Norm-based Behavior Modification in Reflex Agents

An Implementation in JAMDER 2.0

Francisco I. S. Cruz, Robert M. Rocha Jr, Emmanuel S. S. Freire and Mariela I. Cortés

GESSI - Grupo de Engenharia de Software e Sistemas Inteligentes, Computer Science Department,

Universidade Estadual do Ceará (UECE), Fortaleza, Ceará, Brazil

Keywords: Normative Simple Reflex Agent, Norms, Framework, Normative Multi-agent Systems.

Abstract: The agent-oriented development is becoming more frequent in the industry and academy. Currently, more

works are turning to the growth of this area. Many frameworks that support the development of Normative

Multi-agent Systems. However, few works deal the impact of norms on individual behavior of the agent. Like

many others, JAMDER 2.0 framework follows this aspect. This paper discusses the modification of the

behavior of simple reactive agent based on impact caused by norms on the JAMDER 2.0 platform. This work

has been collaborating for the extension of this framework, re-establishing the dynamism, which was in its first

version, and giving it support for changing the behavior of simple reactive agent. In addition, new features have

been included in the framework. Among them, an agent that is able to monitor the actions of a set of agents,

evaluating them according to the norms and applying appropriate sanctions to these agents, if available. For

illustrate extension, the Vacuum cleaner world was implement using the extended JAMDER 2.0.

1 INTRODUCTION

The agent-oriented development is becoming more

frequent in the industry and academy (Silva and

Castro, 2002). In order to cope with the heterogeneity

in these systems, governance mechanisms are defined

through a set of norms that must be attended by the

entities in the system. Norms promote modifications

in the agent decision processes and they can

influence in the rational behavior and performance

of the agent. In this sense, a thorough understanding

of the impact of norms on the level of individual

agents is critical in order to deal with the dynamic

aspects of normative multi-agent systems (NMAS).

Similarly to JAMDER (Lopes et al., 2011), so many

frameworks assist agent-oriented development.

However, few research efforts have addressed the impact

of norms on individual agent behaviour (Campos, Freire

and Cortés, 2012). In the JAMDER 2.0 framework the

deontic concepts of norms are contemplated, however,

only the case of goal-oriented agents with plans is

considered. Thus, an adequate mechanism to deal with

norms in the other kinds of intelligent agents is missing.

So, this paper is a contribution in order to provide

support to the implementation of the static aspects of

norms in simple reflex agents.

The paper is structured as follows. Section 2

presents the related work. The concepts related to

normative MAS and the JAMDER 2.0 framework

are detailed in Section 3. Section 4 describes the

proposed framework´s extensions. A case study is

showed in Section 5 and, finally, conclusions and

future work are presented in Section 6.

2 RELATED WORK

A set of frameworks and platforms has been developed

to support the development of MAS´s. In general, these

mechanisms are associated with a programming

language for composing entities and provide an

environment for their execution. Following are some of

the most used frameworks for implementing MAS.

JACK (Jack, 2013) is a framework in Java for

development of MAS. It provides high performance,

and an easy way to be extended to support BDI

agents and specifics requirements of applications.

The language used by JACK is built from Java

language and can be used in the development of BDI

agents and their behavior. However, JACK does not

support the modeling of normative concepts neither

the simple reflex agent and its IDE is not freeware.

The development of JAM (Huber, 2013) was

based on a series of theories and frameworks for

497

Cruz F., Rocha Jr R., Freire E. and Cortés M..

Norm-based Behavior Modiﬁcation in Reﬂex Agents - An Implementation in JAMDER 2.0.

DOI: 10.5220/0004899004970504

In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 497-504

ISBN: 978-989-758-027-7

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

agents based on BDI agents. It allows the

implementation of agents that have plans and goals.

However, JAM does not have development tool,

does not allow implementation of agent role,

organization and the normative concepts.

JADE (Jade, 2013) is framework implemented in

Java language that simplifies the development of

MAS through middleware that complies with the

FIPA specifications and with a set of graphical tools

that support debugging. This framework allows the

implementation of typical elements that compose

MAS. However, it does not have support for

normative concepts and simple reflex agent.

How JADE did not support the implementation of

normative concepts, Rocha Júnior, Freire and Cortés

(2013) proposed its extension, called JAMDER 2.0. This

extension was based on modeling language NorMAS-

ML (Freire et al., 2012). Thus, JAMDER 2.0 besides

supporting the modeling of the typical elements of MAS

along with normative concepts. However, JAMDER 2.0

do not support the modeling of the agent architectures

defined by Russell and Norving (2003) considering the

norms for execute their actions.

Normative Jason (Santos Neto, 2012) is an

extension of Jason framework based on AgentSpeak

Normative language). This framework provides the

implementation of normative agents based in BDI

agents which are able to understand, to follow or to

violate the norms contained in the environment.

However, the language is defined on first-order

logic, the focus of norms is the behavior of agents

and not in other entities that compose normative

MAS, and does not have support to exchange roles

between agents neither the simple reflex agent.

Based on the analysis presented and considering

the need of a framework that enables the

implementation of normative simple reflex agent

together with the entities that compose a MAS,

JAMDER 2.0 is highlighted because (i) It has a

platform on JAVA language, (ii) It has support to

distributed system, (iii) It complies with the FIPA

patterns, (iv) It supports the MAS typical entities

and the normative concepts, and (v) It has graphical

interface and plugins for IDEs.

3 BACKGROUND

3.1 Normative Simple Reflex Agent

The agent architecture purely reflex agents should be

able to quickly respond to changes in the

environment by means of its condition-actions rules.

With this, the agent perceives information about the

state of the environment through sensors and based

on rules in the form “if condition then action”, it

selects the most adequate action for the current

perception. The agent performs the selected action

upon the environment through actuators.

This kind of agent may be inserted into an

environment that has a specified set of norms that

restrict their actions. As defined by Figueiredo and

Silva (2011), the norms are intended to restrict the

behavior of agents applying sanctions when they are

violated or fulfilled.

Therefore, the norms of an environment should

not be able to avoid the execution of certain action,

but rather to penalize or reward an agent if the action

taken by it is prohibited or obligated. Therefore, if

the set of norms defined in the environment is not

considered in the condition-action rules, an agent

can be penalized if it performs a prohibited action.

In order to avoid the violation of the simple

reflex agent architecture, Campos, Freire and Cortés

(2012) propose to consider the information about the

set of norms as an extension of the condition-action

rules. It involves the definition of three different

groups of condition-action rules. Each group is

associated with one deontic concept and considers

the sanctions linked to each norm, that is:

 Obligation Rules Group: specifies the rules

related with the actions that must be performed by the

agents. If an event of environment matches with a rule

in this group, it must necessarily be performed by the

agent;

 Prohibition Rules Group: specifies the rules that

are related with the actions that cannot be performed by

the agent. If an event of environment matches with a

rule in this group, the rule will not be executed by the

agent;

 Permission Rules Group: specifies the rules

related with the actions that can be executed. If an

event of environment matches a rule set out of this

group, it may or may not be executed by the agent.

In the architecture were added two new groups in

the agent´s action selection mechanism, corresponding

to the representation of the information about its

obligations and prohibitions. This approach considers

that if an action is obligated, then the agent must

perform that action only if it is not prohibited. If an

action is prohibited, then the agent must perform

another action, different from the prohibited action,

which is permitted and rational. If there is not an action

that is obligated and prohibited, then the agent must

perform a permitted action which is rational, as would

do a well-designed simple reflex agent in an

environment without norms.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

498

3.2 JAMDER 2.0 Framework

JAMDER 2.0 (Rocha Júnior, Freire and Cortés,

2013) is an extension of JAMDER (JADE to MAS-

ML 2.0 Development Resource) (Lopes et al., 2012)

that incorporates the resources offered at modeling

level by the NorMAS-ML language, including,

specifically, the norms and their properties.

The extension process was characterized by the

mapping between concepts of modeling and

implementation in order to identify which elements

of the conceptual metamodel relating to NorMAS-

ML entities were present in JAMDER. Therefore,

the following set of classes was associated with

JAMDER for representing the normative concepts:

 Norm: For representing the norm entity was

created the class jamder.norms.Norm which defines the

following properties: (i) the identifier, (ii) the norm type,

(iii) the restricted entity, (iv) the context, (v) the action,

(vi) and the list of activation constraints.

 NormResource: A norm is set to restrict the

behavior of a given resource (Freire et al., 2012). The

jamder.norms.NormResource class was created to

represent any case of norm resource if it is: (i) a

structural feature; (ii) a behavioral feature; (iii) an

entity; (iv) a relationship or (v) a message;

 NormAction: The actions linked to the norms

were represented by the main class jamder.norms.

NormAction and two sub-classes: jamder.norms.

AtomicAction and jamder.norms.CompositeAction,

which represent the operation system.

 NormConstraint: The jamder.norms.

NormConstraint class was created to represent the

activation constraints with their respective sub-

classes that include each type of constraint:

jamder.norms.Before, jamder.norms.After, jamder.

norms.Between and jamder.norms.IfConditional. It

is directly linked to class jamder.norms.Date

responsible for setting a date.

Some JAMDER classes were modified to include

the properties defined in the language NorMAS-ML.

We describe these changes as follows:

 The list of norms contextNorms was added in the

jamder.Environment and jamder.Organization classes. It

represents norms whose environment or organization is

defined as context.

 The list of norms restrictNorms was added in the

jamder.Environment, jamder.Organization, jamder.

agents.GenericAgent and jamder.roles.AgentRole

classes. It represents norms whose instances of class is a

restricted entity.

 Finally, the following classes representing

instances of duty, right, and axiom, respectively,

jamder.behavioural.Duty, jamder.behavioural.Right

and jamder.structural.Axiom were removed along with

the jamder.behavioural.DutyRightProperty class. It is

necessary because these concepts are considered

semantically equivalent to the deontic concepts of

permission and obligation in norms and are removed

in NorMAS-ML.

With these changes in some JAMDER classes

and the creation of new classes (defined in the

previous subsection), the JAMDER 2.0 framework

allows the modeling properties and relationships of

entities within a normative multi-agent system.

4 EXTENSION OF JAMDER 2.0

In order to restore the dynamics of the tool

JAMDER 2.0 and, establish when a norm would be

active, it has been required some changes in the code

and the addition of some methods, classes and

relationships between classes.

A norm can be active depending on the execution

of a NormAction (Rocha Jr., Freire and Cortés,

2013) then the Action class (which is a

representation of AgentAction) began to relate with

the NormAction class in order to map when a

NormAction linked to an Action is executed.

Whenever an action is executed (as an event),

Action sends a signal to NormAction.

The Property class (Booch et al., 2000) received

the concept of Java Generics (Oracle, 2013) to make

possible comparisons between properties in the

IfCondition class, that inherits from

NormConstraint, whose function is to abstract the

activation conditions of norms (Rocha Júnior, Freire

and Cortés, 2013). For instantiating a Property, it

should use the following structure:

Property<T> propertyName=new

Property<T>();

Where T must inherit from Comparable class

(Oracle, 2013).

The abstract method isTrue() was added in

NormConstraint class. Its function is to enable the

statement of when a constraint is true and thus

enable verification of time when a norm is active.

This method was implemented in the classes:

IfCondition, Before, After and Between that inherit

from NormConstraint (Rocha Júnior, Freire and

Cortés, 2013).

In the Norm Class methods were added:

 setContext (Object) and setRestrict (Object) -

their function is modify the context and the entity

restricted of a norm, generically, without having to

know which instance of them;

Norm-basedBehaviorModificationinReflexAgents-AnImplementationinJAMDER2.0

499

 getContext () and getRestrict () - it returns an

Object that contains the context and the restricted entity

respectively;

 isActive() - which specifies when the norm is

active or not;

 apply() and disapply() - which switching on/off

a norm from their context and restricted entity (apply

and disapply a norm). These methods are important in

sanctions application since a sanction in JAMDER 2.0

is a norm (Rocha Júnior, Freire and Cortés, 2013);

 isApply() - it indicates if a norm has been

applied.

Through the methods setContext(object) and

getContext(Object), the norm knows the restricted

actions that are in its context. On the other hand, the

methods setRestrict(Object) and getRestrict(Object)

indentify the entities restricted by a norm. In

addition, the methods apply() and disapply() briefs

what norms are active and inactive in the

environment. It is fundamental for the agent

behavior modification because the agent need to

know what norms are restricted it. For instance,

when a new norm is added in an organization and

this norm refers to a specified agent, this norm is

added in the organization and in the agent. With this,

the context and the envolved entities know the

norms that restricts them.

Consequently, where a new norm are added in

environment, these methods ensure that the norm list

of the restrict entities will be update.

The NormResourceProperty class that inherits from

NormResource was created in order to supply a

resource of norm linked to a property. Differently from

NormResource, NormResourceProperty carries the

concept of Generics in Java such as Property class.

In the AgentRole and ReflexAgentRole classes,

the method inicialize(), before disabled, has been

revitalized. This was only possible because of

inclusion of deontic concept in Action class, since an

agent role consists of a set of rights (which become

permission) and duties (which become obligation)

and the deontic concepts of a norm replace them

(Freire et al., 2012).

The Action class receives a NormType as an

attribute in order to abstract the deontic concept in a

condition-action rule and allowing the revitalization of

AgentRole and, changing the reflex agent behavior.

Finally the ReflexAgent class receives methods

containsNorm(Action, NormType) and

containsNormDiferent(Action, NormType) that are

responsible to check if there is any active norm (with the

concept of deontic NormType) whose action is linked to

the same or different Action, respectively. The Figure 1

shows the Reflex Agent Class.

Figure 1: Reflex Agent Class.

4.1 Verification of Norms

The solution to behavior modification comes

through the norm verification, present in

ReflexAgent, before the execution of each action.

This check was made on the action() method, from

Action class. Before the execution of each action it

makes the verification shown in pseudo code below:

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

500

if (There is an active obligation norm

related to the action that will be

executed){

Executes the action independently

of its preconditions.

}else{

if ((there is no other active

obligation norm that is not related to

the action that will be executed) and

(there is no an active prohibiting

norm related to the action that will

be executed)){

Executes the action depending

on preconditions.

}

Thus, the agent always executes an obligation

action if the obligation norm is active. Otherwise, it

checks if other action, other than that it wants execute,

is required by a norm. If so, it checks if the action is

prohibited. Otherwise, it performs the action if their

preconditions are met. If there is other action obligated

by an active norm, it will be executed when the same

verification above is done when its method action() is

executed.

4.2 Monitoring Agent

In order to evaluate the simple reflex agent behavior

modification, it is necessary somehow to monitor its

behavior. Thus, we created a Monitor abstract class

which inherits from GenericAgents and owning the

method percept (Object, Object). This method is called

by tied agent to the monitor when it (tied agent)

executes an action. Thus it becomes possible to monitor

and modify the behavior of simple reflex agent.

The main function of the monitoring agent is (i) to

evaluate if the tied agent fulfillment or violation of a

norm and (ii) to apply related sanctions when necessary.

The monitoring in a normative system requires

an abstraction for the states of a norm. Then the

literature indicates the use of an Augmented

Transition Networks (ATNs) (Modgil et al., 2009).

An ATN is a graph representing the three states a

norm can take. They are INACTIVE, ACTIVE,

COMPLIANCE-OR-INFRINGEMENT.

In order to incorporate this concept into JAMDER

were created ATN classes and ATNState representing

Augmented Transition Networks and their states

respectively. The second is an enumeration of type

String representing the three states mentioned above.

The Monitor class attributes are a set of agents (to be

monitored) and the ATN which are generated by norms

that restrict these agents whenever an agent is added. The

behavior of the monitoring agent is up to the user. This is

important because the literature often differs a lot about

how and when sanctions are to be applied to the agent to

be monitored (Piunti et al., 2010). The Monitor class

(Figure 2) has the following methods:

 getAgents() - that returns the agents being

monitored by the monitor;

 addAgent(String, GenericAgent) - which is used

to add an agent to be monitored;

 addATN(Norm) - add a ATN by means of a norm.

This method is used in apply() method of the Norm

class. When a norm happens to restrict an agent, a

new ATN is created for monitoring this agent;

 removeATN(String) – remove an ATN through

its key. This method is used in disapply() method of

the Norm class. When a norm fails to restrict an

agent, its ATN is removed;

 getAllAtns() - that returns a Hashtable containing

the ATNs linked to norms that restrict the agents

being monitored;

 punish(Norm) - applying punishment (if it exists)

linked to the norm that receives as the parameter;

 reward(Norm) - applying reward (if it exists)

linked to the norm that receives as the parameter.

 percept(Object, Object) - It is an abstract method

and is a implementation of GoF Observer pattern

(Vlissides et al., 1995). When an action is executed,

the agent sends a signal to its monitoring agent

through this method.

5 CASE STUDY

This section shows the use of the JAMDER

extension for implement the normative vacuum

cleaner world. This case study was used by Campos,

Freire and Cortés (2012) to present their approach.

Considering the normative vacuum cleaner world

with only two rooms, where each room can be clean

or dirty, in our experiments the perceived

information of the environment were represented by

the environmental states. In addition, this world has

norms that restrict the agent's behavior for execute

their activities, and is composed by:

Place - an object that is a graph with two vertices.

Those vertices denote the room: roomA e roomB;

 CleanserOrg - an organization that has the

agent roles: management e cleaner. The first role is

linked to manager agent and the other is linked to

VacuumCleaner;

 ManagerAgent - an agent of monitor type that

use the management paper in the CleanserOrg

organization. Its function is to monitor the Vacuum

Cleaner agent and to modify its behavior as the

Norm-basedBehaviorModificationinReflexAgents-AnImplementationinJAMDER2.0

501

environmental norms. Its actions are

ActionMonitorCyclic and ActionMonitorReflex;

 VacuumCleaner - a normative simple reflex

agent that implements the cleaner paper in

CleanserOrg organization. Its actions are Right, Left,

Suck and NextAction.

The behavior of the ManagerAgent (Figure 3) is

denoted for the actions (i) ActionMonitorCyclic, that is

responsible for applying sanction if the agent has not

executed a prohibited action or an obligated action, and

(ii) ActionMonitorReflex, that is responsible for

applying sanction if the agent has executed a prohibited

action or an obligated action.

The Vacuum cleaner (Figure 4) has the actions

Right, Left, Suck e NextAction. The NextAction is

responsible for perceiving the environment and

controlling the preconditions of the others actions:

 Right - its precondition is true if the vacuum

cleaner is in RoomA and it is clean;

 Left - its precondition is true if the vacuum

cleaner is in RoomB and it is clean;

 Suck - its precondition is true if the RoomA

or RoomB is suck.

 NextAction - it is the agent perception core.

This action constantly checks if the room is dirty and

which room is the agent.

The world has the following norms:

 N1: the vacuum cleaner is required to suck the

roomA from 4:00 to 6:00 a.m.;

 N2: the vacuum cleaner cannot suck the

roomA from 1:00 to 3:00 a.m.;

 N3: if vacuum cleaner fulfills the N1 norm, it

wins 3 points;

 N4: if vacuum cleaner fulfills the N2 norm, it

wins 2 points.

In the beginning of each experiment the normative

vacuum cleaner does not know the world configuration

in terms of dirt. We considered that when the world is

without the presence of norms, the measure of

performance evaluation offers the reward of one point

per each square clean (+1) and penalizes with the loss

of one point per each movement (-1). In the case of the

presence of norms in the world, the measure must be

adapted in order to consider the rewards (+points) and

the penalties (-points), which are consequences of the

agent accepting or rejecting some norm.

Figure 2: Monitoring Agent Class.

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

502

Figure 3: ManagerAgent.

Figure 4: VacuumCleaner.

5.1 Experiments

Firstly, the vacuum cleaner is in Normative Vacuum

Cleaner World that only the norm N1 is active.

Table 1 shows the execution of the agent.

Table 1: Running with just the norm N1.

State

Action Score

Where

is it?

State

roomA

State

roomB

roomA Dirty dirty suck 1

roomA Clean dirty right 0

roomB Clean clean suck 1

roomA Clean clean suck 4

roomA Clean clean right 3

roomB Clean clean suck 2

roomA Clean clean right 1

The rows one to three describe the behavior of the

agent in a period in which the norm had not been

activated and the agent was governed by the rules in

the Permission Group. The row four of the table

(shaded) illustrates the behavior of the agent when the

norm N1 was activated. It is noticed that the agent was

rewarded with three points per action during the period,

according with the sanctions associated with the norm

of obligation (N3). In rows five to seven, the norm was

expired and the agent behavior was again governed by

the Permission rules.

After, the vacuum cleaner is in Normative Vacuum

Cleaner World that the norms N1 and N2 are active.

Table 2 shows the execution of the agent.

Table 2: Running with norms N1 and N2.

State

Action Score

Where

is it?

State

roomA

State

roomB

roomA dirty dirty No_op 2

roomA dirty dirty suck 3

roomA clean dirty right 2

roomB clean clean suck 3

roomB clean clean suck 6

roomB clean clean left 8

roomA clean clean right 7

The rows one and six of the table illustrate the

behavior of the agent when the norm N2 was

activated and N1 was deactivated. It is noticed that

the agent was rewarded with two points per action

during the period, according with the sanctions

associated with the norm of prohibition (N4). The

rows two to four describe the behavior of the agent

in a period in which the norms N1 and N2 had not

Norm-basedBehaviorModificationinReflexAgents-AnImplementationinJAMDER2.0

503

been activated and the agent was governed by the

rules in the Permission Group.

The row five of the table illustrates the behavior

of the agent when the norm N1 was activated and

N2 was deactivated. It is noticed that the agent was

rewarded with three points per action during the

period, according with the sanctions associated with

the norm of obligation (N3). In row seven, the norms

N1 and N2 was expired and the agent behavior was

again governed by the Permission rules.

6 CONCLUSION AND FUTURE

WORK

The influence of the norm concepts related to the

reflex agent architectures is essential in order to

improve the performance of the agents executing in

an environment governed by norms. In this context,

this paper presented the extension of JAMDER 2.0

framework through a mapping between the

characteristics of the approach proposes by Campos,

Freire and Cortés (2012) and JAMDER 2.0. In

addition, the monitoring agent was proposed in order

to support the monitoring of the agents. Finally, a

example based on a Normative Vacuum Clear World

has been used to illustrate the use of the extension of

JAMDER 2.0 framework, demonstrating its

applicability and adequacy for developing normative

simple reflex agent in NMAS.

As future work, it is relevant to consider (i) the

automatic code generation from the normative simple

reflex agent, based on extension of JAMDER 2.0

framework proposed in this work and (ii) the new

extension of JAMDER 2.0 is required for that others

agent architecture proposed by Russell and Norvig

(2003) can understand the environmental norms.

REFERENCES

Booch, G., Jacobson, I., and Rumbaugh, J. (2000). Omg

uniﬁed modeling language speciﬁcation. Object

Management Group ed: Object Management Group,

page 1034.

Campos, G. A., Freire, E. S., and Cortés, M. I. (2012). Norm-

based behavior modiﬁcation in reﬂex agents. In:

International Conference on Artiﬁcial Intelligence (ICAI).

Figueiredo, K. and da Silva, V. T. (2011). Norm-ml: A

modeling language to model norms. ICAART (2), edited

by J. Filipe and ALN Fred, pages 232–237.

Freire, E. S. S., Cortés, M. I., Gonçalves, E. J. T., and Lopes,

Y. S. (2012). A Modeling Language for Normative Multi-

Agent Systems. 13th International Workshop on Agent-

Oriented Software Engineering (AOSE@AAMAS),

Valencia (Spain).

Huber, M. J.: JAM Agent. Available at: http://

www.marcush.net/IRS (2013).

JACK Agent Language. Available at: http://

www.agentsoftware.com.au/products/jack/ (2013).

Java Agent Development Framework. Available at:

http://jade.tilab.com/ (2013).

Lopes, Y. S., Gonçalves, E. J. T., Cortés, M. I., and Freire, E.

S. S. Extending jade framework to support different

internal architectures of agents. 9th European Workshop

on Multi-agent Systems (EUMAS2011), Maastricht,

Holland.

Modgil, S., Faci, N., Meneguzzi, F., Oren, N., Miles, S.and

Luck, M. (2009). A framework for monitoring agent-

based normative systems. In Proceedings of The 8th

International Conference on Autonomous Agents and

Multiagent Systems-Volume 1, pages 153–160.

International Foundation for Autonomous Agents and

Multiagent Systems.

ORACLE, editor (2013). Generic types. Access date: 18 Oct.

2013.

Piunti, M., Ricci, A., Boissier, O., H¨ ubner, J. F., et al.

(2010). Programming open systems with agents,

environments and organizations. In: WOA 2010 - 11

Workshop nazionale’Dagli Oggetti agli Agenti’.

Rocha Jr., R. M., Freire, E. S. S., and Cortés, M. I. (2013).

Estendendo o Framework JAMDER para Suporte à

Implementação de Sistemas Multi-Agente Normativos.

In: IX Simpósio Brasileiro de Sistemas de Informação

(SBSI), 2013, João Pessoa, Brasil. Anais do IX Simpósio

Brasileiro de Sistemas de Informação (SBSI).

Russell, S. J. and Norvig, P. (2003). Artificial intelligence: A

modern approach; [the intelligent agent book]. 2. ed.

Prentice Hall series in artificial intelligence. Prentice Hall,

Upper Saddle River, NJ.

Santos Neto, B. F.: Uma abordagem deôntica para o

desenvolvimento de agentes normativos autônomos. Tese

de doutorado. Rio de Janeiro: PUC, Departamento de

Informática (2012), Brasil.

Silva, C. T. L. L., Castro, J. F. B. (2002). Modeling

Organizational Architectural Styles in UML: The Tropos

Case. In: WER02 - V Workshop on Requirements

Engineering, 2002, Valencia, Spain.

Vlissides, J., Helm, R., Johnson, R., and Gamma, E.: Design

patterns: Elements of reusable object-oriented software.

Reading: Addison-Wesley (1995).

ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems

504
