Enhancing Query Expansion for Tag-based Social

Image Retrieval

Amel Ksibi, Anis Ben Ammar and Chokri Ben Amar

REGIM: REsearch Groups on Intelligent Machines,

Sfax University, BP 1173, Sfax, 3038, Tunisia

Abstract. Recently, extensive research efforts have been dedicated to tag-based

social image search which enables users to formulate their queries using tags.

However, tag queries are often ambiguous and typically short yielding to retrieve

irrelevant images in top ranked list. To overcome this problem, an effective strat-

egy is to produce diverse images in top ranking list covering various aspects of the

query. In this context, we propose a Multi-view Concept-based Query Expansion

(MVCQE) process, using a predeﬁned list of semantic concepts and following

three main steps. First, we harvest social knowledge to capture different con-

texts related to the query. Second, we perform a Multi-view Concepts weighting

by applying concept-based query expansion for the initial query and for each of

its contexts. Third, we select the most representative concepts using an adaptive

threshold with respect to the dispersion of concept weights. Experiments using

ambiguous queries over the NUS-WIDE dataset conﬁrm the effectiveness of our

process to improve the diversiﬁcation compared to well known query expansion

approaches . . .

1 Introduction

With the proliferation of Web 2.0, photo-sharing services are hosting a tremendous

volume of digital images associated with their users generated tags [11]. Thus, tag-

based social image retrieval expect to be an intuitive way to perform search, which

presents two speciﬁc challenges:

– Tags Mismatch: It occurs when tag query fails to appear in tags of relevant images

due to either the use of synonyms, or to the incomplete semantic representations

(e.g. not containing the tag)[4]

– Tag Ambiguity: It occurs when a query is interpreted with several meanings other

than user’s expectation. [14]

In literature, these two challenges have been well studied separately. In one sight, for the

’tags-mismatch’ problem, concept-based approaches have been well intended to over-

come it by searching social images based on concept matching rather than tag matching.

Indeed, queries and images are transformed into semantic concepts vectors as a stan-

dardized representation[6],[7]. In the other sight, to tackle the ’tag ambiguity’ problem,

an effective approach is to provide diverse results that cover multiple topics underlying

a query. To this end, diversity-based approaches can be categorised as either explicit or

Ksibi A., Ben Ammar A. and Ben Amar C..

Enhancing Query Expansion for Tag-based Social Image Retrieval.

DOI: 10.5220/0004603500420051

In Proceedings of the 2nd International Workshop on Web Intelligence (WEBI-2013), pages 42-51

ISBN: 978-989-8565-63-1

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

implicit [10]. Explicit approaches seek to promote images with maximum coverage of

query aspects as characteristic of the query itself, while implicit-based approaches rely

on characteristics of the retrieved images in order to identify diverse images, under the

assumption that similar images will cover similar aspects. In current study,we will fo-

cus only on explicit approaches. Speciﬁcally, we will be interested in query expansion

techniques, which aims to alleviate the query ambiguity by adding meaningful terms

from a suitable knowledge resource. In literature, query expansion has been shown as a

conﬁrmed way for improving retrieval effectiveness in term of Recall value. However, it

can generate topic drift problem when too broaden the query. Thus, different challenges

are identiﬁed:

1. Which knowledge resource should be retained reﬂecting a sufﬁcient coverage of

the dynamic human knowledge?

2. How to optimize the coverage of all query aspects underlying an ambiguous query?

3. How many terms should be added and how to assign weights to each one without

hampering the overall precision?

In this paper, we will harness the semantic representation and the social knowledge

not only to solve tag-mismatch problem, but also to cope with query ambiguity chal-

lenge. Indeed, we will reformulate the tag query using a new concept-based query ex-

pansion process called ”Multi-view concept-based query expansion” by weighting se-

mantic concepts from different view or context, aggregating the obtained weights and

selecting the most representative ones using a dynamic threshold.

This paper is organized as follows: In section 2, we provide an overview of the

existing orientations for diversifying search results. In section 3, we present the overall

architecture of the proposed tag-based social image retrieval system and we detail the

Multi-view concept based query expansion process. In section 4, we give experimental

results.

2 Overview of Query Expansion Approaches for Social Image

Retrieval

Query expansion process has been considered as an intuitive and promising way to

diversify results by adding new meaningful terms from knowledge resources[12]. In

literature, different knowledge bases have been exploited for query expansion. For in-

stance, in [9], authors proposed to expand query through an open-source knowledge

such as WordNet and ConceptNet based on synonyms and concepts. Myoupo et al.[8]

proposed to reformulate queries using Wikipedia Knowledge by adding terms that are

closer to the query. Similarly, Hoque et al. [2] explored Wikipedia resources to en-

sure query expansion. Given an ambiguous query, they attempted to capture its various

aspects, and for each aspect, a dynamic number of terms pertaining to the query were

discovered from wikipedia. Weinberger et al.[14] introduced a new tool to disambiguate

a tag query using a probabilistic framework. In this work, ambiguity is detected when

the same tag generates two tags that occur in two divergent contexts.

The aforementioned query expansion approaches are inﬂuenced by the number of

added terms which affects results diversiﬁcation. In fact, this number can be considered

Fig. 1. Flowchart of the proposed tag-based social image retrieval.

as a diversiﬁcation trade-off where the more added terms are, the higher the diversity

is. Typically, this trade-off is uniformly optimized by maximizing the average diversi-

ﬁcation performance on a set of training queries. However, not all queries are similarly

ambiguous. Thus, different queries might beneﬁt from different trade-off since any uni-

form choice of this trade-off for all queries would be suboptimal. This challenge has

been studied in social image retrieval by Hoque et al.[2]. They proposed to automat-

ically estimate the trade-off based on the level of ambiguity of the query itself. this

trade-off denotes the number of most related concepts within the query expansion pro-

cess based on the number of senses of the query as determined by Wikipedia. The main

weakness of this approach consists in using lexical resources such as Wikipedia to ex-

tract concepts and their weights. Such knowledge resource may only extract the lexical

relatedness query tag and extracted concepts and cannot reﬂect the visual relatedness

between them.

3 Mutli-view Concept-based Query Expansion for Tag-based

Social Image Retrieval

In this section, we will present the overall architecture of the proposed retrieval pro-

cess. Then, we will give a preliminary overview about concept-based query expansion

approach(CQE). Finally, we will describe the Muti-view concept-based query expan-

sion process.

3.1 Overall Architecture of the proposed Retrieval System

The ﬂowchart of the proposed social image retrieval system is illustrated in ﬁgure 1:

Given a set of N pre-deﬁned concepts, we model each image x

in the collection by a

vector C

= {c

, c

, .., c

} containing concept weights using the annotation approach

described in [5]. Each vector deﬁnes the semantic representation underlying an image.

Take the tag query ”Apple” as an example, when ”Apple” is submitted to our tag-

based social image retrieval system, a step of Multi-view concept based query expansion

is performed by aggregating, for each concept, the associated weights obtained from dif-

ferent views. This step is achieved by selecting the most appropriate concepts that cap-

ture the different meanings of the query using a dynamic threshold per-query. We note

the expanded query C

by a vector {c

, c

, .., c

}, An inverted ﬁle is, then, constructed

to reduce the search space by selecting images having at least one selected concept by

the query. We denote by D

= {x

, x

, .., x

} the set of vectors corresponding to

images that are associated with the set of query concepts C

. This collection, which is a

part of the large set D = {x

, x

, .., x

|D|

} ,is obtained by the aforementioned inverted

ﬁle generation.

A step of query-images matching is applied by estimating the cosine similarity be-

tween the expanded query vector C

and each image vector x

among sub-collection

. Once the relevance scores are estimated for all images in the selected collection,

these images are ranked by relevance. Generally, query expansion results in a gain in

recall often compensated by the corresponding loss in precision, since the integration

of some query terms may be less plausible and hence lead to topic drift. To remedy this

problem, we apply a relevance re-ranking model using random walk with restart pro-

cess as such we move relevant images upward assuming that images ,which are visually

and semantically similar to highly ranked images, should be upward [1].

Next subsection describes the process of Multi-view concept based query expansion

in details.

3.2 Multi-view Concept-based Query Expansion: MVCQE

Concept-based query expansion plays a pivotal role in the overall success of any tag-

based retrieval task. Indeed, it can implicitly tackle the query ambiguity problem by

expanding a tag query to a list of top related concepts over the semantic space. In other

words, a tag query is reformulated by assigning high scores to concepts that overlap

different aspects underlying an ambiguous query.

Intuitively, concepts related to the most known sense with respect to the ambiguous

query, will have high scores. As a result, not all aspects will be covered. In order to

reduce the inﬂuence of the most common senses, we propose a new approach called

”Multi-view concept-based query expansion” in which we extract different contexts

related to the tag in question using social knowledge and we apply concept-based query

expansion for the original query and the captured contexts. By doing such, we obtain

different query interpretations with respect to different contexts. As such, one concept

can have a high weight for a one context and low weight for another. In this situation, we

obtain the maximum of weights. As a result, we give high weights to different concepts

representing all the query aspects in different contexts.

Figure 2 illustrates the multi-view concept-based query expansion process in details:

The ﬁrst step consists in extracting semantic clusters related to a given tag-query. Each

cluster deﬁnes a view characterizing a speciﬁed context of the query. Indeed,

Fig. 2. Our proposed Multi-view Concept-based query expansion process scheme.

Fig. 3. Dispersion of concept weights for different queries.

The second step consists in performing concept-based query expansion for each

view and for the original query. By doing so, we obtain different ranking lists of weighted

concepts corresponding to each view or aspect. Then, we aggregate all ranking lists by

applying Max-Fusion for each concept to build the multi-view expanded query vector.

Thus, we assign for each concept the highest weight among the obtained weights by

different views.

The third step is concept selection where the aim is to choose an optimal subset of

concepts from the available set that are able to capture the majority of query’s aspect and

avoid topic drift risk. A challenging question is where to stop selecting concepts from a

ranked list of concept weights? In order to select concepts, concept weights ranking can

be thresholded at an arbitrary rank or score. This threshold improves the diversiﬁcation

performance of the retrieval process as it can also be considered as a diversiﬁcation

parameter: too tight threshold would extract a limited number of concepts being only

the common senses of tag query, while a too loose threshold would produce too query

broadening resulting in a topic drift problem.

Typically, this threshold is uniformly optimised so as to maximize the precision on

a set of training queries. As a result, a ﬁxed threshold is estimated for all queries. Figure

3 shows the distribution of concept weights for different queries. From this ﬁgure, it is

clear that different queries have different degree of dispersion among the weights. So,

that any uniform choice of the threshold for all queries would be suboptimal.

A main factor determining what the right threshold is, consists in weights distribu-

tion. Since this factor is query dependent, the right threshold should be selected dynam-

ically per query, not statically as most previously proposed methods in the literature.

To achieve this objective, we develop a new method deﬁning an optimal trade-off score

τ , per query, using concepts scores and their distribution as input. Indeed, we opt for

threshold optimization per-query by focusing on the dispersion degree among the scores

using the standard deviation σ. The threshold will be estimated using the following for-

mula:

τ =







∗

i=1

if σ ≥ 

∗

i=1

+ σ else

where  ∈ [0, 1] is a heuristic parameter, c

is the weight of concept i and N is the

number of concepts. On one hand, if a query’s ranking list has a high value of dispersion

among the concepts scores, it could be a clue that the ranking function has been able

to discriminate between relevant and irrelevant concepts. So, we estimate the threshold

as the average of all scores. On the other hand, if a low level of dispersion appears,

because the ranking function has assigned similar weights, it can be interpreted as it

was not able to distinguish between relevant and irrelevant concepts. In such case, we

add the value of standard deviation to the average to estimate the threshold.

4 Experiments and Results

4.1 Experiments Setup

To validate our proposed retrieval process, we conduct experiments on the challenging

real-word NUS-WIDE

dataset. It is one of the largest social media datasets which

contains 269,648 Flickr images accompanied by their associated tags and their visual

features. Each image is also indexed by 81 concepts. In addition, we select a set of

12 common ambiguous tag-queries, including Apple, Jaguar, Dove,Tiger, Pear, Jordan,

Eagle, Washington, Flash,...

4.2 Study of MVCQE Effectiveness

We study the effectiveness of MVCQE process by responding to the following ques-

tions:

– To which extent does social knowledge improve the detection of contexts perfor-

mance underlying an ambiguous query?

– What is the impact of using Multi-view on diversifying results?

– What is the impact of using adaptive threshold in MVCQE?

– What is the impact of knowledge resource selection in adaptive threshold in

MVCQE?

http://lms.comp.nus.edu.sg/research/NUS-WIDE.htm

What is the Impact of using Multi-view on Diversifying Results? In this experiment,

we compare our proposed MVCQE approach with the baseline concept-based query

expansion (CQE)[13] and tag-based query expansion(TQE)[3]. In TQE, tag query is

expanded by its top-k related tags from Flickr that frequently co-occur with the original

query.

In the following ﬁgure, we illustrate the obtained tag query reformulations for query

’Tiger’ using the aforementioned approaches. Top-15 related concepts and tags are ex-

tracted. For TQE, the coverage of query aspects is low as all the selected tags are related

to one context for query ’Tiger’. CQE outperforms TQE by capturing more aspects and

contexts than TQE. This improvement is due to the ability of the predeﬁned list of se-

mantic concepts to cover the comprehensive human world knowledge. However, we

note that top-5 selected concepts are belonging to the same context resulting in a lack

of capturing all related contexts of a tag query (such as Tiger OS). MVCQE performs

the best by detecting more diverse aspects, in top-5 selected concepts, other than in

TQE and CQE by selecting ’computer’. The success of our approach MVCQE is due to

the diversiﬁcation of top-k selected concepts yielding to diverse query aspects, yet di-

verse search results. In fact, the multi-view concepts weighting with respect to different

contexts is the responsible of this diversiﬁcation.

Fig. 4. Different interpretations for query ”Tiger”.

What is the Impact of using Adaptive Threshold in MVCQE? In this experiment,we

investigate two types of thresholding: static and adaptive. In static thresholding, the

same ﬁxed pre-selected rank threshold τ is applied to all queries. We test different

scores of τ at 0.2, 0.3 and 0.4. In dynamic thresholding, we estimate, for each query,

the optimal threshold score with respect to the dispersion degree among the concept

weights as described above. We obtain the following results in ﬁgures 5 and 6.

It can be seen from these ﬁgures that deﬁning an uniﬁed threshold score for all

Fig. 5. Obtained results for queries ’Pear’ and ’Tiger’ using different threshold values.

Fig. 6. Optimal thresholds for different queries with respect to dispersion degree among concept

weights.

queries would be suboptimal, which prove the need for dynamic thresholding. Actually,

static threshold hurts retrieval precision and leads to topic drift risk in case of low value

of threshold or under-estimation of query in case of high value of threshold.

What is the Impact of Knowledge Resource Selection in Adaptive Threshold in

MVCQE? In this experiment, we study the impact of knowledge resource choice in

the threshold estimation. For this purpose, we compare Flickr and Wikipedia resources.

Indeed, we estimate the correlation between concepts and the query using FCS mea-

sure over Flickr resources and DiscoDistance over Wikipedia resources. Figures 7 and

8illustrate the results:

From ﬁgures 7 and 8, we notice that weights of concepts for queries ’Tiger’ and

’jaguar’ are more dispersed than queries ’apple’ and ’pear’. Thus, we deduce that the

dispersion of concept weights is the main factor for determining the optimal threshold.

In addition, we note that the interval of weights repartition differ from one another.

Thus, the mean of all concept weights for each query is also a factor for determining

the focused threshold. These deductions prove the formula of our proposed threshold.

5 Conclusions

In this paper, we have presented a new query expansion process MVCQE using se-

mantic concepts representation in different query contexts. The key advantage of our

process is its ability to make effective the use of semantic concepts representation not

only for solving tag-mismatch but also for diversifying search results. In fact, we have

demonstrated that mapping a tag query in the semantic space guarantee the complete

coverage of all query aspects. Further, we have proved the necessity to diversify the

captured query aspects. For this purpose, we have analysed the query from different

contexts or views. Moreover, we have demonstrated that a step of concepts selection

Fig. 7. Weights of concepts estimation over Flickr resources.

Fig. 8. Weights of concepts estimation over Wikipedia resources.

was required. Therefore, we have proposed an automatic adaptive threshold with re-

spect to the dispersion of concept weights for a given query. Finally, we argued that the

proposed adaptive thresholding can be transferable to other applications that need an

optimal threshold in a ranking list and having only the items scores.

Our future work will involve investigation into the further reﬁnement of the pro-

posed system. More speciﬁcally, we plan to expand our MVCQE approach by capturing

hierarchical aspects from a taxonomy of semantic concepts.

References

1. Feki, G., Ksibi, A., Ammar, A. B., Amar, C. B.: Regimvid at imageclef2012: Improving

diversity in personal photo ranking using fuzzy logic. In: ImageCLEF12 (2012)

2. Hoque, E., Hoeber, O., Gong, M.: Balancing the trade-offs between diversity and precision

for web image search using concept-based query expansion. Journal of Emerging Technolo-

gies in Web Intelligence 4(1) (2012)

3. Jin, S., Lin, H., Su, S.: Query expansion based on folksonomy tag co-occurrence analysis.

In: Granular Computing, 2009, GRC ’09. IEEE International Conference on, pp. 300–305

(2009). DOI 10.1109/GRC.2009.5255110

4. Kato, M., Ohshima, H., Oyama, S., Tanaka, K.: Can social tagging improve web image

search? In: Web Information Systems Engineering-WISE 2008, pp. 235–249. Springer

(2008)

5. Ksibi, A., Ammar, A. B., Amar, C. B.: Effective concept detection using second order co-

occurence ﬂickr context similarity measure socfcs. In: CBMI, pp. 1–6 (2012)

6. Ksibi, A., Dammak, M., Ben Ammar, A., Mejdoub, M., Ben Amar, C.: Flickr-based seman-

tic context to reﬁne automatic photo annotation. In: Image Processing Theory, Tools and

Applications (IPTA), 2012 3rd International Conference on, pp. 377–382. IEEE (2012)

7. Ksibi, A., Elleuch, N., Ammar, A. B., Alimi, A. M.: Semi-automatic soft collaborative an-

notation for semantic video indexing. In: EUROCON, pp. 1–6. IEEE (2011)

8. Myoupo, D., Popescu, A., Borgne, H., Mollic, P. A.: Multimodal Image Retrieval over a

Large Database, Lecture Notes in Computer Science, vol. 6242. Springer Berlin Heidelberg

(2010)

9. Roohullah, Jaafar, J.: Exploiting the query expansion through knowledgebases for images.

In: H. Zaman, P. Robinson, M. Petrou, P. Olivier, T. Shih, S. Velastin, I. Nystrm (eds.) Visual

Informatics: Sustaining Research and Innovations, Lecture Notes in Computer Science, vol.

7067, pp. 93–103. Springer Berlin Heidelberg (2011)

10. Santos, R. L., Macdonald, C., Ounis, I.: Exploiting query reformulations for web search

result diversiﬁcation. In: Proceedings of the 19th international conference on World wide

web, WWW ’10, pp. 881–890. ACM, New York, NY, USA (2010)

11. Sun, A., Bhowmick, S. S., Nguyen, K. T. N., Bai, G.: Tag-based social image retrieval: An

empirical evaluation. JASIST 62(12), 2364–2381 (2011)

12. Tang, X., Liu, K., Cui, J., Wen, F., Wang, X.: Intentsearch: Capturing user intention for one-

click internet image search. IEEE Trans. on Pattern Analysis and Machine Intelligence 34(7),

1342–1353 (2012)

13. Wei, X. Y., Ngo, C. W., Jiang, Y. G.: Selection of concept detectors for video search by

ontology-enriched semantic spaces. Multimedia, IEEE Transactions on 10(6), 1085–1096

(2008)

14. Weinberger, K. Q., Slaney, M., Van Zwol, R.: Resolving tag ambiguity. In: Proceedings of

the 16th ACM international conference on Multimedia, pp. 111–120. ACM (2008)
