Virtual Characters with Affective Facial Behavior

Ana Paula Cláudio

, Augusta Gaspar

, Eder Lopes

and Maria Beatriz Carmo

LabMAg, Faculdade de Ciências, Universidade de Lisboa, Lisboa, Portugal

CIS- Centro de Investigação e Intervenção Social, ISCTE Instituto Universitário de Lisboa, Lisboa, Portugal

Keywords: Virtual Humans, Social Anxiety Disorder, Facial Expressions, Body Postures, Exposure Therapy,

Nonverbal Behaviour Research.

Abstract: This paper describes an application that generates a simulation of a jury with one to three virtual humans

capable of exhibiting facial and body expressions controllable in real-time. This control is performed

through an interface that combines facial action elements (AU-Action Units, as described in the Facial

Action Coding System), with upper-body postures. The level of detail of this control offers a range of

possible combinations to obtain emotional expressions. Besides offering the possibility of controlling the

postures of the virtual characters, the application allows the user to choose, among a pre-defined set, the

virtual characters that compose the jury, and is able to introduce in the simulation some extra, potentially

distractive or annoying events. We envisaged two contexts for using this application: i) assisting

psychotherapists in exposure therapy of patients suffering from anxiety of public speaking, particularly in

front of a jury in an assessment situation; ii) supporting nonverbal behaviour research carried out by

psychologists. The development of the application has been closely monitored by a psychologist that is part

of our team. This application is a low-cost approach, which uses only free software and models and resorts

to common equipment; it is easy to install and use by people without expertise in informatics. So far, we

have performed an evaluation with therapists in the first application context, obtaining encouraging results.

1 INTRODUCTION

Social Anxiety Disorder (SAD), or Social Phobia, is a

condition characterized by intense anxiety whenever

the individual is faced with a situation of public

performance or exposure or even the bare anticipation

of such a situation (APA, 2000). When forced to face

them they report the experience as a torture.

This condition cripples one’s social, professional

personal life, presenting itself with a high co-

morbidity with depression (Stein and Kean, 2000).

SAD patients fear negative judgment, and believe to

be so judged. Their perception of others emotional

signals is similar to that of other people when the

signals are neutral or characteristic of positive affect.

But regarding signals that may carry negative,

threatening content, they are faster, more effective

detectors (Douilliez et al., 2012) thereby evincing

their hypervigilance for social threat.

Therapies used to treat SAD often include

medication (mostly anti-depressants),

cognitive-behavioral therapy, psychotherapy and

relaxation techniques. By far, cognitive-behavioral

therapy is the one that has shown the most efficient

and persistent results, especially in the form of

exposure therapy (see Beidel and Turner, 2007).

Exposure therapy comprises today, and since the

early 90’s, approaches based on Virtual Reality

(VR). This is called Virtual Reality Exposure

Therapy (VRET). These approaches have been

reported to produce similar outcomes to those of

traditional exposure counseling (Klinger et al., 2004;

Herbelin, 2005). VRET enables an accurate control

of the process of habituation (and extinction) of fear

to a phobic object, and thus it entails many

additional advantages over classic exposure therapy,

which involved imagery and subsequent contact

with real life situations: a) VRET enables the

customization of scenarios and interactions to meet

the needs and progress of different patients, and

those of each patient throughout the treatment

period; b) it allows an optimization of patient

preparedness before facing reality, thereby avoiding

the risk of a miscalculated premature exposure to

reality; c) by reducing the risk of throwbacks and

excessive reactions, it provides a more stable,

progressive, securing environment for treatment, that

may ensure a predictable and consolidated patient

348

Cláudio A., Gaspar A., Lopes E. and Carmo M..

Virtual Characters with Affective Facial Behavior.

DOI: 10.5220/0004677803480355

In Proceedings of the 9th International Conference on Computer Graphics Theory and Applications (GRAPP-2014), pages 348-355

ISBN: 978-989-758-002-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

outcome; d) finally it protects the patients privacy.

The typical major drawbacks of VRET are the

financial cost of purchasing virtual immersive

equipment (Head-Mounted Displays, CAVEs) and

the secondary effects manifested by some users

(cyber sickness) (LaViola, 2000).

This paper describes an application that

generates a jury of virtual humans (VHs) displaying

facial and body actions controllable in real-time.

Control is achieved through an interface that (among

other functions) supports the combination of facial

action elements with upper-body postures, enabling

a wide range of compositions that may convey

neutral, positive or negative emotional content, as

well as attention or lack of interest. The application

can be used to assist psychotherapists in the

exposure therapy of patients with fear of public

speaking or other type of public performance,

mainly in front of a jury in an assessment situation.

The application is also a useful tool in nonverbal

behavior research: There are currently several

applications that depart from the assumption that the

content of facial behavior and other communication

elements is fully known, when it is not (Gaspar and

Esteves, 2012; Gaspar et al. in press), so a

customizable tool that enables composing different

constellations of units of facial and body behavior

whilst controlling the effect of context and other

variables on perception and emotional reactions is a

most useful, non-biased tool. The effect of changing

a single action in a face whose actions are otherwise

kept constant can be dramatic (see Figure 4);

assessing its impact on observers, may clarify the

communicative role of unitary or composite actions,

and assist in establish objective parameters for

exposure counseling as well as for the advancement

of research in nonverbal behavior.

Our application simulates a jury that can be set

to comprise 1-3 characters. The one character jury

simulates an interview situation whereas the three

character jury resembles more an MSc. dissertation

defense or a contest jury. As to setting alone, there

are multiple customization options in the application

– from room features to the placement of different

VH jury members, their clothing and other qualities

of their looks before setting their behavior. This

application is designed to be projected in a canvas or

wall, at a distance whereby VHs approach real size

and their background occupies an entire wall,

creating a strong immersive effect. The team’s

psychologist played a decisive role in sorting

behavior units to include in the application.

Inclusion relied on two premises –validity of the

behavior signal value and behavior appropriateness

to SAD therapy.

The work herein described follows from previous

work in which our team designed a set to expose

patients to a large auditorium type virtual audience

(Cláudio et al., 2013; Cláudio et al., 2012). The

distinctive features of the current work are the level of

detail that can be customized for the virtual humans’

aspect and behavior (facial expressions, gaze

orientation and posture) and the context, which implies

a much closer interaction between user and VHs. The

current work was also developed with a different tool, a

freeware version of Unity 3 (url-Unity), a software tool

for the production of video-games.

In both the current and the auditorium application

we aimed to develop low cost, “portable” and

ergonomically optimized VR tools that could be

widely used in counseling and research.

This document is organized as follows: next

section presents some of the most relevant related

work; then we describe our approach and the

evaluation performed with therapists, and finally we

draw conclusions and present future work.

2 RELATED WORK

VRET has been applied since the 1990’s to treat

diverse phobic conditions. And targeting social

anxiety or social phobia, namely the fear of public

speaking, poses extra challenges: the inclusion of

credible virtual characters into the VR scenario.

North et al. (1998) presented the first VR

application to treat fear of public speaking - it

included a scenario with an auditorium resembling a

university auditorium and it could be filled with up

to 100 characters. During the session the therapist

could vary the number of characters and their

attitudes using pre-recorded video sequences. The

patient used a head-tracked HMD with an attached

loudspeaker to hear the echo of his own voice

reverberating in the auditorium.

Slater at al. (1999) created a public speaking

simulation in a virtual seminar room with 8

characters sat in semi-circle exhibiting random

autonomous behaviour such as head-nods, blinking

and twitches. The initial study, with 10 students with

different levels of difficulty in public speaking was

later extended to include phobic and non-phobic

individuals (Pertaub et al., 2001; 2002; Slater at. al,

2006). Pertaub et al. (2002) recreated 3 different

types of audience behavior: an emotionally neutral

audience that remained static throughout the talk, a

positive audience showing friendly and appreciative

behaviour, and a negative audience, displaying

VirtualCharacterswithAffectiveFacialBehavior

349

hostile and bored expressions throughout the talk.

For the positive and negative scenarios 10 different

audience behaviours were scripted. Based on the

observation of the actual progress of the subject’s

speech, the therapist could decide the start time for

each script; but the script order was predetermined.

Herbelin et al. (2002) used snapshots of eyes to

recreate a virtual human audience. The snapshots

were placed in concentric circles around the user and

the system allowed pre-setting the number of circles,

the number of snapshots and the distance to the user

in order to change induced anxiety.

Anderson et al. (2003) created a virtual podium

suitable for reading, placed in front of virtual

curtains; when these open, one of two sets may

appear: a seminar room with 5 people around a table

or an auditorium with 25 people, made of

video-clips of real humans. Along the treatment, the

patient is exposed to the most feared situation.

James et al. (2003) proposed a two-fold scenario:

an underground train with characters expressing

neutral behaviors (a non-socially demanding

environment) and a bar where characters seemed

aloof and detached – a socially demanding situation.

The behavior of characters included eye gaze and

pre-recorded sentences. Authors reported that the bar

situation was more likely to trigger anxiety in phobic

subjects than the underground train.

Klinger et al. (2004) conducted a study that

examined changes in the fear of public speaking in

36 participants over 12 sessions. For the virtual

characters they used simple billboards on which

pictures of real people involved in daily situations

were projected. Participants were divided into 2

groups, one treated with traditional CBT and another

with VRET. The VRET included 4 virtual

environments simulating social situations involving

performance (eg, public speaking), inter-personal

interaction (eg, a dinner conversation), assertiveness

(eg, defending an idea) and evaluation (eg, talk

while being observed). Patients in the VRET group

were reported to show a larger reduction in social

anxiety than patients in the CBT group. Herbelin

(2005) published a validation study with 200

patients, confirming that his VR platform met the

requirements of VRET therapeutic exposure for

social phobia. He also proved that it is possible to

improve clinical assessment with monitoring tools

integrated in the application, such as eye-tracking.

All the referred approaches have used head-

tracked HMD; in the study described by Pertaub et

al. (2002), half of the patients experienced the

virtual seminar room through a HMD and the

remainder on a desktop. Herbelin (2005) and Grillon

(2009) besides using HMD and a simple computer

screen have also used a large back-projection screen.

Haworth et al. (2012) implemented virtual

scenarios to be visualized simultaneously by patient

and therapist, possibly in different physical locations

and communicating via a network. The scenarios

target acrophobia and arachnophobia patients and

are visualized in simple desktop screens; the patient

sees only the hands and feet of his avatar in the

virtual world whilst the therapist has no

corresponding avatar in the virtual environment. A

Kinect is used to track the movement of the patient’s

body. The few results of this study so far seem to

demonstrate that this type of low-cost solution is

effective for these particular phobic situations.

Vanni et al. (2013) report a survey on virtual

environments devoted to treating the fear of public

speaking and in their words “VEs represent an

emerging, promising tool to carry out exposure

treatment, better than imaginary exposure and,

potentially, as good as in vivo exposure, in

triggering anxious reactions”. They point out that the

visual fidelity of the virtual character is not of major

importance, as behaviour is what really triggers

emotional reactions. Thus, the VH´s facial

expressions, gaze direction, and varied other actions

are the crucial features of VRET.

The main distinctive characteristics of our

application, besides the low-cost of the projection

method, are: a) the high level of control that the user

has of the simulation, made possible by a special

purpose user friendly interface that allows real-time

control of facial expressions and body postures of

the 3D VHs in the jury; b) being a low cost solution

– this is a feature that is meant to ease use and

dissemination; c) it eliminates the often reported

drawback of side effects of immersive VR

equipment, such as motion sickness and nausea.

3 THE INTERACTIVE VIRTUAL

JURY

3.1 Requirements’ Gathering

The application herein described follows from a

previous work designed to expose patients with fear

of public speaking to a virtual auditorium inhabited

by controllable virtual humans (Cláudio et al. 2013;

Cláudio et al. 2012). The present work, required a

scenario with considerably fewer characters: a virtual

jury simulating an assessment situation. This was

challenging due to the proximity between user (i.e. in

therapy, the therapist or patient, in research, the

GRAPP2014-InternationalConferenceonComputerGraphicsTheoryandApplications

350

observer) and the virtual characters, creating major

concerns about their appearance and behaviour.

In both applications, the main goal was to create

low cost, “portable” and ergonomically viable VR

tools that could be widely used to assist therapists in

the intermediary stages of exposure therapy

treatment, between an in imagino exercise -

imagined exposure situation - and in vivo situation -

exposure to a real situation.

To fulfil this requirement, the apparatus we

adopted for the application is comprised of a

computer (with a mid-range graphics card), a

projector and a canvas, and two sound columns. The

application provides two separate windows: the

simulation window, which is projected and displays

the virtual jury, and the interface window, which is

displayed in the computer screen and used to

configure and to control the simulation. The sound is

synchronized with events happening in the

simulation.

This structure has the advantage of using

inexpensive and easily installed equipment while, by

projecting an image on a large screen, generating a

feeling of immersion. Furthermore, it can be

observed simultaneously by several people, which

may be advantageous in education and training or in

collective research sessions aimed at studying

appraisal and reactions to the VHs behavior.

Comparing with our previous work, the

distinctive requirements posed by the current work

are the higher quality of the VH models and the

level of detail that can be customized and controlled:

gaze orientation, facial expressions and posture.

Requirements common to both applications,

besides the low-cost, are:

- Simulations controllable in real-time by the

therapist. The most important condition to perform

a successful exposure therapy is triggering degrees

of discomfort in the patient that are similar to those

experienced in real situations, i.e., causing in the

patient the feeling of presence (Herbelin, 2005).

- Two distinct windows. One containing the

simulation, the other containing the interface to

control the content of the previous one.

- Support of therapy sessions taking place with

therapist and patient in the same room. This

maintains proximity during the therapy, without

risking the dehumanizing of treatment. A session

is centered in a simulation that is controlled by the

therapist and watched by the patient during a

proposed task. The therapist, attentive to patient

performance, controls stimuli intensity, triggering

specific events in the simulation.

- Friendly and easy to learn therapist interface; easy

to install and use for people without expertise in

informatics.

- Configuration of the scenario prior to the

simulation.

- Induce in the observer a strong sense of presence.

The models of the characters in the jury and their

behavior should be compelling and capable of

looking at the patient.

To implement the whole application we used the

free version of Unity, as previously mentioned. The

VH models

were

free of cost using

MakeHuman

(url-

MakeHuman); to adjust and animate the VH models

and to model some assets of the scenario, we used

Blender (url-Blender). As to hardware, we used a

computer with processor: 2x Intel ® CORE ™ 2

Duo E8400@3.00GHz, 4GB Memory, Graphics

Card Quadro FX 1700/PCI/SSE2 (a mid-range

mobile graphics solution). We also resorted to a

projector, a projection screen (or blank wall) and

two speakers installed close to the projected image.

3.2 The Configuration and Simulation

Interfaces

The application generates a jury simulation with 1-3

VHs capable of exhibiting facial and body

expressions controllable in real-time. It displays two

windows: one for the simulation and another for the

user interface. In the snapshot of the simulation

window in Figure 1 all characters are distracted;

while one of them uses the laptop, another is

whispering to the character sitting beside.

Figure 1: A snapshot of the simulation window.

The interface window displays different contents,

depending on the time of use: i) the configuration

interface to customize the scene and choose the

virtual characters; ii) the simulation interface to

control the characters and the events during the

simulation; iii) the facial expression interface to

control the facial actions of characters.

These interfaces are illustrated and described in

the following subsections.

VirtualCharacterswithAffectiveFacialBehavior

351

3.2.1 The Configuration Interface

In the configuration interface it is possible to choose

the type of scenario, classic or modern, and the color

of the walls and also, from a set of models, the

characters of the jury, 1 to 3, and their corresponding

position sitting in front of the observer. There are

models of both genders, with different clothes and

skin colors; any model can wear glasses. There are

also 3 sliders that can be used to calibrate the

camera, i.e. to adjust its position relatively to the

observer's position.

Along the configuration phase, all choices made

using this interface are immediately exhibited in the

simulation window which is also visible.

3.2.2 The Simulation Interface

The simulation interface can be seen in Figure 2.

Choices performed in this interface have effect in

real time in the simulation window.

To manage interface complexity, the application

supports user control of a character at a time, while

the others exhibit a pre-defined behavior previously

chosen. We call these control modes, interactive

mode and automatic mode, respectively.

Throughout the simulation the user is free to choose

different characters to perform interactive control.

Figure 2: The simulation interface.

Figure 2 shows the simulation interface that

corresponds to a previously configured jury of 2

elements, one on the middle (position number 2) and

one on the right (position number 3). The first

character is in interactive mode of control while the

second is in automatic mode. Notice the differences

in the available options; the interactive mode is

significantly more complex.

There are six automatic modes that can be

chosen alternatively: Attentive (neutral), Attentive

(agreeing), Attentive (disagreeing), Distracted

(agreeing), Distracted (disagreeing) and Leaning

backward, inner brow down. They correspond to

predefined animations executed by the VHs; the

application is prepared to an easy addition of

animations to the automatic mode of control. At the

bottom there are three types of functionality (Figure

2, from left to right): i) a slider to control light

intensity; ii) buttons to trigger sound events in the

environment (plane flying over, phone ringing,

traffic in the outside, rain, a conversation in the

hallway); iii) buttons to control the position and

zooming of the camera. This last set of buttons

offers three alternatives: to visualize all characters

(default), only the body and the face of the VH in

interactive mode or only its face. This feature is

particularly suitable to focus the observer’s attention

on a particular character.

The interface area to control the HV in

interactive mode (see position number 2 in Figure 2)

has three areas of buttons: i) defining two possible

states of attention (Attentive, Distracted); ii) those

that define what we called by Actions (Disagree,

Agree, SMS –answers to a text message that has just

arrived– Use laptop, Sleep, Look to the right,

Whisper –starts a conversation with the character

sitting next, as shown in Figure 1) and, finally, a

button to open the facial expressions menu,

explained in the next subsection. At the bottom,

there are buttons to control body postures: Leaning

neutral, Leaning forward, Leaning backward, Cross

arms, Leaning backward arms crossed. Some, like

waving the head as a sign of agreement (Agree

button) have a predetermined execution time, while

others, like Use laptop are executed as long as the

user desires. It is possible to combine some of the

animations like, for instance, Cross Arms and Agree.

3.2.3 The Facial Expressions Interface

As seen in Figure 3, there is a facial expression

control panel which pops out after clicking the

button “Facial Expressions”. The menu comprises

single elements of facial expressions and not full

facial expressions – i.e. buttons provide the so called

facial action units or AUs. AUs were taken from the

Facial Action Coding System or FACS (Ekman et

al., 2002) and in two AUs (AU4; AU12) there is an

option for 2 intensity levels. At this stage of

development it is extremely difficult to reproduce all

5 levels described in FACS for human spontaneous

behavior. We have chosen only a few FACS AUs, as

we based our work in only the most validated facial

expression- context associations from studies of

behavior and perception (Gaspar, Esteves and

Arriaga, in press), as there has been great

controversy surrounding the assumption that certain

GRAPP2014-InternationalConferenceonComputerGraphicsTheoryandApplications

352

facial expressions convey given discrete emotions

without support from studies of spontaneous facial

expression (eg Russell and Fernandez-Dolls, 1997).

These AUs can be combined and their simultaneous

insertion into the VH’s face is what creates its facial

expression. These facial compositions can be

combined with various options of body orientation

and posture, thereby creating full face-body

interactors. Postures and orientations were chosen

according to relevant content findings in human

nonverbal communication (Eibl-Eibbesfeldt, 1989).

The facial expression control panel includes

actions though to convey positive affect - AU6+12,

– with two intensity levels as options, activated by

the buttons “Smile (AU6+12)” and “Smile++

(AU6+12)”, and AU12 alone, activated by the “Lips

up (AU12)” button. It also includes actions often

processed as negative by observers, and associated

in the sender with either attention (AU4, AU5, AU2,

AU1+2) or negative affect (AU4, AU1+4 and

AU15). The frown (AU4), a movement that brings

eyebrows closer, forming wrinkles in between, and

lowering the inner corners of eyebrows as well,

which in humans is produced by the contraction of

the Corrugator muscle, is particularly relevant and

thus the two intensity levels– the buttons “Brows

brought together (AU4)” and “Brows brought

together (AU4)++”. The menu also includes two

buttons for baseline brows and baseline mouth,

which allow the user to set the VH back to a

virtually Emotion-inexpressive face.

Figure 3: The facial action units’(AUs) panel, which

allows for the composition of patterns (gestalten) of AUs

or facial expressions. The buttons turn green when the

respective AUs are active in the VH’s face.

Figure 4 displays the same VH model with

different combinations of AUs. The baseline face,

with no AUs activated (top-left) and a frown, AU4

(top-right). At the bottom right, we see a

combination of AU4 and AU15, both associated

with negative affect. At the bottom left, we see a

combination of AU4 and AU6+12 (the smile

button). The combination AU6+12 is the defining

feature of the “duchenne smile” which is supposed

to convey positive affect, more so and more honestly

than any other smile. The threatening effect frown is

mitigated and possibly the frown is here perceived

with other frequent context – attention.

Figure 4: Clockwise from top: a VH with a baseline face

(no AUs), displaying a frown (AU4), displaying a

combination of AU4 and AU15, displaying a combination

of AU4 and AU6+12 (the smile button).

4 EVALUATION

To assess the potential utility of this application in

the domain of VRET, in exposure therapy targeting

patients suffering from anxiety of speaking in front

of a jury, we performed an evaluation with six

therapists (2M ages 41 and 59; 4F ages 29-45),

familiarized with the use of exposure therapy and

with no prior contact with the application.

The test had two successive phases. The first,

with ca. 15 min, was a period of familiarization with

the tool. In the second phase, which took 15-20

minutes, the therapists were asked to assume that

they needed to use exposure therapy for a regular

therapeutic cycle, to treat a patient suffering from a

high level of anxiety regarding assessment in front

of a jury. The therapist had to use the application to

rehearse a first VR therapy session to be used in the

early stage of treatment, and a second VR therapy

session to be used in a later stage of treatment. After

each session, the therapists answered some questions

posed by the interviewer and gave scores to the

experienced functionalities, using a scale from 1-bad

to 5-excellent.

The overall classification to the ergonomics of

VirtualCharacterswithAffectiveFacialBehavior

353

the functionalities in the configuration interface was

excellent and all users rated the number of VHs in

the jury adequate. As to the ergonomics of the

available functionalities in the simulation window,

scores were all 5 except one: the ease in changing

the facial expression (M=4.5; SD= 0.58).

Table 1: Scores obtained in aspects concerning the

scenario, the events and the VH in the simulation.

Average SD

The realism of the virtual characters 3.75 0.50

The realism of the facial expressions 3.75 0.50

The realism of the body postures 4.25 0.50

The realism of the automatic behaviors 4.25 0.50

The realism of the scenario 4.5 0.58

The interest of the simulated events 4.25 0.96

Table 1 shows average rates and standard

deviation (SD) in other aspects concerning the

scenario, events and the VHs in the simulation. The

realism of the scenario had the highest score (M=

4.5; SD=0.58), whilst the lowest score was obtained

in the realism of the virtual characters and in the

realism of the facial expressions (M= 3.75SD= 0.5).

Regarding the level of difficulty in using the

prototype, psychotherapists unanimously classified it

as simple, and said they would be willing to use this

application to support a session of exposure therapy.

The best rated features in the simulation were: i)

the real time control of jury behavior and the ease

doing so; ii) the possibility of combining facial

expressions and body postures, to convey emotion

relevant information and the wide range of

combinations; iii) being able to choose having

characters nodding to show agreement or the reverse

by shaking the head, to induce positive or negative

reinforcement; iv) the credibility of the behavior –

generating scenes similar to those of a real jury. We

also received suggestions to make the VH’s

appearance more flexible (e.g. more outfit and age

options) and- specifically to include an older men

wearing a suit and a tie.

5 CONCLUSIONS AND FUTURE

WORK

The user tests were aimed at evaluating the application

from the perspective of a psychotherapist counsellor

leading an exposure therapy session to treat anxiety in a

patient who fears speaking in front of a jury.

The user-therapists were unanimous in stating

that they would use this application to support an

exposure therapy session. This indicates that our

low-cost solution has a real potential for use in that

context, even in the absence (and perhaps also

because of it) of immersive, special purpose VR

hardware. We acknowledge the need to validate the

utility of the application with a clinical population

and to establish standard values of stress reactions

(eg. physiological measures of stress and self-

reports) and emotional content interpretation in the

normative population. This validation is in

preparation. Despite this (temporary) shortcoming,

we feel quite optimistic about the real therapeutic

potential of the application, considering the feedback

of the therapists that evaluated it. The validation will

be decisive in confirming/refining the virtual

humans most adequate and effective behaviour units

toward the patients’ progress.

The features with lower scores in the evaluation

highlight the need to improve the VH models. This

was actually expected, given the quality limitations

of the freeware models. Notwithstanding, the

realism can only be improved up to the limit of

maintaining the rendering of the simulation in real-

time, and most importantly, the virtual fidelity of the

models has been shown to be less relevant than the

behaviour displayed by the characters (Vanni, 2013).

This conclusion is supported by tests with real

patients suffering from fear of public speaking, so

the aesthetical appraisals of therapists or researchers

are secondary to the purpose. Our VH display

signals with ecological validity, as these patients are

indeed biased towards certain behaviour signals in

their audiences, such as frowns (Esteves, 1999).

The application has also great potential for

research, allowing to investigate the function of

facial and body actions thought to express emotional

content, by measuring responses and interpretation

to different constellations of signals, and

systematically test their impact, controlling for the

effects of single components. We are currently

improving the application at two levels: diversity of

the avatars appearance (physiognomy and clothing),

and the neutrality of avatars physiognomy. It is

worth mentioning that physiognomy always affects

appraisal, no matter how “neutral” facial features

are. There is no face 100% neutral be it brow shape,

gender or attractiveness (Adams et al., 2012). So,

validation in the wider population should allow us to

let us sort the effects of signals and physiognomy.

More scenarios will be developed to extend the

application (eg with a group of people in an informal

reunion in a bar). An artificial intelligence module

concerning the simulation of emotions will be

developed and fully integrated in the application.

We feel that the implemented scenarios are

useful in the academic world, assisting for example,

graduate and undergraduate students, who frequently

GRAPP2014-InternationalConferenceonComputerGraphicsTheoryandApplications

354

seek the university psychologist in relation to their

anxiety toward public presentations.

To keep updated on our progress please consult

the project webpage (url-VirtualSpectators).

ACKNOWLEDGEMENTS

We thank the Portuguese Foundation for Science

and Technology and the R&D unity LabMAg for the

financial support given to this work under the

strategic project Pest OE/EEI/UI0434/2011.

REFERENCES

Adams Jr., R. B, Nelson, A. J., Soto, J. A., Hess, U.,

Kleck, R. E., 2012. Emotion in the neutral face.

Cognition and Emotion, 26 (3), 431-441.

APA- American Psychiatric Association, 2000. DSM-IV-

TR. American Psychiatric Publishing, Inc..

Anderson, P., Rothbaum, B., Hodges, L. F., 2003. Virtual

reality exposure in the treatment of social anxiety.

Cognitive and Behavioral Practice, 10(3), 240-247.

Beidel, D. C., Turner, S. M., 2007. Shy Children, Phobic

Adults: Nature and Treatment of Social Anxiety

Disorder. Washington, DC: APA, 2

edition.

Cláudio, A. P., Carmo, M. B., Esteves, F., Pinheiro, T.,

Lima, J., 2012, Virtual environments to cope with

anxiety situations - Two case-studies. In IEEE

Information Systems and Technologies (CISTI), 7th

Iberian Conference, pp. 1-4.

Cláudio, A. P., Carmo, M. B., Pinheiro, T., Esteves, F.,

Lopes, E., 2013. Virtual Environment to Treat Social

Anxiety. In A. Marcus (Ed.): DUXU/HCII 2013, Part

II, LNCS 8013, Springer, Heidelberg, 442-451.

Douilliez, C. Yzerbyt, V., Gilboa-Schechtman, E.,

Philippot, P., 2012. Social anxiety biases the

evaluation of facial displays: Evidence from single

face and multi-facial stimuli. Cog & Emo, 26(6):

1107-1115.

Eibl-Eibesfeldt, I., 1989. Human Ethology. NY: Aldine de

Gruyter.

Ekman, P, Friesen, WV., Hager, J C., 2002. Facial action

coding system. Salt Lake City, UT: Research Nexus.

Esteves, F, 1999. Attentional bias to emotional facial

expressions. European Review of Applied Psychology /

Revue Européenne de Psychologie Appliquée, Vol

49(2), 91-97.

Gaspar, A., Esteves, F., 2012. Preschoolers faces in

spontaneous emotional contexts – how well do they

match adult facial expression prototypes? Int J Behav

Dev. 36(5), 348–357.

Gaspar, A., Esteves, F., Arriaga, P. (in press). On

prototypical facial expressions vs variation in facial

behavior: lessons learned on the “visibility” of

emotions from measuring facial actions in humans and

apes. In O. Pombo and N. Gontier (Eds), The

Evolution of Social Communication in Primates: A

Multidisciplinary Approach, Interdisciplinary

Evolution Research. NY: Springer.

Grillon, H., 2009. Simulating interactions with virtual

characters for the treatment of social phobia. Doctoral

dissertation, EPFL.

Haworth, M. B., Baljko, M., Faloutsos, P., 2012. PhoVR:

a virtual reality system to treat phobias. In Pro-

ceedings of the 11th ACM SIGGRAPH International

Conference on Virtual-Reality Continuum and its

Applications in Industry, 171-174.

Herbelin, B., Riquier, F., Vexo, F., Thalmann, D., 2002.

Virtual reality in cognitive behavioral therapy: a

preliminary study on social anxiety disorder. In

Proceedings of the 8th VSMM2002.

Herbelin, B., 2005. Virtual reality exposure therapy for

social phobia. Doctoral dissertation, EPFL.

James, L. K., et al., 2003. Social anxiety in virtual

environments: Results of a pilot study.

Cyberpsychology & behavior, 6(3), 237-243.

Klinger, E., et al., 2004. Virtual reality exposure in the

treatment of social phobia. Studies in health

technology and informatics, 99, 91.

Klinger, E, et al., 2005. Virtual reality therapy versus

cognitive behavior therapy for social phobia: A

preliminary controlled study. Cyberpsychology &

behavior, 8(1), 76-88.

LaViola Jr, J. J., 2000. A discussion of cybersickness in

virtual environments.

ACM SIGCHI Bulletin, 32(1),

47-56.

North, M. M., et al., 1998. Virtual reality therapy: an

effective treatment for the fear of public speaking. The

International Journal of Virtual Reality 3, 1-6.

Pertaub, D. P., Slater, M., Barker, C., 2001. An

experiment on fear of public speaking in virtual

reality. Studies in health technology and informatics,

372-378.

Pertaub, D. P., Slater, M., Barker, C., 2002. An

experiment on public speaking anxiety in response to

three different types of virtual audience. Presence:

Teleoperators & Virtual Environments, 11(1), 68-78.

Russell, J. A., Fernandez-Dols, J. M., 1997. What does a

facial expression mean? In The psychology of facial

expression, pp. 3–30. New York, NY: Cambridge

University Press.

Slater, M., et al., 2006. A virtual reprise of the Stanley

Milgram obedience experiments. PloS one, 1(1), e39.

Slater, M., Pertaub, D. P., Steed, A., 1999. Public speaking

in virtual reality: Facing an audience of avatars. IEEE

CG&A, 19(2), 6-9.

Stein, M.B. and Kean, Y.M., 2000. Disability and Quality

of Life in Social Phobia: Epidemiologic Findings. Am

J Psychiatry 157: 1606–1613.

Vanni, F., et al., 2013. A survey on virtual environment

applications to fear of public speaking. European

Review for Medical and Pharmacological Sciences,

17(12), 1561-1568.

Unity http://Unity.com/

Blender http://www.blender.org/

MakeHuman http://www.makehuman.org

VirtualSpectators https://labmag.ul.pt/projects/virtual-

environments-to-treat-social-anxiety

VirtualCharacterswithAffectiveFacialBehavior

355
