The Complexity Crisis

Using Modeling and Simulation for System Level Analysis and Design

Franc¸ois E. Cellier

, Xenofon Floros

and Ernesto Kofman

Swiss Federal Institute of Technology (ETH Zurich), Department of Computer Science, Zurich, Switzerland

National University of Rosario (UNR), Department of Automatic Control, CIFASIS-CONICET, Rosario, Argentina

Keywords:

System Level Modeling, System Level Simulation, Modeling and Simulation Environments, Error Tolerant

Modeling, Decentralized Simulation.

Abstract:

This paper discusses the current state of the art of modeling and simulation environments and proposes a set of

enhancements that will be necessary for such environments to meet future demands. Modeling and simulation

are categorized in accordance with the size of the models to be handled: component level modeling, device

level modeling, and system level modeling. It is shown that the requirements that modeling and simulation

environments need to satisfy in order to meet the demands of modelers are vastly different at these three

levels.

1 INTRODUCTION

In the 1970s and1980s, modelers were mostly content

simulating systems at component level. They stud-

ied the performance of a particular type of motor, for

example. Typically, such models were characterized

by half a dozen state variables and a few dozen al-

gebraic variables. A typical general purpose model-

ing and simulation (M&S) environmentsused in those

years was ACSL (Cellier, 1991; Mitchell and Gau-

thier, 1986). ACSL offered vertical sorting of equa-

tions and a (rather primitive) Macro language that en-

abled users to group the equations of sub-components

together. As of the early 1980s, ACSL also offered a

(fairly limited) set of tools for discontinuity handling.

However, this was not the important point. The most

important feature of ACSL and similar environments

was that they freed the modeler from having to under-

stand numerical ODE solution algorithms. The mod-

eler was given a selection of integration algorithms

to choose from, but did not need to understand how

the model was being simulated. ACSL supported

a strict separation of the model equations from the

solver equations, and the modeler could thus focus on

those aspects that he or she understood well, namely

describing the model in mathematical terms.

For models of larger size, tools like ACSL were

mostly useless. Larger models coded in ACSL turned

quickly into spaghetti code similarly bad as if they

had been coded in Fortran or C. Most modelers real-

ized this, and therefore, larger models were mostly

coded in general purpose programming languages,

such as Fortran. Also, many physical systems do not

lend themselves to causal modeling. The computa-

tional causality of the equations governing these sys-

tems depends on their embedding, and consequently,

causal modeling is doomed to failure. For example,

an electrical resistor is characterized by Ohm’s law:

u = R · i (1)

but the equal sign must not be interpreted as an as-

signment equal sign. Depending on the embedding

of the resistor in its surrounding circuit, the law may

need to be turned around, leading to the equation:

i =

· u (2)

For this reason, ACSL could not be used to model and

simulate electrical circuits, for example.

Special purpose modeling languages were de-

signed to offer support for modeling particular classes

of implicitly formulated models, such as Spice (Tu-

inenga, 1995) for the simulation of electrical analog

circuits, or Adams (Ryan, 1990) for the simulation

of mechanical multi-body systems. These tools were

quite successful and found wide-spread use, but they

were also limited in their applicability. If a particular

component model had not been foreseen by the de-

signers of the tool, such as maybe a Zener diode in

Spice, the tool became quickly useless.

IS-5

E. Cellier F., Floros X. and Kofman E. (2013).

The Complexity Crisis - Using Modeling and Simulation for System Level Analysis and Design.

In Proceedings of the 3rd International Conference on Simulation and Modeling Methodologies, Technologies and Applications, pages IS-5-13

DOI: 10.5220/0004986700050013

 SCITEPRESS

The 1990s saw the advent of a new class of M&S

environments that were based on the object-oriented

modeling paradigm. They offered horizontal next to

vertical sorting, thereby enabling the modeler to for-

mulate the model equations in an a-causal fashion.

Although a prototype of an object-oriented M&S en-

vironment had already been implemented in the late

1970s (Elmqvist, 1978), it took 15 more years until a

commercialand more mature implementation of these

important new concepts had become available in the

form of a commercial release of the Dymola language

(Cellier, 1991; Cellier and Elmqvist, 1993). In 1996,

the Dymola language was revised once again, and an

open standard under the name of Modelica was intro-

duced (Mattsson et al., 1997).

The Modelica initiative turned into a true

success story, and Modelica has meanwhile be-

come the de facto industry standard for model-

ing and simulating all types of physical lumped

parameter systems. The Modelica Association

(https://www.modelica.org/association) maintains the

Modelica language deﬁnition (Modelica Association,

2007) as well as the Modelica Standard Library

(MSL) (Modelica Association, 2008), to which many

researchers from around the globe contribute on a reg-

ular basis, and which by now offers large numbers of

models from many different application domains. In

the meantime, the MSL has become as valuable as if

not more valuable than the language deﬁnition itself,

and a number of both commercial and open source

implementations of the Modelica language are being

offered that all work with the MSL. Modelica con-

ferences are being held in frequent intervals that at-

tract each time several hundred attendees, and large

research projects to the amount of tens of millions of

Euros have been funded to further enhance the Mod-

elica language and the MSL.

By means of the object-oriented modeling

paradigm that is being embraced by Modelica, it has

become possible to connect component models reli-

ably to form larger models; thus, Modelica has be-

come the tool to use for device level modeling and

simulation. Typical Modelica models now are com-

prised of several dozens of state variables and several

hundreds of signiﬁcant algebraic equations, after all

of the trivial connection equations of the type:

a = b (3)

have already been eliminated.

Most Modelica implementations offer sophisti-

cated symbolic preprocessing, including algorithms

for index reduction (Cellier and Elmqvist, 1993; Pan-

telides, 1988; Zimmer, 2010), tearing of algebraic

loops (Elmqvist and Otter, 1994; Zimmer, 2010), dis-

continuity handling (Cellier, 1979; Elmqvist et al.,

1993; Otter et al., 1999), and static as well as dy-

namic state selection (Mattsson et al., 2000), to the

extent that the generated simulation code bears lit-

tle resemblance to the original model equations any

longer. The generated simulation code is at least as ef-

ﬁcient as if not more efﬁcient than the spaghetti codes

of the past, and Modelica models can even compete in

simulation efﬁciency with the special purpose model-

ing languages (Spice, Adams) designed earlier.

Information hiding is one of the most important

features of object-oriented modeling. Implementation

details are hidden inside component models that the

end user rarely needs to consult. A graphical user

interface (GUI), spearheaded once again by the de-

signers of Dymola but later standardized as part of

the Modelica language, offers the modeler the ability

to hierarchically structure his or her models in such

a way that the implementation details of the compo-

nent models of lower levels of the hierarchy are en-

capsulated and hidden from users who interface with

their model at a higher level of the modeling hierar-

chy. At each abstraction level, the models can be de-

signed to ﬁt on a single screen, which helps signiﬁ-

cantly with model understandability, debugging, and

maintenance.

Yet, and contrary to the special purpose languages

of the past, all physical knowledge is encoded at the

Modelica modeling level itself as part of the MSL.

Hilding Elmqvist, the originator of Dymola, once

proudly stated:

The most important feature of my language is

that Dymola does not understand physics.

The only knowledge that is hard encoded in the

Modelica compilers is algorithmic knowledge of how

to convert implicitly formulated sets of differential

and algebraic equations (DAEs), possibly containing

structural singularities and algebraic loops and most

likely containing discontinuities, to sets of explicitly

formulated ordinary differential equations (ODEs)

that can be processed by ODE solvers (Cellier and

Kofman, 2006). All of the physical knowledge is soft

encoded in the MSL. This is indeed a very important

feature as it makes Modelica (Dymola) much more

ﬂexible than any of the special purpose languages of

the past.

As models with several dozens of state variables

are almost invariably stiff, most Modelica environ-

ments offer a stiff system solver as their default ODE

or DAE solver. The most commonly used default

solver is DASSL (Petzold, 1983), a code based on a

variable-step, variable-order series of backward dif-

ference formulae (BDF) of different orders of approx-

imation accuracy that are well suited for the simula-

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

IS-6

tion of stiff systems. DASSL is chosen as the default

solver, because it is the most robust stiff system solver

on the market today. It can simulate almost any model

thrown at it. It does not always do so in a highly ef-

ﬁcient manner, but robustness counts for much more

than efﬁciency.

Most Modelica environments also offer a set of

alternative solvers to choose from, but the large ma-

jority of users never select a different solver, because

they don’t understand numerical methods anyway and

therefore have no inkling as to which solver might be

best suited for their particular model. Earlier versions

of Dymola offered the user many compiler switches

that could help the user in optimizing the efﬁciency

of his simulation runs. All of these compiler op-

tions (except for the selection of the solver itself) have

meanwhile been thrown out again (or at least have

been hidden behind undocumented internal compiler

switches that only some employees at Dynasim know

about), because they only confused their engineer-

ing end users. One should never ask users to supply

pieces of information that they do not understand, be-

cause otherwise, they get frustrated and walk away to

another supplier who does not ask questions that they

don’t know how to answer. Offering a palette of dif-

ferent algorithms is ﬁne, but only as long as the M&S

environment is smart enough to ﬁgure out on its own,

which of these methods to use under what conditions.

Neither Dymola nor any other Modelica imple-

mentation has been successful in entering the mar-

ket for simulations of distributed parameter systems.

Although the method of lines (Cellier and Kofman,

2006) makes it easy to convert partial differential

equations (PDEs) to sets of ODEs, the resulting ODE

models cannot be simulated efﬁciently using Dymola.

The reason is that PDEs, unless we are dealing with

toy problems, invariably lead to ODE models com-

prised of hundreds if not thousands of ODEs, and Dy-

mola is not currently capable of simulating such ODE

systems efﬁciently, at least not if the resulting equa-

tion systems are stiff.

As the step from simple component level models

involving half a dozen ODEs to device level models

containing several dozens of ODEs opened up a large

set of new questions and called for drastically dif-

ferent solutions, the same happens once again when

we proceed from several dozens of ODEs to several

hundreds or possibly thousands of ODEs, i.e., when

we advance from device level models to system level

models. These models call once again for drastically

different solutions, and that is what this paper is all

about.

2 SYSTEM LEVEL MODELING

We are building ever more complex systems. The ﬁrst

Airbus 380 was delivered to the customer with a de-

lay of roughly one year, because the producers of the

aircraft were not capable of testing the aircraft in time

in all of its potential modes of operation. The over-

all system has become too complex. The electrical

system alone is of frightening complexity. The Air-

bus 380 cable tree is 500 km long and features tens of

thousands of connections. If we are no longer capable

of testing such an aircraft in all of its potential modes

of operation before handing it over to the customer,

we should at least be able to simulate it using a real-

istic full-scale model of the aircraft capturing all fea-

tures of the vehicle using realistically accurate math-

ematical models. Such a system level description will

deﬁnitely feature many hundreds of state variables.

An air-tower training simulator should be able to

simulate not only one aircraft, but the entire ﬂeet of

air vehicles moving about the airport. As airplanes

arrive, their models should become successively more

complex on their own as they approach touch-down,

whereas the models of departing aircraft should be-

come simpler as they disappear from the vicinity of

the airﬁeld. Some pilots may be humans in training,

whereas other pilots are algorithms that form part of

the simulation. The same goes for the air trafﬁc con-

trollers. We need to simulate simultaneously the mo-

tion of the air vehicles, the communication channels,

and even weather patterns, such as wind velocity and

direction, and we should feed the visible scenery in

the form of optical information to the air tower con-

trollers training in the air-tower simulator as well as

to the pilots training in the aircraft simulator that is

located next to the air-tower simulator.

The human body is incredibly complex. At the

current time, we are barely capable of simulating one

single organ in isolation with a halfway satisfactory

degree of realism. Now the call is out for full-body

simulations. This is the only way how we can begin

to understand how our metabolism deals with drugs,

for example; which side effects are being produced in

the process. When a surgeon opens up a patient, the

body reacts violently and in many different ways to

the intervention. The heart beat rises and the blood

pressure may either rise or fall rapidly. Hormones

are being produced and dispatched by many organs

in parallel. When difﬁcult interventions need to be

made, an anesthesiologist supports the surgeon and

tries to counteract the reactions of the patient, keep-

ing the vital signs of the patient within safe bounds.

Yet, the anesthesiologist operates in a strictly reactive

mode with only limited understanding of what hap-

TheComplexityCrisis

IS-7

pens inside the patient. It is only his or her experi-

ence with similar cases that ensures that he or she will

take the correct decisions quickly and reliably. Full-

body simulations may help to improve this situation

without putting a real patient at risk, but we are still

far from being able to offer realistic full-body simu-

lations. What we know for a fact is that these models

will invariably be of high complexity and feature hun-

dreds if not thousands of state variables.

Object-oriented modeling scales generally well. If

we knew all of the equations that we need, we could

probably encode such a complex model in Modelica

without too much difﬁculties. Yet, even Dymola, the

most advanced of the current Modelica implemen-

tations, would fail miserably in dealing with any of

these models both at compile time and at simulation

time. We shall now discuss why this is the case.

3 VARIABLE STRUCTURE

MODELS

One of the models proposed above mentioned the

need to simplify aircraft models on the ﬂy. Currently,

Modelica does not offer a convenient way of describ-

ing the exchange of models at event times, and Dy-

mola is incapable of compiling and simulating such

models, even if they have been described in an indi-

rect fashion. Neither Modelica nor Dymola are cur-

rently designed to handle variable structure models.

This is a major shortcoming of Modelica, as variable

structure systems are quite common. Any mechanical

system with a clutch is a variable structure system.

When the clutch is engaged, the two axles connected

by the clutch move in unison, and consequently, the

total number of differential equations is smaller than

when the clutch is disengaged and the two axles move

separately one from the other.

Dirk Zimmer recently proposed a remedy to this

shortcomingin his Ph.D. dissertation (Zimmer, 2010).

He designed a variant of the Modelica language, that

he called Sol, that allows to formulate models that can

be activated and deactivated and even duplicated at

event times. He offered a prototype implementation

of a Sol compiler and a prototype run-time environ-

ment to simulate the compiled Sol models.

Yet, this is only a ﬁrst step. In the example of the

simpliﬁed aircraft models, for example, it should not

even be necessary to manually code aircraft models

of different complexity and encode the conditions un-

der which a model change is to occur. In principle,

it should sufﬁce to encode the most complex aircraft

model and leave it up to the compiler to generate sim-

pliﬁed versions thereof on its own using automated

model pruning techniques (Sen et al., 2009). Tests

could be automatically generated that look at the dy-

namics of the trajectories produced by the simulation,

and when the fast transients have died out, automati-

cally switch to a simpliﬁed version of the model.

4 MODEL DEBUGGING

SUPPORT

Anyone who has already modeled a decently complex

system using Modelica knows that debugging a Mod-

elica model can be quite difﬁcult. Coding a model

is easy, but when the compiler tags the model as sin-

gular, meaning that the number of equations does not

equal the number of unknowns, locating the error in

the model can be a challenge.

Tools were developed that help us reduce the like-

lihood of obtaining cryptic compiler error messages,

e.g. by balancing the model connectors (Olsson et al.,

2008). Yet the problems are still formidable. This

happens in today’s device level models. If the size of

the model grows once again by one order of magni-

tude, as this will invariably happen when we proceed

from device level simulations to system level simu-

lations, modeling errors may occur much more fre-

quently, and ﬁnding them just by looking at the code

may become a hopeless undertaking. We shall need

help in this task (Pop et al., 2012).

One possible approach might be to invoke auto-

mated model pruning. When the compiler tags a

model as singular, it automatically simpliﬁes one sub-

model after another. If the singularity disappears in

the process, the error is most likely to be found in the

device model that has just been simpliﬁed. Thus, the

compiler can offer help in better reporting compile-

time errors.

5 MODEL CONNECTION

COMPATIBILITY SUPPORT

Not all models can work correctly with one another.

The trick used often today to avoid that incompatible

models get connected to each other is to make their

connectors incompatible. If a plug doesn’t ﬁt into a

socket, that is a good indication that the device behind

that plug should not get connected to the system at

this location.

However, the compatibility issues are often more

subtle. We need to be able to check that a variable

never assumes a negative value, for example. It could

also be that a connection between two models is only

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

IS-8

valid for positive power ﬂow from the ﬁrst model to

the second, but not when the power ﬂow is reversed.

It may be that a motor model is only valid up to a cer-

tain maximum rotational speed or a maximum level of

armature voltage. Modelica offers already now assert

statements that can be used to catch various types of

incompatibility issues, but many users are hesitant to

use assert statements on variables rather than param-

eters, because these will slow down the simulation.

Also in the context of variable structure models,

the current assert statements may not be powerful

enough. We must be able to encode under what con-

ditions we are allowed to switch from one model to

another, for example.

Finally in the context of automated model prun-

ing, it is not clear how assert statements need to be

adjusted in the process of model pruning. This issue

needs to be studied.

6 MODEL PLAUSIBILITY

SUPPORT

When checking the results obtained from simulating

a model, we usually only look at those few variables

that are most important to us. If the trajectories gener-

ated by the model look plausible, we accept the model

as probably correct. However, it may happen that

the simulation generates entirely implausible trajec-

tory behavior for some other variables that we failed

to look at. We would have rejected the model had we

looked at any of those trajectories.

The problem gets worse as the size of the model

increases. In a system level simulation, we shall still

not have time to look at more than a handful of tra-

jectories. Thus, we need language support to prevent

implausible trajectory behavior from remaining unno-

ticed. It should be possible to specify behavioral pat-

terns for variables that we expect them to exhibit. If

the simulations fail to generate the predicted patterns,

these variables should get ﬂagged by the simulation

so that the modeler will look at the generated trajec-

tories explicitly before accepting the model as being

plausible.

A similar feature is also needed for fault detection.

In a watchdog monitor (Cellier et al., 1992; de Al-

bornoz, 1996), real-time simulation results are com-

pared with measurement data obtained from the mon-

itored plant. If the simulated trajectories deviate from

the observed behavior in signiﬁcant ways, an alarm is

issued that alerts the plant operator to a possible fault

in the system (Escobet et al., 1999). In this case, the

model had been validated before, and it is the plant

that is expected to be at fault rather than its model.

7 THE CURSE OF LARGE-SCALE

SYSTEM SIMULATION

Models of large-scale systems are invariably stiff.

Among the state variables simulated, some will al-

ways change faster than others. This is particularly

true for multi-energy domain simulations. For exam-

ple in a mechatronic system, the electrical time con-

stants are always faster than the mechanical ones by

about two orders of magnitude. If the thermal domain

is to be studied as well, thermal states will have time

constants that are slower than the mechanical ones

again by one or two orders of magnitude. Thus, such

multi-energy domain models are always stiff.

ODE solvers that can be used to simulate stiff sys-

tems must be implicit solvers. Explicit solvers will

need to use step sizes throughout the simulation that

are small in comparison with the fastest time con-

stants captured by the model as otherwise the simu-

lation will become numerically unstable (Cellier and

Kofman, 2006). The numerical stability domains

(Cellier and Kofman, 2006) of stiff system solvers

loop in the right-half complex λ ·h plane. This avoids

numerical stability problems during simulation when

simulating analytically stable systems. All explicit

solvers have numerical stability domains that loop in

the left-half complex λ· h plane, and only some (but

not all) implicit solvers feature numerical stability do-

mains that loop in the right-half complex λ · h plane

(Cellier and Kofman, 2006).

Implicit solvers (including all stiff system solvers,

such as DASSL (Petzold, 1983) or Radau (Hairer and

Wanner, 1999)) need to iterate over a number of it-

eration variables in each integration step using New-

ton iteration (Cellier and Kofman, 2006). The itera-

tion variables usually include all state variables plus

a few algebraic (so-called tearing) variables that are

needed to break algebraic loops that remain in the

model (Cellier and Kofman, 2006).

The simulation is formulated in the following

way:

F (z

k+1

) = 0 (4)

where z is the vector of iteration variables to be cal-

culated at the end of the next integration step, i.e., at

time t

k+1

, and F (.) is a set of zero functions that need

to be solved for the unknown iteration variables. The

Newton iteration can be formulated as follows:

l+1

k+1

= z

k+1

− H

−1

· F (5)

where H = ∂F /∂z is the Hessian matrix (Cellier and

Kofman, 2006). We start out with initial guesses of

the values of the iteration variables, z

k+1

. The (l+1)

TheComplexityCrisis

IS-9

iteration can then be computed from the l

iteration

using the above formula.

The Newton iteration can be set up as follows:

H · δz = F (6)

l+1

k+1

= z

k+1

− δz (7)

Thus, inside each Newton iteration of a non-linear

model, a set of linear equations needs to be solved

during each iteration step. The convergence speed

of the Newton iteration, i.e., the number of iterations

needed for convergence, depends heavily on the ac-

curacy with which the elements of the Hessian matrix

are being estimated and on the accuracy with which

the linear equations are being solved.

The Newton iteration is the crucial part of the sim-

ulation as this is where the simulation spends most of

its time. A ﬁrst improvement over the current state

of the art would therefore be to invoke a linear sys-

tem solver that exploits the multi-core architecture of

modern computers. Also the estimation of the ele-

ments of the Hessian matrix can be easily parallelized.

Different columns of the Hessian matrix can be com-

puted in parallel on separate cores. These perfor-

mance improvements have not been crucial up until

now, because most Dymola models formulated today

at device level simulate within a few seconds of real

time anyway.

Unfortunately, the execution time needed for the

Newton iteration, and thereby for the entire simula-

tion, grows cubically in the number of iteration vari-

ables. Thus, if today’s device level simulations take

seconds to simulate, system level simulations that in-

volve ten times as many iteration variables will take

hours to simulate. This is why Dymola is not yet com-

petitive when simulating distributed parameter mod-

els (Link et al., 2009).

The situation has recently improved by the addi-

tion of sparse matrix solvers to Dymola for dealing

with large sets of linear equations (Braun et al., 2012).

A speed-up of a factor of up to 20 was reported on

some test problems. Yet, this is still insufﬁcient to

make Dymola competitive for the simulation of larger

PDE models.

Future generations of computers will offer larger

numbers of cores, and making use of a linear system

solver and a Hessian generator that fully exploit the

multi-core architecture can push the barrier yet a bit

further, but this alone will not overcome the complex-

ity issue. The simulation time still grows cubically

in the number of iteration variables. For stiff system

simulations to scale well, we shall need to get away

from large Newton iterations.

The multi-core architecture can also be exploited

in other ways. First attempts at distributing transmis-

sion line Modelica models over a multi-core architec-

ture were recently reported by Sj¨olund (Sj¨olund et al.,

2010). Sj¨olund writes in his article that it is very im-

portant that the distribution of the model over the ar-

chitecture be accomplished in a fully automated fash-

ion by the Modelica compiler. Otherwise the tech-

nique will become unmanageable when dealing with

large-scale models. We shall explore this avenue fur-

ther in the next section of this article.

8 QUANTIZED STATE SYSTEM

SIMULATION

In recent years, a new class of ODE solvers has been

developed that is based on state quantization rather

than time slicing (Cellier and Kofman, 2006; Kofman,

2003). Rather than asking the question:

What values will the state variables assume at

the next sampling instant, t

k+1

we ask the question:

At what time will the state variable x

change

by more than ±δx

in comparison with its cur-

rent value?

A quantized state system (QSS) solver operates nat-

urally in an asynchronous mode. Each state variable

carries its own simulation clock. If the states of a sub-

system change very little, the model equations captur-

ing the dynamics of that subsystem will be executed

rarely. In the context of QSS simulations, automated

model pruning may become less of an issue and may

in fact turn out to be unnecessary. A dormant model

occupies space on the disk, but it does not slow down

the simulation, as its equations will not get executed.

As we proceed from device level simulation to sys-

tem level simulation, the relative advantage of QSS

solvers will become more noticeable, as they escape

the curse of complexity.

QSS solvers can easily exploit a multi-core ar-

chitecture. Since each state variable minds its own

business, the solvers associated with the individual

state variables can be easily distributed over multi-

ple cores. This needs to be done intelligently in or-

der to minimize inter-processor communication, but

QSS solvers don’t suffer the fate of the centralized

stiff system solvers of the past. This is a research area

that we are currently exploring (Ph.D. dissertation of

Xenofon Floros to be defended in 2013). In order to

solve the synchronization problem between the differ-

ent simulators running on separate cores, each state

variable synchronizes its own simulation clock with a

scaled version of the real-time clock, but the different

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

IS-10

simulators don’t synchronize their individual clocks

among each other (Bergero et al., 2013).

Recently, ﬁrst versions of stiff QSS solvers have

been developed (Migoni et al., 2013; Migoni et al.,

2012). Although stiff QSS solvers are necessarily im-

plicit, they do not require Newton iteration. The rea-

son is that the next state is known in advance. If the

current state has a value of x

, the next state will as-

sume a value of x

± δx

. Thus in the worst case, we

need to explore two alternatives. The average simu-

lation step of a stiff QSS solver therefore consumes

only about 20% more real time in comparison with its

non-stiff twin.

These solvers nevertheless still carry the risk of

a combinatorial explosion, because transitions in one

state may trigger immediate transitions in other vari-

ables as well. Thus in the worst case, we may need to

check for 2

potential next states. To prevent combi-

natorial explosion, the current generation of stiff QSS

solvers has been implemented in a linearly implicit

fashion only (Migoni et al., 2013). This often works

well, but if the stiffness of the model is not caused by

large and small elements on the diagonal of the Hes-

sian matrix, e.g. in discretized parabolic PDEs, the

“stiff” QSS solvers lose their stiffness property, and

therefore, stiff QSS solvers are not yet as robust as

e.g. DASSL. More research in this area is still needed.

Distribution over multiple cores may help also in this

respect. Since the different columns of the Hessian

matrix can be computed in parallel, it should be possi-

ble to also limit the combinatorial explosion in similar

ways.

First results of simulating large-scale models us-

ing stiff QSS solvers were recently published (Berg-

ero et al., 2012). We simulated a long transmission

line (not a stiff system) with a load that made the

overall system very stiff. Thus, Dymola, using cen-

tralized simulation, has no choice but to make use of

a stiff system solver on all state variables and suffers

the consequences of a large Hessian matrix. The stiff

QSS solver simulated this system 1000 times faster

than Dymola, even without exploiting the multi-core

architecture, which is the type of performance that we

need when proceeding from device level to system

level simulation.

First simulation results using parallel implemen-

tations of stiff QSS solvers distributed over a multi-

core architecture showed very promising results as

well (Bergero et al., 2013). Parallel implementations

of QSS solvers scale very well. Whereas most par-

allel implementations of dynamic system simulations

saturate quickly as more cores are being added (due

to the overhead associated with inter-processor com-

munication), we did not notice any saturation effects

yet when distributing the transmission line simulation

over 12 parallel processes (six cores operating each in

an interleaved mode).

In fact, the speed-up was even slightly faster than

linear, because the overhead associated with manag-

ing the event queue currently grows quadratically in

the number of events being managed (it could grow

with n· log(n), but the event handler has not yet been

implemented in an optimal fashion in the current re-

lease of the tool). As each processor carries its own

event queue, the average length of the individualevent

queues is smaller in the parallel setup, which explains

the faster-than-linear speed-up.

QSS solvers are also more efﬁcient than classi-

cal solvers in handling discontinuities as they do not

require an iteration to localize event times. Power-

electronic circuits with high frequency switching sim-

ulate currently about 20 times faster using QSS

solvers than using DASSL. However,also this feature

will become more important when proceeding from

device level simulation to system level simulation.

Event times (discontinuities) can be assumed to occur

in a statistically independent fashion. Therefore we

can assume that a model that is ten times as big fea-

tures on average about ten times as many discontinu-

ities per time unit. Thus, the event density grows lin-

early with the size of the model. The execution time

of classical solvers grows quadratically with the event

density, whereas that of QSS solvers grows only lin-

early with the number of events per time unit. This is

true even for non-stiff models using non-stiff solvers

for their simulation (Grinblat et al., 2012).

For all of the above reasons, we expect that sys-

tem simulation tools of the future will employ decen-

tralized multi-core implementations of QSS solvers

as their default simulation algorithms, but the QSS

solvers need to become more robust before this can

happen.

9 CONCLUSIONS

In this article, it was shown that the demands on

a modeling and simulation environment vary widely

with the complexity of the systems to be modeled and

the size of the models to be simulated. Modern M&S

environments are useful for modeling devices and for

simulating device level models, but they are not yet

useful for modeling complex systems and for simu-

lating system level models. A series of avenues were

sketched outlining how some of the shortcomings of

current M&S environments may be overcome.

TheComplexityCrisis

IS-11

ACKNOWLEDGMENTS

This research has in part been funded by CTI grant

No. 12101.1;3 PFES-ES and supported by the

OPENPROD-ITEA2 project. The support is grate-

fully acknowledged.

REFERENCES

Bergero, F., Floros, X., Fernandez, J., Kofman, E., and

Cellier, F. (2012). Simulating Modelica Models with

a Stand-alone Quantized State Systems Solver. In

Proceedings 9th International Modelica Conference,

pages 237–246, Munich, Germany.

Bergero, F., Kofman, E., and Cellier, F. (2013). A Novel

Parallelization Technique for DEVS Simulation of

Continuous and Hybrid Systems. Simulation.

Braun, W., Gallardo-Yances, S., Link, K., and Bachmann,

B. (2012). Fast Simulation of Fluid Models with

Colored Jacobians. In Proceedings 9th International

Modelica Conference, pages 247–252, Munich, Ger-

many.

Cellier, F. (1979). Combined Continuous/Discrete System

Simulation by Use of Digital Computers: Techniques

and Tools. PhD thesis, Swiss Federal Institute of Tech-

nology.

Cellier, F. (1991). Continuous System Modeling. Springer–

Verlag, New York, NY, USA.

Cellier, F. and Elmqvist, H. (1993). Automated Formula

Manipulation Supports Object–oriented Continuous

System Modeling. IEEE Control Systems, 13(2):28–

38.

Cellier, F. and Kofman, E. (2006). Continuous System Sim-

ulation. Springer–Verlag, New York, NY, USA.

Cellier, F., Schooley, L., Zeigler, B., Doser, A., Far-

renkopf, G., Kim, J., Pan, Y., and Williams, B. (1992).

Watchdog Monitor Prevents Martian Oxygen Produc-

tion Plant from Shutting Itself Down During Storm.

In Proceedings International Symposium on Robotics

and Manufacturing, pages 697–704, Santa Fe, NM,

USA.

de Albornoz, A. (1996). Inductive Reasoning and Re-

construction Analysis: Two Complementary Tools for

Qualitative Fault Monitoring of Large–scale Systems.

PhD thesis, Polytechnical University of Barcelona.

Elmqvist, H. (1978). A Structured Model Language for

Large Continuous Systems. PhD thesis, Lund Institute

of Technology.

Elmqvist, H., Cellier, F., and Otter, M. (1993). Object–

oriented Modeling of Hybrid Systems. In Proceed-

ings ESS’93, European Simulation Symposium, pages

xxxi–xli, Delft, The Netherlands.

Elmqvist, H. and Otter, M. (1994). Methods for Tear-

ing Systems of Equations in Object–oriented Model-

ing. In Proceedings European Simulation Multicon-

ference, pages 326–332, Barcelona, Spain.

Escobet, A., Nebot, A., and Cellier, F. (1999). Model Ac-

ceptability Measure for the Identiﬁcation of Failures

in Qualitative Fault Monitoring Systems. In Proceed-

ings European Simulation Multi-Conference, pages

339–347, Warsaw, Poland.

Grinblat, G., Ahumada, H., and Kofman, E. (2012). Quan-

tized State Simulation of Spiking Neural Networks.

Simulation, 88(3):299–313.

Hairer, E. and Wanner, G. (1999). Stiff differential equa-

tions solved by Radau methods. Journal of Computa-

tional and Applied Mathematics, 111(1-2):93–111.

Kofman, E. (2003). Quantization-based Simulation of Dif-

ferential Algebraic Equation Systems. Simulation,

79(7):363–376.

Link, K., Steuer, H., and Butterlin, A. (2009). Deﬁcien-

cies of Modelica and its Simulation Environments for

Large Fluid Systems. In Proceedings 7th Interna-

tional Modelica Conference, pages 341–344, Como,

Italy.

Mattsson, S., Elmqvist, H., and Broenink, J. (1997). Mod-

elica – An International Effort to Design the Next

Generation Modeling Language. Journal A, Benelux

Quarterly Journal on Automatic Control, 38(3):16–

19.

Mattsson, S., Olsson, H., and Elmqvist, H. (2000). Dy-

namic Selection of States in Dymola. In Proceedings

Modelica Workshop, pages 61–67, Lund, Sweden.

Migoni, G., Bortolotto, M., Kofman, E., and Cellier, F.

(2013). Linearly Implicit Quantization-based Inte-

gration Methods for Stiff Ordinary Differential Equa-

tions. Simulation Modelling Practice and Theory.

Migoni, G., Kofman, E., and Cellier, F. (2012).

Quantization-based New Integration Methods for Stiff

ODEs. Simulation, 88(4):387–407.

Mitchell, E. and Gauthier, J. (1986). ACSL: Advanced Con-

tinuous Simulation Language – User Guide and Refer-

ence Manual. Mitchell & Gauthier Assoc., Concord,

MA, USA.

Modelica Association, . (2007). The Modelica Language

Speciﬁcation Version 3.0. Technical report.

Modelica Association, . (2008). The Modelica Standard Li-

brary. Technical report.

Olsson, H., Otter, M., Mattsson, S., and Elmqvist, H.

(2008). Balanced Models in Modelica 3.0 for In-

creased Model Quality. In Proceedings 6th Interna-

tional Modelica Conference, pages 21–33, Bielefeld,

Germany.

Otter, M., Elmqvist, H., and Mattsson, S. (1999). Hybrid

Modeling in Modelica Based On Synchronous Data

Flow Principle. In Proceedings IEEE, International

Symposium on Computer Aided Control System De-

sign, pages 151–157, Kohala Coast, Hawaii.

Pantelides, C. (1988). The Consistent Initialization of

Differential–Algebraic Systems. SIAM Journal of Sci-

entiﬁc and Statistical Computing, 9(2):213–231.

Petzold, L. (1983). A Description of DASSL: A Dif-

ferential/Algebraic Equation Solver. In Stepleman,

R., editor, Scientiﬁc Computing, pages 65–68. North–

Holland, Amsterdam, The Netherlands.

Pop, A., Sj¨olund, M., Asghar, A., Fritzson, P., and Casella,

F. (2012). Static and Dynamic Debugging of Modelica

Models. In Proceedings 9th International Modelica

Conference, pages 443–454, Munich, Germany.

SIMULTECH2013-3rdInternationalConferenceonSimulationandModelingMethodologies,Technologiesand

Applications

IS-12

Ryan, R. (1990). ADAMS – Multibody System Analysis

Software. In Schiehlen, W., editor, Multibody Systems

Handbook, pages 361–402. Springer-Verlag.

Sen, S., Moha, N., Baudry, B., and J´ez´equel, J. (2009).

Meta–model Pruning. In Model Driven Engineer-

ing Languages and Systems, pages 32–46. Springer–

Verlag, Berlin and Heidelberg, Germany.

Sj¨olund, M., Braun, R., Fritzson, P., and Krus, P. (2010).

Towards Efﬁcient Distributed Simulation in Model-

ica Using Transmission Line Modeling. In Proceed-

ings 3rd International Workshop on Equation-based

Object-oriented Languages and Tools, pages 71–80,

Oslo, Norway.

Tuinenga, P. (1995). Spice: A Guide to Circuit Simulation

and Analysis Using PSpice - Third Edition. Prentice

Hall, Saddle River, NJ, USA.

Zimmer, D. (2010). Equation–based Modeling of Variable–

structure Systems. PhD thesis, Swiss Federal Institute

of Technology.

BRIEF BIOGRAPHY

Franc¸ois E. Cellier received his

BS degree in electrical engineer-

ing in 1972, his MS degree in

automatic control in 1973, and

his PhD degree in technical sci-

ences in 1979, all from the Swiss

Federal Institute of Technology

(ETH) Zurich. Dr. Cellier

worked at the University of Arizona as professor of

Electrical and Computer Engineering from 1984 until

2005. He returned to his home country of Switzer-

land and his alma mater in the summer of 2005. Dr.

Cellier’s main scientiﬁc interests concern modeling

and simulation methodologies, and the design of ad-

vanced software systems for simulation, computer-

aided modeling, and computer-aided design. Dr. Cel-

lier has authored or co-authored more than 200 tech-

nical publications, and he has edited several books.

He published a textbook on Continuous System Mod-

eling in 1991 and a second textbook on Continu-

ous System Simulation in 2006, both with Springer-

Verlag, New York. He is a fellow of the Society for

Modeling and Simulation International (SCS).

TheComplexityCrisis

IS-13
