Knowledge-based Subtractive Integration of mRNA and miRNA

Expression Proﬁles to Differentiate Myelodysplastic Syndrome

Jiˇr´ı Kl´ema

, Jan Zah´alka

, Michael Andˇel

and Zdenˇek Krejˇc´ık

Department of Computer Science and Engineering, Czech Technical University, Technick´a 2, Prague, Czech Republic

Department of Molecular Genetics, Institute of Hematology and Blood Transfusion, U Nemocnice, Prague, Czech Republic

Keywords:

Gene Expression, Machine Learning, microRNA, Classiﬁcation, Prior Knowledge, Myelodysplastic Syn-

drome.

Abstract:

The goal of our work is to integrate conventional mRNA expression proﬁles with miRNA expressions using

the knowledge of their validated or predicted interactions in order to improve class prediction in genetically

determined diseases. The raw mRNA and miRNA expression features become enriched or replaced by new

aggregated features that model the mRNA-miRNA interaction. The proposed subtractive integration method is

directly motivated by the inhibition/degradation models of gene expression regulation. The method aggregates

mRNA and miRNA expressions by subtracting a proportion of miRNA expression values from their respective

target mRNAs. The method is used to model the outcome or development of myelodysplastic syndrome, a

blood cell production disease often progressing to leukemia. The reached results demonstrate that the inte-

gration improves classiﬁcation performance when dealing with mRNA and miRNA proﬁles of comparable

predictive power.

1 INTRODUCTION

Onset and progression of myelodysplastic syndrome,

like other genetically determined diseases, depend

on the overall activity of copious genes during their

expression process. Current progress in microarray

technologies (Brewster et al., 2004) and RNA se-

quencing (Morin et al., 2008) enables affordable mea-

surement of wide-scale gene activity, but only on the

transcriptome level. Further levels of the gene ex-

pression (GE) process which prove disease, whether

proteome or even phenome, are still difﬁcult to cap-

ture. Henceforth, many natural learning tasks, such as

disease diagnosis or classiﬁcation, become non-trivial

within current generation GE data. However, GE is a

complex process with multiple phases, components,

and regulatory mechanisms. Sensing GE at certain

points of these phases and integrating the measure-

ments with the aid of recent knowledge about sub-

duing mechanisms may show the GE process in a

broader, systematic view, and make the analysis com-

prehensible, robust and potentially more accurate.

The goal of our work is to integrate conven-

tional GE data sources as mRNA proﬁles with mi-

croRNA measurements and to experimentally eval-

uate the merit of using the integrated data for class

prediction. MicroRNAs (miRNAs) (Lee et al., 1993)

serve as one component of complex machinery which

eukaryotic organisms use to regulate gene expres-

sion and protein synthesis. Since their discovery,

miRNA have shown to play crucial role in develop-

ment and various pathologies (Croce, 2009; Sayed

and Abdellatif, 2011). They are short ( 21 nu-

cleotides) noncoding RNA sequences which mediate

post-transcriptional repression of mRNA via multi-

protein complex called RISC complex (RNA-induced

silencing complex) where miRNA serve as a template

for recognizing complementary mRNA. The comple-

mentarity of miRNA-mRNA binding initiates one of

the two possible mechanisms: the complete homol-

ogy triggers degradation of target mRNA, whereas a

partial complementarity leads to inhibition of transla-

tion of target mRNA. However, despite the progress

in understanding the underlying mechanisms in re-

cent years, the effects of miRNA on gene expres-

sion is still a developing ﬁeld and many important

facts about mechanism of action and possible inter-

actions remain still unclear (Fabian and Sonenberg,

2012). The level of expression of particular miR-

NAs can be measured by (e.g.) miRNA microarrays,

analogically to well-known mRNA proﬁling. The re-

sulting dataset, called the miRNA expression proﬁle,

Kléma J., Zahálka J., And

el M. and Krej

cík Z..

Knowledge-based Subtractive Integration of mRNA and miRNA Expression Proﬁles to Differentiate Myelodysplastic Syndrome.

DOI: 10.5220/0004752200310039

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2014), pages 31-39

ISBN: 978-989-758-012-3

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

contains, similarly to mRNA proﬁles, tissue samples

as data instances; only this time the attributes are in-

dividual miRNA sequences. Integrating mRNA and

miRNA data sources may provide a better picture

about the true protein amount synthesized according

to respective genes, regarding the mechanisms of dis-

ease occurrence.

We propose integration stemming from the knowl-

edge which miRNA targets which mRNA. Target pre-

diction is a topic of active research (Tan Gana et al.,

2012). The most reliable form of target prediction

is experimental in vitro validation. Complementary

in silico target prediction offers more miRNA tar-

gets with a higher false detection rate. The predictive

algorithms either work based directly on molecular

biological theory, building the relationship based on

miRNA/mRNA structure and properties (Lewis et al.,

2003; Dweep et al., 2011), or be data-driven; i.e., de-

termining targets empirically using statistical or ma-

chine learning methods on as much data as possible

(Wang and Naqa, 2008; Krek et al., 2005). As an ex-

ample of algorithms of the ﬁrst class we should men-

tion miRanda, as an extension of the Smith-Waterman

algorithm (Smith and Waterman, 1981), miRWalk

(Dweep et al., 2011) and TargetScan (Lewis et al.,

2003); as to those of the second class refer to miRTar-

get2 (Wang and Naqa, 2008) or PicTar 5 (Krek et al.,

2005). Target prediction algorithms usually output a

score, which for a particular mRNA and a particular

miRNA quantiﬁes the strength of the belief that the

two are truly related. While there is no guarantee that

the results are truly correct, employing prediction al-

gorithms on already existing gene/miRNA expression

proﬁles is cheap and, with the possibility of thresh-

olding the score, one can express conﬁdence in the

results, possibly eliminating ﬂuke results.

Despite the above-mentioned problems in target

prediction, the main challenge in mRNA and miRNA

data integration is different. The relationship between

miRNAs and mRNAs is many-to-many, a miRNA

binds to different mRNAs, while an mRNA molecule

hosts binding sites for different miRNAs. Moreover,

the binding can be, and often is, imperfect; with a

miRNA binding only partly to its target site. One

miRNA can, in addition, potentially bind to multiple

locations on one mRNA. Due to all of these aspects

and the fact that the mRNA-miRNA interaction itself

is far from being fully understood, mRNA-miRNA

data integration is a non-trivial task. Simply merg-

ing mRNA and miRNA probesets (Lanza et al., 2007)

may increase current difﬁculties in GE classiﬁcation,

such as overﬁtting caused by the immense number of

features. Hence, a smart method of reasonable inte-

grating miRNA and mRNA features is desired.

The authors of (Huang et al., 2011) present an in-

teresting tool for inferring a disease speciﬁc miRNA-

gene regulatory network based on prior knowledge

and user data (miRNA and mRNA proﬁles). How-

ever, this approach does not address the method of

breaking down the large inferred network into smaller

regulatory units, which are essential for subsequent

classiﬁcation. The method of data speciﬁc identiﬁca-

tion of miRNA-gene regulatory modules is proposed

in (Peng et al., 2009) and (Tran et al., 2008), where

the modules are searched as maximal bi-cliques or

induced as decision rules respectively. But none of

these methods offer an intuitive way to express the

identiﬁed modules within the sample set. Contrari-

wise, (Kim et al., 2012) provides a black box integra-

tion procedure for several data sources like mRNAs,

miRNAs, methylation data etc., with an immediate

classiﬁcation output. Nevertheless, this method con-

tains no natural interpretation of the learned predictive

models, which is unsuitable for an expert decision-

making tool.

In this work, we propose a novel feature extraction

and data integration method for the accurate and in-

terpretable classiﬁcation of biological samples based

on their mRNA and miRNA expression proﬁles. The

main idea is to use the knowledge of miRNA tar-

gets and better approximate the actual protein amount

synthesized in the sample. The raw mRNA and

miRNA expression features become enriched or re-

placed by new aggregated features that model the

mRNA-miRNA regulation instead. The sample pro-

ﬁle presumably gets closer to the phenotype be-

ing predicted. The proposed subtractive aggregation

method directly implements a simple mRNA-miRNA

interaction model in which mRNA expression is mod-

iﬁed using the expression of its targeting miRNAs.

A similar approach has already been demonstrated in

(Andˇel et al., 2013), where we employ matrix factor-

ization proposed in (Zhang et al., 2011) instead. In

comparison to the subtractive method under study, the

matrix-factorization approach leaves room for devel-

oping features corresponding to larger functional co-

modules, but it could overﬁt training data when deal-

ing with a small number of samples.

The method widely used for analyzing associa-

tions between two heterogeneous genome-wide mea-

surements acquired on the same cohort is canoni-

cal correlation analysis (CCA) (Pollack et al., 2002;

Stranger et al., 2007; Witten and Tibshirani, 2009).

CCA is applicable for mRNA and miRNA expres-

sion integration. However, CCA is based purely on

mutual correlation between distinct feature sets and

disregards prior knowledge of their interaction. It

rather aims to describe or simplify the underlying

BIOINFORMATICS2014-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

data, while we focus on prediction of the decrease of

respective protein level due to inhibition that does not

primarily manifest in correlation. In (Li et al., 2012)

the authors model heterogeneous genomic data by the

means of sparse regression. The method explains

mRNA matrix through decomposition into miRNA

expression, copy number value and DNA methylation

matrices. It follows similar descriptive goals as CCA.

Incentivefor our method design comes from probe

sessions performed on patients with myelodysplastic

syndrome (MDS). MDS is a heterogeneous group of

clonal hematological diseases characterized by inef-

fective hematopoiesis originating from hematopoietic

stem cells (Vaˇs´ıkov´a et al., 2010). Patients with MDS

usually develop severe anemia (or other cytopenias)

and require frequent blood transfusion. MDS is also

characterized by a high risk of transformation into

secondary acute myeloid leukemia, and thus could

serve as a model for the research of leukemic trans-

formation.

Of the different cytogenetic abnormalities found

in MDS, deletion of the long arm of chromosome 5

(del(5q)) is the most common aberration. MDS with

isolated del(5q) exhibits a distinct clinical proﬁle and

a favorable outcome. Lenalidomide is a relatively new

and potent immunomodulatory drug for the treatment

of patients with transfusion-dependent MDS with

del(5q). It has pleiotropic biologic effects, including a

selective cytotoxic effect on del(5q) myelodysplastic

clones. As miRNAs serve as key regulators of many

cellular processes including hematopoiesis, a number

of miRNAs have been also implicated in the patho-

physiology of MDS (Rhyasen and Starczynowski,

2012; Dostalova Merkerova et al., 2011).

The paper is organized as follows. Section 2 de-

scribes the proposed subtractive method (SubAgg) in-

cluding its SVD-based modiﬁcation (SVDAgg) that

enables different subtractive weights for different

miRNAs. Section 3 describes the MDS domain, de-

ﬁnes the learning tasks and summarizes the experi-

mental protocol. Section 4 provides experimental re-

sults. Section 5 concludes the paper.

2 MATERIALS AND METHODS

This section covers the procedures proposed for the

integration of mRNA and miRNA data. First, inputs

required for correct functionality of the methods are

deﬁned in Section 2.1. Then dataset merge, a simple

integration technique serving as a benchmark, is pre-

sented in Section 2.2. The new integration method,

subtractive aggregation is presented in Section 2.3.

2.1 Inputs

The integration method requires two datasets; one

containing mRNA measurements, and one containing

miRNA measurements. Those two datasets must be

matched; i.e., both must contain samples taken from

the same patients and the same tissue types.

Let G = {g

,...,g

} be the genes, R = {r

,...,r

}

be the miRNAs and S = {S

,...,S

} be the interro-

gated samples (tissues, patients, experiments). Then

: G × S → R is the amount of respective mRNA

measured by mRNA chip in particular samples, and

: R × S → R is the expression proﬁle of known

miRNA sequences; i.e., the amount of respective

molecules measured by the miRNA chip within the

samples.

For further reference, the mRNA dataset will be

denoted as an s × n matrix X

, with s samples and

n genes. Similarly, the miRNA dataset will be re-

ferred to as an s × m matrix X

, with m miRNAs.

Henceforth, column vectors of the two data matrices,





i=1

and





i=1

, represent measured expression

of particular genes and miRNAs, respectively.

The integration method requires information per-

taining to which miRNA targets which mRNA. The

known miRNA-gene control system is represented by

binary relation T ⊂ R × G.

2.2 Dataset Merge

The most straightforward method of obtaining inte-

grated mRNA and miRNA data is merging the two re-

spective datasets. This method, as mentioned above,

was presented by (Lanza et al., 2007) and is in-

cluded in our experimental evaluation as a bench-

mark. The resulting merged dataset simply contains

column-wise concatenated mRNA and miRNA data

matrices. The advantages of this integration approach

are no required prior knowledge of targets and com-

putational efﬁciency. Excluding prior knowledge of

targets, however, means that the target relationships

are to be induced empirically by the classiﬁer itself.

The question remains as to whether the classiﬁer is

capable of doing that. Also, this approach increases

the already-high number of features.

2.3 Subtractive Aggregation (SubAgg)

Due to the fact, that many aspects of miRNA-mRNA

interactions are not yet fully understood and remain

unclear,we were forced to involveseveral simplifying

assumptions as follows: 1) miRNA effect is strictly

subtractive, 2) the measured miRNA amount is pro-

portionally distributed among its targets, and 3) the

Knowledge-basedSubtractiveIntegrationofmRNAandmiRNAExpressionProfilestoDifferentiateMyelodysplastic

Syndrome

mRNA inhibition rate is proportional to the amount

of available targeting miRNA.

The method aggregatesmRNA and miRNA values

by subtracting a proportion of miRNA expression val-

ues from their respective target mRNAs. At the same

time, it minimizes the number of parameters needed

to be learned to 1. This characteristic complies with

the inconvenient sample set size and the feature set

size rate.

Each gene, or rather its mRNA transcript, g ∈ G

has a deﬁned set of miRNAs which target it, R

⊂ R .

Conversely, each miRNA r ∈ R has a deﬁned set of

mRNAs which it targets, G

⊂ G. Let, x

be the

amount of mRNA measured for respective gene g in

an arbitrary tissue sample and x

be the amount of

particular miRNA r measured in an arbitrary sample.

Let p

be the proportion of the amount of r ∈ R

used

to regulate the expression of gene g and σ be a co-

efﬁcient representing the strength of the inhibition of

mRNA by miRNAs. Since the process is considered

to be strictly subtractive, the aggregated value repre-

senting the inhibited mRNA of gene g, denoted x

sub

would be obtained by subtracting as follows:

sub

= x

− σ

∑

r∈R

. (1)

This equation takes an above-mentioned simpli-

ﬁed view of inhibition of the gene by all targeting

miRNAs. Hence, proportion p

is deﬁned as a ratio

of x

to the sum of levels of all targeted mRNAs. The

inhibition equation is then expanded:

sub

= x

−

∑

r∈R

∑

t∈G

. (2)

Further, the parameter σ has been expanded in

Equation (2). The strength of inhibition is an un-

known value, but needs to be somehow represented

nonetheless. In this method, it is modeled as the prod-

uct of a real parameter c and a normalizer deﬁned

as 1/|R

|. The real parameter c represents the un-

known strength of the relationship and its values are

subject to experimentation. Intuitively, the larger c

is, the more prominent the miRNA data are (larger c

ampliﬁes the inhibition). The c parameter can be set

uniformly for all genes, or alternatively, different c

values may be employed for different mRNAs. Con-

cerning the limited sample sets and the risk of over-

ﬁtting, we worked with the uniform c for all mRNAs.

Its setting is further discussed in the experimental part

of the paper.

It is possible to obtain the overall data matrix X

sub

of inhibited mRNA by iterativelyupdating the subma-

trix X

1...s,G

, thus calculating all x

sub

in Equation (2)

pertaining to one miRNA and all samples in one step.

Henceforth, the implementation of Equation (2) is it-

erated over particular miRNAs, as there are far fewer

miRNAs than mRNAs:

sub

1...s,G

= X

1...s,G

− c∆(u)∆(x

)∆(s)

−1

1...s,G

, (3)

where ∆(v) denotes a diagonal matrix, whose (i,i)-

th item is equal to the i-th value of a vector v; u is

a vector containing the number of targeting miRNAs

for each mRNA and s = X

1...s,G

is a vector of

mRNA value sums pertaining to miRNA targets in all

samples.

2.4 SVD-based Aggregation (SVDAgg)

The aim of an integration method in general, is to re-

duce the mRNA vectors and their respective target-

ing miRNAs into one aggregated feature. A com-

mon known method which reduces data, preserving

as much useful information contained in the non-

reduced vectors as possible, is Singular value decom-

position (SVD) (Eckart and Young, 1936).

The second method we propose, SVD-based ag-

gregation, is based on the idea that targeting miRNAs

of each gene can be represented in one dimensional

basis space. So, for each gene g, the expression data

submatrix X

1...s,R

, referring to the respective target-

ing miRNAs, is projected into its ﬁrst singular vector:

µ,svd

= X

1...s,R

1...|R

|,1

, (4)

where V is the singular vector matrix of targeting

miRNAs. Vector x

µ,svd

, the new representative of

targeting miRNAs, is then joined to the respective

mRNA vector, and reduced into one dimensional

space again:

G,svd

µ,svd

1...2,1

, (5)

where U

1...2,1

is the ﬁrst singular vector of the two

concatenated vectors.

The new feature x

G,svd

, a virtual proﬁle compris-

ing the gene and its miRNAs, is computed in two

steps. The reason for not aggregating the mRNA

vector and respective miRNA vectors together at the

same time follows. Such an alternative approach

gives almost all the power to the miRNAs, and since

they would constitute a majority of vectors, SVD

would have a tendency to disregard the information

contained in the mRNA, which is necessary to avoid.

Moreover, this effect would increase with the increas-

ing number of targeting miRNAs.

BIOINFORMATICS2014-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

3 EXPERIMENTS

This section describes the MDS domain, deﬁnes the

learning tasks, and summarizes the experimental pro-

tocol.

3.1 Datasets

The data were acquired in collaborationwith the Insti-

tute of Hematology and Blood Transfusion in Prague.

Illumina miRNA (Human v2 MicroRNA Expression

Proﬁling Kit, Illumina, San Diego, USA) and mRNA

(HumanRef-8 v3 and HumanHT-12 v4 Expression

BeadChips, Illumina) expression proﬁling were used

to investigate the effect of lenalidomide treatment on

miRNA and mRNA expression in bone marrow (BM)

CD34+ progenitor cells and peripheral blood (PB)

CD14+ monocytes. Quantile normalization was per-

formed independently for both the expression sets, the

datasets were scaled to have the identical median of 1

then. The mRNA dataset has 16,666 attributes rep-

resenting the GE level through the amount of corre-

sponding mRNA measured, while the miRNA dataset

has 1,146 attributes representing the expression level

of particular miRNAs. The measurements were con-

ducted on 75 tissue samples categorized according to

the following conditions: 1) tissue type: peripheral

blood monocytes vs. bone marrow cells, 2) presence

of MDS and del(5q), 3) lenalidomide treatment stage:

before treatment (BT) vs. during treatment (DT).

Henceforth, the samples can be broken into 10 cat-

egories. The categories, along with the actual number

of samples, are shown in Table 1:

Table 1: The overview of MDS classes.

Healthy 10

5q-

BT 9

DT 13

non 5q-

BT 4

DT 5

Healthy 10

5q-

BT 11

DT 5

non 5q-

BT 6

DT 2

The domain experts deﬁned 16 binary classiﬁca-

tion tasks with a clear diagnostic and therapeutic mo-

tivation. There are 8 tasks for each tissue type, the

tissue types are encoded in the task names, while the

numbers of samples are shown in parentheses. The

afﬂicted group comprises all MDS patients regardless

their treatment status.

1. PB1: healthy (10) × afﬂicted (31),

2. BM1: healthy (10) × afﬂicted (24),

3. PB2: healthy (10) × BT (13),

4. BM2: healthy (10) × BT (17),

5. PB3: healthy (10) × BT with del(5q) (9),

6. BM3: healthy (10) × BT with del(5q) (11),

7. PB4: healthy (10) × DT (18),

8. BM4: healthy (10) × DT (7),

9. PB5: afﬂicted: del(5q) (9) × non del(5q) (22),

10. BM5: afﬂicted: del(5q) (8) × non del(5q) (16).

11. PB6: healthy (10) × DT del(5q) (13),

12. BM6: healthy (10) × DT del(5q) (5),

13. PB7: healthy (10) × BT non del(5q) (4),

14. BM7: healthy (10) × BT non del(5q)(6),

15. PB8: del(5q): BT (9) × DT (13),

16. BM8: del(5q): BT (11) × DT (5).

3.2 Prior Knowledge

Considering prior knowledge, we downloaded the

interactions between genes and miRNAs from pub-

licly available databases. TarBase 6.0, strives to en-

compass as many miRNA-mRNA validated target-

ing relations scattered in literature as possible. The

database, maintained by DIANA Lab, was built uti-

lizing text-mining-assisted literature curation – litera-

ture covering the discovery of newtarget relationships

were downloadedin XML format from MedLine, pro-

cessed using text mining and the resulting candidates

for addition to the database were reviewed before the

actual entry by the curators (DIANA Lab personnel).

Its respective target matrix, ﬁltered so as to contain

solely human data, covers 228 miRNAs, 11,996 mR-

NAs and 20,107 target relationships between them.

When selecting only the mRNAs and miRNAs avail-

able in the actual chip probesets and carefully trans-

lating and unifying miRNA identiﬁers using miR-

Base (Kozomara and Grifﬁths-Jones, 2011), the Tar-

Base covers 179 miRNAs, 8,188 mRNAs and con-

tains 14,404 target relationships.

The miRWalk database (Dweep et al., 2011), com-

prises both validated and predicted targets. In our ex-

periments, only the predicted target database is used;

the entries in the validated target database are already

included in TarBase 6.0. Since, according to the

authors, no target prediction algorithm consistently

achieves better results than the others, the predicted

target database includes not only targets obtained us-

ing the eponymous miRWalk algorithm, but also tar-

gets provided by other prediction algorithms. Our

experiments use ﬁve of them, which are outlined in

Section 1. The predicted targets dataset used in the

Knowledge-basedSubtractiveIntegrationofmRNAandmiRNAExpressionProfilestoDifferentiateMyelodysplastic

Syndrome

experiments was obtained from miRWalk by merging

the results of multiple queries on the mRNA targets

of canonically-named miRNAs present in the exper-

imental miRNA dataset. Each query consisted of up

to 20 miRNAs (limit imposed by the miRWalk site),

each query was restricted to targets in the 3’ UTR re-

gion with p-value less or equal to 0.01. The result-

ing dataset obtained contains 392 miRNAs, 14,550

mRNAs and 89,402 unique predicted human miRNA-

mRNA target relationships. 389 miRNAs, 12,847

mRNAs and 79,014 relationships were applicable in

terms of our actual mRNA and miRNA probesets.

The merged target dataset concatenates both the

above-mentionedresources. It is further referred to as

the extended predicted database and contains 93,325

target relationships.

3.3 Experimental Protocol

The main aim of the experiments is to verify whether

the features, extracted by prior knowledge, can im-

prove classiﬁcation quality. Since we deal with

classes of different sizes, we use the Mathews cor-

relation coefﬁcient as a balanced quality measure. It

returns a value between -1 and +1, +1 represents a

perfect match between annotation and prediction. We

employ three benchmarking feature sets to tackle this

issue. The ﬁrst contains mRNA proﬁles only, the

second takes purely miRNA proﬁles, and the third

concatenates them as described in Section 2.2. The

knowledge-based feature sets denoted as SubAgg and

SVDAgg take the merged feature set and concate-

nate it with the aggregated features obtained in Equa-

tions (2), (3) and Equation (5) respectively.

We used 5 times repeated stratiﬁed 5-fold cross

validation to assess the performance of the proposed

methods as well as their benchmarking counterparts.

The whole learning workﬂow was implemented in R

environment.

SVDAgg has no parameters, SubAgg has the in-

hibition strength parameter c that needs to be opti-

mized. The most straightforward way is to set it

to 1 relying purely on mRNA and miRNA expres-

sion normalization. However, the absolute mRNA

and miRNA expression values can hardly be directly

matched. Moreover, the relative predictive power of

mRNA and miRNA feature sets varies for different

tasks. That is why we tuned the optimal value of c

in terms of internal cross-validation. The parameter

values 10

, k∈{-2,1,0,1,2} were concerned, the best

value was taken in each experimental setting and fold

uniformly for all mRNAs.

In order to keep a reasonable number of features,

to minimize overﬁtting, and maintain the constant

number of features across different feature sets in

terms of one learning task, we applied the well-known

feature selection method SVM-RFE (Guyon et al.,

2002). In each of the learning tasks, the size of the

reduced feature set was established as follows. We

found the number of active mRNAs and the number

of active miRNAs, and took their minimum. This

value served as the target feature set size for mRNA,

miRNA, merged and both subtractive classiﬁers.

We deal with 8 binary MDS tasks deﬁned in Sec-

tion 3.1. At the same time, we have two distinct tar-

get relations (validated and extended) as described in

the previous section. These target relations have dif-

ferent domains and ranges, the domain and range of

the validated target relation make subsets of their ex-

tended counterparts. As the aggregated features con-

cern purely the domain miRNAs and the range mR-

NAs we ﬁlter out the rest of mRNA and miRNA pro-

ﬁles from the benchmarking datasets as well. This

is done in order to make the comparison of classi-

ﬁer performance on benchmarking datasets more re-

latable and better identify the potential asset of the

target relationships. The absolute score is not impor-

tant, the main issue is the relative comparison in terms

of a single learning task. In this way, 64 different ex-

perimental settings originate (2 tissue types × 8 task

deﬁnitions × 2 target relations × 2 classiﬁcation al-

gorithms). The settings are independent between tis-

sue types, however, they deal with overlapping sam-

ple and feature sets within the same tissue type.

We employed two diverse classiﬁcation algo-

rithms to avoid the dependence of experimental re-

sults on a speciﬁc choice of learning method. Sup-

port Vector Machine (SVM) with a linear kernel and

the regularization parameter C = 1 was taken as the

ﬁrst option. SVM prevails in predictive modeling of

gene expression data and is usually associated with

high resistance to noise in data. C setting proves

robust even when learning with many relevant fea-

tures (Joachims, 1998). Na¨ıve Bayes (NB) is a simple

and interpretable classiﬁer.

4 RESULTS

The individual feature sets were tested and compared

under all the experimental settings deﬁned above. The

results reached are available in Tables 2 and 3; each

table summarizes the results achieved by one of the

classiﬁcation algorithms.

The following direct observations can be drawn

from the result tables. There are settings that can

be perfectly solved by either the mRNA or miRNA

proﬁles. Then, there are settings with incomparable

BIOINFORMATICS2014-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

score reached with the mRNA and miRNA feature set.

Naturally, these settings are not suitable for any in-

tegration including the concatenation as this integra-

tion can hardly outperform the better of the raw fea-

ture sets. These settings can be a priori identiﬁed and

omitted from the integration procedure, or the proce-

dure can be parametrized in such a way that the in-

ferior dataset has no inﬂuence on the ﬁnal feature set

(e.g., c parameter in SubAgg is set to 0).

On the other hand, when dealing with mRNA

and miRNA proﬁles of comparable predictive power,

the integration improves classiﬁcation performance.

In general, the knowledge-based methods outperform

their concatenation benchmark. As already men-

tioned, we deal with dependent tasks and settings

while traditional hypothesis testing asks for indepen-

dence. That is why we cannot apply Wilcoxon, Fried-

man, or other classical tests. Instead, the methods are

sorted and ranked according to their pair-wise com-

parison in each of the particular settings; Figure 1

provides an overall comparison graph and the last

row of result tables gives the ranks averaged across

all the settings. The comparison suggests that the

knowledge-based feature sets dominate the rest of the

feature pool.

Another useful comparison measure is the over-

all number of occurrences, denoted as synergies, in

which the knowledge based features outperform both

raw feature sets. The presented results show 31 and

26 synergies occurred in the case of SubAgg and

SVDAgg methods respectively; only 10 synergies can

be observed in the case of the benchmark integration.

In the other words, when dealing with settings that

cannot be perfectly solved by the original features, the

knowledge based integration helps.

SVM turns out to be a better choice than na¨ıve

Bayes. Let us stress that the choice of target type (val-

idated, extended) may seem to largely affect classiﬁ-

cation quality; however, the main reason for this dif-

ference lies in the ﬁltering mentioned in Section 3.3.

The validated and extended runs cannot be directly

compared (validated clearly worse than extended).

The relative comparison between the merged and the

other knowledge-based methods suggests that when

including the predicted targets into the aggregation,

no clear improvement can be observed.

5 CONCLUSIONS

Molecular classiﬁcation of biological samples based

on their expression proﬁles represents a natural task.

However, the task proved conceptually difﬁcult due

to the inconvenient rate of the sample and feature set

Table 2: The SVM results in terms of MCC. T stands for

the tissue type, # for the task ID, R for the target relation (V

means validated and E extended), mR for mRNA, miR for

miRNA, mer for merged, Sub stands for SubAgg and SVD

for SVDAgg. The last row gives average ranking of each

feature set; the lower the rank, the better.

T # R

Feature set

mR miR mer Sub SVD

PB 1 E 0.962 0.653 0.962 1.000 1.000

PB 2 E 0.983 0.881 0.983 0.983 1.000

PB 3 E 0.979 0.812 0.979 1.000 1.000

PB 4 E 1.000 0.801 1.000 1.000 0.970

PB 5 E 0.860 0.969 0.891 0.891 0.938

PB 6 E 1.000 0.823 1.000 1.000 0.983

PB 7 E 0.755 0.861 0.719 0.826 0.791

PB 8 E 0.621 0.487 0.564 0.562 0.644

BM 1 E 0.972 0.921 0.986 0.959 0.959

BM 2 E 0.911 0.954 0.911 0.939 0.925

BM 3 E 0.944 0.981 0.944 0.944 0.944

BM 4 E 0.976 0.883 0.976 0.952 0.838

BM 5 E 0.732 0.907 0.773 0.816 0.913

BM 6 E 0.882 0.853 0.882 0.911 0.853

BM 7 E 0.947 0.974 0.974 0.947 1.000

BM 8 E 0.574 0.541 0.539 0.434 0.448

PB 1 V 0.962 0.781 0.962 1.000 0.987

PB 2 V 0.983 0.827 0.983 0.983 0.916

PB 3 V 0.938 0.771 0.979 1.000 0.959

PB 4 V 1.000 0.761 1.000 1.000 0.970

PB 5 V 0.860 0.939 0.891 0.891 0.891

PB 6 V 1.000 0.895 1.000 1.000 1.000

PB 7 V 0.719 -0.156 0.645 0.791 0.607

PB 8 V 0.621 0.506 0.620 0.523 0.586

BM 1 V 0.972 0.854 0.986 0.959 0.986

BM 2 V 0.897 0.874 0.911 0.954 0.954

BM 3 V 0.963 0.909 0.963 1.000 0.981

BM 4 V 0.976 0.856 0.976 0.952 1.000

BM 5 V 0.694 0.893 0.732 0.773 0.717

BM 6 V 0.911 0.795 0.882 0.911 0.941

BM 7 V 0.921 0.896 0.974 0.974 0.947

BM 8 V 0.574 0.607 0.501 0.541 0.574

Avg. ranking 3.08 3.81 2.88 2.56 2.67

sizes and complexity and heterogeneity of the expres-

sion process. These characteristics often cause over-

ﬁtting. Classiﬁers do not sufﬁciently generalize; in-

stead of revealing the underlying relationships, they

capture perturbations in training data. This problem

can be minimized by regularization; i.e., introduc-

tion of additional knowledge. The regularized models

should be more comprehensible and potentially more

accurate than standard models based solely on a large

amount of raw measurements.

The integration of heterogeneous measurements

and prior knowledge is non-trivial, though. In this

paper we proposed the subtractive method that aggre-

gates mRNA and miRNA values by subtracting a pro-

portion of miRNA expression values from their re-

spective target mRNAs. The method simpliﬁes the

mRNA-miRNA interaction and minimizes the num-

ber of parameters needed to be learned to 1. We also

proposed another integration method that can be per-

ceived as an extension that enables different subtrac-

Knowledge-basedSubtractiveIntegrationofmRNAandmiRNAExpressionProfilestoDifferentiateMyelodysplastic

Syndrome

Table 3: The NB results in terms of MCC. The header sym-

bols have the same meaning as in Table 2.

T # R

Feature set

mR miR mer Sub SVD

PB 1 E 0.840 0.732 0.840 0.840 0.799

PB 2 E 0.865 0.846 0.881 0.849 0.898

PB 3 E 0.845 0.689 0.845 0.900 0.881

PB 4 E 0.831 0.732 0.831 0.844 0.816

PB 5 E 0.794 0.984 0.858 0.875 0.860

PB 6 E 0.824 0.770 0.824 0.877 0.965

PB 7 E 0.645 0.791 0.645 0.645 0.965

PB 8 E 0.322 0.429 0.303 0.308 0.523

BM 1 E 0.929 0.915 0.944 0.930 0.943

BM 2 E 0.953 0.953 0.953 0.873 0.984

BM 3 E 0.909 0.981 0.909 0.909 0.963

BM 4 E 0.976 0.787 0.976 0.976 0.793

BM 5 E 0.593 0.871 0.732 0.713 0.753

BM 6 E 1.000 0.707 0.795 0.941 0.707

BM 7 E 0.870 0.866 0.870 0.870 0.896

BM 8 E 0.320 0.399 0.383 0.405 0.268

PB 1 V 0.853 0.551 0.853 0.880 0.880

PB 2 V 0.833 0.627 0.849 0.865 0.965

PB 3 V 0.881 0.641 0.881 1.000 1.000

PB 4 V 0.863 0.685 0.863 0.876 0.844

PB 5 V 0.842 0.937 0.842 0.875 0.860

PB 6 V 0.805 0.627 0.805 0.895 0.911

PB 7 V 0.861 0.826 0.895 0.965 0.826

PB 8 V 0.322 0.210 0.303 0.362 0.523

BM 1 V 0.886 0.887 0.915 0.930 0.929

BM 2 V 0.953 0.828 0.953 0.904 0.954

BM 3 V 0.909 0.908 0.909 0.888 0.944

BM 4 V 0.951 0.882 0.951 0.976 0.909

BM 5 V 0.578 0.815 0.694 0.733 0.694

BM 6 V 0.941 0.853 0.882 0.970 0.911

BM 7 V 0.870 0.872 0.870 0.870 0.870

BM 8 V 0.153 0.201 0.187 0.272 0.361

Avg. ranking 3.41 3.72 3.17 2.36 2.34

tive weights for different miRNAs; the weights are

learned by SVD.

In this work we classiﬁed myelodysplastic syn-

drome patients under 64 experimental settings. We

compared ﬁve types of feature sets. Two of them rep-

resented raw homogeneous expression measurements

(mRNa and miRNA proﬁles), the third implemented

their straightforward concatenation, and the last two

resulted from SubAgg and SVDAgg integration. The

comparison suggests that the knowledge-based fea-

ture sets dominate the rest of the feature pool, and

the features resulting from the mRNA-miRNA target

relation can improve classiﬁcation performance.

There is still a lot of future work. More problem

domains need to be considered. The prior knowl-

edge should be extended to cover the gene regula-

tory network (the protein-protein interactions, inter-

actions between genes, and their transcription fac-

tors). Another challenge is to employ epigenetic data,

namely DNA methylation. Concerning the algorith-

mic issues, we intend to develop another parameter-

free integration method where the prior knowledge

controls pseudorandom construction of weak classi-

Figure 1: Pair-wise classiﬁcation comparison graph. The

nodes represent particular feature sets, an edge from node a

to node b, annotated as x-y-z means that method a outper-

forms method b in x experiments, in y ties and in z losses.

ﬁers vaguely corresponding to the individual biolog-

ical processes. The weak classiﬁers will later be

merged into an ensemble classiﬁer.

ACKNOWLEDGEMENTS

This research was supported by the grants NT14539,

NT14377 and NT13847 of the Ministry of Health of

the Czech Republic.

REFERENCES

Andˇel, M., Kl´ema, J., and Krejˇc´ık, Z. (2013). Integrat-

ing mRNA and miRNA expressions with interaction

knowledge to predict myelodysplastic syndrome. In

ITAT 2013: Information Technologies – Applications

and Theory, Workshop on Bioinformatics in Genomics

and Proteomics, pages 48–55.

Brewster, J. L., Beason, K. B., Eckdahl, T. T., et al. (2004).

The microarray revolution: Perspectives from educa-

tors. Biochem Mol Biol Educ, 32(4):217–27.

Croce, C. M. (2009). Causes and consequences of mi-

croRNA dysregulation in cancer. Nat Rev Genet,

10(10):704–14.

Dostalova Merkerova, M., Krejcik, Z., Votavova, H., Be-

lickova, M., Vasikova, A., and Cermak, J. (2011). Dis-

tinctive microRNA expression proﬁles in CD34+ bone

marrow cells from patients with myelodysplastic syn-

drome. Eur J Hum Genet, 19(3):313–9.

BIOINFORMATICS2014-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

Dweep, H., Sticht, C., Pandey, P., et al. (2011). miRWalk -

Database: Prediction of possible miRNA binding sites

by ”walking” the genes of three genomes. J Biomed

Inform, 44(5):839–47.

Eckart, C. and Young, G. (1936). The approximation of

one matrix by another of lower rank. Psychometrika,

1:211–8.

Fabian, M. R. and Sonenberg, N. (2012). The mechanics

of miRNA-mediated gene silencing: a look under the

hood of miRISC. Nat Struct Mol Biol, 19(6):586–93.

Guyon, I., Weston, J., Barnhill, S., and Vapnik, V. (2002).

Gene selection for cancer classiﬁcation using support

vector machines. Machine Learning, 46:389–422.

Huang, G. T., Athanassiou, C., and Benos, P. V. (2011).

mirConnX: condition-speciﬁc mRNA-microRNA net-

work integrator. Nucleic acids res, 39(Web Server

issue):W416–23.

Joachims, T. (1998). Text categorization with support

vector machines: Learning with many relevant fea-

tures. In European Conference on Machine Learning

(ECML), pages 137–42, Berlin. Springer.

Kim, D., Shin, H., Song, Y. S., et al. (2012). Synergis-

tic effect of different levels of genomic data for can-

cer clinical outcome prediction. J Biomed Inform,

45(6):1191–8.

Kozomara, A. and Grifﬁths-Jones, S. (2011). miRBase: in-

tegrating microRNA annotation and deep-sequencing

data. Nucleic Acids Res, 39(Database-Issue):152–7.

Krek, A., Gr¨un, D., Poy, M. N., et al. (2005). Combina-

torial microRNA target predictions. Nature genetics,

37(5):495–500.

Lanza, G., Ferracin, M., Gaf`a, R., et al. (2007).

mRNA/microRNA gene expression proﬁle in mi-

crosatellite unstable colorectal cancer. Mol Cancer,

6:54+.

Lee, R. C., Feinbaum, R. L., and Ambros, V. (1993). The

C. elegans heterochronic gene lin-4 encodes small

RNAs with antisense complementarity to lin-14. Cell,

75(5):843–54.

Lewis, B. P., Shih, I.-h. H., Jones-Rhoades, M. W., et al.

(2003). Prediction of mammalian microRNA targets.

Cell, 115(7):787–98.

Li, W., Zhang, S.-H., et al. (2012). Identifying multi-layer

gene regulatory modules from multi-dimensional ge-

nomic data. Bioinformatics, 28(19):2458–66.

Morin, R., Bainbridge, M., Fejes, A., et al. (2008). Proﬁl-

ing the HeLaS3 transcriptome using randomly primed

cDNA and massively parallel short-read sequencing.

BioTechniques, 45(1):81–94.

Peng, X., Li, Y., Walters, K. A., et al. (2009). Compu-

tational identiﬁcation of hepatitis C virus associated

microRNA-mRNA regulatory modules in human liv-

ers. BMC Genomics, 10(1):373+.

Pollack, J. R., Sørlie, T., Perou, C. M., et al. (2002). Mi-

croarray analysis reveals a major direct role of DNA

copy number alteration in the transcriptional program

of human breast tumors. Proc Natl Acad Sci U S A,

99(20):12963–8.

Rhyasen, G. W. and Starczynowski, D. T. (2012). Dereg-

ulation of microRNAs in myelodysplastic syndrome.

Leukemia, 26(1):13–22.

Sayed, D. and Abdellatif, M. (2011). MicroRNAs in devel-

opment and disease. Physiol Rev, 91(3):827–87.

Smith, T. F. and Waterman, M. S. (1981). Identiﬁcation

of common molecular subsequences. J Mol Biol,

147(1):195–7.

Stranger, B. E., Forrest, M. S., Dunning, M., et al.

(2007). Relative impact of nucleotide and copy num-

ber variation on gene expression phenotypes. Science,

315(5813):848–53.

Tan Gana, N. H., Victoriano, A. F., and Okamoto, T. (2012).

Evaluation of online miRNA resources for biomedical

applications. Genes to Cells, 17(1):11–27.

Tran, D. H., Satou, K., and Ho, T. B. (2008). Finding mi-

croRNA regulatory modules in human genome using

rule induction. BMC Bioinformatics, 9(S-12).

Vaˇs´ıkov´a, A., Bˇeliˇckov´a, M., Budinsk´a, E., et al. (2010). A

distinct expression of various gene subsets in cd34+

cells from patients with early and advanced myelodys-

plastic syndrome. Leuk Res, 34(12):1566–72.

Wang, X. and Naqa, I. M. E. (2008). Prediction of both

conserved and nonconserved microRNA targets in an-

imals. Bioinformatics, 24(3):325–32.

Witten, D. M. and Tibshirani, R. J. (2009). Extensions of

sparse canonical correlation analysis with applications

to genomic data. Stat Appl Genet Mol Biol, 8(1):28.

Zhang, S.-H., Li, Q., et al. (2011). A novel computational

framework for simultaneous integration of multiple

types of genomic data to identify microRNA-gene

regulatory modules. Bioinformatics, 27(13):401–409.

Knowledge-basedSubtractiveIntegrationofmRNAandmiRNAExpressionProfilestoDifferentiateMyelodysplastic

Syndrome
