Comparative Evaluations of a Hierarchical Categorization of

Search Results based on a Granular View of Domain Ontologies

Silvia Calegari, Fabio Farina

∗

and Gabriella Pasi

DISCo, Universit`a di Milano–Bicocca, Milano, Italy

Keywords:

Granular Domain Ontology, Search Results Categorization, Evaluations.

Abstract:

The aim of this paper is to evaluate the effectiveness of a categorization approach of search results based on the

use of domain ontologies with respect to the application of standard single-label and multi-label classiﬁcation

algorithms. In particular, the approach in (Calegari et al., 2011) is considered, where the categorization process

is performed thanks to the adoption of a taxonomy of information represented as a granular view of a domain

ontology.

1 INTRODUCTION

The huge amount of information on the Web is always

in continuous overwhelming. A drawback of this situ-

ation is that for people is more difﬁcult to discover out

information that could satisfy their information needs

as by the evaluation of a query produced by a search

engine several pages of results can be obtained. In-

deed, people often use search engines to formulate

queries related to their speciﬁc interests (such as pro-

fessional activities or hobbies); and they spend a lot

of time to focusing the attention on relevant search

results. The identiﬁcation of relevant search results is

becoming a time consuming activity; to support the

user during his/her searches on the Web, in the lit-

erature several solutions have been proposed such as

personalization issues (Daoud et al., 2008; Ma et al.,

2007; Shahabi and Chen, 2003; Calegari and Pasi,

2010; Baeza-Yates and Maarek, 2011; Teevan et al.,

2005; Calegari and Pasi, 2008), relevance feedback

approaches (Salton and Buckley, 1990; Lv and Zhai,

2010; Halpin and Lavrenko, 2011; Ruthven and Lal-

mas, 2003), etc.

The research reported in this paper is related to

the problem of categorizing the results produced by

search engines in response to users’ queries. The task

is to help users in easily identifying the search re-

sults that could satisfy at best their information needs.

Twofold is the advantage of using a categorization

method for the Web: (1) a set of search results is

grouped into one or more categories, and (2) the la-

∗

Now at Consortium GARR, the Italian NREN.

bel of each category is set with a suited semantic that

expresses the meaning of the categorized search re-

sults, respectively. This way, a user can identify the

relevant search results faster.

In the literature, both unsupervised and super-

vised techniques of categorization have been pro-

posed (Carpineto et al., 2009; Sebastiani, 2002). The

focus of this paper is on unsupervised approaches that

make use of an external reference knowledge, gener-

ally a taxonomy, to associate each search result with

one or more categories of the considered resource.

For example, in (Ren et al., 2009) a general purpose

ontology to couple each search result with one cate-

gory of the ontology (single-label categorization) is

used. Instead, in (Calegari et al., 2011) a hierarchi-

cal multi-label categorization approach based on the

use of granular views of a domain ontology is pro-

posed. The usage of a domain ontology to categorize

Web search results allows to support users in easily

identifying their relevant search results than a general

purpose ontology. As (1) it avoids the problem of cat-

egorizing search results in ambiguous categories, (2)

it limits the number of categories used during the cat-

egorization process by reducing the time of selection

of the right category, and (3) people often use search

engines to formulate queries on speciﬁc interests that

refer to topical domains.

However, to deﬁne effective categorization algo-

rithms based on a domain ontology is not an easy

task as ontologies are complex structures. In (Cale-

gari and Ciucci, 2010) a method to generate a granu-

lar view of an ontology is proposed. A granular view

is a compact representation of an ontology where the

361

Calegari S., Farina F. and Pasi G..

Comparative Evaluations of a Hierarchical Categorization of Search Results based on a Granular View of Domain Ontologies.

DOI: 10.5220/0004625003610366

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2013), pages 361-366

ISBN: 978-989-8565-81-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

ontology concepts are grouped into coarser granules

based on shared properties of the original concepts.

Then, a granular view allows to manage the concepts

linked with different properties in order to deﬁne a

new subsumption relation among the analyzed con-

cepts according to common properties that they share.

The obtained granular ontology based on the new sub-

sumption relation is named granular view, and it has

less nodes (concepts) than the original domain ontol-

ogy; as a consequence a categorization process based

on this simpliﬁed representation is faster and simpler.

The objective of this paper is to evaluate the cate-

gorization method proposed in (Calegari et al., 2011),

that can be applied with different levels of accuracy

based on which information granules are selected in

the granular view of the reference domain ontology

to assess its efﬁcacy. In particular, two kinds of cat-

egorization may be performed, i.e. single-label and

multi-label. To this goal, we extend the approach de-

ﬁned in (Calegari et al., 2011) to also guarantee a

single-label categorization. To assess the effective-

ness of the single-label categorization, in this paper,

some comparative evaluations have been performed

with respect to standard single-label classiﬁers i.e.,

the Multinomial Na¨ıve Bayes, the linear SVM (i.e.

LibLinear), and the quadratic SVM (i.e. LibSVM,

classiﬁers). Moreover, the results of another kind of

evaluation are reported in this paper: the effectiveness

of the multi-label categorization has been evaluated

by comparing the search results produced by using

the original domain ontology with those produced by

using its granular view.

The paper is organized as follows: Section 2 gives

the methodology used for the multi-label and the

single-label categorization based on a granular view,

Section 3 and Section 4 present the details concern-

ing the metrics used for the evaluations, and the data

of the experiments, respectively. Finally, in Section 5

some conclusions and future activities are stated.

2 CATEGORIZATION OF

SEARCH RESULTS BASED ON

A GRANULAR VIEW

In this section, we shortly sketch the categorization

method (Calegari et al., 2011) used to associate each

search result with one or more topical granules be-

longing to the granular view, named multi-label cat-

egorization. Here, we extend the considered catego-

rization method with the case of single-label catego-

rization. The new property allows to the system to

associate each search result only with a topical gran-

ule of the granular view. This way, the categorization

method can be compared with standard single-label

classiﬁers to test its effectiveness with approaches

recognized as milestone evaluators in the literature

(see Section 3 and Section 4).

The notion of a granular view of a domain ontol-

ogy O is formally deﬁned as a pair:

= {G,R

IS−A

where G is a set of granules, and R

IS−A

is the IS-A

subsumption relation deﬁned on the set of granules

G. To generate a granular view of a domain ontol-

ogy means to group into granules the entities of O

that share some properties and properties value. From

O only the instances linked by the IS-A relation and

the properties deﬁned on them are considered. More

formal details concerning how the granular view is

obtained are reported in (Calegari and Ciucci, 2010;

Calegari et al., 2011) as this aspect is out of topic with

respect to the aim of this paper.

Multi-label Categorization. Let Res the set of

search results, then the association of a search result

∈ Res with one or more granules g

∈ G is per-

formed by two subsequent steps:

1. “Search results conceptual indexing”. Both ti-

tle and snippet of R

are indexed via the con-

trolled vocabulary constituted by G ; we denote by

Rep(R

) the set of the representative granules ex-

tracted from title and snippet

2. “Association of search results R

with granule g

”.

For each granule g

in Rep(R

) the correspond-

ing result R

is associated. The association is per-

formed by selecting the corresponding granules

from Rep(R

) to the granules linked in R

IS−A

Then, R

is recursively associated with the parent

granules of g

in the hierarchy, and Ass

) is

the set containing such granules.

Single-label Categorization. The identiﬁcation of

the more relevant topical granule is chosen by analyz-

ing the set Rep(R

) of each search result obtained as

described in the previous paragraph, i.e. Multi-label

categorization. Now, the selection of the granule is

made by considering how the granules in Rep(R

) are

organized in R

IS−A

; then, the granule is chosen by

considering the common parent granule.

A Simple Example. Let us consider the vocabulary

of the following granular view related to the Wine

Ontology

. The set of granules is G := { Marietta

Zinfandel, Mountadan Pinot Noir, Lane Tanner Pinot

http://www.w3.org/2001/sw/WebOnt/guide-src/wine

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

362

Root

Grape Wines

Red Wines

Still Red Wines

Light Red Wines

Marietta Zinfandel

Mountandam Pinot Noir

Lane Tanner Pinot Noir

Root

Grape Wines

Red Wines

Still Red Wines

Light Red Wines

Marietta Zinfandel

Mountandam Pinot Noir

Lane Tanner Pinot Noir

Figure 1: Multi-label categorization of the search result R

provided by the granular view.

Noir, Red Wines, Grape Wines, Still Red Wines, Light

Red Wines}. During a search session a user is inter-

ested in ﬁnding, for instance, information about red

wines and he/she writes the following query q=“red

wines in France”, and a list of search results is dis-

played.

By analysing the ﬁrst result R

, we have: Ti-

tle=“A guide to French Still Red Wines” and Snip-

pet=“Discover the wines of France, their history an

d valleys;...Lane Tanner Pinot Noir is a famous red

wine produced in. .. ”. From these two texts, we index

by the granules of G

. We obtain Title(R

) =Still

Red Wine and Snippet(R

) =Lane Tanner Pinot Noir.

Thus, Rep(R

) = Title(R

) ∪ Snippet(R

)={Lane

Tanner Pinot Noir,Still Red Wines}.

By considering the case of multi-label categoriza-

tion, Figure 1 depicts the situation after the applica-

tion of Step 1 and Step 2 where the result R

has

been categorized in the following granules Lane Tan-

ner Pinot Noir, Red Wines, Grape Wines, Still Red

Wines, Light Red Wines. The procedure is repeated

for each search result in Res.

By considering the case of single-label categoriza-

tion for Rep(R

), Figure 2 shows that the single cho-

sen granule is Red Wines as it is the common par-

ent granule of Lane Tanner Pinot Noir and Still Red

Root

Grape Wines

Red Wines

Still Red Wines

Light Red Wines

Marietta Zinfandel

Mountandam Pinot Noir

Lane Tanner Pinot Noir

Root

Grape Wines

Red Wines

Still Red Wines

Light Red Wines

Marietta Zinfandel

Mountandam Pinot Noir

Lane Tanner Pinot Noir

Figure 2: Single-label categorization of the search result R

provided by the granular view.

Wines. Again, the process is repeated for each search

result in Res.

At the end, the user gets the search results orga-

nized as a tree of granules according to the consid-

ered categorization methodology, i.e. multi-label or

single-label, respectively.

3 EVALUATIONS

As previously outlined, the ﬁrst objective is to com-

pare the effectiveness of the approach proposed in

(Calegari et al., 2011) for the task of single-label cat-

egorization with the effectiveness of the cited single-

label classiﬁers in the Introduction as deﬁned in the

Weka

toolkit. To this aim the standard IR measures

of agreement, recall and precision are adopted. The

second objective is to evaluate the considered method

for the multi-label categorization task; in (Calegari

et al., 2011) a comparative evaluation of the multi-

label categorization performed on the original domain

ontology with respect to the multi-label categoriza-

tion on its granular view has been presented in terms

of agreement, recall and precision. In this paper we

http://www.cs.waikato.ac.nz/ml/weka/

ComparativeEvaluationsofaHierarchicalCategorizationofSearchResultsbasedonaGranularViewofDomain

Ontologies

363

extend and report comparative evaluations based on

different indicators, i.e. the NDCG, and the S-Recall

measures.

DCG, discounted cumulative gain, measures the

gain of an item based on its position in the result

list. In our context an item refers to a Web search

result, and for our experiments we adopted the mod-

iﬁed NDCG formulation proposed in (Agrawal et al.,

2009). This modiﬁcation explicitly models a judg-

ment value in addition to the ranking obtained by the

application of the methodology, and it normalizes the

DCG values by comparing them to an ideal rank given

by domain experts. In our case, the judgment assigned

by domain experts to each Web search result can be

either 0 (Bad) or 1 (Excellent). Formally, given a

query q:

NDCG(q) =

∑

∈G

DCG(Ass

))

DCG(Ass

exp

))

/|G

where G

∈Res

Rep(R

), and Ass

exp

) is the as-

sociation performed by experts for each search result.

The S-Recall deﬁned in (Zhai et al., 2003) is based

on ”arguments”; in our context arguments are both

topics and subtopics. S-Recall evaluates the size of

the set containing the granules obtained in response

to a query q over the total number of granules G as

S-Recall(q) =

∈Res

|G|

where C

) is the set of granules with at least an

associated result produced by the categorization pro-

cess.

4 EXPERIMENT

The method has been implemented as a standalone

service that interacts with the Yahoo! Search Engine,

and which returns to the user the categorized search

results. We conducted the experiments by using the

Wine Ontology deﬁned by the Stanford University

A granular view has been obtained from the Wine on-

tology by following the methodology in (Calegari and

Ciucci, 2010). The ﬁrst experiments aim to analyze

the behaviour of the considered categorization ap-

proach with respect to the standard single-label clas-

siﬁers mentioned in Section1. To this aim, with each

search result only the broader granule (in the hier-

archy) is associated by analyzing the set of granules

Rep(R

To generate the domain dependent data set related

to the Wine domain, we asked to four wine experts

http://www.w3.org/2001/sw/WebOnt/guide-src/wine

to deﬁne 44 topical queries and next, 880 search re-

sults have been selected. To this set of results we ap-

plied the standard test split with a percentage 70-30

to select training and test set, respectively. In order

to approximate a uniform distribution to improve the

classiﬁers prediction capability, we applied a random

re-sample on the training set.

Figure 3: Single-label Categorization.

To compare the considered categorization method

(Calegari et al., 2011) with the single-label catego-

rizations on the same data set, during the training

phase, the wine experts have acted as assessors in or-

der to labeling each search result with the more ap-

propriate granule of the granular view of the Wine

Ontology. Then, the training phase has been applied

on 1814 instances. Each instance is characterized by

the following attributes: the query, the search result,

and the granules set by the domain experts. For the

test phase, it has been necessary to set some parame-

ters for the LibSVM and the LibLIN classiﬁers. Lib-

SVM has been run with the radial basis kernel func-

tion with ν = 1.0, while for LibLIN the cost&bias pa-

rameter had a unitary value with the L

metric. The

test phase has been performed on 687 instances and

for each instance the granule chosen by the consid-

ered approaches (i.e., the Multinomial Na¨ıve Bayes,

LibLinear, LibSVM, and the single-label categoriza-

tion of Section 2, named Granular View) has been

compared with the one identiﬁed by the experts by

deﬁning the optimal solution.

Figure 3 shows that the Granular View method

improves the considered standard single-label classi-

ﬁers. It happens because the standard classiﬁers do

not consider the semantic that each search result can

have. In particular, when a search result can seman-

tically belong to more than one granule, the prob-

lem is to identify the granule that better represents

the several meanings. The single-label categoriza-

tion approach explained in Section 2 shows close re-

sults with respect to the expert expectation by prefer-

ring the common coarsest granule among the selected

ones. This way, the multiple meaning of a search re-

sult are obtained more precisely.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

364

To this experiment, the Multinomial Na¨ıve Bayes

has been chosen as it is one of the most adopted clas-

siﬁers and it is based on the assumption that each at-

tribute/feature is independent with respect to the other

ones. This is the case suited for our evaluations as

each search results has to be classiﬁed with a granule

and its choice is independent with respect to the other

granules used in the attributes set. Support Vector

Machine and linear classiﬁers are de-facto standards

for classiﬁcation problems. Even with a limited popu-

lation, LibLinear and LibSVM classiﬁer can identify

the optimal solution by obtaining results slightly less

accurate than what obtained with our single-label cat-

egorization approach.

0,3

0,35

0,4

0,45

0,5

0,55

AVG(NDCG)

0,2

0,25

0,3

0,35

0,4

0,45

0,5

0,55

@5 @10 @15 @20

cut @

AVG(NDCG)

Granular View

Ontology

Figure 4: NDCG: Multi-label categorization.

By the second experiment, the method proposed

in (Calegari et al., 2011) has been applied to com-

pare the hierarchical multi-label categorization based

on the original domain ontology (by only consider-

ing the subsumption relation) versus the hierarchical

multi-label categorization based on the granular view

of the original domain ontology.

The granular view is made up of 162 nodes,

whereas the taxonomy of the domain ontology is

made up of 219 nodes. We have compared the cat-

egorization on a set of 44 queries deﬁned by four

wine experts, and we analyzed the top 20 results at

different precision levels: @5, @10, @15 and @20.

NDCG@5 indicates that both taxonomies consider

the same results with the same ranking order, and then

the measure discounts them in a similar way. The

lower NDCG(q) values indicate that the taxonomy of

the domain ontology gives to the results a different

categorization with respect to the ones assigned by ex-

perts; instead, the use of the granular view produces

higher NDCG(q) as it preserves the ranking.

The S-Recall(q) evaluations for the categorization

provided by experts and both the taxonomies have

highlighted that a very small portion of information

is involved for each query. Table 1 shows that the

domain ontology exhibits a worse behaviour than its

granular view: several unnecessary nodes are in fact

used to categorize the search results with the conse-

Table 1: S-recall: multi-label categorization.

cut@ Expert Granular Domain

View Ontology

0.02 0.10 0.22

@10

0.03 0.15 0.28

@15

0.04 0.19 0.21

@20

0.05 0.34 0.41

quence that the user spends a lot of time in navigating

the hierarchy for discovering the search results.

5 CONCLUSIONS

In this paper we have presented some evaluations of a

method aimed at categorizing search results based on

a granular view of a domain ontology to both multi-

label categorization and single-label categorization.

In this last case, we have proposed an extension of

the considered multi-label categorization method in

order to manage cases of single-label categorization

on search results. This way, it is possible to compare

the method with standard classiﬁers such as the Multi-

nomial Na¨ıve Bayes, the LibLinear, and the LibSVM,

respectively.

To test the effectiveness of the considered multi-

label categorization approach, we have performed

new evaluations in addition to (Calegari et al., 2011)

such as NDCG and S-Recall. The granular view

has exhibited a better behaviour than the original do-

main ontology in multi-label categorization, and it has

achieved good results if compared to standard single-

label classiﬁers.

As a future research, we will consider other do-

mains, and we will evaluate the approach compared to

other standard hierarchical and deep classiﬁers (e.g.,

C4.5, random forest, Boltzman machines).

REFERENCES

Agrawal, R., Gollapudi, S., Halverson, A., and Ieong, S.

(2009). Diversifying search results. In WSDM ’09,

pages 5–14, New York, NY, USA. ACM.

Baeza-Yates, R. A. and Maarek, Y. (2011). Web retrieval:

the role of users. In Ma, W.-Y., Nie, J.-Y., Baeza-

Yates, R. A., Chua, T.-S., and Croft, W. B., editors,

SIGIR, pages 1303–1304. ACM.

Calegari, S. and Ciucci, D. (2010). Granular computing ap-

plied to ontologies. International Journal of Approxi-

mate Reasoning, 51:391–409.

Calegari, S., Farina, F., and Pasi, G. (2011). Topical cat-

egorization of search results based on a domain on-

tology. In Amati, G. and Crestani, F., editors, ICTIR,

volume 6931 of Lecture Notes in Computer Science,

pages 262–273. Springer.

ComparativeEvaluationsofaHierarchicalCategorizationofSearchResultsbasedonaGranularViewofDomain

Ontologies

365

Calegari, S. and Pasi, G. (2008). Personalized ontology-

based query expansion. In Web Intelligence/IAT Work-

shops, pages 256–259. IEEE.

Calegari, S. and Pasi, G. (2010). Ontology-based informa-

tion behaviour to improve web search. Future Inter-

net, 2(4):533–558.

Carpineto, C., Osinski, S., Romano, G., and Weiss, D.

(2009). A survey of web clustering engines. ACM

Computing Surveys, 41(3):17:1–17:38.

Daoud, M., Tamine-Lechani, L., and Boughanem, M.

(2008). Using a graph-based ontological user proﬁle

for personalizing search. In CIKM ’08: Proceeding of

the 17th ACM conference on Information and knowl-

edge management, pages 1495–1496, New York, NY,

USA. ACM.

Halpin, H. and Lavrenko, V. (2011). Relevance feedback

between hypertext and semantic web search: Frame-

works and evaluation. Web Semant., 9(4):474–489.

Lv, Y. and Zhai, C. (2010). Positional relevance model

for pseudo-relevance feedback. In Proceedings of

the 33rd international ACM SIGIR conference on Re-

search and development in information retrieval, SI-

GIR ’10, pages 579–586, New York, NY, USA. ACM.

Ma, Z., Pant, G., and Sheng, O. R. L. (2007). Interest-based

personalized search. ACM Trans. Inf. Syst., 25.

Ren, A., Du, X., and Wang, P. (2009). Ontology-based cat-

egorization of web search results using YAGO. In

In Comput. Sciences and Optimiz., pages 800–804.

IEEE.

Ruthven, I. and Lalmas, M. (2003). A survey on the use

of relevance feedback for information access systems.

Knowl. Eng. Rev., 18(2):95–145.

Salton, G. and Buckley, C. (1990). Improving retrieval per-

formance by relevance feedback. Journal of the Amer-

ican Society for Information Science, 41:288–297.

Sebastiani, F. (2002). Machine learning in automated text

categorization. ACM Comput. Surv., 34(1):1–47.

Shahabi, C. and Chen, Y.-S. (2003). Web information

personalization: Challenges and approaches. DNIS.

LNCS., 2822:5–15.

Teevan, J., Dumais, S. T., and Horvitz, E. (2005). Person-

alizing search via automated analysis of interests and

activities. In Baeza-Yates, R. A., Ziviani, N., Mar-

chionini, G., Moffat, A., and Tait, J., editors, SIGIR,

pages 449–456. ACM.

Zhai, C., Cohen, W. W., and Lafferty, J. (2003). Beyond

independent relevance: Methods and evaluation met-

rics for subtopic retrieval. In In Proceedings of SIGIR,

pages 10–17.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

366
