Vulnerability and Remediation for a High-assurance Web-based

Enterprise

William R. Simpson and Coimbatore Chandersekaran

Institute for Defense Analyses, 4850 Mark Center Dr., Alexandria, Virginia 22311, U.S.A.

Keywords: Threat Mitigation, Vulnerability, Penetration Testing, Flaw Remediation.

Abstract: A process for fielding vulnerability free software in the enterprise is discussed. This process involves testing

for known vulnerabilities, generic penetration testing and threat specific testing coupled with a strong flaw

remediation process. The testing may be done by the software developer or certified testing laboratories.

The goal is to mitigate all known vulnerabilities and exploits, and to be responsive in mitigating new

vulnerabilities and/or exploits as they are discovered. The analyses are reviewed when new or additional

threats are reviewed and prioritized with mitigation through the flaw remediation process, changes to the

operational environment or the addition of additional controls or products). This process is derived from

The Common Criteria for Information Technology Security Evaluation, Common Evaluation Methodology

which covers both discovery and remediation. The process has been modified for the USAF enterprise.

1 INTRODUCTION

The sheer volume of regulations and analyses to

reduce cyberspace threats is astounding US

Department of Defense, 2012a,b, NIST, 2009,

Common Criteria 2009, Wassermann , 2007,

Livshits , 2008, Kiezun, , 2009, Jovanovic,2006,

Huang, 2004, Kals, 2006, Mcallister, 2008, Maggi,

2009, are just a few. Threat mitigation is undertaken

to reduce the attack space and to minimize losses

due to cyber activities either malicious or accidental.

From Hacks to Nation-States, these threats continue

to attempt to penetrate networks every day. These

threats are growing, evolving, and sophisticated.

Loss of information capability and information

integrity as well as the loss of intellectual property is

a significant security risk.

The goal of this paper is to describe a process to

mitigate many known vulnerabilities and to be

responsive in mitigating new or newly discovered

vulnerabilities. Vulnerability identification is a

continuous process whereby threats are reviewed

and prioritized with mitigation through either the

flaw remediation process, modifications to the

operating environment, or the reliance of multiple

products in mutual support of one another. The

analyses are reviewed either periodically or on

demand as new threats evolve or are identified.

2 VULNERABILITY CAUSES

Causes of vulnerabilities are numerous. The

Common Weakness Enumeration (CWE), Mitre

2013b, was developed to track causes of

vulnerabilities as a guide to their elimination.

Vulnerabilities are of concern because they may be

turned into exploits that in turn can be used to

disrupt IT systems or ex-filtrate their assets. Figure 1

shows some of the more common causes amongst

non-website software as derived from Mitre 2013b.

Figure 1: Vulnerabilities in Non-Website Software.

119

R. Simpson W. and Chandersekaran C..

Vulnerability and Remediation for a High-assurance Web-based Enterprise.

DOI: 10.5220/0004760501190128

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 119-128

ISBN: 978-989-758-028-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Figure 2: Vulnerabilities in Middleware.

Figure 2 shows the more common causes of

vulnerability among middleware software elements

as derived from Mitre 2013b.

The identification of vulnerabilities as they relate

to software allows software development practices

and tools to look for structures and processes in

software that may be exploited. Many of these tools

will check for susceptibility to specific exploits also.

Proper software development practices will

eliminate many of these vulnerabilities. Formal

design practices offer additional capabilities to avoid

buffer overflows, improper data acceptance and

other software flaw based vulnerabilities, Jones

2010. Nonetheless tools must be used to verify that

they have been properly done, or remediation must

be applied. These tools are not perfect, and the

analysis may miss some vulnerabilities. There use

should be followed by penetration testing. Even

then, other security measures are needed within the

enterprise. Those additional measures will not be

discussed in this paper. These analyses, however,

will reduce the attack space and eliminate some

common attack methodologies for the enterprise.

3 RELATED WORK

Vulnerability analyses are usually coupled with

software quality assurance and fall into three main

categories:

1. Static code analysis

2. Dynamic analysis or execution tracing

3. Penetration testing

3.1 Static Code Analysis

Static program analysis is the analysis of computer

software that is performed without actually

executing programs. In most cases the analysis is

performed on some version of the source code and in

the other cases some form of the object code. The

term is usually applied to the analysis performed by

an automated tool, with human analysis being called

program understanding, program comprehension or

code review. The sophistication of the analysis

performed by tools is rule-driven which provides the

intellectual property associated with the tool set. A

growing commercial use of static analysis is in the

verification of properties of software used in safety-

critical computer systems and locating potentially

vulnerable code.

These types of analyses are discussed in (Jones,

2010), (Livshits, 2006), and (Wichmann, 1995).

3.2 Dynamic

Code Analysis

Dynamic program analysis is the analysis of

computer software that is performed by executing

programs on a real or virtual processor. For dynamic

program analysis to be effective, the target program

must be executed with sufficient test inputs to

produce interesting behavior. Care must be taken to

minimize the effect that instrumentation has on the

execution (including temporal properties) of the

target program. The sophistication of the analysis

performed by tools is both rule-driven and

instrumentation (debug monitors) which provides

the intellectual property associated with the tool set.

Some dynamic code checker tools are given below:

 HP Security Suite is a suite of Tools at various

stages of development. QAInspect and

WebInspect are generally considered Dynamic

Analysis Tools, while DevInspect is considered

a static code analysis tool, (HP 2013).

 IBM Rational AppScan is a suite of application

security solutions targeted for different stages of

the development lifecycle. The suite includes

two main dynamic analysis products – (IBM

2013).

 Intel Thread Checker is a runtime threading

error analysis tool which can detect potential

data races and deadlocks in multithreaded

Windows or Linux applications, (Intel 2013).

3.3 Penetration Testing

A penetration test is a method of evaluating

computer and network security by simulating an

attack on a computer system or network from

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

120

external and internal threats. The process involves

an active analysis of the system for any potential

vulnerabilities that could result from poor or

improper system configuration. The analyses

include both known and unknown hardware or

software flaws, or operational weaknesses in process

or technical countermeasures. This analysis is

carried out from the position of a potential attacker

using a threat model, and can involve active

exploitation of security vulnerabilities.

(Mosaic, 2013) has captured a number of tools

(including The Penetrator, SAINTexploit™,

Metasploit Pro, Core WebVerify™, CORE

INSIGHT™ Enterprise, CORE IMPACT® Pro,

Core CloudInspect and others) that will perform

such exploitation with pros and cons.

In the analysis of requirements the penetration

testing and both static and dynamic analyses to setup

the penetration testing are required. Further, the

work is only begun with these analyses as the

discovery of vulnerabilities and exploits once the

software is fielded must also be submitted to the

flaw remediation system and resolved as quickly as

possible. To get ahead of this cycle many software

vendors now offer rewards for vulnerability and

exploit discovery (Finifter, 2013).

4 VULNERABILITY ANALYSIS

The vulnerability analysis requirement is levied on

all software procured for the high assurance

environments. This is true for Commercial Off-The-

Shelf Software (COTS) or Government Off-The-

Shelf Software (GOTS), as well as legacy systems to

be ported to the high assurance environment, and

assumes that the developer (either COTS or the

enterprise representative through a custom GOTS

developed contract) will perform these analyses and

provide the flaw remediation (an adaptation of

Common Criteria, 2009).

While formal methods in the development

process and the obtaining of software development

credentilas such as Capability Maturity Model

(CMM), (CMMI, 2013), are valuable, they cannot be

used to replace the vulnerability analyses. In an

adversarial procurement environment, where the

developer either cannot or will not perform these

analyses, the developer must agree to allow the

procuring agency to perform these analyses or hire a

competent laboratory to do the analyses. These

costs, if not included in a competitive bid will be

added to the price for the evaluated product when

evaluating alternative products for procurement.

The level of effort will depend on the product

complexity. Execution of the vulnerability analyses

does not require the execution of a full Common

Criteria evaluation, although any such Common

Criteria evaluation should include these analyses.

The vulnerability analysis described here is based

upon the product in its operational environment as

opposed to the Target of Evaluation described in

(Common Criteria, 2009). The flaw remediation

process cannot be performed by anyone other than

the software developer. It is assumed that license or

purchase of a product will include a support contract

that includes the flaw remediation provisions if these

are not provided with the product.

Within the US, a number of competent

laboratories exist to do these analyses. These

laboratories have tools and testing techniques for

penetration testing, and will provide a level of

assurance on the threat mitigation that will lead to

informed decisions. Many are able to conduct these

analyses at higher security classification levels and

have the capability to sign non-disclosure, non-

complete arrangements with the software

developers. Contracting for these analyses would

include a competitive procurement where the

developer is unable or unwilling to perform such

tasks. In addition, the purchase of such equipment

will be dependent upon successful completion of the

vulnerability analysis. Prior vulnerability analysis

reports may be used to the extent that the operational

environments are similar or modifications to the

prior analysis are completed and executed.

In the US there are seven laboratories that are

licensed under the National Voluntary Laboratory

Accreditation Program (NVLAP) Program, (NIST

2006). NVLAP provides third-party accreditation to

testing and calibration laboratories. NVLAP's

accreditation programs are established in response to

Congressional mandates, administrative actions by

the Federal Government, and requests from private-

sector organizations and government agencies.

NVLAP operates an accreditation system that is

compliant with ISO/IEC 17011, Conformity

assessment — General requirements for

accreditation bodies accrediting conformity

assessment bodies, which requires that the

competence of applicant laboratories be assessed by

the accreditation body against all of the requirements

of ISO/IEC 17025, General requirements for the

competence of testing and calibration laboratories.

Figure 3 shows the basic vulnerability analysis

flow.

VulnerabilityandRemediationforaHigh-assuranceWeb-basedEnterprise

121

Figure 3: Vulnerability Analysis Process.

4.1 Vulnerability Analysis Objective

The objectives of a vulnerability analysis are:

1. To determine whether the product(s), in its

operational environment, has easily identifiable

exploitable vulnerabilities.

2. Identify those vulnerabilities.

3. Begin a remediation process that will close those

vulnerabilities.

4. Excessive vulnerabilities may disqualify the

product for enterprise use.

4.2 Vulnerability Analysis Required

Information

The required information for vulnerability analyses

is:

• The Product(s);

• The guidance documentation

• Identification of all interfaces.

• The Product(s) suitable for testing;

• Harnesses and software instrumentation

necessary for testing the product.

• Information publicly available to support the

identification of potential vulnerabilities.

Information that may be used in these analyses

are listed below:

• Common Vulnerabilities and Exposures

(CVE®) (Mitre, 2013a) is a dictionary of

common names (i.e., CVE Identifiers) for

publicly known information security

vulnerabilities. CVE’s common identifiers

make it easier to share data across separate

network security databases and tools, and

provide a baseline for evaluating the coverage

of an organization’s security tools. If a report

from one of the security tools incorporates

CVE Identifiers, the tool may quickly and

accurately access fix information in one or

more separate CVE-compatible databases to

remediate the problem.

• National Vulnerability Database (NVD) (NIST,

2013) is the U.S. government repository of

standards based vulnerability management data

represented using the Security Content

Automation Protocol (SCAP). This data

enables automation of vulnerability

management, security measurement, and

compliance. NVD includes databases of

security checklists, security related software

flaws, misconfigurations, product names, and

impact metrics.

• Common Weakness Enumeration (CWE™)

(Mitre, 2013b) International in scope and free

for public use, CWE provides a unified,

measurable set of software weaknesses that is

enabling more effective discussion, description,

selection, and use of software security tools

and services that can find these weaknesses in

source code and operational systems as well as

better understanding and management of

software weaknesses related to architecture and

design.

• Others including the Open Web Application

Security Project (OWASP, 2013).

The product developer or evaluator performs

additional tests as a result of potential vulnerabilities

encountered during the conduct of other parts of the

evaluation. The use of the term guidance in this

process refers to the operational guidance and the

preparative guidance. Potential vulnerabilities may

be in information that is publicly available, or not,

and may require skill to exploit, or not. These two

aspects are related, but are distinct. It should not be

assumed that, simply because a potential

vulnerability is identifiable from information that is

publicly available, it can be easily exploited.

4.3 Obtaining Vulnerabilities

The product developer or evaluator examines

sources of information publicly available to identify

potential vulnerabilities in the product. There are

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

122

many sources of publicly available information,

which should be considered, but a minimum set is

listed above as input to the analysis. The product

developer or evaluator should not constrain his

consideration of publicly available information to

the above, but should consider any other relevant

information available.

The product developer or evaluator records in

an evaluation report the identified potential

vulnerabilities that are applicable to the product in

its operational environment. The product developer

or evaluator may use manual methods or source

code scanning and execution tracing tools, or all in

this analysis, but minimal coverage of the above

listed sources of vulnerabilities and weaknesses are

100%. Each of the vulnerabilities identified as

appropriate to the product in its operational

environment, is assigned a category and rationale as

follows:

a. That no further consideration of the potential

vulnerability is required if for example the product

developer or evaluator identifies mitigations in the

operational environment, either IT or non-IT that

prevent exploitation of the potential vulnerability in

that operational environment. This may include

mitigations within the product itself.

b. That for any reasons the potential

vulnerabilities may be excluded from further

consideration if the potential vulnerability is not

applicable in the operational environment.

c. Otherwise the evaluator records the potential

vulnerability for further consideration. This list of

potential vulnerabilities applicable to the product in

its operational environment, which can be used as an

input into penetration testing activities, is reported in

the evaluation report.

4.4 Deriving Penetration Tests

The product developer or evaluator derives

penetration tests that are based on the search above

for potential vulnerabilities, threat modelling

activities, and other analysis methods. The product

developer or evaluator prepares for penetration

testing as necessary to determine the susceptibility

of the product, in its operational environment, to the

potential vulnerabilities identified during the search

of the sources of information publicly available.

The product developer or evaluator produces

penetration test documentation for the tests based on

the list of potential vulnerabilities in sufficient detail

to enable the tests to be repeatable. The test

documentation includes:

a) Identification of the potential vulnerability the

product is being tested for;

b) Instructions to connect and setup all required

test equipment as required for conducting the

penetration test;

c) Instructions to establish all penetration test

prerequisite initial conditions;

d) Instructions to stimulate the product;

e) Instructions for observing the behavior of the

product;

f) Descriptions of all expected results and the

necessary analysis to be performed on the observed

behavior for comparison against expected results;

g) Instructions to conclude the test and establish

the necessary post-test state for the product.

The product developer or evaluator conducts

penetration testing based on the list of potential

vulnerabilities identified above, and prepares an

evaluation report on these tests. Where, as a result

of evaluation, the product developer or evaluator

discovers a potential vulnerability, this is reported in

the evaluation report as a residual vulnerability. The

vulnerability is reported as a flaw in the flaw

remediation system with a priority commensurate

with its potential for exploit and the consequences of

a successful exploit.

4.5 Continuous Updating

The product developer or evaluator re-examines

sources of information publicly available to identify

potential vulnerabilities in the product either

periodically or on demand. The analysis may be on

demand when critical vulnerabilities or damaging

exploits in similar products have been identified,

changes in the operational environment are made, or

other changes requiring further analysis.

4.6 Review and Approve

The enterprise representative examines the results of

the evaluation report of actions above and of all

penetration testing to determine that the product, in

its operational environment, is resistant to an

attacker appropriate to the high assurance

environment. If the results reveal that the product, in

its operational environment, has vulnerabilities

exploitable by an attacker appropriate to the high

assurance environment, then remedial action must be

taken by the product developer. The enterprise

representative ensures that periodic re-evaluation as

provided is above is undertaken.

For critical and trusted software such as the

Secure Token Server (STS) or services within the

Enterprise Attribute Store (EAS), the enterprise

representative may, at his option, conduct or procure

VulnerabilityandRemediationforaHigh-assuranceWeb-basedEnterprise

123

independent penetration testing as described in

section II D above, including repeating some of the

testing described and independently derived tests.

The results of these tests may lead to the

identification of vulnerabilities which are subject to

the flaw remediation processes described below.

5 FLAW REMEDIATION

The flaw remediation process is the responsibility of

the product developer (an adaptation of Common

Criteria, 2009, Evaluation Methodology).

5.1 Flaw Remediation Objectives

The objective of this flaw remediation is to

demonstrate that the product developer has

established procedures that describe the tracking of

security flaws, the identification of corrective

actions, and the distribution of corrective action

information to product users. Additionally, this

process demonstrates that the product developer's

procedures provide for the corrections of security

flaws, for the receipt of flaw reports from product

users, for assurance that the corrections introduce no

new security flaws, for the establishment of a point

of contact for each product user, and for the timely

issue of corrective actions to product users. The

administrative tracking and reporting of flaws may

be outsourced, but the developer must be involved in

the corrective actions and must be included in the

developer’s quality control system.

In order for the developer to be able to act

appropriately upon security flaw reports from

product users, product users need to understand how

to submit security flaw reports to the product

developer, and product developers need to know

how to receive these reports. Flaw remediation

guidance addressed to the product user ensures that

product users are aware of how to communicate with

the developer; flaw remediation procedures describe

the product developer's role is such communication.

The Flaw Remediation process as applied to security

issues is shown in Figure 4.

5.2 Flaw Remediation Required

Information

The required information for evaluation of flaw

remediation processes is:

a) The flaw remediation procedures

documentation;

b) Flaw remediation guidance documentation.

The product developer may use automated flaw

remediation tracking systems such as trouble

ticketing software or may manually track such flaws.

However, it is expected that any flaw not remedied

with 10 working days are referred to the quality

assurance tracking system for formalized assignment

of actions and priorities, and timely reviews to

assure progress in resolution of open items. Security

flaws normally have the highest assigned priority for

remediation in high assurance systems. Remediation

may be code changes and patch update,

configuration changes and recommended changes to

STIGs, or other remedies outside of the product in

the operational environment. The enterprise

representative may reject the last approach

depending on its impact.

Figure 4: Flaw Remediation Process.

5.3 A Flaw Remediation Process

The product developer provides a flaw remediation

process:

a. That describes the procedures used to track

all reported security flaws in each release of the

product. The procedures describe the actions that are

taken by the product developer from the time each

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

124

suspected security flaw is reported to the time that it

is resolved. This includes the flaw's entire time

frame, from initial detection through ascertaining

that the flaw is a security flaw, to resolution of the

security flaw. If a flaw is discovered not to be

security-relevant, there is no need (for the purposes

of the Flaw remediation requirements) for the flaw

remediation procedures to track it further; only that

there be an explanation of why the flaw is not

security-relevant.

b. That describe of the nature and effect of each

security flaw be provided, as well as the status of

finding a correction to that flaw. The procedures

identify the actions that are taken by the product

developer to describe the nature and effects of each

security flaw in sufficient detail to be able to

reproduce it. The description of the nature of a

security flaw addresses whether it is an error in the

documentation, a flaw in the design of the product, a

flaw in the implementation of the product, etc. The

description of the security flaw's effects identifies

the portions of the product that are affected and how

those portions are affected.

c. That when applied these procedures would

identify the status of finding a correction to each

security flaw. The flaw remediation procedures

identify the different stages of security flaws. This

differentiation includes at least: suspected security

flaws that have been reported, suspected security

flaws that have been confirmed to be security flaws,

and security flaws whose solutions have been

implemented. It is permissible that additional stages

(e.g. flaws that have been reported but not yet

investigated, flaws that are under investigation,

security flaws for which a solution has been found

but not yet implemented) be included.

d. That requires corrective actions be identified

for each of the security flaws. Corrective action

may consist of a repair to the hardware, firmware, or

software portions of the product, a modification of

product guidance, or both. Corrective action that

constitutes modifications to product guidance (e.g.

details of procedural measures to be taken to obviate

the security flaw) includes both those measures

serving as only an interim solution (until the repair is

issued) as well as those serving as a permanent

solution (where it is determined that the procedural

measure is the best solution). If the source of the

security flaw is a documentation error, the corrective

action consists of an update of the affected product

guidance. If the corrective action is a procedural

measure, this measure includes an update made to

the affected product guidance to reflect these

corrective procedures.

e. That describes the methods used to provide

flaw information, corrections and guidance on

corrective actions to product users. The necessary

information about each security flaw consists of its

description, the prescribed corrective action, and any

associated guidance on implementing the correction.

Product users may be provided with such

information, correction, and documentation updates

in any of several ways, such as their posting to a

website, their being sent to product users, or

arrangements made for the product developer to

install the correction. In cases where the means of

providing this information requires action to be

initiated by the product user, product guidance must

be adequate to ensure that it contains instructions for

retrieving the information. The only metric for

assessing the adequacy of the method used for

providing the information, corrections and guidance

is that there is a reasonable expectation that product

users can obtain or receive it. For product users who

information is not sufficient. Product developers

must actively send the information (or a notification

of its availability) to registered product users.

f. That describes a means by which the product

developer receives from product user’s reports and

enquiries of suspected security flaws in the product.

The procedures ensure that product users have a

means by which they can communicate with the

product developer. By having a means of contact

with the developer, the user can report security

flaws, enquire about the status of security flaws, or

request corrections to flaws. This means of contact

may be part of a more general contact facility for

reporting non-security related problems.

g. That includes a procedure requiring timely

response and the automatic distribution of security

flaw reports and the associated corrections to

registered users who might be affected by the

security flaw. The issue of timeliness applies to the

issuance of both security flaw reports and the

associated corrections. However, these need not be

issued at the same time. It is recognized that flaw

reports should be generated and issued as soon as an

interim solution is found, even if that solution is as

drastic as turn off the product. Likewise, when a

more permanent (and less drastic) solution is found,

it should be issued without undue delay. It is

unnecessary to restrict the recipients of the reports

and associated corrections to only those product

users who might be affected by the security flaw; it

is permissible that all product users be given such

reports and corrections for all security flaws,

VulnerabilityandRemediationforaHigh-assuranceWeb-basedEnterprise

125

provided such is done in a timely manner.

h. That results in automatic distribution of the

reports and associated corrections to the registered

product users who might be affected. Automatic

distribution does not mean that human interaction

with the distribution method is not permitted. In fact,

the distribution method could consist entirely of

manual procedures, perhaps through a closely

monitored procedure with prescribed escalation

upon the lack of issue of reports or corrections. It is

unnecessary to restrict the recipients of the reports

and associated corrections to only those product

users who might be affected by the security flaw; it

is permissible that all product users be given such

reports and corrections for all security flaws,

provided such is done automatically.

5.4 Flaw Remediation Quality System

The product developer provides reporting processes:

a. That ensures reported security flaws are

remediated and the remediation procedures issued to

product users. The flaw remediation procedures

cover not only those security flaws discovered and

reported by developer personnel, but also those

reported by product users. The procedures are

sufficiently detailed so that they describe how it is

ensured that each reported security flaw is

remediated. The procedures contain reasonable steps

that show progress leading to the eventual,

inevitable resolution. The procedures describe the

process that is taken from the point at which the

suspected security flaw is determined to be a

security flaw to the point at which it is resolved.

b. That ensures that the product users are issued

remediation procedures for each security flaw. The

procedures describe the process that is taken from

the point at which a security flaw is resolved to the

point at which the remediation procedures are

provided. The procedures for delivering remediation

procedures should be consistent with the security

objectives.

c. That provides safeguards that any corrections

to these security flaws do not introduce any new

flaws. Through analysis, testing, or a combination of

the two, the developer may reduce the likelihood

that adverse effects are introduced when a security

flaw is corrected.

5.5 Flaw Remediation Reporting

The product developer provides remediation

guidance:

a. That describes a means by which product

users report to the developer any suspected security

flaws in the product. The guidance ensures that

product users have a means by which they can

communicate with the product developer. By having

a means of contact with the developer, the user can

report security flaws, enquire about the status of

security flaws, or request corrections to flaws.

b. That describes a means by which product

users may register with the developer, to be eligible

to receive security flaw reports and corrections.

Enabling the product users to register with the

developer simply means having a way for each

product user to provide the developer with a point of

contact; this point of contact is to be used to provide

the product user with information related to security

flaws that might affect that product user, along with

any corrections to the security flaw. Registering the

product user may be accomplished as part of the

standard procedures that product users undergo to

identify themselves to the developer, for the

purposes of registering a software license, or for

obtaining update and other useful information.

There need not be one registered product user per

installation of the product; it would be sufficient if

there were one registered product user for an

organization. It should be noted that product users

need not register; they must only be provided with a

means of doing so. However, users who choose to

notification of its availability).

5.6 Review and Approve

The enterprise representative examines the results of

the above actions to determine that the product, in its

operational environment, has sufficient flaw

remediation. If the results reveal that the product, in

its operational environment, has insufficient flaw

remediation, then remedial action must be taken by

the product developer or the product may be

replaced.

6 SUMMARY

This paper has provided a set of processes by which

the enterprise can field relatively vulnerability-free

software, at least to the extent of known

vulnerabilities and exploits. New exploits are

subject to temporary solution and become part of the

flaw remediation system where they are reported and

monitored until a satisfactory solution is achieved.

It is not anticipated that the enterprise will be 100%

exploit free from this process alone. Additional

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

126

measures, including firewalls, ports and protocols

restrictions, and some communication scanning may

be required. This process should, however, reduce

the attack space significantly. The implementation

(scheduled for summer 2014) will have to be

monitored and evaluated as it proceeds. This

includes the tracking of exploits, the response of the

software remediation system, and the degree to

which the vulnerability was knowable before the

exploit as well as newly discovered vulnerabilities.

It is expected that these analyses listed in this paper

will need refinement based upon that feedback.

Portions of this architecture are described in

(Simpson, 2011, 2012a, b).

REFERENCES

Common Criteria for Information Technology Security

Evaluation, 2009 (all version 3.1, revision 3):

a) Part 1: Introduction and general model.

b) Part 2: Functional security components.

c) Part 3: Assurance security components.

d) Common Methodology for Information

Technology Security Evaluation.

CMMI Institute, 2013, Standard CMMI Appraisal Method

for Process Improvement (SCAMPI) Version 1.3a:

Method Definition Document for SCAMPI A, B, and

C, http://cmmiinstitute.com/resource/standard-cmmi-

appraisal-method-process-improvement-scampi-b-c-

version-1-3a-method-definition-document/

Department of Defense, 2012a, Committee on National

Security Systems Instruction (CNSSI) No. 1253,

“Security Categorization and Control Selection for

National Security Systems’ categories for Moderate or

High Risk Impact as delineated in NIST 800-53.

Department of Defense, 2012b, DoD Directive (DoDD)

O-8530.1, Computer Network Defense (CND).

Finifter, Matthew, et. al., “An Empirical Study of

Vulnerability Rewards Programs”, USENIX Security

2013, August 15, 2013.

HP Security Tools, 2013, http://h20331.www2.hp.com/

hpsub/cache/281822-0-0-225-121.html?jumpid=ex_

2845_vanitysecur/productssecurity/ka011106

Huang, Y.-W., et. al., 2004, “Securing web application

code by static analysis and runtime protection,” in

WWW ’04: Proceedings of the 13th international

conference on World Wide Web. New York, NY,

USA: ACM, , pp. 40–52.

IBM Rational, 2013, http://www.03.ibm.com

/software/products /us/en/appscan

Intel Compilers, 2013, http://software.intel.com/en-

us/intel-compilers/

Kiezun, A., et. al., 2009, “Automatic creation of SQL

injection and cross-site scripting attacks,” in ICSE’09,

Proceedings of the 30th International Conference on

Software Engineering, Vancouver, BC, Canada, May

20–22.

Jones, Paul, 2010, "A Formal Methods-based verification

approach to medical device software analysis".

Embedded Systems Design., http://www.embedded.

com/design/prototyping-and-development/4008888/

A-Formal-Methods-based-verification-appro ach-to-

medical-device-software-analysis

Jovanovic, N., et. al., 2006, “Pixy: A static analysis tool

for detecting web application vulnerabilities (short

paper),” in 2006 IEEE Symposium on Security and

Privacy, pp. 258–263, [Online]. Available: http://

www.iseclab.org/papers/pixy.pdf

Kals, S., et. al., 2006, “Secubat: a web vulnerability

scanner,” in WWW ’06: Proc. 15th Int’l Conf. World

Wide Web, pp. 247–256.

Livshits, Benjamin, 2006, Improving Software Security

with Precise Static and Runtime Analysis, , section 7.3

"Static Techniques for Security," Stanford doc. thesis.

Livshits B., et. al., 2008, “Securing web applications with

static and dynamic information flow tracking,” in

PEPM ’08: Proceedings of the 2008 ACM SIGPLAN

symposium on Partial evaluation and semantics based

program manipulation. New York, NY, USA: ACM,

pp. 3–12.

Maggi, F., 2009, “Protecting a moving target: Addressing

web application concept drift,” in RAID, pp. 21–40.

Mitre, 2013a, Common Vulnerability and Exposures,

http://cve.mitre.org/

Mitre, 2013b, Common Weakness Enumeration,

http://cwe.mitre.org/

Mcallister, S., et. al., 2008, “Leveraging user interactions

for in-depth testing of web applications,” in RAID ’08:

Proc. 11th Int’l Symp. Recent Advances in Intrusion

Detection, pp. 191–210.

Mosaic, 2013, http://mosaicsecurity.com/categories/27-

network-penetration-testing

NIST, 2006, National Voluntary Laboratory Accreditation

Program, http://www.nist.gov/nvlap/upload/nist-

handbook-150.pdf

NIST, 2009, National Institute of Standards, Gaithersburg,

Md: FIPS PUB 800-53, Recommended Security

Controls for Federal Information Systems and

Organizations, Revision 3, August 2009.

NIST, 2013, National Vulnerability Database,

http://nvd.nist.gov/

Simpson, William R, et.al.., 2011, Lecture Notes in

Engineering and Computer Science, Proceedings

World Congress on Engineering and Computer

Science, Volume I, “High Assurance Challenges for

Cloud Computing”, pp. 61-66, Berkeley, CA.

Simpson, William R, and Chandersekaran, C.., 2012a,

Lecture Notes in Engineering and Computer Science,

Proceedings World Congress on Engineering, The

2012 International Conference of Information Security

and Internet Engineering, Volume I, “Claims-Based

Enterprise-Wide Access Control”, pp. 524-529,

London,.

Simpson, William R, and Chandersekaran, C.., 2012b,

International Journal of Scientific Computing, Vol. 6,

No. 2, “A Uniform Claims-Based Access Control for

the Enterprise”, ISSN: 0973-578X, pp. 1-23.

VulnerabilityandRemediationforaHigh-assuranceWeb-basedEnterprise

127

The Open Web Application Security Project (OWASP),

2013, https://www.owasp.org/index.php/Main_Page

Wassermann G. and Z. Su, 2007, “Sound and precise

analysis of Web Applications for Injection

Vulnerabilities,” SIGPLAN Not., vol.42, no.6, pp.32–41.

Wichmann, B. A., et. al. 1995, Industrial Perspective on

Static Analysis. Software Engineering Journal, 69-75.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

128
