Kinect based People Identiﬁcation System using Fusion of Clustering and

Classiﬁcation

Aniruddha Sinha

, Diptesh Das

, Kingshuk Chakravarty

, Amit Konar

and Sudeepto Dutta

Innovation Lab, Tata Consultancy Services Ltd., Kolkata, India

Dept. of Electronics and Tele-communication Engineering, Jadavpur University, Kolkata, India

Sikkim Manipal Institute of Technology, Sikkim, India

Keywords:

Kinect Sensor, Human Identiﬁcation, Gait Detection, Clustering, Classiﬁcation, Fusion, Dempster-Shafer

Theory, Human Skeleton.

Abstract:

The demand of human identiﬁcation in a non-intrusive manner has risen increasingly in recent years. Several

works have already been done in this context using gait-cycle detection from human skeleton data using

Microsoft Kinect as a data capture sensor. In this paper we have proposed a novel method for automatic

human identiﬁcation in real time using the fusion of both supervised and unsupervised learning on gait-based

features in an efﬁcient way using Dempster-Shafer (DS) theory. Performance comparison of the proposed

fusion based algorithm is done with that of the standard supervised or unsupervised algorithm and it needs to

be mentioned that the proposed algorithm is able to achieve 71% recognition accuracy.

1 INTRODUCTION

Several modalities of human identiﬁcation in terms

of human computer interaction (HCI) exists in the

current literature on machine intelligence. A few of

the common techniques include voice, facial expres-

sion, gesture, iris, ﬁngerprint etc. Unfortunately, all

of these modalities demand direct human interaction

and thus human identiﬁcation in a non-intrusive man-

ner is not feasible. Moreover extraction of ﬁngerprint,

iris or audio related biometric information (at recog-

nizable form) from a large distance is also a challeng-

ing job. This paper aims at developing a novel scheme

for human identiﬁcation from the movement data pat-

tern (gait) of the subject. The main advantages of gait

based person identiﬁcation is that it is unobtrusive

and can be applied from a relatively large distance.

And also the use of gait signature is highly secure be-

cause it is very much hard to hide and immitate. One

approach to extract movement data is to determine

the junction co-ordinates and their velocity to classify

subject from the movement patterns. This however,

requires multiple positional sensors or cameras to de-

termine the co-ordinates and depth of junctions from

a given distance. Fortunately, Microsoft Kinect pro-

vides an interesting platform to capture the junctional

information using RGB camera and depth sensor in

indoor environment. Not only that, as Kinect directly

provides skeleton or junction information to store the

movement pattern instead of video, this approach en-

sures the privacy and security issues for any individ-

ual.

Usually, classiﬁcation (supervised learning) or

clustering (unsupervised learning) algorithm is re-

quired to map or group the sensor captured data into

classes or clusters. In case of supervised learning,

the set of features extracted from the sensor data is

often used to train a classiﬁer for subsequent appli-

cations in classifying an unknown movement pattern.

On the other hand, for unsupervised learning, the ex-

tracted features are used to recognize a new person

without any training or manual labeling but group-

ing based on data similarity. It needs to be men-

tioned that these supervised and unsupervised algo-

rithm based approaches for human identiﬁcation had

already been proposed by Adrian et al. (Ball et al.,

2012) and Preis et al. (Preis et al., 2012) with differ-

ent set of features. While Adrian et al. (Ball et al.,

2012) only considered dynamic angular information

extracted from movement pattern, Preis et al. (Preis

et al., 2012) used both static information like height,

length of torso etc. and dynamic information like step

length and velocity. Hybrid features related to area

of upper and lower body, and distance between the

upper body centroid and the centriods derived from

different body joints are proposed in (Sinha et al.,

171

Sinha A., Das D., Chakravarty K., Konar A. and Dutta S..

Kinect based People Identiﬁcation System using Fusion of Clustering and Classiﬁcation.

DOI: 10.5220/0004690201710179

In Proceedings of the 9th International Conference on Computer Vision Theory and Applications (VISAPP-2014), pages 171-179

ISBN: 978-989-758-009-3

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

2013). Artiﬁcial Neural Network (ANN) based con-

nectionist framework for classiﬁcation using 46 di-

mensional feature vector was demonstrated by Pal et

al. (Pal and Chintalapudi, 1997). But, as the skele-

ton data provided by the Kinect is very noisy, a robust

person identiﬁcation algorithm is required to improve

the recognition accuracy.

The supervised learning algorithm can be neg-

atively inﬂuenced by limited quality of training

data (Karem et al., 2012) as well as the parameters

of the learning algorithms. Moreover it often results

in misclassiﬁcation due to asymmetrical distribution

of real classes in training dataset. As an approach to

overcome these shortcomings, this paper attempts to

design a novel approach of human identiﬁcation by

fusing the score of both supervised and unsupervised

algorithm. In addition, the proposed approach is very

much insensitive to small variation in measurements

due to spurious noise pick-ups, thus improves recog-

nition accuracy.

The personnel identiﬁcation method introduced

above includes three main steps i) Acquisition of mea-

surement related to movement data of subjects us-

ing Kinect sensor , ii) Feature extraction from the

recorded skeleton data, iii) Decision making from

extracted features. The feature extraction module

extracts the half gait cycle automatically from the

recorded movement data and compute all the fea-

tures F mentioned in (Sinha et al., 2013). The de-

cision making module referred above has three ba-

sic modules in its functional architecture i) a clas-

siﬁer C ii) a clustering algorithm A and iii) a fu-

sion algorithm D. The classiﬁer C is trained with ex-

tracted features set F of training dataset and tested

with unknown input (movement) pattern. A classi-

ﬁcation measure in terms of probability M

is cal-

culated from the classiﬁcation output of the test sub-

ject. The unsupervised clustering algorithm A is used

to group the extracted features into three groups and

a probabilistic measure M

is computed according

to the clustering result for the unknown test data.

Then a fusion algorithm D is used to fuse the two

performance measures M

and M

in order to im-

prove the recognition accuracy of the unknown in-

put. After a careful study, we have realized C by

Support Vector Machine (SVM) (Cortes and Vap-

nik, 1995) with radial basis function (RBF) kernel

and A by Fuzzy C-Means (Bezdek, 1981) (Bezdek

et al., 1984) clustering. It is experimentally found

that the combined SVM-FCM approach improves the

recognition accuracy in comparison to the existing

singleton classiﬁcation or clustering algorithm men-

tioned in (Ball et al., 2012) (Preis et al., 2012) (Sinha

et al., 2013). Any fusion algorithm like Bayesian net-

works (Dempster, 1968) (Jeffreys, 1973), Kalman

ﬁlter (Kalman, 1960), Dempster-Shafer (Dempster,

1967) (Fine, 1977) can be used in the present scheme.

We have used Dempster-Shafer algorithm for realiz-

ing D because of the following reasons.

• It is simple and generalizes probabilistic modeling

and inference;

• It has the capability of making proper distinction

between reasoning and decision taking;

• It properly quantiﬁes

1. The presence of conﬁrming or contradicting in-

formation sources (termed as conﬂict).

2. Low conﬁdence and high conﬁdence results

(termed as ignorance) depending on availabil-

ity of information sources.

This novel approach of fusing SVM & FCM out-

put using Dempster-Shafer algorithm provides an out-

standing performance on human identiﬁcation from

raw Kinect data in comparison to the existing research

outcome in this arena (Ball et al., 2012) (Preis et al.,

2012) (Sinha et al., 2013).

Rest of the paper is organized as follows. In Sec-

tion II we explained the existing state-of-the-art meth-

ods in this context. Section III demonstrates the de-

tails of the proposed fusion based algorithm for per-

son identiﬁcation. The performance evaluation sup-

ported by experimental results are presented in Sec-

tion IV. And ﬁnally we have concluded in Section V.

2 RELATED WORK

People identiﬁcation using gait biometric has created

a great interest in scientiﬁc community due to its

non-intrusive nature of identiﬁcation (Cheng et al.,

2012). Gait recognition can be broadly classiﬁed

into two categories 1) Model-based approach and

2) Model-Free approach (Carlsson, 2000) (Huang

et al., 1999) . In the model-based approach gait

signature are generated by modeling and tracking

different body parts (like limbs, arms, thighs etc.)

over time (Wang et al., 2010), (BenAbdelkader

et al., 2002) where as in model-free approach, fea-

tures are generated based on the change in shape

of human silhouettes over time depending on the

motion dynamics (Sarkar et al., 2005). Either of

model-based and model-free approaches resolve the

issues of each other but suffer from its own limita-

tions. In model-based approach, the feature genera-

tion is view-invariant and scale-independent but sen-

sitive to the quality of gait sequences and computa-

tionally expensive. Similarly in model-free approach

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

172

the feature generation is insensitive to the quality of

silhouettes and offers low computational overhead,

but dependent on the viewpoint and scale. Direct

gait classiﬁcation using standard classiﬁers such as

SVM (Support Vector Machine) (Cortes and Vap-

nik, 1995), K-NN (K-Nearest Neighbors) (Bouchrika

and Nixon, 2008), TSVM (Transductive Support Vec-

tor Machine) (Dadashi et al., 2009), Dynamic Time

Wrapping (DTW) (Kale et al., 2003) and HMM (Hid-

den Markov Model) (Cheng et al., 2008) (Meyer

et al., 1998) are adopted by researchers as mentioned

in (Ball et al., 2012) (Preis et al., 2012) (Sinha et al.,

2013). Xeu et al. (Xue et al., 2010) proposed two fold

fusion mechanism namely multiple feature fusion and

multiple view fusion for human gait identiﬁcation us-

ing Independent Component Analysis (ICA) and Ge-

netic Fuzzy Support Vector Machine (GFSVM) (Xue

et al., 2010) classiﬁers. Moreover, Dempster-Shafer

algorithm had been used in (Le Hegarat-Mascle et al.,

1997) for unsupervised classiﬁcation in multi-source

remote sensing where data fusion is done on pixel

level to successfully identify landcover types. In

this paper we have proposed a probabilistic approach

of fusing the SVM & FCM output using Dempster-

Shafer algorithm. This approach of fusing supervised

and unsupervised learning accuracy in real-time hu-

man identiﬁcation problem is novel to the best of au-

thor’s knowledge and helps in improving the overall

recognition accuracy.

3 ALGORITHMIC APPROACH

The proposed algorithm for people identiﬁcation is

based on the fusion of supervised and unsupervised

algorithms. In this paper, Support Vector Machine

(SVM) (Begg et al., 2005) (Cortes and Vapnik, 1995)

with Radial Basis function kernel is used as super-

vised learning algorithm and for unsupervised learn-

ing we have used Fuzzy C-Means clustering algo-

rithm (Bezdek, 1981)(Bezdek et al., 1984).The mo-

tivation is to partition the training data into three clus-

ters with an aim to partition the subjects by height

(small, medium, tall), by speed (slow, medium, fast),

by the area encompassed (less, medium, large) or by

the angles created by different segments of the body

parts (low, medium, high). The centroids of these

clusters would be stored during the training phase.

Later during the testing, the distances of the new set

of features would be computed from the centroids of

the clusters to derive the probability of the test sub-

ject to belong to a particular cluster.This probability

would be then fused using Dempster-Shafer (DS) the-

ory (Dempster, 1967) (Fine, 1977) with the probabil-

ity obtained from SVM during the testing phase. The

uncertainty in the subjects in the clustering provides

additional information to the fusion algorithm and we

hope that this would improve the overall performance

of the accuracy of detecting an individual.

3.1 Feature Extraction

The feature extraction is an important step in any

machine learning based algorithm. In our personnel

identiﬁcation problem, the feature extraction is per-

formed on every half Gait Cycle. A Gait Cycle is

starting with one foot forward and ending with same

foot forward. We have used a set of area (Sinha et al.,

2013), static (Preis et al., 2012) and dynamic (Sinha

et al., 2013) distances, certain angles (Ball et al.,

2012) and the speed (Preis et al., 2012) as features

derived from the 20 skeleton points. A summary of

these features are given below.

Area Features ( f

).- Mean area occupied by upper

( f

) and lower ( f

) part of the body in half-gait cy-

cle is f

= { f

, f

}. The joints considered are given

below:

Upper body - Shoulder centre, shoulder left, hip left,

hip centre, hip right and shoulder right.

Lower body - Hip centre, hip right, knee right, ankle

right, ankle left, knee left and hip left.

Distance Features ( f

). - The Euclidean distances

of the adjacent joints are the static distances. The

Euclidean distances of centroids of upper and lower

limbs from the upper body centroid are the dynamic

distances as they change while one is walking. The

joints considered for computing the centroids are

given below:

Upper body - shoulder centre, shoulder left, hip left,

hip right and shoulder right.

Right hand - shoulder right, elbow right and wrist

right.

Left hand - shoulder left, elbow left and wrist left.

Right leg - hip right, knee right and ankle right.

Left leg - hip left, knee left and ankle left.

Figure 1 shows the Euclidean distance between upper

body centroid and right hand centroid.

Angle Features ( f

). - These are the angles that vari-

ous segments of the two legs make with the horizontal

and vertical planes (Ball et al., 2012).

Other Features ( f

). - Apart from the above men-

tioned features, we have also considered all the static

and dynamic features mentioned in (Preis et al.,

2012).

The combined gait feature vector used for people

identiﬁcation is of dimension

F = { f

, f

} ∈ R

(1)

KinectbasedPeopleIdentificationSystemusingFusionofClusteringandClassification

173

Figure 1: Euclidean distance between upper body centroid

and right hand centroid.

3.2 Dempster-Shafer Theory (DST)

Dempster-Shafer Theory (Dempster, 1967) (Fine,

1977) , based on the principle of mathematical theory

of evidence (Shafer, 1976), is one of the promising al-

gorithms for combining evidence of different sources

to arrive at a degree (generally termed as belief, de-

ﬁned by a belief function) to which all the current

evidence supports . The theory was ﬁrst proposed

by Arthur P. Dempster (Dempster, 1967) and Glenn

Shafer (Fine, 1977) (Shafer, 1976). It is mainly

a generalized form of Bayesian theory of subjective

probability (Dempster, 1968). Then naturally we will

have to understand basics of Bayesian theory (Jef-

freys, 1973) of subjective probability to apply the

DST in our application.

If unconditional probability of an event A is de-

noted by P(A) and A has a domain of possible values

,...,x

}, then the sum of all probabilities of

A = x

, A = x

....A = x

is always 1. In mathematical

notation it can be expressed as

∑

i=1

P(A = x

) = 1 (2)

The conditional probability of A, given that the event

B has already been occurred, denoted by P(A|B) is

deﬁned by

P(A|B) =

P(A ∩ B)

P(B)

(3)

Suppose we are given P(A) and the conditional prob-

ability P(A|B), then Bayes’ law (Jeffreys, 1973) of

conditional probability is deﬁned as

P(B|A) =

P(A|B) ∗ P(B)

P(A)

(4)

If A has n subsets A

,...,A

, such that A

= ∪A

, where i ∈ [1,n] and B has m partitions

,...,B

, such that B = ∪B

, where j ∈ [1,m],

then by Baye’s law, P(B

) can be expressed as

P(B

) =

P(A

) ∗ P(B

)

∑

k=1

P(A

) ∗ P(B

)

(5)

Bayesian theory mainly assigns a positive belief to

each of the propositions but it does not consider dis-

belief of the proposition. DST addresses this prob-

lem by ensuring fusion of information by considering

both their belief and disbelief. In DST, the set of all

possible outcomes of a random experiment often re-

ferred as frame of discernment (FOD). If a random

experiment has {x

,...,x

} outcomes then FOD is

deﬁned as the universal set.

θ = {x

,...,x

}, where cardinality of θ is n = |θ|

and 2

subsets of θ are called propositions. In DS

theory, we used to assign probability masses to the

subsets of θ unlike Bayesian theory where each ele-

ment is treated as singleton subject. When a source of

evidence assigns probability mass to one of the propo-

sitions, the resulting function is termed as basic prob-

ability of assignment (BPA). In formal notation BPA

is m

where m : 2

→ [0,1]

where 0 ≤ m(x

) ≤ 1 and

m(ϕ) = 0 (ϕ is empty subset o f θ)

and

∑

x⊆θ

m(x) = 1.0 (6)

Belief function for DST over FOD is expressed as

Bel(X) =

∑

Y ⊆ X

m(Y ) (7)

Similarly Uncertainty U(X) of DST is the measure to

which we consider nothing one way or other about

proposition. Plausibility for DST is deﬁned as

Pl(X) = Bel(X) + U(X)

In this theory, probability of a set A ∈ 2

is bounded

by Bel(A) ≤ P(A) ≤ Pl(A). Dempster’s rule of com-

bination (Jsang and Pope, 2012) is used to combine

two independent set of probability masses. If there

are two FOD θ1 and θ2 submitted by two source of

information K1 and K2 respectively and BPA for θ1

and θ2 are m

(.) and m

(.), then the combination of

probability masses (called joint mass) is computed in

the following manner

1,2

(X) = K

−1

∑

X=X

∩X

6=ϕ

) ∗ m

)

and K = 1 −

∑

∩X

=ϕ

) ∗ m

)

(8)

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

174

where X

and X

are focal elements of θ1 and θ2. The

equation (8) is also called orthogonal summation of

belief of functions.

3.3 Application of Dempster-Shafer

Theory (DST) in Person

Identiﬁcation

In our proposed approach, we have combined deci-

sion of clustering and classiﬁcation algorithm using

DST to improve the recognition accuracy.

At ﬁrst we have used supervised learning ap-

proach to solve the problem. In our experiment we

have realized supervised learning algorithm by Sup-

port Vector Machine (SVM). Let us consider a case,

where N-person skeleton data is available for learn-

ing and an unknown input pattern needs to be classi-

ﬁed. For this, we have extracted P-dimensional fea-

ture vector for each of the N persons and form a train-

ing dataset D. Then we can represent each person by a

M×P matrix X

∀ i ∈ [1,N]) where rows (D

dim

) of X

denotes observation and column represents features.

Here M is the total number of rows i.e. observations

for the i

person. The dataset D can be expressed

in terms of X

i.e D = {X

,..X

} (D is of di-

mension D

dim

× P). Now supervised learning algo-

rithm SVM is used to generate a training model using

the data set D. The testing is done using this training

model or in the other words for an unknown input of

dimension K × P, SVM use the training model to la-

bel each of the K observations of the same. Once the

labeling is done for each observation, we generate a

probability score based on the distribution of label-

ing for the unknown input among all the N classes. If

<= K) be the number of observations detected

as class i, then the probability score of unknown input

for class i is deﬁned as

= P

Class

SV M

(i) =

; where i ∈ [1, N]. (9)

We have stored P

SV M

Class

SV M

(1), P

Class

SV M

(2), ...., P

Class

SV M

(N)} for the fu-

sion. In the second phase of our algorithm, we

have used unsupervised learning algorithm where no

training is required on dataset D. In unsupervised

approach, when unknown input of dimension K × P

arrives to the system, it automatically employs Fuzzy

C-Means clustering (FCM) algorithm to group all

the observation (Dataset D plus K × P dimensional

unknown input) into C (where 2 ≤ C ≤ (D

dim

− 1))

clusters. Basically, FCM provides us C cluster

centers and a set of membership values. Then we

have calculated Euclidean distance of each of K

observations of the unknown input from these cluster

centers. According to the Euclidean distance, we

label them as cluster i ∀ i ∈ [1,C] e.g if the observa-

tion O

∀r ∈ [1, K] is nearest to the cluster 3 then it

is labeled as 3. Once the labeling is done for each

of K observations, we generate a probability score

based on the distribution of labeling for the unknown

input among all the C clusters. If n

<= K) be

the number of observations detected as cluster i, then

the probability score of unknown input for cluster i is

deﬁned as

Cluster

FCM

(i) =

; where i ∈ [1,C]. (10)

Then in similar fashion, we store

FCM

= {P

Cluster

FCM

(1), P

Cluster

FCM

(2), ..., P

Cluster

FCM

(C)} for

fusion process.

To apply Dempster-Shafer Theory (DST) for combin-

ing stored probabilistic mass P

FCM

and P

SV M

, we have

deﬁned frame of discernment (FOD) as

FOD = θ

person

= 1,2, 3, ..N ,

where N = total number o f persons (11)

We have also done basic probability assignment P

noise

(BPA) to θ

person

based on noise present in the skeleton

data. In our case, the P

noise

is the degree to which the

system fails to properly identify a person, but it has

the knowledge that the person belongs to the FOD. It

mainly occurs due to the noisy dataset. In our exper-

iment, we have realized P

noise

by considering height

noise (outliers) of the dataset. Here, we assume that

height of all persons should lie between 4feet 5inch

to 6feet 3inch. So, any observation with a height be-

yond this range is treated as height-noise. We com-

puted P

noise

as the ratio of number of observation with

height-noise with respect to the total number of obser-

vation. Moreover we consider that P

noise

only occurs

in the clustering process because SVM used to label

each of K observations of the unknown input in any-

one of the N classes so there is no chance of uncer-

tainty in labeling. In formal notation, P

noise

is deﬁned

noise

(K + D

dim

)

; (12)

where, n

= total number of observation with height-

noise.

In the last phase of our algorithm, we have applied

DST to fuse P

FCM

, P

SV M

and P

noise

to generate joint

mass for i

person using equation (13)

f usion

(i) = K

−1

∑

FCM

∪P

noise

)∩P

SV M

FCM

+ P

noise

) ∗ P

SV M

∀i ∈ [1, N]

where, K = 1 −

∑

FCM

∪P

noise

)∩P

SV M

=ϕ

FCM

+ P

noise

) ∗ P

SV M

(13)

Entire ﬂow of the algorithm is shown in the Fig-

ure 2 and Figure 3.

KinectbasedPeopleIdentificationSystemusingFusionofClusteringandClassification

175

Figure 2: Flowchart of the proposed algorithm.

Figure 3: Flowchart of the proposed algorithm.

4 EXPERIMENTAL RESULTS

We have performed the experiments using 8 subject

dataset (with 7 male and 1 female subjects) and con-

sidering two scenarios i) using singleton supervised

or unsupervised algorithm based identiﬁcation and

ii) our proposed fusion (supervised + unsupervised)

based approach. Throughout our experiments perfor-

mance evaluation and comparison are done using pre-

cision and recall based F

score

metric. All the experi-

ments are performed in a Matlab environment using a

Core-2 Duo Intel platform running at 2.53 GHz. We

have used Windows SDK for Kinect version 1.6 (Mi-

crosoft, 2013) for skeleton data extraction and Lib-

SVM (Chang and Lin, 2011) package for the classiﬁ-

cation.

Initially a kinect device has been used to record

the skeleton data from a distance of 6 feet. Then fea-

ture extraction on each half-gait cycle of the 8 subjects

(A-H) is performed resulting in a 46 dimensional fea-

ture vector. We store these feature vector for 8 persons

as a dataset D. With this feature vector we perform the

identiﬁcation job. As mentioned in the Section 3.3,

we ﬁrst employ Support Vector Machine (SVM) clas-

siﬁer to generate a model using D as input. Now a

new unknown test data is considered which needs to

be identiﬁed from among the known 8 subjects. Fea-

ture vector for the test data is evaluated and SVM test

is performed to obtain a set of probabilities. For e.g.

when a new test data of dimension O × 46 (where

number of observation O = 39) for the subject H is

taken, SVM testing provides us a set of probabilities

(using equation (9)) mentioned in the Table 1.

Table 1: Conﬁdence score using SVM classiﬁer.

Class Label

SVM score (C

)

0.028

0.153

0.111

0.097

0.069

0.084

0.0

0.458

Decision

Detected

Now we have stored SVM score C

∀i ∈ [1, 8] in

an array P

SV M

for the fusion process. P

SV M

=[ 0.028,

0.153, 0.111, 0.097, 0.069, 0.084, 0, 0.458].

In the next step, fuzzy c-means (FCM) clustering is

performed with 3 clusters on dataset D along with the

test data. Then labeling is done for each of the obser-

vation of test data with respect to its Euclidean dis-

tance from each of the centers. For our example, we

have labeled each of O observations as cluster 1 or

cluster 2 or cluster 3, according to its Euclidean dis-

tance from 3 cluster centers. In the other words, if

any observation is nearer to cluster 1, it is labeled as

1. Once the labeling is done, we calculate probability

of observation belonging to a particular cluster with

respect to total number of observation. For our exam-

ple case, the probabilities obtained for three clusters

(using equation (10)), are tabulated in the Table 2. In

similar fashion, FCM score are also stored in an array

FCM

to perform the work of fusion

Table 2: Conﬁdence score using FCM.

Cluster Label

Cluster 1

Cluster 2

Cluster 3

FCM Score (P

Cluster

FCM

(i))

0.3073

0.3072

0.3473

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

176

FCM

=[0.3073 0.3072 0.3473].

For the fusion process by Dempster-Shafer theory, we

have also computed uncertainty by equation (12).

Uncertainty = P

noise

= 0.0382.

Now, fusion score (joint mass) is computed by com-

bining individual scores P

SV M

, P

FCM

and P

noise

using

equation (13). Fusion score for subject H is shown in

Table 3.

Table 3: Fusion score for subject H.

Class Label

Fusion score

f usion

(i))

0.017

0.072

0.098

0.022

0.02

0.024

0.675

Decision

Detected

Cluster

FCM

(1)

Cluster

FCM

(2)

Cluster

FCM

(3)

noise

Figure 4: Fusion using Dempster-Shafer Theory.

K mentioned in the equation (13) is the sum of

area of the shaded portion shown in the Figure 4 and

calculated as K = 0.3699.

It can be observed from Table 3, that the unknown

input pattern is not only correctly identiﬁed as Person

8 (subject H), with fusion score P

f usion

(8) = 0.675, but

also has better conﬁdence score than singleton SVM

classiﬁer(mentioned in Table 1 as C

= 0.458). So,

experimental results proves that our proposed fusion

algorithm using Dempster-Shafer theory is perform-

ing better and able to identify the person H with im-

proved level of accuracy.

Next we analyze the overall improvement in conﬁ-

dence score of recognition using the confusion matri-

ces for the above mentioned two approaches namely

with fusion and without fusion i.e. only using SVM

as classiﬁer.

The resulting recognition accuracy using SVM in

terms of F

score

is shown in the Table 4. Then we have

applied our proposed algorithm under the same cir-

Table 4: Conﬁdence score using SVM for different test sub-

jects (green means detected, TS= Test Subject and GT =

Ground Truth).

T S

A B C D E F G H

0.590

0.026 0.0 0.076 0.0 0.1030.205 0.0

B 0.2040.510 0.082 0.102 0.0 0.020 0.0 0.082

C 0.1160.256

0.419

0.0700.070 0.0 0.023 0.046

D 0.071

0.0950.095

0.6670.0240.048 0.0 0.0

E 0.0 0.121 0.030 0.030

0.769

0.0 0.0 0.061

F 0.054 0.0 0.0 0.162 0.0 0.7300.054 0.0

G 0.037 0.0 0.0 0.0 0.0 0.0

0.963

0.0

H 0.028 0.153 0.111

0.0970.069

0.084 0.0 0.458

Table 5: Fusion score for different test subjects (green

means detected, TS= Test Subject and GT = Ground Truth).

T S

A B C D E F G H

A 0.617 0.023 0.0 0.075 0.0 0.100 0.185 0.0

B 0.1440.573

0.092

0.083 0.0 0.016

0.0

0.092

0.1190.293

0.4270.0410.041 0.0 0.0260.053

D 0.038 0.071 0.050

0.759

0.0280.054 0.0 0.0

E 0.0 0.111 0.028 0.031

0.769

0.0 0.0 0.061

0.009

0.0 0.0 0.116 0.0 0.836

0.039

0.0

0.009

0.0 0.0 0.0 0.0 0.0

0.991

0.0

H 0.017 0.072 0.072

0.098

0.022 0.02 0.0240.675

cumstances and the results are presented in the Ta-

ble 5.

Diagonal of these two tables (Table 4 and Table 5)

clearly helps us to understand that the fusion of SVM

and FCM score improves the recognition accuracy for

all the subjects. The recognition accuracy with fusion

and without fusion for all the subjects are summa-

rized in terms of average F

score

in Table 6. Therefore

one can clearly infer that the proposed fusion based

method outperforms any existing singleton approach

for person identiﬁcation. One thing that needs to be

mentioned here is that we have not reported the per-

formance metric of person identiﬁcation using only

unsupervised algorithm because the reported recogni-

tion accuracy by Ball et.al in (Ball et al., 2012) for

only four persons using K-Means algorithm is only

43%.

Table 6: Performance comparison between without fusion

and with fusion.

Without Fusion With Fusion

0.64 0.71

KinectbasedPeopleIdentificationSystemusingFusionofClusteringandClassification

177

5 CONCLUSIONS

In this paper we have proposed a novel approach

based on fusion of supervised and unsupervised learn-

ing algorithm using Dempster-Shafer theory in deﬁn-

ing the ﬁnal decision metric of human identiﬁcation.

Results indicate that the combination of our proposed

fusion algorithm outperforms existing framework of

person identiﬁcation in real time. As a future work,

we would be experimenting on gait independent fea-

tures, which would further improve the robustness of

the system by getting rid of gait boundary detection,

as well as remove the constraint on the side walk.

REFERENCES

Ball, A., Rye, D., Ramos, F., and Velonaki, M. (2012). Un-

supervised clustering of people from ’skeleton’ data.

In Proceedings of the seventh annual ACM/IEEE in-

ternational conference on Human-Robot Interaction

(HRI), pages 225–226.

Begg, R. K., Palaniswami, M., and Owen, B. (2005). Sup-

port vector machines for automated gait classiﬁca-

tion. IEEE Transactions on Biomedical Engineering,

52(5):828–838.

BenAbdelkader, C., Cutler, R., and Davis, L. (2002). Stride

and cadence as a biometric in automatic person iden-

tiﬁcation and veriﬁcation. In Fifth IEEE International

Conference on Automatic Face and Gesture Recogni-

tion, pages 372–377.

Bezdek, J. C. (1981). Pattern Recognition with Fuzzy Ob-

jective Function Algoritms. Plenum Press, New York.

Bezdek, J. C., Ehrlich, R., and Full, W. (1984). Fcm:

The fuzzy cmeans clustering algorithm. Computers

& Geosciences, 10(2):191–203.

Bouchrika, I. and Nixon, M. S. (2008). Exploratory factor

analysis of gait recognition. In 8th IEEE International

Conference on Automatic Face & Gesture Recogni-

tion, 2008. FG’08, pages 1–6. IEEE.

Carlsson, S. (2000). Recognizing walking people. In Pro-

ceedings of the 6th European Conference on Com-

puter Vision (ECCV ) -Part I, pages 472–486.

Chang, C.-C. and Lin, C.-J. (2011). Libsvm: a library for

support vector machines. ACM Transactions on Intel-

ligent Systems and Technology (TIST), 2(3):27.

Cheng, L., Sun, Q., Su, H., Cong, Y., and Zhao, S. (2012).

Design and implementation of human-robot interac-

tive demonstration system based on kinect. In Control

and Decision Conference (CCDC), 2012 24th Chi-

nese, pages 971–975. IEEE.

Cheng, M.-H., Ho, M.-F., and Huang, C.-L. (2008). Gait

analysis for human identiﬁcation through manifold

learning and hmm. Pattern recognition, 41(8):2541–

2553.

Cortes, C. and Vapnik, V. (1995). Support-vector networks.

Mach. Learn., 20(3):273–297.

Dadashi, F., Araabi, B., and Soltanian-Zadeh, H. (2009).

Gait recognition using wavelet packet silhouette rep-

resentation and transductive support vector machines.

In 2nd International Congress on Image and Signal

Processing, 2009. CISP ’09, pages 1–5.

Dempster, A. P. (1967). Upper and lower probabilities in-

duced by a multivalued mapping. The annals of math-

ematical statistics 38, (2):325–339.

Dempster, A. P. (1968). A generalization of bayesian infer-

ence. Journal of the Royal Statistical Society. Series

B (Methodological), pages 205–247.

Fine, T. L. (1977). Review: Glenn shafer, a mathematical

theory of evidence. Bulletin (New Series) of the Amer-

ican Mathematical Society 83, (4):667–672.

Huang, P., Harris, C., and Nixon, M. (1999). Human gait

recognition in canonical space using temporal tem-

plates. IEE Proceedings- Vision, Image and Signal

Processing, 146(2):93–100.

Jeffreys, H. (1973). Scientiﬁc Inference (3rd ed.). Cam-

bridge University Press p. 31.

Jsang, A. and Pope, S. (2012). Dempsters rule as seen by

little colored balls. Computational Intelligence 28,

(4):453–474.

Kale, A., Cuntoor, N., Yegnanarayana, B., Rajagopalan, A.,

and Chellappa, R. (2003). Gait analysis for human

identiﬁcation. In Audio-and Video-Based Biometric

Person Authentication, pages 706–714. Springer.

Kalman, R. E. (1960). A new approach to linear ﬁltering

and prediction problems. Transactions of the ASME

Journal of Basic Engineering, (82 (Series D)):35–45.

Karem, F., Dhibi, M., and Martin, A. (2012). Combina-

tion of supervised and unsupervised classiﬁcation us-

ing the theory of belief functions. In Belief Functions:

Theory and Applications, pages 85–92. Springer.

Le Hegarat-Mascle, S., Bloch, I., and Vidal-madjar (1997).

Application of dempster-shafer evidence theory to un-

supervised classiﬁcation in multisource remote sens-

ing. IEEE Transactions on Geoscience and Remote

Sensing, 35(4):1018–1031.

Meyer, D., Psl, J., and Niemann, H. (1998). Gait classiﬁca-

tion with hmms for trajectories of body parts extracted

by mixture densities. In British Machine Vision Con-

ference, pages 459–468.

Microsoft (2013). Kinect for windows. http://

www.microsoft.com/en-us/kinectforwindows/develop/

developer-downloads.aspx. [Online; accessed

25-July-2013].

Pal, N. R. and Chintalapudi, K. K. (1997). A connection-

ist system for feature selection. Neural Parallel Sci.

Comput, 5(3):359381.

Preis, J., Kessel, M., Werner, M., and Linnhoff-Popien, C.

(2012). Gait recognition with kinect. In 1st Interna-

tional Workshop on Kinect in Pervasive Computing.

Sarkar, S., Phillips, P., Liu, Z., Vega, I., Grother, P., and Or-

tiz, E. (2005). The humanid gait challenge problem:

data sets, performance, and analysis. In IEEE Trans-

actions on Pattern Analysis and Machine Intelligence,

volume 27, pages 162–177.

Shafer, G. (1976). A mathematical theory of evidence Vol.

1. Princeton: Princeton university press.

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

178

Sinha, A., Chakravarty, K., and Bhowmick, B. (2013).

Person identiﬁcation using skeleton information from

kinect. In The Sixth International Conference on

Advances in Computer-Human Interactions (ACHI),

pages 101–108.

Wang, J., She, M., Nahavandi, S., and Kouzani, A. (2010).

A review of vision-based gait recognition methods for

human identiﬁcation. In International Conference on

Digital Image Computing: Techniques and Applica-

tions (DICTA), pages 320 – 327.

Xue, Z., Ming, D., Song, W., Wan, B., and Jin, S. (2010).

Infrared gait recognition based on wavelet trans-

form and support vector machine. Pattern Recogn.,

43(8):2904–2910.

KinectbasedPeopleIdentificationSystemusingFusionofClusteringandClassification

179
