Ontology Integration with Contextual Information

Dan Wu

Software and Computer Systems, School of Information and Communication Technology, Stockholm, Sweden

Keywords: Ontology Integration and Merging, Non-contradictory Ontology Integration, Context, Rules.

Abstract: By studying ontologies in an ontology repository, context rules are developed to improve ontology

integration result. A context rule contains conditions for identifying a context. These context conditions are

described by, so called, context criteria, which are, e.g., author and domain of an ontology. When the

conditions, in a rule, are met, the rule is fired and the contextual information, in the body of the rule, is

inserted into the reasoner, which is used for ontology integration. An example shows the construction of a

context rule. The rule is used for an ontology integration. The integration result is indeed improved

comparing with integration without contextual information.

1 INTRODUCTION

Semantic ontology integration and matching is

important in many applications such as the semantic

web and the knowledge and information integration

(Euzenat et al., 2007). Although methods (Meilicke

et al., 2007; Aleksovski et al., 2006 a,b) have been

proposed, improvements are needed.

An approach of using contextual information is

proposed here to improve the ontology integration.

Our previous works show that different ontologies

are considered as different terminology definitions

from various perspectives (Håkansson and Wu,

2013); perspectives are then described with context

and used for reasoning among different ontologies in

a repostitory (Wu, 2013).

The paper is structured in five parts. Part 2

discusses related work. In part 3, the repository and

context in the repository is presented. Part 4 shows

an example of building contextual rules and how to

apply them to integrate ontologies; in part 5, the

discussion is given, and the last part concludes the

work and present future work.

2 RELATED WORK

Meilicke and Stuckenschmidt (2007) combined

numerical opimization and logical reasoning to

improve the ontology matching result. It uses

hungarian method to compute the optimal one-to-

one mapping and then check if the mapping is

consistent with the union of the ontologies. The idea

of consistency checking is very similar to our

apporach. However, we use rules to resolve the

inconsistency, the results are different. And we

create an integrated ontology that extend the

previous ontologies, while Meilicke and

Stuckenschmidt generate a mapping between two

ontologies.

Aleksovski (2006 a, b) used the background

knowledge for ontology matching. The background

knowledge is an ontology covering the source and

target ontologies and with rich semantic conceptual

descriptions of the domian. In our approach, the

contextual information is an ontology, however

identified by context criteria, which domain is only

one criterion. Context can be identified by a

combination of seven criteria. The reasoning

processes in two approaches are also different.

In an industrial scenario, a context ontology is

used to improve the matching result of an enterprise

ontology and a target ontology (Lin el al., 2010).

Abstract context and operational context are

modelled. During the matching process, the

enterprise ontology, the target ontology and the

context ontology are matched in turn. The

overlapping terminologies of these ontologies are

assigned with different weights or altering

algorithms. This work uses a context ontology,

however, created for the specific scenario. It is not

certain if the context ontology can be reused or not.

485

Wu D..

Ontology Integration with Contextual Information.

DOI: 10.5220/0004820504850490

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 485-490

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

The processes and the algorithms of handling the

match and using context are also different.

3 CONTEXT AND REASONING

An OWL 2 ontology repository is used for reusing

and integrating ontologies (Wu, 2013). The

ontologies in the repository can be integrated to

generate ontology intersections that covering

broader and deeper descriptions of ontologies (ibid.)

3.1 Context and the Context Rules

The ontology and ontology intersections in the

repository can be used as context for other ontology

integration. Context criteria describe the context.

Instead of using a term, criteria are used, such as,

components of ontologies, metadata and

administrative data of ontologies. The components

of an ontology are entities of ontologies, e.g., a class

or a property. The metadata of ontologies are

domain information, author of ontology, purpose of

ontology, context agent and time for creating the

ontology. Context agent is the context user who can

be either a person or an application. The

administrative data is the ontology and the context

identification. In the repository, the context criteria

are represented as entity of ontology, domain of

ontology, author of ontology, purpose of ontology,

context agent, time of ontology,

OntologyIdentification and Contextidentification.

The context criteria may be used all together or with

any combinations of the criteria. Thus, context is

defined as:

Context := {ontologyEntity} | ontologyDomain |

ontologyAuthor | ontologyPurpose | contextAgent |

time | ontologyIdentification | contextIdentification

Context rules relate the situation of the ontology

integration with ontologies in the repository. The

rules are in the form of if context () then

contextualInformation. The function context () uses

context criteria to delimit situations. The

contextualInformation is a collection of expressions

and axioms from an ontology or an ontology

intersection.

For example, if several ontologies define class

"author" and "paper" for conference domain, the

contextual information extracted from the ontologies

or ontology intersections is presented in a context

rule as:

If context (entities ("author", "paper") and

domain ("conference"))

Then contextualInformation (Author

ConferenceMember; Author

⊏

User; submitPaper

(Author,Paper); writePaper

≡

hasAuthor

━

;

hasAuthor(Paper,Author);

contributes (Person,Conference_document);

has_authors

≡

contributes

━

;

has_authors(Conference_document, Person); etc.…)

This rule fires when a situation that is described

with "author" and "paper" entities and the domain

"conference". The contextual information is, then,

used for the reasoning for integrating ontologies.

Context rules are used to build up the context

knowledge. Context knowledge tackles the

conceptual and the pragmatic heterogeneities of

ontologies. For example, different ontology authors

create different ontologies for the same domain.

Then, the different perspectives of the authors are

integrated and defined in the consequence part of the

context rule. The integrated ontologies cover a

broader and deeper conceptual description of the

initial ontologies (Wu, 2013). These integrated

ontologies are, then, used in context rules.

3.2 The Reasoning Process

The process for integrating task of two ontologies is

described below, see Figure 1.

Figure 1: Process of contextual ontology integration.

From left to right, the integration starts with two

input ontologies Q and Q'. The ontology intersection

is produced through the non-contradictory process

(Wu, 2013). The generated ontology intersection is

an independent ontology with its own identification

in the repository (ibid.). Then context rule is

identified to refine the ontology intersection result.

By examining the ontology intersection from the

first step, the knowledge expert chooses the proper

context criteria values. Through the integration

module, the values are added into the rule engine.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

486

The rule engine fires the most specific rule, i.e., the

most conditions are satisfied by the context criteria.

The integration module will take the

contextualinformation from the fired rule, and add it

as the contextual information into the OWL reasoner

to help to infer and refine the integration of the

ontology intersection. This refining process is an

integration of two ontologies, between the ontology

intersection and the contextual information, with the

help of integration rules. Finally, the integration

module generates the result, the contextual ontology

intersection. The process starts with two ontologies

and ends with the contextual ontology intersection as

the result.

4 AN EXAMPLE

This section describes an example to illustrate the

process of the contextual ontology integration. The

task is to integrate two ontologies using a context

rule. Ontologies are downloaded from OAEI 2012

ontology evaluation website

(http://oaei.ontologymatching.org/2012/conference/i

ndex.html). Three ontologies, “cmt.owl”,

“cocus.owl” and “conference.owl”, are downloaded

first in the repository and used for generating a

context rule. New ontologies are downloaded later

for showing the integration with the context rule.

4.1 The Context Rules

By integrating the three ontologies with the non-

contradiction process, an intersection is generated.

Since all ontologies describe conference domain, a

context rule is generated for the domain of

conference. The ontologies are integrated two by

two because the non-contradiction process takes

only two ontologies at a time. In other words,

“cmt.owl” is integrated with “cocus.owl” first. The

intersection of them is then integrated with the third

ontology “conference.owl”. The result is an

intersection of the three ontologies. Since terms of

"Author" and "Paper" are commonly used in the

domain of conference, this example uses only the

definitions concerning these two terms. All the

descriptions that contain "Author" and "Paper" are

extracted from the ontologies. Protégé is used to

extract the class usages and the result is presented in

Table 1.

Table 1: The ontologies in the repository.

Cmt.owl

utho

ConferenceMember

utho

⊏ User

AuthorNotReviewer ⊏ Author

Co-author ⊏ Author

∀x,y: (x,y)  (submitPaper)

implies x

Author and y Paper

(writePaper)

={(x,y)|(y,x)  (hasAuthor)

}

∀x,y: (x,y)  (hasAuthor)

implies x 

ape

and y  Author

∀x,y: (x,y)  (markConflictOfInterest)

implies

(x  Author | x  Chairman | x  Reviewer) and

y  Paper

aper ⊏Document

ape

⊓Review∅

PaperAbstract ⊏Paper

PaperFullVersion ⊏Paper

∀x,y: (x,y)  (acceptPaper)

implies x 

dminstrato

and y  Paper

∀x,y: (x,y)  (acceptedBy)

implies x 

ape

and y  Administrator

acceptPaper

≡

acceptedBy

━

∀x,y: (x,y)  (assignedTo)

implies x 

ape

and y  Reviewer

∀x,y: (x,y)  (hasBeenAssigned)

implies x 

eviewe

and y  Paper

∀x,y: (x,y)  (co-writePaper)

implies x  Co-

author and y  Paper

∀x,y: (x,y)  (hasBid)

implies x  Paper an

y  Bid

∀x,y: (x,y)  (hasCo-author)

implies x 

aper and y  Co-author

∀x,y: (x,y)  (hasDecision)

implies x 

ape

and y  Decision

∀x,y: (x,y)  (readByReviewer)

implies x 

aper and y  Reviewer

∀x,y: (x,y)  (readPaper)

implies x 

eviewe

and y  Paper

∀x,y: (x,y)  (rejectPaper)

implies x 

dministrato

and y  Paper

∀x,y: (x,y)  (rejectBy)

implies x 

ape

and y  Administrato

Cocus.owl

utho

⊏ User

Corresponding_Author⊏

Author



aper ⊏Document

Abstract ⊏Paper

Full_Paper ⊏Paper

Invited_Paper ⊏ Paper

Short_Paper ⊏

ape

Conference.

owl

egular_autho

⊏Conference_contributor

Contribution_1th‐author⊏Regular_author

Contribution_co‐author⊏Regular_author

∀x,y: (x,y)  (has_authors)

implies x 

Conference_Document and y  Person

∀x,y: (x,y)  (contributes)

implies x  Person

and y  Conference_document

ape

⊓Extended_abstract∅

aper ⊏Regular_contribution

∀x,y: (x,y)  (has_an_abstract)

implies x 

aper and y  Abstract

∀x,y: (x,y)  (is_the_1th_part_of)

implies x 

Abstract and (y  Paper | y  Poster | y 

resentation)

OntologyIntegrationwithContextualInformation

487

First, the signatures of ontology “cmt.owl” and

“cocus.owl” are extracted and four sets of entities

are produced: two sets are their labels of the classes;

and two sets are their labels of object properties.

Second, the comparison of syntax of the sets of

labels of the classes and the object properties are

conducted. Synonyms are identified from WordNet

(http://wordnetweb.princeton.edu/perl/webwn). The

string-identical labels and synonyms from the entity

candidates are used for generating assumptions. The

third step is to test the assumptions with the

ontologies one by one and check the contradiction

between them. Integration rules are used to handle

the process and conflicts. An integration rule is for

example: If string-identical (Q.c, Q'.c') and

synonyms (Q.m. Q'n) and (Q.c

⊏

Q.m | Q.m

⊏ Q.c

and (Q'.c'

⊏

Q' n | Q'.n

⊏

Q'.c') then c

≡

c'. This

rule says that to merge two string identical class c

and c' in two ontologies if they share either the super

classes that are synonyms or children classes that are

synonyms. The non-contradiction part is preserved

in the ontology intersection of ontologies “cmt.owl”

and “cocus.owl”. The ontology intersection is then

integrated with “conference.owl” following the same

non-contradiction process to generate the final

intersection of the three ontologies. The ontology

intersection of the three ontologies is used for

building a context rule.

The rule condition is domain ("conference") and

entities ("Author", "Paper"). The consequence part

of the rule is extracted from the ontology

intersection of the three ontologies. The rule is

shown in Table 2.

Table 2: The contextual rule.

If context (domain("conference") and entity

("Author", "Paper"))

Then contextualInformation(

∀x,y: (x,y)  (hasAuthor)

implies x  Paper and y 

utho

; ∀x,y: (x,y)  (writePaper)

implies x 

utho

and y  Paper; writePaper≡hasAuthor

━

;∀x,y:

(x,y)  (submitPaper)

implies x Author and y Paper;

∀x,y: (x,y)  (has_authors)

implies x 

Conference_Document and y  Person; ∀x,y: (x,y) 

(contributes)

implies x  Person and y 

Conference_document; has_authors ≡ contributes

━

;

Author⊏Person; Paper⊏Regular_contribution;

Regular_contribution⊏Written_contribution;

Written_contribution⊏Conference_contribution;

Conference_contribution ⊏Conference_document; etc…..)

In the consequent part of the rule, only part of the

intersection is shown because of the limit of space.

The expressions, in bold font, are used for

contextual integration carried out later on.

4.2 Integration with the Context Rule

Ontologies confious.owl and confof.owl are then

downloaded and the task is to integrate them using

the context rule shown in Table 2. Only classes and

properties that contain terms "Author" and "Paper"

are extracted from the ontologies and used in the

example, shown in Table 3. They represent

ontologies Q and Q’ in section 3.2. In order to

generate a contextual ontology intersection of these

two ontologies, an intersection according to the non-

contradictory integration process (Wu, 2013) is

produced first. The result is shown in Table 4.

Table 3: Ontologies for showing contextual integration.

Confious.owl

∀x,y: (x,y)  (has_author)

implies x

 Article and y  Human;

∀x,y: (x,y)  (is_author_of)

implies x

 Human and y  Article;

has_author

≡

is_author_of

━

; Paper ⊏

Article;

abstract_of_paper ⊏Article;

Accepted_Paper ⊏ Paper

Rejected_Paper ⊏ Paper

Undecided_Paper ⊏ Paper

∀x,y: (x,y)  (is_concerned)

implies

y  Paper; Contact_Person ⊏Human

Confof.owl

∀x,y: (x,y)  (writes)

implies x 

uthor and y  Contribution; ∀x,y:

(x,y)  (writenby)

implies x 

Contribution and y  Author; writes

≡

writtenby

━

;

utho

⊏ Person; Paper ⊏

Contribution; Paper⊓Poster∅;

ape

⊓short_

aper

∅

If only one definition exists in either ontology,

the definition is per se true and preserved in the

intersection. The string identical entity, e.g., paper,

is integrated as one class in the intersection. The

integration does not contradict the input ontologies.

That is to say, classes “Accepted_Paper”,

“Rejected_Paper” and “Undecided_Paper” are

subclasses of class “Contribution”, which cause non

contradiction to both original ontologies. The

ontology intersection, in Table 4, is then been

examined for identifying the context rule.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

488

Table 4: Ontology intersection of Confious.owl &

Confof.owl.

Paper ⊏ Article; Paper ⊏ Contribution; Accepted_Paper

⊏ Paper; abstract_of_paper ⊏ Article; Rejected_Paper ⊏

Paper; Undecided_Paper ⊏ Paper; Paper⊓Poster∅;

Paper⊓short_

paper

∅; Author ⊏ Person ;

Contact_Person ⊏Human;

∀x,y: (x,y)  (writes)

implies x  Author and y 

Contribution;

∀x,y: (x,y)  (writenby)

implies x  Contribution

and y  Author;

writes≡writtenby

━

;

∀x,y: (x,y)  (has_author)

implies x  Article and y

 Human;

∀x,y: (x,y)  (is_author_of)

implies x  Human and

y  Article;

has_author

≡

is_author_of

━

;

∀x,y: (x,y)  (is_concerned)

implies y  Paper;

When context condition data, i.e., domain is

"conference" and entities are "paper" and "author",

are entered into the rule engine, the context rule in

Table 2 fires. The contextual information in the rule

is then inserted into the OWL reasoner to help

further integrating the ontology intersection. This

process is actually an integration of the ontology

intersection with the contextual information. The

process of non-contradiction is applied also for this

integration.

With OWL 2, inverse object properties can be

defined, such as “has_author” and “is_author_of”

are inverse properties. That is to say, if two

individuals x and y are related by “has_author”, then

y and x are related by “is_author_of”. One

integration rule about the inverse relation is:

ObjectProperty-Inverse-rule:

If O: r1 (A, B) and O: r2 (B, A) and

inverseProperties (O: r1, O: r2) and O: r3 (B, A)

and O: r4 (A, B) and inverseProperties (O: r3, r4)

AND

Q: r1 (A, B) and Q: r3 (B, A) and

inverseProperties (Q:r1, Q: r3)

Then r2(B, A) and r4 (A, B) and

inverseProperties (r2, r4)

The rule is shown in functional-style syntax, rather

than using DL syntax as in the tables. O and Q

symbolize two general ontologies. For example, O:

r1 (A, B) states that the class A is the domain of the

property r1 in ontology O, and the class B is the

range of the property r1 in O. InverseProperties (O:

r1, O: r2) means that r1 and r2 are inverse

properties. This integration rule shows the transfer

of inverse role relations in two ontologies. A and B

are two string identical classes in ontology O.

Properties r1, r2, r3 and r4 are four object properties.

If there are two definitions of inverse properties in

one ontology as inverseProperties(O:r1. O:r2) and

inserseProperties(O:r3, O:r4); and if in the other

ontology, the inverse property is between the inverse

properties from the previous ontology, i.e.,

inversProperties(Q:r1, Q:r3); and all definitions are

about the string-identical two classes A and B. The

inverse property will transfer to the other unrelated

properties, i.e., invserProperties(r2, r4). In the rule

condition, namespaces O and Q are used. In the

result part, the namespace is escaped since the result

is the new independent ontology, the ontology

intersection.

Back to the example, there two pairs of inverse

properties are identified in Table 4:

InverseProperties (writes, writtenby) and

InverseProperties (is_author_of, has_author). From

the contextual information in Table 2,

InverseProperties (writePaper, hasAuthor) is

identified. "hasAuthor" is string-identical to

"has_author". However, the rule conditions are not

completely fulfilled. The property "writes" and

"writePaper" are not equivalent. The integration

module asks the knowledge expert in such a

situation:

EquivalentProperties(writes,writePaper)?.

When the knowledge expert confirms the axiom, it is

added into the ontology intersection.

Another axiom, which needs to be confirmed, is

EquivalentClasses(Contact_Person, Author)?. The class

"Contact_Person" is defined in confious.owl, where

a contact_person is a human and is_author of an

article. And it is not defined in other ontologies;

therefore, it is not a problem to add this axiom.

When this axiom is confirmed, the integration rule is

fired.

Accordingly, the new knowledge in the result is:

"is_author_of" is the inverse property "writtenby",

shown below:

∀

x,y: (x,y)



(writterBy)

implies x



Paper and y



Author;

∀

x,y: (x,y)



(is_author_of)

implies x



Contact_Person and y



Paper;

is_author_of

≡

writtenBy

━

;

Author

⊏

Human; writes

≡

writePaper;

Contact_Person

≡

Author

The final result is a non-contradictory ontology

intersection under the open world assumption,

shown below:

Article≡Contribution; abstract_of_paper

⊏

Article; Rejected_Paper

⊏

Paper;

OntologyIntegrationwithContextualInformation

489

Undecided_Paper

⊏

Paper; Accepted_Paper

⊏

Paper; Paper

⊓

Poster =

∅

; Paper

⊓

short_paper

∅

; Paper

⊏

Regular_contribution;

Regular_contribution

⊏

Written_contribution;

Written_contribution

⊏

Conference_contribution;

Conference_contribution

⊏

Conference_document; Author

⊏

Person;

Contact_Person

⊏

Human; Contact_Person



Author;

∀

x,y: (x,y)



(contributes)

implies x



Person and y



Conference_document;

Contribute

⊓

has_author=

∅

;

∀

x,y: (x,y)



(has_author)

implies x



Article and y



Human;

∀

x,y: (x,y)



(is_author_of)

implies x



Human and y



Article;

∀

x,y: (x,y)



(is_author_of)

implies x



Contact_Person and



Paper;is_author_of



writePaper



writes;

∀

x,y: (x,y)



(is_concerned)

implies y



Paper;

∀

x,y: (x,y)



(submitPaper)

implies x



Author and y



Paper;

∀

x,y: (x,y)



(writePaper)

implies x



Author and y



Paper;

∀

x,y: (x,y)



(writes)

implies x



Author and y



Contribution;

∀

x,y: (x,y)



(writenby)

implies



Contribution and y



Author;

∀

x,y: (x,y)



(writterBy)

implies x



Paper and y



Author;

writes≡writtenby

━

; has_author≡is_author_of

━

;has_author≡writes

━

; has_author≡writePaper

━

;

writePaper ≡ writtenBy

━

;

is_author_of≡writtenBy

━

; is_author_of ≡

writtenBy

━

;

With the help of the contextual information, the

ontology integration result has been improved

because of more available information. The

contextual ontology integration result is covering

even more axioms than the first time ontology

integration result. As we can see, the result contains

non-contradictory axioms from the first intersection

of the two ontologies and the contextual

information. The result contains as well new axioms

from the integration rules, which do not contradict

the original ontologies.

Some approaches create ontologies to describe

context. We use context criteria. Using criteria for

context is better than using a single term for

describing context. The context can be described by

the different combination of the criteria. In this

sense, the context is dynamic identified. To create a

context ontology costs more comparing with reusing

ontologies and ontology intersection in a repository.

And it is very uncertain if the context ontology can

be reused in future or not. Building the context

condition and the contextual information into rules

for reusing is an improvement for using context in

reasoning.

5 CONCLUSIONS AND FUTURE

WORK

This paper shows how contextual information can be

used for improving ontology integration using

context rules. The result is promising: the example

shows that broader and deeper conceptual

definitions are deduced from the initial ontologies

and the implied contextual information become

explicit in the final result.

However, more tests need to be conducted to

validate the context rules and the integration rules.

Another important work is to develop methods to

automatically discern the context and suggest the

context criteria, which is dependent on the

knowledge expert at the current stage.

REFERENCES

Aleksovski, Z., Klein, M., ten Kate, W., and van

Harmelen, F., 2006. Matching unstructured

vocabularies using a background ontology. s.l.,

Knowledge Engineering and Knowledge Management

(EKAW).

Aleksovski, Z., ten Kate, W., and van Harmelen, F., 2006.

Expliting the structure of background knowledge used

in ontology matching. s.l., International Workshop on

Ontology Matching (OM-2006).

Euzenat, J., SHvaiko, P., 2007. Ontology Matching.

Berlin, Heidelberg: Springer-Verlag.

Håkansson, Anne; Wu, Dan, 2013. Conceptual Ontology

Intersection for Mapping and Alignment of

Ontologies. In: Agent and Multi-Agent Systems in

Distributed Systems - Digital Economy and E-

Commerce. s.l.:Springer Berlin Heidelberg, pp. 105-

124.

Lin, Feiyu, Butters, Jonathan, Sandkuhl, Kurt, Ciravegna,

Fabio, 2010. Context-based Ontology Matching:

Concept and Application Cases. s.l., 2010 10th IEEE

International Conference on Computer and

Information Technology (CIT 2010).

Meilicke, C. and Stuckenschmidt, H., 2007. Applying

logical constraints to ontology matching. s.l., KI2007:

Advances in Artificial Intelligence.

Wu, D., 2013. Ontology Integration with Non-Violation

Check and Context Extraction, Stockholm: KTH

Royal Institute of Technology.

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

490
