Improving a Fuzzy Discretization Process by Bagging

Jos

e Manuel Cadenas, Mar

ıa del Carmen Garrido and Raquel Mart

ınez

Dpt. Information Engineering and Communications, Computer Faculty, University of Murcia

30100-Campus of Espinardo, Murcia, Spain

Keywords:

Crisp/Fuzzy Discretization, Bagging, Numerical Attributes, Data Mining.

Abstract:

Classiﬁcation problems in which the number of attributes is larger than the number of examples are increas-

ingly common with rapid technological advances in data collection. Also numerical data are predominant in

real world applications and many algorithms in supervised learning are restricted to discrete attributes. Focus-

ing on these issues, we proposed an improvement in a fuzzy discretization method by means of the introduction

of a bagging process in the different phases of the method. The bagging process tries to solve problems which

can appear with small size datasets. Also we show the beneﬁts that bagging introduces in the method by means

of several experiments. The experiments have been validated by means of statistical tests.

1 INTRODUCTION

Successful decision-making, whether done by an in-

dividual or as a group relies on the presence of

many ingredients. Availability and quality of infor-

mation is an essential element of successful decisions,

(O’Reilly, 1982). On the one hand, with the advent of

key information technologies in recent decades, deci-

sion makers now have access to vast amount of his-

torical data. In this case, the information available

could be enough depending on its quality. On the

other hand, due to the highly competitive global mar-

ket, companies must meet the customer increasing de-

mands to rapidly and continually improve the stan-

dard of their products and services. In the real world,

there are many situations where organizations have to

work with small datasets. For instance, with the pi-

lot production of a new product in the early stages of

a system, dealing with a small number of VIP cus-

tomers, and some special cancers, such as bladder

cancer for which there are only a few medical records,

(Der-Chiang and Chiao-Wen, 2012).

The extraction of valuable information from these

small data sources requires purposeful application of

rigorous analysis techniques such as data mining, ma-

chine learning, and other statistical learning tech-

niques, (Unler and Murat, 2010).

Data mining methods are often employed to un-

derstand the patterns present in the data and derive

predictive models with the purpose of predicting fu-

ture behavior. While data mining encompasses a wide

range of data processing and manipulation steps (for-

matting, ﬁltering, visualization,...), machine learning

algorithms are central to the data mining process. Ma-

chine learning algorithms are a collection of meth-

ods that are capable of learning to optimize a per-

formance criterion using example data or past expe-

rience. The classiﬁcation problem, as a form of su-

pervised machine learning, aims to induce a model

with the purpose of predicting categorical class labels

for new samples given a training set of samples each

with a class label. Classiﬁcation has found applica-

tions in various domains such as credit approval in

ﬁnancial services, target marketing in retailing, med-

ical diagnosis in healthcare, and treatment effective-

ness analysis in healthcare. A typical implementa-

tion of the classiﬁcation problem involves selecting

a training dataset with class labels, developing an ac-

curate description or a model for each class using the

attributes available in the data, and then evaluating the

prediction quality of the induced model.

This paper will focus on supervised classiﬁcation

and models which have been obtained from datasets

with few examples in relation with the number of at-

tributes. From the computational learning viewpoint,

these datasets are very important in machine learning

problems, because the information contained can be

more difﬁcult to extract. For instance, with a classi-

ﬁer, it is hard to make accurate predictions because

these datasets do not only make the modeling pro-

cedure prone to overﬁtting, but also cause problems

in predicting speciﬁc correlations between the inputs

201

Manuel Cadenas J., del Carmen Garrido M. and Martínez R..

Improving a Fuzzy Discretization Process by Bagging.

DOI: 10.5220/0004553402010212

In Proceedings of the 5th International Joint Conference on Computational Intelligence (FCTA-2013), pages 201-212

ISBN: 978-989-8565-77-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

and outputs, (Der-Chiang and Chiao-Wen, 2012). For

that reasons, this paper focus on these kind of datasets

because all of the commonly used classiﬁers can suf-

fer from the curse of dimensionality.

While an exact relationship between the probabil-

ity of misclassiﬁcation, the number of training exam-

ples, the number of attributes and the true parame-

ters of the class-conditional densities is very difﬁcult

to establish, some guidelines have been suggested re-

garding the ratio of the sample size to dimensionality,

(Jain, 2000).

As a general rule, a minimum number of 10 ·

|A| · |C| training examples is required for a |A|-

dimensionality classiﬁcation problem of |C| classes,

(Jain, 2000). Following this rule, when datasets have

few examples (hereafter called small size datasets),

we should take into account in the learning algorithm

some measure in order to build better models to get

good accuracy in classiﬁcation.

In this paper we focus on discretization of numer-

ical attributes in small size datasets. The discretiza-

tion of numerical attributes is a crucial step in ma-

chine learning problems since there are classiﬁers that

cannot deal with numerical attributes, and there are

other classiﬁers that exhibit better performance when

these attributes are discretized, since discretization re-

duces the number of numerical attribute values, en-

abling faster and more accurate learning (Antonelli

et al., 2011).

More speciﬁcally we propose the introduction of

a measure in the discretization method presented in

(Cadenas et al., 2012b), OFP CLASS, that allows it

to get good accuracy in classiﬁcation when it deals

with small size datasets. This measure is based on the

use of bagging in order to improve the stability and

accuracy of the discretization process. Bagging is a

special case of the model averaging approach. We

have called the resulting method BAGOFP CLASS.

This paper is organized as follows. First, in Sec-

tion 2, we describe some of the different methods re-

ported in literature to discretize numerical attributes

highlighting the fulﬁlling degree of the rule. Next,

in Section 3, we describe the BAGOFP CLASS dis-

cretization method. Then, in Section 4, we present

some experimental results illustrating the perfor-

mance of BAGOFP CLASS method. Finally, in Sec-

tion 5 remarks and conclusions are presented.

2 RELATED WORKS

There are some classiﬁcation algorithms which can

only take nominal data as inputs and some of them

need to discretize numerical data into nominal data

before the learning process. Therefore, discretization

is needed as a pre-processing step to partition each

numerical attribute into a ﬁnite set of adjacent dis-

tinct intervals/items. A good discretization algorithm

should not only characterize the original data to pro-

duce a concise summarization, but also help the clas-

siﬁcation performance (Zhu et al., 2011).

Discretization algorithms can be categorized from

different viewpoints depending on the measure that is

being focused on. If the class label is used to build

partitions, the discretization methods can be catego-

rized into two ways, namely unsupervised and su-

pervised. With the focus on the kind of logic, dis-

cretization algorithms can be categorized into fuzzy

discretization and crisp discretization. On the one

hand, when the fuzzy logic is used, we can create

fuzzy partitions where a value can belong to more

than one partition. On the other hand, when the clas-

sical logic is used, we create crisp partitions where a

value can only belong to one partition. Furthermore,

discretization methods can be classiﬁed taking into

account the kind of measure that it is used or the way

that the partitions are created.

In this section, we focus on how several discretiza-

tion methods consider the management of small size

datasets explicitly. From this viewpoint, there are

methods that build partitions taking into account the

possible problems that datasets with few examples

can induce in the discretization process and later in

loss of accuracy.

However, there are methods which are not speciﬁc

for small size datasets but get good precision for this

kind of datasets.

For instance, in (Armengol and Garc

ıa-Cerdana,

2012) a method, called ε-procedure, that constructs

crisp partitions on the range of an attribute taking nu-

merical values is proposed. These partitions can be

seen as reﬁnements of the ones given by the expert

or the ones given by a standard discretization method.

Moreover, the method can be seen as “similar” to the

fuzzy discretization methods since the ε-procedure

takes into account the neighborhood of the thresholds

given by the crisp discretization methods.

Another method that does not specify anything

about managing small size datasets is proposed in

(Zhu et al., 2011), where a novel and effective su-

pervised discretization algorithm based on correlation

maximization is proposed by using multiple corre-

spondence analysis. For each numerical attribute, the

candidate cut point that maximizes the correlation be-

tween attribute intervals and classes is selected as the

ﬁrst cut point, then this strategy is carried out in the

left and right intervals recursively to further partition

the intervals.

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

202

As a last instance for discretization methods

which do not consider small size datasets, in (Wang

et al., 2012) the discretization quality is improved by

increasing the certainty degree of a decision table in

terms of deterministic attribute relationship, which is

revealed by the positive domain ratio in rough set the-

ory. Furthermore, they take into account both the

decrement of uncertainty level and increment of cer-

tainty degree to induce a Coupled Discretization al-

gorithm. This algorithm selects the best cut point ac-

cording to the importance function composed of the

information entropy and positive domain ratio in each

run. The algorithm builds crisp partitions because it

is focused on classical logic.

In contrast to the methods which do not consider

the problems of small size datasets, in literature there

are some methods that explicitly work with this kind

of datasets.

So, in (Qureshi and Zighed, 2009) a novel soft de-

cision tree method that uses soft of fuzzy discretiza-

tion instead of traditional crisp cuts is proposed. They

take into account the dataset size and use a resampling

based technique to generate soft discretization points.

They use a fuzzy decision tree and an ordinary boot-

strap as a method for resampling. Bootstrap allows

them to get global partitions and a better estimation

toward the entire population.

In (Der-Chiang et al., 2012), a trend-diffusion

and tree-structure based approach, which is called a

tree structure based trend diffusion (TTD) procedure,

speciﬁcally designed for small datasets in manufac-

turing problems has been proposed. In the ﬁrst phase

of the proposed procedure, TTD is employed to es-

timate the possible value bounds, and then uses a

heuristic mechanism to ﬁll values within the bounds

to form a new training set. In the second phase,

the M5’ model tree is adopted (Wang and Witten,

1997) as the modeling tool to concretely represent the

knowledge. In this second phase it is necessary to

discretize data for the tree. The discretization process

should be repeated whenever each branching process

of M5’ begins. This repetition is a special treatment

to deal with small datasets. In this case, the method

works with small datasets (microarrays), although,

they do not apply the technique for small datasets ex-

plicitly.

Typical datasets which have few examples are the

microarrays datasets. In (Kianmehr et al., 2010) this

kind of data is used. That paper presents a novel clas-

siﬁcation approach that integrates fuzzy class associa-

tion rules and support vector machines. Also, a fuzzy

discretization technique based on fuzzy c-means clus-

tering algorithm is employed to transform the training

set, particularly quantitative attributes, to a format ap-

propriate for association rule mining. A hill-climbing

procedure is adapted for automatic thresholds adjust-

ment and fuzzy class association rules are mined ac-

cordingly. The compatibility between the generated

rules and fuzzy patterns is considered to construct a

set of attribute vectors, which are used to generate a

classiﬁer.

Another paper which deal with biology issue (mi-

croarray time series datasets) is presented in (Dim-

itrova and Vera-Licona, 2010). In that paper a new

algorithm, called SSD, is introduced. SSD is espe-

cially designed for short time series data and is capa-

ble of determining the optimal number of discretiza-

tion states. An important characteristic of such time

series is the relatively small number of data points

(typically no more than ten). A graph-theoretic clus-

tering method is employed to perform the discretiza-

tion and an information-theoretic technique to mini-

mize loss of information content. One of the most

useful characteristic of that method is the determina-

tion of an optimal number of discrete states that is

most appropriate for the data.

It is notable that some of the above methods

use some kind of repetitions to manage small size

datasets. This approach is also used in other types

of machine learning algorithms to manage small size

datasets such as in (Liu et al., 2004) to attribute selec-

tion or in (Zararsiz et al., 2012) to classify. Following

this line, a bagging method is used, in order to emu-

late the repetitions that others methods use.

Bagging was proposed by Breiman in (Breiman,

1996a), and is based on bootstrapping and aggregat-

ing concepts, so it incorporates the beneﬁts of both

approaches. Bagging uses the same training set mul-

tiple times, and has been shown to outperform a sin-

gle classiﬁer trained from the training set (Breiman,

1996a).

In bagging, the training set is randomly sampled

k times with replacement, producing k training sets

with sizes equal to the original training set. Since the

original set is sampled with replacement, some train-

ing instances are repeated in the new training sets,

and some are not present at all. Bagging has several

advantages. First, because different classiﬁers make

different errors, combining multiple classiﬁers gener-

ally leads to superior performance when compared to

a single classiﬁer, and thus it is more noise tolerant.

Second, bagging can be computationally efﬁcient in

training because it can be implemented in a parallel

or distributed way. Finally, bagging is able to main-

tain the class distribution of the training set.

In the next section, we are going to describe the

BAGOFP CLASS method which also obtains good

results when discretizing numerical attributes of small

ImprovingaFuzzyDiscretizationProcessbyBagging

203

size datasets.

3 BAGOFP CLASS:

DISCRETIZING BY BAGGING

In this section we are going to present the

BAGOFP CLASS method so that this method gets

better fuzzy partition than OFP CLASS method (Ca-

denas et al., 2012b) when it works with datasets which

do not verify the rule commented in Section 1. This

rule states that datasets should have more examples

than 10 ·|A|·|C|, where |A| is the number of attributes

that describe each example and |C| is the number of

different values of the class attribute.

Following the methodology of OFP CLASS (Ca-

denas et al., 2012b), BAGOFP CLASS is composed

of two phases. The former uses a fuzzy decision tree

in order to ﬁnd possible cut points to create the par-

titions. The latter takes as input the cut points of the

ﬁrst phase to optimize and to build the ﬁnal fuzzy par-

titions by means of a genetic algorithm. It should be

noted that if the second phase is not carry out, with

the cut points it could be possible to construct inter-

vals and crisp partitions would be obtained for the at-

tributes instead of fuzzy partitions.

The use of bagging in OFP CLASS method is mo-

tivated by the fact that bagging can give substantial

gains in accuracy when the classiﬁcation method used

is unstable. If perturbing the learning set can cause

signiﬁcant changes in the classiﬁer constructed, the

bagging can improve accuracy (Breiman, 1996a). In-

stability was studied in (Breiman, 1996b) where it

was pointed out that neural nets, classiﬁcation and re-

gression trees, and subset selection in linear regres-

sion were unstable. The result, both experimental and

theoretical, is that bagging can push a good but unsta-

ble procedure a signiﬁcant step towards optimality.

In addition, instability of decision trees can be in-

creased by using small size datasets because in a de-

cision tree when a node is split, the attribute with

higher information gain is selected. When the num-

ber of examples is small relative to the number of

the attributes, the probability that redundant attributes

exist is increased. In this way, there will be several

attributes that have the same information gain and

the selection of one of them is random. With a cer-

tain probability, the unselected attributes are not par-

titioned and, therefore, these attributes might not be

part of the ﬁnal partition generated by the decision

tree. When a bagging process is introduced, the prob-

ability that these attributes can be part of the ﬁnal par-

tition is increased. In this situation, the method will

work with different bagging of the dataset. By re-

peating the process, the selection of other attributes is

allowed.

Therefore, since the ﬁrst phase of the algorithm

is based on decision trees, can be improved with the

use of bagging obtaining a better partitioning from

the set of decision trees generated and enabling that

a greater number of attributes to be part of the parti-

tion when the information gain of various attributes

is the same. The second phase of the algorithm is re-

sponsible for selecting the most relevant attributes for

classiﬁcation.

On the other hand, the genetic algorithm in the

second phase of the OFP CLASS method, uses a ﬁt-

ness function which tries to ﬁnd the best set of parti-

tions to divide the examples with respect to the class

attribute. Again, the second phase of OFP CLASS

method can be improved with a bagging process with

the motivation of reducing variability in the partition-

ing results via averaging. The ﬁtness function is mod-

iﬁed in order to obtain a better value for those par-

titions (individuals) with better average performance

when we using a bagging of the dataset. Also with

bagging the genetic algorithm studies different region

of the searching space and it can get more global

fuzzy partitions.

Therefore, we will introduce a bagging process

into the two phases of BAGOFP CLASS method: 1)

in the construction of the decision tree which gen-

erates the cut points of the ﬁrst phase, and 2) in the

ﬁtness function that will be used in the genetic algo-

rithm of the second phase.

The fuzzy partitions created with

BAGOFP CLASS have the same characteristics

as the fuzzy partitions created with the OFP CLASS

method. This means that the domain of each numer-

ical attribute is partitioned in trapezoidal fuzzy sets

and the partitions are:

• Completeness (no point in the domain is outside

the fuzzy partition), and

• Strong (it veriﬁes that ∀x ∈ Ω

∑

f =1

(x) = 1

where B

,..,B

are the F

fuzzy sets for the par-

tition of the i numerical attribute with Ω

domain

and µ

(x) are its functions membership).

The domain of each i numerical attribute is parti-

tioned in trapezoidal fuzzy sets and the membership

functions B

..,B

are calculated in the following

way:

(x) =







1 b

≤ x ≤ b

−x)

−b

)

≤ x ≤ b

0 b

≤ x

;

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

204

(x) =











0 x ≤ b

(x−b

)

−b

)

≤ x ≤ b

1 b

≤ x ≤ b

−x)

−b

)

≤ x ≤ b

0 b

≤ x

;

·· ·;

(x) =











0 x ≤ b

−1)3

(x−b

−1)3

)

−1)4

−b

−1)3

)

−1)3

≤ x ≤ b

−1)4

1 b

≤ x

In the next subsection, we are going to detail

the two phases of the BAGOFP CLASS method

and we are going to highlight the more important

changes regarding the OFP CLASS method. Figure

1 shows, in an illustrative way, the whole process of

BAGOFP CLASS method.

cut points

of attributes

selection

crossing

mutation

Bagging d

·······

Bagging 3

Bagging 2

FIRST PHASE SECOND PHASE

FDTs

Bagging 1

Initial

Dataset

Fuzzy partition

of attributes

Initial

Dataset

Bagging b

·······

Bagging 3

Bagging 2

Bagging 1

Fitness

function

Figure 1: BAGOFP CLASS method.

3.1 First Phase: Cut Points

The ﬁrst phase of BAGOFP CLASS uses a fuzzy

decision tree as base method to search the possible

cut points to build the fuzzy partitions, but unlike of

OFP CLASS method, the input dataset to this fuzzy

decision tree is each dataset obtained by performing a

bagging process over the original dataset.

The kind of values, with which this fuzzy decision

tree can work, are nominal attributes, numerical dis-

cretized attributes by means of a fuzzy partition, non-

discretized numerical attributes described with crisp

values, interval and fuzzy values and furthermore it

allows the existence of missing values in all of them.

The fuzzy decision tree behavior changes depending

on the kind of attribute that is analyzed by the tree in

order to ﬁnd the best of them to divide a node.

On the one hand, when the attribute is numerical

and does not have partitions available, the process to

follow is similar to the decision tree C4.5 process.

The thresholds selected in each node of the tree for

these attributes will be the cut points that delimit the

intervals. On the other hand, for the other kind of

attributes, the methodology followed is the same as

the fuzzy decision tree presented in (Cadenas et al.,

2012b). During the rest of the process the method be-

havior is the same for both discretize attributes and

non-discretized attributes. The procedure of building

the fuzzy decision tree has a priority tail which is used

to arrange tree nodes depending on the number of ex-

amples each one has. The reason for incorporating

the priority tail is that the nodes with more examples

are analized ﬁrst because these nodes will have more

information than those with less examples.

Comparing the new method with the OFP CLASS

method, the main difference between them is that for

datasets which do not have 10 · |A| · |C| training ex-

amples, the cut points obtained by OFP CLASS are

not rich enough in information to provide a good par-

tition, because these cut points are too speciﬁc and

partitions obtained are not global. In order to pre-

vent getting cut points so speciﬁc and more attributed

can be discretized, the input to the fuzzy decision tree

in BAGOFP CLASS is a bagging obtained from the

whole dataset.

It must be remembered that in the bagging pro-

cess, it is possible that a cut point may appear several

times. In this case the cut point will be included once.

Algorithm 1 describes all the process to get all

possible cut points.

All the cut points obtained after the ﬁrst phase are

introduced as input in the second phase in order to

build optimal fuzzy partitions.

3.2 Second Phase: Building Fuzzy

Partitions

In the second phase of the method, we are going to

use a genetic algorithm to get the fuzzy sets that make

up the partitioning of non-discretized attributes. We

have decided to use a genetic algorithm, because these

algorithms are very powerful and robust, as in most

cases they can successfully deal with an inﬁnity of

problems from very diverse areas and speciﬁcally in

Data Mining. These algorithms are normally used in

problems without specialized techniques or even in

those problems where a technique does exist, but is

combined with a genetic algorithm to obtain hybrid

algorithms that improve results (Cox, 2005).

In this section we brieﬂy describe the several

elements which compose the algorithm. We focus

on those that characterizing the BAGOFP CLASS

method. For remaining elements originating from the

OFP CLASS method a more detailed description can

be found in (Cadenas et al., 2012b).

ImprovingaFuzzyDiscretizationProcessbyBagging

205

Algorithm 1: Getting Cut points.

FindingCutPoints(in : E; out : Cut points)

begin

• Initialize the set of cut points to each numerical

attribute k to empty: CPS

• Initialize bagging size δ.

• For j=1 to δ

1. Obtain the dataset BA

consisting of |E| ex-

amples selected from E randomly and with re-

placement.

2. Obtain a fuzzy decision tree from BA

– Start at the root node, which is placed in the

initially empty priority tail. Initially, in the

root node the set of examples BA

with an ini-

tial weight are found.

– Extract the ﬁrst node from the priority tail.

– Select the best attribute to split this node using

information gain, which is explained in detail

in (Cadenas et al., 2012b), as the criterion.

– Having selected the attribute to expand node,

all the descendants generated are introduced

in the tail. If the selected attribute is nomi-

nal, a descendant is generated to each possible

value of that attribute. If the selected attribute

(SA) is numerical it is necessary to obtain the

corresponding cut point and two descendants

are generated. In this case, CPS

is updated

as follows:

CPS

= CPS

∪

{cut point}

– Go back to step two to continue constructing

the tree until no nodes remain in the priority

tail or until another stopping condition occurs,

such as reaching nodes with a minimum num-

ber of examples allowed by the algorithm.

• Return CPS

sets for each numerical attribute k.

end

The genetic algorithm takes as input the cut points

which have been obtained in the ﬁrst phase, but it is

important to mention that the genetic algorithm will

decide what cut points are more important to con-

struct the fuzzy partitions, so it is possible that many

cut points are not used to obtain the optimal fuzzy

partitions. If the ﬁrst phase gets F cut points for the

attribute i, the genetic algorithm can make up F

+ 1

fuzzy partitions for the attribute i at the most. How-

ever, if the genetic algorithm considers that the at-

tribute i will not have a lot of relevance in the dataset,

this attribute will not be partitioned.

The different elements which compose this ge-

netic algorithm are as follows:

Encoding. An individual has a real coding and its

size will be the sum of the number of cut points that

the fuzzy decision tree will have provided for each

attribute in the ﬁrst phase. Each gene represents the

quantity to be added to and subtracted from each at-

tribute’s split point to form the fuzzy partition. Also,

each gene is associated with a boolean value which in-

dicates whether this gene or cut point has to be taken

into account or not, in other words, if this gene or

cut point is active or not. We must consider that if a

gene is not active the domain of the adjacent gene can

change. The domain of each gene is an interval de-

ﬁned by [0,min(

−p

r−1

r+1

−p

)] where p

is the r-th

cut point of attribute i represented by this gene except

in the ﬁrst (p

) and last (p

) cut point of each attribute

whose domains are, respectively:

[

min

(

−p

]

and [0, min(

−p

u−1

,1 − p

When F

= 2, the domain of the single cut point is

deﬁned by [0,min(p

,1 − p

Initialization. Firstly, it is determined if each gene

is active or not. We must consider that at least one

gene from each individual must be active because if

all genes were inactive, any attribute would be dis-

cretized. Once the boolean value of each gene of the

individual has been initialized, the domain of each

gene is calculated, considering which cut points are

active and which are not. After calculating the do-

main of each gene, each gene is randomly initialized

generating a value within its domain.

Fitness Function. The ﬁtness function of each indi-

vidual is deﬁned according to the information gain de-

ﬁned in (Au et al., 2006). In this case, in the same way

as in the ﬁrst phase of the method BAGOFP CLASS,

to calculate the ﬁtness for each individual a bagging

process is applied. In this case, the ﬁtness of the in-

dividual is an average ﬁtness using different bagging

of the input dataset. In this way, the algorithm obtains

a more robust ﬁtness for each individual because the

average ﬁtness gives a more general vision over dif-

ferent data subsets and is a more reliable measure. Al-

gorithm 2 implements the ﬁtness function.

In the algorithm µ

i f

(·) is the membership func-

tion corresponding to fuzzy set f of attribute i. This

ﬁtness function, based on the information gain, indi-

cates how dependent the attributes are with regard to

class, i.e., how discriminatory each attribute’s parti-

tions are. If the ﬁtness obtained for each individual

is close to zero, it indicates that the attributes are to-

tally independent of the classes, which means that the

fuzzy sets obtained do not discriminate classes. On

the other hand, as the ﬁtness value moves further away

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

206

from zero, it indicates that the partitions obtained are

more than acceptable and may discriminate classes

with good accuracy.

Algorithm 2: Fitness Function.

Fitness(in : E, out : FinalFitness)

begin

• Initialize bagging size β

• Initialize ValueFitness = 0

• For j=1 to β

1. Obtain the dataset BA

consisting of |E| ex-

amples selected from E randomly and with re-

placement.

2. For each attribute i = 1, ...,|A|:

2.1 For each set f = 1, ...,F

of attribute i

For each class k = 1,...,|C| calculate the prob-

ability

i f k

∑

e∈BA

i f

(e)

∑

e∈BA

i f

(e)

2.2 For each class k = 1,...,|C| calculate the prob-

ability P

∑

f =1

i f k

2.3 For each f = 1, ...,F

calculate the probability

i f

∑

|C|

k=1

i f k

2.4 For each f = 1,...,F

calculate the information

gain of attribute i and set f

i f

|C|

∑

k=1

i f k

· log

i f k

· P

i f

2.5 For each f = 1, ...,F

calculate the entropy

i f

= −

|C|

∑

k=1

i f k

· log

i f k

2.6 Calculate the I and H total of attribute i

∑

f =1

i f

and H

∑

f =1

i f

3. Calculate the ﬁtness as :

ValueFitness = ValueFitness +

∑

|A|

i=1

∑

|A|

i=1

• FinalFitness = ValueFitness/β

• Return FinalFitness

end

Selection. Individual selection is by means of tourna-

ment, taking subsets with size 2. It must be taken into

account that the best individual is always selected due

to the elitism that the method carries out.

Crossover. The crossover operator is applied with a

certain probability, crossing two individuals through

a single point, which may be any one of the positions

on the vector. Not all crossings are valid, since one

of the restrictions imposed on an individual is that the

individual must not have all its genes inactive. When

crossing two individuals and this situation occurs, the

crossing is invalid, and individuals remain in the pop-

ulation without interbreeding. If the crossing is valid,

the domain for each gene is updated in the individuals

generated. As in selection, the method applies elitism

in this operator, so the best individual is not crossed.

Mutation. Mutation is carried out according to a cer-

tain probability at interval [0.01,0.2].

Since each gene has a boolean associated value

which indicates whether the gene is active or not and

the gene value represents the amount to add and sub-

tract the cut point, the mutation operator is hybrid. In

BAGOFP CLASS method when a gene has to mutate

by chance, there are two options:

1. to activate or deactivate the gene and

2. to modify the amount to add and subtract to the

cut point.

The ﬁrst option allows us to explore new search

spaces. When the second option is applied the slopes

of the partition are modiﬁed. This last option is in-

cluded in the method in order to adjust the slopes as

much as possible and in this way to get better accu-

racy.

The method applies the ﬁrst option 50% of the

time and the second option 50% of the time.

When a gene is activated or deactivated, ﬁrst, the

boolean value associated to the gene is modiﬁed and

then a check is made to make sure there are still active

genes. If there are still active genes, their domains and

the domains of adjacent genes must be updated. If

all the individual genes are deactivated, the mutation

process is not performed.

When the mutation have to modify the value to

add and subtract, a randomly calculated value within

its domain is generated.

Stopping. The stopping condition is determined by

the number of generations.

The genetic algorithm should ﬁnd the best possi-

ble solution in order to achieve a more efﬁcient clas-

siﬁcation.

In the next section we show some computational

experiments where we are going to compare us-

ing several datasets the accuracy in classiﬁcation

of discretizing with OFP CLASS method and with

BAGOFP CLASS method. In these experiments, we

can see that the behavior of the BAGOFP CLASS

ImprovingaFuzzyDiscretizationProcessbyBagging

207

method with datasets with a few examples is better

than the previous method.

4 EXPERIMENTS

This section shows the details of the experimental

framework. We present the datasets employed and

we describe the experimental setup, the performance

measure and the statistical test employed to analyze

the results. Finally, we present and analyze the results

obtained.

4.1 The Datasets and the Experimental

Setup

The proposed approach is going to evaluate by means

of experiments on various datasets selected from UCI

machine learning repository (Frank and Asuncion,

2010). In addition, three high dimensional datasets

(ADE, PRO, SRB) available in (Diaz-Uriarte and

de Andr

es, 2006) have been added. These datasets

used to test the proposed approach are summarized in

Table 1.

Table 1: Datasets.

Dataset Abbr |E| |A| |C| rule

Australian credit AUS 690 14 2 YES

Breast Cancer W. BCW 699 9 2 YES

Statlog Heart HEA 270 13 2 YES

Iris Plant IRP 150 4 3 YES

Vehicle VEH 946 18 4 YES

Adenocarcinoma ADE 76 9868 2 NO

Apendicitis APE 106 7 2 NO

Glass GLA 214 9 7 NO

Ionosphere ION 351 34 2 NO

Prostate PRO 102 6033 2 NO

Sonar SON 208 60 2 NO

SPECTF SPE 267 44 2 NO

Srbct SRB 63 2308 4 NO

Wis. D. Breast C. WDB 569 31 2 NO

Wine WIN 178 13 3 NO

Table 1 shows the number of examples (|E|), the num-

ber of attributes (|A|) and the number of classes (|C|)

for each dataset. All the various dataset attributes are

numerical except AUS dataset having six numerical

attributes and eight nominal attributes. In addition,

the last column “rule” of the Table 1 shows whether

the dataset veriﬁes the condition |E| ≥ 10 · |A| · |C|.

“Abbr” indicates the abbreviation of the dataset used

in the experiments.

In order to evaluate the partitions obtained both in

the OFP CLASS method and the BAGOFP CLASS

method, we use an ensemble classiﬁer called Fuzzy

Random Forest (FRF) (Cadenas et al., 2012a). This

ensemble needs as input data a fuzzy partition for the

numerical attributes. FRF ensemble was originally

presented in (Bonissone et al., 2010), and then ex-

tended in (Cadenas et al., 2012a) to handle imprecise

and uncertain data. The ensemble is composed of a

set of fuzzy decision trees (FDTs).

The experimental parameters are as follows:

• Parameters of the FRF ensemble.

– Ensemble Size: 500 FDTs

– Random selection of attributes from the set of

available attributes:

√

|A|

• Parameters for GA in both methods (OFP CLASS

and BAGOFP CLASS).

◦ Individual Number: 100

◦ Generation Number: 250

◦ Crossover probability: 0.8

◦ Mutation probability: 0.1

4.2 Estimation of the Classiﬁcation

Performance and Validating the

Experimental Results

To analyze the results obtained in the study, the fol-

lowing performance measure has been employed: to

compare the results in the experiments the accuracy

(number of successful hits relative to the total number

of classiﬁcations) is used. More speciﬁcally, the ac-

curacy medium obtained as the average accuracy of a

3×5-fold cross-validation is used.

To complete the experimental study, we perform

an analysis of them in each subsection using statistical

techniques. Following the methodology proposed by

Garc

ıa et al. in (Garc

ıa et al., 2009) we use a non-

parametric test.

We use the Wilcoxon signed-rank test to compare

two methods. This test is a non-parametric statisti-

cal procedure for performing pairwise comparison be-

tween two methods. This is analogous with the paired

t-test in non-parametric statistical procedures; there-

fore, it is a pairwise test that aims to detect signiﬁcant

differences between two sample means, that is, the

behavior of two methods.

In order to carry out the statistical analysis R

packet (Ihaka and Gentleman, 1996) has been used.

4.3 BAGOFP CLASS Method and

Bagging Size Parameters

As we have commented in Sections 2 and 3, the use of

bagging is justiﬁed by the fact that bagging can give

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

208

substantial gains in accuracy when the classiﬁcation

method used is unstable (in our case, fuzzy decision

trees). If perturbing the learning set can cause signiﬁ-

cant changes in the classiﬁer constructed, the bagging

can improve accuracy.

In this subsection we show computationally that

fact. As a result of these tests, we will select the val-

ues for δ and β in the method.

To this end, we will show the behavior of the

FRF classiﬁer using different partitions obtained by

the BAGOFP CLASS method. We will change the

values of δ and β of the following way.

We will set the value of β = 1, and we will vary δ

from 1 to 20. Next, we will set δ = 20, we will vary β

from 2 to 30.

In Figures 2 and 3 the obtained results are shown

using GLAS and ION datasets. The horizontal axis

shows the different values (δ,β) and the vertical axis

the average accuracy of a 3×5-fold cross-validation.

Accuracy

(delta,beta)

(1,1)

(4,1)

(8,1)

(12,1)

(16,1)

(20,1)

(20,4)

(20,8)

(20,12)

(20,16)

(20,20)

(20,24)

(20,28)

(20,32)

(delta,beta)

Figure 2: Behavior of BAGOFP CLASS method with GLA

dataset when vary parameters δ and β.

beta

92,593 92,688

y = 0,258ln(x) + 92,09

MWF1

Logarítmica (MWF1)

Exponencial (MWF1)

92,7

93,3

93,9

94,5

0 4 8 12 16 20 24 28 32 36 40 44 48 52

Accuracy

delta beta

4 8 12 16 20 24 28 32

4 8

12 16 20 24 28 32

(1,1)

(4,1)

(8,1)

(12,1)

(16,1)

(20,1)

(20,4)

(20,8)

(20,12)

(20,16)

(20,20)

(20,24)

(20,28)

(20,32)

(delta,beta)

Figure 3: Behavior of BAGOFP CLASS method with ION

dataset when vary parameters δ and β.

As we can see in these ﬁgures, in the ﬁrst changes

of δ, the accuracy presents the biggest changes. Next,

the behavior is stabilizing.

Values of δ = 20 and β = 30 have an acceptable

performance with all the datasets used in this work.

Therefore, we will use these values for experiments

of the next subsection:

• Parameters for BAGOFP CLASS method.

◦ In ﬁrst phase - δ bagging size: 20

◦ In second phase - β bagging size: 30

4.4 Evaluation of the Classiﬁcation

Performance

The experiments are designed to evaluate the per-

formance of the proposed approach. First, we com-

pare the OFP CLASS method (Cadenas et al., 2012b)

with the proposed method BAGOFP CLASS using

datasets which verify the condition |E| ≥ 10 · |A| · |C|.

The accuracy results are shown in Table 2. And sec-

ond, we compare these two discretization methods us-

ing the datasets that do not verify the condition. The

accuracy results are shown in Table 3.

In Tables 2 and 3, training and test are the per-

centages of classiﬁcation average accuracy (mean and

standard deviation) for training and test datasets, re-

spectively. Moreover, the obtained p-values, when

comparing the results of the test phase using a

Wilcoxon signed-rank test are shown.

In Table 2 it is observed that the results obtained

by the new method seem to be similar to the results

obtained by OFP CLASS. Analyzing the different p-

values with α = 0.05, we can conclude:

• There are no signiﬁcant differences between the

datasets.

• Globally, analyzing all the results obtained for dif-

ferent datasets, we can conclude that there are

no signiﬁcant differences between evaluating with

the discretization of the method OFP CLASS

and evaluating with the discretization of the new

method BAGOFP CLASS.

Table 2: Results obtained by FRF after classifying the

datasets that verify |E| ≥ 10 · |A| · |C| using the discretiza-

tion obtained by OFP CLASS and BAGOFP CLASS.

OFP CLASS BAGOFP CLASS

training test training test p-value

AUS 99.85

0.15

86.42

2.94

100

0.00

86.81

3.12

0.1768

BCW 99.74

0.10

96.13

1.27

98.19

0.22

95.90

1.55

0.7772

HEA 97.84

0.54

79.01

5.34

98.92

0.41

79.26

6.56

0.5092

IRP 97.78

0.92

96.67

3.26

98.98

0.62

96.22

3.16

0.6578

VEH 93.60

0.47

71.16

3.48

99.99

0.02

71.55

4.80

0.4325

aver. 97.76

0.44

85.88

3.26

99.21

0.26

85.95

3.84

0.5805

In Table 3 it is observed that the results obtained

by the new method seem to be better than the results

obtained by OFP CLASS. Analyzing the different p-

values with α = 0.05, we can conclude:

ImprovingaFuzzyDiscretizationProcessbyBagging

209

• For all datasets, the analysis indicates that there

are signiﬁcant differences between the two meth-

ods, where BAGOFP CLASS is the best method.

• Globally, analyzing all the results obtained for dif-

ferent datasets, we can conclude that there are

signiﬁcant differences between evaluating with

the discretization of the method OFP CLASS

and evaluating with the discretization of the new

method. The method which gets the best average

accuracy is BAGOFP CLASS.

Table 3: Results obtained by FRF after classifying

the datasets that do not verify |E| ≥ 10 · |A| · |C| us-

ing the discretization obtained by OFP CLASS and

BAGOFP CLASS.

OFP CLASS BAGOFP CLASS

training test training test p-value

ADE 84.32

2.05

81.94

9.96

100

0.00

85.06

9.83

0.01102

APP 90.33

1.80

88.33

7.95

94.02

0.86

90.25

5.72

0.00529

GLA 85.82

1.03

69.80

5.60

100

0.00

73.38

6.68

0.01199

ION 95.89

0.41

93.07

2.38

100

0.00

94.11

2.05

0.00424

PRO 94.93

1.36

89.84

6.98

100

0.00

93.78

5.36

0.00464

SON 93.59

1.59

80.31

5.11

100

0.00

83.68

4.72

0.00105

SPE 79.81

0.97

79.41

4.12

100

0.00

81.78

4.58

0.00108

SRB 94.58

1.72

78.46

13.54

100

0.00

96.79

3.77

0.00109

WDB 93.99

0.41

93.79

2.23

100

0.00

95.49

1.66

0.00692

WIN 94.33

1.28

93.82

3.54

100

0.00

97.57

1.76

0.00253

aver. 90.76

1.26

84.88

6.14

99.40

0.09

89.19

4.61

2.2e-16

Figure 4 shows, in an illustrative way, the results

obtained using BAGOFP CLASS and OFP CLASS

methods with datasets containing enough examples.

100

Training

Test

Classification accuracy average

OFP_CLASS

BAGOFP_CLASS

Figure 4: Comparing results of datasets verifying |E| ≥ 10 ·

|A| · |C|.

Figure 5 shows in an illustrative way the results

obtained using BAGOFP CLASS and OFP CLASS

methods with datasets containing few examples.

In general, with the datasets used (which either

verify or do not verify |E| ≥ 10 · |A| · |C|) we can con-

100

Training

Test

Classification accuracy average

OFP_CLASS

BAGOFP_CLASS

Figure 5: Comparing results of datasets that do not verify

|E| ≥ 10 · |A| · |C|.

clude that the proposed method is useful. When the

datasets do not verify the condition, the fundamental

difference of the new method of discretization is the

partitioning of the attributes. The most important at-

tributes in the classiﬁcation are partitioned possibly

into more parts and more precisely.

From the computational viewpoint, the introduc-

tion of bagging and therefore an iterative process

in both phases increases the runtime of the method.

However, as discussed in Section 2, bagging can be

computationally efﬁcient because it can be imple-

mented in a parallel or distributed way.

5 CONCLUSIONS

In this study we have presented an improvement on

a discretization method, in order to get better parti-

tions and better accuracy in the classiﬁcation task with

small size datasets.

The discretization method is divided into two

phases. On the one hand, in the ﬁrst phase the method

uses a fuzzy decision tree to search possible cut points

to create partitions. On the other hand, in the sec-

ond phase a genetic algorithm is used to construct the

fuzzy partitions taking as input data, the cut points

obtained in the ﬁrst phase.

The way to improve the discretization method is

using a bagging process into the two phases. The

capacity of bagging to improve the accuracy of un-

stable classiﬁers is exploited in the ﬁrst phase of the

method based on fuzzy decision trees. In addition, the

use of the bagging procedure allows the discretization

of more attributes when datasets have a few training

examples compared with the number of attributes, in

other word, when the rule |E| ≥ 10 ·|A| ·|C| is not ver-

iﬁed.

Also we have presented several experiments

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

210

where the new proposed method using bagging gets

better accuracy in classiﬁcation with this kind of

datasets. These conclusions have been validated by

applying statistical techniques to analyze the behav-

ior of different methods in the experiments.

Improve the discretization of numerical attributes

in small size datasets is important like previous step to

carry out feature selection in microarrays data which

is a topic of current interest and we want to carry out

the feature selection using a fuzzy ensemble which

needs a partition of the numerical attributes.

ACKNOWLEDGEMENTS

Supported by the project TIN2011-27696-C02-02 of

the Ministry of Economy and Competitiveness of

Spain. Thanks also to “Fundaci

on S

eneca - Agen-

cia de Ciencia y Tecnolog

ıa de la Regi

on de Murcia”

(Spain) for the support given to Raquel Mart

ınez by

the scholarship program FPI.

REFERENCES

Antonelli, M., Ducange, P., Lazzerini, B., and Marcel-

loni, F. (2011). Learning knowledge bases of multi-

objective evolutionary fuzzy systems by simultane-

ously optimizing accuracy, complexity and partition

integrity. Soft Computing, 15:2335–2354.

Armengol, E. and Garc

ıa-Cerdana, A. (2012). Reﬁning dis-

cretizations of continuous-valued attributes. In The

9th International Conference on Modeling Decisions

for Artiﬁcial Intelligence, pages 258–269.

Au, W. H., Chan, K. C., and Wong, A. (2006). A fuzzy ap-

proach to partitioning continuous attributes for classi-

ﬁcation. IEEE Tran, Knowledge and Data Engineer-

ing, 18(5):715–719.

Bonissone, P. P., Cadenas, J. M., Garrido, M. C., and

ıaz-Valladares, R. A. (2010). A fuzzy random for-

est. International Journal of Approximate Reasoning ,

51(7):729–747.

Breiman, L. (1996a). Bagging predictors. Maching Learn-

ing, 24(2):123–140.

Breiman, L. (1996b). Heuristics of instability and sta-

bilization in model selection. Annals of Statistics,

24(6):2350–2383.

Cadenas, J. M., Garrido, M. C., Mart

ınez, R., and Bonis-

sone, P. P. (2012a). Extending information processing

in a fuzzy random forest ensemble. Soft Computing,

16(5):845–861.

Cadenas, J. M., Garrido, M. C., Mart

ınez, R., and Bonis-

sone, P. P. (2012b). Ofp class: a hybrid method to

generate optimized fuzzy partitions for classiﬁcation.

Soft Computing, 16:667–682.

Cox, E. (2005). Fuzzy Modeling and Genetic Algorithms

for Data Mining and Exploration. Morgan Kaufmann

Publishers, New York, USA.

Der-Chiang, L. and Chiao-Wen, L. (2012). Extending at-

tribute information for small data set classiﬁcation.

IEEE Transactions on Knowledge and Data Engineer-

ing, 24:452–564.

Der-Chiang, L., Chien-Chih, C., Che-Jung, C., and Wu-

Kuo, L. (2012). A tree-based-trend-diffusion predic-

tion procedure for small sample sets in the early stages

of manufacturing systems. Expert Systems with Appli-

cations, 39:1575–1581.

Diaz-Uriarte, R. and de Andr

es, S. A. (2006). Gene selec-

tion and classiﬁcation of microarray data using ran-

dom forest. BMC Bioinformatics, 7(3).

Dimitrova, E. S. and Vera-Licona, M. P. (2010). Discretiza-

tion of time series data. Journal in Computational Bi-

ology, 17(6):853–868.

Frank, A. and Asuncion, A. (2010). UCI Machine Learning

Repository. University of California, Irvine, School of

Information and Computer Sciences.

Garc

ıa, S., Fern

andez, A., Luengo, J., and Herrera, F.

(2009). A study statistical techniques and perfor-

mance measures for genetics-based machine learn-

ing: accuracy and interpretability. Soft Computing,

13(10):959–977.

Ihaka, R. and Gentleman, R. (1996). R: A language for data

analysis and graphics. Journal of Computational and

Graphical Statistics, 5(3):299–314.

Jain, A. K. (2000). Statistical pattern recognition: A review.

IEEE Transactions on Pattern Analysis and Machine

Intelligence, 22:4–37.

Kianmehr, K., Alshalalfa, M., and Alhajj, R. (2010). Fuzzy

clustering-based discretization for gene expression

classiﬁcation. Knowledge and Information Systems,

24:441–465.

Liu, B., Cui, Q., Jiang, T., and Ma, S. (2004). A com-

binational feature selection and ensemble neuralnet-

work method for classiﬁcation of gene expression

data. BMC Bioinformatics, 5(1).

O’Reilly, C. A. (1982). Variations in decision makers’ use

of information sources: the impact of quality and ac-

cessibility of information. Academy of Management

Journal, 25(4):756–771.

Qureshi, T. and Zighed, D. A. (2009). A soft discretization

technique for fuzzy decision trees using resampling.

Intelligent Data Engineering and Automated Learning

- IDEAL 2009, Lecture Notes in Computer Science,

5788:586–593.

Unler, A. and Murat, A. (2010). A discrete particle swarm

optimization method for feature selection in binary

classiﬁcation problems. European Journal of Oper-

ational Research, 206:528–539.

Wang, C., Wang, M., She, Z., and Cao, L. (2012). Cd: A

coupled discretization algorithm. Advances in Knowl-

edge Discovery and Data Mining Lecture Notes in

Computer Science, 7302:407–418.

Wang, Y. and Witten, I. (1997). Inducing model trees for

continuous classes. In Proceedings of the poster pa-

ImprovingaFuzzyDiscretizationProcessbyBagging

211

pers of the european conference on machine learning,

pages 128–137, Prague.

Zararsiz, G., Elmali, F., and Ozturk, A. (2012). Bagging

support vector machines for leukemia classiﬁcation.

IJCSI International Journal of Computer Science Is-

sues, 9(1):355–358.

Zhu, Q., Lin, L., Shyu, M. L., and Chen, S. C. (2011).

Effective supervised discretization for classiﬁcation

based on correlation maximization. In IEEE Interna-

tional Conference on Information Reuse and Integra-

tion (IRI), pages 390–395.

IJCCI2013-InternationalJointConferenceonComputationalIntelligence

212
