Interfacing Assessment using Facial Expression Recognition

Rune A. Andersen, Kamal Nasrollahi, Thomas B. Moeslund and Mohammad A. Haque

Visual Analysis of People Laboratory, Aalborg University, Soﬁendalsvej 11, 9200 Aalborg, Denmark

Keywords:

Facial Expression Recognition, Interfacing Technologies, Motion Controlled, Gamepad.

Abstract:

One of the most important issues in gaming is deciding about the employed interfacing technology. Gamepad

has traditionally been a popular interfacing technology for the gaming industry, but, recently motion controlled

interfacing has been used widely in this industry. This is exactly the purpose of this paper to study whether

the motion controlled interface is a feasible alternative to the gamepad, when evaluated from a user experience

point of view. To do so, a custom game has been developed and 25 test subjects have been asked to play

the game using both types of interfaces. To evaluate the users experiences during the game, their hedonic

and pragmatic quality are assessed using both subjective and objective evaluation methods in order to cross-

validate the obtained results. An application of computer vision, facial expression recognition, has been used

as a non-obtrusive objective and hedonic measure. While, the score obtained by the user during the game

has been used as a pragmatic quality measure. The use of facial expression recognition has, to the best of

our knowledge, not been used before to assess the hedonic quality of interfaces for games. The thorough

experimental results show that the user experience of the motion controlled interface is signiﬁcantly better

than the gamepad interface, both in terms of hedonic and pragmatic quality. The facial expression recognition

system proved to be a useful non-obtrusive way to objectively evaluate the hedonic quality of the interfacing

technologies.

1 INTRODUCTION

Evaluating the user experience in interactive systems,

similar to many other systems, is of crucial impor-

tance. This can, for example, provide very help-

ful feedbacks for further improvement of such sys-

tems. One of the key issues in developing an interac-

tive system, like a game, is deciding about the inter-

facing technology that the game is going to provide

to its users. For the gaming purposes, traditionally

gamepad interfacing technology has been around for

many years. But, recently motion controlled interfac-

ing has been widely used in many different games.

Can this emerging motion controlled interfacing tech-

nology be considered as a feasible alternative to the

gamepad from the user’s point of view? To answer

this question, we have developed a game based on ki-

netic interaction, which is suitable for multiple inter-

facing technologies, and have asked our test subjects

to play the game once with a gamepad interface and

once with a motion controlled interface. Following

that we have evaluated and compared the users’ expe-

riences in these two different cases.

Before going into any details, we ﬁrst need to an-

swer this question: How can the user experience be

assessed in interactive systems? Following Hassen-

zahl et al (Hassenzahl et al., 2003)’s theory on the user

experience evaluation, there are two types of quality

measures for such systems, hedonic and pragmatic.

The hedonic quality is concerned with whether the

user has a fun and pleasurable experience. But, the

pragmatic quality considers an extend for which the

user can complete the desired task, e.g., How easy

is the interface to learn and to use? How accurate

is it? For assessing these two types of quality mea-

sures, subjective methods (such as questionnaires and

interviews) and objective quantitative methods (such

as electroencephalography, electromyography, heart-

beat rate, respiratory level) have been used. Objec-

tive quantitative methods are always good as they can

complement/validate results of the subjective meth-

ods. However, there is a problem with the mentioned

quantitative methods for assessing the user experience

in motion controlled gaming applications. For their

measurement, one needs to install a hardware/sensor

on the user’s body. It is obvious that such an instal-

lation restricts the user’s movements in playing the

game. Hence, they are not suitable for assessing the

user experience when a motion controlled interface is

used. To overcome this, beside employing subjective

186

Andersen R., Nasrollahi K., Moeslund T. and Haque M..

Interfacing Assessment using Facial Expression Recognition.

DOI: 10.5220/0004730801860193

In Proceedings of the 9th International Conference on Computer Vision Theory and Applications (VISAPP-2014), pages 186-193

ISBN: 978-989-758-009-3

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

methods (using questionnaires), this paper has pro-

posed a new quantitative measure using facial expres-

sion recognition. To do so, a camera ﬁlms the test

subjects during playing the game. There is obviously

a distance between the camera and the test subjects,

i.e., the employed sensor does not impose any restric-

tion on the movements of the user and therefore mo-

tion controlled interfaces can be used easily.

To the best of our knowledge, facial expression

recognition has not been used as a quantitative mea-

sure for evaluating game input devices and methods

of interfacing in the gaming context. However, (Tan

et al., 2012) conducted a feasibility study using facial

expression recognition to evaluate user experience in

games, which showed a correct correlation between

gameplay events and the valence of the classiﬁed fa-

cial expressions.

The rest of this paper is organized as follows: in

the next section the literature on assessing the user

experience of interfacing technologies in games is re-

viewed, in section 3 the developed game and the cho-

sen devices for both interfacing methods are intro-

duced, the employed measurement factors for assess-

ing the user experience are explained in section 4, the

experiential results are discussed in section 5, and ﬁ-

nally, the paper is concluded in section 6.

2 RELATED WORK

This section provides an overview on existing ap-

proaches on evaluating the effect of input devices on

the user experience in games. In (Natapov et al.,

2009) the user experience of playing a game using

Wii



remote and a gamepad are compared. It is

shown that the throughput of the Wii



remote is

signiﬁcantly higher than the gamepad. At the same

time, the error rate of Wii



remote is higher than the

gamepad. Despite this, the Wii



remote was the pre-

ferred controller for playing games amongst the test

subjects. In (Bateman et al., 2011) the performance

difference of game input devices for steering a car

has been studied, and it is shown that a thumbstick

performs signiﬁcantly better in terms of game com-

pletion time than a steering wheel and a mouse.

For examining the user experience of different

game input devices, self-determination theory (Deci

and Ryan, 2002) has been commonly used to study

factors that inﬂuence motivation. The Player Expe-

rience of Needs Satisfaction (PENS) evaluation in-

strument encompasses evaluation of concepts such as

intrinsic motivation, competence, autonomy, related-

ness, presence and intuitive controls through the use

of questionnaires (Ryan et al., 2006). PENS was used

in a study showing that realistic and tangible mapping

of controllers with game tasks increases the experi-

ence of autonomy and presence, but not competence

(McEwan et al., 2012). PENS has further been used in

(Birk and Mandryk, 2013) with self-discrepancy the-

ory (Higgins, 1987) to study self-perception during

playing of a game, including the effect of extraver-

sion, agreeableness, conscientiousness, neuroticism,

and openness to experience. In this study three in-

put devices, the Kinect



, the PlayStation Move



and

the gamepad are compared. It is shown that Kinect



produces signiﬁcantly higher positive affect than the

Move and gamepad. Furthermore, Kinect



showed

to be more enjoyable than the gamepad. Moreover,

it was shown that Kinect



provided higher auton-

omy, relatedness, immersion and agreeableness than

the gamepad, while the gamepad increased the neu-

roticism of the user compared to Kinect



Regarding the effect of motion control in a collab-

orative multi-user game, (Lindley et al., 2008) shows

that input based on motion increases the engagement

and social interaction in the game. In (Dahlgren and

Lyck, 2011) grounded theory is used to examine the

effect of motion controllers on the gameplay experi-

ence, compared to a gamepad. The interviews showed

that motion controllers can enhance the gameplay,

making the players more immersed, if the control

mapping is sufﬁciently realistic and natural. Studies

have further shown that interactivity in the form of

natural controller mapping increases spatial presence

(Skalski et al., 2007) and immersion (Pietschmann

et al., 2012), which has been shown to predict enjoy-

ment of games (Shafer et al., 2011). The studies show

that motion controlled input devices that are mapped

naturally can increase spatial presence and immer-

sion, which leads to greater entertainment value, com-

pared to when a gamepad is used.

3 THE DEVELOPED GAME

To evaluate the user experience of the two interfacing

technologies, a game was developed that features a

humanoid avatar, which is controlled by the user. The

avatar needs to be navigated through a game course

using kinetic interaction, while objects are moving to-

wards the user. There are two types of objects; target

objects that need to be hit, and obstacle objects that

need to be dodged. The two types of objects and the

avatar are shown on Figure 1 (top). Every time an ob-

ject is successfully hit or dodged, points are scored.

The purpose of the game is to score as many points as

possible.

As mentioned before, two interfacing methods

InterfacingAssessmentusingFacialExpressionRecognition

187

Figure 1: Top: The environment of the game showing the avatar and the two types of objects. The obstacle objects in the

ﬁrst two images on the left should be dodged (duck under or jump over) and the target object in the right most image should

be hit. Bottom: The player with the gamepad interface (two left images), and with the motion controlled interface (two right

images).

have been used in this paper. One interfacing method

uses the ﬁne motor skills of the hand (gamepad), and

the other one uses gross motor skills of the entire body

(motion controlled). Historically, video games have

employed a gamepad in some form as input device,

where a gamepad is deﬁned as a controller held with

one or two hands, using the ﬁngers to provide input.

As such, the gamepad is the standard interfacing tech-

nology for games. The chosen gamepad input device

in this paper is a Logitech



RumblePad 2



, because

it is a modern gamepad with features equal to those

found on the current generation of gaming consoles.

The motion controllers that are commercially pop-

ular today as gaming controllers, and thus are candi-

dates for input devices for game developers, fall into

the categories of the hand held device, such as the

Wii remote



and the PlayStation Move



, and whole-

body tracking devices, such as the Kinect



. The

Kinect for Windows



is chosen as the input device

for the motion controlled interface. It is selected be-

cause it allows for the widest range of movements of

the user, encompassing both movements of the hands

that the hand held devices also cover, and movements

of the rest of the body. Thus, interfacing through the

Kinect



allows a wider range of body movements as

input to the game, compared to a hand held device.

This will enable an interface that fully utilizes mo-

tion of the user’s body as input mechanism, in order

to fully examine the possibilities of motion controlled

gaming.

4 USER EXPERIENCE

ASSESSMENT

For comparing the two different interfacing meth-

ods, using the chosen devices described in the pre-

vious section, both objective and subjective evalua-

tion methods are used in accordance with the princi-

ple of triangulation (Jick, 1979), such that the strength

in one method can compensate for the weakness in

another, leading to a more valid result, without scien-

tiﬁc artifacts caused by the use of a single evaluation

method only. The conclusion of this study will there-

fore be cross-validated by comparing the results of the

objective and subjective methods.

The hedonic and pragmatic quality measures are

evaluated subjectively by asking test subjects to

choose the interface they ﬁnd most entertaining and

easiest to learn to use. The pragmatic quality is fur-

ther evaluated objectively by logging the score of the

game. The easier the interface is to learn and the more

accurate it is, the more points the user will score in the

game, as the user has an easier time hitting and dodg-

ing the game objects. The hedonic quality is further

evaluated objectively by a facial expression analysis

system (Ghijsen, 2004), where the SHORE



library

(Fraunhofer IIS, 2013), (Kublbeck and Ernst, 2006)

is used to detect and classify the emotional valence of

the expression of a recognized face in a video stream.

The method is chosen because it is capable of infer-

ring affective states of the user in a non-obtrusive way,

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

188

compared to the more intrusive alternative of facial

electromyography, where the muscle activity in the

face is measured through attached electrodes, which

to a greater extend will bias the evaluation. By apply-

ing this SHORE



facial expression recognition sys-

tem to an image, ﬁrst the faces are detected, then for

each detected face its facial expression is expressed

by four numbers. Each of these numbers are asso-

ciated to one of these facial expressions: happiness,

angry, sad, and surprised. Examples of the output of

this system will be shown later in the paper.

5 EXPERIMENTAL RESULTS

To evaluate the user experience of the two interfacing

methods, 25 test subjects have been asked to partici-

pate in the experiments. There were 22 males and 3

females between the ages of 20 and 32 years. Among

them, 21 were experienced with playing video games

on a gamepad-like input device, four were inexperi-

enced with video games using a gamepad-like device.

Each test subject was led into the test room alone by

the test facilitator. It was explained to them that they

were going to play a video game twice, once with a

gamepad interface and once with a motion controlled

interface through Kinect



. The game was demon-

strated to them by the facilitator, so they knew how

to play it. The test subject tried both versions, the or-

der of which was switched for every new subject. The

setup is shown in Figure 1 (bottom).

During the experiments the following data were

gathered from each test subject:

• Data from the algorithm that registers and classi-

ﬁes facial expressions of the users as an index of

hedonic quality.

• The score attained while completing the game as

an index of pragmatic quality.

• The questionnaire data evaluating perceived enter-

tainment value and learnability.

The facial expression recognition algorithm clas-

siﬁes and records the mean percentage value per video

frame of both the positive and negative facial expres-

sions during the use of each interface. The data is

analyzed using a two-sample design with interfacing

method as the treatment factor. It shows whether there

is a difference in each facial expression category dur-

ing the use of the two interfaces. The role of gam-

ing experience level is examined visually through box

plots depicting facial expression values with both ver-

sions of the game and gaming experience level as fac-

tors.

The game score in each prototype version is

equally analyzed in a two-sample design. This de-

termines whether there is a difference in game score

using the two interfaces. Box plots are used to vi-

sually inspect whether gaming experience level is a

factor on game score.

The questionnaire is designed as two AB experi-

ments to evaluate the hedonic and pragmatic quality

of the interfaces. The test subjects are asked to se-

lect the version that they ﬁnd most entertaining, and

the version they ﬁnd easiest to learn to use. The di-

chotomous response variable is the preferred proto-

type version. Each AB experiment is analyzed in an

exact binomial test (Crawley, 2005) in order to deter-

mine if one version is chosen signiﬁcantly more often

than the other. To avoid biasing the AB experiment,

the sequence that the selectable options A and B are

presented in the questionnaire are switched for every

new test subject.

Following subsections describe the obtained re-

sults.

5.1 Facial Expression Analysis

The ﬁrst step is to objectively evaluate the hedonic

quality of the two interfaces by studying the valence

of the facial expressions. Figure 2 shows the facial

expression graphs of one of the test subjects, while

using the gamepad. For each test subject using each

prototype version an average value per video frame is

computed for each facial expression. It can be seen

in Figure 2 how the facial expression values in per-

centage ﬂuctuate during a game course play-through

using the gamepad interface. Based on these ﬂuctu-

ations the average value is computed for each facial

expression. Taking the blue happy graph as an exam-

ple, it has modest spikes for the entire play-through,

resulting in a 4.59% average value.

The facial expression graphs of the same test sub-

jects while using the Kinect



prototype is shown in

Figure 3. As can be seen, the blue happy graph has

signiﬁcant spikes for most of the play-through, re-

sulting in a 20.17% average happy rating. It can be

seen that this test subject smiles a lot while using the

Kinect



. When compared to Figure 2, she doesn’t

smile while using the gamepad. The happy rating her

face is given while using the gamepad isn’t based on

a smile, which is also indicated by the fact that the

happy rating is mostly accompanied by a parallel an-

gry or sad rating. In Figure 3, spikes in the blue happy

curve is rarely accompanied by spikes in the other

curves, as an indication of a smiling face. The smil-

ing face while using the Kinect



, resulted in an aver-

age happy rating of 20.17%, compared to the 4.59%

InterfacingAssessmentusingFacialExpressionRecognition

189

Figure 2: The results of the facial expression recognition

system for a test subjects using the gamepad interfacing

method. On the y-axis is the facial expression values in

percentage, and on the x-axis is the video frame numbers.

Below is shown the main facial expressions.

Figure 3: The results of the facial expression recognition

system for a test subjects using the Kinect



interfacing

method. On the y-axis is the facial expression values in

percentage, and on the x-axis is the video frame numbers.

Below is shown the main facial expressions.

happy rating while using the gamepad. This means

that the employed facial expression recognition sys-

tem does its job well of giving a higher average happy

rating during a video sequence where a person smiles,

compared to when not smiling. As such it is judged as

a useful tool to classify and analyze valence of emo-

tions based on facial expressions, particularly happy

facial expression caused by being entertained.

Now, the facial expression data is analyzed in a

two-sample design to determine whether there is a

difference between the facial expressions in the two

prototype versions, signifying a difference in hedonic

quality between the two interfacing methods. First,

the happy facial expression is analyzed. To be able

to submit the two happy samples to a Student’s t-test

(Crawley, 2005), each has to follow normal distribu-

tion. As can be seen in Figure 4 (left), the happy per-

centage values of both samples exhibit exponential

growth, which rules out normal distribution. How-

ever, a logarithmic data transformation results in ap-

proximately linear growth, which is illustrated on the

right graph of Figure 4.

Figure 4: Left: The sorted observations of average happy

facial expression per video frame. The blue are from the

gamepad, the green from the Kinect



. Both exhibit an ex-

ponential growth pattern. Right: The logarithm of the same

values. The growth is now close to linear, especially for the

Kinect



values.

To determine whether the happy facial expression

data follows log-normal distribution, Q-Q plots of

the logarithm of the two samples are shown in Fig-

ure 5. Both samples appear to follow log-normal

distribution. When the log-values are submitted

to the Kolmogorov-Smirnov normality-test (Crawley,

2005), the gamepad sample comes out with a p-value

at 0.1882 and the Kinect



sample at 0.9453. As such,

the Kolmogorov-Smirnov null-hypothesis cannot be

rejected, and the assumption of log-normal distribu-

tion can be accepted for both samples.

Figure 5: Q-Q plots for the logarithm of percentage happy

facial expression. To follow log-normal distribution they

are to lie on a straight line. The Kinect



sample does so

very well, while the gamepad sample also does so, but not

as well.

In Figure 6 (left) box plots of the log-samples

are shown. Based on the box plots, it appears that

the test subjects have more happy facial expressions

when using the Kinect



, compared to the gamepad.

When submitting the samples to the F-test, the F-

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

190

Figure 6: Left) Box plot of the logarithm of average per-

centage happy facial expression per video frame. Proto-

type version 1 is the gamepad, version 2 is the Kinect



Right) Box plot of the logarithm of average percentage

happy facial expression per video frame. On the x-axis 1.0

is gamepad version with non-gamers, 2.0 is Kinect



ver-

sion with non-gamers, 1.1 is gamepad version with gamers,

and 2.1 is Kinect



version with gamers.

value comes out at 6.1 with a p-value at 5.262×10

−5

meaning that the variance isn’t equal between the

samples. This was also indicated by the box plots,

where the spread of the gamepad values was much

greater than the Kinect



values.

The data is submitted to a paired t-test using un-

equal variance. The t-value comes out at -3.475 with

a p-value at 0.002051. The 95% conﬁdence interval

is at -3.443 to -0.8733. As the p-value is well be-

low the critical p-value of 0.05, the null hypothesis

can be rejected stating that the mean log-happy values

are equal in the samples. The Kinect



and gamepad

mean values are 1.581 and -0.5769, respectively. It

therefore can be concluded that the test subjects had

signiﬁcantly more happy facial expressions when us-

ing the Kinect



, compared to the gamepad. As an

index of hedonic quality, it signiﬁes that the test sub-

jects had a more pleasurable experience using the mo-

tion controlled interface of the Kinect



, compared to

the gamepad interface. To examine whether gaming

experience level is a factor in happy facial expression

level, the box plot including gaming experience level

is shown in Figure 6 (right). When examining the

box plots, it is evident that the non-gamers in gen-

eral had more happy facial expressions when playing,

compared to the gamers. However, both the gamers

and the non-gamers looked happier when using the

Kinect



, compared to the gamepad.

Similar analysis has been done for the other three

facial expressions. While the angry and sad facial

expression values didn’t exhibit a clear pattern when

analyzed, the samples for surprised facial expression

showed that the Kinect



values were signiﬁcantly

higher than the gamepad values. The t-value was -

4.126 and the p-value 0.0004117 with a 95 % conﬁ-

dence interval from -3.524 to -1.17. As an index of

hedonic quality, the increase in surprised facial ex-

Figure 7: Box plot of the game score data. On x-axis is the

prototype version, 1 is the gamepad, and 2 is the Kinect



on the y-axis is the obtained game score.

pression signiﬁes that the Kinect



version produces

a more pleasurable experience, which to a greater ex-

tend is capable of surprising the test subjects, com-

pared to the gamepad version. Regarding the effect

of gaming experience level on the amount of sur-

prised facial expression, it appeared that non-gamers

didn’t look signiﬁcantly more surprised when us-

ing the Kinect



, compared to the gamepad version,

meaning that it is only gamers that look signiﬁcantly

more surprised when using the Kinect



5.2 Game Score Analysis

Next, the pragmatic quality is analyzed through the

game score. The game score was obtained for each

prototype version for each participant. Figure 7 shows

the box plot of the game score data. It can be seen

from this ﬁgure that the gamepad scores were spread

out more widely from 1500 to 2900. The middle 50%

of the gamepad values (the box in the box plot) are all

below the middle 50% of the Kinect



values, indicat-

ing that the gamepad sample has signiﬁcantly lower

values. The mean game scores of each sample for

gamepad and Kinect



are 2365.22 and 2756.52, re-

spectively.

In order to determine whether there is a signiﬁcant

difference between the mean values of the gamepad

and Kinect



samples, they are submitted to a paired

t-test, where the variance is approximated for each

sample. Prior to that, the assumption of normal dis-

tribution has been validated through Q-Q plots and

the Kolmogorov-Smirnov normality-test. The t-value

comes out at -5.964 with a p-value at 5.301×10

−6

InterfacingAssessmentusingFacialExpressionRecognition

191

Figure 8: Box plot of the game score data. On the x-axis 1.0

is gamepad version with non-gamers, 2.0 is Kinect



ver-

sion with non-gamers, 1.1 is gamepad version with gamers,

and 2.1 is Kinect



version with gamers.

The 95% conﬁdence interval is -527.37 to -255.23.

As the Kinect



score is greater than the gamepad

score, it can be concluded that the Kinect



interface

has a higher pragmatic quality than the gamepad, as

the test subjects was able to score higher when using

the Kinect



interface as an indication of an interface

that is easier to learn to use, and one that has greater

accuracy. By studying the box plot in Figure 8, it

can be seen that non-gamers score much lower than

gamers when using the gamepad. This was expected

as gamers are previously trained in using a gamepad-

like input device for playing games like the proto-

type, where non-gamers are not. In terms of Kinect



scores, both gamers and non-gamers score equally, in-

dicating that gaming experience level doesn’t inﬂu-

ence the ability to use the Kinect



interface. The

bottom-line is that the Kinect



interface has greater

pragmatic quality than the gamepad interface for both

gamers and non-gamers, but for non-gamers the dif-

ference in pragmatic quality is much greater than for

gamers.

5.3 Questionnaires Analysis

Finally, the questionnaire data is analyzed. The pur-

pose is to ﬁnd out how the self-reported evaluation

of hedonic and pragmatic quality comes out for the

two prototype versions. Out of the 25 test subjects,

22 chose the Kinect



as the prototype version that

they found most entertaining to use. When submit-

ted to an exact binomial test, the p-value comes out at

0.0001565 with 95% conﬁdence interval from 0.6878

to 0.9745. The null-hypothesis can therefore be re-

jected, stating that each prototype version is equally

likely to be selected, with the Kinect



version being

selected 88% of the time, and the gamepad 12% of the

time. It can therefore be accepted that the Kinect



version is selected signiﬁcantly more often than the

gamepad version, when being asked to select the ver-

sion that provides the most entertaining experience.

As such, the Kinect



version is perceived as having

signiﬁcantly higher hedonic quality by the test sub-

jects, providing a more pleasurable experience when

used.

When examining the role of gaming experience

level on the perceived hedonic quality of the two in-

terfaces, it can be seen that the three test subjects that

selected the gamepad version as the most entertain-

ing all were gamers. All non-gamers selected the

Kinect



version as most entertaining. It indicates that

people who are inexperienced in playing video games

using a gamepad-like device are even more likely to

prefer the Kinect



over the gamepad, when consider-

ing entertainment value.

When examining the pragmatic quality based on

the questionnaire data, 23 out of the 25 chose the

Kinect



as the version that was easiest to learn to

use. The binomial test comes out with a p-value of

1.943×10

−5

with a 95% conﬁdence interval at 0.7397

to 0.9902. This means that the Kinect



version is

chosen signiﬁcantly more often than the gamepad ver-

sion, when asked to select the version that is easiest to

learn to use. The Kinect



version is selected 92% of

the time, with the gamepad 8% of the time. Thus, the

Kinect



version is perceived as having signiﬁcantly

higher pragmatic quality, than the gamepad version.

The two test subjects that ﬁnd the gamepad version

easier to learn to use are both gamers, who are experi-

enced in playing video games with a gamepad-like de-

vice. The test subjects who are not previously trained

in using the gamepad, all choose the Kinect



as eas-

ier to learn to use. This indicates that non-gamers are

more likely to prefer the motion controlled interface

of the Kinect



, when considering pragmatic quality,

compared to gamers.

6 CONCLUSIONS AND

DISCUSSIONS

In the general context of gaming, this paper has

compared two interfacing technologies, traditional

gamepad and motion controlled techniques. To do so,

a game has been developed which can be played using

both of the interfacing technologies. Then, a group

of 25 test subjects have been asked to play the game

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

192

twice using the available interfacing methods. During

the gaming process both hedonic and pragmatic qual-

ity measures of the test subjects have been monitored

and analyzed using subjective and objective assess-

ment methods.

Using the subjective evaluation method of a ques-

tionnaire designed as an AB experiment, signiﬁcantly

more test subjects chose the Kinect



interface as the

most entertaining, compared to the gamepad inter-

face. In terms of pragmatic quality, signiﬁcantly more

test subject chose the Kinect



interface as easier to

learn to use, compared to the gamepad interface. Fur-

thermore, an objective evaluation method was applied

by analyzing the facial expressions of the test sub-

jects. The result was that the test subjects had signif-

icantly more happy and surprised facial expressions

when using the Kinect



, compared to the gamepad.

As an index of hedonic quality, it signiﬁes that the test

subjects had a more pleasurable experience using the

motion controlled interface of the Kinect



, compared

to the classical gamepad interface, causing them to

look happier and more surprised. This cross-validates

the subjective result. Furthermore, an objective eval-

uation method for pragmatic quality, using the logged

game scores of the test subjects, cross-validated the

obtained subjective result of a higher pragmatic qual-

ity of the Kinect



interface.

Facial expression recognition proved to be a use-

ful application of computer vision, suited to evaluate

the hedonic quality of the interfacing technologies in

an objective, non-obtrusive manner.

REFERENCES

Bateman, S., Doucette, A., Xiao, R., Gutwin, C., Mandryk,

R., and Cockburn, A. (2011). Effects of view, input

device, and track width on video game driving. In

Graphics Interface 2011, pages 207–214, St. John’s,

Canada.

Birk, M. and Mandryk, R. L. (2013). Control your game-

self: effects of controller type on enjoyment, motiva-

tion, and personality in game. In Proceedings of the

SIGCHI Conference on Human Factors in Comput-

ing Systems, CHI ’13, pages 685–694, New York, NY,

USA. ACM.

Crawley, M. J. (2005). Statistics: An Introduction using R.

Wiley. ISBN 0-470-02297-3.

Dahlgren, K. and Lyck, M. (2011). Motion control: In con-

trol or out of control? Master’s thesis, Stockholm

University.

Deci, E. and Ryan, R. (2002). Handbook of Self-

Determination Research. University of Rochester’s

Press.

Fraunhofer IIS (2013). Intelligent Systems -

Fraunhofer Institute for Integrated Circuits.

http://www.iis.fraunhofer.de/de/bf/bsy/fue/isyst.html.

Ghijsen, M. (2004). Facial expression analysis for human

computer interaction. IEEE Transactions on Visual-

ization and Computer Graphics, 2(3):147–161.

Hassenzahl, M., Burmester, M., and Koller, F.

(2003). Attrakdiff: Ein fragebogen zur messung

wahrgenommener hedonischer und pragmatischer

qualitt.

Higgins, E. T. (1987). Self-discrepancy: a theory relating

self and affect. Psychol Rev, 94(3):319–340.

Jick, T. D. (1979). Mixing qualitative and quantitative meth-

ods: Triangulation in action. Administrative Science

Quarterly, 24(4):pp. 602–611.

Kublbeck, C. and Ernst, A. (2006). Face detection and

tracking in video sequences using the modiﬁed cen-

sus transformation. Image and Vision Computing,

24(6):564 – 572.

Lindley, S. E., Le Couteur, J., and Berthouze, N. L. (2008).

Stirring up experience through movement in game

play: effects on engagement and social behaviour.

In Proceedings of the SIGCHI Conference on Human

Factors in Computing Systems, CHI ’08, pages 511–

514, New York, NY, USA. ACM.

McEwan, M., Johnson, D., Wyeth, P., and Blackler, A.

(2012). Videogame control device impact on the play

experience. In Proceedings of The 8th Australasian

Conference on Interactive Entertainment: Playing the

System, IE ’12, pages 18:1–18:3, New York, NY,

USA. ACM.

Natapov, D., Castellucci, S. J., and MacKenzie, I. S.

(2009). Iso 9241-9 evaluation of video game con-

trollers. In Proceedings of Graphics Interface 2009,

GI ’09, pages 223–230, Toronto, Ont., Canada,

Canada. Canadian Information Processing Society.

Pietschmann, D., Valtin, G., and Ohler, P. (2012). The effect

of authentic input devices on computer game immer-

sion. pages 279–292.

Ryan, R., Rigby, and Przybylski, A. (2006). The Motiva-

tional Pull of Video Games: A Self-Determination

Theory Approach. Motivation and Emotion,

30(4):344–360.

Shafer, D. M., Carbonara, C. P., and Popova, L. (2011).

Spatial presence and perceived reality as predictors

of motion-based video game enjoyment. Presence:

Teleoper. Virtual Environ., 20(6):591–619.

Skalski, P., Lange, R., Tamborini, R., and Shelton, A.

(2007). Mapping the road to fun: Natural video game

controllers, presence, and game enjoyment. In 57th

Annual Conference of the International Communica-

tion Association.

Tan, C. T., Rosser, D., Bakkes, S., and Pisan, Y. (2012).

A feasibility study in using facial expressions analy-

sis to evaluate player experiences. In Proceedings of

The 8th Australasian Conference on Interactive Enter-

tainment: Playing the System, IE ’12, pages 5:1–5:10,

New York, NY, USA. ACM.

InterfacingAssessmentusingFacialExpressionRecognition

193
