Incorporating Ad Hoc Phrases in LSI Queries

Roger Bradford

Agilex Technologies Inc, 5155 Parkstone Drive, Chantilly, VA, U.S.A.

Keywords: Latent Semantic Indexing, LSI, Phrase-based Retrieval, Phrase Indexing.

Abstract: Latent semantic indexing (LSI) is a well-established technique for information retrieval and data mining.

The technique has been incorporated into a wide variety of practical applications. In these applications, LSI

provides a number of valuable capabilities for information search, categorization, clustering, and discovery.

However, there are some limitations that are encountered in using the technique. One such limitation is that

the classical implementation of LSI does not provide a flexible mechanism for dealing with phrases. In both

information retrieval and data mining applications, phrases can have significant value in specifying user

information needs. In the classical implementation of LSI, the only way that a phrase can be used in a query

is if that phrase has been identified a priori and treated as a unit during the process of creating the LSI index.

This requirement has greatly hindered the use of phrases in LSI applications. This paper presents a method

for dealing with phrases in LSI-based information systems on an ad hoc basis – at query time, without

requiring any prior knowledge of the phrases of interest. The approach is fast enough to be used during

real-time query execution. This new capability can enhance use of LSI in both information retrieval and

knowledge discovery applications.

1 INTRODUCTION

In 1988, researchers from Bellcore introduced the

technique of latent semantic indexing (LSI) for text

retrieval (Furnas et al, 1988). The technique relies

on the notion of distributional semantics –

specifically, that the meaning of a term in text is

directly correlated with the contexts in which it

appears. LSI accepts as input a collection of

documents and produces as output a high-

dimensional vector space. All of the documents in

the collection are represented by vectors in this

vector space. Similarly, all of the terms that

comprise those documents are represented by

vectors in this vector space (except for very

frequently occurring terms that typically are treated

as stopwords).

LSI employs the technique of singular value

decomposition (SVD) to carry out a large-scale

dimensionality reduction (as described in the

following section). This dimensionality reduction

has two key effects:

 Terms that are semantically related are assigned

representation vectors that lie close together in

the LSI vector space.

 Documents that have similar conceptual content

are assigned representation vectors that lie close

together in the space.

These characteristics of LSI spaces form the

basis for a wide range of applications, ranging from

automated essay scoring to literature-based

discovery (Dumais, 2004). Typically, in these

applications, little or no use is made of phrases.

This is because, in the classical formulation of LSI,

in order for a phrase to be used as such in a query,

that phrase must be identified and treated as a unit in

the initial stage of creating the LSI representation

space. However, experience has shown that it is

quite difficult to predetermine collections of phrases

that will enhance performance in applications. This

paper presents a technique for using phrases in LSI

queries on an ad hoc basis – at query time, without

requiring any changes in existing LSI spaces.

Although LSI primarily has been used with text,

it is a completely general technique and can be

applied to any collection of items composed of

features. LSI has, for example, been used with great

success in categorizing, clustering, and retrieving

audio, image, and video data. Although this paper

focuses on textual phrases, the approach described

Bradford R..

Incorporating Ad Hoc Phrases in LSI Queries.

DOI: 10.5220/0005073300610070

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2014), pages 61-70

ISBN: 978-989-758-048-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

here is equally applicable to non-textual linked

features in other types of media.

2 LSI PROCESSING

The LSI technique applied to a collection of

documents consists of the following primary steps

(Dumais et al 1988):

1. A matrix A is formed, wherein each row

corresponds to a term that appears in the

documents, and each column corresponds to a

document. Each element a

m,n

in the matrix

corresponds to the number of times that the term

m occurs in document n.

2. Local and global term weighting is applied to the

entries in the term-document matrix. This

weighting may be applied in order to achieve

multiple objectives, including compensating for

differing lengths of documents and improving the

ability to distinguish among documents. Some

very common words such as and, the, etc.

typically are deleted entirely (i.e., treated as

stopwords).

3. Singular value decomposition (SVD) is used to

reduce this matrix to a product of three matrices:

A = U Σ V

(1)

Let A be composed of t rows corresponding to

terms and d columns corresponding to

documents. U is then a t*t orthogonal matrix

having the left singular vectors of A as columns.

V is a d*d orthogonal matrix having the right

singular vectors of A as columns. Σ is a t*d

diagonal matrix whose elements are the singular

values of A (the non-negative square roots of the

eigenvalues of AA

4. Dimensionality is reduced by deleting all but the

k largest values of Σ, together with the

corresponding columns in U and V, yielding an

approximation of A:

= U

(2)

which is the best rank-k approximation to A in a

least-squares sense.

5. This truncation process provides the basis for

generating a k-dimensional vector space. Both

terms and documents are represented by k-

dimensional vectors in this vector space.

6. New documents (e.g., queries) and new terms are

represented in the space by a process known as

folding-in (Furnas et al, 1988). To add a new

document, for example, that document is first

subjected to the same pre-processing steps (e.g.,

stopword removal) as those applied to the original

documents used in creating the space. The

document then is assigned a representation vector

that is the weighted average of the representation

vectors for the terms of which it is composed. A

similar process is employed to fold in new terms

(see section 5.2 for more detail).

7. The similarity of any two objects represented in

the space is reflected by the proximity of their

representation vectors, generally using a cosine

measure. Results of queries are sorted by cosine:

the higher the cosine, the more similar the

returned object (term or document) is to the

query.

Extensive experimentation has shown that

proximity of objects in such a space is an effective

surrogate for conceptual similarity in many

applications (Bradford, 2009).

3 PHRASES

People directly perceive phrases as having utility in

representing the information content of documents.

For example, Figure 1 shows the distribution of the

number of tokens constituting indexing elements

chosen by professional indexers for a set of technical

journal articles in INSPEC (Hulth, 2004). Less than

14% of the indexing elements chosen consist of

single tokens.

Figure 1: Human choice of phrases as indexing elements.

Phrase search is widely used in information

retrieval. In (Manning, Raghavan, and Schütze,

2008) it is reported that as many as 10% of web

queries are explicit phrase queries (i.e., entered

within quotes) and many more are implicit phrase

queries entered without double quotes. Use of

phrases in queries is a standard capability in most

contemporary text retrieval systems.

12345678910

Number of Tokens in Indexing Element

Number of Elements

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

With the classical formulation of LSI, if, for

example, life cycle analysis is used as a query, the

system will retrieve the LSI representation vectors

for each of these individual words and then form a

query vector that is the weighted average of these

three vectors. Since the words life, cycle, and

analysis are used in many contexts other than that

indicated by the phrase life cycle analysis, the query

vector thus formed will constitute a poor

approximation of an appropriate vector for

representing the specific concept of life cycle

analysis.

The problem is particularly acute for names of

persons. For example, in many document

collections, an LSI search for George Cheney (the

internationally known speaker and writer on

organizational communication) would yield very

poor results, because the many references to George

Bush and Dick Cheney would create representation

vectors for George and Cheney that were closely

associated with politics as opposed to the

educational context of George Cheney. Although

entity extraction can be, and often is, used in

creating LSI spaces, even the best contemporary

entity extractors miss or incorrectly render on the

order of 20% of the names in typical real-world

document collections. This can be a major

limitation in discovery applications where names of

people provide key context.

It has long been recognized that treating phrases

as units could have beneficial effects in LSI

applications. In one of the earliest papers on LSI,

the inventors of the technique noted the potential

value of use of phrases:

“We think we can greatly improve performance by

incorporating short phrases…” (Dumais et al,

1988) (emphasis added).

4 RELATED WORK

There is a long history of investigation of the utility

of phrases in information retrieval. Global

approaches (i.e., broadly treating phrases in a

document collection as indexing elements) have

yielded generally disappointing results.

As early as 1975, Salton et al showed that use of

statistically-derived phrases could improve retrieval

performance for SMART, a then-current vector-

space-based text retrieval system (Salton, Yang, and

Yu, 1975). The authors obtained improvements in

average precision of 17-39%, but were dealing with

very small text collections (each less than 500

documents). In 1989, Fagan carried out similar

experiments, obtaining mixed results, varying from

-11% to +20%, with somewhat larger test collections

(up to 12 thousand documents) (Fagan, 1989). In

1997, Mitra conducted similar tests with a collection

of 211 thousand documents, obtaining precision

improvements of 1% (Mitra et al, 1997).

There are two primary factors responsible for the

observed decline over time of phrase impact in these

studies – the larger sizes of the test collections

employed and the fact that the comparison baseline

(retrieval performance using individual terms)

improved significantly over that 20-year time frame.

In discussing results from the first five TREC

conferences, Mitra et al noted that: “In the past five

years of TREC, overall retrieval effectiveness for

SMART has more than doubled, but the added

effectiveness due to statistical phrases has gone

down from 7% to less than 1%” (Mitra et al, 1997).

In 1999, Turpin and Moffat provided additional

evidence that, as performance of vector-space-based

information retrieval systems employing individual

terms improved, the utility of adding phrases

diminished (Turpin and Moffat, 1999).

Summarizing the first eight years of TREC

testing, Harman noted: “the investigation of the use

of phrases in addition to single terms … has long

been a topic for research in the information retrieval

community, with generally unsuccessful results. …

almost all (TREC) groups have experimented with

phrases. In general, these experiments have been

equally unsuccessful” (Harmon, 2005).

In 2006, Metzler, Strohman, and Croft reported

results of their work over three years on the TREC

Terabyte tracks. During that period they performed

a variety of tests using statistically-derived phrases.

None of the techniques tried yielded improvement

over a bag-of-words baseline (Metzler, Strohman,

and Croft, 2006).

Multiple approaches have been tried for

automatically identifying phrases of interest within a

document collection. In general, these produce far

more candidate phrases than is desirable. A number

of approaches have been tried for pruning long lists

of candidate phrases. Somewhat surprisingly,

applying filtering criteria such as mutual information

and entropy generally has not resulted in lists of

phrases that yield significant retrieval enhancement.

There has been some success with selecting

specific types of phrases. Ogawa et al employed

two-term noun phrases in tests using TREC-8

queries applied to the WT2g document collection

(247 thousand documents) and TREC-9 queries

applied to the WT10g document collection (1.7

million documents). They achieved improvements

IncorporatingAdHocPhrasesinLSIQueries

in average precision of 3 to 12 percent using phrases

derived from the TREC queries. For phrases derived

from query expansion, they achieved improvements

for the smaller test set, but not for the larger one

(Ogawa et al, 2000). Zhai et al achieved similar

results for noun phrases with TREC-5 queries (Zhai

et al, 1996). Kraiij and Pohlmann found modest

improvements using proper names as indexing units

(Kraiij and Pohlmann, 1998). Jiang et al had good

success with classifier-thing bigrams (word pairs in

which the first word effectively selects for a subclass

of the type referred to by the second word) (Jiang et

al, 2004).

Some techniques for creating lists of phrases

derive the candidates from existing data collections.

In particular, WordNet and Wikipedia have been

popular sources of candidate phrases. However,

these approaches typically have not shown a

significant advantage over other techniques.

Counterintuitively, human selection of phrases

also generally has not produced significant

improvements in retrieval performance. In 2010,

Broschart et al conducted experiments using the

TREC GOV2 collection (25 million documents),

three sets of TREC queries, and five users. For all

five users, incorporation of their chosen phrases as

indexing units yielded overall lower average

precision than the baseline comparison (BM25F).

They found that users frequently disagreed on

phrases in the TREC queries. On average, two users

highlighted the same phrase only 47% of the time

(Broschart, Berberich, and Schenkel, 2010). Such

inconsistencies also were noted by Kim and Chan.

They had ten human subjects read articles averaging

1300 words in length and choose the ten most

meaningful phrases from each one. On average,

only 1.3 phrases matched those chosen by others

(Kim and Chan, 2004).

There has been little reported testing of phrase

pre-processing for LSI. In 2000, Lizza and

Sartoretto incorporated two-word phrases into LSI

indexes for small document collections. They

reported a 9% improvement in average precision for

the TIME collection (423 documents), but no useful

increase for the MEDLINE (1033 documents) and

CISI (1460 documents) collections (Lizza and

Sartoretto, 2000).

Weimer-Hastings investigated the effect of

incorporating noun and verb phrases when using LSI

to grade student answers to questions. He employed

manually identified phrases in comparing student

answers with expected answers. He found a

decrease in correlation with human evaluations

when the phrases were used (Weimer-Hastings,

2000).

Wu and Gunopulos tested LSI with two-word

phrases, selected based on a threshold for either

document frequency or information gain. In their

testing, they employed the R118 subset of the

Reuters 21578 test set. They only were able to

increase F1 for that test set from .8417 to .8449,

which was not statistically significant (Wu and

Gunopulos, 2002).

Nakov, Valchanova, and Angelova examined the

impact of different text pre-processing steps

(lemmatization, stopword removal, etc) in using LSI

for document categorization. They employed a test

set of 702 Bulgarian-language documents assigned

to 15 categories. Altogether they tested 120

combinations of local weight, global weight, and

LSI dimensions. In 87 of these cases, incorporating

phrases into the LSI index yielded no change in

microaveraged categorization accuracy for the

collection. In 27 cases there was an improvement;

for 9 cases the results were worse. Most

improvements were 1% or less. In all cases where

the best-performing local and global weights were

used, phrase processing had no effect (Nakov,

Valchanova, and Angelova, 2003).

Grönqvist examined LSI performance on a

synonym test of 440 Swedish queries, with 10.9% of

the queries and 35.5% of the answers consisting of

phrases. Results from creating the LSI index with

and without phrases are shown in Table 1. He noted

that the difference between the first case and the

second was not statistically significant, but that the

difference between the first and the third was

(Grönqvist, 2005A). Overall, incorporation of two-

and three-word phrases (Grönqvist, 2005B):

 Corrected 30 queries that had been incorrectly

evaluated by classical LSI.

 Incorrectly judged 15 queries that had been

correctly evaluated by classical LSI

Table 1: LSI phrase indexing results.

Indexedterms %Correc

Individualwords

59.55%

Individualwords+two‐word

phrases

61.59%

Individualwords+two‐word

phrases+three‐wordphrases

62.73%

In his thesis, Grönqvist also performed document

retrieval tests with 101 CLEF topics for Swedish and

133 TREC topics for English. For Swedish, there

was a small decrease in performance when

incorporating phrases. For English, the results were

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

essentially unchanged from the individual word case

(Grönqvist, 2006).

Olney used LSI for determining the semantic

equivalence of sentence pairs. He employed two test

sets - the Microsoft Research Paraphrase Corpus and

a corpus based on the novel 20,000 Leagues under

the Sea. The training set consisted of the TASA

corpus (~70 MB of text) combined with the Wall

Street Journal section of the Penn Treebank

(~50,000 words). In creating the term-document

matrix he included all word bigrams that occurred

more than once. This increased the number of rows

in the matrix by an order of magnitude (from 75,640

to 756,741). He found a negligible difference in task

performance for both test sets. A variant in which

word trigrams were used as context, rather than

documents, also yielded no significant difference

Olney, 2009).

Collectively, these studies suggest that pre-

selection of phrases for LSI indexing has limited

utility, at least using current phrase selection

techniques. This result is consistent with the

previously-cited studies of use of phrases with other

vector-space-based information retrieval techniques.

One consistent result in all of the above studies

is that, although overall task performance was not

notably enhanced through use of phrases, the

performance for certain queries was significantly

enhanced when relevant phrases were employed. In

light of the difficulties in pre-selecting phrases, this

result, together with the user predilection to employ

phrases noted in section 3, provides strong

motivation for development of an ad hoc phrase

query capability for vector space retrieval. The

following discussion presents a novel method of

providing such a capability in LSI spaces.

5 AD HOC PHRASE

PROCESSING METHOD

The fundamental characteristics of an LSI space

enable a query-time phrase processing capability for

LSI. The key relevant characteristic of the technique

is the duality condition described below.

5.1 Duality Condition

In any LSI space, the following duality condition

holds:

 The LSI representation vector for any document

corresponds to the weighted average of the LSI

vectors for the terms contained in that

document.

 The LSI representation vector for any term

corresponds to the weighted average of the LSI

vectors for the documents that contain that term.

5.2 Phrase Vector Creation Method

For a given LSI space, the proposed procedure for

generating a representation vector for an arbitrary

given phrase is as follows:

1. Identify the documents from the indexed

collection that contain the given phrase.

2. Retrieve the LSI vectors corresponding to those

documents.

3. Calculate the weighted sum of those

representation vectors. (Using the notation of

section 2, let P be the 1*d vector whose

components indicate frequency of occurrence of

the phrase in the documents of the collection,

weighted by the same global and local

weighting algorithms as used in creating the

original LSI index. The new phrase vector is

then given by PV

-1

The resulting vector will be a good

approximation of the vector that would have been

created if that phrase had been treated as a unit

during the LSI pre-processing stage. It is not exactly

the same vector, because of the complex balance that

is created between term and document vectors when

the SVD algorithm is applied to the collection as a

whole during the creation of the LSI space.

Changing what are considered to be terms within a

set of documents has transitive impacts that affect

the entire LSI space created from those documents.

These changes will create differences in retrieval

results. However, as shown in the following

examples, the approximation vector produced using

this method is quite accurate, at least for an LSI

space of reasonable size.

In order for this technique to be applied at query

time, the process of creating the approximation

vector for a phrase must be quite fast (on the order

of seconds). Thus all three steps described above

must be carried out rapidly:

 For a given phrase, it is necessary to rapidly

determine which documents contain that phrase.

This necessitates use of an inverted index of

term occurrences. This easily can be

implemented using a variety of open source or

commercial software packages. With modern

hardware and software implementations,

providing response times on the order of

seconds for this function is straightforward,

IncorporatingAdHocPhrasesinLSIQueries

even for large document collections. Moreover,

modern LSI applications frequently incorporate

a Boolean retrieval capability for added

flexibility. In such cases, the needed inverted

index will already be available. For example,

the LSI engine employed in the testing

described here comes bundled with the DT

Search commercial Boolean text retrieval

system. Many extant LSI applications employ

the Lucene open source text retrieval engine for

Boolean retrieval. Such software can retrieve

postings lists for terms (and combine them into

occurrence lists for phrases) with sub-second

response, even for large document collections.

 Once the set of documents containing the phrase

has been identified, retrieving the corresponding

LSI vectors (and their term weights) is a

straightforward database lookup process, using

the same database used for other LSI retrieval

functions.

 Combining the vectors can be carried out

rapidly in local memory.

In contemporary hardware environments it is

quite feasible for this series of operations to be

carried out in near-real time (seconds) while

processing a user query.

5.3 Examples

The most straightforward method of demonstrating

the efficacy of an ad hoc technique such as this is to

directly compare the results of example LSI queries

involving phrases for three cases:

1. Where there is no attempt at specific phrase

processing (classical LSI processing, where the

terms of the phrase are treated independently).

2. Where the phrase is treated as a unit during pre-

processing of the text of the document

collection (so that the phrase is treated as a

single feature in creating the term-document

matrix).

3. Where the phrase is processed at query time

using the procedure described above.

The following examples were generated using

LSI spaces constructed from a collection of 1.6

million news articles from the time frame 2012-

2013. This document set was a convenient size for

experimentation, although at the lower end of

collection size for contemporary enterprise LSI

applications, most of which tend to range from

millions to tens of millions of documents (Bradford,

2011). The LSI indexes were created using the

following processing parameters: logarithmic

weighting locally, entropy weighting globally, 300

dimensions, and pruning of terms that only occurred

once. (These are typical parameters for

contemporary LSI applications).

A decision was made to carry out entity

extraction for PERSON, LOCATION, and

ORGANIZATION entities as a pre-processing step

for the baseline LSI case. The ad hoc query

technique described here is eminently suitable for

dealing with named entities. If these entities had not

been included in the baseline case, quite striking

examples could have been presented here for ad hoc

retrieval of person, organization, and location

names. However, it has become routine practice in

recent years for entity extraction to be applied as a

pre-processing step in creating LSI indexes for

applications. (Named entities are one exception to

the problem of pre-determining multiword units.

Even with the error rates of contemporary entity

extractors, incorporating entity extraction into LSI

pre-processing has been shown to have significant

beneficial effect on LSI performance in most

applications). Since it is so widely used, it was felt

that the most meaningful baseline for comparisons

for this paper would be an LSI index that included

entity pre-processing.

The entity extraction was carried out using a

commercial entity extraction product (Rosoka

version 3.0). The LSI indexing was carried out

using a commercial LSI engine (Content Analyst

version 3.10). Index creation time was

approximately 45 minutes employing 16 m1.xlarge

Amazon AWS EC2 instances for creation of the

term-document matrix and one cr1.8xlarge instance

for the SVD calculation.

In each of the following examples, three sets of

results are presented for each phrase query:

 The first set of results was generated using a

query against a classical LSI index, with no

specific phrase processing.

 The second set of results was produced by

taking the given phrase and building a new LSI

space, identical to that of the previous case, with

the single exception of treating that one phrase

as a unit during the LSI processing.

 The third set of results was obtained by

employing the ad hoc phrase retrieval technique

described in this paper.

In each of the following three examples, the

tables show the ten terms in the LSI space that were

ranked closest to the query vector corresponding to

the given phrase (i.e., those terms having the highest

cosine value between their representation vectors

and that of the query). For the news articles used in

the testing, there are many similar terms. Requiring

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

exact matches within the top ten terms out of the 1.5

million total terms in the collection is a rather

stringent measure of performance.

Only the top ten terms are shown here, due to

space limitations. However, examination of the top

100 terms demonstrated comparable degrees of

similarity in each case. In general, the higher the

indicated overlap for the top terms in each example,

the greater the similarity would be for the results of

any query related to or containing the given phrase.

5.3.1 Example 1

For this example, the query phrase was gross

national product. Table 2 shows the closest ten term

results for this phrase used as a query, for each of

the three phrase processing variants.

Table 2: Top ten term results for query = gross national

product.

PHRASE PROCESSING

NONE PRE-

PROCESSED

AD HOC

1. product lithuanian_minis

try_of_finance

gdp

2. national expenditures gross

3. gross estonian_statisti

cs__office

expenditures

4. projected icelandic_treasu

lithuanian_minis

try_of__finance

5. flajs unipolarization dependent

6. andrej_flajs spkef dependency

7. forecasts economy gdps

8. projections economic estonian_statisti

cs_office

9. grow pajula icelandic_treasu

10. slower asfinag expenditure

For the case where there was no phrase

processing, the top three (closest) terms correspond

to the individual terms in the phrase. This is

classical LSI - treating the phrase as a

straightforward combination of the meanings of its

individual terms. Terms five and six refer to Andrej

Flajs, who was the lead author on a study of gross

national income which is frequently referenced in

the articles of the collection. Terms four and seven

through ten are all generic terms that occur

frequently in articles in the context of discussion of

gross national product (GNP).

For the case where the phrase was treated as a

unit in pre-processing, the top ten results are quite

different. Three of the top four terms are names of

organizations. During the time frame of the articles,

there was extensive news coverage of the European

financial crisis. These three organizations were

frequently mentioned in news articles related to

GNP changes in that time frame. SpKef was the

largest savings bank in Iceland, which failed. Hardo

Pajula is an economic analyst who wrote extensively

on the Euro Zone crisis in this time period.

ASFiNAG is a corporation that was a significant

contributor to high Austrian debt in this time frame.

It is interesting that there is no overlap among

the top ten terms for these two cases. The classical

implementation of the LSI query yields terms that

are generically related to a discussion of gross

national product. However, as indicated, identifying

those three words as constituting an important

phrase, and treating it as a unit in the LSI pre-

processing, yields much more specific results. The

results focus on key entities central to discussions of

GNP in these specific documents.

For the ad hoc phrase processing approach

described in this paper, four of the top ten terms

overlap with the top ten terms retrieved in the full

phrase pre-processing instance. In fact, these four

overlap terms are the top four terms retrieved in the

pre-processed case.

5.3.2 Example 2

For this example, the query phrase was rare earth

element. (Rare earth elements are members of a

subgroup of the periodic table of elements, plus

scandium and yttrium). Table 3 shows the closest

ten terms for this phrase for each of the three phrase

processing variants.

Table 3: Top ten term results for query = rare earth

element.

PHRASE PROCESSING

NONE PRE-

PROCESSED

AD HOC

1. earth praseodymium dysprosium

2. earths dysprosium rare

3. rare rhodia bastnasite

4. planetary association_of_c

hina_rare_earth

praseodymium

5. planets molycorp molycorp

6. comets scandium superfund

7. asteroids nechalacho molycorp_inc

8. jpl molycorp_inc association_of_

china__rare_ea

rth

9. hi_tech_co jia_yinsong nechalacho

10. asteroid bastnasite su_bo

IncorporatingAdHocPhrasesinLSIQueries

For the case of no phrase processing, it is clear that

the results are driven by the term earth. The terms

rare and element are used in multiple contexts, but,

in this collection, earth is discussed almost always in

the context of being a planet. Accordingly, seven of

the top ten terms in this case have the context of

celestial bodies. JPL is an acronym for Jet

Propulsion Laboratory, a leading US organization

for space exploration.

As in the first example, there is no overlap

between the top ten results for the case of no phrase

processing and the results for the pre-processed case.

In the pre-processed case, the top two terms and the

sixth term are names of rare earth elements. Rhodia

is the name of a leading rare earth production

company. The fourth term in the listing is the

Association of China Rare Earth Industry, from

which the entity extractor has dropped the word

industry. Molycorp is a mining company that is a

major supplier of rare earth ores. Nechalacho is the

site of a major mining activity for rare earth ores.

Jia Yinsong is chief of the Rare Earth Office of the

Ministry of Industry and Information Technology in

China. Bastnasite is the most abundant rare earth

element mineral.

In this example, the contexts of the two result

lists for the no-phrase-processing and the phrase-

pre-processing instances are completely different.

Whereas in the previous case, a user might have

been willing to work with the more general results

given by classical LSI for gross national product; in

this case, the results with no phrase processing are

completely unrelated to the intent of the query rare

earth element.

In this example, the ad hoc approach has

performed very well. Seven of the top ten terms

from the phrase-pre-processing instance occur

among the top ten terms for the ad hoc case. This

includes the top two terms from the pre-processed

case. Su Bo is Vice Minister of Industry in China.

The news articles contain excerpts from a number of

speeches that he made about rare earth elements in

this time frame.

In this case, the phrase is highly non-

compositional; i.e., its meaning is not a simple

combination of the meanings of its constituent

words. (Actually it is not a simple combination of

the dominant senses of the constituent terms in this

collection). The technique described here has its

greatest impact for such phrases. For this type of

query, use of the technique described here would

have a significant beneficial impact on user

satisfaction.

5.3.3 Example 3

For this example, the query phrase was highly

enriched uranium. Table 4 shows the closest ten

terms for this phrase for each of the three phrase

processing variants.

For the case with no phrase processing, the terms

are generally related to uranium enrichment. Fordo

is the site of a uranium enrichment plant in Iran.

For the case where the phrase was treated as a

unit in pre-processing, the top ten results are quite

different – there is only one term that also occurred

in the top ten for the no-phrase-processing case.

With phrase pre-processing, the acronym for

highly enriched uranium (HEU) is the top term, as

might be expected. Nuclear Threat Initiative is a

nonprofit organization dedicated to reducing the

spread of weapons of mass destruction. CPPNM is

an acronym for Convention on the Physical

Protection of Nuclear Material. Robert Gallucci is

president of the MacArthur foundation. Miles

Pomper is a Senior Research Associate at the Center

for Nonproliferation Studies. Frank N. von Hippel

is Co-Director of the Program on Science and

Global Security at Princeton University. Multiple

news articles from the collection dealt with papers

that these individuals had written and speeches that

they had given related to nuclear proliferation.

Table 4: Top ten term results for query = highly enriched

uranium.

PHRASE PROCESSING

NONE PRE-

PROCESSED

AD HOC

1. uranium heu plutonium

2. enriched plutonium heu

3. enrichment fissile fissile

4. weapons-

grade

nuclear_threat_i

nitiative

weapons-

grade

5. fordo weapons-grade nonproliferati

6. international

_atomic_ene

rgy_agency

robert_gallucci enriched

7. iaea nonproliferation nuclear

8. centrifuges cppnm gary_samore

9. centrifuge miles_pomper nuclear_threat

__initiative

10. enriching hippel siegfried_hec

ker

The ad hoc approach performed well for this

phrase. Six of the top ten result terms from full

phrase pre-processing occur in the ad hoc result list,

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

including the top five terms from the pre-processed

case.

The other terms presented also have the

appropriate context. Gary Samore is the Executive

Director for Research at the Belfer Center for

Science and International Affairs. Siegfried Hecker

was co-director of the Center for International

Security and Cooperation from 2007-2012. Multiple

articles from the collection discussed speeches given

and papers written by these two individuals that

dealt with nuclear proliferation.

A summary of the term overlap results from

these examples is shown in Table 5.

An interesting aspect of the term results is their

specificity. Considering the three examples taken

together, only 23% of the terms produced by

classical LSI corresponded to named entities. More

than three-fourths were general terms. The pre-

processed results were much more specific. More

than half (57%) corresponded to named entities.

The ad hoc technique described here produced

results intermediate between these – 40% of those

results were named entities.

Table 5: Comparison of Result Sets.

Phrase

Overlap of Result Sets with those for

full phrase pre-processing

No Phrase Pre-

processing

Ad Hoc

Technique

Top 10

Terms

Top

100

Docs

Top 10

Terms

Top

100

Docs

gross national

product

12% 40 %

52%

rare earth

element

15% 70%

79%

highly enriched

uranium

10%

3% 60%

47%

5.3.4 Document Result Comparisons

Examination of the results for retrieved documents

showed patterns similar to those for terms. In these

tests, each of the three example phrases was used as

a query and the 100 highest-ranked documents were

retrieved. These results also are shown in table 5.

They show differences similar to those for terms.

For the news articles used in the testing, there are

many similar documents. Requiring exact matches

within the top 100 documents out of 1.6 million is a

relatively strict measure of performance.

Although space limitations preclude showing

other examples, all phrases tested have shown

results similar to those in Table 5. In general, the

results are most striking when the query phrase is

highly non-compositional. Overall, for term

retrieval, the average overlap between the no-phrase-

processing results and those for full phrase pre-

processing is only a few percent. For document

retrieval, the average overlap is only about 10%.

For the technique described in this paper, the

average overlap with full phrase pre-processing for

both types of retrieval is close to 60%.

The test data demonstrate that the retrieval

results generated using the proposed technique

constitute a useful approximation of those that

would have been obtained if the given phrases had

been treated as indexing units during the creation of

the LSI spaces.

6 CONCLUSIONS

The method described here provides an approach for

using arbitrary phrases as queries in an LSI space

after the LSI index has been created. Tests

demonstrate that the results of such queries are a

useful approximation of the results that would have

been obtained if those phrases had been treated as

indexing units during the creation of the LSI space.

This is true both when retrieving closest terms and

closest documents. In contemporary hardware

environments, the technique is fast enough that it

can be used for near-real-time processing at query

time.

The implementation of this technique in LSI-

based information systems can be anticipated to

yield improvements in user satisfaction. Users are

accustomed to being able to use phrase searches in

Boolean retrieval systems and find their absence in

LSI systems a limitation. There also are clear

improvements in performance for many queries. In

general, the precision of results obtained using the

technique described here will be much greater than

that obtained by simply including the individual

terms of the phrase in a standard LSI query. This is

particularly true for highly non-compositional

phrases.

The technique described here is equally

applicable for English- and for foreign-language

text. It also has direct analogues for dealing with

coupled features in LSI spaces used to represent

non-textual data.

Some advanced knowledge discovery

applications employ workflows in which LSI queries

are automatically generated. Such applications

typically emphasize generation of high-precision

result sets. The technique described here is

particularly applicable to such environments.

IncorporatingAdHocPhrasesinLSIQueries

ACKNOWLEDGEMENTS

The author would like to thank the members of the

Semantic Engineering staff at Agilex Technologies

who participated in the reported testing. He would

also like to thank the anonymous referees, who made

suggestions that significantly improved the quality

of the paper.

REFERENCES

Bradford, R., 2009. Comparability of LSI and human

judgment in text analysis tasks. Proceedings, Applied

Computing Conference, Athens, Greece, 359-366.

Bradford, R., 2011. Implementation techniques for large-

scale latent semantic indexing applications.

Proceedings, ACM Conference on Information and

Knowledge Management, Glasgow, Scotland,

October, 2011.

Broschart, A., Berberich, K., Schenkel, R., 2010.

Evaluating the potential of explicit phrases for

retrieval quality. Proceedings, ECIR 2010, 623-626.

Dumais, S., 2004. Latent semantic analysis. ARIST

Review of Information Science and Technology, vol.

38, Chapter 4.

Dumais, S., et al, 1988. Using latent semantic analysis to

improve access to textual information. Proceedings,

CHI 88, June 15-19, 1988, Washington, DC, 281-285.

Fagan, J., 1989. The effectiveness of a nonsyntactic

approach to automatic phrase indexing for document

retrieval. JASIS, 40(2), 115-132.

Furnas, G., et al, 1988. Information retrieval using a

singular value decomposition model of latent semantic

structure. Proceedings 11

SIGIR, 465-480.

Grönqvist, L., 2005A. An evaluation of bi- and tri-gram

enriched latent semantic vector models. ELECTRA

Workshop, Methodologies and Evaluation of Lexical

Cohesion Techniques in Real-world Applications,

Salvador, Brazil, 19 August, 2005, 57–62.

Grönqvist, L., 2005B. Evaluating latent semantic vector

models with synonym tests and document retrieval.

ELECTRA Workshop, Methodologies and Evaluation

of Lexical Cohesion Techniques in Real-world

Applications, Salvador, Brazil, 19 August, 2005, 86–

88.

Grönqvist, L., 2006. Exploring Latent Semantic Vector

Models Enriched With N-grams. PhD Thesis, Växjö

University, Sweden.

Harmon, D., 2005. The TREC ad hoc experiments. In

TREC: Experiment and Evaluation in Information

Retrieval, Voorhees and Harmon, eds, MIT Press.

Hulth, A., 2004. Combining Machine Learning and

Natural Language Processing for Automatic Keyword

Extraction. Thesis, Stockholm University, April,

2004.

Jiang, M., et al, 2004. Choosing the right bigrams for

information retrieval. Proceeding of the Meeting of

the International Federation of Classification

Societies, 2004, 531-540.

Kim, H-R., and Chan, P., 2004. Identifying variable-

length meaningful phrases with correlation functions.

Proceedings, ICTAI, 2004, 16th IEEE International

Conference on Tools with Artificial Intelligence, 30-

38.

Kraaij, W., and Pohlmann, R., 1998. Comparing the

effects of syntactic vs. statistical phrase indexing

strategies for Dutch. Proceedings, ECDL 98, LNCS

1513, 605-617.

Lizza, M., and Sartoretto, F., 2001. A comparative

analysis of LSI strategies. In Computational

Information Retrieval, M. Berry ed., SIAM, 171-181.

Manning, C., Raghavan, P., and Schütze, H., 2008.

Introduction to Information Retrieval, Cambridge

University Press, 36.

Metzler, D., Strohman, T., Croft, W., 2006. Indri at TREC

2006: lessons learned from three terabyte tracks.

Proceedings, Fifteenth Text REtrieval Conference,

NIST Special Publication SP 500-272.

Mitra, M., et al, 1997. An analysis of statistical and

syntactic phrases. Proceedings of RIAO 97, Montreal,

Canada, 200-214.

Nakov, P., Valchanova, E., and Angelova, G. 2003.

Towards deeper understanding of the LSA

performance. In Proceedings, Recent Advances in

Natural Language Processing, 2003, 311-318.

Ogawa, Y., et al, 2000. Structuring and expanding queries

in the probabilistic model. Proceedings, Ninth Text

REtrieval Conference (TREC-9), NIST Special

Publication 500-249, 427-435.

Olney, A. 2009. Generalizing latent semantic analysis. In

Proceedings, 2009 IEEE International Conference on

Semantic Computing, 40-46.

Salton, G., Yang, C., Yu, T., 1975. A theory of term

importance in automatic text analysis. JASIS, 26(1),

33-44.

Turpin, A., and Moffat, A., 1999. Statistical phrases for

vector-space information retrieval. Proceedings,

SIGIR 99, Berkley, CA, August 1999, 309-310.

Weimer-Hastings, P. 2000. Adding syntactic information

to LSA. In Proceedings of the 22

Annual Meeting

of the Cognitive Science Society.

Wu, H., and Gunopulos, D. 2002. Evaluating the utility

of statistical phrases and latent semantic indexing for

text classification. Proceedings ICDM, 713-716.

Zhai, C., et al, 1996. Evaluation of syntactic phrase

indexing – CLARIT NLP track report. In

Proceedings, Fifth TExt Retrieval Conference, NIST

Special Publication 500-238, 347-358.

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval
