Quantum Probability in Operant Conditioning

Behavioral Uncertainty in Reinforcement Learning

Eduardo Alonso

1,2

and Esther Mondragón

Department of Computer Science, City University London, London EC1V 0HB, U.K.

Centre for Computational and Animal Research Centre, St. Albans AL1 1RQ, U.K.

Keywords: Operant Conditioning, Reinforcement Learning, Uncertainty, Quantum Probability, Classical Probability.

Abstract: An implicit assumption in the study of operant conditioning and reinforcement learning is that behavior is

stochastic, in that it depends on the probability that an outcome follows a response and on how the presence

or absence of the output affects the frequency of the response. In this paper we argue that classical

probability is not the right tool to represent uncertainty operant conditioning and propose an interpretation

of behavioral states in terms of quantum probability instead.

1 INTRODUCTION

Operant conditioning, how animals learn the relation

between their behavior (responses) and its

consequences (outcomes) is explained in reference

to two dimensions, namely, whether the outcome

follows the response and whether the frequency of

the response increases or decreases subsequently

(Skinner, 1938). If the outcome follows the

response, the relation is positive; and negative if it

does not. If the frequency of the response increases,

we call it reinforcement; if it decreases, punishment.

Thus, as illustrated in Fig. 1, there are four

fundamental conditioning procedures:

 Positive reinforcement: The response is

followed by an outcome that is appetitive,

increasing the response frequency. For instance,

food follows pressing a lever.

 Negative reinforcement: The response is not

followed by the outcome, increasing the

response frequency. For instance, pressing the

lever removes an aversive output such as a loud

noise.

 Positive punishment: The response is followed

by the outcome, decreasing the response

frequency. For instance, pressing a lever is

followed by an electric shock.

 Negative punishment: The response is not

followed by the outcome, decreasing the

response frequency. For instance, removing ad

libitum food when pressing the lever.

Figure 1: Operant conditioning procedures.

This interpretation of associative learning has

been borrowed in Artificial Intelligence, in particular

in modeling reinforcement learning, where an agent

learns by interacting with its environment in the

form rewards (Sutton and Barto, 1998). In

reinforcement learning, positive and negative

outputs are defined as scalar rewards. It is assumed

that those behaviors that are predicted to obtain

higher accumulative reward will be elicited more

frequently. One of the main issues in modeling

operant conditioning and reinforcement learning is

to represent the inherent uncertainty animals and

software agents face accurately. In this paper we

present a formalization of uncertainty in terms of

quantum probabilities, which solve some issues that

arise with classical and Bayesian probabilities

typically associated with operant conditioning and

reinforcement learning.

Posi ve

Reinforcement

Nega ve

Reinforcement

Posi ve

Punishment

Nega ve

Punishment

Posi ve

Applies

output

Nega ve

Removes

output

Reinforcement

Increases

frequency

behavior

Punishment

Decreases

frequency

behavior

548

Alonso E. and Mondragon E..

Quantum Probability in Operant Conditioning - Behavioral Uncertainty in Reinforcement Learning.

DOI: 10.5220/0004903205480551

In Proceedings of the 6th International Conference on Agents and Artiﬁcial Intelligence (ICAART-2014), pages 548-551

ISBN: 978-989-758-015-4

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

2 BASIS VECTORS AND

BEHAVIORAL STATE

In quantum probability theory a vector space

(technically, a Hilbert space) represents all possible

outcomes for questions we could ask about a system.

A basis is a set of linearly independent vectors that,

in linear combination, can represent every vector in

the vector space. They represent the coordinate

system and correspond to elementary observations.

Put it another way, the intersection of all subspaces

containing the basis vectors, that is, their linear span,

constitutes the vector space. A vector represents the

state of the system, given by the superposition of the

basis vectors according to their coefficients (Hughes,

1989; Isham, 1989). Historically, quantum

probability has been applied to physical systems but

the same analysis can refer to other types of systems,

including animals and software agents. At the end of

the day, animals are behavior systems –sets of

behaviors that are organized around biological

functions and goals, e.g., feeding (Timberlake and

Silva, 1995), defense (Fanselow, 1994), or sex

(Domjan, 1994). Software agents, on the other hand,

are formally defined as systems that (learn to) act in

virtual environments. Not surprisingly,

reinforcement learning in software agents has taken

concepts and methods from operant conditioning

theory. In turn, the former, software learning agents,

can be understood as computational models of the

latter, operant conditioning.

We define two basis vectors according to the

dichotomies reinforcement vs. punishment and

positive vs. negative in Fig. 1. The former, that we

call Frequency, takes values ranging from a

maximum number of responses per unit time

(Reinforcement) to the absence of response

(Punishment); the latter, that we call Applies, takes

values from “the response always applies the

outcome” (Positive) to “the response always

removes the outcome” (Negative). The values in

between indicate various response frequencies, that

is, probabilities that the animal responds, and

various probabilities that the outcome follows the

response, respectively.

The relation of the two bases is undetermined, in

the sense that even in the simplest reinforcement

schedules (fixed/variable ratio/interval schedules)

we cannot observe with certainty how the response

affects the outcome and how the outcome affects the

frequency of responding at the same time. This

uncertainty is aggravated in more complex

compound schedules.

The problem is thus how to determine the

behavioral state of an animal given this uncertainty.

Several models have been proposed to explain

patterns of operant behavior, some of which use

probabilities (see (Staddon and Cerutti, 2003) for a

recent survey). We argue that the inherent

uncertainty in operant conditioning cannot be

represented using classical probability (Kolmogorov,

1933), and that we need quantum probability

instead.

The behavioral state of the animal is represented

using the state vector, a unit length vector, denoted

as |Ψ in bra-ket notation. We need to find out which

linear combination of the basis vectors results in a

given behavioral state and with which probability.

We start with a single question in Fig. 2, about

whether the response applies the outcome. In this

case |Positive and |Negative are the basis states, so

we can write |Ψ = a|Positive + b|Negative

, where

“a” and “b” are amplitudes (coefficients) that reflect

the components of the state vector along the

different basis vectors. The answer to the question is

certain when the state vector |Ψ exactly coincides

with one basis vector. For instance if “the response

always applies the outcome”, then |Ψ = |Positive.

In such case the probability of Positive is 1. Since

the basis vectors are orthogonal, that is, since they

represent mutually exclusive answers, we know that

“the response removes the outcome” with 0

probability, corresponding to a 0 projection to the

subspace for Negative.

Figure 2: State space with the Applies subspace

(corresponding to the question whether response applies

outcome) and Positive-Negative basis vectors. The blue

vertical line represents the projection of |Ψ on |Positive.

To determine the probability of Positive we use a

projector, P

Positive

, which takes the vector |Ψ and

lays it down on the subspace spanned by |Positive,

that is, P

Positive

|Ψ = a|Positive. Then, the probability

that the response applies the outcome is equal to the

squared length of the projection, ||P

Positive

|Ψ||

. The

same applies to the probability associated with

b|Negative.

Posi ve

Nega ve

(a)

QuantumProbabilityinOperantConditioning-BehavioralUncertaintyinReinforcementLearning

549

3 COMPATIBILITY

In operant conditioning we are interested in two

questions, whether the response applies the outcome,

and whether the response frequency increases, each

with two possible answers: Positive and Negative to

the question “Applies”, and Reinforcement and

Punishment to “Frequency”. Crucially for our

analysis, these questions are incompatible. For

compatible questions, we can specify a joint

probability function for all combinations of answers,

and in such cases the predictions of classical

probability and quantum probability theories are the

same. By contrast, for incompatible questions, it is

impossible to determine the answers concurrently.

Being certain about the answer of one question

induces an indeterminate state regarding the answers

of other, incompatible questions. This is the case in

operant conditioning: We cannot observe at the same

time whether an outcome follows from a response

and whether the response follows from the outcome,

that is, whether the response frequency increases.

Classical probability does not apply to incompatible

questions.

Figure 3: State space including the Frequency subspace

with the Reinforcement (increases)-Punishment

(decreases) basis vectors.

Mathematically, incompatibility means that

subspaces exist at non-orthogonal angles to each

other, as in the sub-spaces in Fig. 3. Hence, since

certainty about a possible answer means that the

state vector is contained within the subspace for the

answer, if we are certain that Applies holds, then the

state vector is aligned with the Positive subspace –in

which case, we can immediately see that we have to

be somewhat uncertain about Frequency.

We use two joint probability cases, namely, the

conjunction fallacy and the commutative property, to

illustrate how quantum probability is applied to our

operant conditioning vector space and how results

differ from a classical treatment.

Suppose that we ask first about frequency and

then whether the response applies the outcome, and

that we denote the answer to the first question as Fr

(a value between Reinforcement and Punishment)

and the answer to the second question as Ap (a value

between Positive and Negative). In quantum

probability theory, a conjunction of incompatible

questions involves projecting first to a subspace

corresponding to an answer for the first question

and, second, to a subspace for the second question

(Busemeyer, Pothos, Franco, and Trueblood, 2011).

The magnitude of a projection depends on the angle

between the corresponding subspaces. When the

angle between subspaces is large a lot of probability

amplitude is lost between successive projections. As

can be seen in Fig. 3, this can result in

||P

|Ψ||

< ||P

|Ψ||

that is, the direct projection to the Applies

subspace (blue line) is less than the projection to the

Applies subspace via the Frequency one (green line).

In classical terms, we have a situation whereby

Prob(Ap) < Prob(Ap & Fr),

which is impossible in classical probability

theory: The probability of two events occurring

together is always less than or equal to the

probability of either one occurring alone. The

opposite, assuming that specific conditions are more

probable than a single general one, is the well-

known conjunction fallacy.

The second case that illustrates that operant

conditioning may be governed by quantum

probabilities, refers to the effect of the order of the

observations. Consider the comparison between first

asking about Fr and then about Ap versus first

asking about Ap and then about Fr. By virtue of the

commutative property, in classical probability theory

the order of conjunction does not alter the result,

hence

Prob(Fr & Ap) = Prob(Ap & Fr).

However, in quantum probability theory P



, and thus, the conjunction of incompatible

questions fails commutativity. We see that

Prob(Fr & Ap) = ||P

|Ψ||

is larger than

Prob(Ap & Fr) = ||P

|Ψ||

because in the second case we project from |Ψ

to |Ap, losing a lot of amplitude (their relative angle

is large), and then from |Ap to |Fr we lose even

more amplitude.

In general, the smaller the angle between the

subspaces for two incompatible questions the greater

Posi ve

Nega ve

(b)

ICAART2014-InternationalConferenceonAgentsandArtificialIntelligence

550

the relation between the answers. We lose little

amplitude by sequentially projecting the state vector

from one subspace to the other. That means that

accepting one answer makes the other very likely –

or, in classical terms, that they are highly correlated.

4 CONCLUSIONS

In this short paper we argue that quantum

probability might be a useful tool in representing

inherent uncertainty in observing (measuring)

behavioral states in operant conditioning and, by

extension, in reinforcement learning. Such states are

defined as the superposition of incompatible basis

vectors and thus cannot be represented using

classical probability –which axioms don’t apply. Our

approach, that borrows ideas from recent proposals

to use quantum probability in categorization (Pothos

& Busemeyer, 2009), addresses long-lasting calls to

formalize operant conditioning in a rigorous way

(e.g., Killeen, 1992). We have kept the formal

aspects of quantum probability to a minimum and

focused on illustrating with a simple example how

quantum probability principles can be used in

operant conditioning and why.

REFERENCES

Busemeyer, J. R., Pothos, E. M., Franco, R. & Trueblood,

J. S. (2011) A quantum theoretical explanation for

probability judgment errors. Psychological Review

118(2):193–218.

Domjan, M. (1994). Formulation of a behavior system for

sexual conditioning. Psychonomic Bulletin & Review,

1, 421-428.

Fanselow, M. S. (1994). Neural organization of the

defensive behavior system responsible for fear.

Psychonomic Bulletin & Review, 1, 429-438.

Hughes, R. I. G. (1989) The structure and interpretation of

quantum mechanics. Harvard University Press.

Isham, C. J. (1989) Lectures on quantum theory. World

Scientific.

Killeen, P. R. (1992). Mechanics of the animate. Journal

of the Experimental Analysis of Behavior, 57, 429-

463.

Kolmogorov, A. N. (1933/1950) Foundations of the theory

of probability. Chelsea Publishing Co.

Pothos, E. M. & Busemeyer, J. R. (2009) A quantum

probability explanation for violations of “rational”

decision theory. Proceedings of the Royal Society B

276:2171–78.

Skinner, B. F. (1938). The behavior of organisms: an

experimental analysis. Oxford, England: Appleton-

Century.

Staddon, J.E., & Cerutti, D. T. (2003). Operant behavior,

Annual Review of Psychology, vol. 54, 115-144.

Sutton, S. R., and Barto, A. G. (1998). Reinforcement

Learning: An Introduction. Cambridge, MA: MIT

Press.

Timberlake, W., & Silva, K. M. (1995). Appetitive

behavior in psychology, ethology, and behavior

systems. In N. Thompson (Ed.), Perspectives in

ethology: Vol. 11. Behavioral design, pp. 212-254.

NY: Plenum.

QuantumProbabilityinOperantConditioning-BehavioralUncertaintyinReinforcementLearning

551
