Discovering New Gene Functionalities from Random Perturbations of

Known Gene Ontological Annotations

Giacomo Domeniconi

, Marco Masseroli

, Gianluca Moro

and Pietro Pinoli

DISI, Universit

a degli Studi di Bologna, Via Venezia 52, 47523, Cesena, Italy

DEIB, Politecnico di Milano, Piazza L. Da Vinci 32, 20133 Milan, Italy

Keywords:

Gene Ontology, Biomolecular Annotation Prediction, Bioinformatics, Knowledge Discovery, Supervised

Learning, Data Representation.

Abstract:

Genomic annotations describing functional features of genes and proteins through controlled terminologies

and ontologies are extremely valuable, especially for computational analyses aimed at inferring new biomed-

ical knowledge. Thanks to the biology revolution led by the introduction of the novel DNA sequencing tech-

nologies, several repositories of such annotations have becoming available in the last decade; among them, the

ones including Gene Ontology annotations are the most relevant. Nevertheless, the available set of genomic

annotations is incomplete, and only some of the available annotations represent highly reliable human curated

information. In this paper we propose a novel representation of the annotation discovery problem, so as to

enable applying supervised algorithms to predict Gene Ontology annotations of different organism genes. In

order to use supervised algorithms despite labeled data to train the prediction model are not available, we

propose a random perturbation method of the training set, which creates a new annotation matrix to be used to

train the model to recognize new annotations. We tested the effectiveness of our approach on nine Gene Ontol-

ogy annotation datasets. Obtained results demonstrated that our technique is able to improve novel annotation

predictions with respect to state of the art unsupervised methods.

1 INTRODUCTION

Prediction of associations between items and features

characterizing them is a common machine learning

task which is often performed in several application

domains, including bioinformatics. When the consid-

ered features are described through controlled termi-

nologies, particularly if their terms are related into

taxonomies or ontologies, such task well supports

knowledge discovery. In bioinformatics, several ter-

minologies and ontologies are available to describe

structural and functional features of biomolecular en-

tities. Among them, the most developed and relevant

is the well known Gene Ontology (GO) (GO Consor-

tium et al., 2001). The association of its terms to

biomolecular entities, mainly genes and proteins, is

widely used to annotate, and thus characterize, them.

The GO comprises three sub-ontologies, which

overall include nearly 40,000 controlled terms

that characterize species-independent Biological Pro-

cesses (BP), Molecular Functions (MF) and Cellular

Components (CC). Structured as a Directed Acyclic

Graph (DAG) of terms hierarchically related, mainly

through ”is a” or ”part of” relationships, the GO is

designed to capture orthogonal features of genes and

proteins. In its DAG, each node represents a GO term

and each directed edge from a node a to a node b rep-

resents a relationship that exists from a child term a

to its parent term b.

In modern, high-throughput and computationally

intensive molecular biology, controlled biomolecular

annotations are very valuable. Yet, some of them are

less reliable, or may even be incorrect, since com-

putationally inferred without human curator supervi-

sion, or due to biomolecular knowledge improvement

since their annotation. Besides, available biomolecu-

lar annotations are incomplete, given the many gene

and protein features of numerous organisms still to

be discovered and annotated. In this context, com-

putational methods that can estimate incorrectness of

available annotations and predict new annotations are

paramount. Particularly, the ones that provide ranked

lists of inferred annotations can, for instance, quicken

the curation process by focusing it on the prioritized

novel annotations (Pandey et al., 2006).

In this work, in order to discover new GO term an-

107

Domeniconi G., Masseroli M., Moro G. and Pinoli P..

Discovering New Gene Functionalities from Random Perturbations of Known Gene Ontological Annotations.

DOI: 10.5220/0005087801070116

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2014), pages 107-116

ISBN: 978-989-758-048-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

notations of different organism genes based on avail-

able GO annotations, we apply different supervised

algorithms and benchmark them with an unsupervised

method previously used to this purpose. To apply

supervised algorithms to the prediction problem, we

propose to assign labels to the originally unlabeled

GO annotations based on a random perturbation of

the annotation matrix that switches off some known

annotations. In so doing, we create a training ma-

trix with missing annotations; thus, we can train the

model to recognize new annotations. This allows ap-

plying powerful supervised methods to available gene

annotations and predicting new gene function anno-

tations with better performance than the previously

used unsupervised methods. Although sophisticated

techniques exist to predict gene functions by leverag-

ing multiple heterogeneous data sources, simpler an-

alytical frameworks using faster methods based only

on available annotations proved to be effective and

very useful, as here conﬁrmed.

The rest of the paper is organized as follows.

Section 2 reports an overview of other works about

biomolecular annotation prediction. Section 3 de-

scribes the annotation datasets used in our experi-

ments. Section 4 exposes the methods used to predict

new annotations. Section 5 illustrates the performed

experiments and reports their results, benchmarking

them with those of another work. Finally, in Section

6 we discuss our contribution and foresee possible fu-

ture developments.

2 RELATED WORKS

Different methods have been proposed to predict

biomolecular annotations.

In (King et al., 2003), decision trees and Bayesian

networks were suggested to learn patterns from avail-

able annotation proﬁles and predict new ones. Along

this line, Tao and colleagues (Tao et al., 2007) im-

proved by using a k-nearest neighbour (k-NN) clas-

siﬁer to make a gene inherit the annotations that are

common among its nearest neighbour genes in a gene

network. Such an inheritance is regulated by the func-

tional distance between genes, based on the semantic

similarity of the GO terms used to annotate them.

Novel gene annotations can also be inferred based

on multiple data sources. In (Barutcuoglu et al.,

2006), gene expression levels from microarray exper-

iments are used to train a Support Vector Machine

(SVM) classiﬁer for each gene annotation to a GO

term; consistency among predicted annotation terms

is then enforced through a Bayesian network mapped

onto the GO structure. Conversely, in (Raychaudhuri

et al., 2002) and (P

erez et al., 2004), the authors took

advantage of textual information by mining the litera-

ture and extracting keywords that are then mapped to

GO concepts. This approach has the disadvantage to

require a preparatory data integration step in order to

be performed; this both adds complexity to the frame-

work and reduces its ﬂexibility.

In (Khatri et al., 2005) and (Done et al., 2010),

Khatri and colleagues suggested a prediction algo-

rithm based on the Singular Value Decomposition

(SVD) method of the gene-to-term annotation ma-

trix, which is implicitly derived from the count of

co-occurrences between pairs of terms in the avail-

able annotation dataset. This prediction method based

on basic linear algebra was then extended in (Chicco

et al., 2012), by incorporating gene clustering based

on gene functional similarity computed on Gene On-

tology annotations. It was further enhanced by au-

tomatically choosing its main parameters, including

the SVD truncation level, based on the evaluated

data (Chicco and Masseroli, 2013). The SVD has

also been used with annotation co-occurrence weights

based on gene-term frequencies (Done et al., 2007)

and (Pinoli et al., 2014b). Being based on simple

matrix decomposition operations, these methods are

independent of both the chosen organism and func-

tion term vocabulary involved in the annotation set.

Anyway, obtained results highlighted their poor per-

formance in terms of accuracy.

Other methods based on evaluation of co-

occurrences exist; in particular the ones related to La-

tent Semantic Indexing (LSI) (Dumais et al., 1988),

which have been originally proposed in Natural Lan-

guage Processing. Among them, the probabilistic

Latent Semantic Analysis (pLSA) (Hofmann, 1999)

gives a well deﬁned distribution of sets of terms as

an approximation of the co-occurrence matrix. It uses

the latent model of a set of terms to increase robust-

ness of annotation prediction results. In (Masseroli

et al., 2012) and (Pinoli et al., 2013), pLSA proved

to provide general improvements with respect to

the truncated SVD method of Khatri and colleagues

(Khatri et al., 2005).

In bioinformatics, topic modeling has been lever-

aged also by using the Latent Dirichlet Allocation

(LDA) algorithm (Blei et al., 2003). In (Bicego et al.,

2010) and (Perina et al., 2010), LDA was used to sub-

divide expression microarray data into clusters. Be-

sides, they deﬁned a new model able to consider a

given dependence between genes; this dependence is

introduced in the model through a variable that rep-

resents a categorization of the genes and that can be

inferred from a priori knowledge on the evaluated

genes. Very recently, Pinoli et al. (Pinoli et al., 2014a)

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

108

Table 1: Quantitative characteristics of the nine considered annotation datasets. Figures refer to the sum of direct and indirect

annotations not inferred from electronic annotation, i.e. without IEA evidence code.

Gallus gallus Bos taurus Danio rerio

CC MF BP CC MF BP CC MF BP

# considered genes 260 309 275 497 540 512 430 699 1,528

# considered terms 123 134 610 207 226 1,023 131 261 1,176

# annotations (July 2009) 3,442 1,927 8,709 7,658 3,559 18,146 4,813 4,826 38,399

# annotations (May 2013) 3,968 2,507 10,827 9,878 5,723 24,735 5,496 6,735 58,040

∆ annotations between GPDW versions

#∆ annotations 526 580 2,118 2,220 2,164 6,589 683 1,909 19,641

%∆ annotations 15.28 30.10 24.32 29.00 60.80 36.31 14.19 39.56 51.15

took advantage of the LDA algorithm, together with

the Gibbs sampling (Grifﬁths, 2002) (Casella and

George, 1992) (Porteous et al., 2008), to predict gene

annotations to GO terms. These methods strongly

overcome the ones based on linear algebra, but the

complexity of the underlying model and the slowness

of the training algorithms make these approaches ill-

suited when the size of the dataset grows.

In summary, previously proposed methods for

biomolecular annotation prediction either are general

and ﬂexible, but provide only limited accuracy mainly

due to the simple model used, or improve prediction

performance by either leveraging a complex integra-

tive analytical framework, which often is difﬁcult and

time consuming to be properly set up, or adopting

a more complex model, which in turn signiﬁcantly

slows the prediction process in particular in the usual

case of many data to be evaluated.

3 GENOMIC DATASETS

In order to have easy access to subsequent versions

of gene annotations to be used as input to the con-

sidered algorithms or to evaluate the results that they

provide, we took advantage of the Genomic and Pro-

teomic Data Warehouse (GPDW) (Canakoglu et al.,

2012). In GPDW several controlled terminologies

and ontologies, which describe genes and gene prod-

ucts related features, functionalities and phenotypes,

are stored together with their numerous annotations

to genes and proteins of many organisms. These data

are retrieved from several well known biomolecular

databases. In the context of developing and testing

machine learning methods on genomic annotations,

GPDW is a valuable source since it is quarterly up-

dated and old versions are kept stored. We lever-

aged this feature in our method evaluation by consid-

ering differed versions of the GO annotations of the

genes of three organisms. In GPDW they are avail-

able with additional information, including an evi-

dence code that describes how reliable the annotation

is. We leveraged it by ﬁltering out the less reliable

annotations, i.e. those with Inferred from Electronic

Annotation (IEA) evidence, from the datasets used for

our evaluation. Table 1 gives a quantitative descrip-

tion of the considered annotations.

In GPDW, as in any other biomolecular database,

only the most speciﬁc controlled annotations of each

gene are stored. This is because, when the controlled

terms used for the annotation are organized into an

ontology, as for the GO, biologists are asked to an-

notate each gene only to the most speciﬁc ontology

terms representing each of the gene features. In this

way, when a gene is annotated to a term, it is implic-

itly indirectly annotated also to all the more generic

terms, i.e. all the ancestors of the feature terms in-

volved in its direct annotations. This is called anno-

tation unfolding.

All direct and indirect annotations of a set of genes

can be represented by using binary matrices. LetG be

the set of genes of a certain organism and T a set

of feature terms. We deﬁne the annotation matrix A ∈

{0, 1}

|G|×|T |

as the matrix whose columns correspond

to terms and rows to genes. For each gene g ∈ G and

for each term t ∈ T , the value of the A(g,t) entry of

the annotation matrix is set according to the following

rule:

A(g,t) =











1, if g is annotated either to t

or to any of t descendants

0, otherwise

(1)

Examples of two versions of these matrices are shown

in Figure 1a and 1b, where A

is an updated version

of A

. Each GPDW update contains some number

of new discovered annotations, namely new 1 in the

matrix.

DiscoveringNewGeneFunctionalitiesfromRandomPerturbationsofKnownGeneOntologicalAnnotations

109

GO terms (Outdated version)

GO:0043226 GO:0005575 GO:0005623 GO:005737

GO terms (Updated version)

GO:0043226 GO:0005575 GO:0005623 GO:005737GO:0043226 GO:0005575 GO:0005623 … GO:005737

Gene

0 1 0 … 0

Gene 1 0 0 0

GO:0043226 GO:0005575 GO:0005623 … GO:005737

Gene

0 1 1 … 1

Gene 1 0 1 0Gene

1 0 0 … 0

… … … … … …

G 0 1 1 1

Gene

1 0 1 … 0

… … … … … …

G 1 1 1 1Gene

0 1 1 … 1 Gene

1 1 1 … 1

t GO 005737

GO terms

features label

t=GO:005737

features label

GO:0043226 GO:0005575 GO:0005623 … GO:005737

Gene 0 1 0 1Gene

0 1 0 … 1

Gene

1 0 0 … 0

… … … … … …

Gene

0 1 1 … 1

(a)

(b)

(c)

Figure 1: Illustrative diagram of the data representation. The data set (c) is created with an older annotation version A

(a) for

the features and an uptdated version A

(b) for the labels.

4 ANNOTATION DISCOVERY

METHODS

4.1 Data and Problem Modelling

Given a feature term t, we want to predict if a gene

g is likely to be, or not to be, annotated to that term

t, i.e. if the element A(g, t) of the annotation matrix

is likely to be 1, or 0. This can be modelled as a su-

pervised problem, in which the predicted class is a

term, i.e. a column of the matrix, that can be 0 or

1 according to the presence or absence of annotation

between the gene and the term, while all other annota-

tions of the gene represent the features of the record,

as in Figure 1c. Considering that predictions must be

made for all the terms t ∈ T , i.e. all the columns of the

matrix, the problem can be modeled as a supervised

multi-label classiﬁcation, with the difference that we

do not have a distinct set of features and labels, but

we have a set of terms that are both classes and fea-

tures. To address this problem, we use the most com-

mon approach in the literature, i.e. transform it into a

set of binary classiﬁcation problems, which can then

be handled using single-class classiﬁers. Henceforth,

for simplicity of exposition, we will refer to a single

supervised task concerning the discovery of a new an-

notation of the gene g to the term t (for instance the

term GO:005737 in Figure 1), which is then repeated

iteratively for all other genes and terms.

Let’s now see how to assign a label to each in-

stance of the data model. Given an annotation matrix,

our proposal is to use as input a version of the ma-

trix with less annotations (referred as outdated matrix,

since it may resemble an outdated annotation dataset

version); then, to derive from such input matrix the

features of the data model, and consider as label of

each record the presence or absence of an annotation

in a more complete matrix (referred as updated ma-

trix, since it may resemble a newer annotation dataset

version). This representation is sketched in Figure 1.

Given the feature term t considered for the prediction,

called class-term, the representation of the data is cre-

ated by taking as features, for each gene, all the anno-

tations to all the other terms in an outdated version of

the matrix A

, while the label is given by the value

of the class-term in the updated version of the matrix

. Henceforth, we refer to this representation matrix

as M

, where t is the class-term of the model.

This data representation is exactly the same as that

of a supervised classiﬁcation problem represented in

a Vector Space Model. Thus, a classic supervised task

could be envisaged by subdividing this new matrix M

horizontally and using a part of the genes to train the

model and the remaining part to test it. In this domain,

however, this approach is not applicable because it

implies the availability of at least the part of the up-

dated matrix to train the model, but new datasets are

only released as a whole and not partially. Thus, the

purpose is to predict which annotations are missing

in the entire matrix, rather than on some part of it.

The data representation matrix M

requires informa-

tion from two different annotation dataset versions.

Thus, since the aim is to make predictions over the en-

tire dataset, to train the model we use a matrix M

train

that is created by using the information from both the

latest version currently available at training time, i.e.

, and an older version of the matrix with missing

annotations, i.e. A

. With this two different versions

of the matrices, the training set is created by using

the features derived from the outdated version A

and

the labels from the updated one A

. Then, the vali-

dation of the classiﬁcation model has to be made by

discovering new annotations, missing in the current

state of the matrix. Therefore, the features regarding

the current version A

and labeled with the values of

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

110

a future updated matrix A

are used to create the val-

idation matrix M

validation

. The training and validation

data representation process is sketched in Figure 2.

GO terms

Other terms t

Gene

…

Gene

train

features label

Training set

Gene

…

GO terms

Other terms t

Gene

…

Gene

Validation set

GO terms

valid

features label

Gene

GO terms

Other terms t

Gene

…

Gene

…

Gene

Figure 2: Illustrative diagram of the dataset representation

for the prediction model of the annotations to a term t. The

training set (M

train

) is created with an older annotation ver-

sion A

for the features and the current annotation version

for the labels. Similarly, the validation set (M

valid

) is

created using A

and a future updated annotation matrix A

4.2 Random Perturbation

The supervised problem modelling described in the

previous subsection requires, at training time, two

versions of the annotation matrix to create the super-

vised model, i.e. A

and A

. However, biologists typ-

ically have available only the most updated version of

the annotation matrix, not keeping stored the outdated

versions for space reasons, given the large amount of

data. Thus, with reference to Figure 1, there is avail-

able only one version of the matrix, i.e. only the cur-

rent version A

, with which the training data repre-

sentation M

train

is created.

To overcome the problem just mentioned, we start

from the observation that also the input matrix A

contains missing annotations. Therefore, we could

use only this matrix to obtain the representation M

assuming A

= A

. However, the classiﬁcation model

will have to discover new gene-term annotations start-

ing from an outdated matrix; thus, it will be more

effective if it is trained with a training set in which

the features are taken from an outdated matrix, with

a greater number of missing annotations than the ma-

trix version from which the labels of the instances are

obtained. If we consider that the annotations of genes

to features are discovered by teams of biologists that

work independently from each other, a reasonable hy-

pothesis is that the new annotations discovered by the

entire scientiﬁc community, on the whole, do not have

any kind of bond or rule. This should be equivalent

to a random process of discovery of new annotations.

Such considerations led to our thesis that new gene

annotations can be better discovered by artiﬁcially in-

creasing the number of missing annotations in the in-

put matrix A

. Since, as mentioned, usually only the

input matrix A

is available, this can be achieved by

randomly deleting known annotations in the matrix

to obtain a new matrix A

artiﬁcially perturbed.

Thus, to get the data to train the classiﬁcation

model, we propose to randomly perturb the matrix A

to create a new matrix A

, in which some annotations

are eliminated with a probability p. In this way we

obtain the matrix A

= random perturbation(A

, p).

Formally, for each gene g and term t, the perturbation

is done as follows:

(g,t) =











0 if A

(g,t) = 1 ∧ random 6 p

1 if A

(g,t) = 1 ∧ random > p

0 if A

(g,t) = 0

(2)

Once the perturbed matrix A

is generated, to en-

sure its correctness with respect to the unfolding of

the annotations, the matrix A

is corrected by switch-

ing to 0 also all the annotations to the same gene of

all the descendants of the ontological terms with mod-

iﬁed gene annotation; we call this process perturba-

tion unfolding. It is important to note that, depending

on this correction, the percentage of the actual modi-

ﬁed annotations of the matrix A

will hence be greater

than the percentage derived from p. The overall data

representation process is the same as that shown in

Figure 2, with the difference that the matrix A

is cre-

ated by perturbing randomly A

Considering the annotation unfolding in the GO,

in order to avoid trivial predictions (i.e. 1 if a child

is 1), in the set of features of the dataset M

all the

descendants or ancestors of the term t are not taken

into consideration. Once created the training matrix

train

, we can use any supervised algorithm, capa-

ble of returning a probability distribution, to train the

prediction model and then validate it with M

validation

The predicition model provides a probability distribu-

tion pd(g,t), called likelihood, concerning the pres-

ence of an annotation of the gene g to the term t.

To provide predictions of only new annotations, only

those annotations that were missing in the outdated

version of the matrix are taken into account. The su-

pervised process described above is repeated for all

the terms t ∈ T , giving as ﬁnal output a list of predic-

tions of new gene annotations ordered according to

their likelihood; the illustrated annotation discovery

workﬂow is sketched in Figure 3.

DiscoveringNewGeneFunctionalitiesfromRandomPerturbationsofKnownGeneOntologicalAnnotations

111

Updated GPWDOutdated GPWD

Retrieve the Annotation matrix A

(excluding IEAs)

Retrieve the updated Annotation

matrix A (excluding IEAs)

Perturb randomly the matrix

with

probability p,

obtaining

For each term

Apply the likelihood

correction

Create the training set with A

for

the features and A

for the labels

Count the confirmed predictions

List of predicted

t ti

Train the supervised model

anno a ons

Create the validation set with A

for

the features

Result

Make predictions

t T

∈

Then

the

matrix

Figure 3: Workﬂow of the training and validation processes.

4.3 Likelihood Correction

As shown above, the output of the supervised model

is a list of predicted annotations, each one with a like-

lihood degree. According to the hierarchical structure

of GO, when a gene is annotated to an ontological

term, it must be also annotated to all the ancestors of

that term; this constraint is also known as True Path

Rule (Tanoue et al., 2002). The supervised classiﬁer,

however, provides a likelihood for each gene anno-

tation regardless of the predictions of the annotation

of other GO terms to the same gene. This can result

in possible cases of anomalies in which a gene shall

be annotated to a term, but not to one or more of its

ancestor terms, thus violating the True Path Rule. To

obtain a likelihood that takes into account the hierar-

chy of the terms, once obtained the likelihood of each

gene-term association, we proceed as follows:

1. For each novel gene-term annotation, to the prob-

ability given by the model we add the average of

all the probabilities of the novel annotations of the

gene to all the ancestors of the term. Note that,

since the classiﬁcation model provides in output a

probability distribution ranging between 0 and 1,

the hierarchical likelihood of each gene-term an-

notation shall be between 0 and 2, as follows:

(g,t) =

∑

∈ancestors(t)

pd(g,t

)

|ancestors(t)|

+ pd(g,t) (3)

2. Once the likelihood is made hierarchical, the cor-

rection of the possible anomalies regarding the

True Path Rule is taken into account. An iterative

process is carried on from the leaf terms to the

root term of the hierarchy, upgrading each likeli-

hood with the maximum likelihood value of the

descendant terms, as follows:

l(g,t) = max{pd

(g,t), max

∈children(t)

{pd

(g,t

)}}

(4)

In such a way, for each ontology term, the like-

lihood of a gene to be annotated to that term is

always greater than or equal to the likelihood of

the gene to be annotated to the term descendants.

4.4 Evaluation

In our experiments we tested the effectiveness of su-

pervised models in discovering new functional gene

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

112

Table 2: Validation results of the predictions obtained by varying the supervised algorithm used to build the prediction model.

The results show, for each of the nine considered datasets, the amount of the top 250 predicted gene annotations to the GO BP,

MF and CC terms that have been found conﬁrmed in the updated GPDW version. The setup of these experiments was done

with random perturbation of the training matrix with probability p = 0.05. The ﬁrst column (SIM) reports the results obtained

in (Pinoli et al., 2014b) with the SIM best conﬁguration. Each result is reported as the average and corresponding standard

deviation of 10 experiments repeated by changing the random perturbation seed. In bold the best result for each dataset.

Dataset

SIM IBk J48 Logistic NB RF SMO

Gallus g. - BP

86 58.6±20.2 47.2±4.7 32.7±6.8 25.4±4.4 52.7±12.1 28.7±9.3

Gallus g. - MF

24 58.0±5.6 79.7±12.7 40.0±10.4 14.2±1.6 54.4±9.6 50.7±14.3

Gallus g. - CC

50 81.5±8.2 73.4±8.5 31.9±6.4 23.5±3.7 55.2±11.3 29.6±4.0

Bos t. - BP

55 48.9±6.8 49.7±5.1 37.0±6.5 28.4±4.2 62.4±7.6 31.2±4.6

Bos t. - MF

28 58.2±4.4 58.8±10.5 27.5±4.3 15.7±2.9 57.5±11.2 36.9±4.4

Bos t. - CC

91 112.0±9.7 94.3±9.8 38.2±5.3 8.2±2.0 93.7±10.4 48.4±6.8

Danio r. - BP

35 70.9±15.9 59.8±6.1 31.0±4.8 25.2±3.3 58.1±5.1 16.6±2.3

Danio r. - MF

35 77.5±10.3 75.8±7.1 54.4±11.0 41.2±2.7 83.1±9.6 79.7±8.7

Danio r. - CC

44 81.5±8.5 69.3±8.7 27.6±7.6 26.2±6.6 92.3±11.0 30.2±6.6

Total

447 647.1 608.8 320.3 207.9 609.4 352.0

Table 3: Validation results of the predictions obtained using IBk as supervised algorithm and varying the probability p of

random perturbation of the training matrix. The results show, for each of the nine considered datasets, the amount of the

top 250 predicted gene annotations to the GO BP, MF and CC terms that have been found conﬁrmed in the updated GPDW

version. Each result is reported as the average and corresponding standard deviation of 10 experiments repeated by changing

the random perturbation seed. In bold the best result for each datasets.

Dataset

p = 0 p = 0.05 p = 0.10 p = 0.15 p = 0.20 p = 0.25 p = 0.30

Gallus g. - BP

42 58.6±20.2 54.8±16.2 51.3±12.5 55.9±10.4 50.2±10.2 47.4±9.7

Gallus g. - MF

50 58.0±5.6 61.8±11.0 59.5±13.0 58.3±10.2 63.6±13.5 64.2±8.4

Gallus g. - CC

75 81.5±8.2 77.5±9.7 82.2±8.1 78.1±7.5 73.3±13.2 78.8±12.0

Bos t. - BP

43 48.9±6.8 51.7±10.1 50.4±8.4 53.1±9.6 52±12.5 52.2±15.4

Bos t. - MF

58 58.2±4.4 62.7±7.7 71.4±10.9 73±12.6 74.7±11.6 77.0±13.0

Bos t. - CC

108 112.0±9.7 114.3±11.0 118.6±13.0 118.1±13.0 119.0±13.1 116.7±22.0

Danio r. - BP

55 70.9±15.9 70.6±16.5 74.8±13.9 85.7±25.6 83.1±16.3 90.6±19.4

Danio r. - MF

76 77.5±10.3 72.5±7.1 67.7±10.1 62.0±7.6 58.4 ±8.7 51.4±15.1

Danio r. - CC

79 81.5±8.5 84.7±8.7 90.7±10.0 85.6±13.5 83.3±14.5 75.8±19.9

Total

586 647.1 650.6 666.6 669.8 661.6 654.1

annotations from the available annotations. Since the

proposed method is applicable to any supervised algo-

rithm that returns a probability distribution, we tested

different types of existing algorithms in order to mea-

sure their effectiveness, in particular: Support Vector

Machines, nearest neighbors, decision trees, logistic

regressions and naive bayes, using the implementa-

tions provided by Weka

in its 3.7.9 version. In the

experiments we tested the Weka classiﬁers: IBk (with

k = 3), J48, Logistic, Naive Bayes (NB), Random For-

est (RF) and SMO. For each algorithm we used the

default parameter settings provided by Weka; no tun-

ing of parameters has been done for time reasons.

We measured the effectiveness of the predictions

in the same way it was done in (Pinoli et al., 2014b),

in order to be able to directly compare our results with

those in that work; the overall procedure was as fol-

lows.

http://www.cs.waikato.ac.nz/ml/weka/.

1. We extracted the input annotations from an out-

dated version of the GPDW (July 2009), exclud-

ing from those annotations the ones less reliable,

i.e. with IEA evidence code.

2. We randomly perturbed the unfolded annotation

matrix to get a modiﬁed version of it, with some

missing annotations.

3. By running the prediction algorithm, we got a list

of predicted annotations ordered by their conﬁ-

dence value (i.e. their corresponding likelihood

l(g,t)).

4. We selected the top P predictions (we use P =

250) and we counted how many of these P pre-

dictions were found conﬁrmed in the updated ver-

sion of the GPDW (May 2013 version), regardless

their evidence code.

5. For each experiment, steps 2, 3, 4 were repeated

10 times by varying the random seed. The effec-

DiscoveringNewGeneFunctionalitiesfromRandomPerturbationsofKnownGeneOntologicalAnnotations

113

tiveness of each experiment was determined by

averaging the counts obtained in all the experi-

ment repetitions.

We depict the training and validation procedure work-

ﬂows in Figure 3.

5 RESULTS

Table 2 shows the results obtained by varying the su-

pervised algorithm used to train the prediction model,

always using a ﬁxed random perturbation probability

p = 0.05. Considering that the best result obtained in

(Pinoli et al., 2014b) was a total of 447 correct predic-

tions, Table 2 shows that, with the proposed method, 3

out of 6 of the tested algorithms outperform the results

obtained in (Pinoli et al., 2014b). These results are

excellent if we consider that they are obtained with-

out any tuning of the algorithm parameters, therefore

there is margin to improve them with an appropriate

tuning. According to the results in Table 2, we can in-

fer that using the standard parameterization provided

by Weka, the algorithm that obtains the best results is

IBk, with an improvement of 44.8% compared with

the results of (Pinoli et al., 2014b). IBk results also

6.2% better than Random Forest and 6.3% better than

J48, the only other two supervised algorithms consid-

ered that result better than (Pinoli et al., 2014b).

The proposed method introduces a new parame-

ter: the probability p of the random perturbation of

the training matrix. Table 3 shows the results obtained

by varying the probability p and using the best super-

vised algorithm from Table 2, namely IBk. These re-

sults show that the best predictions are obtained with

p = 0.2. Considering the perturbation unfolding, this

p value leads to a perturbed matrix A

with more

than 20% of annotations less than in A

(empirically

they are about 30% less). Such percentage is very

close to the average value of the variation of num-

ber of annotations between A

and A

, i.e. 33.4%,

notable in Table 1. Moreover, the probability p that

gets the best results for each dataset seems to have a

relationship with the dataset annotation variation be-

tween A

and A

. This result leads to the conjectures

that i) representing new annotations randomly leads

to train a classiﬁer able to predict the actual new an-

notations between two different annotation versions;

ii) the more the amount of artiﬁcial missing annota-

tions introduced in the training set is comparable to

the actual missing annotations in the validation set,

the more the predictions are accurate. Another result

deducible from Table 3 is that using p = 0, namely

the annotation matrix is not perturbed (A

= A

), we

get anyway good results, higher than those in (Pinoli

0 0.1 0.2 0.3

100

200

Probability of perturbation

# Predictions

A. Gallus gallus

IBk Pinoli et al. 2013b

0 0.1 0.2 0.3

100

200

Probability of perturbation

B. Bos taurus

0 0.1 0.2 0.3

100

200

Probability of perturbation

# Predictions

C. Danio Rerio

0 0.1 0.2 0.3

200

400

600

Probability of perturbation

D. Total

Figure 4: Validation results of the predictions obtained by

varying the probability of perturbation p, compared with

those obtained in (Pinoli et al., 2014b). The results show,

for each organism in the A, B and C charts, the sum of the

predicted annotations that have been found conﬁrmed in the

updated GPDW version of the three GO ontologies. The

chart D shows the total values for all the organism.

et al., 2014b). This is important since it allows to

avoid the parameter p and the tuning of the system

for any considered dataset when not top performance

is required. For a graphical view, the results discussed

are also shown in Figure 4, grouped by considered

organism. Our approach outperforms the best accu-

racy achieved in (Pinoli et al., 2014b) of 49.66%, in

particular we obtain the highest improvement for big

datasets, i.e. in the Danio rerio dataset there is an

improvement of 104.56% of the correct annotations

predicted.

6 DISCUSSION AND

CONCLUSIONS

The method proposed in this paper discovers new GO

term annotations for genes of different organisms,

based on available GO annotations of these genes,

outperforming the state of the art. Our approach is

based on the labeling of each ontological term of an

outdated annotation proﬁle of a gene with a label

taken from an updated version of the gene annota-

tion proﬁle. In this way the model is trained to rec-

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

114

ognize the presence of novel gene annotations using

the obsolete annotation proﬁle of the gene. The appli-

cation of this method requires two different versions

of the annotation matrix to build representations of

the training data. However, biologists typically have

available only the most updated version of the gene

annotation matrix. Given this constrain, we have pro-

posed a method to represent the training data using

a single annotation matrix as input. It is based on

creating a different annotation matrix, representing an

older version of the input one, by perturbing the input

one in order to randomly remove some of its annota-

tions. This allows the use of supervised algorithms

even in datasets without labels and the comparison

of supervised algorithm results with those obtained

by unsupervised methods on the same originally un-

labeled datasets.

Obtained results are very encouraging, since they

show a great improvement compared with unsuper-

vised techniques. Furthermore, these results could be

even better with an appropriate tuning of the parame-

ters of the supervised algorithms used; our purpose is

to thoroughly investigate this aspect in the future.

From the obtained results we can see that by in-

creasing the number of perturbed (removed) annota-

tions, the results improve, reaching a peak when the

number of artiﬁcial missing annotations in the train-

ing set is comparable to the number of those in the

validation set, i.e. when the variety of missing an-

notations has been fully mapped in the training set.

Furthermore, it is noteworthy also the case where we

do not perturb the training matrix, avoiding the tuning

of the parameter p, which gets anyway good results.

We plan to further verify the effectiveness of the pro-

posed approach, also applying weighting schemes on

the data representation.

ACKNOWLEDGEMENTS

This research is part of the “GenData 2020” project

funded by the Italian MIUR. The authors would like

to thank Claudio Sartori for the useful discussions

about data mining algorithms.

REFERENCES

Barutcuoglu, Z., Schapire, R. E., and Troyanskaya, O. G.

(2006). Hierarchical multi-label prediction of gene

function. Bioinformatics, 22(7):830–836.

Bicego, M., Lovato, P., Oliboni, B., and Perina, A. (2010).

Expression microarray classiﬁcation using topic mod-

els. In Proceedings of the 2010 ACM Symposium on

Applied Computing, pages 1516–1520. ACM.

Blei, D. M., Ng, A. Y., and Jordan, M. I. (2003). Latent

dirichlet allocation. the Journal of machine Learning

research, 3:993–1022.

Canakoglu, A., Ghisalberti, G., and Masseroli, M. (2012).

Integration of biomolecular interaction data in a ge-

nomic and proteomic data warehouse to support

biomedical knowledge discovery. In Computational

Intelligence Methods for Bioinformatics and Bio-

statistics, pages 112–126. Springer.

Casella, G. and George, E. I. (1992). Explaining the gibbs

sampler. The American Statistician, 46(3):167–174.

Chicco, D. and Masseroli, M. (2013). A discrete optimiza-

tion approach for svd best truncation choice based

on roc curves. In Bioinformatics and Bioengineering

(BIBE), 2013 IEEE 13th International Conference on,

pages 1–4. IEEE.

Chicco, D., Tagliasacchi, M., and Masseroli, M. (2012).

Genomic annotation prediction based on integrated in-

formation. In Computational Intelligence Methods

for Bioinformatics and Biostatistics, pages 238–252.

Springer.

Done, B., Khatri, P., Done, A., and Draghici, S. (2007). Se-

mantic analysis of genome annotations using weight-

ing schemes. In Computational Intelligence and

Bioinformatics and Computational Biology, 2007.

CIBCB’07. IEEE Symposium on, pages 212–218. IET.

Done, B., Khatri, P., Done, A., and Draghici, S. (2010).

Predicting novel human gene ontology annotations us-

ing semantic analysis. IEEE/ACM Transactions on

Computational Biology and Bioinformatics (TCBB),

7(1):91–99.

Dumais, S. T., Furnas, G. W., Landauer, T. K., Deerwester,

S., and Harshman, R. (1988). Using latent semantic

analysis to improve access to textual information. In

Proceedings of the SIGCHI conference on Human fac-

tors in computing systems, pages 281–285. ACM.

GO Consortium et al. (2001). Creating the gene ontology

resource: design and implementation. Genome re-

search, 11(8):1425–1433.

Grifﬁths, T. (2002). Gibbs sampling in the generative model

of latent dirichlet allocation. Standford University,

518(11):1–3.

Hofmann, T. (1999). Probabilistic latent semantic index-

ing. In Proceedings of the 22nd annual international

ACM SIGIR conference on Research and development

in information retrieval, pages 50–57. ACM.

Khatri, P., Done, B., Rao, A., Done, A., and Draghici, S.

(2005). A semantic analysis of the annotations of the

human genome. Bioinformatics, 21(16):3416–3421.

King, O. D., Foulger, R. E., Dwight, S. S., White, J. V.,

and Roth, F. P. (2003). Predicting gene function from

patterns of annotation. Genome research, 13(5):896–

904.

Masseroli, M., Chicco, D., and Pinoli, P. (2012). Proba-

bilistic latent semantic analysis for prediction of gene

ontology annotations. In Neural Networks (IJCNN),

The 2012 International Joint Conference on, pages 1–

8. IEEE.

Pandey, G., Kumar, V., and Steinbach, M. (2006). Compu-

DiscoveringNewGeneFunctionalitiesfromRandomPerturbationsofKnownGeneOntologicalAnnotations

115

tational approaches for protein function prediction: A

survey. Technical report, Minneapolis, MN, USA.

erez, A. J., Perez-Iratxeta, C., Bork, P., Thode, G., and An-

drade, M. A. (2004). Gene annotation from scientiﬁc

literature using mappings between keyword systems.

Bioinformatics, 20(13):2084–2091.

Perina, A., Lovato, P., Murino, V., and Bicego, M. (2010).

Biologically-aware latent dirichlet allocation (balda)

for the classiﬁcation of expression microarray. In Pat-

tern Recognition in Bioinformatics, pages 230–241.

Springer.

Pinoli, P., Chicco, D., and Masseroli, M. (2013). Enhanced

probabilistic latent semantic analysis with weighting

schemes to predict genomic annotations. In Bioinfor-

matics and Bioengineering (BIBE), 2013 IEEE 13th

International Conference on, pages 1–4. IEEE.

Pinoli, P., Chicco, D., and Masseroli, M. (2014a). Latent

dirichlet allocation based on gibbs sampling for gene

function prediction. In Proceedings of the Interna-

tional Conference on Computational Intelligence in

Bioinformatics and Computational Biology, pages 1–

7. IEEE Computer Society.

Pinoli, P., Chicco, D., and Masseroli, M. (2014b). Weight-

ing scheme methods for enhanced genome annota-

tion prediction. In Computational Intelligence Meth-

ods for Bioinformatics and Biostatistics (CIBB), 2013

10th International Meeting on, pages 76–89. LNBI,

Springer International Publishing.

Porteous, I., Newman, D., Ihler, A., Asuncion, A., Smyth,

P., and Welling, M. (2008). Fast collapsed gibbs sam-

pling for latent dirichlet allocation. In Proceedings

of the 14th ACM SIGKDD international conference

on Knowledge discovery and data mining, pages 569–

577. ACM.

Raychaudhuri, S., Chang, J. T., Sutphin, P. D., and Altman,

R. B. (2002). Associating genes with gene ontology

codes using a maximum entropy analysis of biomedi-

cal literature. Genome Research, 12(1):203–214.

Tanoue, J., Yoshikawa, M., and Uemura, S. (2002). The

genearound go viewer. Bioinformatics, 18(12):1705–

1706.

Tao, Y., Sam, L., Li, J., Friedman, C., and Lussier, Y. A.

(2007). Information theory applied to the sparse gene

ontology annotation network to predict novel gene

function. Bioinformatics, 23(13):i529–i538.

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

116
