Not All ISPs Equally Secure Home Users

An Empirical Study Comparing Wi-Fi Security Provided by UK ISPs

Z. Cliffe Schreuders and Adil M. Bhat

School of Computing, Creative Technologies and Engineering, Leeds Metropolitan University,

Caedmon Hall, Headingley Campus, Leeds, U.K.

Keywords: Wardriving, Wi-Fi Security, ISPs.

Abstract: A majority of home users rely on their Internet service providers (ISPs) to provide them with wireless

equipment that is secure, and assume that they are appropriately protected from threats such as

piggybacking and eavesdropping. In this paper we present the results of an empirical study comparing the

security provided to home users by their ISPs. Passive wireless data collection was used to gather

information on 7,847 unique wireless access points within Leeds, UK. Non-parametric inferential statistical

analysis was used to compare the security provided by the corresponding ISPs, as identified via the SSID

naming used by ISPs in the UK. The ISPs identified included BT, O2, Orange, Plus Net, Sky, TalkTalk, and

Virgin Media. Statistically significant differences in the security of the networks were found between ISPs,

which we contend can in part be explained by their upgrade policies. These results are contrasted with the

security configuration provided by three of the largest ISPs to new customers. For example, BT (the largest

ISP in the UK) was found to have a greater number of access points configured with the cryptographically

broken Wireless Equivalent Privacy (WEP) encryption method in use, compared to most of the other large

ISPs, and this is in contrast to the favourable security configuration of the routers that are provided to new

customers. The paper concludes with recommendations for when ISPs provide Wi-Fi enabled routers to

home users.

1 INTRODUCTION

Many ISPs make a point of advertising that the Wi-

Fi networks of the routers that they provide to home

users are secure. Furthermore, many home users lack

the expertise to configure their own access points,

and assume that the router provided by their ISP is

adequately secure. While many routers provide

relatively secure configurations at the time of

purchase, over time weaknesses are discovered in

protocols that were previously considered secure.

Encryption methods such as Wireless Equivalent

Privacy (WEP) have long been considered

cryptographically broken (Borisov et al., 2001);

(Fluhrer et al., 2001). WEP was introduced by IEEE

in 1999 to provide data confidentiality and integrity

for 802.11 wireless networks, with the intent that the

security was “equivalent” to wired networks.

However, design flaws were quickly discovered –

such as the small initialisation vector (IV) value,

which results in susceptibility to a Fluhrer, Mantin

and Shamir attack (Fluhrer et al., 2001). Other flaws

in the WEP algorithm make the attacks more

efficient, and even enable real-time decryption

(Bittau et al., 2006); (Stubblefield et al., 2004);

(Tews et al., 2007). These flaws effectively render

WEP networks unsuitable for most security

purposes.

Wi-Fi Protected Access (WPA) provides a more

secure alternative for protecting Wi-Fi networks.

However, weaknesses have been found, such as

weaknesses in the pre-shared key mode with TKIP,

which can result in decryption and injection of

packets (Tews and Beck, 2009). As a consequence

WPA has been deprecated in favour of WPA2.

WPA2 is currently considered the most secure of the

common encryption options for securing 802.11

networks.

Wi-Fi Protected Setup (WPS) is a key

distribution method built into many modern network

devices, which reveals the network key (regardless

of encryption method used) when a client specifies

the correct 8 digit PIN. On some devices, this

request can be made wirelessly. It has recently been

568

Schreuders Z. and Bhat A..

Not All ISPs Equally Secure Home Users - An Empirical Study Comparing Wi-Fi Security Provided by UK ISPs.

DOI: 10.5220/0004600405680573

In Proceedings of the 10th International Conference on Security and Cryptography (SECRYPT-2013), pages 568-573

ISBN: 978-989-8565-73-0

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

reported that in many cases this technology is

enabled by default and is vulnerable to (reduced

search space) online brute-force attacks (Stefan

Viehböck, 2011). This is an example of an attack

that many current routers are vulnerable to and, as

subsequently discussed, the problem is analogous to

the upgrade to more secure encryption methods. It is

common practice in the UK for ISPs to provide

“free” routers with wireless access points (APs) to

customers, included with their subscription. BT is

currently the largest broadband provider in the UK,

with reportedly over 6 million subscribers. Virgin

Media, TalkTalk, and Sky are the next largest, with

approximately 4 million broadband customers each.

Other ISPs that provide Wi-Fi APs include O2,

Orange, and Plusnet. The security of the home

routers provided by these ISPs are explored

throughout this paper.

2 AIMS

This study aimed to identify whether various ISPs

provide different levels of Wi-Fi security to their

home customers, and aimed to identify any

discrepancies between the protection provided. This

research question was evaluated for a relatively large

population of wireless home networks, and in order

to explore the change over time, the default

configuration of routers recently provided by three

of the largest ISPs were also compared in terms of

the level of security provided to home users.

3 METHODS

Data collection was conducted in two stages:

1. Wardriving to collect information on wireless

networks in Leeds, UK as it pertains to the

security provided by ISPs

2. Manual investigation of routers recently

provided by BT, Virgin Media, and Sky

3.1 Wireless Data Collection

Wardriving was conducted using the following

equipment:

 9dBi omnidirectional antenna

 802.11b/g/n USB adaptor

 GPS USB dongle

 Laptop running Backtrack 5 R2 with Kismet

Wireless data collection was performed towards the

end of 2012. The antenna was mounted to the roof of

a car, which was driven around high-density

residential areas of Leeds, UK. Specifically

wardriving (wireless data collection from a motor

vehicle) was conducted in select streets in these

areas: Hyde Park, Woodhouse, Headingely, Armley,

Bramley, Beeston, Roundhay, Harehills,

Chapeltown, Hunslet, Kirkstall, and Horsforth.

These areas were chosen as they were expected to

have a high density of home Wi-Fi networks.

Kismet was the software used to log details of

wireless networks. Kismet is a passive network

detection tool. It cycles through Wi-Fi channels

listening to information that is publicly broadcast by

networks, and records information from packets

indicating the presence of access points. Kismet was

configured not to log traffic content (which arguably

would have further ethical ramifications), but to

record high-level details of existing networks, such

as the SSID and security protocol in use.

Ethics approval was granted by the governing

university. Legal precedent seems to suggest that

piggybacking (that is, actually using someone else's

network) without permission is illegal in the UK.

However, the information collected for this study is

broadcast publicly (so no unauthorised access

occurs) and is also routinely collected and stored by

many consumers and businesses; for example, for

location-based services.

After data collection was complete, the data was

exported from Kismet for analysis.

For each network, as determined by the security

flags recorded, a simple security rating score was

assigned, as illustrated in Table 1. This enables a

mean score to be calculated to give an approximate

view of differences, and defines an ordinal scale for

non-parametric data analysis.

Table 1: Security score calculation.

Encryption method Security rating

None 0

WEP 1

WPA 2

WPA2 3

As a passive tool, Kismet records the properties

of each network corresponding to a MAC address. It

is possible for an SSID to appear multiple times due

to multiple devices connecting to the same network.

When this occurred, multiple records where reduced

to one unique record for the network by keeping the

NotAllISPsEquallySecureHomeUsers-AnEmpiricalStudyComparingWi-FiSecurityProvidedbyUKISPs

569

record with the highest level of security: for the case

where a WPA and WPA2 connection were both

found on the same access point. This approach was

taken in order to ensure that each access point was

depicted once and security levels were not under

reported.

The ISP of each connection was established

based on the SSID in use. In the UK, ISPs

consistently name the access points provided to their

customers: for example, an SSID of “SKY84946”

indicates the router was provided to a Sky home

user, while an SSID of “virginmedia8395730” was

provided by Virgin Media. Using this technique, the

ISPs associated with networks were identified.

Open hotspots were pre-filtered out of the data

set based on SSID. Other networks included

manually configured routers, and hidden SSIDs.

These networks were categorised as “other”, and

were excluded from inferential analysis; however,

descriptive statistics were produced.

Finally, inferential statistics were applied to

investigate correlations between ISP and security.

3.2 Manual Router Investigation

Although wardriving provides information about an

extensive number of networks, manually

investigating routers can provide more depth into

details such as the strength of network keys and

default settings. For this reason, routers from three

of the largest ISPs, which had been provided to

home users within the last year, were analysed in

terms of their security properties. Analysis was

based on a convenience sample of routers from BT,

Virgin Media, and Sky. This information illustrated

notable differences in the approach of the various

ISPs and, as discussed herein, was in contrast with

the results based on wireless data collection.

4 RESULTS

4.1 Analysis of Wireless Data

Just over 10,000 networks were recorded during

wardriving. After filtering of hotspots and removal

of duplicate SSIDs 7,847 networks remained. Of

these, 5,158 were identified as being associated with

a specific ISP. The ISPs identified were: BT, O2,

Orange, Plus Net, Sky, TalkTalk, and Virgin Media.

Initial descriptive analysis is presented in Table

2. The table shows the number of wireless networks

of each ISP, and the number and proportion of each

encryption method found in use on access points

provided by the ISP.

Table 2: ISPs and use of encryption methods.

None WEP WPA WPA2 Total

(1%)

116

(13.8%)

(1.4%)

706

(83.8%)

842

(0%)

112

(38.6%)

(0%)

178

(61.4%)

290

Orange

(0%)

(9.1%)

(0%)

(90.9%)

Other

120

(4.5%)

277

(10.3%)

719

(26.7%)

1573

(58.5%)

2689

Plusnet

(0.8%)

(0%)

116

(98.3%)

118

Sky

(0.1%)

(1.7%)

398

(29.3%)

936

(68.9%)

1358

Talk-

Talk

(0%)

(1.2%)

(0.8%)

510

(98.1%)

520

Virgin

Media

(0.1%)

(0.4%)

(0.5%)

1964

(98.9%)

1986

The mean of the scores for each ISP is illustrated

in Figure 1, and are as follows: BT=2.68, O2=2.23,

Orange=2.82, Other=2.39, Plusnet=2.96, Sky=2.67,

TalkTalk=2.97, and Virgin Media=2.98. Although

this view of the data is an approximation (being

means of ordinal data), it illustrates that differences

appear to exist between ISPs.

Non-parametric statistical tests were applied to

investigate whether the ISP has a significant effect

of the level of security of home users.

A Kruskal-Wallis H test was conducted to

compare the effect of ISP on Wi-Fi security rating.

There was a statistically significant effect of the ISP

(H(6)=827.211, p < 0.001). It can be concluded that

there is a difference in wireless security correlated

with the ISPs.

Post-hoc analysis was conducted using the

Mann-Whitney U test with Bonferonni adjustment

applied. In each pairwise comparison between three

of the largest ISPs (BT, Virgin Media, and Sky) the

differences were found to be statistically significant

(p < 0.001). That is, all the three ISPs were

significantly different from each other in terms of

wireless security. Pairwise comparison was

performed between each ISP, and the other

significant results include:

 O2 was found to provide statistically significant

lower levels of security when compared with all

the other ISPs. WEP usage was of the highest

proportion, compared to other ISPs.

 BT was found to provide significantly different

levels of security when compared to all the ISPs,

except Orange (likely due to the small sample of

Orange networks). BT had notably higher

SECRYPT2013-InternationalConferenceonSecurityandCryptography

570

Figure 1: Mean security rating scores by ISP.

proportions of WEP networks compared to

others, except in comparison to O2. Means and

proportions are previously reported.

 Sky was also found to provide statistically

different security in comparison with all the

other ISPs, except Orange. Although Sky had a

lower WEP proportion than some others, WPA

(rather than WPA2) usage was higher than the

other ISPs.

 Virgin Media, TalkTalk, and Plusnet were

statistically different to O2, BT, and Sky, as

mentioned above. Comparison with other ISPs

did not indicate significant difference of the

security.

 Orange (with a small sample size) was

significantly different only to O2.

4.2 Analysis of Routers

Recent routers provided to UK customers of BT,

Virgin Media, and Sky were investigated. A

summary of the findings is presented in Table 3.

5 DISCUSSION

It is commendable that, across all the ISP provided

routers that were identified, WPA2 adoption was

quite high. Also, amongst the ISPs studied in greater

detail, new customers were typically provided with

access points which by default are configured for a

WPA/WPA2 mixed mode, which is generally

considered to provide security adequate for home

use.

However, in the population studied, there was

still a disturbing number of WEP networks in use on

routers provided by ISPs, and even a number of

networks with no encryption in use. Many of the

three largest ISPs' (BT, Virgin Media, and Sky)

routers included home networks with no encryption.

These networks are very few in number and

represent less than 1% of the total analysed

networks. However, if this is representative of the

millions of home Wi-Fi networks, this could be

considered to represent a large total number of users.

One explanation for home routers configured this

way is deliberate configuration by end users to open

their networks to others.

Table 3: Standard router configurations for BT, Virgin

Media and Sky.

BT Virgin Media SKY

Encryption

options

WEP, WPA,

WPA2,

WPA/WPA2

(mixed mode)

WEP, WPA,

WPA2,

WPA/WPA2

(mixed

mode),

WPA/WPA2-

Enterprise

(802.1X)

WEP, WPA,

WPA2,

WPA/WPA2

(mixed

mode), WPA

Enterprise

(802.1X)

Default

encryption

WPA/ WPA2

Mixed mode

WPA/WPA2

Mixed mode

WPA/WPA2

Mixed mode

Authentication

option available

PSK PSK PSK

WPS-PIN Yes Yes Yes

Default network

key

Alphanumeric

Alphabetical

(Lower case

only)

Alphabetical

(Uppercase

only)

Default network

key length

10-digit 8-digit 8-digit

Key size 62

Default router

administration

password

Alphanumeric “changeme” “sky”

Of the routers provided by ISPs, over 5% (271)

NotAllISPsEquallySecureHomeUsers-AnEmpiricalStudyComparingWi-FiSecurityProvidedbyUKISPs

571

were configured to use WEP. The distribution

clearly varies between ISPs, with some ISPs with

substantially higher proportions of WEP networks

than others.

Data analysis showed that the ISP has a

significant effect on the level of security on their

users' home networks. Which raises the question:

should ISPs be considered responsible for the Wi-Fi

security of their customers? It could be argued that

ISPs have a “duty of care” when they provide

routers with wireless access points, given that ISPs

often advertise that they provide secure networks,

and the fact that many home users are unlikely to

reconfigure the routers provided to them.

In many cases ISPs were found to have

significantly different distributions of encryption

employed by their routers. Some ISPs appear to have

kept their users' security more up-to-date than

others. This may be of interest to consumers who

could be determining their own future security status

when choosing an ISP.

Of the largest ISPs (BT, Virgin Media, TalkTalk,

and Sky), BT was found to have the highest

proportion of routers configured to use WEP

encryption, at 13.8%. If the sample in this study was

representative of the population at large, BT's

customer base could have upwards of 800,000 home

users using WEP in the UK. This could be

considered cause for concern, as these networks

would be vulnerable to easy attack, and could be

targeted for eavesdropping, piggybacking, and

various other threats.

This is in contrast to the findings from the

analysis of recently provided routers, which

illustrates that BT does seem to provide

comparatively well configured routers to new users.

BT home networks using the “BT Home Hub”

1.0 and 1.5 were all using WEP encryption. These

networks were identifiable based on their SSID,

starting with “BTHomeHub-” followed by an

alphanumeric pseudo-random string: for example,

“BTHomeHub-7AFC”. Other BT networks, using

newer routers (SSID names starting with

“BTHomeHub2-”, “BTHomeHub3-” and “BTHub3-

”) were found to be using WPA2.

This suggests that many of the insecurely

configured routers were installed some time ago, and

have yet to be updated with more modern encryption

methods. We contend that this is likely due to the

upgrade policies of the ISPs.

The recent vulnerabilities discovered in WPS

authentication, as described in the introduction,

illustrates the ongoing importance of ISP response

time to Wi-Fi security threats, and applies to many

of the routers provided by ISPs. The way that ISPs

react to these issues is expected to have a significant

effect on the ongoing security posture of their

customers.

6 RECOMMENDATIONS

Based on these findings, when ISPs provide routers

to their customers, the following recommendations

are offered:

 ISPs should make an effort to track which model

of router and the version of firmware their

customers are using, and automatically push

updates and upgrades to users

 ISPs should proactively upgrade their users'

routers (software and/or hardware) as soon as

possible after critical security vulnerabilities are

discovered and fixes are available – or at least

contact customers and educate them on risks and

provide update options

 When fixes are not yet available (as may

currently be the case with some WPS

configurations), ISPs should inform customers of

the threats they face and estimate time until

solutions will be available

 WEP should be removed as an option from new

routers, or at least trigger obvious and

informative alerts to users if they choose to

switch to this non-default configuration

 Routers should come securely pre-configured,

including adequately pseudo-random network

keys and web administration passwords (rather

than default passwords such as Sky's “sky” or

Virgin Media's “changeme”)

 Unless it has been demonstrated to be

significantly less usable, as far as is practical,

larger key spaces should be employed for pre-

configured passwords: for example, by using

alphanumeric rather than alphabetical passwords

 Other ISP specific recommendations:

◦ BT should consider ways to improve the

security posture of customers currently using

BT Home Hub version 1 or 1.5

◦ O2 should investigate and act upon their

customers' routers employing WEP

 Users should be educated regarding maintaining

the security of their networks

SECRYPT2013-InternationalConferenceonSecurityandCryptography

572

7 RELATED RESEARCH

Various small scale wardriving efforts have been

conducted in Leeds, UK: such as a report from 2004

of 66 networks, all reported to be using either WEP

or no encryption (Dlaverty, 2004).

Some other independent work has also analysed

and critiqued the security of the routers provided by

UK ISPs to their customers. For example, the

security of the BT Home Hub router has received

extensive criticism, not only for the choice of

encryption and key length (as discussed herein), but

also for insufficient entropy of pseudo-random

passwords, vulnerabilities in the web interface, and

open ports for management services (Adrian Pastor,

2007). Problems have also been discovered with

Sky's pseudo-random passwords (in this case with

their older Netgear v2 DG934g routers), passwords

can be deduced based on the (public) MAC address

(John Leyden, 2008). These routers are also

vulnerable to an attack that can determine the ADSL

password, when the username is known

(NewsreadeR, 2008).

As far as we are aware, this is the first empirical

study to investigate correlations between security

and ISPs, and how ISPs differ from each other in

terms of the types of security provided to their users.

8 CONCLUSIONS

Analysis of data collected via wardriving in Leeds,

UK, has shown a statistically significant effect on

Wi-Fi security by ISPs, and significant differences

between many individual ISPs. A number of

networks were found to be using WEP, despite this

being known to be a cryptographically broken

encryption method, and these routers were provided

by identifiable ISPs, who are in a position to be able

to keep track of out-of-date routers. We contend that

this highlights the importance of router upgrades,

and have provided a number of recommendations for

ISPs, router manufacturers, and home users that

apply when ISPs provide routers with wireless

access points to customers.

The question of duty of care was raised: should

ISPs be considered responsible for the Wi-Fi

security of their customers when they provide

routers with wireless access points, given that ISPs

often advertise that they provide secure networks,

and many home users are unlikely to reconfigure the

routers provided to them?

REFERENCES

Adrian Pastor, 2007. BT home flub: pwnin the BT Home

Hub [WWW Document]. GNUCITIZEN. URL

http://www.gnucitizen.org/blog/bt-home-flub-pwnin-

the-bt-home-hub/ (accessed 10.28.12).

Bittau, A., Handley, M., Lackey, J., 2006. The final nail in

WEP’s coffin, in: Proceedings of the 2006 IEEE

Symposium on Security and Privacy, SP ’06. IEEE

Computer Society, Washington, DC, USA, pp. 386–

400.

Borisov, N., Goldberg, I., Wagner, D., 2001. Intercepting

mobile communications: the insecurity of 802.11, in:

Proceedings of the 7th Annual International

Conference on Mobile Computing and Networking,

MobiCom ’01. ACM, New York, NY, USA, pp. 180–

189.

Dlaverty, 2004. Open all hours - Wardriving in Leeds,

West Yorkshire, England [WWW Document].

Openxtra. URL http://www.openxtra.co.uk/articles/

wardriving-leeds (accessed 10.28.12).

Fluhrer, S., Mantin, I., Shamir, A., 2001. Weaknesses in

the key scheduling algorithm of RC4, in: Vaudenay,

S., Youssef, A. (Eds.), Selected Areas in

Cryptography, Lecture Notes in Computer Science.

Springer Berlin / Heidelberg, pp. 1–24.

John Leyden, 2008. Sky Broadband puts the fault into

default Wi-Fi security: Users in guess-able random

keys quandary [WWW Document]. The Register.

URL http://www.theregister.co.uk/2008/02/21/sky_

broadband_wi_fi_keys_unpicked/ (accessed 10.28.12).

NewsreadeR, 2008. Is your router secure? [WWW

Document]. Sky User. URL http://www.skyuser.co.uk/

skyinfo/783.html (accessed 10.28.12).

Stefan Viehböck, 2011. Brute forcing Wi-Fi Protected

Setup: When poor design meets poor implementation

[WWW Document]. URL http://packetstorm.foofus.

com/papers/wireless/viehboeck_wps.pdf

Stubblefield, A., Ioannidis, J., Rubin, A.D., 2004. A key

recovery attack on the 802.11b wired equivalent

privacy protocol (WEP). ACM Trans. Inf. Syst. Secur.

7, 319–332.

Tews, E., Beck, M., 2009. Practical attacks against WEP

and WPA, in: Proceedings of the Second ACM

Conference on Wireless Network Security, WiSec ’09.

ACM, New York, NY, USA, pp. 79–86.

Tews, E., Weinmann, R.-P., Pyshkin, A., 2007. Breaking

104 Bit WEP in less than 60 seconds, in: Proceedings

of the 8th International Conference on Information

Security Applications, WISA’07. Springer-Verlag,

Berlin, Heidelberg, pp. 188–202.

NotAllISPsEquallySecureHomeUsers-AnEmpiricalStudyComparingWi-FiSecurityProvidedbyUKISPs

573
