Improving Quality in Agile Development Processes

Pryscilla Marcilli Dóra

1,2

, Ana Cristina Oliveira

1,3

and J. Antão B. Moura

Systems and Computing Department, Federal University of Campina Grande (UFCG), Campina Grande, Brazil

University Center of João Pessoa (UNIPÊ), João Pessoa, Paraíba, Brazil

Federal Institute of Paraíba (IFPB), Campina Grande, Paraíba, Brazil

Keywords: Software Quality, Independent Testers, Agile Process Improvement.

Abstract: Software quality control in agile software development is based on two main principles: pair programming

and test-driven development. More recently, “post-agile” techniques seem to favor releasing early over

quality. Pressure for low cost, rapid development and to code for new features leads to the allocation of

resources to software development tasks preferably rather than to quality control. Such practices may put

the responsibilities for development and test on the same team and even facilitate sloppy testing. Albeit in

prototyping this may be acceptable and even make business sense that is not the case of scenarios that

include system software (e.g., a general purpose mobile operating system) or critical applications for

airspace, military, banking or healthcare purposes. In this article, we present our experience in organizing an

agile team which is divided into two cells with different responsibilities: software development per se and

testing exclusively. Preliminary results for the case of a grid computing backup system indicate higher test

efficiency and surprisingly, possible shorter time-to-market of the two-cell organization given

complimentary practices are also adopted. These results may contribute for the on-going discussion on the

role and impact of testing in agile development.

1 INTRODUCTION

As stated in (Guerra and 2002): "the quality of

software is closely linked to the process used to

develop it, and finding a process that fits exactly the

specificities of the development environment is

almost impossible". Hence, it may be better to adapt

and adopt the process that most resembles the

characteristics of the environment (Dinakar, 2009).

Some environmental features increase the

complexity of that task, such as when you have a

small team (Crispin and

Gregory, 2009).

Agile methodologies, such as eXtreme

Programming (XP) and Scrum, treat quality as a

responsibility of the entire development, small team.

However, in many situations, teams spend more time

in production (coding) activities rather than

activities related to quality, so the results still show

unsatisfactory levels of quality and software discard

remains high (Chaos

Report, 2011).

Mechanisms for quality control reduce the agility

of a development team. In fact, if viewed in

isolation, software testing activities require time,

more physical resources, and properly trained

personnel (Lycett et al., 2003). There is a growing

debate in the industry about the need to stress

delivery speed over testing in “post-agile”

processes–see for instance (Savoia, 2011). For

economy of resources, there is a trend to (continue

to) embed testers in product teams with the

consequence of “the role of test and Quality

Assurance (QA) management becoming unclear”

(Heuser, 2012). Another trend indicates that testing

activities are concentrating more on checking

business alignment (uprooting idea bugs) rather than

on code bug fixes (Lent, 2013)–i.e., post-agile

practices seem to suggest end user testing after

product launch. Trends or practices that favor speed

over testing may lead to defective software being

released more often. Albeit in some scenarios–such

as in idea testing by startups or in prototyping–this

may be acceptable and even make business sense,

that is not the case of scenarios that include system

software (e.g. a general purpose mobile operating

system) or critical applications–for the banking or

healthcare industries, say–which have stringent

quality requirements.

Our own experience in developing system

411

Marcilli Dóra P., Cristina Oliveira A. and Antão B. Moura J..

Improving Quality in Agile Development Processes.

DOI: 10.5220/0004559704110416

In Proceedings of the 8th International Joint Conference on Software Technologies (ICSOFT-EA-2013), pages 411-416

ISBN: 978-989-8565-68-6

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

software however, indicates that agile techniques can

be improved with additional or adjusted practices

that improve quality and speed simultaneously. This

is surprising since additional practices would tend to

make the process slower. This paper provides some

details a case in such experience in the hope of

contributing to the discussion about agile speed v.

testing controversy.

The case study we consider here is a backup

utility (OurBackup (Oliveira, 2007)) from the Our

Grid project, an open source free-to-join peer-to-

peer (P2P) grid that aggregates computational

resources (grid machines) to support the execution

of bag-of-tasks (Boot) parallel applications on

demand. The project was developed at the

Distributed Systems Laboratory at the Federal

University of Campina Grande (DSL/UFCG) in

Brazil. Several strategies to mitigate the risks of low

quality were adopted during the project, including

the definition of a software development process

originally named OurProcess (OP), an adaptation of

the XP methodology for the development of

distributed systems. Further (practice) additions to

OP–including the adoption of an independent team

for Quality Assurance–led to an agile, mainly

quality-centered process named OurQualityProcess

(OQP).

OQP’s main characteristics and practices are

briefly reviewed in section 2. Section 3 compares

results of OP’s and OQP’s application to the case

study. Analysis of the results and recommendations

are made in section 4. Results from related work are

compared to ours in section 5. Conclusions, caveats

and further work are presented in section 6

2 OQP: SOFTWARE QUALITY

CONTROL

XP was chosen as a starting point and base for QOP

because our team at DSL/UFCG had familiarity

with its concepts and usage.

The main goal of OQP is to maintain agility. But

to also focus on producing clear requirements and

automatic (Buglione and Hauck, 2012), reproducible

tests, while being still minimally intrusive,

additional practices were added to its XP base (or

Our Process – OP, as we called it internally). OQP’s

additional practices and techniques focus on the

number of defects identified before a new version is

released. The main addition is the insertion of an

external quality assurance (QA) team to focus

exclusively on the quality of final products. (This

does not eliminate the responsibility for quality of

the development team which should cooperate with

the inserted QA team).

Another adaptation of the base XP process

entails validation of requirements, by analyzing and

criticizing each specification sentence. While the

development team writes software requirements and

acceptance tests for the obvious cases, the QA team

checks non-functional aspects, such as

completeness, correctness and unambiguity. This

practice minimizes problems of requirement writing

and interpretation, leading to an executable

documentation in the form of automatic, cohesive

and correct tests that last the software “lifetime”.

Yet another adjustment to OP to yield OQP is to

halve the duration of XP’s typical one-day long

tasks. (This is because “software developers” at

DSL/UFCG are usually students who need to take

care of other daily duties–e.g., attending classes.)

During the implementation of the system

functionalities, the practice of Test-Driven-

Development (TDD) (Beck et al., 2001; Crispin and

House, 2002) is also widely used by the

development team, while the QA team identifies

new test scenarios, sometimes by performing manual

testing prior to automation. The practice of

refactoring is also made to encompass both teams’

codes, developers’ as well as the QA team’s.

Other additional practices include contract-

driven development (Mitchell et al., 2002),

execution of different test batteries (builds), constant

revisions and synchronization between teams. With

this incremented and adjusted set of practices OQP’s

usage is guided by three basic principles as seen

next.

2.1 OQP Principles

i) Gradual QA - After the elaboration of basic

acceptance tests (by the developers), a process called

“explosion of test cases” begins with the purpose of

stressing the code (when available). Each produced

acceptance test leads to one or more tests, which are

developed by the QA team.

Once the defects are fixed (by developers), the

QA team runs the battery of (possibly manual) tests

to validate the correction of defects and to identify

new test cases. Testing stops when a set percentage

of code coverage is reached. According to a survey

of development practioners and managers that

should be higher than 90% (Dóra et al., 2013).

ii) Maintainability of Code Health - Every new

piece of code must go through a battery of

automated tests to be integrated into the repository.

At integration one can check the "health" of the

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

412

code. Different batteries of tests are defined with

different objectives. At first coding, a battery is still

simple with only unit tests and mock tests

(Mackinnon et al., 2000) related to the module under

development. The battery of tests grows according

to the evolution of the software being developed. A

battery of integration tests is performed where the

mock tests are replaced by integration tests, and

every night the full battery of tests is performed

creating a daily status of the "health" of the code.

Furthermore, the integration of a new developed

test should occur as soon as possible so that all team

members have access to the new test and thus

increase the verification of newly developed code.

Note that Development by Contract (DBC) also

contributes to code health by mapping the

responsibilities of classes and objects, making the

implementation more robust. Business rules are

checked by logical assertions that verify whether the

input and output data are correctly processed.

iii) Code Review – is enacted during pair

programming or by a person who is not involved in

the actual coding, preferably by the team leader,

either of development or QA. The adoption of this

principle reduces errors, misinterpretations,

increases code legibility, reduces breaches of

contracts, and improves design. Its combination to

the other two principles causes all developed code to

be examined by at least two people in its life cycle.

2.2 Life Cycle

As in XP, integral development of the software

occurs through a succession of coded and tested

releases. The activities performed for a release are

identified by the lines across Figure 1 and are

detailed in Table 1. Each release is divided into four

phases: Requirements elicitation, Development,

Alpha and Beta Testing. During these phases, the

activities of the development and QA teams are

performed in parallel.

Figure 1: OQP release life cycle.

To validate OQP we applied it to a pilot project and

compared the results to OP’s at DSL/UFCG.

Table 1: OQP Activities and phases.

Teams

Requirement

elicitation

Development Alpha Beta

Develop

-ment

Write

requirement

Code

Implementation

Correction

of defects

Correctio

n of

defects

Define design

Implementation

of unit and

integration test

Acceptance

tests

Correction of

defects

V&V

requirements

Implementation

of new cases of

automated

acceptance tests

Manual and

exploratory

testing

Validatio

n of

defect

correction

Accepta

nce tests

3 CASE STUDY

The proposed Our Quality Process (OQP) was

applied to the OurBackup (OB) Home software

(Oliveira 2007), a backup system based on social

networks. Initially, a set of six macro-features were

defined and implemented under the OP process.

These features enable the user to install the software,

log onto the system, build his/her social network (by

addition and / or acceptance of friends), and lastly,

to perform and restore backups. Upon conclusion of

the first version (V1), eight new features were added

now under OQP, producing a “quality” version 2.

For the comparative study, three releases

developed with OP (OurBackup Release)–OBR

i=1,2 and 3; and three releases developed with OQP

(OurBackup Quality Release) OBQR

, i=1,2 and 3

were considered.

Although every effort was directed to the

production of automatic tests, some manual testing

was needed. However, if a critical defect was

discovered during manual testing, the manual

procedure would be interrupted and a new test

would be developed to detect the defect or to

validate the correctness of the corresponding code.

3.1 Data Collection and Analysis

Initially collected measures were (Table 2): a) % of

test classes; b) % testing methods; c) Number of

cases of manual testing; and, d) automatic testing

coverage. These measures were collected with the

aid of the following tools: Jira (bug tracking);

FindBugs code static analysis); JUnit (for test

development); easyMock (for mock object testing);

Bamboo (for continuing code integration); and, SVN

(version control).

The number of tests in a project is not the most

ImprovingQualityinAgileDevelopmentProcesses

413

appropriate metric to attest to its quality, but it may

suggest amount of effort towards quality control. In

column a in Table 2, we note a gradual increase in

the percentage of test classes as OQP is adopted –

reaching an increase of 50% over OP’s percentage

(22% over 14,8%).

The increase in the amount of classes of tests by

itself is not an indication that there has been an

increase in the effort to produce automatic tests. So,

we collected other data that indicate such an

increase: column b shows the proportion of testing

methods relative to the total of developed methods.

Column c shows an increase in manual testing as

one switches from OP to OQP to produce OBQR

and OPQR

. But a consistent decrease from OBQR

to OBQR

and a lower amount of manual testing

with OBQR

relative to OBR

This seems to indicate

that OQP’s sharper focus on testing tends to reduce

manual testing which is tedious and error prone.

The relative larger number of manual tests for

OQP can be attributed to this process’ permanent

availability of testers coupled with the functional

code-breaking idiosyncrasies of OB’s target

distributed environment: different operating systems

(OS) or different features across instances of a same

OS (such as different versions, Network Address

Translation, firewalls, antivirus software, and so

forth). Environments such as OB’s tend to reduce

the realistically possible amount of automatic testing

(as a percentage of the entire code) to the range of

20-40% (Harrison, 2013).

Table 2: Initial data comparison.

Version

a)Classes

of tests

(%)

b)Testing

Methods

(%)

c) # of

Manual Tests

d)Automatic

tests’ code

coverage (%)

OB R1 15,8 8,0 0 0

OB R2 14,4 11,0 74 21

OB R3 14,8 10,8 160 18

OBQ R1 13,5 13,4 275 34

OBQ R2 21,0 16,3 229 62

OBQ R3 22,2 17,7 143 91

Code coverage was measured in terms of lines,

methods and classes covered by tests and it was

collected using the Clover tool (Clover, 2012).

Column d brings these data and it shows a consistent

increase in code coverage as OQP is continually

employed to reach 91% with OBQR

(meeting the

quality baseline of over 90% as indicated by 60% of

the respondents in the international survey in (Dóra

et al., 2013)). In contrast OP shows a somewhat

haphazard behavior.

One may also note that, differently from OP,

OQP meets baseline values for other metrics in this

international survey: percentage of erroneous

deadline and programmer-month effort estimations

(within 5 to 15% as indicated by 48% of

respondents) and percentage of defects discovered

after release delivery (1 to 5%).

Regarding the lifetime of defects, or how fast

the team is in resolving defects, a significant

improvement with OQP was observed (please refer

to Table 3).

Again, Table 3 illustrates a gradual improvement

in quality as OQP usage continues (by contrast, OP

degrades on the average, while OQP’s min, max,

average and median times to fix defects improve).

Table 3: Lifetime of defects.

Software

Version

Minimum

(days)

Maximum

(days)

Average

(days)

Median(days)

OB R1 - - - -

OB R2 3 801 65 19

OB R3 1 328 168 221

OBQ R1 1 102 24 60

OBQ R2 0 29 9 13

OBQ R3 0 7 6 5

4 EVALUATION AND LESSONS

We believe OQP’s superiority over OP in the pilot

project of OurBackup is due to:

Independence of testers in the QA team: there

is a QA boss who is not the development leader.

Testers are well regarded by the leader when they

find critical defects and vulnerabilities in the

software. Testers do not feel guilty when they reveal

defects that they have not inserted themselves in the

code.

Promoting testing competencies: testers should

be trained to improve their skills in detecting failures

and writing tests.

Sharper focus on quality: a tester is more

productive than a developer that only tests his code

in the remaining time of development. Moreover, an

external tester, in general, is less likely to ignore

errors caused by programming vices.

Also and contrary to agile processes that

typically allow little emphasis on testing tasks

initially (Reichert, 2012), OQP recommends

concentration on tests right from the onset of the

project. This may not need to increase budgets by

much. Test outsourcing may reduce the need for

costly, in-house testing environments, thus easing

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

414

the internal competition for resources between

developers and testers. In turn, this should make it

easier and cheaper to have a two-cell organization as

advocated here.

5 RELATED WORK

The debate on agile speed v. testing seems to have

been kindled by the inability of agile practices of

unit and acceptance tests to always meet the need for

quality of delivered products (Hislop et al., 2002).

This paper indicates that testing and speed need not

be traded off if practices that lead to development

and independent testing activities are added to agile

processes. The results presented here may have shed

light on this debate. and may help practitioners’

make informed decisions regarding quality

management of software development projects.

One may contend at this point that the benefits of

continuous, independent software testing activities

having been established long ago, are undisputable

and for that, need not be revisited. The on-going

debate in the marketplace indicates otherwise:

practices of yesteryears are criticized for being in

want of reform to meet new challenges. Also and

despite recent progress, most companies still present

very low levels of testing maturity (Experimentus,

2011). As stated in this last reference: “It is perhaps

a damning indictment of the industry that after all

these years we can consistently design and plan

testing, but have no thought or regard for effectively

measuring the success and efficiency of this activity

(which, combined with the costs of rework, forms a

significant proportion of project costs)”. This paper

offered some insight into measurements of test

results.

State-of-the-practice requirements needed to

measure (expected) software quality were elicited in

an international survey of expert software

development managers (Dóra et al., 2013). This

survey yielded a software quality metrics baseline

for the accuracy of project estimates, the detection of

defects before product release, and the test coverage.

This baseline was used for comparing results of the

test-driven, adapted agile OQP process proposed

here against those of its foundation XP process.

The authors of the work in (Artho et al., 2006)

have proposed and studied a framework to scale up

unit tests, and, as a result, they achieved test

coverage of over 99 % with 36 % of the code

dedicated to testing. In the case study worked out

here, OQP achieved a test coverage of 91 %, with a

total test code of 18 %. Although results of both

works exceed the test coverage baseline of (Dóra et

al., 2013), OQP ended up having half of the test

code percentage of total coding effort. One cannot

vouch for OQP’s superiority (or the framework in

(Artho et al., 2006) for that matter), however, given

environmental differences underlying both works. A

more detailed scrutiny and comparison of both

works could reveal interesting, complementary

aspects that could be explored to support decisions

concerning code coverage against test code amount

trade-offs, which was not intentionally made here.

6 CONCLUSIONS

AND OUTLOOK

This paper proposed complementing the basic

aspects of Agile development processes with a few

but significant techniques and practices that, taken

together, have been shown effective in improving

quality and defect-fixing-delays for the case of a

backup utility in a large scale, open source free-to-

join, peer-to-peer (P2P) grid computing

environment.

The case studied compared results for two

different versions of the backup utility. Although

this may hinder the significance of conclusions and

recommendations, it offered some evidence that

investing in independent testing may indeed pay off

not only in software quality but in development time

as well.

Further work is needed to extricate and isolate

cause-effect relationships (between added practices

and the observed improvements), to establish the

degree of significance of each cause to results, and

to generalize conclusions. The early evidence

presented here supports OQP’s separation of testing

from development. This separation may run against

current industry trends but it may as well better

support agile practioners, particularly those with

responsibility for critical application development

where a higher degree of compliance between

requirements and implemented features is expected.

ACKNOWLEDGEMENTS

The authors thank anonymous reviewers whose

comments clarified and enriched the contents of this

paper.

ImprovingQualityinAgileDevelopmentProcesses

415

REFERENCES

Artho, C., Biere, A., Honiden, S., Schuppan, V., Eugster,

P., Baur, M., Zweimüller, B., Farkas, P. Advanced

Unit Testing -- How to Scale Up a Unit Test

Framework. AST 2006, Shanghai, China, May 2006.

Beck, K., Beedle, M., Van Bennekum, A., Cockburn, A.,

Cunningham, W., Fowler, M., Grenning, J.,

Highsmith, J., Hunt, A., Jeffries, R., Kern, J., Marick,

B., Martin, R. C., Mellor, S., Schwaber, K.,

Sutherland, J., and Thomas, D., (2001). “Manifesto for

agile software development”. http://

www.agilemanifesto.org. Accessed in: Dec 17

, 2008.

Buglione, L., Hauck, J. C., Gresse Von Wangenheim, C.,

Mccaffery, F., (2012). “Hybriding CMMI and

Requirement Engineering Maturity & Capability

Models”. ICSOFT – 7th International Conference on

Software Paradigm Trends, Italy.

Chaos Report (2011). http://blog.standishgroup.com

Accessed in: Jun 18

, 2012.

Crispin, L., Gregory. J., (2009). “Agile Testing: Practical

Guide for testers and Agile Teams”. Addison-Wesley

Signature Series.

Crispin, L., House, T., (2002). “Testing Extreme

Programming”. XP Series.

Clover (2012). http://www.atlassian.com

Dinakar, K., (2009). "Agile Development: Overcoming a

Short-Term Focus in Implementing Best Practices". In

Conference on Object Oriented Programming Systems

Languages and Applications (OOPSLA), Orlando, FL,

pp. 579-588

Dora, P., Oliveira, A. C., and Moura, J. A.B., (2013). “A

Baseline for Quality Management in Software

Projects”. In Proceedings of Informática 2013 – 15

International Convention and Fair, March 18th to

, Havana, Cuba, ISBN 978-959-7213-02-4.

Experimentus, (2011). “Test Maturity Model Integrated

(TMMi) – Survey Results, How Mature are

Companies’ Software Quality Management Processes

in Today’s Market?” Update 2011, White paper,

www.experimentus.com, 20 pp.

Guerra, A., Santana, M. (2002). “Quality of Software

Process or Quality of Software Product?”. In:

International Conference on Software Quality, Canada.

Harrison, J. A., (2013). Cited in “A debate on the merits of

mobile software test automation”, James A. Denman,

Published 23 May 2013, http://searchsoftware

quality.techtarget.com/news

Heuser, M., (2012). “Exploring the shifting roles in test

and QA management”. In http://searchsoftwarequality.

techtarget.com. Accessed in: Oct 12

Hislop, W., Lutz, J., Naveda F., McCracken, M., Mead, R.,

Williams, L. A. (2002). “Integrating Agile Practices

into Software Engineering Courses”. In 15th CSEET.

Lent, J., (2013). “Software Testing Trends 2012: Business

Alignment, Not Bug Fixes”. http://searchsoftware

quality.techtarget.com. Accessed in: Jan 28

, 2013.

Lycett, M., Macredie, D., Patel, C., Paul, J., (2003).

“Migrating Agile Methods to Standardized

Development Practice”. In: IEEE Computer Society,

pp. 79-85.

Mackinnon, T., Freeman, S., Craig, P., (2000). “Endo-

Testing: Unit Testing with Mock Objects”. XP

eXamined by Addison-Wesley.Meyer, B., (1997).

“Object-Oriented Software Construction”. Second

Edition, Prentice Hall.

Mitchell, R., McKim, J., Meyer, B., (2001). “Design By

Contract, by example”. Addison-Wesley Publishing

Company.

Oliveira, M., (2007). “OurBackup: Uma Solução P2P de

Backup Baseada em Redes Sociais”. Dissertação de

Mestrado, COPIN - UFCG, Campina Grande, PB,

Brasil (In Portuguese).

Reichert, A., (2012). “How to Focus an Agile Scrum Team

on Quality and Testing”. http://searchsoftwarequality.

techtarget.com, first published in August 2012.

Savoia, Al., (2011). “Test is Dead”. 6th Annual Google

Test Automation Conference (GTAC). Uploaded on

Oct 27, 2011.

ICSOFT2013-8thInternationalJointConferenceonSoftwareTechnologies

416
