A Comparison of Three Pre-processing Methods for Improving Main

Content Extraction from Hyperlink Rich Web Documents

Moheb Ghorbani

, Hadi Mohammadzadeh

and Abdolreza Nazemi

Faculty of Engineering, University of Tehran, Tehran, Iran

Institute of Applied Information Processing, University of Ulm, Ulm, Germany

School of Economics and Business Engineering, Karlsruhe Institute of Technology (KIT), Karlsruhe, Germany

Keywords:

Main Content Extraction, Pre-processing Algorithms, Hyperlink Rich Web Documents.

Abstract:

Most HTML web documents on the World Wide Web contain a lot of hyperlinks in the body of main con-

tent area and additional areas. As extraction of the main content of such hyperlink rich web documents is

rather complicated, three simple and language-independent pre-processing main content extraction methods

are addressed in this paper to deal with the hyperlinks for identifying the main content accurately. To evaluate

and compare the presented methods, each of these three methods is combined with a prominent main con-

tent extraction method, called DANAg. The obtained results show that one of the methods delivers a higher

performance in term of effectiveness in comparison with the other two suggested methods.

1 INTRODUCTION

A huge volume of web pages being mainly text is

placed on the web every day. A signiﬁcant proportion

of this data is published in news websites like CNN

and Spiegel as well as information websites such as

Wikipedia and Encyclopedia. Generally speaking, ev-

ery web page of the news/information websites in-

volves a main content (MC) and there is a great in-

terest to extract it at a high accuracy because the MC

can be saved, printed, sent to friends and etc. there-

after.

In spite of the numerous studies which have been

done during the recent decade on extraction of the

MC from the web pages and especially from the news

websites, and although many algorithms with an ac-

ceptable accuracy have been implemented, they have

rarely paid attention to two critical issues, namely

pre-processing and post-processing. Thus, these MC

algorithms were not fully successful in some cases.

Particularly, the MC extraction algorithms have often

failed to extract the MC from the web pages which

contain a great number of hyperlinks like for example

Wikipedia. This paper will introduce and compare

three different methods which can be used for pre-

processing of the MC extraction algorithms based on

HTML source code elements. Each of the three pre-

sented methods is combined with a DANAg (Moham-

madzadeh et al., 2013) algorithm as a pre-processor

in order to be able to compare them with each other.

The obtained results show that one of the suggested

methods is very accurate.

This paper is organized as follows: Section 2

reviews the related work brieﬂy, while the pre-

processing approaches are discussed in Section 3.

The data sets and experiments are explained in Sec-

tion 4, and Section 5 makes some conclusions.

2 RELATED WORK

Algorithms and tools which are implementedfor main

content extraction usually employ an “HTML DOM

tree structure” or “HTML source code elements” or

in simple words HTML tags. Algorithms can also be

divided into three categories based on the HTML tags

including “character and token-based” (Finn et al.,

2001), “block-based” (Kohlsch¨utter et al., 2010), and

“line-based”. Most of these algorithms need to know

whether the characters in an HTML ﬁle are compo-

nents of content characters or non-content characters.

For this purpose, a parser is usually used to recognize

which type of the component they are. Character and

token-based algorithms take an HTML ﬁle as a se-

quence of characters (tokens) which certainly contain

the main content in a part of this sequence. Having

executed the algorithms of this section, a sequence

335

Ghorbani M., Mohammadzadeh H. and Nazemi A..

A Comparison of Three Pre-processing Methods for Improving Main Content Extraction from Hyperlink Rich Web Documents.

DOI: 10.5220/0004947503350339

In Proceedings of the 10th International Conference on Web Information Systems and Technologies (WEBIST-2014), pages 335-339

ISBN: 978-989-758-024-6

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

of characters (tokens) is labeled as the main content

and is provided to the user. BTE (Finn et al., 2001)

and DSC (Pinto et al., 2002) are two of the state-of-

the-art algorithms in this category. Block-based main

content extraction algorithms, e.g. boilerplate detec-

tion using shallow text features (Kohlsch¨utter et al.,

2010), divide an HTML ﬁle into a number of blocks,

and then look for those blocks which contain the main

content. Therefore, the output of these algorithms

is comprised of some blocks which probably con-

tain the main content. Line-based algorithms such

as CETR (Weninger et al., 2010), Density (Moreno

et al., 2009), and DANAg (Mohammadzadeh et al.,

2013), consider each HTML ﬁle as a continuous se-

quence of lines. Taking into account the applied logic,

they introduce those lines of the ﬁle which are ex-

pected to contain the main content. Then, the main

content is extracted and provided to the user from the

selected lines. Most of the main content extraction

algorithms beneﬁt from some simple pre-processing

methods which remove all JavaScript codes, CSS

codes, and comments from an HTML ﬁle (Weninger

et al., 2010) (Moreno et al., 2009) (Mohammadzadeh

et al., 2013)(Gottron, 2008). There are two major rea-

sons for such an observation: (a) they do not directly

contribute to the main text content and (b) they do not

necessarily affect content of the HTML document at

the same position where they are located in the source

code. In addition some algorithms (Mohammadzadeh

et al., 2013) (Weninger et al., 2010) normalize length

of the line and, thus render the approach independent

from the actual line format of the source code.

3 PRE-PROCESSING METHODS

In this section, all kinds of the pre-processing meth-

ods are explained in detail. Hereafter, these meth-

ods are referred to as Filter 1, Filter 2, and Filter

3, for further simplicity. In this contribution, only

the presented pre-processing methods are combined

with one of the line-based algorithms which is called

DANAg (Mohammadzadeh et al., 2013).

3.1 Filter 1

Algorithm 1 shows the simple logic used in Filter 1.

It can be seen that one just needs to remove all the

existing hyperlinks in an HTML ﬁle which is done at

line 4 of this algorithm. The only disadvantage of this

pre-processing method is that by removing the hyper-

links, the anchor texts are also removed. As a result,

this will cause the hyperlinks in the extracted main

content to be lost. Thus, their anchor texts, which

must be seen in the main content, will no longer exist

in the ﬁnal main content. Consequently, the applica-

tion of Filter 1 will reduce either the accuracy or the

amount of recall (Gottron, 2007). In the ACCB algo-

rithm (Gottron, 2008), as an adapted version of CCB,

all the anchor tags are removed from the HTML ﬁles

during the pre-processing stage, i.e. Filter 1.

Algorithm 1: Filter 1.

1: Hyper = {h

, h

, ..., h

}

2: i = 1

3: while i <= n do

4: h

.remove()

5: i = i+1

6: end while

3.2 Filter 2

The idea behind Filter 2 which is shown in Algo-

rithm 2 implies that the all attributes of each anchor

tag are removed. With respect to Algorithm 2, which

shows the pseudocodes of Filter 2, one can understand

that an anchor tag contains only an anchor text.

<a>anchor text</a>

An advantage of Filter 2 over Filter 1 is that some

anchor texts related to the anchor tags, which are lo-

cated in the main content area, can be extracted by us-

ing Filter 2. In other words, the amount of recall (Got-

tron, 2007) yielded from application of Filter 2 would

be greater than the one obtained from Filter 1.

Algorithm 2: Filter 2.

1: Hyper = {h

, h

, ..., h

}

2: i = 1

3: while i <= n do

4: for each attribute of h

5: h

.remove(attribute)

6: end for

7: i = i+ 1

8: end while

3.3 Filter 3

In the third pre-processing method, called Filter 3, all

the HTML hyperlinks are normalized. In other words,

the purpose of this method is to normalize the ratio of

content and code characters representing the hyper-

links. Filter 3 is addressed in the AdDANAg (Mo-

hammadzadeh et al., 2012) algorithm.

For further simpliﬁcation and better compre-

hension, the underlying approach of Filter 3

is described using a typical example. In the

following HTML code, the only attribute is

href="http://www.spiegel.de/"

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

336

<a href="http://www.spiegel.de/">Spiegel Web

Site</a>

Now, length of the anchor text is calculated and

saved for each hyperlink (in this example:

Spiegel

Web Site

) into a variable called length. Then, the

attribute part of the opening tag is substituted with

a string of space characters (

) with a length of

(length− 7) where the value 7 comes from the length

<a></a>

. Therefore, the new hyperlink for this ex-

ample should be as below:

>Spiegel Web Site</a>

The above-mentioned explanations of Filter 3 are

summarized in Algorithm 3. As can be observed in

this algorithm, the

while

loop which is repeated for n

times calculates the length of the anchor text related

to each hyperlink and stores in the LT variable. Then,

a string of LT-7 length is made from the space char-

acter and then is inserted into a string variable “Str”.

Finally, the attribute part of the hyperlink is replaced

with the Str string.

Algorithm 3: Filter 3.

1: Hyper = {h

, h

, ..., h

}

2: i = 1

3: while i <= n do

4: length = Length(h

.anchor text)

5: String Str = new String(“

”, length− 7)

6: substitute(h

.attributes, Str)

7: i = i+ 1

8: end while

4 DATA SETS AND RESULTS

To evaluate all the three pre-processing algorithms,

two suitable data sets are introduced by (Gottron,

2008) and (Mohammadzadeh et al., 2013). Compo-

sition and size of the evaluation data sets are given in

Tables 1 and 2.

The ﬁrst dataset contains 2,166 web documents

in Arabic, Farsi, Pashto, and Urdu and has been col-

lected from 10 different web sites for evaluation of

the main content extraction in right-to-left language

web documents. The second corpus contains 9,101

web pages in English, German, and Italian from 12

different web sites and has been established for eval-

uation of the main content extraction in western lan-

guage web documents.

Tables 3 and 4 list the obtained results, i.e. recall,

precision and F1 score (Gottron, 2007), from combin-

ing each of the ﬁlters introduced in this paper with the

DANAg algorithm. Tables 3 and 4 are again divided

into three parts: the ﬁrst part contains 4 rows and

Table 1: Evaluation corpus of 2,166 web pages.

web site size languages

BBC 598 Farsi

Hamshahri 375 Farsi

Jame Jam 136 Farsi

Al Ahram 188 Arabic

Reuters 116 Arabic

Embassy of 31 Farsi

Germany, Iran

BBC 234 Urdu

BBC 203 Pashto

BBC 252 Arabic

Wiki 33 Farsi

Table 2: Evaluation corpus of 9,101 web page.

web site size languages

BBC 1,000 English

Economist 250 English

Golem 1,000 German

Heise 1,000 German

Manual 65 German, English

Republica 1,000 Italian

Slashdot 364 English

Spiegel 1,000 German

Telepolis 1,000 German

Wiki / 1,000 English

Yahoo 1,000 English

Zdf 422 German

compares the recalls; whereas the second part com-

pares the precision; and ﬁnally, the third section com-

pares the F1 scores. By looking at Tables 3 and 4, one

can make the following conclusions:

• As seen in the third part of both Tables 3 and 4,

Filter 3 has acquired a better F1 score in compar-

ison with the other two ﬁlters in most of the 18

cases. In contrast, Filter 2 has obtained the mini-

mum amount of F1 score as compared to Filters 1

and 3.

• Based on the ﬁrst part of Tables 3 and 4, it can

be observed that Filter 3 has the maximum recall

only in 11 web sites out of the total number of 22

web sites, while Filter 3 attains the maximum F1

score in 18 web sites.

• In web sites where the values of recall obtained

from Filter 2 or 3 are equal to that of Filter 1, one

may judge that the web site does not have any hy-

perlink in its MC. For example, it can be seen on

Economics and ZDF web sites that the recall is

equal for all the three ﬁlters.

• When Filter 1 has a recall equal to the one in a

web site such as Reuters, it can be argued that the

web site certainly includes no hyperlink in its MC,

thus the other two pre-processors of Filters 2 and

AComparisonofThreePre-processingMethodsforImprovingMainContentExtractionfromHyperlinkRichWeb

Documents

337

Table 3: Comparison between Recall, Precision and F1 on the corpus in Table 1.

Al Ahram

BBC Arabic

BBC Pashto

BBC Persian

BBC Urdu

Embassy

Hamshahri

Jame Jam

Reuters

Wikipedia

recall

DANAg 0.942 0.990 0.959 0.997 0.999 0.949 0.993 0.963 1.0 0.613

Filter 1 0.942 0.987 0.961 0.997 0.999 0.953 0.953 0.963 1.0 0.853

Filter 2 0.942 0.989 0.961 0.997 0.999 0.953 0.942 0.963 1.0 0.886

Filter 3 0.942 0.987 0.959 0.997 0.999 0.949 0.993 0.97 1.0 0.81

precision

DANAg 0.970 0.988 0.929 0.994 0.999 0.902 0.989 0.970 0.897 0.912

Filter 1 0.969 0.952 0.929 0.973 0.999 0.833 0.611 0.97 0.897 0.869

Filter 2 0.969 0.691 0.918 0.961 0.999 0.831 0.498 0.97 0.897 0.852

Filter 3 0.969 0.987 0.929 0.994 0.999 0.902 0.989 0.976 0.897 0.915

DANAg 0.949 0.986 0.944 0.995 0.999 0.917 0.991 0.966 0.945 0.699

Filter 1 0.949 0.969 0.944 0.985 0.999 0.884 0.716 0.966 0.945 0.852

Filter 2 0.949 0.804 0.939 0.979 0.999 0.883 0.624 0.966 0.945 0.861

Filter 3 0.949 0.985 0.944 0.996 0.999 0.917 0.991 0.973 0.945 0.852

Table 4: Comparison between Recall, Precision and F1 on the corpus in Table 2.

BBC

Economist

Zdf

Golem

Heise

Republica

Spiegel

Telepolis

Yahoo

Wikipedia

Manual

Slashdot

recall

DANAg 0.893 0.966 0.963 0.997 0.945 0.997 0.942 0.979 0.955 0.578 0.680 0.318

Filter 1 0.913 0.967 0.963 0.993 0.976 0.995 0.946 0.979 0.954 0.810 0.687 0.399

Filter 2 0.922 0.967 0.963 0.745 0.965 0.994 0.946 0.979 0.952 0.760 0.690 0.440

Filter 3 0.890 0.967 0.963 0.999 0.964 0.996 0.941 0.980 0.953 0.787 0.686 0.372

precision

DANAg 0.991 0.855 0.882 0.963 0.945 0.955 0.969 0.919 0.950 0.782 0.359 0.174

Filter 1 0.991 0.830 0.880 0.941 0.900 0.872 0.943 0.914 0.948 0.927 0.355 0.208

Filter 2 0.935 0.732 0.812 0.707 0.830 0.792 0.938 0.914 0.944 0.882 0.356 0.192

Filter 3 0.991 0.855 0.880 0.989 0.911 0.954 0.974 0.919 0.948 0.927 0.357 0.197

DANAg 0.924 0.990 0.912 0.979 0.955 0.970 0.949 0.932 0.952 0.645 0.401 0.209

Filter 1 0.939 0.884 0.910 0.965 0.931 0.914 0.938 0.930 0.950 0.856 0.403 0.248

Filter 2 0.916 0.827 0.871 0.724 0.884 0.865 0.937 0.930 0.948 0.809 0.404 0.239

Filter 3 0.922 0.900 0.910 0.994 0.931 0.970 0.951 0.932 0.950 0.840 0.404 0.236

3 have calculated the recall value as one.

• When Filter 2 has a higher recall and a lower pre-

cision than the other two ﬁlters, it can be con-

cluded that a major part of the extraneous items

has been selected as the MC. It is well known that

the menus are regarded as one of the additional

items in the web pages and each item in the menu

is usually built by an anchor tag. Therefore, by ap-

plication of Filter 2, it would be possible to con-

sider menus as the MC in some of the web sites

such as BBC Arabic. However, the value of recall

is equal to 0.989 in the web site of BBC Arabic,

which is excellent. On the other hand, the value

of precision is reported to be 0.804 which is rather

poor and indicates existence of some words in the

ﬁnal MC which can hardly be taken as a part of

MC.

5 CONCLUSIONS AND FUTURE

WORKS

In this paper, three simple pre-processing methods

are proposed which can be combined with the line-

based main content extraction methods. These meth-

ods have been compared with each other and the re-

sults show that Filter 3 yields better output values.

Especially on hyperlink rich web documents such as

Wikipedia, Filter 3 clearly outperforms to the other 2

pre-processing methods.

For the future work, it is recommended to com-

bine the already introduced pre-processing meth-

ods with some other state-of-the-art main content

extraction approaches, such as CETR (Weninger

et al., 2010), Density (Moreno et al., 2009), and

ACCB (Gottron, 2008).

WEBIST2014-InternationalConferenceonWebInformationSystemsandTechnologies

338

ACKNOWLEDGEMENTS

We would like to thank Thomas Gottron for providing

us the dataset which was used in the evaluation of this

work.

REFERENCES

Finn, A., Kushmerick, N., and Smyth, B. (2001). Fact or ﬁc-

tion: Content classiﬁcation for digital libraries. In DE-

LOS Workshop: Personalisation and Recommender

Systems in Digital Libraries.

Gottron, T. (2007). Evaluating content extraction on HTML

documents. In ITA ’07: Proceedings of the 2nd In-

ternational Conference on Internet Technologies and

Applications, pages 123 – 132, Wrexham, Wales, UK.

Gottron, T. (2008). Content code blurring: A new approach

to content extraction. In DEXA’08: 19th International

Workshop on Database and Expert Systems Applica-

tions, pages 29 – 33, Turin, Italy. IEEE Computer So-

ciety.

Kohlsch¨utter, C., Fankhauser, P., and Nejdl, W. (2010).

Boilerplate detection using shallow text features. In

Proceedings of the third ACM international confer-

ence on Web search and data mining, WSDM ’10,

pages 441–450, New York, NY, USA. ACM.

Mohammadzadeh, H., Gottron, T., Schweiggert, F., and

Nakhaeizadeh, G. (2012). The impact of source code

normalization on main content extraction. In WE-

BIST’12: 8th International Conference on Web Infor-

mation Systems and Technologies, pages 677 – 682,

Porto, Portugal. SciTePress.

Mohammadzadeh, H., Gottron, T., Schweiggert, F., and

Nakhaeizadeh, G. (2013). Extracting the main con-

tent of web documents based on character encoding

and a naive smoothing method. In Software and Data

Technologies, CCIS Series, Springer, pages 217 – 236.

Springer-Verlag Berlin Heidelberg.

Moreno, J., Deschacht, K., and Moens, M. (2009). Lan-

guage independent content extraction from web pages.

In Proceeding of the 9th Dutch-Belgian Information

Retrieval Workshop, pages 50 – 55.

Pinto, D., Branstein, M., Coleman, R., Croft, W. B., King,

M., Li, W., and Wei, X. (2002). QuASM: a system

for question answering using semi-structured data. In

JCDL ’02: Proceedings of the 2nd ACM/IEEE-CS

joint conference on Digital libraries, pages 46 – 55,

New York, NY, USA. ACM Press.

Weninger, T., Hsu, W. H., and Han, J. (2010). CETR: con-

tent extraction via tag ratios. In Proceedings of the

19th International Conference on World Wide Web,

pages 971 – 980. ACM Press.

AComparisonofThreePre-processingMethodsforImprovingMainContentExtractionfromHyperlinkRichWeb

Documents

339
