear (0.23), suboptim (0.17), central (0.15),

stochast (0.15)

model

transact (0.14), dock (0.14), probabilist (0.13)

Control

bar (0.23), chart (0.23), synthetic-(x) (0.23),

robot (0.22), time (0.22), fuzzi (0.20)

Network

neural (0.62), recur (0.28), social (0.24),

modular (0.22)

Fuzzi

logic (0.49), type (0.36), interv (0.29), infer

(0.24),backlash (0.20), control (0.20)

algorithm

genet (0.36), memetic (0.20), pso (0.19)

neural

network (0.62), recur (0.28), modular (0.24),

decentr (0.21)

Optim

swarm (0.28), particl (0.20), electrostat

(0.19), weld (0.19)

design

suboptim (0.22), analogu (0.21), central

(0.20), infin (0.19)

applic

chao (0.35), moment (0.35), ration (0.35),

adms (0.35), short (0.29)

AnalysisofMexicanResearchProduction-ExploringaScientificalDatabase

179

4 TEXT MINING PROCESS

Clustering is an unsupervised technique used to

group together objects which are “close” to one

another. In this paper we try to group the titles in

several clusters that represent the subareas worked

by Mexican researchers.

Deciding which clustering method to use can be

a complex task. Additionally, determining the

number of clusters that are most appropriate for the

data can be a hard problem. Ideally, resulting

clusters should have good statistical properties and

also give relevant results. Cluster analysis is an

exploratory data analysis tool for organizing

observed data into meaningful clusters, trying to

maximize the similarity of cases within each cluster

and maximizing the dissimilarity between those

clusters.

There are several measures for validating results

of a cluster analysis (Brock et al, 2008). This

validation can be based on the internal properties of

the data or on some external reference. We applied

internal cluster validation and consider connectivity,

Dunn index and silhouette width. Connectivity must

be minimized and the other two maximized. For

validate the cluster analysis we used the R package

clValid (Brock et al, 2011).

The clustering methods were: hierarchical,

kmeans, DIANA, SOM, SOTA, PAM, AGNES and

model. Hierarchical clustering is an agglomerative

clustering algorithm, where clusters are successively

joined together in order of their “closeness”. K-

means is an iterative method which minimizes the

within-class sum of squares for a given number of

clusters. DIANA is a divisive hierarchical algorithm

that starts with all observations in a single cluster,

and successively divides the clusters until each

cluster contains a single observation. SOM (Self-

organizing maps) is an unsupervised learning

technique based on neural networks. SOTA (Self-

organizing tree algorithm) is an unsupervised

network with a divisive hierarchical binary tree

structure. PAM (Partitioning around medoids) is

similar to K-means, but admits the use of other

dissimilarities. AGNES (Agglomerative Nesting) is

a hierarchical clustering method which works

bottom-up, initially each element is a cluster on its

own, and then merges two closest clusters into one,

until there is one remaining cluster which contains

all the elements. In model-based clustering, a

statistical model consisting of a finite mixture of

Gaussian distributions is fit to the data where each

mixture component represents a cluster, and the

mixture components and group membership are

estimated using maximum likelihood (EM

algorithm).

Figure 2: Validation internal measures for all root terms

data.

5 RESULTS

For internal cluster validation we consider from two

to twenty clusters. We remove sparse terms and

form, group A with 19 terms, group B with 45 terms

and group C with 147 with minimum frequency of

48, 32, 16, respectively.

For group A the optimal scores are for

hierarchical with 2 clusters in Connectivity with

2.9290 and Silhouette with 0.1816 and hierarchical

with 19 with 1.0196 for Dunn. So in this particular

case hierarchical clustering with two clusters

performs the best. The Dunn index of 19 represents

that each word is in a cluster.

We used hierarchical clustering (Zhao et al,

2005) with the ward’s minimum variance method,

which denotes the increase in variance when two

clusters are merged. Regrettably almost everything

is in one cluster.

These results suggest that the Mexican Research

in Computer Science community is working in two

main areas.

We repeat the same experiment with group B and

group C. Both results are much similar to the group

A. For group B the optimal scores are for

hierarchical with two clusters in Connectivity with

2.9290 and Silhouette with 0.3077 and hierarchical

with 18 with 0.8914 for Dunn. For group C the

optimal scores are for hierarchical with two clusters

0 200 400 600

Internal validation

Number of Clusters

Connectivity

5555555

2345678910

0.20.40.60.8

Internal validation

Number of Clusters

Dunn

555

2345678910

0.2 0.4 0.6 0.8

Internal validation

Number of Clusters

Silhouette

5555555

666

2345678910

hierarchical

kmeans

diana

som

sota

pam

agnes

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

180

in Connectivity with 2.9290 and Silhouette with

0.4723 and hierarchical with 4 with. 0.8221.

Figure 3: Selection of the EEI like best model.

Figure 4: Cluster plot of the model.

Finally we run the experiment with all the 2765

root terms and the results confirm the three previous.

The optimal scores in this case were hierarchical

with two clusters in connectivity with a score of

2.9290, hierarchical with four clusters in the Dunn

index with a score of 0.8149 and hierarchical with

two clusters in Silhouette with a score of 0.8265 (see

Fig. 2). The best five algorithms rank are,

hierarchical-2 hierarchical-4 hierarchical-2 diana-2

and diana-4. So, we these results the best candidate

is hierarchical with two clusters.

Model based approaches assume several data

models and apply likelihood estimation and Bayes

criteria. We used Mclust() function in the mclust

package of R that selects the optimal model

according to Bayesian Information Criterion (BIC)

(Schwarz, 1978). This function selected the “EEI”

model, where clusters has equal volume and shape

with 7 components. See fig. 3.

The number of titles in each cluster is show in

table 3 and the plot in Fig. 4. From this table we can

observed that cluster number 2 has more than the

half of all the titles.

The model based approach has more clusters, so

it seems to be more appropriate this division in order

to try to find some tendency or classification in the

research work.

One last calculi we done were about the most

appropriate model to our collection and the ideal

number of clusters. We have supposed that our

collection is a mixture of the same model for all the

clusters, every cluster having the same model class

(implicitly the same shape) and various parameters.

In base of the works of (Fraley and al, 2007) and

Fraley et al, 2002) and using the package mclust of

R, we have obtained that the BIC values (a measure

of the fitness of the model) are best only for 2 or 3

clusters in the hypothesis of model of type EEI and

also for each k number of clusters between 2 and 40

a model of type EII (more restricted and each matrix

is the matrix of eigenvalues). See figure 5 to

illustrate this. In conclusion, the number of clusters

is between two and four.

Table 3: Clustering table.

Cluster 1 2 3 4 5 6 7

Numberof

Elements

71 894 119 172 95 110 127

Figure 5: Variation of BIC value upon the numbers of

clusters and the most fit models.

6 CONCLUSIONS AND

PERSPECTIVE

Deeping our understanding of the state of art of the

Mexican research in Computer could be can be

worthwhile in order to identify the gap of knowledge

among Mexican researcher and for government

agencies to support or not research and funding in

some areas and for students and new researchers

because they can consider work or not in a subarea.

In order to know where Mexican researchers are

working in we analyze different clustering algorithm

in order to regroup the titles of the indexed papers

during 2009, 2010 and 2011.

The highest frequent results give us only few

information, for example we can’t know what area

of networks are working in, computer networks,

neural networks or social networks. High correlation

results show that most of the papers of Mexican

researchers in Computer Science are related with

neural networks, fuzzy logic and genetic algorithms

and there is also a significant amount of work in

control and optimization systems.

2468

0 5000 10000 15000

Number of components

BIC

EII

VII

EEI

VEI

EVI

VVI

EEE

EEV

VEV

VVV

AnalysisofMexicanResearchProduction-ExploringaScientificalDatabase

181

We analyse different algorithms with different

number of clusters, terms and internal properties and

the results shows that the most appropriate number

of clusters is between two and four. However this

number of clusters (areas) is very small compared

with ACM or Microsoft. Analyzing the titles in these

clusters, the papers of the collection can be grouped

in Artificial Intelligence and Modeling Systems, but

this conclusion requires some human analysis, so we

need apply some contextual information to produce

computer science meaningful clusters.

It is needed to do more experiments in order to

try to select one or a few clustering algorithms that

automatically classify the titles of scientific papers.

As a future work we are going to apply these

algorithms to the keywords and abstracts of the

papers in order to compare the results obtained.

Also we are planning consider the membership

of several areas, two or three. This is natural because

computer science is an interdisciplinary science and

there is a lot trying to resolve problem of other areas.

We also think that would be interesting to work in a

window time of two or five year in order to analyse

the evolution of the research in one country as with

several ones.

Our approach is also applicable for any scientific

field.

REFERENCES

ACM (2012). Retrieved January 8, 2013, from

dl.acm.org/ccs.cfm.

Vaidas Balys, Rimantas Rudzkis (2010) Statistical

Classification of Scientific Publications, Informatica,

Volume 21, Issue 4, pp 471 – 486.

Guy Brock, Vasyl Pihur, Susmita Datta and Somnath

Datta (2008). clValid: An R Package for Cluster

Validation, Journal of Statistical Software. March

2008, Volume 25, Issue 4. http://www.jstatsoft.org.

Guy Brock, Vasyl Pihur, Susmita Datta and Somnath

Datta (2011). clValid: Validation of Clustering

Results. R package version 0.6-4. http://CRAN.R-

project.org/package=clValid.

G. Csardi, T Nepusz (2006). The igraph software package

for complex network research, InterJournal, Complex

Systems 1695. 2006. http://igraph.sf.net.

Ingo Feinerer, Kurt Hornik, and David Meyer (2008). Text

Mining Infrastructure in R. Journal of Statistical

Software 25(5): 1-54. URL: http://www.jstatsoft.org/

v25/i05/.

Ingo Feinerer and Kurt Hornik (2013). tm: Text Mining

Package. R package version 0.5-8.3. http://CRAN.R-

project.org/package=tm.

Ian Fellows (2012). wordcloud: Word Clouds. R package

ver2.2 http://CRAN.R-project.org/package=wordcloud

C. Fraley, A. E. Raftery (2007). Bayesian regularization

for normal mixture estimation and model-based

clustering. Journal of Classification, Vol. 24, Issue2,

pp. 155-181.

C. Fraley, A. E. Raftery (2002). Model-based clustering,

discriminant analysis and density estimation. Journal

of the American Statistical Association, Vol. 97, pages

611-631.

Cristal-Karina Galindo Duran, Mihaela Juganaru-Mathieu,

Carlos Aviles Cruz, Héctor Javier Vazquez (2010).

Desarrollo de una aplicación destinada a la

clasificación de información textual y su evaluación

por simulación, Administración y Organizaciones

25:13, pages 119-131.

Tarek Gharib, Mohammed Fouad, Mostafa Aref (2010)

Fuzzy Document Clustering Approach using WordNet

Lexical Categories. In Advanced Techniques in

Computing Sciences and Software Engineering,

Khaled Elleithy (editor), Springer, pp 181-186.

Michiel Hazewinkel (2005) Dynamic Stochastic Models

for Indexes and Thesauri, Identification Clouds, and

Information Retrieval and Storage, In Recent

Advances in Applied Probability, Ricardo Baeza-Yates

et al (editors), Springer US, 2005, pp 181-204.

Mikael Laakso, Bo-Christer Björk (2012). Anatomy of

open access publishing: a study of longitudinal

development and internal structure, BMC Medicine,

10:124, pp 1-9.

Jian Ma; Wei Xu; Yong-hong Sun; Turban, E.; Shouyang

Wang; Ou Liu (2012) "An Ontology-Based Text-

Mining Method to Cluster Proposals for Research

Project Selection," Systems, Man and Cybernetics,

Part A: Systems and Humans, IEEE Transactions on ,

vol.42, no.3, pp 784-790.

M. Maechler, P Rousseeuw, A. Struyf, M. Hubert, K.

Hornik, (2012). cluster: Cluster Analysis Basics and

Extensions. R package version 1.14.3.

Microsoft Academic Search (2012). Retrieved January 22,

2013, from academic.research.microsoft.com.

R. Core Team (2013). R: A language and environment for

statistical computing.

R Foundation for Statistical

Computing, Vienna, Austria. ISBN 3-900051-07-0,

URL htttp://www.R-project.org/.

G. Schwarz (1978). Estimating the dimension of a model.

The Annals of Statistics, 6:461-464, 1978.

Fabrizio Sebastiani (2002) Machine learning in automated

text categorization, Journal ACM Computing Surveys,

Volume 34 Issue 1, pages 1 – 47.

Mohsen Taheriyan (2011) Subject classification of

research papers based on interrelationships analysis. In

Proceedings of the 2011 Workshop on Knowledge

Discovery, Modeling and Simulation (San Diego,

California, USA, August 2011). KDMS '11. ACM,

New York, NY, pages 39-44.

H. Wickham (2009) ggplot2: elegant graphics for data

analysis. Springer New York.

Ying Zhao, George Karypis, Usama Flayyad (2005),

Hierarchical Clustering Algorithms for Document

Datasets, Data Mining and Knowledge Discovery,

Volume 10, Issue 2, March 2005, pages 141-168.

KDIR2013-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

182
