Mastery Profiling Through Entity Linking

To Support Project Team Formation in Higher Education

Alexander M. Olieman and Frank Nack

Informatics Institute, University of Amsterdam, Science Park 904, Amsterdam, Netherlands

Keywords: Collaborative Learning, Computer-Supported Group Formation, Information Extraction, Entity Linking,

Mastery Profiling, Graph Exploration, DBpedia Spotlight, Gremlin.

Abstract: Computer-supported group formation enables educators to assign students to project teams. The focus in

this paper is placed on gathering data about student attributes that are relevant in the context of specific

course projects. We developed a method that automatically produces learner models from existing docu-

ments, by linking students to topics and estimating the levels of skill, knowledge, and interest that students

have in these topics. The method is evaluated in an experiment with student participants, wherein its per-

formance is measured on two levels. Our results demonstrate that it is possible to link students to topics with

high precision, but suggest that estimating mastery levels is a more challenging task.

1 INTRODUCTION

Group-based learning has taken an important role in

curricula across the educational spectrum. One as-

pect of group-based learning that has attracted con-

siderable attention from researchers, is the formation

of groups of learners. Group formation influences

the interactions that group members have, and there-

by affects the results of the learning experience

(Kyprianidou et al., 2011). Poorly formed groups

may suffer from, for example, an unproductive use

of time or incompatible personality types. The way

students are partitioned into groups also raises the

question if they can be assessed fairly, e.g. due to an

unbalanced spread of skills (Livingstone and Lynch

2000).

In higher education, common group forming

methods are student self-selection and random as-

signment. These methods do not necessarily lead to

good learning experiences, but are often the only

practical alternatives for instructors who teach large

numbers of new students each year. Instructors

might lack the necessary information about the stu-

dents to implement a more elaborate group for-

mation process, or face the impracticality of manual-

ly solving a large combinatorial problem (Craig et

al., 2010). This has motivated research towards the

development of tools that can aid instructors in

forming groups, which is known as Computer-

Supported Group Formation (CSGF) (Ounnas et al.

2009).

Regardless of the algorithms that are used, the

criteria that can be used in the group formation pro-

cess are limited by the data that is used to describe

the students. Hence much of the previous work

makes use of student attributes for which standard-

ized tests are available, such as team roles, personal-

ity types, and learning styles (Magnisalis et al.,

2011). Important disadvantages of gathering student

data in this way are the dependence on lengthy ques-

tionnaires, and the need to ask students new ques-

tions when course-specific characteristics are taken

into account.

In computer-supported collaborative learning set-

tings where the majority of learning occurs in a

virtual environment, there are opportunities to gather

relevant data about students continuously. In more

traditional settings, it may instead be viable to use

data from existing resources that describe students,

specifically to model students’ mastery of topics.

Previous suggestions are to use text mining tech-

niques on curricula vitae (CVs), academic tran-

scripts, and personal websites (Ounnas et al., 2009).

The objective of this study is to develop and

evaluate a method which allows existing data

sources that describe students’ mastery levels (e.g.

of knowledge, skills, and interests) to be automati-

cally combined into a learner profile for use in

CSGF algorithms. The scope of group formation

182

M. Olieman A. and Nack F..

Mastery Proﬁling Through Entity Linking - To Support Project Team Formation in Higher Education.

DOI: 10.5220/0004764001820190

In Proceedings of the 6th International Conference on Computer Supported Education (CSEDU-2014), pages 182-190

ISBN: 978-989-758-020-8

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

problems that need to be addressed by this method is

restricted to the domain of team project-based higher

education. To work towards this objective, the main

research question that this paper addresses is formu-

lated as follows:

Can existing data sources that describe stu-

dents’ mastery of topics be fused into a learner

profile, to facilitate computer-supported group

formation?

The remainder of this paper is structured as fol-

lows. In Section 2 we discuss related work. Section

3 serves to briefly describe a further exploration of

the problem domain. In Section 4 we discuss gather-

ing existing resources from student participants.

Based on these resources we produce learner pro-

files, using a method that is described in Section 5.

In Section 6 we discuss our evaluation approach and

results, followed by the conclusion and future work.

2 RELATED WORK

2.1 Computer-supported Group

Formation

CSGF is based on the idea that instructors can assign

students to groups by making explicit educational

criteria according to which groups should be formed

(Craig et al., 2010). The essence of CSGF is: the

synthesis of groups by applying criteria that opti-

mize aspects of each group, by making use of data

about the individual learners (Magnisalis et al.,

2011).

A classification, originating from literature on

team diversity, divides relevant attributes into task-

related (e.g. knowledge, skills, experience) and

relations oriented (e.g. gender, culture, attitude,

social ties) (Jackson et al., 1995). Task-related at-

tributes of individual students are relevant because

they indicate which cognitive resources will be

available in any possible grouping. Relations orient-

ed attributes indicate how group members are ex-

pected to interact. A common approach to recording

task-related attributes is to ask students for their

grades in selected prerequisite courses (Lingard and

Berry, 2002). Another approach is to measure skill

levels for a few domain-specific skills by question-

naire (Winter, 2004).

Most of the criteria according to which groups

should be formed can be classified as homogeneous,

heterogeneous, or apportioned (Craig et al., 2010).

Both homogeneous and heterogeneous criteria are

concerned with the distance between students within

a group for a specific attribute, while apportioned

criteria serve to distribute a specific attribute as

evenly as possible across the groups.

Hoogendoorn (2013) has recently conducted

three field experiments which provide evidence for

the effect of heterogeneity on the performance of

student teams. His results suggest that gender di-

verse teams perform significantly better than male-

dominated teams, and no worse than female-

dominated terms. The effect of ethnic diversity on

team performance is found to be positive for teams

where at least half of the members have different

backgrounds. Diversity in cognitive ability of team

members only shows a positive effect on perfor-

mance when the degree of heterogeneity is moder-

ate. Heterogeneity of cognitive resources is suggest-

ed as an underlying mechanism for the effect of

diversity in ethnicity and cognitive ability.

Other researchers argue for certain criteria with-

out empirical support (e.g. based on expert opinion).

Most arguments are made for heterogeneous criteria

(i.e. complementary fit) on specific attributes, in-

cluding skills, knowledge, abilities (Wells, 2002;

Werbel and Johnson 2001; Wilkinson and Fung

2002), and learning styles (Magnisalis et al., 2011).

Student interests and values should however be

grouped homogeneously (Werbel and Johnson,

2001). Grades in prerequisite courses are most often

apportioned (Craig et al., 2010; Ounnas, 2010).

2.2 Entity Linking

Entity linking (EL) is the information extraction task

of automatically “matching a textual entity mention

[...] to a [knowledge base] entry, such as a Wikipe-

dia page that is a canonical entry for that entity.”

(Rao et al., 2013, p. 96). Three key challenges have

been identified for EL to deal with: name variation,

entity ambiguity, and absence (Dai et al., 2012; Rao

et al., 2013). Name variation entails that an entity

can be referred to by multiple different terms. Entity

ambiguity refers to the issue that a single name

string can match with several distinct entities. The

issue with absence is that when no knowledge base

(KB) entry exists for the entity that is mentioned in

the text, no entity should be returned, rather than the

highest-ranking KB entry.

There are, however, two relevant limitations pre-

sent in the existing work on EL. Most research fo-

cuses explicitly on linking named entities (i.e. enti-

ties referred to by proper names), specifically on

persons, locations, and organizations (Mendes, Dai-

ber, et al., 2011; Rao et al., 2013). Additionally,

many current approaches are evaluated only on Eng-

lish-language texts, with a focus on the news domain

MasteryProfilingThroughEntityLinking-ToSupportProjectTeamFormationinHigherEducation

183

(Mendes et al. 2011; Rao et al., 2013).

DBpedia Spotlight is an open-source system that

can annotate any given input text with DBpedia

resources (i.e. KB entries), which are based on se-

mantic extraction from Wikipedia articles (Mendes,

Jakob, et al., 2011). Several parameters provide the

means to filter annotations according to task-specific

requirements. By default, DBpedia Spotlight is not

specialized towards specific entity types, but it may

be configured to annotate only instances of specific

types, either by selection of classes, or by arbitrary

SPARQL

queries (Mendes et al., 2011).

When linking targets are known to have a specif-

ic type, e.g. genes (in the biomedical domain), anno-

tating only those entities is quite straightforward

(Dai et al., 2012). If a domain-specific vocabulary

already contains links to DBpedia or Wikipedia then

one can consider all DBpedia Spotlight candidate

entities, and then check whether the top-ranked

candidate has a corresponding entity in the local

vocabulary (Mendes et al., 2011).

Multiple EL researchers have found it helpful to

include a measure of semantic-relatedness between

entities in the disambiguation process (e.g. Han et

al., 2011). The intuition behind collective entity

disambiguation is that the links between, e.g., Wik-

ipedia articles reflect how closely the corresponding

entities are related, and that texts are more likely to

mention several related entities than entirely unrelat-

ed entities.

Besides using metrics of semantic-relatedness

and disambiguation purposes, it might be feasible to

use them to find additional topics in which a student

has some mastery. For instance, when a student's CV

mentions that she is skilled in technical drawing, we

can infer that she has some skill in drawing in gen-

eral.

3 VIEWS ON FORMING TEAMS

In the group formation literature arguments are made

for the relevance of skills, knowledge, abilities,

interest, and grades. All arguments are, however,

made from the educator's perspective, and infor-

mation about the student's perspective is lacking. We

have therefore surveyed a group of university stu-

dents and asked them about the considerations they

have had while forming project teams in the past.

As in other group formation studies, we recruited

participants from a subpopulation of students who

study the same subject (Lingard and Berry, 2002;

SPARQL 1.1 - <http://www.w3.org/TR/sparql11-overview/>

Winter, 2004). All participants were enrolled in the

MSc program Design for Interaction at the Delft

University of Technology (DUT), and were recruited

through a mailing list. The same sample of students

were respondents to the questionnaire as well as

participants in the experiment that is described in

subsequent sections.

The questionnaire was taken by 11 students. We

focused our questions on seven attributes: compe-

tence, education, experience, general ability, inter-

est, knowledge, and skill.

The results of the questionnaire broadly corre-

spond to what was found in the CSGF literature. On

this basis, we decide to include skill and knowledge

in our learner profiles. We also include interest in

our profiles because it is used in team formation

criteria by many instructors (Werbel and Johnson

2001; Kyprianidou et al., 2011). Competence, we

argue, is not a suitable choice because it depends on

specific skills and knowledge.

4 GATHERING EXISTING

RESOURCES

After finishing the initial questionnaire, students

were asked to participate in creating a learner profile

based on existing documents about them. To partici-

pate, they needed to provide access to a project port-

folio, an academic transcript, and temporary access

to their LinkedIn

profile, and/or provide the URL to

a personal website. The terms that indicate relevant

attributes need to be recognized in these resources,

and should be linked to a shared vocabulary in

which the learner profiles can be expressed. The

quality of the resulting profiles is evaluated by com-

paring them with a ground truth that is given by the

participants.

The decision to gather academic transcripts,

CVs, and personal websites was motivated by sug-

gestions found in literature (Ounnas et al., 2009).

Although documents in a project portfolio do not

describe students in the same sense as the other

document types do, they can give a more detailed

view of the specific topics a student has engaged

with during previous projects (at least for a human

reader).

Participants’ academic transcripts and LinkedIn

profiles were saved by a sign-up application. The

course descriptions that correspond to the course

identifiers in the academic transcripts were retrieved

LinkedIn - <http://www.linkedin.com/>

CSEDU2014-6thInternationalConferenceonComputerSupportedEducation

184

through the DUT API

. The project portfolios con-

sist of deliverables, such as reports, presentation

slides, and project blogs. The corresponding files

were provided by Shareworks Solutions BV. For the

two participants who provided a website, we saved

the pages manually.

In total, 10 LinkedIn profiles (all English), 190

course descriptions (66 Dutch, 124 English), 54

portfolio documents (2 Dutch, 52 English), and two

websites (both English) were gathered. Participants

were associated with between 15 and 57 documents;

on average with 37 documents. Most course descrip-

tions and some portfolio documents were associated

with more than one participant.

5 PRODUCING LEARNER

PROFILES

Two existing implementations of DBpedia Spotlight

are used to produce annotations that we define as

"links between a phrase in a document and a topic,

which is represented by a DBpedia URI". Subse-

quently, we estimate skill, knowledge, and interest

levels by taking into account surrounding terms of

each annotation, document origins, and annotation

frequencies. The learner profiles that are produced

by this method consist of statements, where a state-

ment is "the relation between a student and a single

topic, which is quantified by three mastery levels.

Finally, the set of statements in each profile is ex-

panded by inference over probabilistic and semantic

relations between topics.

5.1 Vocabulary Selection

and Modification

CSGF differs from the current applications of entity

linking: when links are generated for the readers of

an article, it is assumed that the readers are familiar

with the majority of abstract concepts that are men-

tioned. For CSGF, abstract concepts are mostly

relevant, and people and places less so. To annotate

documents only with topics that are relevant for

CSGF, we test the approach taken in Mendes, Dai-

ber, et al. (2011) and in Wetz et al. (2012), for which

we require an application-relevant subset of DBpe-

dia entities.

We use the LinkedIn "Skills & Expertise" vo-

cabulary

LI as a basis. Reasons to choose this

vocabulary are that it is already partially linked to

Delft University of Technology API - <http://apidoc.tudelft.nl/>

LinkedIn Skills & Expertise - <http://www.linkedin.com/skills/>

Wikipedia, and that it is used daily by thousands of

people to describe their professional abilities. From



LI, we define our vocabulary LI∩.

There are 26 292 topics  in ; nearly 70% of ∈



LI, but only 0.7% of all DBpedia resources. The

links between 

LI and Wikipedia contain inaccura-

cies. We have manually corrected 40 of such links,

but we estimate that at least 10% of ∈

LI are

needlessly missing a link, or are linked to an incor-

rect Wikipedia article.



LI only links topics with English Wikipedia ar-

ticles, and as such  would only include English

identifiers for topics. Since our profiling method

also needs to deal with documents in other lan-

guages, we incorporate alternative topic identifiers

into  by using Wikipedia's interlanguage links

For each ∈ the Dutch identifier  (if available)

is retrieved from the nl.dbpedia.org SPARQL end-

point through the query:

SELECT ? WHERE {? owl:sameAs

<http://dbpedia.org/resource/> .}

There are topics that are mentioned frequently in

all types of the gathered resources, but that are not

relevant for learner profiles. We exclude 56 of such

topics in total from .

5.2 Information Extraction Pipeline

The information extraction process that we employ

lends itself to being described as a data transfor-

mation pipeline.

For each gathered document  ∈ , a

DBpedia Spotlight implementation, given a configu-

ration, annotates the content per section. The re-

sources that are returned are filtered with our vocab-

ulary.

In each section we count qualifying terms, which

indicate specific types of mastery, and linearly com-

bine the normalized counts with

, ,  weights that depend

on the document origin . The resulting ,,

score is assigned to each annotation within the sec-

tion, after which the scores are summed per topic for

the entire document. The summed scores are stored

in the document (



) as indications of mastery,

where one  



,,,



.

Hereafter, we select for each profile  ∈

 the 



that are associated with  by a

document link   , . The indications in the

associated documents are summed per , , result-

ing in 1. .



mastery levels scores, where one

See: <http://en.wikipedia.org/wiki/Help:Interlanguage_links>

MasteryProfilingThroughEntityLinking-ToSupportProjectTeamFormationinHigherEducation

185

 ,,, for each unique topic that is associ-

ated with . The indications that originate from

course descriptions are, before summation, weighted

by the grade that the student received for the corre-

sponding course.

The maximum , , and  scores of the summed

indications differ significantly between origins. For

each origin, the scores are linearly transformed to

the range 0, 100 , because we wish to compare the

accuracy of statements from different origins in our

evaluation. The resulting normalized indications

represent the relative mastery levels per topic for a

single student, i.e., they encode beliefs that the stu-

dent has more mastery in one topic than in another.

For CSGF the aim is to compare the mastery lev-

els per topic between students. A final data trans-

formation is thus needed. Each normalized 

,

transformed to its percentile rank (PR) 

,

in the

frequency distribution of the  with the same

,  from all profiles. Finally, statements are saved

as 

,

,.

5.3 Linking Documents to Topics

The first step in our approach to mastery level profil-

ing is to ask for each student: in which topics does

this student have any skill, knowledge, and/or inter-

est? We use entity linking to answer this question

based on the gathered documents, in lieu of more

tailored information extraction techniques. This

enables us to test the hypothesis that:

“From all entities that are mentioned in the doc-

uments associated with a student, a vocabulary can

be used to select the entities that are topics in which

this student has some mastery”.

5.3.1 Annotation Method

Two DBpedia Spotlight implementations (Mendes,

Jakob, et al. 2011; Daiber et al. 2013) are used and

configured to produce annotations in our experi-

ment. The original Information Retrieval-based

implementation, with the default configuration, spots

all phrases in the input text that also occur in a da-

taset of possible surface forms for all DBpedia. It

selects candidate entities for each spotted phrase,

and ranks them according to the prior probability

that the observed phrase refers to the selected candi-

date. The candidates are then re-ranked by querying

a Vector Space Model (VSM), in which entities are

represented by the paragraphs that mention them in

Wikipedia, with the context of the observed. Top-

ranking candidates are the most likely disambigua-

tions.

The newer statistical model uses a generative

probabilistic model for disambiguation. This model

is used to calculate a disambiguation score for entity

, given the spotted phrase  and its context , by

combining 







, 









, and . The original phrase

spotting method is used in parallel with a Natural

Language Processing (NLP) method that is not lim-

ited to surface forms that occur in DBpedia. Any

overlap in spotted phrases is resolved, after which

the phrases that fall below a score threshold  are

dropped from the annotation process.

In both implementations the topical pertinence of

a candidate for the observed context is indicated by

the disambiguation score. The relative difference in

this score between the first and second ranking can-

didate indicates contextual ambiguity, i.e. how un-

certain it is that the top-ranked candidate is the entity

that is mentioned in this context. The confidence

parameter, which is provided at runtime, applies a

threshold of 1   to candidates' con-

textual ambiguity scores. A second runtime parame-

ter, support, specifies the minimum number of Wik-

ipedia inlinks a candidate resource must have to be

further considered.

We define a third runtime parameter which

chooses between single and multiple candidate fil-

tering. In single candidate filtering, we take the set

of top-ranking entities 



that Spotlight produces for

a section and select as topics the entities that occur

in our vocabulary (







∩). In multiple candi-

date filtering we instead initialize 



, take

the set of ranked candidate vectors 



̅



,̅



,…,,

and from each vector we add the top-ranking topic to





(denoted 



∪



, where 



:



∈





:



in̅and ∈ ).

5.3.2 Exploration of the Parameter Space

To assess the suitability of various configurations for

producing learner models (before the ground truth is

given by the participants), we have manually anno-

tated a small test collection of documents, and have

measured the performance of our annotation method

on this collection.

We use the measures precision, recall, and F-

score (F

) to evaluate the performance of the annota-

tion method. The definitions of these measures are

adapted from the prevailing definitions in entity

linking (Han et al. 2011) to better suit our annotation

task. Let  be the person who is profiled in ,

with the set of associated documents







:, 



. 



is the set of all topics

with which







:, 



has been annotated.





is the set of all topics in which 

CSEDU2014-6thInternationalConferenceonComputerSupportedEducation

186

claims to have some mastery.

  

|



∩



|



(1)

 

|



∩



|



(2)





1





  





   

(3)

In this work 0.5, which reflects our assumption

that recall is only half as important as precision for

this annotation task.

For the test documents we have had to use





and have created 



. In 



we have only included the topics for which  im-

plied some mastery on the part of any student asso-

ciated with .

To find which configurations perform best for

our annotation task, we have performed a parameter

sweep on 3 Dutch and 8 English test documents.

Because we were not able to assign a value to the

threshold , we have instead manipulated a spot

score weight which, when enlarged, increases the

probability that spotted terms are annotated.

With both languages, a clear tradeoff between

precision and recall can be observed. Multiple can-

didate filtering, as expected, results in higher recall,

but lower precision, than single candidate filtering.

Increasing the confidence value causes higher preci-

sion, but lower recall. We found the effect of the

support parameter to be negligible.

Based on these results, we continue our main ex-

periment with the IR-based implementation and

  0.3 for English documents, and the

statistical implementation with a spot score weight

of 0.4 and   0.2 for Dutch documents.

For both languages we use single candidate filtering

and   0.

5.4 Estimating Mastery Levels

To estimate which type(s) of mastery a student has

in a topic, we have selected the descriptions of the

25 most attended courses, and recorded all terms that

imply skill or knowledge (i.e. qualifying terms).

We represent the qualifying terms as sets, and

count for every section that contains annotations

how many terms indicate skill and knowledge.

Stemming is used to also count lexical variations of

the terms. Predefined weights per document origin

are linearly combined with the fractions of skill and

knowledge term counts, to produce a ,, score

per annotation in a section. In the defined weights,

we assume that portfolio documents and websites

indicate each type of mastery, but that course de-

scriptions do not indicate any interest.

In our definition of mastery levels we need to

take into account that the ground truth that we will

use in our evaluation is provided by the participants.

The scale and unit in which mastery levels are ex-

pressed need to be understood by students to allow

them to accurately correct their profiles (Bull and

Kay 2007). In our model a mastery level means that

a student has more knowledge, skill, or interest in a

topic than a percentage of his or her peers. "Paul

(Knowledge, 75) Archery", for example, would

indicate that Paul has more knowledge about archery

than 75% of his peers.

To estimate mastery levels, we use the intuition

that a student will have more mastery in topics that

are mentioned more often in the associated docu-

ments. For the topics that originate from course

descriptions we also incorporate the grade that a

student received and the extent of the course. Each

indication of mastery that originates from a course

description is multiplied by a weight 

,

, which is

calculated as:



,



0.5  2  _





11  

,

(4)

All indications in the associated documents for a

single student are subsequently summed per , .

Hereafter, the indications are normalized per origin,

but across profiles, to the range 0, 100, so that for

each ,  there exist maximum , , and  scores

with the value 100. This enables us to generate indi-

cations for a fifth origin ALL, in which we have

compensated for differences in annotation frequency

and weighting between topics and origins. The indi-

cations for ALL are generated by summing the exist-

ing indications per profile.

Finally, indications are transformed into state-

ments with the desired semantics by using the fre-

quency distributions of , , and  scores, again per

, , over all profiles. Each score is transformed

into a mastery level by calculating its percentile rank

in the corresponding frequency distribution. But

because mastery levels are defined relative to a stu-

dent's peers, we would need frequency distributions

that include all peers.

To compensate for the limited number of partici-

pants, we apply a form of additive smoothing in the

calculation of percentile ranks. Into each frequency

distribution 

,

we insert the values 0.0, 1.5 



,

, and |

,

|1 evenly spaced values

in between. The percentile ranks of individual indi-

cations are computed from these modified frequency

MasteryProfilingThroughEntityLinking-ToSupportProjectTeamFormationinHigherEducation

187

distributions.

5.5 Expanding Profiles by Inference

Because our vocabulary is not a KB, in the sense

that it contains no information about relationships

between topics, we use DBpedia as a source for

semantic relations between topics. We aim to predict

for each student, on the basis of the topics that are

linked from their profile, in which other topics they

are likely to have some mastery.

We use Gremlin

, which implements efficient

graph traversal as described in Rodriguez &

Neubauer (Rodriguez & Neubauer 2011), to traverse

the semantic network of DBpedia. For each topic

(node) in a profile, the dcterms:subject links

are followed to the categories the topic is a member

of, from where skos:broader and

skos:narrower are followed to neighboring

categories, up to two levels outward. At each catego-

ry node that is visited during the traversal, the con-

tained topics are also visited, and the frequencies of

these visits are counted as a side effect. When the

traversal is finished, we take the frequency table,

and store it as a measurement of the relatedness

between the starting node and the visited topics.

Then, to infer which newly found topics should

be included in the profile, we summate the frequen-

cy tables of all topics in the profile. From the result-

ing table, we ignore any topics that are already in the

profile, and take the top-10 related topics that are in

our vocabulary, and the top-10 topics that are not in

our vocabulary.

LinkedIn uses a proprietary algorithm, which

likely incorporates aspects of collaborative filtering,

to display 20 "related skills" on each of the pages

that we used as the basis for our vocabulary. Such

lists of related skills are added into a frequency table

for each profile, and are further treated identically to

the inferences from DBpedia.

6 EVALUATION

The ground truth against which we measure the

performance of the method is provided by 8 partici-

pants. We have provided them with an interface that

allowed them to review and correct their own pro-

file. First they were presented with 184–353 topics

that were extracted from all types of documents

(). Participants were asked to remove all

Gremlin - < http://gremlin.tinkerpop.com/ >

topics in which they had no mastery by clicking the

corresponding buttons.

The second step for the participants was to cor-

rect the estimated mastery levels. Here, statements

were presented as boxes (again including the topic

name and description) with three sliders for the skill,

knowledge, and interest level. Due to the large

amount of extracted statements, we randomly omit-

ted 50% of the statements that were based only on

extraction from course descriptions or portfolio

documents.

The third step was similar to the first, except

with 20 inferred topics from DBpedia, and 20 in-

ferred topics from LinkedIn. In the fourth and final

step, the participants were asked to add any topics in

which they had mastery that were missing from their

profile.

It is worth noting that people are prone to over-

and underestimating themselves (Dunning et al.,

2003). This is, however, not a weakness of our ex-

periment in particular. In CSGF it is still quite com-

mon to base a profile of task-related attributes solely

on the information that is provided by the learner in

question.

The measures precision, recall, and F

0.5

-score,

which have been defined in Section 5.3.2, are used

to evaluate the performance of our annotation pro-

cess. We do not average our measures over the pro-

files, but rather take the counts of 







, and their intersection per profile, sum the

counts, and then compute precision, recall, and F

0.5

over all profiles. To assess how successful we were

at estimating mastery levels, we test for correlation

between the estimated and actual levels. We use

Pearson's correlation coefficient () as a measure,

and we report on statistical significance at the levels

of 0.10 (

) and 0.001 (*). Because we included a

limited number of inferred topics in the participants'

profiles, we cannot use exactly the same measures as

with the extracted topic links. Instead, we use Preci-

sion at 10, which denotes the fraction of inferred

topics in which the participants claim to have mas-

tery.

Our results (see Table 1) indicate that the combi-

nation of extracted information from all document

origins leads to the most accurate profiles. The pro-

files included a large amount of topics in which the

participants actually had some mastery. Course de-

scriptions are the only type of document that could

be used to produce profiles of similar quality by

itself. Documents from other origins lead to topic

links with a comparable precision, but in a quantity

that is likely not sufficient for application in CSGF.

CSEDU2014-6thInternationalConferenceonComputerSupportedEducation

188

Table 1: Performance of the Mastery Profiling Method.

Extracted

Origin Topic Links Levels Corr.

Pr. Re. F

0.5

Sk. Kn. In.

Course

0.859 0.711 0.825 .210* .212* –––

LinkedIn 0.935 0.077 0.290 .060 .108 .047

Portfolio 0.811 0.184 0.482 .220* .058 .073

Website 1.000 0.003 0.013 .853

.696 .700

ALL 0.845 0.860 0.848 .268* .241* .299*

Inferred

In-

Vocabulary

DBpedia

Pr. at 10

Yes 0.825 0.925

No 0.750 0.875

Inference can be used to expand learner profiles with

high precision. The additional topics that are found

by taking into account probabilistic relations be-

tween topics from LinkedIn are more precise than

those that are found from a traversal over the seman-

tic network of DBpedia. It is more accurate, in both

cases, to filter the inferred topics with our vocabu-

lary. A large majority of the inferred topics that are

not in our vocabulary is, however, also correct.

Our method was not able to estimate mastery

levels with the accuracy that is necessary for CSGF.

The estimated mastery levels show a weak but sig-

nificant correlation with the levels that the partici-

pants reported. The differences between origins

suggest that course grades and qualifying terms are

both indicators for mastery levels, but that the num-

ber of sections that is annotated with a given topic is

a worse indicator than we expected.

7 DISCUSSION

Our annotation process has produced results that are

very promising for use in CSGF. It does not rely on

optimizations specific for the field the students are

training in. Instead, it relies upon the configurability

of DBpedia Spotlight and the broad coverage of

professional topics that is used on LinkedIn. Ad-

vantages of keeping the method and implementation

field-agnostic are the reproducibility of the experi-

ments with students of other fields, and a greater

potential to collaborate in the development of the

necessary software.

We found that the method makes mistakes that

may, however, be overcome with domain-specific

optimizations. Abbreviations of field-specific con-

cepts which are commonly used with a different

meaning are not disambiguated correctly. We also

found that the coverage of the vocabulary was too

broad. For example, "Schizophrenia" is in most

disciplines never a main topic.

Our results in estimating mastery levels are less

promising. It is possible that we have used suitable

indicators and that the used data transformations are

not right for this task. A post-hoc analysis of our

results can clarify this matter to some extent. It will

be interesting to see if a method that is based on

machine learning, but uses the same features as we

have, will fare better in future research.

To make further advances in mastery profiling,

we may have to turn to techniques that are outside

the scope of the current method. Portfolio docu-

ments that were the product of teamwork inherently

describe the actions of multiple team members. We

would want to distinguish between individuals, and

discern "who did what". For course descriptions it

holds that not all text indicates what the students will

do or learn. Administrative remarks say something

about the course or about the teacher, but give no

relevant information about the students who have

completed the course. Such mistakes ask for more

focus on textual relations, as is done in Open Infor-

mation Extraction (Etzioni et al. 2011).

8 CONCLUSIONS

In this paper, we have presented a method that pro-

duces learner profiles on the basis of existing docu-

ments that are associated with students. It is able to

link students to a large amount of topics, in which

they have skill, knowledge, and/or interest, with

high precision. We have not yet succeeded in esti-

mating the mastery levels that students have in these

topics. Our method can be used as a baseline in

future experiments that aim to produce learner pro-

files from existing documents. We aim to publish

our current implementation under an open source

license to facilitate this.

Our work is also a demonstration of a novel ap-

plication of entity linking. We have shown that

DBpedia Spotlight can be configured to accurately

annotate course descriptions, portfolio documents,

and websites. A customized vocabulary was used to

filter annotations that are relevant to the mastery

profiling task, and to combine the annotations from

Dutch and English language documents into a single

learner profile. The sets of topics that were extracted

from students' associated documents have been suc-

cessfully expanded by inference over semantic and

probabilistic relationships between topics.

MasteryProfilingThroughEntityLinking-ToSupportProjectTeamFormationinHigherEducation

189

We hope that the work that has been described in

this paper can serve as a starting point for the inclu-

sion of detailed task-related attributes in learner

profiles and, more generally, that it will assist in the

adoption of CSGF in higher education.

ACKNOWLEDGEMENTS

Many thanks go to Wouter Weerkamp for valuable

guidance and feedback; to Flip van Haaren and

Raymond Jelierse at Shareworks for feedback and

technical assistance; to the participants for respond-

ing to the questionnaire and for reviewing their own

learner models; and to Joachim Daiber for clarifying

the configurability of DBpedia Spotlight.

REFERENCES

Bull, S. & Kay, J., 2007. Student Models that Invite the

Learner In: The SMILI:-) Open Learner Modelling

Framework. International Journal of Artificial

Intelligence in Education, 17(2), pp.89–120.

Craig, M., Horton, D. & Pitt, F., 2010. Forming

reasonably optimal groups: (FROG). In Proceedings

of the 16th ACM international conference on

Supporting group work. pp. 141–150.

Dai, H. et al., 2012. From Entity Recognition to Entity

Linking: A Survey of Advanced Entity Linking

Techniques. In The 26th Annual Conference of the

Japanese Society for Artificial Intelligence. pp. 1–10.

Daiber, J. et al., 2013. Improving Efficiency and Accuracy

in Multilingual Entity Extraction. In Proceedings of

the 9th International Conference on Semantic Systems.

Austria, Graz.

Dunning, D. et al., 2003. Why people fail to recognize

their own incompetence. Current Directions in

Psychological Science, 12(3), pp.83–87.

Etzioni, O. et al., 2011. Open information extraction: The

second generation. In Proceedings of the 22nd

international joint conference on Artificial

Intelligence. pp. 3–10.

Han, X., Sun, L. & Zhao, J., 2011. Collective entity

linking in web text: a graph-based method. In

Proceedings of the 34th international ACM SIGIR

conference on Research and development in

Information Retrieval. pp. 765–774.

Hoogendoorn, S.M., 2013. Diversity and team

performance: A series of field experiments. PhD

Thesis. University of Amsterdam. Available at:

http://dare.uva.nl/record/440433.

Jackson, S., May, K. & Whitney, K., 1995. Understanding

the dynamics of diversity in decision-making teams. In

R. A. Guzzo, E. Salas, & Associates, eds. Team

Effectiveness and Decision Making in Organizations.

San Francisco, pp. 204–261.

Kyprianidou, M. et al., 2011. Group formation based on

learning styles: can it improve students’ teamwork?

Educational Technology Research and Development,

60(1), pp.83–110.

Lingard, R. & Berry, E., 2002. Teaching teamwork skills

in software engineering based on an understanding of

factors affecting group performance. In Frontiers in

Education Conference. Boston, MA: IEEE.

Livingstone, D. & Lynch, K., 2000. Group Project Work

and Student-centred Active Learning: Two different

experiences. Studies in Higher Education, 25(3),

pp.325–345.

Magnisalis, I., Demetriadis, S. & Karakostas, A., 2011.

Adaptive and Intelligent Systems for Collaborative

Learning Support: A Review of the Field. IEEE

Transactions on Learning Technologies, 4(1), pp.5–

20.

Mendes, P., Jakob, M., et al., 2011. DBpedia Spotlight:

Shedding Light on the Web of Documents. In

Proceedings of the 7th International Conference on

Semantic Systems (I-Semantics). Austria, Graz.

Mendes, P., Daiber, J., et al., 2011. Evaluating DBpedia

Spotlight for the TAC-KBP Entity Linking Task. In

Proceedings of the TAC-KBP 2011 Workshop.

Gaithersburg, USA.

Ounnas, A., 2010. Enhancing the Automation of Forming

Groups for Education with Semantics

. PhD Thesis.

University of Southampton. Available at:

http://eprints.soton.ac.uk/171641/.

Ounnas, A., Davis, H. & Millard, D., 2009. A framework

for semantic group formation in education.

Educational Technology & Society, 12(4), pp.43–55.

Rao, D., McNamee, P. & Dredze, M., 2013. Entity

linking: Finding extracted entities in a knowledge

base. In T. Poibo et al., eds. Multi-Source,

Multilingual Information Extraction and

Summarization. Berlin, Heidelberg: Springer Berlin

Heidelberg, pp. 93–115.

Rodriguez, M. A. & Neubauer, P., 2011. The Graph

Traversal Pattern. In S. Sakr & E. Pardede, eds. Graph

Data Management: Techniques and Applications. IGI

Global.

Wells, C. E., 2002. Teaching Teamwork in Information

Systems. In E. Cohen, ed. Challenges of Information

Technology Education in the 21 st Century. pp. 1–24.

Werbel, J.D. & Johnson, D. J., 2001. The Use of Person –

Group Fit for Employment Selection : A Missing Link

in Person – Environment Fit. Human Resource

Management, 40(3), pp.227–240.

Wetz, P. et al., 2012. Matching Linked Open Data Entities

to Local Thesaurus Concepts. In Proceedings of the I-

SEMANTICS 2012 Posters & Demonstrations Track.

pp. 6–11.

Wilkinson, I. A. G. & Fung, I. Y. Y., 2002. Small-group

composition and peer effects. International Journal of

Educational Research, 37(5), pp.425–447.

Winter, M., 2004. Developing a Group Model for Student

Software Engineering Teams. MSc Thesis. University

of Saskatchewan. Available at: http://hdl.handle.net/

10388/etd-07052004-140018.

CSEDU2014-6thInternationalConferenceonComputerSupportedEducation

190
