Snow Side Wall Detection using a Single Camera

Kazunori Onoguchi

and Takahito Sato

Graduate School of Science and Technology, Hirosaki University, 3 Bunkyo-cho, Hirosaki, Japan

Faculty of Science and Technology, Hirosaki University, 3 Bunkyo-cho, Hirosaki, Japan

Keywords:

IPM, Optical Flow, Distance Measurement, Backup Camera, ITS.

Abstract:

In the area where it snows heavily, snow removal of a road cannot often catch up with snowfall. Especially,

a community road becomes too narrow for vehicles to pass each other since snow removal is insufﬁcient

compared with a main street. To obtain this information, this paper presents the novel method to measure the

distance between a vehicle and a snow wall of shoulder by a single camera. Our method creates the inverse

perspective mapping (IPM) image by projecting an input image to the virtual plane which is parallel to the

moving direction of the vehicle and which is perpendicular to the road surface. Then, the distance to the side

wall is calculated from the histogram whose bin is the length of an optical ﬂow detected in the IPM image.

The optical ﬂow of the IPM image is detected by a block matching and the motion of the side wall is obtained

from the peak of the histogram. The narrow way is detected by results measured by several vehicles with a

backup camera.Our method is robust to changes in the appearance of the texture on the side wall that occur

when a vehicle moves along a road.

1 INTRODUCTION

In the northern part of Japan, there are many areas

where it snows heavily. In these areas, snow removal

of a road is important for citizens’ life. If road width

is wide enough, vehicles can pass mutually even if

snow is stacked to the road shoulder. However, there

are many narrow community roads in the local city of

Japan. After snowfall, these roads become too nar-

row for vehicles to pass mutually as shown in Fig.1

and this situation causes a minor collision or trafﬁc

congestion. Since it’s difﬁcult to pass through a nar-

row road, vehicles are gathered in a wide main street.

This causes the further trafﬁc congestion. If the road

information, such as narrowness of the road, is timely

given to drivers, this problem will be improved be-

cause drivers can choose the course for bypassing

these points. However, it’s not easy to know the cur-

rent situation of community roads because most of

them are not equipped with a trafﬁc surveillance cam-

era.

We aim at realizing the system which detects the

place through which the road is too narrow for vehi-

cles to pass mutually owing to the snow stacked to

the shoulder. In order to estimate narrowness of the

road, this system uses the distance between the ve-

hicle and a snow side wall, measured by a lot of ve-

hicles with a backup camera. Since vehicles with a

backup camera for parking support increases recently

in Japan, our method acquires the distance informa-

tion from a backup camera. This system assumes that

the distance information measured by each vehicle is

sent to a base station by a cell phone line with posi-

tion information obtained from GPS. The road point

where many vehicles output short distance is judged

to be narrow. Since the distance information collected

by many vehicles is used for analysis, it does not be-

come a problem even if some vehicles fail to measure

the distance occasionally.

This paper describes the novel method how to

measure the distance between the vehicle and the side

wall by a single camera, especially a backup camera.

Since a backup camera uses a wide-angle lens, image

distortion is severe. Therefore, distance measurement

is difﬁcult for the usual motion stereo. Our method

solves this problem by processing in the inverse per-

spective mapping (IPM) image. At ﬁrst, the IPM im-

age is created by projecting an input image to the vir-

tual plane which is parallel to the moving direction

of the vehicle and which is perpendicular to the road

surface. Then, the distance to the side wall is calcu-

lated from the histogram whose bin is the length of an

optical ﬂow detected in the IPM image. Our method

assumes that a vehicle goes straight along the road in

502

Onoguchi K. and Sato T..

Snow Side Wall Detection using a Single Camera.

DOI: 10.5220/0004759105020509

In Proceedings of the 3rd International Conference on Pattern Recognition Applications and Methods (ICPRAM-2014), pages 502-509

ISBN: 978-989-758-018-5

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

a short time. The moving direction and the moving

distance are estimated from images of a backup cam-

era. The distance to the side wall is calculated only

while a vehicle goes straight. Since corresponding

between features is performed by a block matching

in the IPM image and the motion vector is estimated

from the peak of the histogram, our method is robust

to changes in the appearance of the texture on the side

wall that occurs when a vehicle moves along a road.

The remainder of this paper is organized as fol-

lows. In Sect.2, related works are reviewed brieﬂy.

In Sect.3, the outline of the proposed method is de-

scribed. In Sect.4, the method to calculate the dis-

tance to the side wall is explained in detail. In Sect.5,

experimental results performed to simulation images

and several snow road scenes are discussed. Conclu-

sions are presented in Sect.6.

2 RELATED WORKS

Stereo vision is often used for measuring the dis-

tance to an object with cameras(Dhond and Aggar-

wal, 1989),(Hoff and Ahuja, 1989). Various meth-

ods which can acquire a dense depth map have been

proposed and used for automobile applications, such

as obstacle detection, road boundary detection and

so on(Einecke and Eggert, 2013),(Suhr and Jung,

2013),(M. Michael and Schlipsing, 2013),(C. Guo

and Naito, 2013),(M. Enzweiler and Franke, 2013).

A commercial car with the collision avoidance sys-

tem using a stereo camera has already been pro-

duced(Eyesight, 2013)(K. Saneyoshi and Sogawa,

1993)(Sogawa and Hanawa, 2002). Although stereo

vision is effective in distance measurement with a

camera, it requires higher cost than monocular vision

because it needs calibrated two cameras. Therefore,

there are few vehicles which have been equipped with

stereo cameras.

On the other hand, vehicles with a single camera

for rear view monitor or drive recorder are increas-

ing. Especially, vehicles with a backup camera for

parking support are rapidly increasing in Japan as the

car navigation system spreads widely. For this reason,

we proposes the method which measures the distance

to the snow side wall by a single camera, especially

a backup camera. Although a lot of methods have

been proposed for distance measurement with a sin-

gle camera, motion stereo is generally used in auto-

mobile applications(Huang, 1994)(A. Wedel and Cre-

mers, 2006)(A.J. Davison and Stasse, 2007). Motion

stereo needs to search corresponding points between

two frames taken at different points or it needs to track

feature points between frames. However, an image of

Figure 1: Snow wall of shoulder.

a backup camera has a severe distortion. In addition,

appearance of the texture on the side wall changes a

lot as the vehicle moves forward since the side wall

is parallel to the moving direction of the vehicle. In

addition, a lot of similar texture exist on the snow side

wall. Therefore, it’s difﬁcult to estimate the distance

to the snow side wall stably by conventional methods.

3 OUTLINE OF THE PROPOSED

METHOD

Figure 2 shows the model of the driving environment

which the proposed method assumes. The distance

x between the on-vehicle camera and the side wall

along the road is calculated from the moving distance

of a vehicle and the movement of the side wall in the

IPM image when a vehicle moves forward. The pro-

posed method calculates the distance to the side wall

near a vehicle. Therefore, it is assumed that the side

wall consists of planes perpendicular to a road sur-

face.

Figure 3 shows the procedure of the proposed

method. At ﬁrst, the motion of ego-vehicle is es-

timated from image sequences of a backup camera.

The motion vector is estimated from optical ﬂows de-

tected on a road surface. Our method decides that

an ego-vehicle moves straight when the motion vec-

tor shows the upward direction in a certain period of

time. When a vehicle moves straight, the inverse per-

spective mapping (IPM) image is created and opti-

cal ﬂows are detected in the IPM image by the block

matching. If the wall is close to a vehicle, the move-

ment of the wall in the IPM image is large as shown

in Fig. 4(a) and the magnitude of the optical ﬂow is

also large. If the wall is far from a vehicle, the move-

ment of the wall in the IPM image is small as shown

in Fig. 4(b) and the magnitude of the optical ﬂow is

also small. Then, a histogram whose bin is the mag-

nitude of the optical ﬂow is created. The magnitude

SnowSideWallDetectionusingaSingleCamera

503

(a) Side wall (b) Relation between a

vehicle and a wall

Figure 2: Model of driving environment.

Figure 3: Outline of the proposed method.

with the maximum peak in this histogram is selected

as the movement of the side wall in the IPM image.

Finally, the distance between a vehicle and the side

wall is calculated from this movement and the motion

of an ego-vehicle.

4 ESTIMATION OF VEHICLE’S

MOTION

The motion of an ego-vehicle is estimated from the

optical ﬂow detected on a road plane by the Lucas-

Kanade method(Lucas and Kanade, 2008). Figure

5(a) shows ﬂow vectors detected in an image of a

backup camera. Extremely long ﬂows are deleted as

incorrect ones. Since lens distortion is large in the

far area, the optical ﬂow is detected only on the road

surface near the camera. An image is divided into

square blocks, as shown in 5(b) and an average ﬂow

is calculated in each block. Then, a histogram of ﬂow

(a) Near (b) Far

Figure 4: IPM image.

direction is created by voting the length of each av-

erage ﬂow. A direction in a histogram is quantized

every 10 degrees. Figure 5(c) shows the example of

a histogram. In an image of a backup camera, let the

leftward direction be 0 degree, let the downward di-

rection be 90 degrees, let the rightward direction be

180 degree and let the upward direction be 270 de-

grees. When a vehicle moves straightforward, the

maximum peak of a histogram appears around 270

degrees because a backup camera takes a rear-view.

When the maximum peak of a histogram is observed

around 270 degrees in a certain period of time, our

method decides that an ego-vehicle moves straight-

forward. When an ego-vehicle moves straightfor-

ward, ﬂow vectors in the camera coordinate system

whose direction are around 270 degrees are converted

to the vehicle coordinate system. Conversion param-

eters are determined in advance by the camera cali-

bration. We use a mat on which the square grid pat-

tern is drawn for calibration. This mat is set on the

ground in front of a backup camera. In both the cam-

era coordinate system and the vehicle coordinate sys-

tem, the position of the grid corner is manually mea-

sured and the table corresponding between these co-

ordinate systems is created. The conversion parame-

ter is calculated by solving the perspective projection

matrix using this table. The average length of con-

verted ﬂow vectors is used as the moving distance of

an ego-vehicle.

5 CREATION OF IPM IMAGE

The inverse perspective mapping (IPM) usually con-

verts the coordinate system of the image plane to

the coordinate system of the road surface to create a

bird’s-eye view image which looks down a road from

the sky(Bertozzi and Broggi, 1997). Our method con-

verts an image to the virtual plane which is parallel to

the moving direction of the vehicle and perpendicular

to the road surface. This vertical plane is set between

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

504

(a) Optical ﬂow (b) Square blocks

Figure 5: Optical ﬂow from the backup camera.

(a) Input image (b) IPM image

mapped on the

virtual plane

Figure 6: Example of IPM image.

the side wall and an on-vehicle camera. The homog-

raphy matrix(Onoguchi, 1998) is used for projecting

an input image to the virtual plane. In the IPM im-

age, the region distant form a vehicle has low reso-

lution. However, this problem does not affect subse-

quent processing since the proposed method uses only

the region near a vehicle. Figure 6 shows the example

of the inverse perspective mapping. Figure 6(a) shows

an input image. The rectangular ROI is set in the left

side of an input image for creating the IPM image.

Figure 6(b) shows the IPM image created from the

image of the ROI. The position and the shape of the

ROI is ﬁxed manually when a camera is installed.

6 DISTANCE CALCULATION TO

THE SIDE WALL

We explain the method which calculates the distance

between an on-vehicle camera and the side wall by

using Fig.7.

In Fig.7, a camera mounted on a vehicle moves

∆y from right to left. Let P

denote the focus of a

camera at the right position and let P

denote the focus

of a camera at the left position. At P

, the point k on

the side wall is projected to p

on the image plane

and at P

, k is projected to p

on the image plane.

The point k

) is an intersection of the virtual plane

and the straight line connecting k and p

). Let ∆x

denote the distance between the virtual plane and the

focus of a camera and x denote the distance between

the side wall and the focus of a camera. The angle

(θ

) between the virtual plane and a straight line

connecting k and p

) is given by

tan θ

∆x

b − ∆y

y − ∆y

(1)

tan θ

∆x

, (2)

where a is the distance on the virtual plane from

to k

and b is the distance on the virtual plane from

to k

The distance a and b on the virtual plane are given

a =

∆x. (3)

b = ∆y +

∆x −

∆x∆y

. (4)

Therefore, the difference b − a is given by

b − a = ∆y −

∆x∆y

= ∆y(1 −

∆x

). (5)

Figure 8 shows IPM images obtained by project-

ing the side wall to a virtual plane at the position P

and the position P

. The distance D between corre-

sponding points is given by

sD = a − (b − ∆y) = −(b − a) + ∆y =

∆x∆y

, (6)

where s is the constant magniﬁcation which

changes the distance on an IMP image into the dis-

tance on an virtual plane. In order to estimate s, we

put the calibration board on which the square grid pat-

tern is drawn on the position of the virtual plane. Let

B denote the size of the square grid and let B

IPM

de-

note the size of the square grid in the IPM image. s is

given by

s =

IPM

(7)

Because the moving the distance ∆y of a vehicle is

given by Sec. 4 and the distance ∆x between a camera

and the virtual plane is constant, the distance x to the

side wall is given by

SnowSideWallDetectionusingaSingleCamera

505

Figure 7: Inverse perspective projection to virtual plane.

Figure 8: IPM image at P

and P

x =

∆x∆y

. (8)

7 CORRESPONDING BETWEEN

IPM IMAGES

The distance D between corresponding points are es-

timated by the block matching in IPM images created

at P

and P

. In the IPM image, the texture around

the corresponding point at P

is similar to the tex-

ture around it at P2 because the appearance of tex-

tures on the side wall is not subject to inﬂuence of

the perspective projection. Thus, our method uses the

cross-correlation for searching corresponding points

between IPM images.

Figure 9(b) shows the IPM image of Fig.9(a) and

Fig. 9(c) shows optical ﬂows detected in Fig.9(b).

The optical ﬂow is detected by the block matching.

Since the distance to the side wall is calculated only

when the vehicle moves straightforward, the direction

of the optical ﬂow is almost vertical and the vertical

length is similar in the IPM image. Therefore, the

histogram whose bin is the vertical length of the ﬂow

vector is created to estimate the distance D, as shown

in Fig.9(c). The vertical length of the bin with the

maximum peak is selected as the distance D. The ver-

tical length in the IPM image can be converted to the

actual distance D on the virtual plane because the dis-

tance ∆x between the camera and the virtual plane is

constant. The conversion parameter is beforehand es-

timated by the calibration.

(a) Input image (b) IPM image

Figure 9: Movement of the side wall in the IPM image.

8 EXPERIMENTS

We conducted experiments which estimated the dis-

tance to the side wall in simulation scenes and real

road scenes. An image size is 320× 240 pixels and the

processing time is 30 f ps on PC with Xeon 2.67GHz

CPU.

8.1 Experiments on Simulation Scenes

The accuracy of the distance to the side wall is evalu-

ated by using simulation images. Figure 10 shows im-

ages of snow side walls created by CG software. The

side wall in Fig.10 (a) is parallel to the moving direc-

tion of a vehicle and perpendicular to the road surface.

The side wall in Fig.10 (b) is parallel to the moving

direction of a vehicle but slant to the road surface.

The side walls in Fig.10 (c) and (d) are not parallel to

the moving direction of a vehicle. In Fig.10 (c), the

angle between the side wall and the moving direction

is 15 degree. In Fig.10 (d), the angle between the side

wall and the moving direction is 30 degrees. Figure

11 shows the IPM image obtained from Fig.10. The

distance to the snow side wall is estimated from the

movement between the upper image and the lower im-

age. Figure 12 shows estimation results when the dis-

tance to the side wall is 70cm, 90cm, 110cm, 130cm or

150cm. Figure 12 (a) shows that the proposed method

can estimate the distance to the side wall correctly be-

cause a measurement value is almost equal to a true

value. In Fig.12(b), a true value shows the the dis-

tance to the ground position of the side wall. Since

the side wall leans outside, a measurement value is

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

506

(a) (b) (c) (d)

Figure 10: The result of a simulation scene (Input image).

(a) (b) (c) (d)

(e) (f) (g) (h)

Figure 11: The result of a simulation scene (IPM image).

slightly larger than the true value. In Fig.12(b), the

measurement value of 130cm and 150cm is missing

because most of the side wall is out of the IPM im-

age. Fig.12 (c) shows the result similar to Fig.12 (a).

This result shows the proposed method can estimate

the distance to the side wall even if the moving direc-

tion of a vehicle is shifted about 15 degree with the

side wall.

8.2 Experiments on Real Road Scenes

Experiments were conducted using images taken at a

snowy road by a backup camera and a front camera.

Figures 13 - 18 show results of the backup camera.

In these ﬁgures, the upper image shows the input im-

age and the lower left image shows the IPM image.

The lower right graph shows the distance to the snow

side wall. In this graph, a horizontal axis shows time

(the number of frames) and a vertical axis shows the

distance between a vehicle and the side wall. The

origin is the upper left. The upper horizontal grey

line shows 100cm distance and the lower horizontal

grey line shows 200cm distance. Input images were

captured by the same backup camera. Therefore, the

(a) (b)

Figure 12: The result of a simulation scene (Accuracy of

distance).

shape and the position of a rectangular region for cre-

ating the IPM image were same in Figs.13 - 18. Be-

cause in these scene, the ego-vehicle almost moves

straight along a snow wall at a ﬁxed speed, we es-

timated the distance to the snow side wall from the

cross line between a road and a snow wall, which was

manually extracted in each scene. The relation be-

tween the distance and the lower endpoint of the cross

line was beforehand obtained by the calibration that

was performed in advance.

The snow side walls of Figs.13, 14, 15, 16, 17

and 18 are away from a backup camera about 140cm,

180cm, 180cm, 180cm, 130cm and 130cm respec-

tively. In the lower right graphs of Figs.13 - 18, most

of the measurements show the values near these esti-

mates. These results show that the proposed method

can measure the distance to the side wall stably from

the low resolution image captured by a backup cam-

era.

Since we aim at realizing the system which deter-

mines the road situation by the distance information

collected by a lot of vehicles with a backup camera,

some error which occurred by the individual vehicle

is not a problem. Because the average of measure-

ment error is important, we evaluated it in two scenes

where the ego vehicle moves straight along a snow

wall, while keeping the distance to a snow wall at

100cm and 150cm. As a result of evaluation using the

image of 1, 000 frames, the measurement error was

−1.8cm in 100cm and it was 10.2cm in 150cm. This

result shows that the proposed method is effective in

the system which we are going to realize although the

SnowSideWallDetectionusingaSingleCamera

507

Figure 13: The result of a real road scene 1(Backup cam-

era).

Figure 14: The result of a real road scene 2(Backup cam-

era).

Figure 15: The result of a real road scene 3(Backup cam-

era).

Figure 16: The result of a real road scene 4(Backup cam-

era).

Figure 17: The result of a real road scene 5(Backup cam-

era).

Figure 18: The result of a real road scene 6(Backup cam-

era).

Figure 19: The result of a real road scene 1 (Front camera).

Figure 20: The result of a real road scene 2 (Front camera).

ICPRAM2014-InternationalConferenceonPatternRecognitionApplicationsandMethods

508

accuracy is not better than the conventional method

using a standard lens or a range sensor.

Figures 19 and 20 show results of the front cam-

era. The snow side walls in Figs. 19 and 20 are away

from a front camera about 180cm and 50cm. A vehi-

cle kept the almost same distance from the side wall.

In the lower right graphs of Figs. 19 and 20, most

of measurements are plotted around correct values.

Since the focal length of the front camera is longer

than that of the backup camera, the side wall in the

IPM image of the front camera is clearer than that of

the backup camera. Thus, the distance to the snow

side wall can be estimated more accurately.

9 CONCLUSIONS

This paper presented the method which can measure

the distance between a vehicle and the snow wall of

shoulder by a single camera, especially a backup cam-

era. Our method corresponds features in the IPM im-

age and estimates the motion vector from the peak of

the histogram whose bin is the magnitude of the opti-

cal ﬂow. Therefore, it is robust to the change in the ap-

pearance of the feature on the side wall, which occurs

when a vehicle moves along a road. Experimental re-

sults using simulation scenes and snow road scenes

show the effectiveness of the proposed method.

In the future, we will evaluate the accuracy of the

distance in real road scenes by comparing with the

measured value of a laser sensor and develop the sys-

tem which estimate passing difﬁculty points by inte-

grating the distance information obtained from a lot

of vehicles with GPS data. It is also a future work to

measure the inﬂuence of the error included in moving

distance ∆y.

REFERENCES

A. Wedel, U. Franke, J. K. T. B. and Cremers, D. (2006).

Realtime depth estimation and obstacle detection from

monocular video. Pattern Recognition, Lecture Notes

in Computer Science, 4174:475–484.

A.J. Davison, I.D. Reid, N. D. M. and Stasse, O. (2007).

Monoslm: Real-time single camera slam. IEEE Trans.

on PAMI, 29(6):1052–1067.

Bertozzi, M. and Broggi, A. (1997). Vision-based vehicle

guidance. Computer, 30(7):49–55.

C. Guo, J. Meguro, Y. K. and Naito, T. (2013). Cadas: a

multimodal advanced driver assistance system for nor-

mal urban streets based on road context understand-

ing. Proceedings of IV2013, pages 228–235.

Dhond, U. R. and Aggarwal, J. K. (1989). Structure from

stereo - a review. IEEE Trans. on Systems, Man and

Cybernetics,, 19(6):1489–1510.

Einecke, N. and Eggert, J. (2013). Stereo image warping

for improved depth estimation of road surfaces. Pro-

ceedings of IV2013, pages 189–194.

Eyesight (2013). http://www.subaru.com/engineering/

safety.html.

Hoff, W. and Ahuja, N. (1989). Surfaces from stereo: In-

tegrating feature matching, disparity estimation, and

contour detection. IEEE Trans. on PAMI,, 11(2):121–

136.

Huang, T. S. (1994). Motion and structure from feature

correspondences: a review. Proceedings of the IEEE,

82(2):252–268.

K. Saneyoshi, K. Hanawa, K. K. and Sogawa, Y. (1993).

3-d image recognition system for drive assist. Pro-

ceedings of IV’93, pages 60–65.

Lucas, B. D. and Kanade, T. (2008). An iterative image

registration technique with an application to stereo vi-

sioin. Proceedings of Image Understanding Work-

shop, pages 121–130.

M. Enzweiler, P. Greiner, C. K. and Franke, U. (2013). To-

wards multi-cue urban curb recognition. Proceedings

of IV2013, pages 902–907.

M. Michael, J. Salmen, J. S. and Schlipsing, M. (2013).

Real-time stereo vision: Optimizing semi-global

matching. Proceedings of IV2013, pages 1197–1202.

Onoguchi, K. (1998). Shadow elimination method for mov-

ing object detection. Proceedings of ICPR’98, pages

583–587.

Sogawa, Y. and Hanawa, K. (2002). Sensors for automo-

biles. forward direction recognition system with stereo

vision for automobiles. Journal of the Society of Au-

tomotive Engineers of Japan (Japanese, 56(4):34–39.

Suhr, J. K. and Jung, H. G. (2013). Noise resilient road

surface and free space estimation using dense stereo.

Proceedings of IV2013, pages 461–466.

SnowSideWallDetectionusingaSingleCamera

509
