Using Ontology-based Information Extraction for Subject-based

Auto-grading

Olawande Daramola, Ibukun Afolabi,

Ibidapo Akinyemi and Olufunke Oladipupo

Department of Computer and Information Sciences, Covenant University, Ota, Nigeria

Keywords: Ontology, Ontology-based Information Extraction, Automatic Essay Scoring, Subject-based Automatic

Scoring.

Abstract: The procedure for the grading of students’ essays in subject-based examinations is quite challenging

particularly when dealing with large number of students. Hence, several automatic essay-grading systems

have been designed to alleviate the demands of manual subject grading. However, relatively few of the

existing systems are able to give informative feedbacks that are based on elaborate domain knowledge to

students, particularly in subject-based automatic grading where domain knowledge is a major factor. In this

work, we discuss the vision of subject-based automatic essay scoring system that leverages on semi-

automatic creation of subject ontology, uses ontology-based information extraction approach to enable

automatic essay scoring, and gives informative feedback to students.

1 INTRODUCTION

Student assessment task is usually challenging

particularly when dealing with a large student

population. The manual grading procedure is also

very subjective because it depends largely on the

experience and competence of the human grader.

Hence, automated grading solutions have been

provided to alleviate the drudgery of students’

assessments. According to Shermis and Burstein

(2013), notable systems for Automatic Essay

Scoring (AES) include IntelliMetric, e-Rater, c-

Rater, Lexile, AutoScore CTB Bookette, Page, and

Intelligent Essay Assessor (IEA).

However, most of the existing AES systems have

to be trained on several hundreds of scripts already

scored by human graders, which are used as the gold

standard from which the system learn the rubrics to

use for their own automatic scoring. This procedure

can be costly, and imprecise considering the

inconsistent and subjective nature of human

assessments. Also, most of the AES do not use

elaborate domain knowledge for grading, rather they

either use statistical or machine learning models or

their hybrids, which limits their ability to give

informative feedbacks to students on the type of

response expected from based on the course content

(Brent et al., 2010).

In this work, we present the vision of a subject-

based automatic essay grading system that uses

ontology-based information extraction for students’

essay grading, and provides informative feedback to

students based on domain knowledge. In addition,

our approach attempts to improve on existing AES

architectures for subject-based automatic grading by

enabling the semi-automatic creation of relevant

domain ontologies, which reduces the cost of

obtaining crucial subject domain knowledge. Semi-

automatic creation of domain ontology is

particularly useful for subject grading where the

only valid basis for assessment of students’

responses is the extent of their conformity to the

knowledge contained in the course content (Braun et

al., 2006). Ontology as the deliberate semantic

representation of concepts in domain and their

relationships offers a good basis for providing more

informative feedbacks in AES.

Hence, the intended contribution of our proposed

approach stems from the introduction of ontology

learning framework into AES as a precursor to

providing informative feedbacks to students.

Typically, our proposed approach employs

ontology-based information extraction which uses

basic natural language processing procedures –

tokenization, word tagging, lexical parsing,

anaphora resolution -, and semantic matching of

texts to realise automatic subject grading.

The remaining parts of this paper are described

373

Daramola O., Afolabi I., Akinyemi I. and Oladipupo O..

Using Ontology-based Information Extraction for Subject-based Auto-grading.

DOI: 10.5220/0004625903730378

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2013), pages 373-378

ISBN: 978-989-8565-81-5

 2013 SCITEPRESS (Science and Technology Publications, Lda.)

as follows. Section 2 contains a background and a

review of the related work. In Section 3, we present

the core idea of our approach, while Section 4

describe the process of ontology learning from

domain text, and some of the essential aspects of our

AES architecture. We conclude the paper in Section

5 with a brief note and our perspective of further

work.

2 BACKGROUND AND

RELATED WORK

Research on the viability of automatic essay scoring

(AES) for student assessments have been undertaken

since the 1960s, and several techniques have been

used. The first AES, called Project Essay Grade

(PEG) (Page, 1968) was implemented using multiple

regression techniques. Some other methods that have

been used for AES include: Latent Semantic

Analysis (LSA) – Intelligent Essay Assessor (IEA)

(Landauer and Laham, 2000); Natural Language

Processing (NLP) - Paperless School free-text

Marking Engine (PS-ME) (Mason and Grove-

Stephenson, 2002), IntelliMetric (Elliot, 2003), e-

Rater (Burstein, 1998); Machine Learning and NLP

- LightSIDE, AutoScore, CTB Bookette (Shermis

and Burstein, 2013); text categorization – (Larkey,

1998), CRASE, Lexile Writing analyzer (Shermis

and Burstein, 2013), Bayesian Networks - Bayesian

essay testing system (BETSY) (Rudner and Liang,

2002); Information Extraction (IE) - SAGrader

(Brent et al., 2010); Ontology-Based Information

Extraction (OBIE) - Gutierrez et al. (2012).

Experimental evaluation of many of these AES also

revealed that their scores have good correlation with

that of human graders. However, majority of these

systems cannot be used for short answer grading. An

exception to this is IntelliMetric by (Elliot, 2003). A

major drawback of many of these AES is that they

have to be trained with scripts graded by human

graders (usually in hundreds) for them to learn the

rubrics to be used for text assessment. The human

graded scripts serve as the gold standard for the

evaluation, despite the fact that human judgments

are known to be inconsistent and subjective. A more

accurate basis for evaluation should be the fitness of

student’s response to the knowledge that must be

expressed according to the course content. Also,

they lack provision for subject-specific knowledge

which limits their applicability to various subject

domains, hence they are mostly for grading essays

written in specific major languages. Therefore, they

lack ability to provide informative feedbacks that

stems from domain knowledge that can be useful to

both students and teachers (Brent et al., 2010);

(Chung and Baker, 2003).

In the category of short answer grading systems

are examples such as c-rater (Leacock, C., and

Chodorow, 2003), which is based on NLP; SELSA

(Kanejiya et al., 2003) which is based on LSA and

context-awareness; and Shaha and Abdulrahman,

(2012) which is based on integrating Information

Extraction (IE) technique and Decision Tree

Learning (DTL).

The use of semantic technology for AES, which

is the focus of our work, is relatively new, as very

few approaches have been reported so far in the

literature. The SAGrader (Brent et al., 2010)

implements automated subject grading by combining

pattern matching and use of semantic networks for

domain knowledge representation. The system is

able to provide limited feedback by identifying

domain terms that are mentioned by students.

SAGrader has limited expressiveness because a

semantic network was used instead of an extensive

ontology for domain knowledge representation. He

et al. (2009), reported the use of latent semantic

analysis, BLUE algorithm and ontology to provide

intelligent assessment of students’ summaries.

Castellanos-Nieves et al., (2011) reports an

automatic assessment of open questions in

eLearning courses by using a course ontology and

semantic matching. However, the ontology was

manually created. Also, Gutierrez et al., (2012) used

OBIE to provide more informative feedback during

automatic student assessment by using an ontology

that was manually created. However, creating

ontology manually is a costly exercise, which is not

realistic for large subject domains that will require

large and complex ontologies. Also, creation of

ontology requires high technical expertise which is

not common.

Hence, our approach intends to improve on

existing OBIE approaches by enabling the semi-

automatic creation of the ontology from domain text,

and giving informative feedbacks that stem from

domain knowledge to students, and even teachers for

both short answers grading and long essays. The

form of feedback will entail misspellings, correct

and incorrect statements, and incomplete statements,

and structure deficiency in sentence constructions.

3 OVERVIEW OF THE

APPROACH

The core idea of the proposed approach is outlined

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

374

as sequence of offline and run-time activities as

follows.

(i) Select relevant subject domain text and

information sources that can be used to train a

lexical tagger, such as OpenNLP or Stanford NLP

tree tagger – this will enable greater accuracy of

natural processing activities such as part-of-speech

tagging of words that will subsequently be

encountered in students’ scripts and teacher’s

marking guide.

(ii) Create an ontology for the subject domain

semi-automatically from textual information sources

of the domain such as text books/book chapters or

lecture notes. In cases, where such relevant domain

ontology already exists, select it to use for the

grading process by importing it into the proposed

architectural framework.

(iii) Create a meta-model schema of the marking

guide of the subject prepared by the examiner, which

will be used by the auto-grading system as basis to

associate questions to corresponding responses by

students. The meta-model is typically a graph-based

data structure (see Fig 1.) that describes the

arrangement of the questions in the exam/test that is

used as a logical template to map a student’s

response to corresponding sections of the marking

guide on a question-by-question basis. It captures

the description of each question (q1-q4) in terms of

the number of its sub-parts (a, b, c ...), its unique

identification (id), type of response expected (R) –

classified into 3 categories, list, short essay, and

long essay -, and the mark allocated (M) to the

question. The description of a question in the meta-

model primarily determines the type of semantic

treatment that is applied when extracting

information from a student’s response.

(iv) Collate students’ responses to specific

questions and pre-process the student’s response by

conducting spelling checks, identifying wrong

punctuations, and noting right or wrong use of

domain concepts. Keep track of all corrected

instances, which will be included in the feedback to

students.

(v) Extract information from student’s response

based on pre-defined extraction rules depending on

the type of expected response as contained in the

marking guide meta-model. Evaluate the lexical

structure of each sentence in the response to a

question by performing subject-predicate-object

(SPO) analysis of each sentence in order to extract

the subject (noun), predicate (verb), and object

(noun). For a correct statement, the extracted

subject, and object should correspond to specific

concepts in the domain ontology, either, in their

exact form, root form or synonym forms, while the

predicate should be valid for the concepts in the

sentence based on the taxonomy, and axioms of the

underlying ontology.

a

b

c

R

M

Figure 1: A schematic view of the marking guide meta-

model.

(vi) Perform text semantic similarity matching of

the information extracted from student’s response,

and the content of the marking guide. Two

possibilities exist, depending on the expected

response to a question. First, for questions where

short, or long essay response are expected, extract

rules using the <concept> <predicate> <concept>

pattern to analyse each sentence of the answer to that

question as contained in the marking guide. The

extracted rules are then matched semantically with

the result of SPO analysis of student’s response to

determine similarity and then scoring. Second, for

questions where the type response expected is a list,

extract a bag of concepts from the marking guide

and compare with the bag of words from student’s

response using a vector space model to determine

semantic similarity.

(vii) Execute an auto-scoring model based on the

degree of semantic similarity between a student’s

response to a question (C

) and the teacher’s

marking guide (C

) using the domain ontology for

reasoning. The semantic similarity sim(C

) in the

interval [0-1] will be the basis for assigning scores –

e.g. sim(C

) > 0.7 = full marks; 0.5 ≥

sim(C

) ≤ 0.7 = 75% of full marks; sim(C

) <

0.5 = 0.

(viii) Accumulate score obtained per question and

repeat steps (iv) - (viii) until all questions have been

graded.

UsingOntology-basedInformationExtractionforSubject-basedAuto-grading

375

4 ONTOLOGY LEARNING

FROM SUBJECT DOMAIN

TEXT

Our approach for ontology learning emulates the

ruled-based procedure for extracting seed ontology

from raw text as employed by (Omoronyia et al.,

2010; Kof, 2004). The steps of the ontology building

process are described as follows:

Document Preprocessing: This is a manual

procedure to ensure that the document from which

ontology is to be extracted is fit for sentence-based

analysis. The activities will include replacing

information in diagrams with their textual

equivalent, removing symbols that may be difficult

to interpret, and special text formatting. The quality

of pre-processing of a document will determine the

quality of domain ontology that will be extracted

from such source document.

Automatic Bracket Trailing: This is a procedure to

identify sentences/words that are enclosed in bracket

within text and to treat them contextually. Usually in

the English language, brackets are used in text to

indicate reference pointers e.g. (“Fig 2”) or (“see

Section 4”) or to embed supplementary text within

other text. The bracket trailing procedure ensures

that reference pointers enclosed in brackets are

overlooked and that relevant nouns that are enclosed

in brackets are rightly associated with head subject

or object that they refer to depending on whether the

bracket is used within the noun phrase (NP) or verb

phrase (VP) part of the main sentence. Consider the

sentence: “E-Commerce (see Fig. 1) involves the

exchange of goods and services on the Internet

based on established electronic business models

(such as Business-to-Business, Business-to-

Customer, and Customer-to-Business)”. Bracket

trailing will ensure that the reference “see Fig. 1” is

overlooked, while the noun subjects “Business-to-

Business”, “Business-to-Customer”, “Customer-to-

Business” are related to object electronic business

models. Relations derived via bracket trailing are

semantically related to relevant subject/object in text

by using a set of alternative stereotypes such as

<refers to>, <instance of> or <same as> depending

on the adjective variant used with an extracted noun.

The domain expert that is creating the ontology is

prompted to indicate his preference.

Resolution of Term Ambiguity: This involves a

semi-automated process of discovering and

correcting ambiguous terms in textual documents

using observed patterns in a sentence parse tree

(Omoronyia, et al., 2010). To do this, the observed

pattern in a particular sentence parse tree is

compared with the set of collocations (words

frequently used together) in the document in order to

identify inconsistencies. When the usage of a word

in a specific context suggests inconsistency, then the

relevant collocation is used to substitute it, in order

to produce an ontology that is more representative of

the subject domain.

Subject Predicate Object (SPO) Extraction: This

procedure uses a natural language parser to generate

a parse tree of each sentence in the document in

order to extract subjects, objects and predicates. The

structure of each sentence clause consists of the

Noun Phrase (NP) and Verb Phrase (VP). The noun

or variant noun forms (singular, plural or proper

noun) in the NP part of a sentence is extracted as the

subject, while the one in the VP part is extracted as

the object. The predicate is the verb that relates the

subject and object together in a sentence.

Association Mining: This explores the relationship

between concepts in instances where a preposition

other than a verb predicates relates a subject and an

object together. A prepositional phrase consists of a

preposition and an object (noun). Automatic

association mining is a procedure that detects the

existence of a prepositional phrase and relates it with

the preceding sibling NP. Example “E-Commerce as

a form of online activity is gaining more

prominence”. Here, E-Commerce is the subject,

while “as a form of online activity” is a prepositional

phrase containing the object “online activity”.

Association mining will recognize the inferred

relationship between “E-commerce” and “online

activity” and associate them together by using the

generic stereotype <relates to>.

Concept Clustering: This entails eliminating

duplications of concepts, and relationships in all

parsed sentences. Also, concepts are organized into

hierarchical relationships based on similarity

established between concepts.

The semi-automatic procedure for ontology enables

the domain expert to revise the seed ontology

through an ontology management GUI interface in

order to realize a more usable, and more expressive

ontology. From the ontology management GUI, the

domain expert can create ontological axioms –

restrictions such as allValuesFrom,

somevaluesFrom, hasValues, minimum cardinality

and maximum cardinality in order to facilitate

inference of new interesting knowledge.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

376

5 KEY COMPONENTS OF THE

AES FRAMEWORK

The architecture of our proposed AES will be

composed of an integration of components and

procedures that will help to realize automatic

grading via a sequential workflow. It accommodates

a series of activities that can be classified as offline

and online activities. The offline activities include:

training the natural language POS tagger on domain

text to aid recognition of domain specific terms, the

architecture will afford an interface to import the

domain text, and train the POS tagger. An ontology

learning and management module that leverages

algorithms for shallow parsing and middleware

algorithms implemented by Stanford NLP

, and

Protégé OWL 2

will used to perform ontology

extraction from domain text in order to create

domain ontology for the subject domain concerned

semi-automatically.

The other essential components of the

architecture are described as follows:

Meta-model Engine: it automatically transforms a

teacher’s marking guide into an intermediate formal

representation that forms the basis for semantic

comparison with a student’s response to questions. It

has an interface where the teacher will input

metadata information for specific questions – its

unique id, type of response expected, and mark

allocated -, and the answer to each questions. Based

on these information, the marking guide meta-model

will be automatically created.

Information Extractor: This component will

implement a Semantic Text Analyser (STA). The

STA will serve as the semantic engine of the AES

system. It will employ a combination of natural

language processing procedures, and domain

knowledge to make sense out of a student’s response

based on some pre-defined extraction rules. STA

will perform semantic text analysis such as

tokenization of text, term extraction, word sense

disambiguation, and entity extraction using the

domain ontology and WordNet.

Auto-Scoring Engine: This component will perform

semantic matching of the contents that have been

extracted from the students’ response to specific

questions and the equivalent marking guide meta-

model representation of specific questions. It will

use a pre-defined scoring model (see Section 3) to

determine score allocated to the a student’s response

http://www-nlp.stanford.edu/software/lex-parser.shtml

http://protege.stanford.edu/download/registered.html

to a question

Resources Repository (RR): This refers to the set of

data, knowledge, and open source middleware

artefacts that will enable the semantic processing

capabilities of the AES framework. All other

components of the AES framework leverage on the

components of the RR to realise their functional

objectives. A brief overview of the role of elements

of the RR is given as follows:

Domain Ontology: the domain lexicon that

encapsulates knowledge of the subject to be graded.

It is used to enable the extraction of Information

from students’ responses.

WordNet – An English language lexicon used for

semantic analysis.

MySQL – A database management system used to

implement data storage in the AES framework.

MySQL’s capability for effective indexing, storage,

and organisation will aid the performance of the

AES in terms of information retrieval, and general

usability.

Protégé OWL API – A Java-based semantic web

middleware that is used to facilitate ontology query

and management, and ontology learning from text.

Pellet – An ontology reasoner that support

descriptive logics reasoning on domain ontology

components.

Standford NLP – A Java-based framework for

natural language processing. It will provide the set

of APIs that will be used by the Information

extractor component of the AES framework.

6 CONCLUSIONS

In this paper, we have presented the notion of

ontology-based information extraction framework

for subject-based automatic grading. Relative to

existing approaches, the benefit of the proposed

framework is the semi-automatic creation of domain

ontologies from text, which is capable of reducing

cost of subject automatic essay grading significantly.

In addition, our proposed framework will improve

on existing efforts by enabling informative

feedbacks to students. It also affords greater

adaptability, because it allows for grading in several

subject domains, once there is suitable domain

ontology, and a relevant marking guide. However,

the proposed approach relies primarily on the

existence of a good quality ontology, which means

the domain expert may still need to do some

enhancements after the semi-automatic creation

UsingOntology-basedInformationExtractionforSubject-basedAuto-grading

377

process in order to realise a perfect ontology.

Nevertheless, the additional effort required will

definitely be less than the cost of creating a good

ontology from the scratch. As an ongoing work, we

intend to realize the vision of the framework is the

shortest possible time, and to conduct some

evaluations using a University context.

REFERENCES

Braun, H., Bejar, I., and Williamson, D., 2006. Rule based

methods for automated scoring: Application in a

licensing context. In D. Williamson, R. Mislevy and I.

Bejar (Eds.), Automated scoring of complex tasks in

computer based testing. Mahwah, NJ: Erlbaum.

Brent E., Atkisson, C. and Green, N., 2010. Time-Shifted

Online Collaboration: Creating Teachable Moments

Through Automated Grading. In Juan, Daradournis

and Caballe, S. (Eds.). Monitoring and Assessment in

Online Collaborative Environments: Emergent

Computational Technologies for E-learning Support,

pp. 55–73. IGI Global.

Burstein, J., Kukich, K., Wolff, S., Lu, C., Chodorow, M.,

Braden-Harder, L., Harris, M., 1998. Automated

Scoring Using A Hybrid Feature Identification

Technique. In Proc. COLING '98 Proceedings of the

17th international conference on Computational

linguistics, pp. 206-210.

Castellanos-Nieves D., Fernandez-Breis J.T., Valencia-

Garcia R., Martinez-Bejar R., Iniesta-Moreno M.,

2011. Semantic Web Technologies for supporting

learning assessment. Information Sciences, 181 (2011)

pp. 1517–1537.

Chung, G., and Baker, E., 2003. Issues in the reliability

and validity of automated scoring of constructed

responses. In M. Shermis and J. Burstein (Eds.),

Automated essay grading: A cross-disciplinary

approach. Mahwah, NJ: Erlbaum.

Elliot, S., 2003. A true score study of 11

grade student

writing responses using IntelliMetric Version 9.0 (RB-

786). Newtown, PA: Vantage Learning.

Gutierrez, F., Dou, D. and Fickas, S., 2012. Providing

Grades and Feedback for Student Summaries by

Ontology-based Information Extraction. In.

Proceedings of the 21st ACM international conference

on Information and knowledge management (CIKM

‘12), pp. 1722-1726.

He, Y., Hui, S., and Quan, T., 2009. Automatic summary

assessment for intelligent tutoring systems. Computers

and Education, 53(3) pp. 890–899.

Kanejiya D., Kumar, A., and Prasad, S., 2003. Automatic

evaluation of students’ answers using syntactically

enhanced LSA. Proceedings of the HLTNAACL 03

workshop on Building educational applications using

natural language processing-Vol. 2, pp. 53–60.

Kof, L., 2005. An Application of Natural Language

Processing to Domain Modelling - Two Case Studies.

International Journal on Computer Systems Science

Engineering, 20, pp. 37–52.

Landauer, T.K., and Laham, D., 2000. The Intelligent

Essay Assessor. IEEE Intelligent Systems, 15(5), pp.

27–31.

Larkey, S., 1998. Automatic essay grading using text

categorization techniques. Proceedings of the 21st

annual international ACM conference on Research

and development in information retrieval (SIGIR ’98).

pp. 90-95.

Leacock, C., and Chodorow, M., 2003. C-rater:

Automated Scoring of Short-Answer Questions.

Computers and the Humanities, Vol. 37 (4), pp. 389-

405.

Mason, O. and Grove-Stephenson, I., 2002. Automated

free text marking with paperless school. In M. Danson

(Ed.), Proceedings of the Sixth International

Computer Assisted Assessment Conference,

Loughborough University, Loughborough, UK.

Omoronyia, I., Sindre, G., Stålhane, T., Biffl, S., Moser,

T., Sunindyo, W.D., 2010. A Domain Ontology

Building Process for Guiding Requirements

Elicitation. In Requirements Engineering: Foundation

for Software Quality, Lecture Notes in Computer

Science Volume 6182, pp. 188-202.

Page E.B., 1968. The Use of the Computer in Analyzing

Student Essays. Int'l Rev. Education, Vol. 14, pp. 210–

225.

Rudner, L. M. and Liang, T., 2002. Automated essay

scoring using Bayes’ theorem. The Journal of

Technology, Learning and Assessment, 1 (2), 3–21.

Shaha T. A. and Abdulrahman A. M., 2012. Hybrid

Approach for Automatic Short Answer Marking.

Proceeding of Southwest Decision Sciences Forty

Third Annual Conference, New Orleans, pp. 581 -589.

Shermis M., J. Burstein (2013). Handbook of Automated

Essay Evaluation, Current Applications and New

Directions, Routledge, New York.

KEOD2013-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

378
