An Ontology for Enforcing Security and Privacy Policies on Mobile

Devices

Brian Krupp, Nigamanth Sridhar and Wenbing Zhao

Electrical and Computer Engineering Department, Cleveland State University,

2121 Euclid Ave, Cleveland, OH 44115, U.S.A.

Keywords:

Mobile Devices, Security and Privacy, Ontologies.

Abstract:

Mobile devices have experienced explosive growth and rapid adoption. These devices have also become troves

of security and privacy data of the consumers that utilize them. What makes mobile devices unique from

traditional computing platforms is the additional sensing components they contain and their ease of access

which allow consumers to make these devices a part of their lives. Additionally these devices are fragmented

in operating systems, sensing capabilities, and device manufacturers. In this paper we deﬁne an ontology that

can be utilized as a foundation for enforcing security and privacy policies across all mobile devices, and use

the ontology to deﬁne policies and to model knowledge elements for mobile devices. We also identify areas

where the policies can be applied, including whether to enforce policies on the device or in the cloud.

1 INTRODUCTION

Mobile devices continue to grow in prominence in

utilization across both consumers and businesses.

For vast number of consumers, mobile devices have

become their primary communication and enter-

tainment devices in their day to day lives. For

example Foursquare claims that there have been

over ﬁve billion check-ins using their application

alone (Foursquare, 2014). Likewise, Twitter claims

an average of 5,700 tweets per second (Twitter, 2014).

Mobile devices are equipped with a variety of sen-

sors that may log the activities and locations of their

users. Hence, such data can be highly personal and

sensitive and must be protected by proper security and

privacy policies and mechanisms. The task of pro-

tecting such data is made even more challenging due

to the need of synchronization of personal data across

all devices using cloud based services such as iCloud,

OneDrive, Google Drive, etc.

The need for developing and enforcing security

and privacy policies on mobile devices can be demon-

strated by recent privacy leaks and security exploita-

tions. For example the popular social networking

application Facebook was found to leak a user’s

phone number without a user logging into the appli-

cation (Symantec, 2014). Another example regarding

the popular mobile game Angry Birds not only col-

lects user’s privacy data such as their location but this

data has also been targeted by agencies such as the

NSA (Ball, 2014) to proﬁle users.

In this paper we build on previous research and

analysis of the most widely used mobile operating

systems to propose an ontology that can be used

across all mobile devices to enforce security and pri-

vacy policies for consumers. We deﬁne how to model

the vast amount of knowledge that can be gained from

mobile devices both static and inferred from observed

activity on the device. We then recognize how this

ontology can be utilized and implemented both within

and outside the device.

The rest of this paper is organized as follows. In

Section 2, we discuss the current state of the art in the

ﬁeld of deﬁning security and privacy policies for mo-

bile devices. In Section 3, we provide an overview of

our ontology, and describe it in detail in Sections 4, 5,

and 6. We then describe how the ontology could be

utilized and enforce user deﬁned security and privacy

policies in Section 7. We conclude with a summary

of our contributions and some pointers to future work

in Section 8.

2 RELATED WORK

There has been various work in constructing ontolo-

gies around security and attack behavior with some

of these targeted towards mobile. However related

288

Krupp B., Sridhar N. and Zhao W..

An Ontology for Enforcing Security and Privacy Policies on Mobile Devices.

DOI: 10.5220/0005081502880295

In Proceedings of the International Conference on Knowledge Engineering and Ontology Development (KEOD-2014), pages 288-295

ISBN: 978-989-758-049-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

work that focused on mobile has been limited. Beji

et al. proposed a security ontology towards mobile

devices and took a more traditional security approach

by deﬁning semantics around common security ele-

ments including Asset, Vulnerability, Threat, etc (Beji

and El Kadhi, 2009b). They emphasize that mobile

devices lack standards in this area and the ontology

they proposed took a general approach without a fo-

cus on speciﬁc use cases. They then further extended

their ontology to take a knowledge based approach

(Beji and El Kadhi, 2009a). In both proposals the on-

tology was formally deﬁned in Web Ontology Lan-

guage (OWL). Tsoumas et al. took a similar ap-

proach in focusing on security and proposed an on-

tology with a focus more on the security management

aspect (Tsoumas and Gritzalis, 2006). Their frame-

work also has a knowledge focus which pulls data

from different sources.

Wang et al. proposed an ontology where again

the focus was on security but more with an empha-

sis on vulnerability management (Ju An WangGuo,

2010). They model similar attributes as in Beji et al

with a focus on Attack, Attack Mechanism, Attacker,

Product Vendor, etc. With a focus on being able to

manage vulnerabilities, their goal was to identify pat-

terns from external threats and vulnerabilities more

formally and precise (Ju An WangGuo, 2010).

Woo et al. also focused on modeling vulnerabil-

ities but took a different approach where they pro-

pose an ontology that models behaviors (Woo et al.,

2013). They recognize the difﬁculty to detect a secu-

rity threat with the different methods a system can be

attacked, so they take the approach of looking at be-

haviors that would identify an attack. Their ontology

models classes such as Actions, Behaviors, Abstract

Behaviors, etc.

Focusing on deﬁning policies, Uszok et al. pro-

posed KAoS which is a system of policy and domain

services that allow a computer system to enforce hu-

man expressible policies (Uszok et al., 2003). Pana-

giotopoulos et al. proposed PROACT (Panagiotopou-

los et al., 2010), an ontology focusing on privacy in

smaller components such as wireless sensor compo-

nents.

On the contrary to the work described above, we

propose an ontology that can be used to enforce se-

curity and privacy policies with a focus on mobile de-

vices using a knowledge based approach. Also the uti-

lization of the ontology we propose does not require

modiﬁcation to the operating system and focuses on

both privacy and security concerns.

3 ONTOLOGY OVERVIEW

We propose an ontology that consists of the following

three main categories: Policy, Activity, and Knowl-

edge. The relationship between Activity and different

type of Knowledge are illustrated in Figure 1.

In the Policy category of our ontology, we model

the policies that a user would deﬁne for their mo-

bile device, including ones described in more detail

in (Krupp et al., 2013; Krupp et al., 2014).

In the Activity category, we model real time ac-

tivity on the device that includes elements such as

location activity, network activity, and device state.

Activity is essentially a holding for any activity data

that can be transformed into knowledge. Over time if

it is not transformed into knowledge, the data is dis-

carded. An example of this transformation would be

gathering several locations from the device during the

day. If this data doesn’t contribute to new knowledge,

it will be discarded.

In the Knowledge category we model existing

knowledge and inferred knowledge as deﬁned below:

• Existing knowledge models personal data on the

mobile device including photos, calendar events,

location, etc. The need to model this knowledge is

so that the policies deﬁned by the consumer have

a consistent model to utilize when the policies are

being enforced.

• Inferred knowledge is what can be inferred from

existing knowledge. Since existing knowledge

can be built both from activity and directly from

the user’s personal data on the device, inferred

knowledge may contain previous activity data that

was transformed into knowledge. Knowledge that

can be inferred includes areas such as usage pat-

terns, network activity, and movement of the user.

The two primary drivers of including this in our

ontology is both performance and space. In per-

formance, since inferred knowledge summarizes

a collection of existing knowledge and activity el-

ements, this saves the enforcing application from

having to analyze all elements that made up the

inferred knowledge each time it needs to utilize it.

Also in regards to space, inferred knowledge al-

lows us to remove existing knowledge elements

that may no longer be needed as the inferred

knowledge from the elements that made it would

no longer be needed. This would be an obvious

constraint on an implementation utilizing this on-

tology if it held a historical record of all activ-

ity and existing knowledge without ever disposing

the data. This additional subcategory in our ontol-

ogy prevents the ontology from losing the value of

what that historical data provided.

AnOntologyforEnforcingSecurityandPrivacyPoliciesonMobileDevices

289

Enforcement Service

Activity

Existing Knowledge

Inferred Knowledge

Privacy Data

(Photos, Contacts, etc)

Current Activity

(Location, Network, etc)

Inferred Knowledge from

Existing Knowledge

Mobile Device

Knowledge Built from Activity

Figure 1: Ontology relationship depicting how data that is

modeled exists from one state to another.

For this ontology we identiﬁed the most com-

mon knowledge and activity elements across the most

widely used mobile operating systems. We recognize

that there will be outliers that are not covered in this

ontology based on OS, device, and sensor capability.

However our primary goal is to provide an ontology

that can cover a broad spectrum of devices as opposed

to one set or the union of all attributes of mobile de-

vices. All of the ontology objects discussed above

will be described in greater detail in the following sec-

tions. For this paper we deﬁne the properties that on-

tology elements contain, their relationships with other

objects in the ontology, and examples of application

of the ontology. The ontology we propose here has

been formally deﬁned in OWL using Protege.

4 POLICY

The Policy portion of our ontology is mainly de-

rived from our previous research building a frame-

work for enhancing security and privacy on mobile

devices (Krupp et al., 2013; Krupp et al., 2014). The

policies deﬁned in the ontology are divided into three

main categories: Security, Privacy, and General. An-

other type of policy deﬁned in our ontology is the

ChainablePolicy which links both a security policy

and a privacy policy to provide more ﬁne grained poli-

cies.

4.1 Security

Our main goal in this category is to deﬁne policies

around data transferred or persisted, authentication

data, and ensuring that they are handled using the

proper security mechanisms such as transport layer

security or encryption. The policies deﬁned here are

targeted for non-jailbroken devices but can be used for

jailbroken devices as well. Within the security cat-

egory we deﬁne DataPersistence, NetworkSecurity,

and UserCredential security policies.

With DataPersistence our primary objective is to

ensure that any data persisted on the device would be

properly secured using the minimum encryption level.

Additionally with the availability of syncing data to

cloud based storage providers, we add the ability for

a user to specify policies on permitting data to be

synced. This policy could be used within corporate

networks to ensure that sensitive data is encrypted on

mobile devices in case they are lost or stolen, and that

sensible data would not leave the local network.

The NetworkSecurity policy speciﬁes where data

can leave the device as opposed to DataPersistence

that deﬁnes how data can be persisted on the device.

This policy contains properties that deﬁne what do-

mains the application can communicate to and any

transport layer security requirements on the transmis-

sion of data. This can be be used to restrict any pri-

vacy leakage of an application that sends data on be-

half of the application to third party servers (for exam-

ple, for the purpose of tracking user online behaviors).

Additionally for any sensitive information that is in

transit, a user can ensure that they are using transport

layer security.

Lastly with the UserCredential policy our primary

objective is to ensure that speciﬁc policies around a

user credential being transmitted over a network could

contain its own restrictions. With this policy, we al-

low a global setting that would allow the credential to

be used by all applications.

4.2 Privacy

Both iOS and Android provide general privacy con-

trols that allow an application access to user’s pho-

tos, contacts, location, and other personal data. These

controls provide an all or nothing access to a speciﬁc

class of a user’s personal data. Currently consumers

cannot deﬁne ﬁner granular controls such as allowing

an application to only gather location data in speciﬁc

locations, restricting the access to certain photos from

an application, or not allowing access to a subset of

contact records. With the Privacy category, we aim to

provide these controls.

KEOD2014-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

290

We deﬁne two general categories for privacy poli-

cies which include policies around data that sen-

sors create and policies around data that users create.

Within the policies that users can create, we deﬁne

policies for Calendar, Contacts, and Multimedia. For

all policies we deﬁne a generic policy that speciﬁes

read/write permissions to these data stores. Addition-

ally Calendar and Multimedia contain temporal re-

strictions and Multimedia also allows for spatial re-

strictions. For example, a user could deﬁne that an

application does not have access to photos that were

taken during certain dates or at certain locations. Fur-

thermore, the ontology contains policies that specify

whether or not a particular attribute such as timestamp

or location of an entity can be accessed by an applica-

tion. This is important because even if a user does not

allow an application access to location data, an appli-

cation can easily determine a user’s location patterns

based on the location attribute of the photos taken by

the user. With the Contacts policy there are several at-

tributes such as name, address, phone number, email,

etc. that we deﬁne individual settings to protect ac-

cess to each of these elements.

For all of the policies deﬁned, a user can selec-

tively specify which calendar events, photos and other

multimedia, and contacts that cannot be accessed by

the application. This allows a user to ensure that a

sensitive piece of privacy information is not accessi-

ble by a mobile application.

By sensor data, we refer to the data generated by

various sensors equipped in a mobile device. While

devices can contain accelerometer and gyroscopes,

we ﬁnd that location data is most critical and deﬁne a

robust set of privacy settings around location. Besides

allowing general read access to the location, we deﬁne

properties to allow the user to specify spatial and tem-

poral constraints on gathering the location. Spatial

constraints include speciﬁed regions that the user does

not want their location to be gathered. This policy

could be used to disable location gathering in highly

sensitive locations that a user would not want to share.

This policy could also enable a user to block out loca-

tion gathering at certain times during the day to pre-

vent an application from predicting the pattern of the

user’s movements. Additionally we allow the user to

deﬁne whether or not regional monitoring (geofenc-

ing) is allowed and when gathering the location data

if it should be anonymized, generalized, or provided

as bogus data. Bogus data may be provided when the

application requires a location to be provided to func-

tion, regardless of what that location data is. Gener-

alized would give a consistent location within a given

region for applications that do not need the speciﬁc lo-

cation to provide their functionality such as a weather

Policy

PrivacySecurity

Sensor Data

User Data

Multimedia

Calendars

Contacts

Location

Data

Persistence

Network

General

Chainable

Uses

Figure 2: Ontology relationship depicting how policy is or-

ganized in the ontology.

forecasting application.

4.3 General

The General policy encompass temporal and spatial

policies that would be used as described in the above

policies.

4.4 Chainable

The primary goal of a Chainable policy is to allow

a user to attach several security policies to a privacy

policy. This allows a user to specify that an appli-

cation can gather its location but gathered location

data cannot be transmitted over a network. The policy

also enables a user to allow an application to access a

user’s photos but not write them to the local disk un-

encrypted. A Chainable policy gives the user a deeper

level of control of their privacy data by allowing se-

curity and privacy policies to be combined together,

as shown in Figure 2.

5 ACTIVITY

With the Activity category our objective is to model

common activity that can be gathered from how the

user interacts with the device, and to transform such

activity into knowledge. Activity usually represents

the current state of the device. We specify the follow-

ing Activity policies: Network Status, Location, Bat-

tery, Network, Motion, Multimedia, and Bluetooth.

Most of these policies are self explanatory in what ac-

tivity they model, however some need additional clar-

iﬁcation below.

AnOntologyforEnforcingSecurityandPrivacyPoliciesonMobileDevices

291

Facebook TwitterLinkedIn General

Friend

Post

Connection

Update

Follower

Contact

Message

Figure 3: Shows generalization of integrated application

data.

The Multimedia Activity policy does not contain

the same attributes as Multimedia Knowledge. It is

more concerned with if microphone/camera is en-

abled, or is being recorded or replayed. Network Sta-

tus Activity models what kind of network connection

the user has, and if they are connected using WiFi to

what SSID the device is connected. With Motion Ac-

tivity, we specify how motion data can be used to help

in determining location and movement from one loca-

tion to another.

6 KNOWLEDGE

The Knowledge category encompass both Existing

Knowledge and Inferred Knowledge. Existing Knowl-

edge is gathered from personal data on the device as

well as activities on the device, such as current loca-

tion, network activities, etc. From Existing Knowl-

edge, we can infer deeper knowledge, which we refer

to as Inferred Knowledge, such as the pattern of the

user’s movement with respect to the time of day, or

the kind of personal data the user typically shares with

others. In the following sections we further describe

this part of the ontology.

6.1 Existing Knowledge

Existing Knowledge is used to model data that exists

on the device that is to be persisted as part of the en-

forcement of a user’s given policy. Existing Knowl-

edge can be further divided into Contacts, Creden-

tials, Multimedia, Integrated Applications, Events,

and Sensing.

Contacts, Multimedia, and Credentials model user

supplied data, and they would need to be updated as

needed from what the user has on the device so that

when enforcing a policy, there is a model represent-

ing this data. Integrated Applications is more con-

cerned about applications that have ties into the oper-

ating system such as Facebook, Twitter, and LinkedIn.

The data that these applications provide can be gen-

eralized into a model that includes contacts and mes-

sages as depicted in Figure 3.

Events include Calendars and Task Lists. Both are

very similar in nature but have subtle differences in

that certain elements such as a date and time one must

contain and the other can contain. For example, both

a calendar event and a task list contain a title and some

additional notes. A calendar always has a date and

time associated with it while a task list can contain

those attributes as well if there is a reminder event to

be ﬁred. Additionally both a calendar and a task list

item can have a location associated with it where the

calendar event could be the location of the event and

a task list could be a reminder that is triggered when

the user enters a geofenced location.

6.2 Inferred Knowledge

Inferred Knowledge constitutes valuable elements for

the enforcement of security and privacy policies spec-

iﬁed for a mobile device. Inferred Knowledge in-

cludes Spatial Data, General Usage, and Network Ac-

tivity. Spatial Data further consists of Location at

Time of Day and Movement from Location to Loca-

tion. The former is built from gathered location ac-

tivity over time and can be used to predict the user’s

location given the time of day. The latter is also built

from location data and time, and can be used to pre-

dict the user’s movement behavior. Both allow the ap-

plication that enforces the policy (referred to as ”en-

forcing application” in later text) to determine if an

application is tracking the user’s travel patterns, and

prevent such personal data to be leaked. Additionally

both allow the enforcing application to predict where

a user may be at a given time and ensure that location

data is not leaked if the enforcing application does

not have access to the user’s current location. This

prediction would become more accurate as more lo-

cation activity data is provided.

General Usage captures the knowledge regarding

usage patterns. Time of Day Device is Used Most and

Location Device is Used Most can be used to help

ﬁnd opportune times and locations when a device is

less utilized to carry out more resource intensive op-

erations such as synchronizing data from the device to

an enforcement application. Additionally the enforce-

ment application would know from the most utilized

locations and date times when it would need to allo-

cate additional resources.

General Usage also includes Application Used at

Location, Application Utilized During Day and Time,

and Application Currently Utilized. Application Cur-

rently Utilized is determined from the network activ-

ity on the domain, attempted personal data access, and

data persistence. This allows the application enforc-

ing policies to understand what mobile application is

currently active and enforce the appropriate policies.

If the enforcing application is uncertain what mobile

application is currently being utilized, it can use in-

KEOD2014-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

292

Inferred KnowledgeActivity

Inferred Application Currently Utilized

Inferred

Application Used

at Time of Day

Inferred

Application Used

at Location

Network Activity Location Activity

Figure 4: Various inputs into building inferred knowledge

from activity and previous knowledge.

ferred knowledge from Application Used at Location,

Application Utilized During Day and Time, to deter-

mine what application is active. In each scenario,

if there is a high degree of conﬁdence from the de-

termined application, the detected application would

feedback into the inferred knowledge around applica-

tion utilization (Figure 4).

Network Activity includes Domains Visited at Lo-

cation/Day and Time, High Network Activity on Net-

work Level, Privacy Data to Send, and Large Privacy

Data Upload. By inferring what domains are visited

at a location and time, we can determine what appli-

cation is currently being utilized on the mobile device

if we are unable to determine it from the current ac-

tivity on the device. With inferring the domains, we

can then determine what data may be sent and what

policies to enforce. By inferring how much network

activity is expected given a type of network connec-

tion (Wi-Fi, Cellular), the enforcing application can

detect abnormalities in the amount of data that is be-

ing transferred and designate appropriate resources to

enforce the user’s policies. For example if a user usu-

ally only uploads several or more photos on a Wi-Fi

connection, if we infer that there is a high level of

network activity on a cellular connection we can in-

vestigate further to determine if the abnormality is vi-

olating any security or privacy policies.

By inferring what personal data is sent for a given

application, the enforcing application can expect what

additional personal data may be sent when that appli-

cation is used. This again allows the enforcing ap-

plication to anticipate activities, which strengthens its

enforcement of the policy. Large Privacy Data Up-

load can be inferred by looking for personal data that

may have been sent out over a longer period of time

by an application as opposed to being sent all at once.

The inferred knowledge can be used to detect stealth

attacks that leak privacy data.

7 ONTOLOGY ENFORCEMENT

In the previous sections we deﬁned the ontology that

can be used to deﬁne security and privacy policies

across mobile devices. In this section we address how

the ontology can be enforced and applied as well as

address some potential issues in the implementation

of ontology enforcement. In this section we outline

a service-based ontology enforcement approach. Un-

like previous research on detecting leakage of privacy

information from a device which has traditionally re-

quired modiﬁcation to the operating system, we aim

to remove this requirement to lower the barrier of ef-

fective enforcement of security and privacy policies.

We believe that having the enforcement as a service

outside of the device allows the user’s mobile experi-

ence to remain unaffected by not requiring consump-

tion of the the device’s power as well as not produce

delays in the user experience by performing computa-

tionally expensive operations on the device to enforce

the user’s deﬁned policies.

7.1 Ontology Enforcement Service

An example implementation of the ontology enforce-

ment service is illustrated in Figure 5. The service

consists of two main components. The ﬁrst compo-

nent is a web based proxy service that is responsible

for maintaining the model of the ontology and enforc-

ing the deﬁned policies by examining the intercepted

data originating from the mobile device. The second

component is a client application that is responsible

for reading system-level data from the device that the

proxy service would be interested in, and uploading

the data to the proxy service. We describe these two

components in more detail in the following sections.

Note that all networked communications from the ap-

plications in the device are routed to the proxy ser-

vice.

7.1.1 Client Application

The client application on the device is responsible for

ensuring that system-level data on the device is syn-

chronized with the web based proxy device, as shown

in Figure 5. For example, when a user adds new pho-

tos on the device, the client application needs to en-

sure that this photo exists on the service as quickly as

possible. The client application is also responsible for

occasionally polling activity data on the device and

sending it to the service. The activity data is needed

for both knowledge building and for the proxy ser-

vice to enforce spatial and temporal parameters in the

predeﬁned policy. Furthermore, the client application

is responsible for authenticating the remote service to

AnOntologyforEnforcingSecurityandPrivacyPoliciesonMobileDevices

293

Proxy Service

Ontology

Mobile Device

Proxy Service Client

Knowledge

Data

Activity

Data

Mobile Device

Applications

Networking

Proxy

Service

Data Collection Service

Data Data

Data

Network Requests

Internet

Request

Validation

Network Request

to Proxy

Populate and Transform

Validated Request

Validate

Validation

Result

Detected

Request

from Proxy

Service Client

Figure 5: Example implementation for enforcing ontology.

ensure that data is not leaked to a service imposing

as the dedicated service that the client is utilizing. It

is inevitable that there will be a large amount of data

synced to the proxy service from the client to facilitate

the modeling of a large amount of existing knowledge

in the ontology.

7.1.2 Proxy Service

For regular consumers, the proxy service can be of-

fered as a public cloud service. However for orga-

nizations that provision mobile devices to their em-

ployees, it may be more attractive to deploy the proxy

service on-premise where global policies could be de-

ﬁned and the service could be easily scaled.

In either deployment scenario, the proxy service

is responsible for examining networked trafﬁc from

the mobile device and determining if the data that it is

receiving are requests from the client application on

the device or requests from other applications on the

device, as illustrated in Figure 5. When updates are

received from the client application, they are passed

on to a data collection service that is responsible for

building the ontology model based on attributes of the

data that it receives. The data collection service may

need additional data from the client to make a deci-

sion, in which case, such information is indicated in

the response to the client.

If the request is detected to be from any other ap-

plication, the proxy service delegates the validation

of the request to a request validation service. The re-

quest validation service examines the data in the re-

quest and it determines if there are any corresponding

knowledge entities in the request using the ontology.

Based on this determination, it then locates the poli-

cies that correspond to the identiﬁed knowledge en-

tities in the request and validates whether or not the

request should be made. This is by far the most criti-

cal piece in the service and where our future research

will target as this service needs to be as efﬁcient as

possible to ensure that the user does not experience a

noticeable delay.

7.2 Discussion

As we recognized earlier, the request validation com-

ponent of the proxy service may be computationally

expensive. This will be the primary focus of our fu-

ture research so that we can minimize the computa-

tion needed to allow for timely enforcement without

a perceived user delay. We also recognize that the

policies we deﬁned in this ontology may not be ideal

for all consumers to create and manage. However,

consumers seeking the additional ﬁne grained control

can add this service and build these policies. Alter-

natively, organizations that would have the proxy ser-

vice on premise could deﬁne and manage these poli-

cies for use across their entire workforce. In any sce-

nario, we recognize that managing the policies needs

to be as simple and intuitive as possible for user adop-

tion.

The client application must keep the proxy service

in sync with data that exist on the device. This re-

quirement raises two primary concerns. One concern

is that there must be a level of trust to the proxy ser-

vice as it would hold a large amount of data from the

device. This may seem impractical. However, cloud

based services that synchronize data across devices

are pervasive today, such as OneDrive, iCloud, Drop-

Box, and Google Drive. This does stress the impor-

tance of establishing trust with the proxy service and

performing authentication both on the client and the

service. The other concern is the ability to synchro-

nize the data efﬁciently and at periods that do not af-

fect the user experience. We envision that the client

application would have to be ”smart” and take advan-

tage of opportunistic periods where utilization is per-

ceived low and the device is either plugged in or has

KEOD2014-InternationalConferenceonKnowledgeEngineeringandOntologyDevelopment

294

sufﬁcient battery power. The most opportune periods

for performing sync can also be determined from the

inferred knowledge that is built on previous usage ac-

tivity.

Within the proxy service there would also need to

exist a background service that performs necessary

transformations of activity data into existing knowl-

edge and existing knowledge into inferred knowledge.

Similar to the client application, this transformation

service should take advantage of periods that are de-

termined to be most opportunistic to perform these

transformations so that the user’s experience is un-

affected. From these transformations, validation of

intercepted network requests should become more ef-

ﬁcient during more active periods.

8 CONCLUSION AND FUTURE

WORK

In this paper we proposed an ontology by examining

previous research and analyzing the most widely used

mobile operating systems for common attributes. The

ontology we propose can be used to enforce secu-

rity and privacy policies on a mobile device using a

knowledge based approach. The key difference in the

ontology we propose here compared with previous re-

search is that it focuses on enforcement of policies as

opposed to detection of security vulnerabilities as was

the primary focus of the related work we identiﬁed.

Additionally the ontology we propose along with how

it can be enforced does not require modiﬁcation to the

operating system. Our ontology also focuses on pri-

vacy concerns as well as security concerns.

For elements in the ontology such as activity and

existing knowledge, we recognize that personal data

and sensing components would have to be made avail-

able to the enforcing application. The determination

of possible policy violations can be performed locally

at the mobile device, or via a cloud service. We are

working on implementing such a cloud enforcement

service based on the proposed ontology. We take this

approach because it may consume less resources for

policy enforcement compared with the local enforce-

ment approach. Furthermore, with most modern mo-

bile operating systems implementing sandboxing con-

trols, any enforcing application that lived locally on

the mobile device would need to violate the sandbox-

ing mechanism to inspect data being leaked from the

device to enforce the user’s deﬁned privacy and secu-

rity policies. Therefore, a cloud based enforcement

service is more feasible, which will be our focus in

future work.

REFERENCES

Ball, J. (2014). Angry birds and ’leaky’ phone apps

targeted by nsa and gchq for user data. http://

www.theguardian.com/world/2014/jan/27/nsa-gchq-

smartphone-app-angry-birds-personal-data.

Beji, S. and El Kadhi, N. (2009a). A knowledge based pro-

cess proposal for mobile security. In Developments in

eSystems Engineering (DESE), 2009 Second Interna-

tional Conference on, pages 166–172.

Beji, S. and El Kadhi, N. (2009b). Security ontology pro-

posal for mobile applications. In Mobile Data Man-

agement: Systems, Services and Middleware, 2009.

MDM ’09. Tenth International Conference on, pages

580–587.

Foursquare (2014). About foursquare. https://

foursquare.com/about.

Ju An WangGuo, Michael M.Camargo, J. (2010). An on-

tological approach to computer system security. In-

formation Security Journal: A Global Perspective,

19(2):61 – 73.

Krupp, B., Sridhar, N., and Zhao, W. (2013). A frame-

work for enhancing security and privacy on unmod-

iﬁed mobile mobile operating systems. In The First

International Workshop on Mobile Cloud and Social

Computing.

Krupp, B., Zhao, W., and Sridhar, N. (2014). Tell me

the truth! what is your intent with my mobile data?

Technical Report TR-CSU-ECE-1411, Electrical and

Computer Engineering, Cleveland State University.

Panagiotopoulos, I., Seremeti, L., Kameas, A., and

Zorkadis, V. (2010). Proact: An ontology-based

model of privacy policies in ambient intelligence en-

vironments. In Informatics (PCI), 2010 14th Panhel-

lenic Conference on, pages 124–129.

Symantec (2014). Norton mobile insight discovers

facebook privacy leak. http://www.symantec.com/

connect/blogs/norton-mobile-insight-discovers-

facebook-privacy-leak.

Tsoumas, B. and Gritzalis, D. (2006). Towards an ontology-

based security management. In Advanced Information

Networking and Applications, 2006. AINA 2006. 20th

International Conference on, volume 1, pages 985–

992.

Twitter (2014). New tweets per second record, and

how! https://blog.twitter.com/2013/new-tweets-per-

second-record-and-how.

Uszok, A., Bradshaw, J., Jeffers, R., Suri, N., Hayes, P.,

Breedy, M., Bunch, L., Johnson, M., Kulkarni, S.,

and Lott, J. (2003). Kaos policy and domain services:

toward a description-logic approach to policy repre-

sentation, deconﬂiction, and enforcement. In Policies

for Distributed Systems and Networks, 2003. Proceed-

ings. POLICY 2003. IEEE 4th International Workshop

on, pages 93–96.

Woo, S., On, J., and Lee, M. (2013). Behavior ontology:

A framework to detect attack patterns for security. In

Advanced Information Networking and Applications

Workshops (WAINA), 2013 27th International Confer-

ence on, pages 738–743.

AnOntologyforEnforcingSecurityandPrivacyPoliciesonMobileDevices

295
