Constructing Facial Expression Log from Video Sequences using

Face Quality Assessment

Mohammad A. Haque, Kamal Nasrollahi and Thomas B. Moeslund

Visual Analysis of People Laboratory, Aalborg University (AAU),

Sofiendalsvej 11, 9200 Aalborg, Denmark

Keywords: Facial Expression Log, Face Quality Assessment, Automatic Face Detection and Processing, Facial

Expression Recognition.

Abstract: Facial expression logs from long video sequences effectively provide the opportunity to analyse facial

expression changes for medical diagnosis, behaviour analysis, and smart home management. Generating

facial expression log involves expression recognition from each frame of a video. However, expression

recognition performance greatly depends on the quality of the face image in the video. When a facial video

is captured, it can be subjected to problems like low resolution, pose variation, low brightness, and motion

blur. Thus, this paper proposes a system for constructing facial expression log by employing a face quality

assessment method and investigates its influence on the representations of facial expression logs of long

video sequences. A framework is defined to incorporate face quality assessment with facial expression

recognition and logging system. While assessing the face quality a face-completeness metric is used along

with some other state-of-the-art metrics. Instead of discarding all of the low quality faces from a video

sequence, a windowing approach has been applied to select best quality faces in regular intervals.

Experimental results show a good agreement between the expression logs generated from all face frames

and the expression logs generated by selecting best faces in regular intervals.

1 INTRODUCTION

Facial analysis systems now-a-days have been

employed in many applications including

surveillance, medical diagnosis, biometrics,

expression recognition and social cue analysis

(Cheng et al.,, 2012). Among these, expression

recognition received remarkable attention in last few

decades after an early attempt to automatically

analyse facial expressions by (Suwa, 1978).

In general, human facial expression can express

emotion, intension, cognitive processes, pain level,

and other inter- or intrapersonal meanings (Tian,

2011). For example, Figure 1 depicts five emotion-

specified facial expressions (neutral, anger, happy,

surprise, and sad) of a person’s image from a

database of (Kanade, 2000). When facial expression

conveys emotion and cognitive processes, facial

expression recognition and analysis systems find

their applications in medical diagnosis for diseases

like delirium and dementia, social behaviour

analysis in meeting rooms, offices or classrooms,

and smart home management (Bonner, 2008, Busso,

2007, Dong, 2010, Doody, 2013, Russell, 1987).

However these applications often require analysis of

facial expressions acquired from videos in a long

time-span. A facial expression log from long video

sequences can effectively provide this opportunity to

analyse facial expression changes in a long time-

span. Examples of facial expression logs for four

basic expressions found in an example video

sequence are shown in Figure 2, where facial

expression intensities (0-100), assessed by an

expression recognition system, are plotted against

the video sequence acquired from a camera.

Figure 1: Five emotion-specified facial expressions for the

database of (Kanade, 2000): (left to right) neutral, anger,

happy, surprise, and sad.

Recognition of facial expressions from the

frames of a video is essentially the primary step of

generating facial expression log. As shown in Figure

3, a typical facial expression recognition system

517

A. Haque M., Nasrollahi K. and B. Moeslund T..

Constructing Facial Expression Log from Video Sequences using Face Quality Assessment.

DOI: 10.5220/0004730105170525

In Proceedings of the 9th International Conference on Computer Vision Theory and Applications (VISAPP-2014), pages 517-525

ISBN: 978-989-758-004-8

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

from video consists of three steps: face acquisition,

feature mining, and expression recognition. Face

acquisition step find the face from video frames by a

face detector or tracker. Feature mining step extracts

geometric and appearance based features from the

face. The last step, i.e., expression recognition

employs learned classifiers based on the extracted

features and recognizes expressions.

(a) Angry (b) Happy

Figure 2: An illustration of facial expression log for four

basic expressions found in a video, where vertical axis

presents the intensities of expression corresponding to the

sequence in the horizontal axis.

Figure 3: Steps of a typical facial expression recognition

system.

Generating facial expression log from a video

sequence involves expression recognition from each

frame of the video. However, when a video based

practical image acquisition system captures facial

image in each frame, many of these images are

subjected to the problems of low resolution, pose

variation, low brightness, and motion blur (Fang et

al., 2008). In fact, most of these low quality images

rarely meet the minimum requirements for facial

landmark or expression action unit identification.

For example, a face region with size 96x128 pixels

or 69x93 pixels can be used for expression

recognition. However, a face region with size 48x64

pixels, 24x32 pixels, or less is not likely to be used

for expression recognition (Tian, 2011). This state of

affairs can often be observed in scenarios where

facial expression log is used from a patient’s video

for medical diagnosis, or from classroom video for

social cue analysis. Extracting features for

expression recognition from a low quality face

image often ends up with erroneous outcome and

wastage of valuable computation resource.

In order to get rid of the problem of low quality

facial image processing, a face quality assessment

technique can be employed to select the qualified

faces from a video. As shown in Figure 4, a typical

face quality assessment method consists of three

steps: video frame acquisition, face detection in the

video frames using a face detector or tracker, face

quality assessment by measuring face quality

metrics (Mohammad, 2013). Face quality

assessment in video before further application

reduces significant amount of disqualified faces and

keeps the best faces for subsequent processing.

Thus, in this paper, we propose a facial expression

log construction system by employing face quality

assessment and investigate the influence of Face

Quality Assessment (FQA) on the representation of

facial expression logs of long video sequences.

Figure 4: Steps of a typical facial image acquisition

system with face quality measure.

The rest of the paper is organized as follows:

Section 2 presents the state-of-the-art and Section 3

describes the proposed approach. Section 4 states the

experimental environment and results. Section 5

concludes the paper.

2 STATE-OF-THE-ARTS

The first step of facial expression recognition is

facial image acquisition, which is accomplished by

employing a face detector or tracker. Real-time face

detection from video was a very difficult problem

before the introduction of Haar-like feature based

Viola and Jones object detection framework (Viola,

2001). Lee et al. and Ahmed et al. proposed two face

detection methods based on saliency map (Lee,

2011, Ahmad, 2012). However, these methods,

including the Viola and Jones one, merely work real-

time for low resolution images. Thus, few methods

100

150

103

137

171

100

150

103

137

171

100

150

103

137

171

100

150

103

137

171

Face acquisition

from video

Feature

mining

Expression

Recognition

Further

Processing

Images from

Video Frames

Face Detection

from the Frames

Face Quality Assessment

and Selecting Best Faces

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

518

address the issues of high resolution face image

acquisition by employing high resolution camera or

pan-tilt-zoom camera (Cheng et al., 2012, Dinh,

2011). On the other hand, some methods addressed

the problem by speeding up the face detection

procedure in a high resolution image (Mustafa,

2007, 2009). When a face is detected in a video

frame, instead of detecting the face in further frames

of that video clip, it can be tracked. Methods for

tracking face in video frames from still cameras and

active pan-tilt-zoom cameras are proposed in

(Corcoran, 2007) and (Dhillon, 2009, and Dinh,

2009), respectively.

A number of methods proposed for face quality

assessment and/or face logging. Nasrollahi et al.

proposed a face quality assessment system in video

sequences by using four quality metrics: resolution,

brightness, sharpness, and pose (Nasrollahi, 2008).

Mohammad et al. utilized face quality assessment

while capturing video sequences from an active pan-

tilt-zoom camera (Mohammad, 2013). In (Axnick,

2009, Wong, 2011), two face quality assessment

methods have been proposed in order to improve

face recognition performance. Instead of using

threshold based quality metrics, (Axnick, 2009) used

a multi-layer perceptron neural network with a face

recognition method and a training database. The

neural network learns effective face features from

the training database and checks these features from

the experimental faces to detect qualified candidates

for face recognition. On the other hand, Wong et al.

used a multi-step procedure with some probabilistic

features to detect qualified faces (Wong, 2011).

Nasrollahi et al. explicitly addressed posterity facial

logging problem by building sequences of increasing

quality face images from a video sequence

(Nasrollahi, 2009). They employed a method which

uses a fuzzy combination of primitive quality

measures instead of a linear combination. This

method was further improved in (Bagdanov, 2012)

by incorporating multi-target tracking capability

along with a multi-pose face detection method.

A number of complete facial expression

recognition methods have been proposed in the

literature. Most of the methods, however, merely

attempt to recognize few most frequently occurred

expressions such as angry, sad, happy, and surprise

(Tian, 2011). In order to recognize facial

expressions, some methods merely used geometric

features (Cohn, 2009), some methods merely used

appearance features (Bartlett et al., 2006), and some

methods used both (Wen, 2003). While classifying

the expressions from the extracted features, most of

the well-known classifiers have been tested in the

literature. These include neural network (NN),

support vector machines (SVM), linear discriminant

analysis (LDA), K-nearest neighbour (KNN), and

hidden Markov models (HMM) (Tian, 2011).

3 THE PROPOSED APPROACH

A typical facial expression logging system from

video consists of four steps: face acquisition, feature

mining, expression recognition, and log

construction. On the other hand, a typical FQA

method in video consists of three steps: video frame

acquisition, face detection in the video frames using

a face detector or tracker, FQA by measuring face

quality metrics. However, as discussed in Section 1,

the performance of feature mining and expression

recognition highly depends on the quality of the face

region in video frames. Thus, in this paper, we

proposed an approach to combine a face quality

assessment method with a facial expression logging

system. The overall idea of combining these two

approaches into one is depicted in Figure 5. Before

passing the face region of video frames to the feature

extraction module, the FQA module discards the

non-qualified faces. The architecture of the proposed

system is depicted in Figure 6 and described in the

following subsections.

Figure 5: Face quality is assessed before feature extraction

is attempted for expression recognition.

3.1 Face Detection Module

This module is responsible to detect face in the

image frames. The well-known Viola and Jones face

detection approach has been employed from (Viola,

2001). This method utilizes so called Haar-like

features in a linear combination of some weak

classifiers to form a strong classifier to perform a

face and non-face classification by using an adaptive

boosting method. In order to speed up the detection

process an evolutionary pruning method from (Jun-

Su, 2008) is employed to form strong classifiers

using fewer classifiers. In the implementation of this

article, the face detector was empirically configured

using the following constants:

 Minimum search window size: 40x40 pixels

Face

detection

Feature

extraction

Expression

recognition

Face quality

assessment

ConstructingFacialExpressionLogfromVideoSequencesusingFaceQualityAssessment

519

in the initial camera frames

 The scale change step: 10% per iteration

 Merging factor: 2 overlapping detections

The face detection module continuously runs and

tries to detect face in the video frames. Once a face

is detected, it is passed to the Face Quality

Assessment (FQA) module.

Figure 6: The block diagram of the proposed facial

expression log construction system with face quality

assessment.

3.2 Face Quality Assessment Module

FQA module is responsible to assess the quality of

the extracted faces. Four parameters that can

effectively determine the face quality have been

selected in (Nasrollahi, 2008) for surveillance

applications. These parameters are: out-of-plan face

rotation (pose), sharpness, brightness, and

resolution. All these metrics have remarkable

influence in expression recognition. However, the

difference between a typical surveillance application

and an expression logging system entails exploration

of some other face quality metrics. For example,

face completeness can be an important measure for

face quality assessment before expression

recognition. This is because features for expression

recognition are extracted from different components

of a face, more specifically from eyes and mouth. If

a facial image doesn’t clearly contain these

components, it is difficult to measure expressions.

Thus, we calculate a face completeness parameter,

along with four other parameters from (Nasrollah,

2008), by detecting the presence of the eyes and the

mouth in a facial image. A normalized score is

obtained in the range of [0:1] for each quality

parameter and a linear combination of scores has

been utilized to generate single score.

The basic calculation process of some FQA

parameters is described in (Mohammad, 2013). We,

however, include a short description below for the

readers’ interest by incorporating necessary changes

to fit these mathematical models with the

requirement of constructing facial expression log.

 Pose estimation - Least out-of-plan rotated face:

The face ROI (Region of Interest) is first

converted into a binary image and the center of

mass is calculated using:





jiib







(1)





jijb







(2)

Then, the geometric center of face region is

detected and the distance between the center of

region and the center of mass is calculated by:

)()(

mcmc

yyxxDist 

(3)

Finally the normalized score is calculated by:

Dist

Pose



(4)

Where





yx ,

is the center of mass, b is the

Frames from

Camera

Face Detection from

the Frames

Face Detection

Extracted Faces from the

Tracked Area

Selecting & Storing

Best Faces after FQA

Face Qualit

Assessment

(

FQA

)

Feature extraction from

the qualified faces

Expression recognition

using extracted features

Facial Ex

ression Reco

nition

Facial expression log

Camera capture

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

520

binary face image, m is the width, n is the

height, A is the area of the image, x

, x

and y

, y

are the boundary coordinates of the face, and

Dist

is an empirical threshold used in

(Mohammad, 2013).

 Sharpness: Sharpness of a face image can be

affected by motion blur or an unfocused capture.

This can be measured by:

 

yxlowAyxAabsSharp ,,





(5)

Sharpness’s associated score is calculated by:

Sharp

P 

(6)

Where, lowA(x,y) is the low-pass filtered

counterpart of the image A(x,y), and Sharp

is an

empirical threshold used in (Mohammad, 2013).

 Brightness: This parameter measures whether a

face image is too dark to use. It is calculated by

the average value of the illumination component

of all pixels in an image. Thus, the brightness of

a frame is calculated by (6), where I(i,j) is the

intensity of pixels in the face image.





















jiI

Bright

(7)

Brightness’s associated score is calculated by:

Bright

P 

(8)

Where, Bright

is an empirical threshold used in

(Mohammad, 2013).

 Image size or resolution: Depending upon the

application, face images with higher resolution

may yield better results than lower resolution

faces (Axnick, 2009, Long, 2011). The score for

image resolution is calculated by (10), where w is

image width, h is image height, Width

and

Height

are two thresholds for expected face

height and width, respectively. From the study of

(Nasrollahi, 2008), we selected the values of the

thresholds 50 and 60, respectively.



















thth

Size

Height

Width

P ,1min

(9)

 Face completeness: This parameter measures

whether the key face components for expression

recognition can be detected automatically from

the face. In this study, we selected eyes and

mouth region as the key components of face and

obtain the score using the following rule:



leidentifiabarecomponentsif

leidentifiabnotarecomponentsifssCompletene



(10)

The final single score for each face is calculated by

linearly combining the abovementioned 5 quality

parameters with empirically assigned weight factor,

as shown in (10):





Score

Quality

(11)

Where, w

are the weight associated with P

, and

are the score values for the parameters pose,

sharpness, brightness, resolution, and completeness

consecutively. Finally, the best quality faces are

selected by observing the Quality

Score

. The detail

procedure of selection the best faces for expression

logging is described in the following section.

3.3 Facial Expression Recognition and

Logging

This module recognizes facial expressions from

consecutive video frames and plots the expression

intensities against time in separate graphs for

different expressions. In this paper, we use an off-

the-shelf expression recognition technique from

(Kublbeck, 2006), which is implemented in SHORE

library (Fraunhofer IIS, 2013). An appearance based

modified census transformation is used in this

method for face detection and expression intensity

measurement. In fact, the eye-region, nose-region

and mouth region represent the expression variation

in face appearance, as shown in Figure 6. Changes in

patterns of these regions are obtained by employing

the transformation. Four frequently occurred

expressions are measured by this system: angry,

happy, sad, and surprize.

The next step after expression recognition is the

construction of facial expression log. Four graphs

are created for four expressions from a video

sequence. As generating expression log from the

faces of consecutive frames of a video suffers

significantly due to erroneous expression recognition

from low quality faces from the video frames,

generating log by merely using the high quality

faces can be a solution. However, discarding low

quality face frames from video generate

discontinuity in the expression log, especially if a

large number of consecutive face frames contain low

quality face. Thus, we employed a windowing

approach in order to ensure continuity of the

expression log while assuring an acceptable

similarity with the expression log from all faces and

expression log from qualified faces. The approach

works by selecting the best face among n

consecutive faces, where n is the window size

indicating the number of video frames in each

ConstructingFacialExpressionLogfromVideoSequencesusingFaceQualityAssessment

521

window. When plotting the expression intensities

into the corresponding graphs of the expressions,

instead of plotting values for all face frames, the

proposed approach merely plots the value for the

best face frame in each window. The effect of

discarding the expression intensity score for other

frames of the window is shown in the experimental

result section.

4 EXPERIMENTAL RESULTS

4.1 Experimental Environment

The underlying algorithms of the experimental

system were implemented in a combination of

Visual C++ and Matlab environments. As the

existing online datasets merely contain images or

videos of good quality faces rather than mixing of

good and bad quality faces, to evaluate the

performance of the proposed approach we recorded

several video sequences from different subjects by

using a camera setup. Faces were extracted from the

frames of 8 experimental video clips (named as, Sq1,

Sq2, Sq3, Sq4, Sq5, Sq6, Sq7, and Sq8) having 1671

video frames, out of which 950 frames contain

detectable faces with different facial expressions.

Face quality assessment and expression

recognition were performed to generate the results.

Four basic expressions were used for recognition:

happy, angry, sad, and surprise. Two types of facial

expression logs were generated: first type shows the

facial expression intensities of each face frames of

video (Type1), and the other type shows the facial

expression intensities of the best faces in each

consecutive window with n-frames of the video

(Type2). In order to compare Type1 and Type2

representations, we calculate normalized maximum

cross-correlation magnitudes of both graphs for each

expression (Briechle, 2001). Higher magnitude

implies more similarity between the graphs.

4.2 Performance Evaluation

The experimental video clips were passed through

the face detection module and face quality metrics

were calculated after detecting faces. As an example,

Figure 7 shows the Quality

Score

for each face frames

of the video sequence Sq1, where the score is plotted

against the video frame index. From the figure it is

observed that some of the faces may exhibit poor

quality score as low as 40%. If these low quality

faces are sent to the expression recognition module

the recognition performance will be significantly

suffered.

Figure 7: Face quality score calculated by the FQA

module for 200 face frame of experimental video sequence

Sq1.

Facial expression recognition module measures

the intensity of each facial expression for each face

of the frames of a video, and then facial expression

logs were generated. Figure 8 illustrates two types of

expression logs for the experimental video sequence

Sq1, where the window size n was set to 3 for

selecting best faces. The graphs at the left of each

rows of Figure 8 present the Type1 graph and the

graphs at the right presents corresponding Type2

graph. When we visually analysed and compared

Type1 and Type2 graphs, we observed temporal

similarity between these two facial expression logs

from the same video sequence due to the application

of windowing approach.

In order to formalize this observation, we

showed a normalized maximum cross-correlation

magnitude similarity measure between these two

representations of the video sequences for all four

expressions by varying the window size n. The

results are summarized in Table 1 and Table 2 for

window sizes 3 and 5, respectively. From the results,

it is observed that discarding more faces decreases

similarity between Type1 and Type2 graphs. For

some sequences, changing the window size doesn’t

have much effect for some expression modalities.

This is due to non-variable expression in these video

sequences. However, in order to keep agreement

with other modalities, the window size should be

kept same. For example, in Sq3 the results for the

expressions of happiness, sadness and surprise aren’t

affected much by the change of window size.

Moreover, some expression exhibited very high

0,1

0,2

0,3

0,4

0,5

0,6

0,7

0,8

0,9

109

121

133

145

157

169

181

193

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

522

dissimilarity even for a very small window size. This

is because the expression in that video sequence

changed very rapidly, and thus discarding face frame

discards expression intensity values too. On the

other hand, discarding more faces by setting a higher

window size reduces the computational power

consumption geometrically. Thus, the window size

should be defined depending upon the application

the expression log is going to be used.

a) Happy

b) Angry

c) Sad

d) Surprise

Figure 8: Facial expression log for the experimental video

sequence Sq1 (the left graphs are from all face frames, and

the right graphs are from selected best quality face frame

by the windowing method with 3-frames per window).

5 CONCLUSIONS

This paper proposed a facial expression log

construction system by employing face quality

assessment and investigated the influence of face

quality assessment on the representation of facial

expression logs of long video sequences. A step by

step procedure was defined to incorporate face

quality assessment with facial expression

recognition system and finally the facial expression

logs were generated. Instead of discarding all of the

low quality faces, a windowing approach was

applied to select best quality faces in a regular

interval. Experimental results shows a good

agreement between expression logs generated from

all face frames and expression logs generated by

selecting best faces in a regular interval.

Table 1: Similarity between Type1 and Type2 graphs,

when window size is 3 (higher value implies more

similarity).

Angry Happy Sad Surprise Average

Sq1 0.60 0.94 0.80 0.90 0.81

Sq2 0.81 0.97 1.00 0.77 0.89

Sq3 0.70 0.99 1.00 1.00 0.92

Sq4 0.52 0.97 1.00 1.00 0.87

Sq5 0.62 0.99 1.00 1.00 0.90

Average similarity for n=3 0.88

Table 2: Similarity between Type1 and Type2 graphs,

when window size is 5 (higher value implies more

similarity).

Angry Happy Sad Surprise Average

Sq1 0.31 0.54 0.49 0.53 0.47

Sq2 0.44 0.50 1.00 0.46 0.60

Sq3 0.57 1.00 1.00 1.00 0.89

Sq4 1.00 0.46 1.00 1.00 0.86

Sq5 1.00 0.46 1.00 1.00 0.86

Average similarity for n=5 0.73

As the future works, we will analyse the face

quality assessment metrics individually and their

impact on facial expression recognition. In the

construction of facial expression log, a formal model

needs to define by addressing the questions such as

how to address discontinuity of face frame while

making the log, how to improve face quality

assessment, how to select optimum window size for

discarding non-qualified face frames, how to include

motion information for missing face frames while

generating face log.

100

150

103

137

171

100

150

1 10192837465564

100

150

103

137

171

100

150

1 10192837465564

100

150

103

137

171

100

150

1 10192837465564

100

150

117

146

175

100

150

1 10192837465564

ConstructingFacialExpressionLogfromVideoSequencesusingFaceQualityAssessment

523

REFERENCES

Ahmed, E. L., Rara, H., Farag, A., and Womble, P., 2012.

“Face Detection at a distance using saliency maps,”

IEEE Conf. on Computer Vision and Pattern

Recogntion Workshops, pp. 31-36.

Axnick, K., Jarvis, R., and Ng, K. C., 2009. “Using Face

Quality Ratings to Improve Real-Time Face

Recognition,” Proc. of the 3

Pacific Rim Symposium

on Advances in Image and Video Technology, pp. 13-

24.

Bagdanov, A. D., and Bimbo, A. D., 2012. “Posterity

Logging of Face Imagery for Video Surveillance,”

IEEE MultiMedia, vol. 19, no. 4, pp. 48-59.

Bartlett, M., Littlewort, G., Frank, M., Lainscsek, C.,

Fasel, I., and Movellan, J., 2006. “Fully Automatic

Facial Action Recognition in Spontaneous Behavior,”

Int. COnf. on Automatic Face and Gesture

Recogntion, pp. 223-230.

Bonner, M. J. et al., 2008. “Social Functioning and Facial

Expression Recognition in Survivors of Pediatric

Brain Tumors”, Journal of Pediatric Psychology, vol.

33, no. 10, pp. 1142-1152, 2008.

Briechle, K., and Hanebeck, U. D., 2001. “Template

Matching using Fast Normalized Cross Correlation,”

Proc. of SPIE Aero Sense Symposium, vol. 43-87, pp.

1-8.

Busso, C., Narayanan, S. S., 2007. “Interrelation between

Speech and Facial Gestures in Emotional Utterances:

A single subject study”, IEEE Trans. On Audio,

Speech and Language Processing, pp. 1-16.

Cheng, X., Lakemond, R., Fookes, C., and Sridharan, S.,

2012. “Efficient Real-Time Face Detection For High

Resolution Surveillance Applications,” Proc. Of the

Int. Conf. on Signal Processing and

Communication Systems, pp.1-6.

Cohn, J., Kreuz, T., Yang, Y., Nguyen, M., Padilla, M.,

Zhou, F., and Fernando, D., 2009, “Detecting

depression from facial action and vocal prosody,”

Proc. of the Int. Conf. on Affective Computing and

Intelligent Interaction.

Corcoran, P., Steingerg, E., Bigioi, P., and Brimbarean,

A., 2007. “Real-Time Face Tracking in a Digital

Image Acquisition Device,” European Patent No. EP

2 052 349 B1, pp. 25.

Dhillon, P. S., 2009. “Robust Real-Time Face Tracking

Using an Active Camera,” Advances in Intellignet and

Soft Computing: Computational Intelligences in

Security for Information Systems, vol. 63, pp. 179-186.

Dinh, T., Yu, Q., and Medioni, G., 2009. “Real Time

Tracking using an Active Pan-Tilt-Zoom network

Camera,” Proc. of the Int. Conf. on Intelligent Robots

and Systems, pp. 3786-3793.

Dinh, T. B., Vo, N., and Medioni, G., 2011. “High

Resolution Face Sequences from a PTZ Network

Camera,” Proc. of the IEEE Int. Conf. on Automatic

Face & Gesture Recognition and Workshops, pp. 531-

538.

Dong, G., and Lu, S., 2010. “The relation of expression

recognition and affective experience in facial

expression processing: an event-related potential

study,” Psychology Research and Behavior

Management, vol. 3, pp. 65-74.

Doody, R. S., Stevens, J. C., Beck, C., et al. 2013,

“Practice parameter: Management of dementia (an

evidence-based review): Report of the quality

standards subcommittee of the American Academy of

Neurology,” Neurology, pp. 1-15.

Fang, S. et al., 2008. “Automated Diagnosis of Fetal

Alcohol Syndrome Using 3D Facial Image Analysis,”

Orthodontics & Craniofacial Research, vol. 11, no. 3,

pp. 162-171.

Fraunhofer IIS, 2013. “Sophisticated High-speed Object

Recognition Engine,” www.iis.fraunhofer.de/shore.

Jun-Su, J., and Jong-Hwan, K., “Fast and Robust face

Detection using Evolutionary Prunning,” IEEE Trans.

On Evolutionary Computation, vol. 12, no. 5, pp. 562-

571, 2008.

Kanade, T., Cohn, J., Tian, Y. L., 2000. “Comprehensive

database for facial expression analysis,” Proc. of the

Int. Conf. on Face and Gesture Recognition, pp. 46-

53.

Kublbeck, C., and Ernst, A., 2006. “Face detection and

tracking in video sequences using the modified census

transformation,” Image and Vision Computing, vol.

24, no. 6, pp. 564-572.

Lee, Y. B., and Lee, S., 2011. “Robust Face Detection

Based on Knowledge Directed Specification of

Bottom-Up Saliency,” ETRI Journal, vol. 33, no. 4,

pp. 600-610.

Mohammad, A. H., Nasrollahi, K., and Moeslund, T. B.,

2013. “Real-Time Acquisition of High Quality Face

Sequences From an Active Pan-Tilt-Zoom Camera,”

Proc. of the Int. Conf. on Advanced Video and

Surveillance Systems, pp. 1-6.

Mustafah, Y. M., Shan, T., Azman, A. W., Bigdeli, A.,

and Lovell, B. C., 2007. “Real-Time Face Detection

and Tracking for High Resolution Smart Camera

System,” Proc. Of the 9

Biennial Conf. on Digital

Image Computing Techniques and Applications, pp.

387-393.

Mustafah, Y. M., Bigdeli, A., Azman, A. W., and Lovell,

B. C., 2009. “Face Detection System Design for Real-

Time High Resolution Smart Camera,” Proc. Of the

ACM/IEEE Int. Conf. on Distributed Smart

Cameras, pp. 1-6.

Nasrollahi, K., and Moeslund, T. B., 2008. “Face Quality

Assessment System in Video Sequences,” 1

European Workshop on Biometrics and Identity

Management, Springer-LNCS, vol. 5372, pp. 10-18.

Nasrollahi, K., and Moeslund, T. B., 2009. “Complete face

logs for video sequences using face quality measures,”

IET Signal Porcessing, vol. 3, no. 4. Pp. 289-300, DOI

10.1049/iet-spr.2008.0172.

Russell, A. J., and Fehr, B., 1987, “Relativity in the

Perception of Emotion in Facial Expressions” Journal

of Experimental Psychology, vol. 116, no.3, pp. 223-

237.

Suwa, M., Sugie, N., and Fujimora, K., 1978. “A

preliminary note on pattern recognition of human

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

524

emotional expression,” Proc. of the Int. Joint Conf. on

Pattern Recognition, pp. 408-410.

Tian, Y., Kanade, T., and Cohn, J. F., 2011. “Facial

Experssion Recognition,” Handbook of Face

Recognition, Chapter 19, pp. 487-519.

Viola, P., and Jones, M., 2001 “Robust real-time face

detection,” Proc. Of the 8

IEEE Int. Conf. on

Computer Vision, pp. 747.

Wen, Z., and Huang, T., 2003. “Capturing subtle facial

motions in 3D face tracking,” Proc. of the Int. Conf.

on Computer Vision.

Wong, Y., Chen, S., Mau, S., Sanderson, C., and Lovell,

B. C., 2011. “Patch-based Probabilistic Image Quality

Assessment for Face Selection and Improved Video-

based Face Recognition,” Proc. of the IEEE Conf. on

Computer Vision and Pattern Recognition Workshops,

pp. 74-81.

ConstructingFacialExpressionLogfromVideoSequencesusingFaceQualityAssessment

525
