A Metadata Focused Crawler for Linked Data

Raphael do Vale A. Gomes

, Marco A. Casanova

Giseli Rabello Lopes

and Luiz André P. Paes Leme

Departamento de Informática, PUC-Rio, Rua Marquês de S. Vicente, 225, Rio de Janeiro, Brasil

Instituto de Computação, UFF, Rua Passo da Pátria, 156, Niterói, Brasil

Keywords: Focused Crawler, Tripleset Recommendation, Linked Data.

Abstract: The Linked Data best practices recommend publishers of triplesets to use well-known ontologies in the

triplication process and to link their triplesets with other triplesets. However, despite the fact that extensive

lists of open ontologies and triplesets are available, most publishers typically do not adopt those ontologies

and link their triplesets only with popular ones, such as DBpedia and Geonames. This paper presents a

metadata crawler for Linked Data to assist publishers in the triplification and the linkage processes. The

crawler provides publishers with a list of the most suitable ontologies and vocabulary terms for triplifica-

tion, as well as a list of triplesets that the new tripleset can be most likely linked with. The crawler focuses

on specific metadata properties, including subclass of, and returns only metadata, hence the classification

“metadata focused crawler”.

1 INTRODUCTION

The Linked Data best practices (Bizer et al., 2009)

recommend publishers of triplesets to use well-

known ontologies in the triplication process and to

link with other triplesets. However, despite the fact

that extensive lists of open ontologies and triplesets

are available, such as DataHub

, most publishers

typically do not adopt ontologies already in use and

link their triplesets only with popular ones, such as

DBpedia

and Geonames

. Indeed, according to

(Nikolov and d'Aquin, 2011; Nikolov et al. 2012;

Martínez-Romero, 2010), linkage to popular triple-

sets is favored for two main reasons: the difficulty of

finding related open triplesets; and the strenuous

task of discovering instance mappings between dif-

ferent triplesets.

This paper describes a crawler that addresses the

problem of finding vocabulary terms and triplesets

to assist publishers in the triplification and the link-

age processes. Unlike typical Linked Data crawlers,

the proposed crawler then focuses on metadata with

specific purposes, illustrated in what follows.

In a typical scenario, the publisher of a tripleset

first selects a set T of terms that describe an applica-

http://datahub.io

http://dbpedia.org

http://www.geonames.org

tion domain. Alternatively, he could use a database

summarization technique (Saint-Paul et al., 2005) to

automatically extract T from a set of triplesets.

Then, the publisher submits T to the crawler,

which will search for triplesets whose vocabularies

include terms direct or transitively related to those in

T. The crawler returns a list of vocabulary terms, as

well as provenance data indicating how the output

was generated. For example, if the publisher selects

the term “

Music” from WordNet, the crawler might

return “

Hit music” from BBC Music.

Lastly, the publisher inspects the list of triplesets

and terms returned, with respect to his tripleset, to

select the most relevant vocabularies for triplifica-

tion and the best triplesets to use in the linkage pro-

cess, possibly with the help of recommender tools.

We stress that the crawler was designed to help rec-

ommender tools for Linked Data, not to replace

them.

This paper is organized as follows. Section 2

presents related work. Section 3 summarizes back-

ground information about the technology used. Sec-

tion 4 briefly explains how the crawler works with

the help of an example. Section 5 details the crawl-

ing process. Section 6 describes experiments that

assess the usefulness of the crawler. Finally, Section

7 presents the conclusions.

489

do Vale Amaral Gomes R., A. Casanova M., Rabello Lopes G. and André P. Paes Leme L..

A Metadata Focused Crawler for Linked Data.

DOI: 10.5220/0004867904890500

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 489-500

ISBN: 978-989-758-028-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

2 RELATED WORK

We first compare the proposed crawler to Linked

Data crawlers.

Fionda et al. (2012) present a language, called

NAUTILOD, which allows browsing through nodes

of a Linked Data graph. They introduced a tool,

called swget (semantic web get), which evaluates

expressions of the language. An example would be:

“find me information about Rome, starting with its

definition in DBpedia and looking in DBpedia,

Freebase and the New York Times databases”.

swget <dbp:Rome>

(<owl:sameAs>)* -saveGraph-domains

{dbpedia.org,

rdf.freebase.com,

data.nytimes.com}

LDSpider (Isele et al., 2010) is another example of a

Linked Data crawler. Similarly to the crawler pro-

posed in this paper, LDSpider starts with a set of

URIs as a guide to parse Linked Data.

Ding et al. (2005) present the tool created by

Swoogle to discover new triplesets. The authors

describe a way of ranking Web objects in three

granularities: Web documents (Web pages with

embedded RDF data), terms and RDF Graphs (tri-

plesets). Each of these objects has a specific ranking

strategy.

The Linked Data crawlers just described have

some degree of relationship with the proposed

crawler, though none has exactly the same goals. As

explained in the introduction, the proposed crawler

focuses on finding metadata that are useful to design

new triplesets. Furthermore, rather than just derefer-

encing URIs, it also adopts crawling queries to im-

prove recall, as explained in Section 5.1.

We now comment on how the proposed crawler

relates to recommender tools for Linked Data.

Some generic recommender tools use keywords

as input. Nikolov et al. (2011, 2012) use keywords

to search for relevant resources, using the label

property of the resources. Indeed, a label is a proper-

ty used to provide a human-readable version of the

name of the resource

. A label value may be inaccu-

rate, in another language or simply be a synonymous

of the desired word. There is no compromise with

the schema and its relationships. Therefore, the risk

of finding an irrelevant resource is high.

Martínez-Romero et al. (2010) propose an ap-

proach for the automatic recommendation of ontolo-

gies based on three points: (1) how well the ontology

matches the set of keywords; (2) the semantic densi-

http://www.w3.org/TR/rdf-schema/#ch_label

ty of the ontology found; and (3) the popularity of

the tripleset on the Web 2.0. They also match a set

of keywords to resource label values, in a complex

process.

The crawler proposed in this work may be used

as a component of a recommender tool, such as

those just described, to locate: (1) appropriate ontol-

ogies during the triplification of a database; (2) tri-

plesets to interlink with a given tripleset. We stress

that the crawler was not designed to be a full rec-

ommender tool, but rather to be a component of one

such system.

3 BACKGROUND

The Linked Data principles advocate the use of RDF

(Manola and Miller, 2004), RDF Schema (Brickley

and Guha, 2004) and other technologies to standard-

ize resource description.

RDF describes resources and their relationships

through triples of the form (s, p, o), where: s is the

subject of the triple, which is an RDF URI reference

or a blank node; p is the predicate or property of the

triple, which is an RDF URI reference and specifies

how s and o are related; and o is the object, which is

an RDF URI reference, a literal or a blank node. A

triple (s, p, o) may also be denoted as “<s><p><o>”.

A tripleset is just a set of triples. In this paper

will use dataset and tripleset interchangeably.

RDF Schema is a semantic extension of RDF to

cover the description of classes and properties of

resources. OWL (W3C, 2012) in turn extends RDF

Schema to allow richer descriptions of schemas and

ontologies, including cardinality and other features.

RDF Schema and OWL define the following

predicates that we will use in the rest of the paper:



rdfs:subClassOf indicates that the subject of

the triple defines a subclass of the class defined by

the object of the triple



owl:sameAs indicates that the subject denotes the

same concept as the object



rdfs:seeAlso indicates that the subject is gener-

ically related to the object



rdf:type indicates that the subject is an instance

of the object

For example, the triple

<dbpedia:Sweden> <rdf:type> <dbpedia:Country>.

indicates that the resource Sweden is an instance of

the class Country.

Triplesets are typically available on the Web as

SPARQL endpoints (Prud’hommeaux and Seaborne,

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

490

2008) or as file dumps (large files containing all the

data from a tripleset, or small files containing only

the relevant data for a defined term).

More than just a query language similar to SQL,

SPARQL is a protocol: it defines the query interface

(HTTP), how requests should be made (POST or

GET) and how the data should be returned (via a

standard XML). Thus, an agent can perform queries

on a dataset and acquire knowledge to create new

queries and so on.

Finally, VoID (Alexander et al., 2009) is an on-

tology used to define metadata about triplesets. A

VoID document is a good source of information

about a tripleset, such as the classes and properties it

uses, the size of the tripleset, etc.

Let d be a tripleset and V be a set of VoID

metadata descriptions. The classes and properties

used in d can be extracted from tripleset partitions

defined by the properties

void:classPartition

and

void:propertyPartition that occur in V.

Class partitions describe sets of triples related to

subjects of a particular class. Property partitions

describe sets of triples that use a particular predicate.

These partitions are described by the properties

void:class and void:property respectively.

The set of vocabulary terms used in d can be gener-

ated by the union of all values of the properties

void:class and void:property. In some cases,

the VoID description of a tripleset does not define

partitions, but it specifies a list of namespaces of the

vocabularies used by the tripleset with the

void:vocabulary predicate. One can enrich the

set of vocabulary terms used in d with such a list.

4 A USE CASE

Consider a user who wants to publish as Linked

Data a relational database d storing music data (art-

ists, records, songs, etc.). The crawler proposed in

this paper will help the user to publish d as follows.

First, the user has to define an initial set T of

terms to describe the application domain of d. Sup-

pose that he selects just one term

dbpedia:Music,

taken from DBpedia.

The user will then invoke the crawler, passing T

as input. The crawler will query the Datahub.io cata-

logue of Linked Data triplesets to crawl triplesets

searching for new terms that are direct or transitively

related to

dbpedia:Music. The crawler focuses on

finding new terms that are defined as subclasses of

the class

dbpedia:Music, or that are related to

dbpedia:Music by owl:sameAs or

rdfs:seeAlso properties. The crawler will also

count the number of instances of the classes found.

The crawler will return: (1) the list of terms

found, indicating their provenance - how the terms

are direct or transitively related to

dbpedia:Music

and in which triplesets they were found; (2) for each

class found, an estimation of the number of instances

in each tripleset visited; and (3) a list relating the

VoID data of each tripleset with each one of the

terms found in (1).

The user may take advantage of the results the

crawler returned in two ways. He may manually

analyze the data and decide: (1) which of the probed

ontologies found he will adopt to triplify the rela-

tional database; and (2) to which triplesets the

crawler located he will link the tripleset he is con-

structing. Alternatively, he may submit the results of

the crawler to separate tools that will automatically

recommend ontologies to be adopted in the triplifi-

cation process, as well as triplesets to be used in the

linkage process (Leme et al., 2013; Lopes et al.,

2013).

For example, suppose that the crawler finds two

subclasses,

opencyc:Love_Song and open-

cyc:Hit_Song, of wordnet:synset-music-

noun-1

in the ontology opencyc:Music. Suppose

also that the crawler finds large numbers of instanc-

es of these subclasses in two triplesets,

mu-

sicBrains

and bbcMusic. The user might then

decide that

opencyc:Music is a good choice to

adopt in the triplification process and that

mu-

sicBrains

and bbcMusic are good choices for the

linkage process.

5 A METADATA FOCUSED

CRAWLER

This section discusses the construction of the

metadata focused crawler. The reader will find a

pseudo-code describing the crawler in Annex 1.

5.1 Crawling Queries

The crawler works with catalogues that use the

CKAN framework to identify SPARQL endpoints

and RDF dumps. It receives as input a set of terms T,

called the initial crawling terms. Such terms are

typically selected from generic ontologies, such as

WordNet

, DBpedia and Schema.org

, albeit this is

not a requirement for the crawling process.

http://wordnet.princeton.edu/

http://schema.org

AMetadataFocusedCrawlerforLinkedData

491

Given T, the crawler proceeds in stages (see Sec-

tion 5.2) to extract new terms using crawling queries

over all triplesets listed in the catalogues and using

URI dereferencing.

The crawling queries find new terms that are re-

lated to the terms obtained in the previous stage

through the following crawling properties (see Sec-

tion 3)

rdfs:subClassOf, owl:sameAs and

rdfs:seeAlso. Hence, these queries are respec-

tively called subclass, sameAs and seeAlso queries.

Figure 1 shows one of the templates of the

crawling queries that obtain terms related to a

known term t through the crawling property p.

SELECT distinct ?item

WHERE { ?item p <t> }

Figure 1: Template of the SPARQL query to obtain a

subset of the crawling results.

Notice that, for the properties owl:sameAs and

rdfs:seeAlso, the crawler also uses the template

query of Figure 2. For each term t to be crawled, it

inverts the role of t, as shown in Figure 2, when the

predicate p is

owl:sameAs and rdfs:seeAlso,

since these predicates are reflexive and it is reasona-

ble that the description of the term itself will be

explained in that order. However, the crawler does

not invert the role of t when the predicate p is

rdfs:subClassOf, since this predicate is not re-

flexive.

SELECT distinct ?item

WHERE { <t> p ?item }

Figure 2: Template of the inverted SPARQL query.

In the specific case of the crawling property

rdfs:subClassOf, suppose that C and C’ are clas-

ses defined in triplesets S and S’, respectively, and

assume that C’ is declared as a subclass of C through

a triple of the form

(C’,

rdfs:subClassOf, C)

Triples such as this are more likely to be included in

the tripleset where the more specific class C’ is de-

fined than in the tripleset where the more generic

class C is defined. Hence, after finding a class C, the

crawler has to search for subclasses of C in all tri-

plesets it has access using the template of Figure 1.

Another case occurs when the relationship be-

tween C and C’ is defined in a third schema S”.

Similarly to the previous example, we need a sub-

class query over S” to discover this relationship

between C and C’. S’’ is obtained by dereferencing

the URI of C’. In most cases the returned tripleset is

the complete ontology where C’ is defined, while in

some other cases only a fragment of the ontology

where C’ is defined is returned.

Finally, a special type of crawling query is ob-

tained by replacing p in Figure 1 with

rdf:type.

However, in this case, only the overall number of

instances found and the total number of instances for

each tripleset are retrieved and stored in the result

set of the crawling process.

5.2 Crawling Stages

The crawler simulates a breath-first search for new

terms. Stage 0 contains the initial set of terms. The

set of terms of each new stage is computed from

those of the previous stage with the help of the que-

ries and URI dereferencing, as described in Section

5.1, except for

rdf:type, which is used only to

count the number of instances found.

The crawling frontier is the set of terms found

which have not yet been processed. To avoid circu-

lar references, we used a hash map that indicates

which terms have already been processed.

Since the number of terms may grow exponen-

tially from one stage to the next, we prune the search

by limiting:

 The number of stages of the breath-first search

 The maximum number of terms probed

 The maximum number of terms probed in each

tripleset, for each term in the crawling frontier

 The maximum number of terms probed for each

term in the crawling frontier

For each new term found, the crawler creates a

list that indicates the provenance of the term: how

the term is direct or transitively related to an initial

term and in which tripleset(s) it was found. That is,

the crawler identifies the sequence of relationships it

traversed to reach a term, such as in the following

example:

wordnet:synset-music-noun-1 ->

owl:sameAs ->

OpenCyc:Music -> rdfs:subClassOf ->

OpenCyc:LoveSong -> instance ->

500 instances.

5.3 Using VoID to Extract More

Information about Triplesets

The crawler will eventually collect a large number

of terms and count the number of instances of a

reasonable number of classes, declared in many

triplesets. These data can be used to extract more

metadata about a tripleset by parsing its VoID de-

scription, as follows.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

492

For each tripleset t in the catalogues the crawler

uses, if t has a VoID description V, the crawler re-

trieves all objects o from triples of the form

(s,

void:class, o) declared in V. The resources

retrieved are compared to all resources the crawler

already located. Each new resource found is saved

and returned as part of the final output of the entire

crawling operation, with an indication that it is also

related to tripleset t through a VoID description.

Although the crawling process has limiting pa-

rameters to avoid time-consuming tasks, the pro-

cessing of VoID descriptions is simple enough and

is, therefore, not subjected to limitations.

6 TESTS AND RESULTS

6.1 Organization of the Experiments

We evaluated the crawler over triplesets described in

Datahub.io. The tool was able to recover 317 triple-

sets with SPARQL endpoints. But, despite this num-

ber, it could run queries on just over half of the tri-

plesets due to errors in the query parser or simply

because the servers were not available.

To execute the tests, we separated three set of

terms related to the music and publications applica-

tion domains. In both cases, we focused on three

generic ontologies to create the initial crawling

terms, WordNet, DBpedia and Schema.org.

WordNet is a lexical database that presents dif-

ferent meanings for the same word. For example, the

term

wordnet:synset-music-noun-1 means “an

artistic form of auditory communication incorporat-

ing instrumental or vocal tones in a structured and

continuous manner”. In addition, the term

word-

net:synset-music-noun-2 is defined as “any

agreeable (pleasing and harmonious) sounds; "he fell

asleep to the music of the wind chimes"”. Both are

music, but have different meanings.

DBpedia is the triplified version of the Wikipe-

dia database. The triplification process is automati-

cally accomplished and the current English version

already has 2.5 million classified items.

Schema.org is the most recent ontology of all

three. It focuses on HTML semantics and was creat-

ed by Google, Bing and Yahoo. Therefore, Sche-

ma.org is now used by many triplesets

. Schema.org

is also developing other ways to increase the search

results by creating a mapping with other ontologies,

such as DBpedia and WordNet.

We elected these three ontologies as the most

http://schema.rdfs.org/mappings.html

generic ones. All three have a collection of terms

that covers numerous domains and could be used

together to determine an initial set that represents the

user intentions. Of course, if a user has good

knowledge about a domain, he can adopt more spe-

cific ontologies to determine the initial crawling

terms. In the examples that follow, we use the ab-

breviations shown in Table 1.

Table 1: Namespace abbreviation.

Abbreviation Namespace

akt

http://www.aktors.org/ontology/portal#

bbcMusic

http://linkeddata.uriburner.com/about/id/entity/http/w

ww.bbc.co.uk/music/

dbpedia

http://dbpedia.org/resource/

dbtune

http://dbtune.org/

freebase

http://freebase.com/

freedesktop

http://freedesktop.org/standards/xesam/1.0/core#

lastfm

http://linkeddata.uriburner.com/about/id/entity/http/w

ww.last.fm/music/

http://purl.org/ontology/mo/

musicBrainz

http://dbtune.org/musicbrainz/

nerdeurocom

http://nerd.eurecom.fr/ontology#

opencyc

http://sw.opencyc.org/2009/04/07/concept/en/

schema

http://schema.org/

twitter

http://linkeddata.uriburner.com/about/id/entity/http/tw

itter.com/

umbel

http://umbel.org/

wordnet

http://wordnet.rkbexplorer.com/id/

yago

http://yago-knowledge/resource/

6.2 Results

The experiments involved two domains, Music and

Publications, and used the following parameters:

 Number of stages: 2

 Maximum number of terms probed: 40

 Maximum number of terms probed for each term

in the crawling frontier: 20

 Maximum number of terms probed in each triple-

set, for each term in the crawling frontier: 10

Music Domain. We chose Music as the first domain

to evaluate the crawler and elected three ontologies,

DBpedia, WordNet and Music Ontology

, to select

the initial crawling terms. The Music Ontology is a

widely accepted ontology that describes music, al-

bums, artists, shows and some specific subjects.

The initial crawling terms were:

mo:MusicArtist

mo:MusicalWork

http://musicontology.com/

AMetadataFocusedCrawlerforLinkedData

493

mo:Composition

dbpedia:MusicalWork

dbpedia:Song

dbpedia:Album

dbpedia:MusicalArtist

dbpedia:Single

wordnet:synset-music-noun-1

Table 2: Related Terms.

Related terms

Query type Description

(a) Related terms for mo:MusicArtist

subclass

mo:MusicGroup

mo:SoloMusicArtist

instance

103,541 instances, mostly from

lastfm

(b) Related terms for mo:MusicalWork

subclass

mo:Movement

instance 16,833 instances found in multiple data-

bases like dbtune and academic music

databases

subclass

dbpedia:Album

dbpedia:Song

dbpedia:Single

dbpedia:Opera

dbpedia:ArtistDiscography

and 21,413 classes from yago

sameAs

dbpedia:MusicGenre

umbel:MusicalComposition

seeAlso

lastfm:Syfin

lastfm:Kipling

lastfm:Pandemic

lastfm:Ardcore

lastfm:Lysis

lastfm:Freakhouse

lastfm:Saramah

lastfm:Akouphen

lastfm:Freakazoids

lastfm:Cyrenic

lastfm:Phender

twitter:Ariadne_bullet

instance 145,656 instances

(d) Related terms for dbpedia:Song

Own URL

dbpe-

dia:EurovisionSongContestEntry

sameAs

schema:MusicRecording

subclass

dbpe-

dia:EurovisionSongContestEntry

seeAlso

lastfm:Apogee

lastfm:Brahman

lastfm:Anatakikou

lastfm:Sakerock

lastfm:8otto

lastfm:Cro-Magon

lastfm:Ladz

Plus 7 lastfm resources in Japanese

instance 10,987 instances from multiple language

versions of

dbpedia, lastfm and others

Table 2: Related Terms. (Cont.)

(e) Related terms for

dbpedia:Album

Own URL

freebase:en.Album

opencyc:Album

subclass

nerdeurocom:Album

and 17,222 subclasses, mostly from yago

sameAs

schema:MusicAlbum

freebase:en.Album

dbpedia:Sophomore_Album

and some dbpedia:Album classes from

other Wikipedia languages

instance 100,090 instances from multiple language

versions of

dbpedia and others

(f) Related terms for dbpedia:MusicalArtist

seeAlso

lastfm:Krackhead

sameAs

dbpedia:Musician

umbel:MusicalPerformer

subclass

dbpedia:Instrumentalist

dbpedia:BackScene

and 2,178 subclasses from yago

instance 49,973 instances from multiple language

versions of dbpedia

(g) Related terms for dbpedia:Single

seeAlso

last.fm:Toxin

last.fm:Dethrone

last.fm:Burdeos

last.fm:Sylence

twitter:joint_popo

last.fm:Toximia

last.fm:Alcoholokaust

last.fm:Electromatic

last.fm:Mighty+Atomics

subclass

3,414 subclasses, the majority from

yago

instance 44,623 instances

In what follows, we will first comment on the results

obtained in Stage 1, for each initial term. Then, we

will proceed to discuss how the new terms obtained

in Stage 1 were processed in Stage 2.

Table 2(a) shows the results of Stage 1 for

mo:MusicalArtist. On Stage 2, for each of the

terms

mo:MusicGroup and mo:SoloMusicArtist

the crawler obtained

similar results: nearly 2,000

resources were found in

bbcMusic and mu-

sicBrainz:data

, which are large databases about

the music domain; and the seeAlso query pointed to

an artist,

lastfm:Hadas. As seeAlso provides addi-

tional data about the subject, we speculate that the

result the crawler returned represents a mistake

made by the database creator.

Table 2(b) shows the results of Stage 1 for

mo:MusicalWork. Note that the crawler found a

variety of instances from multiple databases, mainly

on universities. On Stage 2, when processing

mo:Movement, the crawler found a seeAlso refer-

ence to

lastfm:Altmodisch.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

494

On Stage 1, when processing mo:Composition,

the crawler found 13 instances, but no related terms.

Table 2(c) shows the results of Stage 1 for the

first DBpedia term,

dbpedia:MusicalWork. The

crawler found 5 subclasses from DBpedia and more

than 20 thousand subclasses from the

yago tripleset.

This unusual result is due to the segmentation used

yago. For example, there are subclasses for seg-

menting records by artist, by historical period, and

even by both.

The first three terms,

dbpedia:Album, dbpe-

dia:Song

and dbpedia:Single, will be ana-

lyzed in the next paragraphs since they are also in

the initial set of terms.

On Stage 2, the processing of

dbpedia:Opera

returned no results and the processing of

dbpe-

dia:ArtistDiscography returned 3,423 instanc-

es, but no new term. The processing of

um-

bel:MusicalComposition returned 1809 instanc-

es and

dbpedia:MusicGenre retrieved 7,808 new

instances.

Table 2(d) shows the results of Stage 1 for

dbpedia:Song. The crawler found the most diver-

sified results in terms of query types and query re-

sults. It was able to identify resources in different

languages (such as Portuguese and Greek), which

was only possible because it focused on metadata.

Crawlers that use text fields (Nikolov and d'Aquin,

2011) can only retrieve data in the same language as

that of initial terms.

On Stage 2, when processing

dbpe-

dia:EurovisionSongContestEntry

, the crawler

obtained three subclasses from

yago, a sameAs rela-

tionship with

schema:MusicRecording and found

the same result of

dbpedia:Song for the seeAlso

property. The other resource probed on the Stage 2

was

schema:MusicRecording which returned no

instances or new crawling terms.

Table 2(e) shows the results of Stage 1 for

dbpedia:Album. The processing of this term also

produced an interesting result. The sameAs query

found a small number unique relationships, but

found some

dbpedia:Album in other languages.

One may highlight the

opencyc:Album class, for

which the crawler was able to find 245 instances.

Table 2(f) shows the results of Stage 1 for

dbpe-

dia:MusicalArtist. The processing of this term

exhibited results similar to those obtained by pro-

cessing

dbpedia:Album, in terms of quantity of

subclasses. Therefore, it was possible to recover

results in multiple languages.

On Stage 2, when processing

dbpe-

dia:Musician, the crawler found over 163 sameAs

terms, the majority of them pointing to DBpedia in

other languages (even in non-latin alphabets). On the

other hand, the seeAlso query found over 50 terms,

but none of them seems related to the subject. When

processing

umbel:MusicalPerformer, the crawl-

er retrieved one subclass,

umbel:Rapper, and over

6,755 instances from a variety of triplesets.

Table 2(g) shows the results of Stage 1 for

dbpedia:Single. As for other resources from

DBpedia, the crawler was able to find a large num-

ber of subclasses from

yago tripleset. In addition, it

found more than 40 thousand instances from differ-

ent triplesets in many languages.

The last term probed in Stage 1 was

word-

net:synset-music-noun-1

. The crawler found a

sameAs relationship with an analogue term from

another publisher:

wordnet:synset-music-

noun-1

. On Stage 2, the crawler found a new

sameAs relationship to

opencyc:Music.

Finally, we remark that, when we selected the

terms to evaluate, we expected to find relationships

between DBpedia and Music Ontology, which did

not happened. In addition, we found much better

results using terms from DBpedia than from the

Music Ontology, which is specific to the domain in

question. The definition of links between the Music

Ontology and DBpedia could increase the popularity

of the former. For example, if the term

mo:MusicArtist were related to the term dbpe-

dia:MusicalArtist, crawlers such as ours would

be able to identify the relationship. Also, matching

or recommendation tools would benefit from such

relationship.

Publications Domain. For the second domain,

we focused on two ontologies, Schema.org and

Aktors

, which is commonly used by publications

databases. We selected the following terms:

schema:TechArticle

schema:ScholarlyArticle

akt:Article-Reference

akt:Article-In-A-Composite-Publication

akt:Book, akt:Thesis-Reference

akt:Periodical-Publication

akt:Lecturer-In-Academia

akt:Journal

The results were quite simple. While the queries

based on Schema.org practically returned no results,

queries on Aktors returned enough instances, but

with no complex structure. A quick analysis showed

that almost all triplesets were obtained from popular

publications databases (such as DBLP, IEEE and

ACM) by the same provider (RKBExplorer), which

http://www.aktors.org

AMetadataFocusedCrawlerforLinkedData

495

used the Aktors ontology. In addition, the Aktors

ontology is not linked to other ontologies, which

lead to an almost independent cluster in the Linked

Data cloud.

The VoID processing, as discussed in Section

5.3, was not able to find any new information. In

fact, in a more detailed analysis, it was clear that

VoID seems to be a neglected feature. From the

initial 317 triplesets, only 102 had the VoID descrip-

tion stored in Datahub.io, and only 8 had any triple

with the property

void:class (which were not

related to our test domains).

Processing times. Table 3 shows the processing

time for each experiment. In general, the time spent

to process each term was direct related to the num-

ber of terms found (some exceptions apply due to

bandwidth issues).

Table 3 shows that the minimum time was 14

minutes, when no new terms were found, but the

maximum time depended on the number of new

terms in the crawling frontier and how the network

(and the endpoints) responded.

Finally, we observe that the processing time can

be optimized, provided that: (1) the endpoints que-

ries have lower latency; (2) the available bandwidth

is stable across the entire test; (4) cache features are

used; (3) queries are optimized to reduce the number

of requests.

Table 3: Performance evaluation.

Term Proc. time

(minutes)

Music domain

mo:MusicArtist

mo:MusicalWork

mo:Composition

dbpedia:MusicalWork

183

dbpedia:Song

163

dbpedia:Album

173

dbpedia:MusicalArtist

167

dbpedia:Single

186

wordnet:synset-music-noun-1

Publications domain

schema:TechArticle

schema:ScholarlyArticle

akt:Article-Reference

akt:Article-In-A-Composite-

Publication

akt:Book

akt:Thesis-Reference

akt:Periodical-Publication

akt:Lecturer-In-Academia

akt:Journal

6.3 A Comparison with Swget

We opted for a direct comparison between the pro-

posed crawler and swget for three reasons. First,

there is no benchmark available to test Linked Data

crawlers such as ours and it is nearly impossible to

manually produce one such (extensive) benchmark.

Second, swget is the most recent crawler available

online. Third, it was fairly simple to setup an exper-

iment for swget similar to that described in Section

6.2 for the Music domain.

Briefly, the experiment with swget was executed

as follows. Based on the examples available at the

swget Web site, we created the following template to

run queries (where t’ is the term to be probed and q’

the current crawling property):

t’ -p <q’> <2-2>

The above query means “given a term t’, find all

resources related to it using the predicate q’ expand-

ing two levels recursively.

Then, we collected all terms swget found from

the same initial terms of the Music domain used in

Section 6.2, specifying which crawled property

swget should follow. Table 4 shows the number of

terms swget found, for each term and crawling prop-

erty.

Table 4: Number of terms found using swget.

Term

subclas

sameA

seeAlso type

mo:MusicArtist

4 0 0 3

mo:MusicalWork

7 0 0 3

mo:Composition

0 0 0 3

dbpedia:MusicalWork

16 1 0 3

dbpedia:Song

6 1 0 3

dbpedia:Album

6 1 0 3

dbpedia:MusicalArtist

9 1 0 3

dbpedia:Single

6 1 0 3

Based on the experiments with swget and the crawl-

er, we compiled the list of terms shown in Table 5 of

Annex 2. We excluded the terms retrieved from

yago to avoid unbalancing the experiment in favor

of the crawler. Then, we manually inspected the

terms and marked, in Table 5, those that pertain to

the Music domain and those that swget and the pro-

posed crawler found.

The results detailed in Annex 2 can be summa-

rized by computing the precision and recall obtained

by swget and our crawler for the list of terms shown

in Table 5:

 swget: precision = 35% recall = 24%

 crawler: precision = 95% recall = 91%

These results should be interpreted as follows.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

496

Swget achieved a much lower precision since it finds

more generic and more specific terms at the same

time, while our crawler only searches for the more

specific terms. This feature creates undesirable re-

sults for the purposes of focusing on an application

domain. For example, using

rdfs:subClassOf as

predicate and

dbpedia:MusicalWork as object,

swget returned

dbpedia:Work, a superclass at the

first level. At the next stage, swget then found re-

sources such as

dbpedia:Software and dbpe-

dia:Film, each of them subclasses of dbpe-

dia:Work

, but unrelated to the Music domain.

The crawler achieved a better recall since, in

part, it was able to, given two classes defined in

different triplesets, uncover relationships between

the classes described in a third tripleset. Indeed,

swget processed

umbel:MusicalPerformer using

properties

rdfs:subClassOf and owl:sameAs.

Our expectation was that it would be able to find the

class

dbpedia:MusicalWork, as our crawler was,

which did not happen. A quick analysis showed that

the relationship between both classes was not de-

scribed in any of the original triplesets, but in a third

tripleset,

http://linkeddata.uriburner.com/.

This behavior should not be regarded as defect of

swget, though, but a consequence of working with a

general purpose crawler, rather than a metadata fo-

cused crawler, such as ours.

6.4 Lessons Learned

In this section, we highlight the main lessons learned

from the results of our experiments.

We first enumerate some aspects that may influ-

ence the crawling results, such as the settings of the

parameters and the availability of sufficient infor-

mation about the crawled triplesets.

Parameter setting. Since, in our crawler, the set

of terms of each new stage is computed from that of

the previous stage, the number of terms may grow

exponentially. We defined some parameters to prune

the search. Hence, the user must adequately set such

parameters to obtain results in reasonable time,

without losing essential information.

Choosing the initial crawling terms. In the Music

domain experiments, we started with terms from

three different triplesets, DBpedia, WordNet and

Music Ontology, the first two being more generic

than the last one. It seems that the resources defined

in the Music Ontology are not interlinked (directly

or indirectly) with the more popular triplesets. This

limitation is related to the fact that some triplesets do

not adequately follow the Linked Data principles, in

the sense that they do not interlink their resources

with resources defined in other relevant triplesets.

Ontologies describing the domain of interest.

Our crawler proved to return more useful when there

are relationships among the metadata. In the experi-

ments using the publications domain, our crawler

returned a simplified result because all triplesets

related to the initial crawling terms used the same

ontology to describe their resources. In general, the

larger the number of triplesets in the domain, the

more useful the results of our crawler will be.

VoID description. The VoID processing seems to

be an adequate solution to a faster access to tripleset

information. Despite the VoID expressivity, most

triplesets used in our experiments had a simplistic

VoID description available. Hence, our crawler

hardly found new data using the VoID descriptions.

We now highlight some improvements obtained

by our metadata focused crawler, when compared to

traditional crawlers.

Discovering relationships between resources of

two triplesets described in a third one. Using our

crawler, we found cases in which a relationship be-

tween two resources r and r’, respectively defined in

triplesets d and d’, was described in another tripleset

d”. This happens, for example, when the ontologies

used by d and d’ are only stored in a different dataset

d”. In these cases, it was necessary to crawl all tri-

plesets, other than d and d’, to find the relationship

between r and r’. A traditional crawler following

links from d would not find any link between r and

r’ because it is only declared in d”.

Crawling with SPARQL queries. Our crawler re-

turns richer metadata than a traditional crawler since

it uses SPARQL queries, executed over all triplesets.

In particular, our crawler discovers not only the links

between resources, but also the number of instances

related to the crawling terms.

Identifying resources in different languages and

alphabets. Our crawler was able to identify re-

sources in different languages, even in different

alphabets, through the sameAs and seeAlso

queries.

Performing simple deductions. Using the prove-

nance lists the crawler generates, one may perform

simple deductions, using the transitivity of the sub-

class property, perhaps combined with the sameAs

relationship. For example, suppose that the crawler

discovered that

opencyc:Hit_music is a subclass

opencyc:Music, which in turn has a sameAs

relationship with

wordnet:synset-music-noun-

1. Then, one may deduce that open-

cyc:Hit_music is a subclass of word-

net:synset-music-noun-1

AMetadataFocusedCrawlerforLinkedData

497

7 CONCLUSIONS AND FUTURE

WORK

This paper presented a metadata focused crawler for

Linked Data. The crawler starts with a small set T of

generic RDF terms and enriches T by identifying

subclasses, equivalences (

sameAs property) and

related terms (

seeAlso property).

In general, the metadata focused crawler intro-

duced in this paper helps simplify the triplification

and linkage processes, thereby contributing to the

dissemination of Linked Data. Indeed, the results of

the crawler may be used: to recommend ontologies

to be adopted in the triplification process; to recom-

mend triplesets to be used in the linkage process;

and to increase the quality of VoID descriptions.

Finally, the overall crawling process is open to

several improvements. For example, we may use

summarization techniques to automatically select the

initial set of terms. We may also optimize the crawl-

ing process by combining the crawling queries into a

single query and by using caching to avoid band-

width issues.

ACKNOWLEDGEMENTS

This work was partly funded by CNPq, under grants

160326/2012-5, 303332/2013-1 and 57128/2009-9,

and by FAPERJ, under Grants E-26/170028/2008

and E-26/103.070/2011.

REFERENCES

Alexander, K. Cyganiak, R., Hausenblas, M., Zhao, J.,

2009. Describing linked datasets - on the design and

usage of void, the ‘vocabulary of interlinked datasets’.

Proc. Workshop on Linked Data on the Web

(LDOW’09), Madrid, Spain.

Bizer, C., Heath, T, Berners-Lee, T., 2009. Linked Data -

The Story So Far, Int’l. Journal on Semantic Web and

Info. Sys., 5 (3), pp. 1-22.

Brickley, D., Guha, R.V. (eds.), 2004. RDF Vocabulary

Description Language 1.0: RDF Schema. W3C Rec-

ommendation 10 February 2004.

Ding, l., Pan, R., Finin, T., Joshi, A., Peng, y., Kolari, P.,

2005. Finding and ranking knowledge on the semantic

web. Proc. 4th Int’l. Conf. on the Semantic Web,

Springer-Verlag, pp. 156-170.

Fionda, V., Gutierrez, C., Pirró, G., 2012. Semantic navi-

gation on the web of data: specification of routes, web

fragments and actions. Proc. 21st Int’l. Conf. on

World Wide Web, pp. 281-290.

Isele, R., Harth, A., Umbrich, J., Bizer, C., 2010. LDspi-

der: An open-source crawling framework for the Web

of Linked Data. Proc. Int’l. Semantic Web Conf.

(Posters), Shanghai, China.

Leme, L.A.P.P., Lopes, G.R., Nunes, B.P., Casanova,

M.A., Dietze, S., 2013. Identifying candidate datasets

for data interlinking. Proc. 13th Int’l. Conf. on Web

Engineering, Aalborg, Denmark (July 8-12, 2013), pp.

354-366.

Lopes, G.R., Leme, L.A.P.P., Nunes, B.P., Casanova,

M.A., Dietze, S., 2013. Recommending Tripleset In-

terlinking through a Social Network Approach. Proc.

14th Int’l. Conf. on Web Information System Engi-

neering, Nanjing, China (Oct. 13-15, 2013), pp. 149-

161.

Manola, F., Miller, E., 2004. RDF Primer, W3C Recom-

mendation 10 February 2014.

Martínez-Romero, M., Vázquez-Naya, J., Munteanu, C.,

Pereira, J., Pazos, A., 2010. An approach for the auto-

matic recommendation of ontologies using collabora-

tive knowledge. Proc. 14th Int’l. Conf. on Knowledge-

based and Intelligent Information and Engineering

Systems, Part II, Springer, pp. 74-81.

Nikolov, A., d'Aquin, M., 2011. Identifying Relevant

Sources for Data Linking using a Semantic Web In-

dex. Proc. Workshop on Linked Data on the Web.

Volume 813 of CEUR Workshop Proceedings, CEUR-

WS.org.

Nikolov, A., d'Aquin, M., Motta, E., 2012. What should I

link to? Identifying relevant sources and classes for

data linking. Proc. Joint Int’l. Semantic Technology

Conference, pp. 284-299.

Prud’hommeaux, E., Seaborne, A., 2008. SPARQL Query

Language for RDF, W3C Recommendation 15 January

2009.

Saint-Paul, R., Raschia, G., Mouaddib, N., 2005. General

purpose database summarization. Proc. 31st Int’l.

Conf. on Very Large Data Bases. VLDB Endowment,

pp. 733-744.

W3C OWL Working Group, 2012. OWL 2 Web Ontology

Language Document Overview (Second Edition).

W3C Recommendation 11 December 2012.

Wang, J., Wen, J., Lochovsky, F., Ma, W., 2004. Instance-

based schema matching for web databases by domain-

specific query probing. Proc. 30th Int’l. Conf. on Very

Large Data Bases. Vol. 30. VLDB Endowment, pp.

408-419.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

498

APPENDIX

1 Crawler Pseudo-code

enericCrawlingQuery(d, S, t, p; R);

input: d - direction of the query (“direct” or “reverse”)

S - a SPARQL Endpoint or a RDF Dump to be queried

t - a crawling term

p - a predicate

output: R - a set of terms crawled from t

begin

if d == “direct”

then R := execute SELECT distinct ?item WHERE { ?item p <t> } over S

else R := execute SELECT distinct ?item WHERE { <t> p ?item } over S

return R;

end

CRAWLER(maxLevels, maxTerms, maxFromTerm, maxFromSet; T, C; Q, P, D)

Parameters: maxLevels - maximum number of levels of the breath-first search

maxTerms - maximum number of terms probed

maxFromTerm - maximum number of new terms probed from each term

maxFromSet - maximum number of terms probed from a tripleset, for each term

input: T - a set of input terms

C - a list of catalogues of triplesets

output: Q - a queue with the terms that were crawled

P - a provenance list for the terms in Q

D - a provenance list of the triplesets with terms in Q

begin Q, P, D := empty;

#levels, #terms := 0;

nextLevel := T

;

while #levels < maxLevels and #terms < maxTerms do

begin

#levels := #levels + 1;

currentLevel := nextLevel; /* currentLevel and nextLevel are queues of terms */

nextLevel := empty;

for each t from currentLevel do

begin

add t to Q;

/* crawling by dereferencing */

S := downloaded RDF content obtained by dereferencing t;

R1 := empty;

for each predicate p in { rdfs:subClassOf,owl:sameAs,rdfs:seeAlso } do

begin

if p == “rdfs:subClassOf” then d := “direct” else d := “inverse”;

genericCrawlingQuery( d, S, t, p; RTEMP );

if (RTEMP not empty)

then begin add (t, p, RTEMP, S) to P;

R1 := concatenate(R1, RTEMP);

end

/* crawling by direct querying the triplesets in C */

R2 := empty;

for each tripleset S from the catalogues in C do

begin

RS := empty;

for each predicate p in { rdfs:subClassOf,owl:sameAs,rdfs:seeAlso } do

begin

genericCrawlingQuery( “direct”, S, t, p; RTEMP );

if (RTEMP not empty)

then begin add (t, p, RTEMP, S) to P;

RS := concatenate(RS, RTEMP);

end

if (RS not empty)

then begin add (t, S) to D;

truncate RS to contain just the first maxFromSet terms;

R2 := concatenate(R2, RS);

end

RT := concatenate(R1, R2)

for each u in RT do

begin

#termsFromTerm := #termsFromTerm

+1;

#terms := #terms +1;

if ( #termsFromTerm > maxFromTerm or #terms > maxTerms ) then exit;

add u to nextLevel;

end

return Q, P, D;

end

AMetadataFocusedCrawlerforLinkedData

499

2 A Comparison Between Swget and the Proposed Crawler for the Music Domain

Terms retrieved by swget or crawler MV SW RC

(Terms retrieved by swget)

dbpedia:MusicalWork - - -

1 dbpedia:Song Y Y Y

2 dbpedia:Single Y Y Y

3 dbpedia:Album Y Y Y

4 dbpedia:Work N Y N

5 dbpedia:ArtistDiscography Y Y Y

6 dbpedia:Opera Y Y Y

7 dbpedia:EurovisionSongContestEntry Y Y Y

8 owl:Thing N Y N

9 dbpedia:Software N Y N

10 dbpedia:RadioProgram N Y N

11 dbpedia:Cartoon N Y N

12 dbpedia:TelevisionSeason N Y N

13 dbpedia:Film N Y N

14 dbpedia:Website N Y N

15 dbpedia:CollectionOfValuables N Y N

16 dbpedia:WrittenWork N Y N

17 dbpedia:Musical Y Y N

18 dbpedia:Artwork N Y N

19 dbpedia:LineOfFashion N Y N

20 dbpedia:TelevisionShow N Y N

21 dbpedia:TelevisionEpisode N Y N

22 dbpedia:Song Y Y Y

23 dbpedia:Single Y Y Y

dbpedia:MusicalArtist - - -

24 dbpedia:Artist N Y N

25 schema:MusicGroup Y Y N

26 dbpedia:Sculptor N Y N

27 dbpedia:Painter N Y N

28 dbpedia:Actor N Y N

29 dbpedia:ComicsCreator N Y N

30 dbpedia:Comedian N Y N

31 dbpedia:FashionDesigner N Y N

32 dbpedia:Writer N Y N

33 dbpedia:Person N Y N

dbpedia:Song - - -

(No new term retrieved swget)

dbpedia:Album - - -

(No new term retrieved swget)

dbpedia:Single - - -

(No new term retrieved swget)

mo:MusicArtist - - -

34 mo:SoloMusicArtist Y Y Y

35 foaf:Agent Y Y N

36 mo:MusicGroup Y Y Y

37 foaf:Person Y Y N

38 foaf:Organization Y Y N

mo:MusicalWork - - -

39 mo:Movement Y Y Y

40 frbr:Work N Y N

41 frbr:ScholarlyWork N Y N

42 frbr:ClassicalWork N Y N

43 frbr:LegalWork N Y N

44 frbr:LiteraryWork N Y N

45 frbr:Endeavour N Y N

46 wordnet:Work~2 N Y N

mo:Composition - - -

(No term retrieved)

(Terms retrieved only by crawler)

47 umbel:MusicalComposition Y N Y

48 schema:MusicRecording Y N Y

49 freebase:en.Album Y N Y

50 opencyc:Music Y N Y

51 opencyc:Album Y N Y

52 nerdeurocom:Album Y N Y

53 schema:MusicAlbum Y N Y

54 dbpedia:Sophomore_Album Y N Y

55 dbpedia:Musician Y N Y

56 umbel:MusicalPerformer Y N Y

57 umbel:Rapper Y N N

58 dbpedia:Instrumentalist Y N Y

59 dbpedia:BackScene N N Y

60 dbpedia:MusicGenre Y N Y

61 freebase:en.Album Y N Y

36 items from lastfm Y N Y

2 items from twitter N N Y

Notes:

 Column Headers / Values:

“MV” (“Manual Validation”):

o Y = term relevant for the Music domain

o N = term not relevant for the Music domain

“SW” (“Retrieved by swget”) and

“RC” (“Retrieved by the crawler”):

o Y = term retrieved by swget or the crawler

o N = term not retrieved by swget or the crawler

 Terms retrieved by swget or crawler:

Retrieved terms: 99

Relevant terms that were retrieved (identified by “Y”

in column “MV”): 66

 Terms retrieved by swget:

Retrieved terms: 46

Relevant terms that were retrieved (identified by rows

with the pattern (Y,Y,-)): 16

Precision = 16 / 46 = 0.35

Recall = 16 / 66 = 0.24

 Terms retrieved by the crawler:

Retrieved terms: 63

Relevant terms that were retrieved (identified by rows

with the pattern (Y,-,Y)): 60

Precision = 60 /63 = 0.95

Recall = 60/66 = 0.91

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

500
