Expert vs Novice Evaluators
Comparison of Heuristic Evaluation Assessment
Magdalena Borys and Maciej Laskowski
Institute of Computer Science, Lublin University of Technology, Nadbystrzycka 38D street, Lublin, Poland
Keywords: Usability, Website Usability Evaluation, Heuristic Evaluation.
Abstract: In this paper authors propose the comparison between results of website heuristic evaluation performed by
small group of experts and large group of novice evaluators. Normally, heuristic evaluation is performed by
few experts and requires their knowledge and experience to apply heuristics effectively. However, research
involving usability experts is usually very costly. Therefore, authors propose the experiment in order to
contrast the results of evaluation performed by novice evaluators that are familiar with assessed website to
the results obtained from expert evaluators in order to verify if they are comparable. The usability of
website was evaluated using the authors’ heuristics with extended list of control questions.
1 INTRODUCTION
The notion of usability gained its popularity in the
early 1980s as one of key factors of software quality.
Since then, the different methods and approaches
have been proposed to evaluate the usability of an
user interface and interactions with system at each
stage of software development process.
Taking into consideration the multitude of
usability evaluation methods, the main focus is laid
on the relative effectiveness of empirical usability
studies in opposition to other, less costly, methods.
The expert based methods hold the promise of
usability results that are keeping costs low by
relying on expert review or analysis of interfaces
rather than observing actual user behaviour
(Hollingsed and Novick, 2007). Despite the fact that
expert based methods usually do not require special
equipment and lab facilities, it should be taken into
account, that experts with appropriate skills and
level of experience are hard to find and still cannot
be included in all software project budgets.
The experiment presented in the paper shows
that the results of evaluation performed by novice
evaluators who are familiar with assessed website
and have been introduced to some basic concepts of
usability can be compared to the results obtained by
experienced expert evaluators. And therefor to
answer research question: it is possible to substitute
few skilled and experienced evaluator with large
number of novice evaluators familiar with evaluated
subject?
The problem of novices vs experts is not a new
one, but the experiment described in this paper was
based on authors’ own heuristics with extended list
of control questions.
2 RELATED WORKS
While analysing the problem of novice and
experienced evaluators, several existing papers, such
as the work of Hertzum and Jacobsen (Hertzum and
Jacobsen, 2001) should be taken into account, where
the evaluator effect for both novice and experienced
evaluators in usability evaluation methods (UEMs)
such as heuristic evaluation, cognitive workthrough
and thinking-aloud study was investigated. They
stated that despite used UEM the average agreement
between any 2 evaluators who have evaluated
the same interface using the same evaluation method
will ranges from 5% to 65%. What is more, none of
the investigated UEMs was considered
as consistently better than the others in revealing
evaluator effect As the simplest solution for coping
with evaluators is to involve multiple evaluators in
usability evaluation.
The evaluation performance of two types of
cognitive styles was explored by Ling and Salvendy
(Ling and Salvendy, 2009). In the proposed
experiment the results indicate that the field
independent individuals, who tend to be less
144
Borys M. and Laskowski M..
Expert vs Novice Evaluators - Comparison of Heuristic Evaluation Assessment.
DOI: 10.5220/0004970901440149
In Proceedings of the 16th International Conference on Enterprise Information Systems (ICEIS-2014), pages 144-149
ISBN: 978-989-758-029-1
Copyright
c
 2014 SCITEPRESS (Science and Technology Publications, Lda.)

influenced by the information from the visual fields
and consider all the other information from senses,
performed evaluation with significantly higher
thoroughness, validity, effectiveness and sensitivity
than the field dependent individuals, who tend to be
greatly influenced by the dominant visual field.
The set of experiments comparing effectiveness
of MOT technique (inspection by metaphors of
human thinking) with heuristic evaluation, cognitive
walkthrough and “think aloud” testing for novice
evaluators was introduced by Frøkjær and Hornbæk
(Frøkjær and Hornbæk, 2008). In experiments they
demonstrated that MOT was more useful as an
inspection technique for novice evaluators that
heuristic evaluation - the evaluators found an equal
number of problems with the two methods, but
problems found with MOT are more serious and
complex to repair, and more likely to persist for
expert users. However, understanding MOT as
a technique for evaluating interfaces appeared to be
difficult.
Another comparative study was proposed in
(Lanzilotti et al., 2011). The study involves novice
evaluators and end users, who evaluated an
e-learning application using one of three techniques:
pattern-based inspection, heuristic evaluation and
user testing. In the study authors show that pattern-
based inspection reduces reliance on individual
skills and permits the discovery of a larger set of
different problems and decrease evaluation cost.
Moreover, the results of study indicated that
evaluation in general is strongly dependent on the
methodological approach, judgement bias and
individual preferences of evaluators. Authors also
state that patterns help to share and transfer
knowledge between inspectors and thus simplify the
evaluation process for novice evaluators.
More experiments on how to improve heuristic
evaluation done by novice evaluators was performed
by Botella, Alracon and Penalver (Botella, Alracon
and Penalver, 2013). They proposed the framework
for improving usability reports for novice evaluators
by combining the classical usability report with
the interaction pattern design. However, they did not
provide any evidence of method usage or its
comparison to other techniques.
3 HEURISTIC EVALUATION
METHOD
Heuristic evaluation is one of the most widely used
methods for application evaluation. While using
the application, an expert checks and marks the
predefined areas in order to note the compliance
with interface design guidelines called also
heuristics and look for potential problems.
3.1 General Description
In heuristic evaluation method, each of those
predefined areas can be divided into several more
detailed sub-areas and be assigned with questions for
the expert to answer while working with an
application.
The main advantage is the method cost, which
does not require representative samples of users,
special equipment or laboratory settings. Moreover,
experts can detect wide range of system problems in
a limited period of time. As the main drawback
studies list the dependency on experts’ skill and the
fact that experience as heuristics are often generic
(Lanzilotti et al., 2011). Other studies list that
heuristic evaluation can lead to situation when many
small and minor usability problems are detected and
improved whereas major usability problems remain
unnoticed (Koyani, Bailey and Nall, 2004).
Contrary to the widespread assumption, experts
usually do not acquire better results in performing
specific tasks in the tested system, as they usually do
not know that system before the testing. But their
expert status is based on their own experience with
different kinds of software. This, as proven by
studies, allows them to perform faster than the
novices (Dillon and Song, 1997) and to spend less
time handling the errors despite making number of
errors comparable to the novice users (Jochen et al.,
1991).
The most known guidelines concerning user
interface are:
 Nielsen's heuristics (Nielsen and Molich, 1990);
 Gerhardt-Powals’ cognitive engineering
principles (Gerhardt-Powals, 1996);
 Weinschenk and Barker classification
(Weinschenk and Barker, 2000);
 Connell’s Full Principles Set (Connell, 2000).
3.2 Applied Heuristics
Authors decided to used heuristics that they created
and applied in previous research (Borys, Laskowski
and Milosz, 2013). The proposed heuristics covers
the following areas:
 Application interface.
 Navigation and data structure.
 Feedback, system messages, user help.
 Content.
 Data input.
ExpertvsNoviceEvaluators-ComparisonofHeuristicEvaluationAssessment
145

Table 1 shows the detailed list of areas and subareas
(“LUT list”) with questions assigned to each point.
Accordingly, Table 2 presents the grading scale used
to assess each tested area.
Table 1: LUT list of predefined testing areas with
questions assigned.
Web application interface
Layout
Is the layout readable?
Is it adjusted to different resolutions?
Is it adjusted to mobile devices?
Is it consistent?
Does it support task implementation?
Colour scheme
Is there proper contrast between text and
background ?
Is the colour scheme readable for people
with colour vision disorders?
Is the colour scheme readable on various
kinds of displays?
Navigation and data structure
Ease of use
Is the access to all sections of a web
application easy and intuitive?
Is the access to all functions of a web
application easy and intuitive?
Information
hierarchy
Isn’t the information hierarchy too
complicated?
Information
structure
Is the information structure understandable
for users?
Is it consistent?
Is it well planned?
Screen elements Do they support the navigation?
Feedback, system messages, user help
System messages
(general)
Do they provide enough information on
the status of actions performed by user?
System messages
(errors)
Do they contain hints on problem
solution?
Feedback and user
help
Does the information appear in places,
where it may be needed?
Is the provided information
understandable for an average user?
Is the provided information accessible for
an average user?
Is it possible for an average user to
perform actions suggested by system help
in order to solve the encountered problem?
Content
Labels
Do the labels used in the interface provide
enough information?
Do all the interface elements have
necessary labels?
Naming
Is the interface naming understandable for
its users?
Is the interface naming consistent?
Page text Is it understandable for users?
Data input
Data
Is the data validated by the form elements?
Do the forms have elements acting as hints
for the input data (e.g. on format or data
range)?
Can average user fill in the form easily?
Forms
Are they designed in a readable way?
Are they adjusted to the mobile devices?
Do they allow user to input all of the
necessary data?
Table 2: Grading scale applied to LUT list.
Grade Description
1 Critical GUI errors were observed, preventing
normal usage or discouraging user from using
the web application.
2 Serious GUI issues were encountered, which
may prevent most users from task realization.
3 Minor usability GUI – ere observed, which if
accumulated may have negative impact on
user performance.
4 Single minor GUI issues were observed,
which may have negative impact on user
work quality (e.g. poor readability).
5 No GUI issues influencing either user
performance or work quality were identified.
The results of proposed evaluation approach can
be used to calculate Web Usability Points as
a complex factor (rate) of the usability of websites
GUI. WUP metric uses grades (Table 2) granted by
experts to each question from the LUT list (Table 1).
WUP for websites can be calculated using following
formula:



ij
ia
q
k
ijk
s
j
ij
n
i
ia
p
qsn
WUP
11
111
(1)
where:
a
n
- number of areas,
i
s
- number of subareas in i-area,
ij
q
- number of questions in i-area and j-subarea,
ijk
p
- grade value (points) granted to k-question in
j-subarea in i-area.
The value of WUP varies from 1 to 5. The higher
value, the better usability of the interface.
4 EXPERIMENT AND RESULTS
4.1 Research Question
The goal of our experiment was to examine two set
of results of web usability assessment based on
heuristic evaluation method from the point of view
of the following research question: ”Whether the
website usability evaluation results based on well-
defined heuristic from large group of novices are
comparable to results gained from small group of
experts in the domain of web usability?”
4.2 Research Hypotheses
To examine the research question following research
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
146

hypothesis was formulated: “Results of evaluations
provided by large group of novices and results of
evaluations provided by small group of experts are
comparable.”
4.3 Research Methodology
The research hypotheses were verified by
experimental works. The experiments were
conducted on university websites. The heuristic
evaluation were performed by 26 computer science
students who had no or very little knowledge in
usability domain and by 4 experts in web usability.
All students were familiar with the websites before
the evaluation which facilitate theirs performance in
evaluation. In order to make sure that all the notions
and ideas of website usability and heuristics are
clear and understood, all the students were involved
in a hour training before the experiment was
conducted.
Both groups, novices and experts, used heuristics
described in section 3.2 to guide their evaluations.
Despite the fact that all evaluations consisted of
numerical assessment of each section and a list of
detected usability problems, only numerical
assessments were taken into consideration during
statistical analysis. Statistical analysis were
performed in program Statistica 10.
4.4 Results
The means and standard deviations for each testing
areas of LUT list for whole population, novice and
expert evaluators group are shown in Table 3. What
is interesting, all plots shows greater divergence in
experts’ assessment than in novices’ one.
Distributions for each testing areas (except
Application interface) area in novices and experts
groups are normal (based on Kolmogorov-Smirnov
normality test with p > 0.95). Therefor the t-tests for
two independent group for each testing areas (except
Application interface) were performed and indicated
no statistical significant difference between groups.
The box-and-whisker plot for two independent
groups – novices and experts – for each testing area
of applied usability heuristics are presented on
Figure 1-4.
Since distribution for Application interface
testing area does not follow normal distributed data,
nonparametric test for two independent group were
performed. Both Mann-Whitney U test and Wald-
Wolfowitz runs test do not indicated any significant
differences (for p < 0.05), therefor there is no reason
to reject the hypothesis that results from novice and
expert evaluators are comparable.
Table 3: Group means and std. deviations for testing areas.
Testing area N Mean Std. deviation
Population
1 30 3.91 0.77
2 30 3.22 1.16
3 30 3.53 0.69
4 30 3.78 0.82
5 30 3.29 0.88
Group: Novice evaluators
1 26 3.99 0.69
2 26 3.24 1.16
3 26 3.45 0.67
4 26 3.75 0.83
5 26 3.25 0.84
Group: Expert evaluators
1 4 3.39 1.13
2 4 3.13 1.31
3 4 4.06 0.72
4 4 4.00 0.82
5 4 3.54 1.23
Box and whisker
p
lot: Navi
g
ation and data struct ure
Mean
Mean±std error
Me an ±1 ,96 *Std er r o r
Novice Expert
Level
2,0
2,2
2,4
2,6
2,8
3,0
3,2
3,4
3,6
3,8
4,0
4,2
4,4
4,6
Navigation and data structure
Figure 1: Box and whisker plot for two independent
group: Navigation and data structure.
Box and whisker
p
lot: Feedback, s
y
stem messa
g
es, user hel
p
Mean
Me an ± s td er ro r
Mean±1,96*Std error
Novice Expert
Level
1,6
1,8
2,0
2,2
2,4
2,6
2,8
3,0
3,2
3,4
3,6
3,8
4,0
4,2
4,4
4,6
Feedback, syste m me ssages, user help
Figure 2: Box and whisker plot for two independent
group: Feedback, system messages, user help.
ExpertvsNoviceEvaluators-ComparisonofHeuristicEvaluationAssessment
147


Box and whisker
p
lot: Content
Mean
Mean±std error
Mean±1,96*Std error
Novice Expert
Level
3,0
3,2
3,4
3,6
3,8
4,0
4,2
4,4
4,6
4,8
5,0
Content
Figure 3: Box and whisker plot for two independent
group: Content.

Box and whisker
p
lot: Dat a in
p
ut
Mean
Me an ±s td er r or
Mean±1,96*Std error
Novice Expert
Level
2,2
2,4
2,6
2,8
3,0
3,2
3,4
3,6
3,8
4,0
4,2
4,4
4,6
4,8
5,0
Da ta i n p ut
Figure 4: Box and whisker plot for two independent
group: Data input.
5 CONCLUSIONS
The main purpose of this research was to investigate
if the usability assessment performed by novices
provides comparable results in the web usability
evaluation using heuristics to the results obtained by
experts. Hypothesis has been fully confirmed.
Moreover, the LUT list of predefined testing
areas helped both experts and novices to perform
their evaluation in a systematic and methodical
manner.
Authors came across a few interesting research
problems to be solved in the future, such as:
 what is the lower limit of the number of novices
in order to get the same (or comparable) results
as the group of experts?
 what are the limitations of the described method
in a number of tested applications or websites?
 what is the influence of length of the experiment
on both experts’ and novices’ performance?
The aforementioned questions are just a contribution
to further studies and experiments, which may result
in interesting outcomes.
ACKNOWLEDGEMENTS
Authors would like to thank dr Malgorzata
Plechawska-Wojcik, Marcin Badurowicz and Kamil
Żyła and to all students who took part in the
experiment for their contribution to this paper.
Authors are the participants of the project:
"Qualifications for the labour market - employer
friendly university", co-financed by European Union
from European Social Fund.
REFERENCES
Borys, M., Laskowski, M., Milosz, M., 2013.
Memorability experiment vs. expert method in
websites usability evaluation. In ICEIS 2013 -
Proceedings of the 15th International Conference on
Enterprise Information Systems, 3, SciTePress.
Botella, F., Alarcon, E., Penalver, A., 2013. A new
proposal for improving heuristic evaluation reports
performed by novice evaluators. In Proceeding
ChileCHI '13 Proceedings of the 2013 Chilean
Conference on Human - Computer Interaction. ACM,
NY, USA, pp. 72-75.
Connell, I. W., 2000. Full Principles Set. Set of 30
usability evaluation principles compiled by the author
from the HCI literature. In http://www0.cs.ucl.ac.uk/
staff/i.connell/DocsPDF/PrinciplesSet.pdf.
Dillon, A., Song, M., 1997. An empirical comparison of
the usability for novice and expert searchers of a
textual and a graphic interface to an art-resource
database. Digital Information.
Frøkjær, E. and Hornbæk, K. 2008. Metaphors of human
thinking for usability inspection and design. In ACM
Transaction on Computer-Human Interaction, 14 (4),
pp. 1-33.
Gerhardt-Powals, J., 1996. Cognitive engineering
principles for enhancing human - computer
performance, In International Journal of Human-
Computer Interaction, 8(2), pp. 189-211.
Hertzum, M., Jacobsen, N. E. 2001. The evaluator effect:
A chilling fact about usability evaluation methods.
In International Journal of Human-Computer
Interaction, 13(4), pp. 421-443.
Hollingsed T., Novick D. G., 2007. Usability Inspection
Methods after 15 Years of Research and Practice. In
SIGDOC '07 Proceedings of the 25th annual ACM
international conference on Design of communication,
NY, pp. 249-255.
ICEIS2014-16thInternationalConferenceonEnterpriseInformationSystems
148

Jochen P. et al., 1991. Errors in computerized office work:
Difference between novice and expert users. ACM
SIGCHI Bulletin.
Koyani S., Bailey R. W., Nall J. R., 2004. Research-Based
Web Design & Usability Guidelines. In Computer
Psychology.
Landauer Th. K., 1996. The Trouble with Computers:
Usefulness, Usability, and Productivity. MIT Press.
Lanzilotti, R., Ardito, C., Costabile, M. F., De Angeli, A.,
2011. Do patterns help novice evaluators?
A comparative study. In International Journal of
Human-Computer Studies, 69(1–2), pp. 52-69.
Ling, Ch., Salvendy, G., 2009. Effect of evaluators’
cognitive style on heuristic evaluation: Field
dependent and field independent evaluators. In
International Journal of Human-Computer Studies,
67(4), pp. 382-393.
Nielsen, J., and Molich, R., 1990. Heuristic evaluation of
user interfaces. In Proceedings ACM CHI'90
Conference, pp. 249-256.
Weinschenk, S., Barker, D. T., 2000. Designing Effective
Speech Interfaces, Wiley, 1 edition.
ExpertvsNoviceEvaluators-ComparisonofHeuristicEvaluationAssessment
149
