2D-3D Face Recognition via Restricted Boltzmann Machines

Xiaolong Wang

, Vincent Ly

, Rui Guo

and Chandra Kambhamettu

University of Delaware, Newark, DE, U.S.A.

The University of Tennessee, Knoxville, U.S.A.

Keywords:

Restricted Boltzmann Machines, Canonical Correlation Analysis, Heterogeneous Face Recognition, Match-

ing, Feature Extraction.

Abstract:

This paper proposes a new scheme for the 2D-3D face recognition problem. Our proposed framework mainly

consists of Restricted Boltzmann Machines (RBMs) and a correlation learning model. In the framework,

a single-layer network based on RBMs is adopted to extract latent features over two different modalities.

Furthermore, the latent hidden layer features of different models are projected to formulate a shared space

based on correlation learning. Then several different correlation learning schemes are evaluated against the

proposed scheme. We evaluate the advocated approach on a popular face dataset-FRGCV2.0. Experimental

results demonstrate that the latent features extracted using RBMs are effective in improving the performance

of correlation mapping for 2D-3D face recognition.

1 INTRODUCTION

Over the past few years, face recognition remains one

of the most popular topics in machine learning and

computer vision. Application based on face recogni-

tion technology (FRT) has been widely used in many

areas such as security and multimedia. However, the

recognition performance still degrades when affected

by factors, such as illumination, pose and expression.

To alleviate these inﬂuences, some researchers try to

conduct face recognition via other modalities, such as

Near-infrared (NIR) and 3D. 3D data, especially, has

been widely used in face recognition. Recently, facil-

itated by the emerging low cost 3D sensing devices,

such as Microsoft Kinect, Asus Xtion PRO, a large

variety of RGB-Depth sensing techniques have been

deployed to biometric signal aggregation and process-

ing (Shotton et al., 2011). Meanwhile, 2D-3D het-

erogeneous face recognition has also attracted more

interests. Heterogeneous face recognition refers to

matching face images across different modalities.

Compared with face recognition using visible im-

ages, heterogeneous face recognition is more chal-

lenging, as illustrated in Figure.1. The individual’s

identity from 2D image is difﬁcult to be determined

using a 3D depth image. The difﬁculty is due to the

dissimilar appearances of the 2D face image and the

3D face image. In this work, we focus on face recog-

nition from 2D to 3D.

Compared to visible face recognition, the works

Figure 1: Examples of 2D and 3D face images. 2D faces

(ﬁrst row) associated with their corresponding depth im-

age(second row).

related with heterogeneous face recognition between

2D and 3D are not widely studied. In (Rama et al.,

2006), Partial Principal Component Analysis (P

CA)

was used to extract features and reduce features di-

mension in the 3D and 2D data separately. Their ex-

perimental results revealed that P

CA could minimize

the inﬂuence of illumination. Riccio et al.(Riccio

and Dugelay, 2005) proposed to use predeﬁned con-

trol points to calculate the geometrical invariants to

correct the pose variation for 2D/3D face recogni-

tion. Afterwards, many researchers discovered the ef-

fectiveness of Canonical correlation learning (CCA)

in this problem. Yang et al. (Yang et al., 2008)

adopted CCA to learn the mapping relation among

corresponding patches between 2D texture image and

3D depth image. The idea of utilizing CCA as the

major technique for mapping between two different

574

Wang X., Ly V., Guo R. and Kambhamettu C..

2D-3D Face Recognition via Restricted Boltzmann Machines.

DOI: 10.5220/0004736505740580

In Proceedings of the 9th International Conference on Computer Vision Theory and Applications (VISAPP-2014), pages 574-580

ISBN: 978-989-758-004-8

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

modalities is also applied in work (Huang et al., 2012;

Wang et al., 2013).

The aim of correlation learning is to maximize the

intra-class similarity of the same individual within the

projected subspace. As we know, CCA is a stan-

dard algorithm for calculating the linear projection

of two random vectors which are maximally corre-

lated. Kernel canonical correlation analysis (KCCA)

extends CCA into nonlinear projection. KCCA per-

forms better at capturing the maximally correlated

nonlinear projection. It tries to ﬁnd kernel Hilbert

spaces with kernel functions. CCA and KCCA are

adopted in learning features of multiple modalities,

then can be used in fusion for classiﬁcation (Sargin

et al., 2007); especially under the situation when two

modalities are used in the training phase and only one

modality is available in the prediction phase. There

are lots of applications across many different areas,

such as natural language analysis (Vinokourov et al.,

2002; Dhillon et al., 2011), age estimation (Guo and

Wang, 2012), signal processing across multimodals

(Slaney and Covell, 2000). The success of aforemen-

tioned works sheds the light in the research of het-

erogeneous 2D/3D face mapping which highlights the

signiﬁcance of correlation learning.

Recently, RBM is found to be effective in learn-

ing correlation among multi-modalities (Ngiam et al.,

2011; Srivastava and Salakhutdinov, 2012). As a

member of the Boltzamnn Machine family, RBM at-

tracts a resurgent study interest by inheriting the ex-

cellent ability of representation learning in an iterative

way. Through the weights and offset parameters ad-

justing, the bipartite structured net efﬁciently learns

the nested abstractions from the raw data from high

dimension space. RBM beneﬁts itself in terms of the

hierarchical feature extraction ability and the unsu-

pervised training manner. Facilitated by these merits,

RBM is found to be effective. As we know, for cross

modality learning, data from two different modalities

is only available during the training phase. During

the testing phase, only the data from a single modal-

ity is available. Therefore, learning an efﬁcient single

modality feature has become one essential step in this

matching work. In (Ngiam et al., 2011), Ngiam et

al. demonstrated that an auxiliary non-linear network

can capture the relationship among different modali-

ties. Motivated by their work, we plan to explore the

feasibility of feature learning using single-layer net-

work in 2D/3D face recognition.

There are several novelties in our work. First, a

single-layer network is introduced to deal with the

face recognition problem between 2D and 3D cou-

pled with correlation mapping. Based on our knowl-

edge, this is the ﬁrst time that RBM model has been

adopted in heterogeneous face recognition. The pro-

posed method offers better performance relative to the

existing correlation learning schemes. This scheme

can also be adopted in other related heterogeneous

recognition works. The experimental results demon-

strate the effectiveness of our scheme compared with

reliance only on the correlation learning scheme. Sec-

ond, to measure the generality of this scheme, differ-

ent correlation methods have been compared for ef-

ﬁciency along with the layer features (2D RBM and

3D RBM features). In addition, the matching perfor-

mance between two different modalities of different

facial parts has been analyzed.

The rest of the paper is structured as follows. In

Section 2, we introduce the proposed scheme. Exper-

imental results are discussed in Section 3, and Section

4 provides conclusions.

2 OUR APPROACH

In this section, we describe our approach for the

task of 2D-3D face recognition. Figure 2 shows an

overview of our scheme. After pre-processing and

extracting the feature from the images, RBM is con-

ducted. Then correlation learning is performed to

learn the projection matrix within each region be-

tween the two modalities. This will help project fea-

tures of different modalities into a shared represen-

tation space. In general, our scheme mainly includes

four parts, which are raw feature extraction (including

image pre-processing), latent feature extraction(using

RBM), correlation learning and matching. In the fol-

lowing paragraph, we will introduce the main algo-

rithms used in each part.

2.1 Restricted Boltzmann Machines

Recently, deep learning has been widely used in ma-

chine learning and computer vision. One of the fa-

mous works is trying to examine how deep sigmoidal

networks can help obtain better representation for

handwritten classiﬁcation (Hinton and Salakhutdinov,

2006). The key part is to conduct multi-layer training

based on Restricted Boltzmann Machines(RBMs).

This scheme achieved excellent classiﬁcation results

on this sort of problems.

RBM belongs to the category of Markov Random

Field. Compared with Boltzmann Machines (BMS),

RBMs further restrict BMs to the connection between

visible-visible layer and hidden-hidden connections

(within the intra-layers). An RBM bipartite structure

can be illustrated as in Figure 3, where w is the weight

connecting the hidden layers(h) and visible layers(v).

2D-3DFaceRecognitionviaRestrictedBoltzmannMachines

575

(a) (b)

Figure 2: The proposed framework for 2D-3D face recognition.(a) Illustration of training and testing scheme. During the

training phase, corresponding 2D and 3D face images of the same individual are used to learn RBM model and correlation

basis. During the testing phase, we ﬁrstly extract 2D probe image feature. Then after hidden latent feature extraction and

correlation projection, the probe images will be matched against the gallery set to get the corresponding ID. (b) Illustration

of principal components of the proposed scheme. For the Pre-processing section, all the images (2D/3D) are cropped to the

same size. The pre-processing of 3D images also include image denoising and hole ﬁlling. In our work, face is ﬁrst divided

into eleven facial parts, then feature extraction and RBM model learning is conducted within each part. The output latent 2D

and 3D features acquired from RBM model are used to learn the basis of correlation learning model.

Figure 3: Illustration of RBM structure, where h indicates

the hidden unit and v indicates visible unit. w is the weight

connecting v and h.

From the model illustrated in Figure 3, we ﬁnd that

RBM is not a direct graphical model comprised of

hidden variables(h) and visible variables(v). In ad-

dition, there is no connection between the variables

of the same layer (e.g. within visible or hidden layer).

The energy function E(v,h) of an RBM is formulated

as:

E(v, h) = −

∑

−

∑

−

∑

i, j

i j

(1)

where W

i j

represents the weight between the visible

layer unit i and hidden layer unit j. The parameters

c and b indicate the basis of hidden and visible layers

respectively. The parameters W

i j

, c and b can be es-

timated using maximum likelihood parameter estima-

tion (Hinton and Salakhutdinov, 2006). This scheme

can help minimize the energy states drawn from the

data distribution and raise the energy states which are

improbable given the data (Bengio, 2009). The join

probability distribution is calculated as

P(v, h) =

exp(−E(v, h))

(2)

where Z =

∑

v,h

exp(−E(v, h)) indicates the Boltz-

mann partition function. We can also calculate the

marginal distribution of the visible units by summing

up the possible hidden units, which can be calculated

P(v) =

∑

exp(−E(v, h))

(3)

With regard to the RBM structure listed in Figure 3,

the units in visible and hidden layers are conditionally

independent. When the units are binary, which means

v, h ∈ [0, 1], the probabilistic version of the neuron ac-

tivation can be represented as:

P(v

= 1|h) = sigm(b

P(h

= 1|v) = sigm(c

(4)

Compared with the binary input values, real val-

ued data can be well modeled using Gaussian

RBM(GRBM) (Hinton and Salakhutdinov, 2006).

GRBM does a good job at modeling continuous mul-

tivariate data. There are many applications using

GRBM, including action recognition (Wang et al.,

2011), speech recognition (Mohamed et al., 2012),

etc. In general, GRBM can be regarded as a mixture

of diagonal Gaussians with shared W , c and b param-

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

576

eters. Its energy function is deﬁned as follows:

(v, h) = −

∑

− b

)

−

∑

i, j

i j

−

∑

(5)

Under this model, the conditional distributions for

inference and generation are calculated as follows:

P(v

|h) = N(b

+ σ

∑

i j

,σ

))

P(h

= 1|v) = sigm(c

∑

i j

)

(6)

where N(·) denotes the Gaussian density, and sigm is

the logistic function. In our work, GRBM is applied

to learn the single data representation.

2.2 CCA

Canonical correlation analysis(CCA) (Sutton and

Barto, 1998) has been widely used in multivari-

ate analysis. It was ﬁrst advocated by Hotelling

(Hotelling, 1936) to calculate the basis vectors for two

related multidimensional variables and can be used

to maximize the correlation between these two sets

of related variables. CCA methods have been widely

used in machine learning and computer vision prob-

lems, such as action recognition(Kim et al., 2007),

face recognition(Li et al., 2009). After projecting the

data to high-dimensional space, CCA can be modeled

as the relation between these two sets of variables.

Suppose (x, y) is the corresponding data set. It in-

cludes N pairs of samples x

, y

. CCA is used to learn

the projection matrix w

and w

to maximize the cor-

relation between the projected matrix w

x and w

That is to maximize the following correlation equa-

tion:

v =

(7)

where C

and C

indicate the intra-class con-

variance matrices. v is the correlation coefﬁcient.

And C

and C

indicate the inter-class con-variance

matrices. Because v is invariant to the scaling of w

and w

, CCA optimization problem can be equivalent

to maximizing w

. This subjects to w

1 and w

= 1. (Hardoon et al., 2004) shows w

can be solved by using the following eigenvalue prob-

lem,

−1

= λ

(8)

where λ is the eigenvalue associated with the eigen-

vector w

. To stabilize the solution, regularization

terms r

and r

are always added to each data set

(Hardoon et al., 2004). Then v becomes

v =

+ λI)w

yy+

λI)w

(9)

Experiment results prove that Regularized

CCA(rCCA) performs better than CCA in our

work.

2.3 Kernel CCA

Because of its linearity, CCA may not be a good

solver when dealing with some nonlinear correla-

tion problems (Hardoon et al., 2004). Kernel CCA

(KCCA) performs better than CCA in ﬁnding nonlin-

ear projection of the two views (Hardoon et al., 2004).

The main idea of KCCA is to project the data into

a higher-dimension feature space using kernel func-

tions. In this paper, we use the Gaussian kernel as the

kernel function of KCCA, which can be represented

k(x, y) = e

−

||x−y||

2σ

(10)

Then the direction of w

and w

can be represented

as the data onto the direction α and β, which are

= Xα and w

= Y β. Let M

= X

X and M

= Y

be kernel matrices corresponding to the two represen-

tation. Then v can be represented as

v =

α  β

(11)

To force non-trivial learning on the correlation by

dealing with the overﬁtting and ﬁnding irrelevant cor-

relations, a regularization is always applied to KCCA.

Correlation coefﬁcient v becomes

v =

(α

α + ka

α)(β

β + kβ

β)

(12)

Then the generalized eigenvalue problem becomes

+ kI)

−1

+ kI)

−1

α = λ

(13)

Where λ is the eigenvalue corresponding to the eigen-

vector w

. Then the whole equation becomes the stan-

dard eigenproblem Ax = λx. In our experiments, k

is set to 0.01. If k = 0, then it becomes the standard

KCCA. In our work, regularization is found to be use-

ful.

2D-3DFaceRecognitionviaRestrictedBoltzmannMachines

577

3 EXPERIMENT

In this section, we demonstrate the dataset used in this

work. We also describe the details of our experiment

methodology as well as the analysis of experiment re-

sults.

3.1 Dataset

To evaluate our proposed scheme, we use FRGCv2.0

database (Phillips et al., 2005). The images within

the dataset include pose, expression and illumination

changes, which is as illustrated in Figure 1. We ran-

domly choose 300 subjects from FRGCv2.0. For each

subject, two visible texture images and two corre-

sponding 3D range images are selected. The whole

database is divided into two parts, training set and

testing set. The training set contains the 2D-3D pairs

of 225 subjects, and the testing set includes other 75

subjects. Note that in all of our experiments, there is

no overlap between the training and testing data. This

means the images of the same individual are never

used in the training and testing phase at the same time.

Figure 4: Illustration of face parts division. To be concise,

only 2D face image is used. 3D face images also follow the

same division scheme.

3.2 Pre-processing

To get the depth image, we follow the procedure in

(Xu et al., 2009). The main problem for obtaining

the depth image from 3D point cloud is the noise re-

moval and hole ﬁlling. To reduce the noise, we apply

the mean value ﬁlter with the kernel size 5 × 5 cen-

tered with evaluating pixel. If the absolute difference

between the central pixel and mean value is greater

than our predeﬁned threshold, then this pixel will be

regarded as an outlier and replaced. Linear interpo-

lation based on the neighboring pixels is applied to

calculate the value of the center pixel value and used

to ﬁll the hole.

Before conducting the experiments, all 2D and

3D images are aligned and cropped to the same size,

128 × 128 pixels, based on eyes coordinates. Since

there are many variations (expression, pose), instead

of using the whole face (Huang et al., 2010), we use

facial parts. The regions of our face parts are illus-

trated in Figure 4. Different from (Yang et al., 2008),

the parts used in our experiment have semantic mean-

ing, e.g. eyebrow, eyes, nose, mouth, cheeks and

etc. Because there are pose and expression changes

in FRGCv2.0, we adopt the method for face division

in (Kumar et al., 2009). Each extracted face part is

enlarged to alleviate the inﬂuence brought by these

factors. The division of the face is illustrated in Fig-

ure 4.

3.3 Learning Scheme and Matching

Pixel intensity is used as the feature in this work. Let

us assume the 2D/3D feature pairs in each face part

are given as (F

, F

). Then PCA whitening is ap-

plied to the feature pairs separately. The output fea-

ture pairs are noted as (F

, F

). In our work, we

set 24 as the dimension of PCA whitening. Fea-

ture mean value normalization is also applied. Then

GRBM is used to get the representation of (F

, F

)

separately. The hidden layer variables extracted using

GRBM model are (F

, F

). After correlation learn-

ing, we can obtain two projection directions W

and

. (F

, F

) are projected into the shared subspace

using x = w

and y = w

. w

and w

are ob-

tained during the training process. Then the similarity

score s(x, y) can be obtained using the following nor-

malized score function:

s(x, y) =

x · y

(||x|| · ||y||)

(14)

Figure 5: A bar plot of matching accuracy of different fa-

cial parts. The number listed here corresponds to the face

part number in Fig 4. The results listed here are based on

GRBM+rKCCA scheme.

3.4 Experiment Results and Analysis

As described above, we want to investigate the perfor-

mance of different facial parts for 2D/3D face recog-

nition. As far as we know, this is the ﬁrst time that the

effectiveness of different face parts for 2D-3D face

recognition has been evaluated.

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

578

Table 1: Assignment of weight for each facial part. The number is the same as illustrated in Fig.4.

Face Part # 1 2 3 4 5 6 7 8 9 10 11

0.25 0.25 0.25 0.30 0.30 0.50 0.35 0.15 0.15 0.10 0.10

Figure 6: A bar plot of matching accuracy of different algo-

rithms.

Table 2: Performance of different schemes comparison.

Model Accuracy

CCA 0.911

rCCA 0.924

rKCCA 0.931

GRBM+rCCA 0.952

GRBM+rKCCA 0.960

From our experimental results listed in Figure 5,

we ﬁnd that there is a signiﬁcant difference among

face parts for face recognition. The facial part near

the nose region plays the most important role in the

matching scheme. Considering the different match-

ing accuracy of each part, the weighed sum rule (Jain

et al., 2011) is used as the fusion tool to obtain the

ﬁnal result. Weighted sum rule can be represented as

F =

∑

t=1

(15)

where F is the matching score and n is the total num-

ber of face parts. w

is the weight value corresponding

to the matching score s

of face part t. The assignment

of value w

for each facial part is illustrated in Table

1. The matching results after different face parts fu-

sion are shown in Table 2. A better matching result is

obtained after fusion of different face parts. From the

results listed in Figure 6, we ﬁnd that RBM can boost

the performance of correlation mapping.

In this paper, we also evaluate the proposed algo-

rithm using the global face. The accuracy is 55.0%

(based on GRBM+rKCCA). This result also demon-

strates that the single global face mapping between

2D and 3D face data is not appropriate for describ-

ing the relationship between 2D and 3D face data.

Since the correspondence of different face parts be-

tween 2D and 3D is not identical, it’s not accurate to

use the whole face for correlation learning between

two modalities.

4 CONCLUSIONS

In this paper, one single-layer network was proposed

for heterogeneous 2D/3D face recognition problem.

Our experiment results proved that learning correla-

tion representation on the layer features extracted us-

ing RBM resulted in a better matching performance.

Meanwhile, we also explored the effectiveness of dif-

ferent facial parts in 2D/3D face matching. The re-

sults indicated that fusion with different facial parts

can achieve a signiﬁcant improvement compared with

the global face.

The proposed scheme is an excellent addition to

the corpus of heterogeneous face recognition works.

The proposed learning scheme can also be adopted

by other 2D/3D face recognition works as the major

learning scheme.

REFERENCES

Bengio, Y. (2009). Learning deep architectures for ai. Foun-

dations and trends

 in Machine Learning, 2(1):1–

127.

Dhillon, P., Foster, D. P., and Ungar, L. H. (2011). Multi-

view learning of word embeddings via cca. In Ad-

vances in Neural Information Processing Systems,

pages 199–207.

Guo, G. and Wang, X. (2012). A study on human age esti-

mation under facial expression changes. In Computer

Vision and Pattern Recognition (CVPR), 2012 IEEE

Conference on, pages 2547–2553. IEEE.

Hardoon, D. R., Szedmak, S., and Shawe-Taylor, J. (2004).

Canonical correlation analysis: An overview with ap-

plication to learning methods. Neural Computation,

16(12):2639–2664.

Hinton, G. E. and Salakhutdinov, R. R. (2006). Reducing

the dimensionality of data with neural networks. Sci-

ence, 313(5786):504–507.

Hotelling, H. (1936). Relations between two sets of vari-

ates. Biometrika, 28(3/4):321–377.

Huang, D., Ardabilian, M., Wang, Y., and Chen, L. (2010).

Automatic asymmetric 3d-2d face recognition. In

Pattern Recognition (ICPR), 2010 20th International

Conference on, pages 1225–1228. IEEE.

2D-3DFaceRecognitionviaRestrictedBoltzmannMachines

579

Huang, D., Ardabilian, M., Wang, Y., and Chen, L. (2012).

Oriented gradient maps based automatic asymmetric

3d-2d face recognition. In Biometrics (ICB), 2012 5th

IAPR International Conference on, pages 125–131.

IEEE.

Jain, A. K., Ross, A. A. A., and Nandakumar, K. (2011).

Introduction to biometrics. Springer.

Kim, T.-K., Wong, S.-F., and Cipolla, R. (2007). Tensor

canonical correlation analysis for action classiﬁcation.

In Computer Vision and Pattern Recognition, 2007.

CVPR’07. IEEE Conference on, pages 1–8. IEEE.

Kumar, N., Berg, A. C., Belhumeur, P. N., and Nayar, S. K.

(2009). Attribute and simile classiﬁers for face veriﬁ-

cation. In Computer Vision, 2009 IEEE 12th Interna-

tional Conference on, pages 365–372. IEEE.

Li, A., Shan, S., Chen, X., and Gao, W. (2009). Maxi-

mizing intra-individual correlations for face recogni-

tion across pose differences. In Computer Vision and

Pattern Recognition, 2009. CVPR 2009. IEEE Confer-

ence on, pages 605–611. IEEE.

Mohamed, A.-r., Dahl, G. E., and Hinton, G. (2012).

Acoustic modeling using deep belief networks. Audio,

Speech, and Language Processing, IEEE Transactions

on, 20(1):14–22.

Ngiam, J., Khosla, A., Kim, M., Nam, J., Lee, H., and Ng,

A. (2011). Multimodal deep learning. In Proceed-

ings of the 28th International Conference on Machine

Learning (ICML-11), pages 689–696.

Phillips, P. J., Flynn, P. J., Scruggs, T., Bowyer, K. W.,

Chang, J., Hoffman, K., Marques, J., Min, J., and

Worek, W. (2005). Overview of the face recogni-

tion grand challenge. In Computer vision and pattern

recognition, 2005. CVPR 2005. IEEE computer soci-

ety conference on, volume 1, pages 947–954. IEEE.

Rama, A., Tarres, F., Onofrio, D., and Tubaro, S. (2006).

Mixed 2d-3d information for pose estimation and face

recognition. In Acoustics, Speech and Signal Pro-

cessing, 2006. ICASSP 2006 Proceedings. 2006 IEEE

International Conference on, volume 2, pages II–II.

IEEE.

Riccio, D. and Dugelay, J.-L. (2005). Asymmetric 3d/2d

processing: a novel approach for face recognition. In

Image Analysis and Processing–ICIAP 2005, pages

986–993. Springer.

Sargin, M. E., Yemez, Y., Erzin, E., and Tekalp, A. M.

(2007). Audiovisual synchronization and fusion us-

ing canonical correlation analysis. Multimedia, IEEE

Transactions on, 9(7):1396–1403.

Shotton, J., Fitzgibbon, A., Cook, M., Sharp, T., Finoc-

chio, M., Moore, R., Kipman, A., and Blake, A.

(2011). Real-time human pose recognition in parts

from single depth images. In Computer Vision and

Pattern Recognition (CVPR), 2011 IEEE Conference

on, pages 1297–1304. IEEE.

Slaney, M. and Covell, M. (2000). Facesync: A linear op-

erator for measuring synchronization of video facial

images and audio tracks. In NIPS, pages 814–820.

Srivastava, N. and Salakhutdinov, R. (2012). Multimodal

learning with deep boltzmann machines. In Advances

in Neural Information Processing Systems 25, pages

2231–2239.

Sutton, R. S. and Barto, A. G. (1998). Reinforcement learn-

ing: An introduction, volume 1. Cambridge Univ

Press.

Vinokourov, A., Cristianini, N., and Shawe-taylor, J. S.

(2002). Inferring a semantic representation of text via

cross-language correlation analysis. In Advances in

neural information processing systems, pages 1473–

1480.

Wang, H., Klaser, A., Schmid, C., and Liu, C.-L. (2011).

Action recognition by dense trajectories. In Computer

Vision and Pattern Recognition (CVPR), 2011 IEEE

Conference on, pages 3169–3176. IEEE.

Wang, X., Ly, V., Guo, G., and Kambhamettu, C. (2013). A

new approach for 2d-3d heterogeneous face recogni-

tion. In Multimedia (ISM), 2013 IEEE International

Symposium on. IEEE.

Xu, C., Li, S., Tan, T., and Quan, L. (2009). Automatic 3d

face recognition from depth and intensity gabor fea-

tures. Pattern Recognition, 42(9):1895–1905.

Yang, W., Yi, D., Lei, Z., Sang, J., and Li, S. Z. (2008).

2d–3d face matching using cca. In Automatic Face &

Gesture Recognition, 2008. FG’08. 8th IEEE Interna-

tional Conference on, pages 1–6. IEEE.

VISAPP2014-InternationalConferenceonComputerVisionTheoryandApplications

580
