Automated Quantitative Attributes Prediction from Architectural

Description Language

Imen Derbel

, Lamia Labed Jilani

and Ali Mili

Institut Superieur de Gestion, Bardo, Tunisia

New Jersey Institute of Technology, Newark NJ 07102-1982, U.S.A.

Keywords:

Software Architecture, Non Functional Attributes, Architectural Description Language, Acme, Bottleneck

Analysis, Quality Attributes, Performance, Reliability, Maintainability, Availability.

Abstract:

Software architecture has become an increasingly important research topic in recent years. Concurrently much

more attention has been paid to methods of evaluating non functional attributes of these architectures. How-

ever, in current architectural description languages (ADLs) based on a formal and abstract model of system

behavior, there is a notable lack of support for representing and reasoning about non functional attributes. In

this paper, we propose ACME+ ADL as an extension of ACME ADL and discuss our quantitative model for

formal analysis of software architectures. This paper gives an overview of our formal approach for describ-

ing software architectures and analyzing their performance, reliability, maintainability and availability. The

proposed model is supported by an automated tool that transforms an architecture described in ACME+ into

a set of inequalities characterizing system non functional attributes. These inequalities are then solved using

Mathematica in order to obtain system properties as function of its components and connectors properties.

1 INTRODUCTION

Software systems are characterized by both their

functional requirements (what the system does) and

by their non functional requirements (how the system

behaves with respect to some observable attributes

like performance, reusability, reliability, etc.). Spec-

iﬁcation of non-functional properties at the architec-

tural level of a software system can be used to de-

scribe a system, analyze it, or direct decisions to make

reﬁnements. Therefore, the representation and analy-

sis of non-functional attributes are taken into account

early in the software life cycle allowing not only early

problems detection and cost beneﬁts but also assuring

that the chosen architecture will meet both functional

and non-functional quality requirements.

In current practice, very few of the non-functional

requirements are automatically checked. This man-

ual checking activity is prone to errors and time-

consuming due to the complex designs, as a result

of a high number of components, connectors and the

interconnections between them, as well as the possi-

ble architectural decisions. Therefore, an automated

veriﬁcation, validation and testing of the quality at-

tributes of a software architecture is becoming more

needed for practitioners. Also, there is a notable lack

of support for non-functional attributes in existing

Architecture Description Languages(ADLs). Acme

(Garlan et al., 1997), Aesop (Garlan et al., 1994),

Weaves (Gorlick and Razouk, 1991) and others allow

the speciﬁcation of arbitrary component properties,

but, none of them interprets such properties nor do

they make direct use of them (Medvidovic and Tay-

lor, 2000).

In this work, we propose an ADL based formal

method for representing and reasoning about sys-

tem non-functionalattributes at the architectural level.

We are interested in performance attributes (response

time and throughput), reliability (failure probability),

maintainability and availability. We aim to translate

an architectural description into a set of inequalities

that characterize non functional attributes of software

architectures. These inequalities are then optimized

using Mathematica (

Wolfram Research) in order

to obtain system properties as function of compo-

nents and connector properties. The architect can an-

alyze a software system by varying all the architec-

ture constituents (e.g., components, connectors) and

their non-functional attributes, test and compare it by

obtaining the system non-functional attributes output

given by that set. The architect can then compare the

obtained results and inform the practitioner on what

Derbel I., Labed Jilani L. and Mili A..

Automated Quantitative Attributes Prediction from Architectural Description Language.

DOI: 10.5220/0005003700870094

In Proceedings of the 9th International Conference on Software Paradigm Trends (ICSOFT-PT-2014), pages 87-94

ISBN: 978-989-758-037-6

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

solution is the most reliable, efﬁcient, available, etc.

switch its attempts and preferences.

This paper is organized as follows. In section 2,

we discuss requirements of our analysis model. In

section 3, we present the main syntactic features that

we have added to Acme. In section 4, we present the

Mathematica inequalities produced using an inductive

reasoning. In section 5, we discuss bottleneck analy-

sis; in section 6, we show how we generate the pro-

posed analysis tool. We give an illustrative example

in section7. The paper concludes in section 8.

2 MODEL REQUIREMENTS

We submit the following requirements as a long term

goals for our model:

• If we give the values of the non-functional prop-

erties of components and connectors, we want to

derive the corresponding values for the whole ar-

chitecture.

• If we are given a system architecture, and

given components and connectors quantitative

non functional attributes, we want the model to

help us propagate inductively the requirements

from components and connectors to the whole

system.

• If we are given values of the non functional at-

tributes of the components and connectors of an

architecture, we want to determine the sensitiv-

ity of the system attributes with respect to com-

ponent and connector attributes. In other words,

if we want to enhance a given system attribute,

which component or connector should we alter?

or, which component or connector is the bottle-

neck to the current attribute value?

For the purposes of this paper, we content ourselves

with the ﬁrst and second goals. In order to enable

us to represent and reason about non functional prop-

erties of software architectures, we need an architec-

tural model characterized by:

• The ability to represent the architecture of com-

ponents, their ports and connectors, their roles.

• The ability to represent quantitative non func-

tional properties of components and connectors.

• The ability to represent operational properties of

the architecture, in addition to its topological

properties. For example, if we have two com-

ponents A and B connected in parallel between

a shared source and a shared sink, we want to de-

termine whether they play complementary roles

(in which both are needed for normal operation)

or alternative roles (if any one is operational, the

system is operational). While these two conﬁg-

urations have the same topology, they represent

radically different architectures, with different op-

erational properties values. Thus, at a minimum,

we must be able to identify, among ports of a com-

ponent (and roles of a connector) which ports are

used for input and which ports are used for output.

Furthermore, if we have more than one input port

or more than one output port, we need to represent

the relation between the ports: are they mutually

synchronous or asynchronous? Do they carry du-

plicate information? or disjoint/ complementary

information? or overlapping information?

• The ability to represent for each component (con-

nector) more than one relation between input ports

(source roles) and output ports (destination roles).

The reason we need this provision is that often the

same component (or connector) may be involved

in more than one operation, where each operation

involves a different conﬁguration of ports (roles),

and have different values for its non functional at-

tributes.

• The availability of automated support.

None of the existing ADLs meets all the requirements

deﬁned above. However, the Acme ADL is the most

suitable for our purposes but after including some ex-

tensions. Acme ADL was chosen for many reasons.

First, unlike many ADLs(e.g. Darwin and Rapide),

it provides accurate textual notations to describe soft-

ware architectures, distinguishing between the differ-

ent architectural elements: components, connectors,

and conﬁguration. Second, it is supported by AcmeS-

tudio, a modeling, parsing and code generation tool.

Furthermore, Acme is a pivot language that allows to

switch from one ADL to another to beneﬁt from the

complementary capabilities of ADLs. Hence, to cater

to the ﬁve requirements we have presented above,

we adopt Acme’s basic syntax and ontology of ar-

chitecture description, and add to it the concept of

Functional Dependency

. We refer to the extended

Acme ADL as ACME+.

3 ACME+ SYNTAX

In order to represent and reason about non func-

tional attributes at the architectural level, we pro-

pose the extension of Acme ADL with a new con-

cept of

Functional Dependency

. The new con-

struct of Functional Dependency deﬁned in a com-

ponent (connector) description aims to represent re-

lations between component ports (connector roles)

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

and speciﬁes its quantitative non functional prop-

erties. Each component (connector) has only one

Functional Dependency

construct described by one

or many dependency relations. Each relation ex-

presses that the component (connector) needs input

data received by its input ports (source roles) to pro-

ceed and produce data to its output ports (destina-

tion roles). This process is characterized by a set

of non-functional attributes. Consequently, each re-

lation description connects input ports (source roles)

and output ports (destination roles) and is character-

ized by speciﬁc non functional attributes values. A

Functional Dependency

description is written at the

end of a componentspeciﬁcation, after the declaration

of all the ports, or at the end of a connector descrip-

tion, after the declaration of all the roles. A declara-

tion of a

Functional Dependency

consists of:

• A name, to identify the dependency relation,

• A declaration of the input relation (how input

ports or source roles are coordinated),

• A declaration of the output relation (how output

ports or destination roles are coordinated),

• A declaration of relevant properties (e.g. process-

ing time for components, transmission time for

connectors, etc).

As an example, let’s take a

Functional Dependency

construct that includes only one dependency relation.

We may write:

fundep {Relation Name //name of the dependency relation

input (Input Ports relations),

output(Output Ports relations),

properties(ProcTime=0.02 s, Thruput = 45 trans/s,

FailProb =0.001, MTTR= 120 h , MTBF= 2300 h)}

Identiﬁcation of Input and Output ports:

At a minimum, the dependency must specify which

ports are used for input and which ones are used for

output. If a component has, say ﬁve ports, P1, P2, P3,

P4, P5 and we wish to record that P1, P2, P3 are the

input ports and P4,P5 are the output ports, we write:

input(P1,P2,P3),

output(P4,P5).

Relations between Input ports:

For input ports, we must specify whether they provide

alternative/duplicateinformation (the componentmay

proceed with data from any one of the ports) or com-

plementary information (component needs data from

all input ports before it proceeds); also, there are cases

where we may need a majority of input ports to pro-

ceed. We write respectively:

input(AnyOf(P1,P2,P3)),

input(AllOf(P1,P2,P3)),

input(MostOf(P1,P2,P3)).

In the latter two cases, we must also specify

whether the input ports must deliver their inputs syn-

chronously or asynchronously. Hence we could say,

for example:

input(AllOf(asynch(P1,P2,P3)),

input(MostOf(synchro(P1,P2,P3)).

Relations between Output ports: As for output

ports, in case we have more than one for a given com-

ponent, we may represent two aspects: the degree of

overlap between the data on the various ports (Dupli-

cate, Exclusive, Overlap), and the synchronizationbe-

tween the output ports (Simultaneous, Asavailable).

Pursuing the example discussed above, if P4 and P5

are output ports, then we can write, depending on the

situation:

output(Overlap(Asavailable(P4,P5)),

output(Exclusive(Simultaneous(P4,P5)),

output(Exclusive(Asavailable(P4,P5)).

4 ACME+ SEMANTIC

We want to map ACME+ source code onto a set

of Mathematica inequalities that characterize the non

functional attributes of the architecture of interest. To

this effect, we assume that: (1) all ports of compo-

nents are labeled for

input

or for

output

; all roles

of connectors are labeled as

fromRole

or as

toRole

;

(2) each port of each component and each role of each

connector has an attribute for each property of interest

labeled RT (response time), TP (throughput),FP (fail-

ure probability), MTTR and MTBF; (3) there is a sin-

gle component without input port and a single output

port, called the

source

; there is a single component

without output port and with a single input port, called

the

sink

; we assume that the

source

and

sink

com-

ponents are both dummy components, that are used

solely for the purposes of our model. The system non

functional properties are computed from the proper-

ties attached to the components and connectors (Proc-

Time, TransTime, Thruput, FailProb, MTTR, MTBF)

and represent attributes associated to the input port of

the

sink

component, namely:

System.ResponseTime = sink.input.RT,

System.Throughput = sink.input.TP,

System.FailureProbability = sink.input.FP,

System.MTTR = sink.input.MTTR,

System.Availability= sink.input.MTBF /

(sink.input.MTBF + sink.input.MTTR)

In order to obtain the values of these attributes, we

decide to maximize or minimize attribute values at-

tached to the input port of the

sink

component tak-

ing into account inequalities generated inductively.

AutomatedQuantitativeAttributesPredictionfromArchitecturalDescriptionLanguage

These inequalities are obtained by propagating at-

tributes from the

source

componentto the

sink

com-

ponent in a stepwise manner. They are written as

≤ for the maximum problem and ≥ for the mini-

mum problem. Thus, as we want to maximize system

throughput and MTBF, we write ≤ inequalities and

try to maximize sink.input.TP, sink.input.MTBF,

subject to the corresponding inequalities. Also, as we

aim to minimize system response time, failure prob-

ability and maintainability, we write ≥ inequalities

and try to minimize sink.input.RT, sink.input.FP,

sink.input.MTTR, subject to the corresponding in-

equalities.

4.1 Basis of Induction

The output port of the source component has trivial

values for all the attributes, namely:

source.output.RT >= 0,

source.output.FP >= 0,

source.output.MTTR >= 0,

source.output.TP <= infinity,

source.output.MTBF <= infinity.

4.2 Inductives Rules between

Components and Connectors

Whenever a port is attached to a role, the attribute val-

ues are passed forward from the output port to the

source role. As an example, we present inequalities

generated for Response time and throughput quality

attributes:

C.output to N.originRole

We write:

C.output.TP = N.originRole.TP

C.output.RT = N.originRole.RT

4.3 Inductive Rules within Components

We present inequalities of the components and leave

it to the reader to see how the inequalities of the con-

nectors can be derived by analogy.

4.3.1 Single Input/ Single Output

Given a component C, we write an inequality that

links the attributes of the input port(input), the at-

tributes of the output port(output), and the properties

of the component. We write the inequalities:

C.output.RT >= C.input.RT + C.ProcTime.

C.output.FP >= 1-(1-C.input.FP)(1-C.failProb).

C.output.MTTR >= C.input.MTTR + C.MTTR.

C.output.TP <= Min(C.input.TP;C.thruPut).

C.output.MTBF <= (C.input.MTBF x C.MTBF)/

(C.input.MTBF + C.MTBF).

4.3.2 Multiple Inputs and Outputs

These equations depend on the nature of the func-

tional dependency relations. Let C designate a com-

ponent, whose input ports are called input1;...;inputn

and output ports are called output1;...;outputk. We

suppose that these input and output ports are related

with a functional dependency relation R expressed as

follows:

Input(InSelection(InSynchronisation

(input1; ..; inputn)));

Output(OutSelection(OutSynchronisation

(output1; ..; outputk)));

Properties(procTime=0.7;thruPut=0.2;failProb=0.2)

)

We review in turn the ﬁve attributes of interest.

• Response Time

For each output port outputi expressed in the relation

R, inequalities depend on the construct InSelection,

expressing the nature of the relation between input

ports.

InSelection

is AllOf, then C needs all informa-

tion from its input ports to proceed and generate an

output. We write:

C.outputi.RT>=Max(C.input1.RT;..;C.inputn.RT)

+ C.R.procTime.

InSelection

is AnyOf, then the receipt of the ﬁrst

input information from any input port, triggers C run-

ning. We write:

C.outputi.RT>=Min(C.input1.RT;..;C.inputn.RT)

+ C.R.procTime.

• Throughput

For each output port outputi of the component C ex-

pressed in the relation R, we write an inequality re-

lating the component’s throughput and inputiP. This

rule depends on whether all of inputs are needed, or

any one of them.

Consequently if

InSelection

is AllOf, and since the

slowest channel will impose its throughput, keeping

all others waiting, we write:

C.outputi.TP<=Min(C.R.thruPut;(C.input1.TP+..+

C.inputn.TP)).

Alternatively, if

InSelection

is AnyOf, since the

fastest channel will impose its throughput, we write:

C.outputi.TP<=Max(Min[C.R.thruPut;C.input1.TP];..;

Min[C.R.thruPut; C.inputn.TP]).

• Failure Probability

For each output port outputi of the component C ex-

pressed in the relation R, we write an equation relating

component’s failure probability and input ports fail-

ure probability. This rule depends on whether all of

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

inputs are needed, or any one of them. We ﬁrst con-

sider that inputi provide complementary information

(

InSelection

is AllOf). A computation initiated at

C.outputi will succeed if the component C succeeds,

and all the computations initiated at the input ports

of C succeed. Assuming statistical independence, the

probability of these simultaneous events is the prod-

uct of probabilities. Whence we write:

C.outputi.FP>=1-(1-C.input1.FPx..xC.inputn.FP)

(1 - C.R.FailProb).

Second we consider that inputi provide inter-

changeable information (

InSelection

is AnyOf). A

computation initiated at C.outputPi will succeed if

component C succeeds, and one of the computations

initiated at input portsC.inputi succeeds. Whence we

write:

C.outputi.FP >= 1-(1-C.input1.FP)x..x

(1 - C.inputn.FP)(1- C.R.FailProb).

• Maintainability

For each output port outputPi expressed in the

relation R, inequalities depend on the construct

InSelection

, expressing the nature of the relation

between input ports.

InSelection

is AllOf, then C needs all informa-

tion from its input ports to proceed and generate an

output. Let’s recall that the maintainability of the sys-

tem is expressed in terms of MTTR quality attribute.

Hence we propagate MTTR through the architecture

and write:

C.outputi.MTTR>=C.R.MTTR+C.input1.MTTR+..+

C.inputn.MTTR.

InSelection

is AnyOf, then the receipt of the

ﬁrst input information from any input port, triggers C

running. We write:

C.outputi.MTTR>=C.R.MTTR+(C.input1.MTTRx..x

C.inputn.MTTR)/

(C.input1.MTTR+..+C.inputn.MTTR)

• Availability

For each output port outputi expressed in the

relation R, inequalities depend on the construct

InSelection

, expressing the nature of the relation

between input ports. The system availability is ex-

pressed in terms of system MTTR and system MTBF

as explained in section 3. MTTR inductive inequali-

ties have been already discussed. Hence, we present

MTBF related inequalities.

InSelection

is AllOf, then C needs all informa-

tion from its input ports to proceed and generate an

output, we write:

C.outputi.MTBF<=(C.R.MTBFxC.input1.MTBFx...x

C.inputn.MTBF)x

(C.R.MTBF+C.input1.MTBF+...+C.inputn.MTBF)

InSelection

is AnyOf, then the receipt of the ﬁrst

input information from any input port, triggers C run-

ning. We write:

C.outputi.MTBF<=(C.R.MTBFxC.input1.MTBF x...x

C.inputn.MTBF)/

(C.R.MTBF+C.input1.MTBFx...xC.inputn.MTBF)

5 BOTTLENECK ANALYSIS

Bottleneck analysis forms the core of system perfor-

mance analysis. In our tool we have decided to apply

bottleneck analysis laws of queueing networks. In the

following we present these laws. A more detailed ex-

planation can be found in (Denning, 2008): The uti-

lization of the i

device(component or connector) is

deﬁned by:

= X × D

(1)

where X is the system throughput and D

is the total

service demand on the i

device for all visits V

a task with processing time S

. D

is deﬁned by the

following law:

= V

× S

(2)

where V

= X

/X, X

is the i

device throughput.

Since utilization U

cannot exceed 1, then X ×D

≤ 1.

Consequently, for each device i, the system through-

put X checks the following law:

X ≤

(3)

Therefore, the component or connector with largest

limits the system throughput and is the bottle-

neck. In other words, we must compute D

for each

device in the system. Let us assume that D

Max{D

,...,D

}; device j is the bottle-

neck. In order to make these results into practice, our

tool, automatically computes the demand property of

each component and connector deﬁned by the con-

stituents properties:

D =

(C.ThruPut ×C.ProcTime)

System.Throughput

(4)

Then it picks up the device having the maximum

value of D. There are several ways to deal with a bot-

tleneck component: speed it up or reduce its demand

in the system. After applying one of these options,

we can re-compute the new quality attributes of the

software and compare the improvements that will re-

sult. The main advantage of quality attributes analysis

at architectural level is to detect such problems at an

early stage. Since considering such changes at a late

stage can be expense, difﬁcult or even unfeasible.

AutomatedQuantitativeAttributesPredictionfromArchitecturalDescriptionLanguage

6 AUTOMATED TOOL FOR

SOFTWARE ANALYSIS

In order to put the proposed model into practice, we

have resolved to proceed as follows:

• We adopt ACME+ as the architectural description

language on which we attach our analysis model.

ACME+ is based on Acme’s ontology to which

we add

functional dependency

construct. The

new construct expresses operational information

and represents components and connectors non

functional properties.

• We deﬁne an attribute grammar on top of ACME+

syntax, which assigns attributes such as response

time, throughput, failure probability, etc to all

the ports and all the roles of the architecture.

This attribute grammar can in principle be used

as a synthesized grammar, propagating actual at-

tributesup the syntax tree, or as an inherited gram-

mar, propagating required / hypothetical attributes

down the syntax tree.

• We deﬁne semantic rules in the form of inequali-

ties that involve these attributes, and attach them

to various reductions of ACME+ BNF. The rules

in question are nothing but the inductive inequal-

ities we have discussed in the previous section,

along with associated operations (symbol table

operations).

• We use compiler generation technology to gen-

erate a compiler for the augmented ACME+ lan-

guage. The purpose of this compiler is to generate

inequalities that involve the attributes associated

to the ports and roles of the architecture.

• To compute the system wide properties of the

architecture (such as response time, through-

out, failure probability, etc), all we have to do

is solve the inequalities derived by the com-

piler. The resolution is achieved by Math-

ematica (

Wolfram Research) by maximizing

(sink.input.TP, sink.input.MTBF) and minimizing

(sink.input.RT, sink.input.FP, sink.input.MTTR).

Mathematica can solve the inequalities either

symbolically (by keeping component properties

and connector properties unspeciﬁed, and pro-

ducing an expression of the overall system at-

tributes as a function of the component and con-

nector properties) or numerically (by assigning

actual values to component properties and con-

nector properties and producing numerical values

for the overall system).

In order to facilitate the use of the compiler for an-

alyzing system architecture, we have developed a

graphical user interface (GUI). In its current version,

the compiler generates inequalities pertaining to re-

sponse time, throughput, failure probability, main-

tainability and availability; each of these attributes

corresponds to a tab in the GUI. Once we select a tab,

we can perform the following operations:

• Compute the system level attribute as a function

of component level properties. The GUI does so

by merely solving the system of inequalities for

the unknown

sink.inpPort.AT, for attribute AT (where AT is the

attribute identiﬁed by the selected tab). When a

tab is selected, the GUI posts this value automati-

cally.

• The GUI allows the user to update the value of

a property of a component or connector, and will

re-compute and post the updated value of the se-

lected system level attribute.

• Once a tab is selected, the GUI also generates,

and posts in a special purpose window, the sym-

bolic expression of the corresponding attribute as

a function of relevant properties of components

and connectors.

• To enable a user to assess the sensitivity of the

system level attribute with respect to component

level properties, the GUI shows a curve that plots

the system level attribute on the Y axis and the

component level property on the X axis.

• Finally, for some attributes, the GUI can also

identify the component or connector that is the

bottleneck of system performance for the selected

attribute. Once the bottleneck of the architecture

is identiﬁed, the user can change the value of its

relevant property and check for the new (possibly

distinct) bottleneck.

Space limitations preclude us from illustrating our

analysis model with examples of system analysis. A

demo of the tool that we developed, which includes

the compiler and the user interface, is available on-

line at: http://web.njit.edu/∼ mili/granada.exe. In this

demo, we present the use of the analysis tool in order

to analyze Aegis Weapons System (Allen and Garlan,

1996).

7 EXAMPLE

7.1 System Description

Let’s consider a system consisting of three interact-

ing components: a web server(S), a web client(C),

and a database(DB). We assume that the client makes

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends

requests to the server and receives corresponding re-

sponses. The server makes a request of the database in

the process of ﬁlling the client’s request. For the sake

of brevity, we content ourselves with giving ACME+

descriptions of only server componentand we analyze

performance (response time, throughput) and reliabil-

ity (failure probability) quality attributes.

We have noted that the server does two different pro-

cesses, each process is described by a dependency re-

lation which links an output port to an input port and

is characterized by a different quality attribute values:

• Following the receipt of the customer’s request by

its input port

input

, the server generates a re-

quest to the database by its output port

output

This process requires a service time equal to 20

ms. We refer to the dependency relation describ-

ing this process as

Request

• Once the server receives a response from the

database by its input port

input1

, it sends a re-

sponse to the client by its output port

output

This process requires a service time equal to 20

ms. We refer to the dependency relation describ-

ing this process as

Response

Server’s ACME+ Description is given by:

component S ={port input,port output,

port input1,port output1,

FunDep = {

Requete (Input( input);

Output(output) ;

Properties_values( ProcTime=20 ms,

Thruput= 600 tr/s,

FailProb=0.0002))

Reponse (Input( input1);

Output(output1) ;

Properties_values (ProcTime=20 ms,

Thruput= 700 tr/s,

FailProb=0.0002))};

Several questions concerning the overall quality at-

tributes the system should be answered, such as:

• What are system quality attributes: response time,

throughput, failure probability, etc.?

• Which component is the bottleneck? Should it be

upgraded or replicated?

7.2 Quality Attributes Analysis

In the following, we present the basis of induction and

inequalities generated relatively to the server(S).

Basis of Induction. We write:

Datasource.output.RT >= 0,

Datasource.output.FP >= 0,

Datasource.output.TP <= infinity,

Inequalities between Ports of S and Roles of Con-

nectors. Let’s take the example of the link between S

and the connector Cn1:

S.input.RT >= Cn1.toRole.RT

S.input.FP >= Cn1.toRole.FP

S.input.TP <= Cn1.toRole.TP

Inequalities within Connectors. Let’s take the ex-

ample of the connector Cn1 connecting C to S.

Cn1.toRole.RT >= Cn1.fromRole.RT+Cn1.transTime

Cn1.toRole.FP >= 1-(1-Cn1.fromRole.FP)x

(1-Cn1.transTime)

Cn1.toRole.TP <= Min(Cn1.fromRole.TP;Cn1.transTime)

Inequalities within S. With respect to the two depen-

dency relations, we write:

S.output.RT >= S.input.RT+S.Request.ProcTime

S.output1.RT >= S.input1.RT+S.Response.ProcTime

S.output.FP >= 1-(1- S.input.FP)x

(1-S.Request.FailProb)

S.output1.FP >= 1-(1-S.input1.FP)x

(1-S.Response.FailProb)

S.output.TP<= Min(S.input.TP;S.Request.thruput)

S.output1.TP<=Min(S.input1.TP;S.Response.thruput)

After using Mathematica to solve the inequalities, we

ﬁnd the system attributes presented in table 1:

Table 1: Values of systems properties.

System

Attribute

Response

Time (s)

Throughput

(tr/sec)

Failure

Probab

exp-

Datasink.

outputP.RT

Datasink.

outputP.TP

Datasink.

outputP.FP

ression

value 265 300 0.001

7.3 Bottleneck Analysis

We propose to apply bottleneck analysis to deter-

mine the component that limits system performance.

For each component: client, server and database, we

calculate the

request

(Cp.thruPut×Cp.procTime)

System.Throughput

then we select the componenthaving the largest value.

Client and server components are described by two re-

lations of functional dependency (

Request

(Req)and

Response

(Resp)). Therefore, for each component,

we compute two

demand

values with respect to each

dependency relation (Table 2). For example, for the

server component, we compute two values D

Requete

and D

Reponse

respectively to the relations Request and

Response. They are deﬁned by:

Request

(S.Requete.thruPut×S.Requete.procTime)

System.Throughput

;

Response

(S.Reponse.thruPut×S.Reponse.procTime)

System.T hroughput

Table 2: Components demand values.

Client Server Database

Demand D

Req

= 40 D

Req

= 30 D

Process

values D

Resp

= 62.5

Resp

= 35

77.25

AutomatedQuantitativeAttributesPredictionfromArchitecturalDescriptionLanguage

is the maximum value, therefore the database

component is the bottleneck of the system. To man-

age the problem of the bottleneck component, the de-

signer can proceed in two ways:

• either replace the base data component by another

component with better performance.

• or duplicate this component to distribute the

workload to several other components.

In the following, we will discuss these two solutions

assuming that the rest of the system remains un-

changed and we will compare the new non-functional

properties obtained for each solution.

• First Solution: Component Substitution

We assume that the database component is substituted

by a single instance with improved performance: a

service time of 90 s, a throughputof 350trans/s. Sys-

tem ACME+ Description remains unchanged and the

new values of system properties will be modiﬁed as

shown in Table 3.

Table 3: Case of substitution: System properties.

System

Attribute

Response

Time (ms)

Throughput

(tr/sec)

Failure

Probab

exp-

Datasink.

outputP.RT

Datasink.

outputP.TP

Datasink.

outputP.FP

ression

value 252 350 0.0002

• Second Solution: Component Duplication

We assume that the database component is replaced

by two identical instances of databases: DB1 and

DB2, each of which is characterized by a time ser-

vice 103 s and a throughput 300 trans/s.

Suppose that the server S sends requests to DB1 and

DB2 respectively via connectors Ca1, Ca2 and re-

ceives responses from databases by connectors Cb1

Cb2. We ﬁnd the system attributes represented in the

table 4.

Table 4: Case of duplication: System properties.

System

Attribute

Response

Time (ms)

Throughput

(tr/sec)

Failure

Probab

expression

Datasink.

outputP.RT

Datasink.

outputP.TP

Datasink.

outputP.FP

value 265 500 0.0002

After comparing the results in tables 3 and 4, we

note that the substitution of the database component

by another component with better performance de-

creases the response time of the system, increases

its throughput and decreases its probability of fail-

ure. However replication leads to an unchanged value

of the response time of the system, increases the val-

ues of system throughput and reduces the probability

of failure. The choice of the best solution between

these two cases depends on customer preferences be-

tween getting a faster system or a system with the

same response time and higher throughput. Other fac-

tors such as cost modiﬁcations can also be taken into

account in the ﬁnal decision.

8 CONCLUSION

In this paper, we have proposed ACME+ as an exten-

sion of Acme ADL, on which we attach our analysis

model and discussed the development and operation

of a compiler that compiles architectures written in

this language to generate inequalities that character-

ize non functional attributes of software architectures.

The tool that we have developedincludes the compiler

and the user interface, it permits the experimentation

of ACME+ and its proof of concept. In case of interest

it may be demonstrated at the conference.We are cur-

rently trying to compare the results obtained for some

system non functional attributes with those supported

by other ADLs based on a formal, abstract model of

system behavior. The perspectives of our work are

to add other quantitative non functional attributes and

to investigate more profoundly architecture styles and

dynamic architectures.

REFERENCES

Allen, R. and Garlan, D. (1996). A case study in architec-

tural modeling: The aegis system. In In Proceedings

of the 8th International Workshop on Software Speci-

ﬁcation and Design, pages 6–15.

Denning, P. (2008). Throughput. Wiley Encyclopedia of

Computer Science and Engineering.

Garlan, D., Allen, R., and Ockerbloom, J. (December

1994). Exploiting style in architectural design envi-

ronments. In Proceedings of SIGSOFT’94: Founda-

tions of Software Engineering, pages 175–188.

Garlan, D., Monroe, R., and Wile, D. (November 1997).

Acme: An architecture description interchange lan-

guage. CASCON’97. Toronto, Ontario, page 169183.

Gorlick, M. and Razouk, R. (1991). Using weaves for soft-

ware construction and analysis. In ICSE, pages 23–34.

Medvidovic, N. and Taylor, R. (2000). A classiﬁcation

and comparison framework for software architecture

description languages. IEEE Trans. Software Eng.,

26(1):70–93.

ICSOFT-PT2014-9thInternationalConferenceonSoftwareParadigmTrends
