Introducing a Security Governance Framework

for Cloud Computing

Oscar Rebollo

, Daniel Mellado

and Eduardo Fernández-Medina

Social Security IT Management, Ministry of Labour and Immigration,

Doctor Tolosa Latour s/n, Madrid, Spain

Spanish Tax Agency - Large taxpayers department - IT Auditing Unit,

Paseo de la Castellana 106, Madrid, Spain

GSyA Research Group, Department of Information Technologies and Systems,

University of Castilla-La Mancha, Paseo de la Universidad 4, Ciudad Real, Spain

Abstract. The cloud computing paradigm provides a more efficient way in

which to provide IT services, introducing on-demand services and flexible

computing resources. The adoption of these cloud services is being hindered by

the security issues that arise with this new environment. A global security solu-

tion, which deals with the specific particularities of the cloud paradigm, is

therefore needed, and literature fails to report on such a solution. As a conse-

quence, in this paper we propose a novel security governance framework fo-

cused on the cloud computing environment (ISGcloud). This framework is

founded upon two main standards: on the one hand, we implement the core

governance principles of the ISO/IEC 38500 governance standard; and on the

other hand, we propose a cloud service lifecycle based on the ISO/IEC 27036

outsourcing security draft. The paper includes an overview of the framework

and the description of a collection of activities and their related tasks.

1 Introduction

During the last few years, both organisations and individuals have started paying

attention to the explosive growth and adoption of cloud computing services. This new

paradigm encompasses access to a shared pool of computing resources that can be

rapidly provisioned and released with minimal management effort [1]. Users may

benefit from the flexibility and elasticity of on-demand cloud services, especially at

present when economic restrictions require IT departments to achieve more objectives

with less resources. When these kinds of services are aligned with well-defined stra-

tegic initiatives and objectives, they make valuable contributions to an enterprise [2].

However, the many benefits provided by cloud computing are also accompanied by

the appearance of new risks [3], in addition to the continued presence of all the securi-

ty issues that may affect its underlying technologies [4]. The independence of the

cloud service delivery model signifies that security management is necessary if its

adoption is to be fostered [5]. Cloud computing extends computing resources across

the corporate perimeter, resulting in control being lost over its information assets. A

security governance function therefore needs to be established for the management

Rebollo O., Mellado D. and Fernández-Medina E..

Introducing a Security Governance Framework for Cloud Computing.

DOI: 10.5220/0004601400240033

In Proceedings of the 10th International Workshop on Security in Information Systems (WOSIS-2013), pages 24-33

ISBN: 978-989-8565-64-8

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

levels, with a clear security strategy [6]. Regardless of the cloud model adopted, secu-

rity and governance must lead and guide the adoption of cloud services [7]. Security

policies and measures involve a third party when moving services to cloud compu-

ting, and this loss of control emphasizes the need for security governance within the

enterprise and for the transparency of cloud providers [8, 9]. Security governance, as

part of the company’s corporate governance, is the most suitable path by which to

gain control of security processes and guarantee an alignment with business strategies

[10].

An Information Security Governance (ISG) framework that tackles all the security

issues in the cloud environment in a uniform manner is not currently available. Alt-

hough there are many technological approaches that can improve cloud security, there

are currently no comprehensive solutions [11]. Our previous research shows that

existing efforts that attempt to deal with cloud computing security do not detail the

governance aspects [12]. In this paper we therefore propose a first approach to a secu-

rity governance framework that considers the particularities of cloud deployments

(ISGcloud). The ISGcloud framework compiles existing published guidance works on

the field, and groups them homogeneously to provide a model that is capable of deliv-

ering an ISG process for the cloud services. ISGcloud is led by standards, resulting in

an alignment with actual best practices. With the use of standards we aim to increase

the quality and reliability of the results and simplify the governance process while

guaranteeing the security of the cloud service and promoting the reuse of resources

[13].

The perspective followed in our approach is process oriented, thus facilitating its

inclusion in any organisation. In order to deploy security governance, we have chosen

the model published in the ISO/IEC 38500 standard, which states that directors should

perform governance by using three main processes: Evaluate, Direct and Monitor

[14]. The Evaluate-Direct-Monitor cycle will therefore become a core process of our

framework. We also propose the addition of a fourth process, namely Communicate,

owing to the relevance of disseminating security knowledge within the organisation,

particularly as regards the adoption of new services such as those of cloud computing.

In addition to the four core processes highlighted, we consider that it is paramount

to identify a cloud service lifecycle as part of our objective of defining an ISG de-

ployment. The relationship between the cloud client and its provider, as with any

other outsourcing service, leads to new risks throughout its lifecycle phases that must

be managed in order to guarantee the service’s success [15]. The ISO/IEC 27036

standard [16], despite being in its draft stage, outlines security controls to be ad-

dressed in an outsourcing lifecycle. We have adapted this standard to a generic cloud

computing lifecycle in order to identify the steps in the processes.

This paper is structured as follows: the following section contains related work in

the fields of security governance and cloud computing that have influenced our re-

search; Section 3 provides an overview of our ISGcloud framework, describing its

core processes and the proposed lifecycle of a cloud service; Section 4 presents a

detailed description of our framework’s activities and tasks; finally, Section 5 con-

tains a discussion of our contribution and future work.

2 Related Work

This section briefly summarises those proposals published in recent years whose ob-

jective is to tackle security issues from the governance perspective. We focus particu-

larly on those dealing with cloud computing deployments.

A key reference, when discussing IT Governance, is Control Objectives for Infor-

mation and related Technology (COBIT) [17]. COBIT is a framework for IT Govern-

ance which introduces a set of 37 processes grouped into five domains; detailing the

control objectives, metrics, maturity models and other management guidelines for

each of these processes.

The International Organisation for Standardization (ISO) has a wide portfolio of

standards, some of which are dedicated to security and governance aspects. The

ISO/IEC 27001 standard is of particular interest to our objective as is related to In-

formation Security Management Systems, which can be used by organisations to

develop and implement a framework for managing the security of their information

assets and prepare for an independent assessment applied to the protection of their

information [18].

These two frameworks are analysed in [19], in which some other references are al-

so considered. Of these approaches it is worth highlighting the ISG proposal [20],

which defines an information security framework, clearly distinguishing between the

governance and management sides, in addition to describing the tasks, roles and re-

sponsibilities of any key individual in an organisation.

The main drawback of using these frameworks when dealing with cloud computing

security is that they have not been specifically designed for this environment, and

therefore lack the particularities that arise in this situation. The special security re-

quirements that arise when dealing with a cloud computing deployment have led to

many publications that attempt to tackle these matters. Existing cloud security pro-

posals are reviewed in [21], and the most representative are introduced below.

The security guidance published by the Cloud Security Alliance provides practical

recommendations on reducing the associated risks when adopting cloud computing

[22]. The guidance proposes recommendations that help identify threats in the cloud

context and choose the best options to mitigate vulnerabilities. Organisations using

this guide must select which lines are applicable to their cloud deployment. These

lines range from governance to operation issues.

A security risk assessment has been proposed by the European Network and In-

formation Security Agency (ENISA) to provide both a framework to evaluate risks

and security guidance for existing users [23]. The risk assessment evolves into an

information assurance framework, which includes controls from the ISO 27000 fami-

ly of standards.

In order to provide an understanding of cloud computing and its related risks, the

Information Systems Audit and Control Association (ISACA) has published [24].

This proposal tackles governance and security aspects separately, and contains refer-

ences to additional publications in order to complement the framework.

The systematic review performed in [12] analyses all of these cloud security pro-

posals together with other literature publications. The results of this comparison show

many lacks in existing frameworks as regards the comprehensive embracement of

security governance in cloud computing environments.

There are various core governance processes approaches in literature; some ISO

standards, such as that of the ISO/IEC 27001, propose adopting the Plan-Do-

Check-Act (PDCA) process model to implement the governance of the security of

information systems and networks [18]. We consider this approach and the ISO/IEC

38500 (Evaluate-Direct-Monitor) as valid and plausible, since both reflect the estab-

lishment of iterative processes that provide feedback on the activities performed.

Similar approaches with which to define these processes can also be found in

literature. For instance, in [25] the authors define a security governance framework

based on the Direct-Control cycle. Upon examining this process it was discovered that

it shares many dualities with the aforementioned ones, as it differentiates the

governance and management domains, and applies the iterative cycle to the strategic,

tactical and operational levels.

3 Overview of the ISGcloud Framework

This section provides a general overview of our proposed ISGcloud framework. We

describe how the process has been developed by considering the specificities of a

cloud computing environment and what links to existing standards it includes.

As previously mentioned, the core processes of ISGcloud are based on the

ISO/IEC 38500 standard. According to this standard, the governance cycle follows

three processes: a) Evaluate the current and future use of IT; b) Direct preparation and

implementation of plans and policies to ensure that the use of IT meets business

objectives; and c) Monitor conformance to policies, and performance against the

plans [14]. We additionally incorporate the Communicate process which adds the

dissemination of the knowledge that is required in ISG. From here on, we shall refer

to these iterations as the Evaluate-Direct-Monitor cycle.

This iterative governance cycle is also similar to the COBIT 5 proposal, where the

Evaluate-Direct-Monitor cycle is intended for IT governance processes, and a Plan-

Build-Run-Monitor cycle is suggested for the management areas [17].

The process of implementing and managing ISG in cloud computing is closely

bound to the service offered by the cloud provider and consequently with its lifecycle.

Taking the ISO/IEC 27036 standard [16] as a basis, we propose the following generic

cloud computing lifecycle: 1. Planning / Strategy Definition; 2. Cloud Security

Analysis; 3. Cloud Security Design; 4. Cloud Implementation / Migration; 5. Secure

Cloud Operation; and 6. Cloud Service Termination.

We intend to use the proposed lifecycle to develop a framework that will be

suitable for all cloud deployments. Depending on the details of the cloud

implementation or even on whether the cloud service is already in use, practitioners

will be able to discard some of the proposed activities and tailor those remaining to

their needs.

The four ISG processes constitute one dimension of the ISGcloud framework, and

the six activities of the cloud computing lifecycle become a second dimension. We

therefore depict our framework in a bi-dimensional perspective, in which the cloud

services traverse the six activities in which successive Evaluate-Direct-Monitor cycles

are held. The relationship between the core security governance cycle and the cloud

lifecycle is shown in Fig. 1. The front of the triangular prism represents the four main

security governance processes (Evaluate, Direct, Monitor and Communicate) that are

executed iteratively in each activity of the process. The lateral side of the prism

depicts the consecutive activities of the cloud service lifecycle through which security

governance is implemented.

Fig. 1. Overview of the ISGcloud framework.

Surrounding the prism in Fig. 1 are some of the most relevant aspects to have

influenced the security governance activities and which must therefore be considered

in our framework. The left-hand side of the figure contains those issues that are

internal to the organisation, while the right-hand side lists external matters. The

inclusion of standards and best practices has been represented over the cloud service

lifecycle in order to reflect the primordial importance of these contributions to our

framework. Although we propose some relevant standards, these guidelines may

already exist and be deployed within the organisation, or can be obtained from

external sources.

4 ISGcloud’s Activities

Having introduced the core processes of our cloud security governance framework

and its main components, this section details the process structure throughout the

cloud service lifecycle.

The user roles involved in the proposed framework include personnel from the

whole organisation. The governance activities require the active involvement of

senior officers, high executives and managers, and therefore participate along with

other lower level roles. Since senior officers are responsible for the organisation’s

governance processes, they are involved in all the activities, signifying that they need

to be informed of ISGcloud’s evolution and approve the results of its tasks.

All the activities should be performed iteratively, following the core principles of

our framework. This feedback will allow practitioners to return to activities that have

previously been accomplished with new output products that may contain additional

information to perform another cycle. The remainder of this section details the tasks

proposed in each activity along with a brief description.

Evaluate

Direct Monitor

Communicate

Businessprocesses

Businesspressures/needs

Employees/users

Internalthreats

ITInfrastructure

CloudProvider

Regulations

Externalthreats

ITAdvance

ORGANISATION

INTERNAL

EXTERNAL

4.1 Activity 1: Planning /Strategy Definition

The first activity of the ISGcloud framework is designed as an introductory process to

establish the foundations needed for the remaining activities.

Task 1A: Establish Information Security Governance Structure. Given the

importance of security governance, the intention of this task is to introduce ISG into

the organisation’s culture. Senior officers and high executives, who have knowledge

of the company’s structure, mission and goals, are in charge of identifying the

participants, grouping them in teams by affinity and assigning their responsibilities.

The governance process involves the whole organisation, signifying that the

relationships among the different management levels and the reporting lines need to

be clearly defined. This task comes up with the ISG strategic plan that covers all these

issues and includes the top-level policies concerning security governance.

Task 1B: Define Information Security Program. Once an effective governance

structure and top-level security policies have been defined, then an Information

Security Program must be developed. This program consists of a series of activities

that support the enterprise risk management plan and result in the development of the

security strategy and policies [26]. This task must be performed co-ordinately by IT

and security managers and senior officers, in order to guarantee that the security

program is aligned with the business objectives.

4.2 Activity 2: Cloud Security Analysis

The second activity focuses on performing various analyses related to the security of

the cloud service. These analyses are developed according to the governance structure

and the Information Security Program elaborated in the former activity.

Task 2A: Define Information Security Requirements. The first task in this activity

has the objective of translating the strategic security policies and high level threats

defined with the security program into more detailed requirements. Ensuring a

complete alignment with the organisation’s mission, the goals are translated into

security requirements. This task requires a previous evaluation of existing standards

and guidelines that are suitable for the organisation. When defining these

requirements it is important to start considering the cloud service that the organisation

intends to implement and its related deployment. Hence it is in this step when the

ISGcloud framework begins its relationship with the cloud computing environment.

Task 2B: Cost/benefit Analysis of Available Cloud Options. Once the security

requirements and security policies have been defined, the organisation needs to

evaluate the cloud options that are available for the services being deployed. This

evaluation is performed in this task through cost/benefit analyses that include the cost

of effective governance to manage risk and ensure regulatory compliance [27] and the

value added by the cloud service. These analyses must include security considerations

of the different candidate cloud providers in relation to the cloud service model

chosen. Although it is an early estimation, the business case provides a first economic

approach as regards the organisation’s cloud service security prospects.

Task 2C: Cloud Risk Analysis. The third analysis included in this activity is a cloud

security risk analysis. The objective of this task is to provide an understanding of the

cloud service security risks identified and to define management processes for these

risks. Like any risk assessment, this includes the identification of the information

assets with their related threats and vulnerabilities, and the definition of procedures to

manage the risk and counteract them. We recommend using the Information

assurance framework defined in [23] by ENISA, which assists in following these

steps.

4.3 Activity 3: Cloud Security Design

The objective of ISGcloud’s third activity is to provide a comprehensive design of the

security governance that will be implemented together with the cloud service.

Task 3A: Define SLAs and legal contracts. Like any outsourcing service, cloud

computing services need adequate service level agreements (SLAs) to be properly

managed. Successful security governance is achieved through an appropriate

translation of the organisation’s security requirements into agreements with its cloud

provider in order to manage and minimise risks. These agreements should include not

only legal clauses, but also a complete group of security measures, which will be the

starting point for the subsequent audit and monitoring tasks. SLAs, as part of the

iterative governance cycle, must be periodically reviewed with the purpose of

modifying detected lacks and improving the cloud service’s security management.

Task 3B: Establish Information Security Roles and Responsibilities. The security

design requires a detailed establishment of responsibilities within the organisation.

This assignment depends to a great extent on the governance structure defined in the

first activity. This task demands an identification of the information assets, in order to

define the ownership and responsibility of each one.

Task 3C: Specify Cloud Service Monitoring and Auditing. This is a key task in the

security design as it specifies the conditions under which the cloud service will be

monitored. The organisation defines the processes and metrics needed to perform

security audits based on the previously defined SLAs. The results of this activity

determine how the Monitor and Evaluate processes of the iterative cycle will be

executed in the operation activities.

Task 3D: Define Applicable Security Controls. The last task in the design activity

is focused on defining the security controls. Based on the risk analysis, the

organisation must develop the security measures that it will apply both during the

cloud service operation and also in cases of incidents or major disasters. This task can

be performed by following any of the existing security standards, such as ISO/IEC

27001 [18].

4.4 Activity 4: Cloud Implementation / Migration

Once the security design has been completed, then the cloud service implementation

takes place. The execution of this activity varies depending on whether the cloud

service implemented has been previously used in the organisation or whether it is a

migration from one cloud provider to another.

Task 4A: Secure Cloud Implementation. This task focuses on the security during

the service implementation and the parallel modification of the organisational security

processes. Additional security controls are needed in the migration, some of which

will depend on the type of cloud deployment. Along with the service implementation,

the organisation’s processes are adapted to the newly designed specification.

Task 4B: Educate and Train Staff. The extension of the cloud service security

issues within the organisation is a key governance process. Although the

Communicate process should have increased the security awareness in previous

activities, it is in this task in which a global training plan is developed, and each

member of the staff is educated according to his/her participation in the cloud service.

4.5 Activity 5: Secure Cloud Operation

The fifth activity of ISGcloud is devoted to the cloud service operation. The previous

activities can be considered as time delimited, but it is generally difficult to fix time

limits to the operation since it usually has an indefinite duration. This is why the pro-

posed core iterative cycle is especially relevant in this activity.

Task 5A: Cloud Security Operation. The security operation task reflects the

successive iterations of the governance cycle. This cycle requires a precise design of

the processes, so that every participant can play their defined role. The continuous

improvement process may produce modifications to products from previous activities,

such as the Information Security Program or the Risk Analysis. If so, it may be

interesting to revisit previous activities, even while the cloud service is operating.

Successful security governance not only requires regular service measurement, but

also an adequate prioritization of the programs and regular reporting of security

issues, which may include recommendations for corrective and preventive actions.

Task 5B: Communicate Information Security within the Organisation. This task

reflects the continuous communication process that takes place within the

organisation to maintain security awareness and permit the extension of new policies.

Although this task could also be included in the previous one (Cloud security

operation), the differences between the Communicate process and the Evaluate-

Direct-Monitor cycle suggest this separation, in a more illustrative and understandable

manner.

4.6 Activity 6: Cloud Service Termination

The objective of the last activity is to provide the service termination with security.

Task 6A: Cloud Service Termination. This task includes the steps needed to

guarantee a secure service termination and information retrieval from the cloud

provider, whether the service is transferred to another provider or is finally discarded.

The main outputs of this task are the security reports that contain the knowledge

gained by the organisation, which can be reused in successive security governance

iterations.

5 Conclusions

Several research efforts concerning cloud services’ security have been published, but

we have spotted a lack of a security governance framework that takes into account the

particularities of cloud computing. The main contribution of this work is the proposal

of a comprehensive ISG framework (ISGcloud) that is intimately linked with the

cloud service lifecycle. The objective of ISGcloud framework is to provide practition-

ers with a systematic approach that can be easily followed to guarantee successful

security governance, independently of the type of cloud deployment.

In order to being able to understand the framework, we have introduced a brief

description of ISGcloud’s activities and tasks. However, we are aware that more

detail is needed before our proposal is put into practice. We plan to continue our

research expanding the proposed tasks, so that each one identifies its involved steps,

the user roles that participate in its execution, its input and output products, and

proposed guidance documents that may help to achieve its objectives. Our future

research should allow us to provide a structured process approach that facilitates its

integration with other organisational processes and its reusability, which may be

modelled following the Software & Systems Process Engineering Meta-Model

Specification (SPEM) [28]. Following this line, we plan to complement the SPEM

definition of the framework’s activities with a supporting tool, such as EPF

Composer.

Furthermore, we intend to be able to carry out a practical utilizacion of ISGcloud

framework in a real life scenario, so that our theoretical research is put into practice to

evaluate and validate its utility. We shall continue to validate our proposal by

contacting candidate organisations that intend to develop cloud services or have

already deployed them, and are interested in security governance issues related to the

cloud environment.

Acknowledgements

This research is part of the following projects: MEDUSAS (IDI-20090557), financed

by the Centre for Industrial Technological Development (CDTI), ORIGIN (IDI-

2010043(1-5)) financed by the CDTI and the FEDER, SERENIDAD (PEII11-037-

7035) financed by the "Viceconsejería de Ciencia y Tecnología de la Junta de Comun-

idades de Castilla- La Mancha" (Spain) and FEDER, and SIGMA-CC (TIN2012-

36904) and GEODAS (TIN2012-37493-C03-01) financed by the "Ministerio de

Economía y Competitividad" (Spain).

References

1. Mell, P., Grance, T.: The NIST Definition of Cloud Computing. SP 800-145. National

Institute of Standards and Technology (NIST) (2011)

2. Gartner: Gartner's Hype Cycle for Cloud Computing. (2012)

3. Chen, Y., Paxson, V., Katz, R.H.: What’s New About Cloud Computing Security? Univer-

sity of California, Berkeley (2010)

4. Hamlen, K., Kantarcioglu, M., Khan, L., Thuraisingham, B.: Security Issues for Cloud

Computing. International Journal of Information Security and Privacy 4 (2010) 39-51

5. Subashini, S., Kavitha, V.: A survey on security issues in service delivery models of cloud

computing. Journal of Network and Computer Applications 34 (2011) 1-11

6. Bisong, A., Rahman, S.S.M.: An overview of the Security Concerns in Enterprise Cloud

Computing. International Journal of Network Security & Its Applications (IJNSA) 3 (2011)

30-45

7. Avanade: Global Survey: Has Cloud Computing Matured? Third Annual Report , June

2011 (2011)

8. Rosado, D.G., Gómez, R., Mellado, D., Fernández-Medina, E.: Security Analysis in the

Migration to Cloud Environments. Future Internet 4 (2012) 469-487

9. Zhu, Y., Hu, H., Ahn, G.-J., Yau, S. S.: Efficient audit service outsourcing for data integrity

in clouds. Journal of Systems and Software 85 (2012) 1083–1095

10. Mellado, D., Sánchez, L.E., Fernández-Medina, E., Piattini, M.: IT Security Governance

Innovations:Theory and Research. IGI Global, USA (2012)

11. Rong, C., Nguyen, S.T., Jaatun, M. G.: Beyond lightning: A survey on security challenges

in cloud computing. Computers and Electrical Engineering 39 (2013) 47-54

12. Rebollo, O., Mellado, D., Fernández-Medina, E.: A Systematic Review of Information

Security Governance Frameworks in the Cloud Computing Environment. Journal of Uni-

versal Computer Science 18 (2012) 798-815

13. Fung, A.R.-W., Farn, K.-J., Lin, A. C.: Paper: a study on the certification of the information

security management systems. Computer Standards & Interfaces 25 (2003) 447-461

14. ISO/IEC: ISO/IEC 38500:2008 Corporate governance of information technology (2008)

15. Chou, D.C., Chou, A.Y.: Information systems outsourcing life cycle and risks analysis.

Computer Standards & Interfaces 31 (2009) 1036–1043

16. ISO/IEC: ISO/IEC 27036 - IT Security - Security techniques - Information security for

supplier relationships (draft)

17. ITGI: Control Objectives for Information and related Technology (COBIT 5) (2012)

18. ISO/IEC: ISO/IEC 27001:2005 Information technology - Security techniques - Information

security management systems - Requirements (2005)

19. Rebollo, O., Mellado, D., Sánchez, L.E., Fernández-Medina, E.: Comparative Analysis of

Information Security Governance Frameworks: A Public Sector Approach. The Proceed-

ings of the11th European Conference on eGovernment – ECEG 2011, Ljubljana, Slovenia

(2011) 482-490

20. Solms, S.H.v., Solms, R.v.: Information Security Governance. Springer (2009)

21. Rebollo, O., Mellado, D., Fernández-Medina, E.: A Comparative Review of Cloud Security

Proposals with ISO/IEC 27002. Proceedings of the 8th International Workshop on Security

in Information Systems - WOSIS 2011, Beijing, China (2011) 3-12

22. Cloud Security Alliance: Security Guidance for Critical Areas of Focus in Cloud Compu-

ting V3. (2011)

23. Catteddu, D., Hogben, G.: Cloud Computing Security Risk Assessment - Benefits, risks and

recommendations for information security. European Network and Information Security

Agency (ENISA) (2009)

24. ISACA: IT Control Objectives for Cloud Computing. (2011)

25. Solms, R.v., Solms, S. H. B.v.: Information Security Governance: A model based on the

Direct–Control Cycle. Computers & Security 25 (2006) 408-412

26. Allen, J.H., Westby, J. R.: Governing for Enterprise Security Implementation Guide. Soft-

ware Engineering Institute - CERT (2007)

27. Miller, J., Candler, L., Wald, H.: Information Security Governance - Government

Considerations for the Cloud Computing Environment. Booz Allen Hamilton (2009)

28. OMG: Software & Systems Process Engineering Meta-Model Specification v.2.0.

http://www.omg.org/spec/SPEM (2008)
